Incandescent

THE FILAMENT
Incandescent lamp filaments are made
of tungsten. Tungsten is a metal that
can operate at very high temperatures
without evaporating too quickly and
resulting in early lamp failure.
Incandescent filaments only
convert about 10 percent of the
energy used into visible light, so it
is necessary to use a material
that can withstand extremely
high temperatures. Most
lamps use a coiled
filament design, which
has been found to be
stronger and deliver
better performance.
THE GLASS BULB
The filament inside an
incandescent lamp
must be protected so that
oxygen does not reach it and
cause it to evaporate on con-
tact. Most incandescent lamps
are either vacuum-sealed or
gas-filled. It was discovered in
the early 1900s that the
introduction of gas inside the
bulb, or envelope, created a
pressure against the
filament. This pressure
allowed the filament to
burn hotter and last
longer. Most gas-filled
incandescent lamps today
use a mixture of argon
and nitrogen gases.
Incandescent Basics
The basic design of the incandescent
lamp has not changed much since the
late 1800s, when Thomas Alva Edison
successfully produced the first
operational electric light bulb.
These are the must-know
fundamental facts about
incandescent lamps and
the alternative
choices that are
available today.
Bulb
shapes
The size and shape of a lamp’s
bulb are designated by a letter(s)
and a number. The letter specifies
the shape of the bulb and the
number indicates the maximum
diameter in 1/8-inch increments.
Example: A G40 is a globe shape
which is 5 inches in diameter.
HOW IT WORKS
Just as a piece of metal being
blacksmithed or the molten glass at the
end of a blower’s rod heats to a brilliant
glow, so does the filament of an
incandescent lamp. The difference is
that electricity is used to heat the filament
instead of fire. This phenomenon is known
as incandescence.
THE BASE
Screw-type bases used on incandescent
lamps consist of three components: the
threaded screw section, the glass insulation
ring and the contact disc. The lead wires
which exit the glass bulb of the lamp are
attached to the base at two points. One
wire is soldered to the bottom of the
contact disc and the other to the top
edge of the screw section. The glass ring
acts as an insulation barrier between the
two points. This assembly completes the
circuit and the lamp is electrified once
the base is screwed into a socket and the
contact disc touches the center point of
the socket.
The base itself has nothing to do with the
seal of the bulb; it is a separate part of
the lamp that is attached with cement.
Typically, bases are made from aluminum
or brass. Brass bases tend to perform best
due to their compatibility with most socket
materials.
Base Types
AF
G PAR
PS R
S T
BCA
BR HX
Medium
E26
Medium
Skirted
Mogul
E40
Int.
E17
Cand.
E12
S.C. Bay. D.C. Bay.
Mog. End
Prong
Screw Terminal S14S Med. Side Prong

Key
Characteristics
Rated Voltage:
The lamp’s filament is designed to
operate within a specific volt-
age range in order for it to
deliver its intended light output.
Lamps that are burned at volt-
ages higher than their rating will
result in higher wattage, efficacy
(lumens per watt) and lumens.
Lamps operated below their
rated voltage will significantly
increase their life while reduc-
ing their wattage, efficacy and
lumen output.
Lumen Maintenance:
As the filament of an incandes-
cent lamp burns, the tungsten is
slowly evaporating and deposit-
ing itself on the interior wall of
the bulb. This creates the black
coating seen after a bulb has
been in use for a while.
Additionally, as the filament
evaporates, the lumen output
decreases until it reaches the end
of its life when the wire breaks. It is
recommended that a “group
replacement” or relamping is
conducted once a number of
lamps have failed or a notice-
able decrease in light output has
taken place.
Burning Position:
For the most part, incandescent
lamps can be burned in any
position. However, take note and
observe a lamp manufacturer’s
recommendations for use.
Light Output vs. Life
The life of an incandescent lamp
and its lumen output are both
determined by the filament design.
These characteristics represent a
give-and-take relationship—one must
be sacrificed to improve the other.
There are many choices available to
the consumer, each one marketed
for a particular application, purpose
or feature.
It is important to determine your
customer’s priorities and needs
when recommending a light source
purchase. Is the lamp going to be
placed in a hard-to-reach area,
making long life more important than
light output? Or will it be a workhorse,
illuminating important tasks and
needing maximum lumens?
The Federal Trade Commission
instituted new packaging labeling
requirements in 1992 to explain the
function of a lamp better to the
purchaser. So if you know your way
around this labeling, you can suggest
optimum choices for your customer,
or explain the features to customers
to allow them to make their own
educated decisions.
These examples of actual labels illustrate the differences between two stan-
dard household “A” lamps. One is marketed for longer life, while the other is
marketed for greater lumen output. Note the life/light tradeoffs.
High Lumen Output Longer Lamp Life

Incandescent Lamps
9
incandescent lamps
Watts Bulb Base
Satco
Product
Number Lamp Code Volts Finish
Master/
Inner
Carton Pkg. Type Filament
Avg.
Rated
Hours Lumens MOL Notes
Visit our website at www.satco.com
When using a 130 Volt Lamp on a 120 Volt line, life is extended by approx. 2.5 times and lumens are reduced approx. 20%
3B9 1/2 Cand. S3659 3BA9 1/2/Flicker 120 Clear 500/25 Box Neon 1000 - 3 1/2”
S3759 3BA9 1/2/Flicker 120 Clear 120/12 CD/1 Neon 1000 - 3 1/2”
CA5 1/2 Cand S3661
3CA5 1/2/ Flicker 120 Clear 500/25 Box Neon 1000 - 3 1/4”
S3761
3CA5 1/2/ Flicker 120 Clear 120/12 CD/1 Neon 1000 - 3 1/4”
CA8 Cand S3656 3CA8/Flicker 120 Clear 500/25 Box Neon 1000 - 3 7/8”
S3756 3CA8/Flicker 120 Clear 120/12 CD/1 Neon 1000 - 3 7/8”
CA9 Med. S3660 3CA9/Flicker 120 Clear 500/25 Box Neon 1000 - 4 9/16”
S3760 3CA9/Flicker 120 Clear 120/12 CD/1 Neon 1000 - 4 9/19”
CA10 Med S3657 3CA10/Flicker 120 Clear 500/25 Box Neon 1000 - 4 1/16”
S3757 3CA10/Flicker 120 Clear 120/12 CD/1 Neon 1000 - 4 1/16”
S6 Cand S4567 3S6/5 130 Clear 10 Sleeve/10 C-6 1500 10 1 7/8”
4C7 Cand S3680 4C7 120 Clear
2000/50 Bulk C-7A 3000 16 2 1/8”
S3797 4C7 120 Clear 400/20 CD/2 C-7A 3000 16 2 1/8”
S4724 4C7 120 Clear 48/12 CD/4 C-7A 3000 16 2 1/8”
S3681 4C7/W 120 White
2000/50 Bulk C-7A 3000 8 2 1/8”
5Cand. S4520 5C7 120 Silicone
Tail
144/12 CD/2 C-7A 1000 10 2 1/2 +
6S6 Cand. S4568 6S6/6V 6 Clear 10
Sleeve/10 C-6 1500 40 1 7/8”
S4569 6S6/12V 12 Clear 10
Sleeve/10 C-6 1500 40 1 7/8”
S4570 6S6/24V 24 Clear 10
Sleeve/10 C-6 1500 40 1 7/8”
S4571 6S6/48V 48 Clear 10
Sleeve/10 C-6 1500 40 1 7/8”
S3900 6S6 130 Clear 120/10
Sleeve/10 C-7A 2500 30 1 7/8”
S4717 6S6 130 Clear 120/12 CD/2 C-7A 2500 30 1 7/8”
S4572 6S6/230V 230 Clear 10 Sleeve/10 C-7A 1500 25 1 7/8”
DC Bay. S3901 6S6/DC 130 Clear 120/10 Sleeve/10 C-7A 2500 30 1 7/8”
B9 1/2
Cand.
CA5 1/2
Cand.
CA8
Cand.
CA9
Med.
CA10
Med.
S6
Cand.
C7
Cand.
S6
DC Bay.
C7 Tail
Cand.

