Sengled Element E11-G13 User manual

E11-G13- Wireless LED Bulb
Z02-Hub –Sengled Hub
User Manual
Manuel de l’utilisateur
Guía delusuario
LED + Smart Control

System Features:
•
•
•
•
EN
Control Element lighting from anywhere at anytime
Schedule scenes based on timing, brightness
View current power and historic energy consumption.
Track and report number of power cycles and usage hours
Element Bulb Features
•
•
•
•
•
Wireless control
Dimmable via Element app
Support for warm white 2700K color temperature
25,000 hour LED lifetime
Wide beam angle
Supports Zigbee HA 1.2.1
Element Hub Features:
•
•
•
Connects up to 64 Element bulbs via the Element mobile app
Wirelessly control groups and individual Element bulbs
Supports Zigbee HA 1.2.1
Element Bulb Specification
•
•
•
•
•
•
•
•
•
•
Model: E11-G13
Power: 9.0W
Brightness: 800 lumens
Beam Angle: 240°
Input: 100-130V AC, 60Hz, 85mA
Light Socket: E26
Operating Temperature: -4 °F ~ + 104 °F (-20
°C ~ + 40 °C )
Storage Temperature: -40 °F ~ + 158 °F (-40
°C ~ +70 °C )
Operating Humidity: 10% ≤RH ≤95%, non-condensing
Dimensions: Dia: 2.4in (61.5mm); H: 4.4in (112mm)
Element Hub Specification
•
•
•
•
•
Model: Z02-hub
Input: 5V DC, 300mA
Adapter Input: 100-240V AC, 30mA; Output: 5V DC, 1A
Dimensions: L: 78mm; W: 78mm; H: 26mm
Support Zigbee HA 1.2.1 and 2.4 GHz Wi-Fi
Box Contents
•
•
•
Two Element A19 Bulbs and One Hub
One Ethernet Cable
Quick Start Guide

EN
Local Operations
Reset the hub:
1.Ensure that the hub has been removed from any previous Sengled
Element accounts. If the hub is still associated with an account:
navigate to the device tab, then delete the hub in question.
2.If there is an Ethernet cable attached to the hub, remove the
cable from the hub. If not, continue to the next step.
3.Power off the hub and then power it back on and wait 30
seconds.Then press and hold the reset button on the side of the
hub for 8 seconds. (User may want to use a pen or pencil.) Please
note, you must wait 30 seconds or the reset process may fail.
4.If successful, the middle LED of the hub will flash eight times.
Rejoin wireless network from the bulb: Power cycle the bulb (off
then back on) five times quickly. The bulb will blink two times
indicating network rejoin.
Reset factory default for the bulb: Power cycle the bulb (off then
back on) quickly for at minimum ten times. The bulb will blink five
times indicating pairing mode.
EZ-Mode commissioning from the bulb: Power cycle the bulb (off
then back on) seven times quickly to enable EZ-Mode. The bulb will
blink to indicate that it is in this mode for three minutes. To exit this
mode earlier, power off the bulb via the wall switch, wait for two
seconds and then power it back on.
*To ensure the following steps work successfully, please power
on the bulb first and wait for at least four seconds before taking
any of the steps.
System Setup Instructions
•
•
Please review the Quick Start guide for instructions on how to
set up the Element Hub
Please contact customer service via Sengled.com for
information on how to purchase additional bulbs. To add
additional bulbs, please follow the in-app instructions to scan,
power on and add the bulbs to their desired hub as shown below

Important Safety Instructions
•
•
•
•
This product is intended for indoor use only
Do not install the product near any heat sources, such as
heaters, radiators, stoves, heat registers or other apparatus
that produce heat
To reduce the risk of electric shock, do NOT disassemble.
There are no serviceable parts inside
Do not clean the device when it is on and connected to the
power supply
Device detail Add Bulb
(1)
(4)
(3)
Add Bulbs
(2)
Scan code Mac address
Add Bulb
EN
•
•
NOTE: Bulbs associated with another Sengled account must
first be deleted and factory reset. Refer to the Local
Operations section of the User Manual for instructions on
how to factory reset a bulb.
NOTE: Bulbs accidentally deleted from a Sengled account
must first be factory reset before being re-added.

•
•
•
EN
For best protection against lightning,unplug or unscrewthe-
products from its power source duringa storm
The bulb will be hot when in use and should not be touched
without taking care
Do NOT throw the LED bulb into regular trash at the end of
its life. Bring the bulb to a local recycling center for proper
disposal
E11-G13
FCC ID：2AGN8-E11G13 IC：20888-E11G13
Z02-hub
FCC ID：2AGN8-Z02HUB IC：20888-Z02-HUB
Federal Communications Commission (FCC)
Interference Statement
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generate, uses
and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to
radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to
correct the interference by one of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that
may cause undesired operation.
NOT FOR EMERGENCY LIGHTING
RISK OF ELECTRIC SHOCK-DO NOT USE WHERE DIRECTLY
EXPOSED TO WATER
CAUTION:

© 2016 Sengled, Incorporated. All rights reserved. Sengled
Element is a trademark of Sengled, Incorporated, registered in
the United States and other countries. Specifications are
subject to change without notice. Other trademarks and trade
names are the property of their respective owners.
IC Radiation Exposure Statement for Canada
This device complies with Industry Canada licence-exempt RSS
standard(s). Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this device
must accept any interference, including interference that may
cause undesired operation of the device.
User manuals for transmitters equipped with detachable antennas
shall also contain the following notice in a conspicuous location:
This radio transmitter (identify the device by certification number,
or model number if Category II) has been approved by Industry
Canada to operate with the antenna types listed below with the
maximum permissible gain and required antenna impedance for
each antenna type indicated. Antenna types not included in this
list, having a gain greater than the maximum gain indicated for
that type, are strictly prohibited for use with this device.
IMPORTANT NOTE:
Radiation Exposure Statement:
This equipment complies with “Industry Canada RSS-102 for
radiation exposure limits set forth for an uncontrolled environment”.
This equipment should be installed and operated with minimum
distance 20cm between the radiator and your body.
EN
FCC Caution: Any changes or modifications not expressly approved
by the party responsible for compliance could void the user’s
authority to operate this equipment.
RF exposure warning
This equipment complies with FCC radiation exposure limits set
forth for an uncontrolled environment.
This equipment must be installed and operated in accordance
with provided instructions and the antenna(s) used for this
transmitter must be installed to provide a separation distance of
at least 20 cm from all persons and must not be collocated or
operating in conjunction with any other antenna or transmitter.

Rev 1.1 2016.04
© 2016 Sengled, Incorporated. All rights reserved.
