Imax AM-4 User manual

Service Manual
TYPE:YS6020
AM-4
Manual-Service-IMAX-AM4CE-00-1v4 • Mar 28, 2014

The exclamation point within an equilatereal triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.
Le point d’exclamation à l’intérieur d’un triangle
équilatéral est prévu pour alerter l’utilisateur de la
présence d’instructions importantes dans la
littérature accompagnant l’appareil en ce qui
concerne l’opération et la maintenance de cet
appareil.
This lightning flash with arrowhead symbol, within
an equilateral triangle, is intended to alert the user to
the presence of uninsulated “dangerous voltage”
within the product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to persons.
Ce symbole d’éclair avec tête de flèche dans un triangle
équilatéral est prévu pour alerter l’utilisateur de la présence d’un
« voltage dangereux » non-isolé à proximité de l’enceinte du
produit qui pourrait être d’ampleur suffisante pour présenter
un risque de choque électrique.
IMPORTANT SAFETY INSTRUCTIONS
safety-4v9 • October 19/2013
CAUTION:TO REDUCETHE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
THIS DEVICE IS FOR INDOOR USE ONLY!
FOLLOW ALL INSTRUCTIONS SUIVEZTOUTES LES INSTRUCTIONS
Instructions pertaining to a risk of fire,
electric shock, or injury to a person
Read Instructions: The Owner’s Manual should be read and understood before operation
of your unit.Please, save these instructions for future reference and heed all warnings.
Clean only with dry cloth.
Packaging: Keep the box and packaging materials, in case the unit needs to be
returned for service.
Warning: To reduce the risk or fire or electric shock, do not expose this apparatus to rain or
moisture.Do not use this apparatus near water!
Warning: When using electric products, basic precautions should always be followed,
including the following:
Power Sources
Your unit should be connected to a power source only of the voltage specified in the
owners manual or as marked on the unit.This unit has a polarized plug. Do not use
with an extension cord or receptacle unless the plug can be fully inserted. Precau-
tions should be taken so that the grounding scheme on the unit is not defeated. An
apparatus with CLASS I construction shall be connected to a Mains socket outlet with
a protective earthing ground. Where the MAINS plug or an appliance coupler is used
as the disconnect device, the disconnect device shall remain readily operable.
Hazards
Do not place this product on an unstable cart, stand, tripod, bracket or table.The
product may fall, causing serious personal injury and serious damage to the product.
Use only with cart, stand, tripod, bracket, or table recommended by the manufacturer
or sold with the product. Follow the manufacturer’s instructions when installing the
product and use mounting accessories recommended by the manufacturer. Only use
attachments/accessories specified by the manufacturer
Note: Prolonged use of headphones at a high volume may cause
health damage on your ears.
The apparatus should not be exposed to dripping or splashing water; no objects
filled with liquids should be placed on the apparatus.
Terminals marked with the “lightning bolt” are hazardous live;the external wiring
connected to these terminals require installation by an instructed person or the use of
ready made leads or cords.
Ensure that proper ventilation is provided around the appliance.Do not install near
any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
No naked flame sources, such as lighted candles, should be placed on the apparatus.
Power Cord
Do not defeat the safety purpose of the polarized or grounding-type plug.A polarized plug
has two blades with one wider than the other.A grounding type plug has two blades and a
third grounding prong.The wide blade or the third prong are provided for your safety.If the
provided plug does not fit into your outlet, consult an electrician for replacement of the
obsolete outlet.The AC supply cord should be routed so that it is unlikely that it will be
damaged.Protect the power cord from being walked on or pinched particularly at plugs.If
the AC supply cord is damaged DO NOT OPERATE THE UNIT. To completely disconnect
this apparatus from the AC Mains, disconnect the power supply cord plug from the AC
receptacle.The mains plug of the power supply cord shall remain readily operable.
Unplug this apparatus during lightning storms or when unused for long periods of time.
Service
The unit should be serviced only by qualified service personnel.Servicing is required
when the apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate normally, or has been dropped.