Incandescent Lamps
incandescent lamps
10
Watts Bulb Base
Satco
Product
Number Lamp Code Volts Finish
Master/
Inner
Carton Pkg. Type Filament
Avg.
Rated
Hours Lumens MOL Notes
Customer Service 1-800-43-SATCO
When using a 130 Volt Lamp on a 120 Volt line, life is extended by approx. 2.5 times and lumens are reduced approx. 20%
7C7 Cand. S3691 7C7 120 Clear
2000/25 Bulk C-7A 3000 35 2 1/8”
S3791 7C7 120 Clear 400/20 CD/2 C-7A 3000 35 2 1/8”
S4725 7C7 120 Clear 48/12 CD/4 C-7A 3000 35 2 1/8”
S3902 7C7 130 Clear 120/10
Sleeve/10 C-7A 2500 35 1 7/8”
S3692 7C7/W 120 White 2000/25 Bulk C-7A 3000 20 2 1/8”
S3792 7C7/W 120 White 400/20 CD/2 C-7A 3000 20 2 1/8”
S4726 7C7/W 120 White 48/12 CD/4 C-7A 3000 20 2 1/8”
CA-10 Cand. S3866 7CA10/12V 12 Clear 500/25 Box CC-2V 1500 65 4 1/4”
7.5 B9 1/2 Cand. S4994 7 1/2B9 1/2
Showroom
120 Clear 500/25 Bulk C-7A 3000 37 3 1/2”
C9 1/2 Cand. S4988 7 1/2C9 1/2
Showroom
120 Clear 500/25 Bulk C-7A 3000 37 3 1/2”
CA5 Cand. S3241 7 1/2CA5 120 Clear 2000/50 Box C-7A 1500 40 2 7/8”
S3242 7 1/2CA5/F 120 Frosted 2000/50 Box C-7A 1500 35 2 7/8”
S3243 7 1/2CA5/FY 120 Fr. Yellow 2000/50 Box C-7A 1500 35 2 7/8”
S11 Med. S3606 7 1/2S11 120 Clear
1000/25 Sleeve C-7A 2500 40 2 1/4”
S3794 7 1/2S11 120 Clear 240/20 CD/1 C-7A 2500 40 2 1/4”
S3607 7 1/2S11/W 120 Gloss Wht 1000/25 Sleeve C-7A 2500 20 2 1/4”
S3795 7 1/2S11/W 120 Gloss Wht 240/20 CD/1 C-7A 2500 20 2 1/4”
S3608 7 1/2S11/B 120 Cer. Blue 1000/25 Sleeve C-7A 2500 - 2 1/4”
S4508 7 1/2S11/B 120
Cer. Blue 120/10 CD/1 C-7A 2500 - 2 1/4”
S3609 7 1/2S11/G 120 Cer. Green 1000/25 Sleeve C-7A 2500 - 2 1/4”
S4509 7 1/2S11/G 120 Cer. Green 120/10 CD/1 C-7A 2500 - 2 1/4”
S3610 7 1/2S11/O 120
Cer. Orange 1000/25 Sleeve C-7A 2500 - 2 1/4”
S4510 7 1/2S11/O 120 Cer. Orange 120/10 CD/1 C-7A 2500 - 2 1/4”
S3611 7 1/2S11/R 120 Cer. Red 1000/25 Sleeve C-7A 2500 - 2 1/4”
S4511 7 1/2S11/R 120 Cer. Red 120/10 CD/1 C-7A 2500 - 2 1/4”
S4512 7 1/2S11/Y 120 Cer. Yellow 120/10 CD/1 C-7A 2500 - 2 1/4”
C7
Cand.
CA-10
Cand.
B9 1/2
Cand.
C9 1/2
Cand.
CA5
Cand.
S11
Med.

Incandescent Lamps
11
incandescent lamps
Watts Bulb Base
Satco
Product
Number Lamp Code Volts Finish
Master/
Inner
Carton Pkg. Type Filament
Avg.
Rated
Hours Lumens MOL Notes
Have a special requirement? Visit our website at www.satco.com
When using a 130 Volt Lamp on a 120 Volt line, life is extended by approx. 2.5 times and lumens are reduced approx. 20%
10 C7 Cand. S3903 10C7 130 Clear 120/10
Sleeve/10 C-7A 2500 60 2 1/8”
DC Bay. S3904 10C7/DC 130 Clear 120/10 Sleeve/10 C-7A 2500 60 2 1/8”
CA7 Cand. S3272 10CA7 120 Clear 1000/25 Box C-7A 1500 80 3”
S3276 10CA7/F 120 Frosted 1000/25 Box C-7A 1500 70 3”
G8 Cand. S3864 10G8/W 120 Glossy
White
1000/25 Box C-7A 1500 50 1 7/8”
G12 1/2 Cand. S3844 10G12 1/2 120 Clear 500/25 Box C-7A 1500 60 2 3/8”
S3830 10G12 1/2/W 120 Sat. White 500/25 Box C-7A 1500 50 2 3/8”
S3755
10G12 1/2/W 120 Sat. White 120/10 CD/2 C-7A 1500 60 2 3/8”
S3833 10G12 1/2/R 120
Trans Red 500/25 Box C-7A 1500 - 2 3/8”
S3834 10G12 1/2/B 120
Trans Blue 500/25 Box C-7A 1500 - 2 3/8”
S3835
10G12 1/2/G 120 Trans Green 500/25 Box C-7A 1500 - 2 3/8”
S3836 10G12 1/2/A 120
Trans Amber 500/25 Box C-7A 1500 - 2 3/8”
S3837 10G12 1/2/PK 120
Trans Pink 500/25 Box C-7A 1500 - 2 3/8”
S11 Int. S3621 10S11/N
115/125 Clear 600/10 Box C-7A 1500 80 2 3/8”
S3622 10S11N/F 115/125 Frosted 600/10 Box CC-2V 1500 80 2 3/8”
11 S14 Med. S3965 11S14 130 Clear 120/4 Sleeve/4 CC-9 2500 80 3 1/2”
S4565 11S14 130 Clear 120/10 CD/1 CC-9 2500 80 3 1/2”
S3966 11S14/F 130 Frosted 120/4 Sleeve/4 CC-9 2500 65 3 1/2”
S4566 11S14/F 130 Frosted 120/10 CD/1 CC-9 2500 65 3 1/2”
S3963 11S14/B 130 Cer Blue 120/4 Sleeve/4 CC-9 2500 - 3 1/2”
S4563 11S14/B 130 Cer Blue 120/10 CD/1 CC-9 2500 - 3 1/2”
S3962 11S14/G 130
Cer Green 120/4 Sleeve/4 CC-9 2500 - 3 1/2”
S4562 11S14/G 130 Cer Green 120/10 CD/1 CC-9 2500 - 3 1/2”
S3964 11S14/O 130 Cer Orange 120/4 Sleeve/4 CC-9 2500 - 3 1/2”
S4564 11S14/O 130 Cer Orange 120/10 CD/1 CC-9 2500 - 3 1/2”
S3961 11S14/R 130 Cer Red 120/4 Sleeve/4 CC-9 2500 - 3 1/2”
S4561 11S14/R 130 Cer Red 120/10 CD/1 CC-9 2500 - 3 1/2”
S3960 11S14/Y 130 Cer Yellow 120/4 Sleeve/4 CC-9 2500 - 3 1/2”
S4560 11S14/Y 130 Cer Yellow 120/10 CD/1 CC-9 2500 - 3 1/2”
C7
Cand.
CA7
Cand.
C7
DC Bay.
G8
Cand.
G12 1/2
Cand.
S11
Int.
S14
Med.

