Philips Halogen Lamp User manual

1
114.2 ±1.6
117.6 max.
∅11 max.
Dimensions in mm
Commercial Type Wattage Voltage Luminuous Base Average EOC
name intensity life
WVlm h
Halotone Economy 200T3Q/CL 200 220-240 2820 R7s 1500 519023
Halotone Economy 300T3Q/CL 300 220-240 4480 R7s 1500 519030
Halotone Economy 500T3Q/CL 500 220-240 7920 R7s 1500 519047
Packing data
Pinch 350°C
Bulb 900°C (minimum 250°C)
Single box packaging
Packing configuration Weight Dimensions Volume
kg cm m3
100x1 0.8 27.2 x 22.3 x 12.0 0.007
Maximum permissible temperatures
Halogen lamps Double-ended flood
Halotone Economy
Definition
Double-ended mains voltage
LINEARline halogen lamp with a
single-coil filament and a clear
tubular quartz bulb.The lamps are
equipped with a R7s lamp cap.
Features
The most important features
of this lamp are:
•single supports
•limited burning position
(+/- 15°)
•white caps
•arc preventing fuses
•average lamp life of 1500 hrs.
•colour temperature 2800 °K
•excellent colour rendering
(Ra= 100)
• dimmable.
Note
LAMPS SHOULD BE USED IN
LIGHTING EQUIPMENT WITH
A COVER GLASS.
Applications
LINEARline halogen lamps are
ideally suitable for flood-, up-,
task-lighting and wall-washing in
homes, shops, hotels/restaurants
and security lighting (outdoor).