Incandescent Lamps
incandescent lamps
12
Watts Bulb Base
Satco
Product
Number Lamp Code Volts Finish
Master/
Inner
Carton Pkg. Type Filament
Avg.
Rated
Hours Lumens MOL Notes
Don’t see the lamp you need? Call Customer Service 1-800-43-SATCO
When using a 130 Volt Lamp on a 120 Volt line, life is extended by approx. 2.5 times and lumens are reduced approx. 20%
12 S8 SC Bay S3623 93 12 Clear 600/10 Box C-6 200 190 2”
S3723 93 12 Clear 240/20 CD/2 C-6 300 190 2”
15 A15 Med. S3948 15A15 130 Clear 120 2pk C-9 2500 100 3 1/2”
S3949 15A15/F 130 Frosted 120 2pk C-9 2500 100 3 1/2”
B8 Cand. S3345 15B8/Petite 130 Clear 500/25 Box C-7A 1500 114 3”
B9 1/2 Cand. S3230 15B9 1/2 120 Clear 500/25 Box C-7A 1500 114 3 1/2”
A3620 15B9 1/2 130 Clear 500/25 Box C-7A 2500 114 3 1/2”
S3291 15B9 1/2/F 120 Frosted 500/25 Box C-7A 1500 114 3 1/2”
CA8 Cand. S3273 15CA8 120 Clear 500/25 Box C-7A 1500 100 3 5/8”
S3773 15CA8 120 Clear 120/10 CD/2 C-7A 1500 100 3 5/8”
A3673 15CA8 130 Clear 500/25 Box C-7A 2500 95 3 5/8”
A3573 15CA8 130 Clear 120/10 CD/2 C-7A 2500 95 3 5/8”
S3277 15CA8/F 120 Frosted 500/25 Box C-7A 1500 95 3 5/8”
S3777 15CA8/F 120 Frosted 120/10 CD/2 C-7A 1500 95 3 5/8”
A3677 15CA8/F 130 Frosted 500/25 Box C-7A 2500 90 3 5/8”
A3577 15CA8/F 130 Frosted 120/10 CD/2 C-7A 2500 90 3 5/8”
CA10 Cand S3867 15CA10/12V 12 Clear 500/25 Box CC-2V 1500 150 4 1/4”
F10 Cand. S3360 15F10 120 Clear 500/25 Box C-7A 1500 110 3 1/16”
S2760 15F10 120 Clear 120/12 CD/2 C-7A 1500 110 3 1/16”
S3361 15F10/W 120 White 500/25 Box C-7A 1500 90 3 1/16”
S2761 15F10/W 120 White 120/2 CD/2 C-7A 1500 90 3 1/16”
G12 1/2 Cand. S3845 15G12 1/2 120 Clear 500/25 Box C-7A 1500 100 2 3/8”
G12 1/2
Pear
Cand. S3879 15G12 1/2/W 120 Sat. White 500/25 Box C-7A 1500 100 2 3/8”
S3750 15G12 1/2/W 120 Sat. White 120/10 CD/2 C-7A 1500 100 2 3/8”
S8
SC Bay.
A15
Med.
B8
Cand.
B9 1/2
Cand.
CA8
Cand.
CA10
Cand.
F10
Cand.
G12 1/2
Cand.
G12 1/2
Pear
Cand.

Incandescent Lamps
13
incandescent lamps
Watts Bulb Base
Satco
Product
Number Lamp Code Volts Finish
Master/
Inner
Carton Pkg. Type Filament
Avg.
Rated
Hours Lumens MOL Notes
Visit our website at www.satco.com
When using a 130 Volt Lamp on a 120 Volt line, life is extended by approx. 2.5 times and lumens are reduced approx. 20%
15
G16 1/2 Cand. S3821 15G16 1/2 120 Clear 500/25 Box C-7A 1500 114 3”
S3726 15G16 1/2 120 Clear 120/10 CD/2 C-7A 1500 114 3”
A3921 15G16 1/2 130 Clear 500/25 Box C-7A 2500 98 3”
A3521 15G16 1/2 130 Clear 120/10 CD/2 C-7A 2500 98 3”
S3824 15G16 1/2/W 120
Sat. White 500/25 Box C-7A 1500 94 3”
S3752 15G16 1/2/W 120
Sat. White 120/10 CD/2 C-7A 1500 94 3”
A3924 15G16 1/2/W 130
Sat. White 500/25 Box C-7A 2500 83 3”
A3524 15G16 1/2/W 130
Sat. White 120/10 CD/2 C-7A 2500 83 3”
S3236 15G16 1/2/W 120
Gloss Wht 500/25 Box C-7A 1500 94 3”
S11 Int. S3628 15S11/N
115/
125
Clear 600/10 Box C-7A 1500 100 2 3/8”
T4 1/2 Cand. S3913 15T4 1/2/C 130 Clear 10 Sleeve/10 C-7A 1000 90 1 1/2” 5
T6 Cand. S3910 15T6 130 Clear 120/10 Sleeve/10 C-5A 2500 95 3 1/16”
S3912 15T6/145V 145 Clear 120/10 Sleeve/10 C-5A 2500 80 3 1/16”
S3315 15T6/F 120 Frost 500/25 Sleeve C-5A 2500 90 4” 5
S3715 15T6/F 120 Frost 72/6 CD/2 C-5A 2500 90 4” 5
T7 Cand. S3905 15T7C 130 Clear 120/10 Sleeve/10 C-5A 2500 95 2 1/4”
S4718 15T7C 130 Clear 120/12 CD/1 C-5A 2500 95 2 1/4”
Int. S3911 15T7/N 130 Clear 120/10 Sleeve/10 C-5A 2500 95 2 1/4”
S4722 15T7/N 130 Clear 120/12 CD/1 C-5A 2500 95 2 1/4”
DC Bay. S3906 15T7/DC 130 Clear 120/10 Sleeve/10 C-5A 2500 95 2 1/4”
S4719 15T7/DC 130 Clear 120/12 CD/1 C-5A 2500 95 2 1/4”
20 R11 1/2
SC Bay S1383 1383 12-13 Frosted 600/10 Box C-6 600 200 2 1/2”
S
HATTER
PROO
F
S1383/TF 1383/TF 12-13 Frst /
ShatterPrf
10 Box C-6 600 200 2 1/2” 4
T6 1/2
DC Bay S3297 20T6 1/2DC 130 Clear 500/25 Box C-6 1500 150 5 3/8”
S3298
20T6 1/2DC/F 130 Frosted 500/25 Box C-6 1500 140 5 3/8”
Int. S3280 20T6 1/2N 130 Clear 500/25 Box C-6 1500 150 5 3/8”
S3281 20T6 1/2N/F 130 Frosted 500/25 Box C-6 1500 140 5 3/8”
24 RP11
SC Bay S3624 1133 6-8 Clear 600/10 Box C-6 300 400 2 1/4”
S3724 1133 6-8 Clear 240/20 CD/2 C-6 300 400 2 1/4”
G16 1/2
Cand.
S11
Int.
T6
Cand.
T7
Cand.
T7
Int.
T7
DC Bay.
R11 1/2
SC Bay.
T6 1/2
DC Bay.
T6 1/2
Int.
RP11
SC Bay.
T4 1/2
Cand.

Incandescent Lamps
incandescent lamps
14
Watts Bulb Base
Satco
Product
Number Lamp Code Volts Finish
Master/
Inner
Carton Pkg. Type Filament
Avg.
Rated
Hours Lumens MOL Notes
Customer Service 1-800-43-SATCO
When using a 130 Volt Lamp on a 120 Volt line, life is extended by approx. 2.5 times and lumens are reduced approx. 20%
25 A15 Med. S3814 25A15/CL 130 Clear 500/25 Box C-9 2500 130 3 1/2”
S3815 25A15/F 130 Frosted 500/25 Box C-9 2500 120 3 1/2”
S
HATTER
PROO
F
S4880 25A15/TF 130 Frost
ShatterPrf
500/25 Box C-9 2500 120 3 1/2” 4
A19 Med. S6040 25A19/CL 120 Clear 120 2pk C-9 2500 185 4 1/8”
S3940 25A19/CL 130 Clear 120 2pk CC-6 2500 185 4 1/8”
S6050 25A19/F 120 Frosted 120 2pk C-9 2500 185 4 1/8”
S3950 25A19/F 130 Frosted 120 2pk CC-6 2500 185 4 1/8”
S6080 25A/TR 130 Trans Red 24/12 Sleeve C-9 1000 - 4 1/8”
S6081 25A/TG 130 Trans Green 24/12 Sleeve C-9 1000 - 4 1/8”
S6082 25A/TB 130 Trans Blue 24/12 Sleeve C-9 1000 - 4 1/8”
S6083 25A/TY 130 Trans Yellow 24/12 Sleeve C-9 1000 - 4 1/8”
S6090 25A/R 130 Cer Red 24/12 Sleeve C-9 1000 - 4 1/8”
S6091 25A/G 130 Cer Green 24/12 Sleeve C-9 1000 - 4 1/8”
S6092 25A/B 130 Cer Blue 24/12 Sleeve C-9 1000 - 4 1/8”
S6093 25A/Y 130 Cer Yellow 24/12 Sleeve C-9 1000 - 4 1/8”
S5010 25A19/F/12V 12 Frosted 120/6 Box C-6 1500 250 4 1/8”
S5020 25A19/F/34V 34 Frosted 120/6 Box C-6 1500 250 4 1/8”
S5050 25A19/F/220V 220 Frosted 120 2pk CC-2F 2500 180 4 1/8”
B8 Cand. S3346 25B8/Petite 130 Clear 500/25 Box CC-2V 1500 212 3”
B9 1/2 Cand. S3282 25B9 1/2 120 Clear 500/25 Box CC-2V 1500 212 3 1/2”
S3782 25B9 1/2 120 Clear 120/10 CD/2 CC-2V 1500 212 3 1/2”
S4995 KR25B9 1/2 120 Clear 500/25 Box CC-2V 2500 212 3 7/8” 1
S3716 KR25B9 1/2 120 Clear 120/10 CD/2 CC-2V 2500 212 3 7/8” 1
A3682 25B9 1/2 130 Clear 500/25 Box CC-2V 2500 193 3 1/2”
A3582 25B9 1/2 130 Clear 120/10 CD/2 CC-2V 2500 193 3 1/2”
S3285 25B9 1/2/F 120 Frosted 500/25 Box CC-2V 1500 212 3 1/2”
S3785 25B9 1/2/F 120 Frosted 120/10 CD/2 CC-2V 1500 212 3 1/2”
A3685 25B9 1/2/F 130 Frosted 500/25 Box CC-2V 2500 193 3 1/2”
A3585 25B9 1/2/F 130 Frosted 120/10 CD/2 CC-2V 2500 193 3 1/2”
S3288 25B9 1/2/W 120 Gloss Wht 500/25 Box CC-2V 1500 180 3 1/2”
S3788 25B9 1/2/W 120 Gloss Wht 120/10 CD/2 CC-2V 1500 180 3 1/2”
A3688 25B9 1/2/W 130 Gloss Wht 500/25 Box CC-2V 2500 163 3 1/2”
A3588 25B9 1/2/W 130 Gloss Wht 120/10 CD/2 CC-2V 2500 163 3 1/2”
S3218 25B9 1/2/B 120 Trans Blue 500/25 Box CC-2V 1500 - 3 1/2”
S3219 25B9 1/2/R 120 Trans Red 500/25 Box CC-2V 1500 - 3 1/2”
S3813 25B9 1/2/A 120 Trans Amber 500/25 Box CC-2V 1500 - 3 1/2”
A15
Med.
A19
Med.
B8
Cand.
B9 1/2
Cand.

Incandescent Lamps
15
incandescent lamps
Watts Bulb Base
Satco
Product
Number Lamp Code Volts Finish
Master/
Inner
Carton Pkg. Type Filament
Avg.
Rated
Hours Lumens MOL Notes
Have a special requirement? Visit our website at www.satco.com
When using a 130 Volt Lamp on a 120 Volt line, life is extended by approx. 2.5 times and lumens are reduced approx. 20%
25 B9 1/2
E14/Euro S3390 25B9 1/2 120 Clear 500/25 Box CC-2V 1500 210 3 1/2”
S4711 25B9 1/2 120 Clear 120/12 CD/2 CC-2V 1500 212 3 1/2”
S3380 25B9 1/2/F 120 Frosted 500/25 Box CC-2V 1500 200 3 1/2”
S4714 25B9 1/2/F 120 Frosted 120/10 CD/2 CC-2V 1500 200 3 1/2”
B10 Cand. S2970 25B10/VLX 120 Nat Day
Frost
50/10 CD/1 CC-2V 2000 220 3 7/8” 3
S3386 25B10/220V 220 Clear 500/25 Box CC-2F 1000 200 3 3/4”
E14/Euro S3393 25B10/220V 220 Clear 500/25 Box CC-2F 1000 200 3 3/4”
B11 Med. S3231 25B11 120 Clear 500/25 Box CC-2V 1500 210 3 7/8”
S3731 25B11 120 Clear 120/10 CD/2 CC-2V 1500 210 3 7/8”
S4468 KR25B11 120 Clear 500/25 Box CC-2V 2500 212 3 7/8” 1
A3631 25B11 130 Clear 500/25 Box CC-2V 2500 210 3 7/8”
A3531 25B11 130 Clear 120/10 CD/2 CC-2V 2500 210 3 7/8”
S3234 25B11/F 120 Frosted 500/25 Box CC-2V 1500 200 3 7/8”
S3734 25B11/F 120 Frosted 120/10 CD/2 CC-2V 1500 200 3 7/8”
A3634 25B11/F 130 Frosted 500/25 Box CC-2V 2500 200 3 7/8”
A3534 25B11/F 130 Frosted 120/10 CD/2 CC-2V 2500 200 3 7/8”
S3237 25B11/W 120 White 500/25 Box CC-2V 1500 150 3 7/8”
S3737 25B11/W 120 White 120/10 CD/2 CC-2V 1500 150 3 7/8”
A3637 25B11/W 130 White 500/25 Box CC-2V 2500 160 3 7/8”
A3537 25B11/W 130 White 120/10 CD/2 CC-2V 2500 160 3 7/8”
C11 Cand. S3403 25C11 120 Satin Spun 500/25 Box C-7A 4000 160 4”
S2703 25C11 120 Satin Spun 120/10 CD/1 C-7A 4000 160 4”
S3406 25C11/A 120 Amber Spun 500/25 Box C-7A 4000 - 4”
S2706 25C11/A 120 Amber Spun 120/10 CD/1 C-7A 4000 - 4”
C15 Med. S3413 25C15 120 Satin Spun 300/25 Box C-9 4000 160 4 1/2”
S2713 25C15 120 Satin Spun 120/12 CD/1 C-9 4000 160 4 1/2”
CA8 Cand. S3274 25CA8 120 Clear 500/25 Box CC-2V 1500 210 3 5/8”
S3774 25CA8 120 Clear 120/10 CD/2 CC-2V 1500 210 3 5/8”
A3674 25CA8 130 Clear 500/25 Box CC-2V 2500 210 3 5/8”
A3574 25CA8 130 Clear 120/10 CD/2 CC-2V 2500 210 3 5/8”
S3278 25CA8/F 120 Frosted 500/25 Box CC-2V 1500 200 3 5/8”
S3778 25CA8/F 120 Frosted 120/10 CD/2 CC-2V 1500 200 3 5/8”
A3678 25CA8/F 130 Frosted 500/25 Box CC-2V 2500 200 3 5/8”
A3578 25CA8/F 130 Frosted 120/10 CD/2 CC-2V 2500 200 3 5/8”
B9 1/2
E14/Euro
B10
Cand.
B10
E14/Euro
B11
Med.
C11
Cand.
C15
Med.
CA8
Cand.

Incandescent Lamps
incandescent lamps
16
Watts Bulb Base
Satco
Product
Number Lamp Code Volts Finish
Master/
Inner
Carton Pkg. Type Filament
Avg.
Rated
Hours Lumens MOL Notes
Don’t see the lamp you need? Call Customer Service 1-800-43-SATCO
When using a 130 Volt Lamp on a 120 Volt line, life is extended by approx. 2.5 times and lumens are reduced approx. 20%
25 CA9 1/2 Cand. S4465
KR25CA9 1/2 120 Clear 500/25 Box CC-2V 2500 212 3 15/16” 1
CA10 Cand. S3868 25CA10/12V 12 Clear 500/25 Box CC-2V 1500 250 4 1/4”
Med. S3264 25CA10 120 Clear 500/25 Box
CC-2V 1500 210 4 1/4”
S3764 25CA10 120 Clear 120/10 CD/2
CC-2V 1500 210 4 1/4”
A3664 25CA10 130 Clear 500/25 Box CC-2V 2500 210 4 1/4”
A3564 25CA10 130 Clear 120/10 CD/2 CC-2V 2500 210 4 1/4”
S3869 25CA10/12V 12 Clear 500/25 Box CC-2V 1500 250 4 1/4”
S3267 25CA10/F 120 Frosted 500/25 Box CC-2V 1500 200 4 1/4”
S3767 25CA10/F 120 Frosted 120/10 CD/2 CC-2V 1500 200 4 1/4”
A3667 25CA10/F 130 Frosted 500/25 Box CC-2V 2500 200 4 1/4”
A3567 25CA10/F 130 Frosted 120/10 CD/2 CC-2V 2500 200 4 1/4”
F10 Cand. S3371 25F10 120 Clear 500/25 Box C-7A 1500 195 3 1/16”
S2771 25F10 120 Clear 120/12 CD/2 C-7A 1500 195 3 1/16”
S3372 25F10/W 120 White 500/25 Box C-7A 1500 185 3 1/16”
S2772 25F10/W 120 White 120/12 CD/2 C-7A 1500 185 3 1/16”
S3373 25F10/AU 120 Aurora 500/25 Box C-7A 1500 190 3 1/16”
S2773 25F10/AU 120 Aurora 120/12 CD/2 C-7A 1500 190 3 1/16”
S3374 25F10/A 120 Amber 500/25 Box C-7A 1500 - 3 1/16”
S2774 25F10/A 120 Amber 120/12 CD/2 C-7A 1500 - 3 1/16”
F15 Med. S3363 25F15 120 Clear 300/25 Box CC-9 1500 225 4 1/2”
S2763 25F15 120 Clear 120/12 CD/2 CC-9 1500 225 4 1/2”
S3364 25F15/W 120 White 300/25 Box CC-9 1500 195 4 1/2”
S2764 25F15/W 120 White 120/12 CD/2 CC-9 1500 195 4 1/2”
S3365 25F15/AU 120 Aurora 300/25 Box CC-9 1500 200 4 1/2”
S2765 25F15/AU 120 Aurora 120/10 CD/2 CC-9 1500 200 4 1/2”
S3366 25F15/A 120 Amber 300/25 Box CC-9 1500 - 4 1/2”
G12 1/2 Cand. S3846 25G12 1/2 120 Clear 500/25 Box C-7A 1500 180 2 3/8”
G12 1/2
Pear
Cand. S3863 25G12 1/2/W 120 Sat.
White
500/25 Box C-7A 1500 180 2 3/8”
S3751 25G12 1/2/W 120 Sat.
White
120/10 CD/2 C-7A 1500 202 2 3/8”
CA9 1/2
Cand.
CA10
Cand.
CA10
Med.
F10
Cand.
F15
Med.
G12 1/2
Cand.
G12 1/2
Pear
Cand.

Incandescent Lamps
17
incandescent lamps
Watts Bulb Base
Satco
Product
Number Lamp Code Volts Finish
Master/
Inner
Carton Pkg. Type Filament
Avg.
Rated
Hours Lumens MOL Notes
Visit our website at www.satco.com
When using a 130 Volt Lamp on a 120 Volt line, life is extended by approx. 2.5 times and lumens are reduced approx. 20%
25 G16 1/2 Cand. S3822 25G16 1/2 120 Clear 500/25 Box C-7A 1500 232 3”
S3727 25G16 1/2 120 Clear 120/10 CD/2 C-7A 1500 232 3”
S4471 KR25G16 1/2 120 Clear 500/25 Box CC-2V 2500 212 3”
A3922 25G16 1/2 130 Clear 500/25 Box C-7A 2500 186 3”
A3522 25G16 1/2 130 Clear 120/10 CD/2 C-7A 2500 186 3”
S3825 25G16 1/2/W 120 Sat. White 500/25 Box C-7A 1500 202 3”
S3753 25G16 1/2/W 120 Sat. White 120/2 CD/2 C-7A 1500 202 3”
A3925 25G16 1/2/W 130 Sat. White 500/25 Box C-7A 2500 162 3”
A3525 25G16 1/2/W 130 Sat. White 120/10 CD/2 C-7A 2500 162 3”
S3260 25G16 1/2/W 120 Gloss Wht 500/25 Box C-7A 1500 175 3”
S2975 25G16 1/2/VLX 120 Nat Day
Frost
50/10 CD/1 CC-2V 2000 220 3” 3
S3244 25G16 1/2/SL 120 Silver
Crown
500/25 Box
CC-2V 1500 232 3”
Med. S3838 25G16 1/2 120 Clear 500/25 Box
CC-2V 1500 210 3 1/4”
S3841 25G16 1/2 120 Gloss Wht 500/25 Box CC-2V 1500 160 3 1/4”
G18 1/2 Med. S3887 25G18 1/2 120 Clear 250/25 Box C-9 1500 158 3 1/2”
S3827 25G18 1/2/W 120 Gloss Wht 250/25 Box C-9 1500 120 3 1/2”
G25 Med. S3447 25G25 120 Clear 72/6 Box CC-9 2500 212 4 3/8”
A3647 25G25 130 Clear 72/6 Box CC-9 3000 193 4 3/8”
S3440 25G25/W 120 Gloss Wht 72/6 Box CC-9 2500 187 4 3/8”
A3640 25G25/W 130 Gloss Wht 72/6 Box CC-9 3000 167 4 3/8”
S3860 25G25/SL 120 Silver
Crown
72/6 Box CC-9 1500 170 4 3/8”
G30 Med. S3651 25G30 120 Clear 72/6 Box CC-9 2500 212 5 1/8”
S3653 25G30/W 120 Gloss Wht 72/6 Box CC-9 2500 187 5 1/8”
G40 Med. S3010 25G40 120 Clear 24/6 Box C-9 4000 120 6 3/4”
S3000 25G40/W 120
Gloss Wht 24/6 Box C-9 4000 110 6 3/4”
HX10 1/2 Cand. S3744 25HX10 1/2 120 Clear 120/12 CD/2 C-7A 1500 175 4 15/16”
S3746 25HX10 1/2/F 120 Frosted 120/12 CD/2 C-7A 1500 175 4 15/16”
S3748 25HX10 1/2/AU 120 Aurora 120/12 CD/2 C-7A 1500 175 4 15/16”
G16 1/2
Cand.
G16 1/2
Med.
G18 1/2
Med.
G25
Med.
G30
Med.
G40
Med.
HX10 1/2
Cand.

Incandescent Lamps
incandescent lamps
18
Watts Bulb Base
Satco
Product
Number Lamp Code Volts Finish
Master/
Inner
Carton Pkg. Type Filament
Avg.
Rated
Hours Lumens MOL Notes
Customer Service 1-800-43-SATCO
When using a 130 Volt Lamp on a 120 Volt line, life is extended by approx. 2.5 times and lumens are reduced approx. 20%
25 R14 Int. S3205 25R14N 120 Clear 500/25 Box CC-2V 1500 135 2 5/8”
S4700 25R14N 120 Clear 120/10 CD/1 CC-2V 1500 135 2 5/8”
R14
Stubby
Med. S3601 25R14 120 Clear 500/25 Box CC-2V 1500 135 2 1/4”
R14 Med. S3604 25R14 120 Clear 500/25 Box CC-2V 1500 135 2 5/8”
S4704 25R14 120 Clear 120/10 CD/1 CC-2V 1500 135 2 5/8”
S11 Int. S3630 25S11/N 115/
125
Clear 600/10 Box CC-2V 1500 210 2 3/8”
T6 1/2 DC Bay S3248 25T6 1/2/DC 130 Clear 500/25 Box C-8 1500 180 5 3/8”
S3711 25T6 1/2/DC 130 Clear 120/10 CD/1 C-8 1500 180 5 3/8”
S3249
25T6 1/2/DC/F 130 Frosted 500/25 Box C-8 1500 170 5 3/8”
S3713
25T6 1/2/DC/F 130 Frosted 120/10 CD/1 C-8 1500 170 5 3/8”
Int. S3222 25T6 1/2N 130 Clear 500/25 Box C-8 1500 180 5 3/8”
S3708 25T6 1/2N 130 Clear 120/10 CD/1 C-8 1500 180 5 3/8”
S3223 25T6 1/2N/F 130 Frosted 500/25 Box C-8 1500 170 5 3/8”
S3709 25T6 1/2N/F 130 Frosted 120/10 CD/1 C-8 1500 170 5 3/8”
T8 Cand. S3907 25T8/C 130 Clear 120/10 Sleeve/10 C-5A 2500 190 2 5/8”
Int. S3908 25T8/N 130 Clear 120/10 Sleeve/10 C-5A 2500 190 2 5/8”
S4720 25T8/N 130 Clear 120/12 CD/1 C-5A 2500 190 2 5/8”
DC Bay. S3909 25T8/DC 130 Clear 120/10 Sleeve/10 C-5A 2500 190 2 5/8”
S4721 25T8/DC 130 Clear 120/12 CD/1 C-5A 2500 190 2 5/8”
T10 Med. S3250 25T10 120 Clear 500/25 Box C-5V 1000 210 5 3/16”
S3700 25T10 120 Clear 120/10 CD/1 C-5V 1000 210 5 3/16”
S3251 25T10/F 120 Frosted 500/25 Box C-5V 1000 200 5 3/16”
S3701 25T10/F 120 Frosted 120/10 CD/1 C-5V 1000 200 5 3/16”
30 R20 Med. S3210 30R20 120 Frosted 96/12 Sleeve CC-9 2000 185 4”
S2810 30R20 130 Frosted 96/12 Sleeve CC-9 2000 185 4”
R14
Int.
R14
Stubby
Med.
S11
Int.
T6 1/2
DC Bay.
T6 1/2
Int.
T8
Cand. T8
Int.
T8
DC Bay.
T10
Med. R20
Med.
R14
Med.

Incandescent Lamps
19
incandescent lamps
Watts Bulb Base
Satco
Product
Number Lamp Code Volts Finish
Master/
Inner
Carton Pkg. Type Filament
Avg.
Rated
Hours Lumens MOL Notes
Have a special requirement? Visit our website at www.satco.com
When using a 130 Volt Lamp on a 120 Volt line, life is extended by approx. 2.5 times and lumens are reduced approx. 20%
30/
70/
100
A19 Med. S1824 30/100A19/W
Reduced Size
120 White 36/12 Sleeve CC-8 2500 250/
700/
950
4 1/8”
A21 Med. S1820 30/100A21/W 120 White 36/12 Sleeve CC-2V/
C-9
2500 250/
700/
950
5 1/16”
34 A19 Med. S4460 S40A/34/SS 120 Frosted 48 4pk CC-8 1500 385 4 7/16”
S4990 S40A/34/SS 130 Frosted 48 4pk CC-8 1500 375 4 7/16”
40 A15 Med. S3810 40A15/CL 130 Clear 500/25 Box C-9 2500 290 3 1/2”
S3720 40A15/CL 130 Clear 240/20 CD/1 C-9 2500 290 3 1/2”
S3811 40A15/F 130 Frosted 500/25 Box C-9 2500 280 3 1/2”
S3721 40A15/F 130 Frosted 240/20 CD/1 C-9 2500 280 3 1/2”
S
HATTER
PROO
F
S4881 40A15/TF 130 Frost
ShatterPrf
500/25 Box C-9 2500 280 3 1/2” 4
S2976 40A15/VLX 120 Nat Day
Frost
50/10 CD/1 C-9 5000 300 3 1/2” 3
A19 Med S6041 40A19/CL 120 Clear 120 2pk C-9 2500 340 4 1/8”
S3941 40A19/CL 130 Clear 120 2pk C-9 2500 320 4 1/8”
S4020 40A19/CL 130 Clear 30 4pk 4pk C-9 1000 320 4 1/8”
S6051 40A19/F 120 Frosted 120 2pk C-9 2500 340 4 1/8”
S1711 40A19/F 120 Frosted 48 4pk C-9 1500 340 4 1/8”
S3951 40A19/F 130 Frosted 120 2pk C-9 2500 320 4 1/8”
S1810 40A19/W 120 White 48 4pk C-9 1500 280 4 1/8”
S3991 40A19/W 130 White 40 3pk 3pk C-9 1250 288 4 1/8”
S4010 40A19/W 130 White 30 4pk 4pk C-9 1000 288 4 1/8”
S3859 40A/Bug 130 Yellow 24 2pk C-9 2000 - 4 1/8”
S4980 40A/R 130 Cer Red 24/12 Sleeve C-9 1000 - 4 1/8”
S4981 40A/B 130 Cer Blue 24/12 Sleeve C-9 1000 - 4 1/8”
S4982 40A/G 130 Cer Grn 24/12 Sleeve C-9 1000 - 4 1/8”
S4983 40A/Y 130
Cer Yellow 24/12 Sleeve C-9 1000 - 4 1/8”
S4076 40A19/W/230V 230 White 120 Box CC-2F 2500 330 4 1/8”
Euro
DC Bay.
S5030 40A19/F 130 Frosted 120 Box CC-6 2500 330 4 1/8”
S5040 40A19/F/220V 220 Frosted 120 Box CC-2F 2500 330 4 1/8”
A19
Med.
A21
Med. A15
Med.
A19
Euro
DC Bay.

Incandescent Lamps
incandescent lamps
20
Watts Bulb Base
Satco
Product
Number Lamp Code Volts Finish
Master/
Inner
Carton Pkg. Type Filament
Avg.
Rated
Hours Lumens MOL Notes
Don’t see the lamp you need? Call Customer Service 1-800-43-SATCO
When using a 130 Volt Lamp on a 120 Volt line, life is extended by approx. 2.5 times and lumens are reduced approx. 20%
40 B8 Cand. S3347 40B8/Petite 130 Clear 500/25 Box CC-2V 1500 384 3”
B9 1/2 Cand. S3283 40B9 1/2 120 Clear 500/25 Box CC-2V 1500 384 3 1/2”
S3783 40B9 1/2 120 Clear 120/10 CD/2 CC-2V 1500 384 3 1/2”
S4996 KR40B9 1/2 120 Clear 500/25 Box CC-2V 2500 380 3 7/8” 1
S3717 KR40B9 1/2 120 Clear 120/10 CD/2 CC-2V 2500 380 3 7/8” 1
A3683 40B9 1/2 130 Clear 500/25 Box CC-2V 2500 384 3 1/2”
A3583 40B9 1/2 130 Clear 120/10 CD/2 CC-2V 2500 384 3 1/2”
S3286 40B9 1/2/F 120 Frosted 500/25 Box CC-2V 1500 384 3 1/2”
S3786 40B9 1/2/F 120 Frosted 120/10 CD/2 CC-2V 1500 384 3 1/2”
A3686 40B9 1/2/F 130 Frosted 500/25 Box CC-2V 2500 384 3 1/2”
A3586 40B9 1/2/F 130 Frosted 120/10 CD/2 CC-2V 2500 384 3 1/2”
S3289 40B9 1/2/W 120 White 500/25 Box CC-2V 1500 328 3 1/2”
S3789 40B9 1/2/W 120 White 120/10 CD/2 CC-2V 1500 328 3 1/2”
A3689 40B9 1/2/W 130 White 500/25 Box CC-2V 2500 328 3 1/2”
A3589 40B9 1/2/W 130 White 120/10 CD/2 CC-2V 2500 328 3 1/2”
S3725 40B9 1/2/DIA 120
Cl. Crystal
Cut
120/10 CD/2 CC-2V 1500 370 3 7/8”
S3818 40B9 1/2/A 120 Trans
Amber
500/25 Box CC-2V 1500 – 3 1/2”
E14
Euro.
S3391 40B9 1/2 120 Clear 500/25 Box CC-2V 1500 370 3 1/2”
S4712 40B9 1/2 120 Clear 120/10 CD/2 CC-2V 1500 370 3 1/2”
S3381 40B9 1/2/F 120 Frosted 500/25 Box CC-2V 1500 360 3 1/2”
S4715 40B9 1/2/F 120 Frosted 120/10 CD/2 CC-2V 1500 360 3 1/2”
B10 Cand. S2971 40B10/VLX 120 Nat Day
Frost
50/10 CD/1 CC-2V 2000 370 3 7/8” 3
S3387 40B10/220V 220 Clear 500/25 Box CC-2F 1000 330 3 3/4”
S3385 40B10/F/220V 220 Frosted 500/25 Box CC-2F 1000 330 3 3/4”
E14/Euro. S3394 40B10/220V 220 Clear 500/25 Box CC-2F 1000 330 3 3/4”
B10/B11 Med. S3232 40B11 120 Clear 500/25 Box
CC-2V 1500 370 3 7/8”
S3732 40B11 120 Clear 120/10 CD/2 CC-2V 1500 370 3 7/8”
S4469 KR40B11 120 Clear 500/25 Box CC-2V 2500 380 3 7/8” 1
S4740 40B10/FAN 120 Fan Bulb
Clear
120/12 CD/2 CC-2V 2000 370 3 7/8”
B8
Cand.
B9 1/2
Cand.
B9 1/2
E14/Euro
B10
Cand.
B10
E14/Euro
B11
Med.

Incandescent Lamps
21
incandescent lamps
Watts Bulb Base
Satco
Product
Number Lamp Code Volts Finish
Master/
Inner
Carton Pkg. Type Filament
Avg.
Rated
Hours Lumens MOL Notes
Visit our website at www.satco.com
When using a 130 Volt Lamp on a 120 Volt line, life is extended by approx. 2.5 times and lumens are reduced approx. 20%
40 B10/B11 Med. A3632 40B11 130 Clear 500/25 Box
CC-2V 2500 370 3 7/8”
A3532 40B11 130 Clear 120/10 CD/2
CC-2V 2500 370 3 7/8”
S3235 40B11/F 120 Frosted 500/25 Box
CC-2V 1500 360 3 7/8”
S3735 40B11/F 120 Frosted 120/10 CD/2
CC-2V 1500 360 3 7/8”
S4742 40B10/FAN/F 120 Fan Bulb
Frosted
120/12 CD/2 CC-2V 2000 360 3 7/8”
A3635 40B11/F 130 Frosted 500/25 Box CC-2V 2500 360 3 7/8”
A3535 40B11/F 130 Frosted 120/10 CD/2 CC-2V 2500 360 3 7/8”
S3238 40B11/W 120 White 500/25 Box CC-2V 1500 330 3 7/8”
S3738 40B11/W 120 White 120/10 CD/2 CC-2V 1500 330 3 7/8”
A3638 40B11/W 130 White 500/25 Box CC-2V 2500 320 3 7/8”
A3538 40B11/W 130 White 120/10 CD/2 CC-2V 2500 320 3 7/8”
S3384 40B11/230V 230 Clear 500/25 Box CC-2F 1000 370 3 7/8”
C11 Cand. S3404 40C11 120
Satin Spun 500/25 Box C-7A 4000 316 4”
S2704 40C11 120
Satin Spun 120/12 CD/1 C-7A 4000 316 4”
C15 Med. S3414 40C15 120
Satin Spun 300/25 Box C-7A 4000 316 4 1/2”
S2714 40C15 120
Satin Spun 120/12 CD/1 C-7A 4000 316 4 1/2”
S3416 40C15/A 120
Amber Spun 300/25 Box C-7A 4000 - 4 1/2”
S2716 40C15/A 120
Amber Spun 120/12 CD/1 C-7A 4000 - 4 1/2”
CA9 1/2 Cand. S3275 40CA9 1/2 120 Clear 500/25 Box CC-2V 1500 370 3 7/8”
S3775 40CA9 1/2 120 Clear 120/10 CD/2 CC-2V 1500 370 3 7/8”
S4466 KR40CA9 1/2 120 Clear 500/25 Box CC-2V 2500 380 3 15/16” 1
A3675 40CA9 1/2 130 Clear 500/25 Box CC-2V 2500 370 3 15/16”
A3575 40CA9 1/2 130 Clear 120/10 CD/2 CC-2V 2500 370 3 15/16”
S3279 40CA9 1/2/F 120 Frosted 500/25 Box CC-2V 1500 384 3 15/16”
S3779 40CA9 1/2/F 120 Frosted 120/10 CD/2 CC-2V 1500 384 3 15/16”
A3679 40CA9 1/2/F 130 Frosted 500/25 Box CC-2V 2500 350 3 15/16”
A3579 40CA9 1/2/F 130 Frosted 120/10 CD/2 CC-2V 2500 350 3 15/16”
CA10 Med. S3265 40CA10 120 Clear 500/25 Box CC-2V 1500 370 4 1/4”
S3765 40CA10 120 Clear 120/10 CD/2 CC-2V 1500 370 4 1/4”
A3665 40CA10 130 Clear 500/25 Box CC-2V 2500 370 4 1/4”
A3565 40CA10 130 Clear 120/10 CD/2 CC-2V 2500 370 4 1/4”
S3268 40CA10/F 120 Frosted 500/25 Box CC-2V 1500 360 4 1/4”
S3768 40CA10/F 120 Frosted 120/10 CD/2
CC-2V 1500 360 4 1/4”
A3668 40CA10/F 130 Frosted 500/25 Box
CC-2V 2500 360 4 1/4”
A3568 40CA10/F 130 Frosted 120/10 CD/2
CC-2V 2500 360 4 1/4”
B11
Med.
C11
Cand.
C15
Med.
CA9 1/2
Cand.
CA10
Med.

Incandescent Lamps
incandescent lamps
22
Watts Bulb Base
Satco
Product
Number Lamp Code Volts Finish
Master/
Inner
Carton Pkg. Type Filament
Avg.
Rated
Hours Lumens MOL Notes
Customer Service 1-800-43-SATCO
When using a 130 Volt Lamp on a 120 Volt line, life is extended by approx. 2.5 times and lumens are reduced approx. 20%
40 F15 Med. S3367 40F15 120 Clear 300/25 Box CC-9 1500 420 4 1/2”
S2767 40F15 120 Clear 120/12 CD/2 CC-9 1500 420 4 1/2”
S3368 40F15/W 120 White 300/25 Box CC-9 1500 372 4 1/2”
S2768 40F15/W 120 White 120/12 CD/2 CC-9 1500 372 4 1/2”
S3369 40F15/AU 120 Aurora 300/25 Box CC-9 1500 420 4 1/2”
S2769 40F15/AU 120 Aurora 120/12 CD/2 CC-9 1500 420 4 1/2”
S3370 40F15/A 120 Amber 300/25 Box CC-9 1500 - 4 1/2”
S2770 40F15/A 120 Amber 120/12 CD/2 CC-9 1500 - 4 1/2”
G12 1/2 Cand. S3847 40G12 1/2 120 Clear 500/25 Box C-7A 1500 370 2 3/8”
G14
E14 / Euro. S3397 40G14 130 Clear 500/25 Box CC-9 1000 360 3 1/8”
S4707 40G14 130 Clear 120/10 CD/2 CC-9 1000 360 3 1/8”
S3398 40G14/W 120 Gloss Wht 500/25 Box CC-9 1000 320 3 1/8”
S4708 40G14/W 130 Gloss Wht 120/10 CD/2 CC-9 1000 320 3 1/8”
G16 1/2 Cand. S3823 40G16 1/2 120 Clear 500/25 Box CC-2V 1500 384 3”
S3728 40G16 1/2 120 Clear 120/10 CD/2 CC-2V 1500 384 3”
S4472 KR40G16 1/2 120 Clear 500/25 Box CC-2V 2500 380 3”
A3923 40G16 1/2 130 Clear 500/25 Box CC-2V 2500 360 3”
A3523 40G16 1/2 130 Clear 120/10 CD/2 CC-2V 2500 360 3”
S3826 40G16 1/2/W 120 Sat. White 500/25 Box CC-2V 1500 348 3”
S3754 40G16 1/2/W 120 Sat. White 120/10 CD/2 CC-2V 1500 348 3”
A3926 40G16 1/2/W 130 Sat. White 500/25 Box CC-2V 2500 325 3”
A3526 40G16 1/2/W 130 Sat. White 120/10 CD/2 CC-2V 2500 325 3”
S3261 40G16 1/2/W 120 Gloss Wht 500/25 Box CC-2V 1500 348 3”
S2974  40G16 1/2/VLX 120 Nat Day
Frost
50/10 CD/1 CC-2V 2000 370 3” 3
S3245 40G16 1/2/SL 120 Silver
Crown
500/25 Box CC-2V 1500 384 3”
Med. S3839 40G16 1/2 120 Clear 500/25 Box CC-2V 1500 370 3 1/4”
S3842 40G16 1/2/W 120 Gloss Wht 500/25 Box CC-2V 1500 320 3 1/4”
G17 Med S3967 40G17/IF 130 Inside Frst 500/25 Box CC-9 1000 348 3 1/8”
S4709 40G17/IF 130 Inside Frst 120/10 CD/1 CC-9 1000 348 3 1/8”
S3968 40G17/W 130 Gloss Wht 500/25 Box CC-9 1000 348 3 1/8”
S4710 40G17/W 130 Gloss Wht 120/10 CD/1 CC-9 1000 348 3 1/8”
G18 1/2 Med. S3888 40G18 1/2 120 Clear 250/25 Box C-9 1500 368 3 1/2”
S3828 40G18 1/2/W 120 Gloss
Wht
250/25 Box C-9 1500 280 3 1/2”
F15
Med.
G12 1/2
Cand.
G14
E14/Euro.
G16 1/2
Cand.
G16 1/2
Med.
G17
Med.
G18 1/2
Med.

Incandescent Lamps
23
incandescent lamps
Watts Bulb Base
Satco
Product
Number Lamp Code Volts Finish
Master/
Inner
Carton Pkg. Type Filament
Avg.
Rated
Hours Lumens MOL Notes
Have a special requirement? Visit our website at www.satco.com
When using a 130 Volt Lamp on a 120 Volt line, life is extended by approx. 2.5 times and lumens are reduced approx. 20%
40 G25 Med. S3448 40G25 120 Clear 72/6 Box CC-9 2500 384 4 3/8’
S4048 40G25/3PK 120 Clear 40 3pk 3pk CC-9 2500 384 4 3/8’
A3648 40G25 130 Clear 72/6 Box CC-9 3000 360 4 3/8’
A4148 40G25/3PK 130 Clear 40 3pk 3pk CC-9 3000 360 4 3/8’
A3644 40G25/220V 220 Clear 72/6 Box CC-9 2500 212 4 3/8’
S3441 40G25/W 120
Gloss Wht 72/6 Box CC-9 2500 340 4 3/8’
S4041 40G25/W/3PK 120
Gloss Wht 40 3pk 3pk CC-9 2500 340 4 3/8’
A3641 40G25/W 130
Gloss Wht 72/6 Box CC-9 3000 320 4 3/8’
A4141 40G25/W/3PK 130
Gloss Wht 40 3pk 3pk CC-9 3000 320 4 3/8’
A3645 40G25/W/220V 220
Gloss Wht 72/6 Box CC-9 2500 187 4 3/8’
S3861 40G25/SL 120 Silver
Crown
72/6 Box CC-9 1500 280 4 3/8’
S4815 40G25/VLX 120 Nat Day
Frost
50/10 Box C-9 5000 320 4 3/8’ 3
G30 Med. S3652 40G30 120 Clear 72/6 Box CC-9 2500 384 5 1/8”
S3671 40G30/W 120 Gloss
Wht
72/6 Box CC-9 2500 320 5 1/8”
G40 Med. S3011 40G40 120 Clear 24/6 Box C-9 4000 300 6 3/4”
S3001 40G40/W 120
Gloss Wht 24/6 Box C-9 4000 280 6 3/4”
HX-10 1/2 Cand. S3745 40HX10 1/2 120 Clear 120/12 CD/2 C-7A 1500 360 4 1/2”
S3747
40HX10 1/2/F 120 Frosted 120/12 CD/2 C-7A 1500 360 4 15/16”
S3749 40HX10 1/2/AU 120 Aurora 120/12 CD/2 C-7A 1500 360 4 15/16”
K19 Med. S4976 40K19/2PK 120 White 12 2pk 2pk C-9 1500 260 4 1/8”
R14 Int. S3215 40R14N 120 Clear 500/25 Box CC-2V 1500 280 2 5/8”
S4701 40R14N 120 Clear 120/10 CD/1 CC-2V 1500 280 2 5/8”
E14 / Euro. S3396 40R14/E14 130 Clear 500/25 Box CC-2V 1500 280 2 5/8”
S4706 40R14/E14 130 Clear 120/10 CD/1 CC-2V 1500 280 2 5/8”
R14
Stubby
Med S3602 40R14 120 Clear 500/25 Box CC-2V 1500 280 2 1/4”
G25
Med.
G30
Med.
G40
Med.
HX-10 1/2
Cand.
R14
Int.
K19
Med.
R14
Euro.
R14
Stubby
Med.

Incandescent Lamps
incandescent lamps
24
Watts Bulb Base
Satco
Product
Number Lamp Code Volts Finish
Master/
Inner
Carton Pkg. Type Filament
Avg.
Rated
Hours Lumens MOL Notes
Don’t see the lamp you need? Call Customer Service 1-800-43-SATCO
When using a 130 Volt Lamp on a 120 Volt line, life is extended by approx. 2.5 times and lumens are reduced approx. 20%
40 R14 Med S3605 40R14 120 Clear 500/25 Box CC-2V 1500 280 2 5/8”
S4705 40R14 120 Clear 120/10 CD/1 CC-2V 1500 280 2 5/8”
R16 Med. S3214 40R16 120 Frosted 500/25 Box C-9 1500 280 3 7/16”
S4702 40R16 120 Frosted 120/10 CD/1 C-9 1500 280 3 7/16”
S11 Int. S3629 40S11/N 115/
125
Clear 600/10 Box CC-2V 1500 370 2 3/8”
S3729 40S11/N 115/
125
Clear 240/20 CD/1 CC-2V 1500 370 2 3/8”
T6 1/2 Int. S3224 40T6 1/2/N 130 Clear 500/25 Box C-8 1500 350 5 3/8”
S3710 40T6 1/2/N 130 Clear 120/10 CD/1 C-8 1500 350 5 3/8”
S3225 40T6 1/2/N/F 130 Frosted 500/25 Box C-8 1500 340 5 3/8”
S3712 40T6 1/2/N/F 130 Frosted 120/10 CD/1 C-8 1500 340 5 3/8”
T8 Int. S3917 40T8N 130
Microwave
Clear
120/10 CD/1 CC-2V 2000 2 5/8”
Med S2977 40T8 130 Clear
Showcase
10 Box C-8 2000 265 12”
Disc
Base
S2980 SL40 120 Clear
Lumiline
24 Sleeve C-8 1500 325 11 3/4”
S2981 SL40/W 120 White
Lumiline
12 Sleeve C-8 1500 295 11 3/4”
T10 Med. S3252 40T10 120 Clear 500/25 Box C-5V 1000 300 5 5/8”
S3702 40T10 120 Clear 120/10 CD/1 C-5V 1000 300 5 5/8”
S3253 40T10/F 120 Frosted 500/25 Box C-5V 1000 290 5 5/8”
S3703 40T10/F 120 Frosted 120/10 CD/1 C-5V 1000 290 5 5/8”
50 A19 Med. S5011 50A19/F/12V 12 Frosted 120/6 Box C-6 1500 540 4 1/8”
S5021 50A19/F/34V 34 Frosted 120/6 Box C-6 1500 540 4 1/8”
S3969 50A/RS 130 Frosted 24 2pk C-9 2500 320 4 1/8”
50/
100/
150
A21 Med. S1821 50/150A21/W 120 White 36/12 Sleeve CC-2V/
C-9
2500 520/
1050/
1570
5 5/16”
S2985 S
50/150A21/PK 120 Soft Pink
3-way
12 Sleeve CC-8 1200 - 5 5/16”
S4823 50/150A21/VLX 120 Nat Day
Frost
50/10 Box C-9 5000 350/
910/
1260
5 5/16” 3
R14
Med.
R16
Med.
S11
Int.
T6 1/2
Int.
T8
Int.
T10
Med.
A19
Med.
A21
Med.
T8
Med.
T8
Disc
Base