AVIS: AFIN DE REDUIRE LES RISQUE DE CHOC ELECTRIQUE,
N’ENLEVEZ PAS LE COUVERT (OU LE PANNEAU ARRIERE)
NE CONTIENT AUCUNE PIECE REPARABLE PAR L’UTILISATEUR.
CONSULTEZ UNTECHNICIEN QUALIFIE POUR L’ENTRETIENT
CE PRODUIT EST POUR L’USAGE À L’INTÉREUR SEULEMENT
Instructions relatives au risque de feu,
choc électrique, ou blessures aux personnes
Veuillez Lire le Manuel: Il contient des informations qui devraient êtres comprises avant
l’opération de votre appareil.Conservez.Gardez S.V.P.ces instructions pour consultations
ultérieures et observez tous les avertissements.
Nettoyez seulement avec le tissu sec.
Emballage: Conservez la boite au cas ou l’appareil devait être retourner pour réparation.
Avertissement: Pour réduire le risque de feu ou la décharge électrique, n'exposez pas
cet appareil à la pluie ou à l'humidité.N’utilisez pas cet appareil près de l’eau!
Attention: Lors de l’utilisation de produits électrique, assurez-vous d’adhérer à des
précautions de bases incluant celle qui suivent:
Alimentation
L’appareil ne doit être branché qu’à une source d’alimentation correspondant au
voltage spécifié dans le manuel ou tel qu’indiqué sur l’appareil.Cet appareil est équipé
d’une prise d’alimentation polarisée. Ne pas utiliser cet appareil avec un cordon de
raccordement à moins qu’il soit possible d’insérer complètement les trois lames.Des
précautions doivent êtres prises afin d’eviter que le système de mise à la terre de
l’appareil ne soit désengagé. Un appareil construit selon les normes de CLASS I
devrait être raccordé à une prise murale d’alimentation avec connexion intacte de mise
à la masse.Lorsqu’une prise de branchement ou un coupleur d'appareils est utilisée
comme dispositif de débranchement, ce dispositif de débranchement devra demeurer
pleinement fonctionnel avec raccordement à la masse.
Risque
Ne pas placer cet appareil sur un chariot, un support, un trépied ou une table instables.
L’appareil pourrait tomber et blesser quelqu’un ou subir des dommages importants.
Utiliser seulement un chariot, un support, un trépied ou une table recommandés par le
fabricant ou vendus avec le produit.Suivre les instructions du fabricant pour installer
l’appareil et utiliser les accessoires recommandés par le fabricant.Utilisez seulement
les attachements/accessoires indiqués par le fabricant
Note: L'utilisation prolongée des écouteurs à un volume élevé peut
avoir des conséquences néfastes sur la santé sur vos oreilles. .
Il convient de ne pas placer sur l’appareil de sources de flammes nues, telles que
des bougies allumées.
L’appeil ne doit pas être exposé à des égouttements d’eau ou des éclaboussures
et qu’aucun objet rempli de liquide tel que des vases ne doit être placé sur l’appareil.
Assurez que lappareil est fourni de la propre ventilation. Ne procédez pas à
l’installation près de source de chaleur tels que radiateurs, registre de chaleur, fours
ou autres appareils (incluant les amplificateurs) qui produisent de la chaleur.
Les dispositifs marqués d’une symbole “d’éclair” sont des parties dangereuses
au toucher et que les câblages extérieurs connectés à ces dispositifs de
connection extérieure doivent être effectivés par un opérateur formé ou en utilisant
des cordons déjà préparés.
Cordon d’Alimentation
Ne pas enlever le dispositif de sécurité sur la prise polarisée ou la prise avec tige de
mise à la masse du cordon d’alimentation.Une prise polarisée dispose de deux lames
dont une plus large que l’autre.Une prise avec tige de mise à la masse dispose de
deux lames en plus d’une troisième tige qui connecte à la masse.La lame plus large ou
la tige de mise à la masse est prévu pour votre sécurité.La prise murale est désuète si
elle n’est pas conçue pour accepter ce type de prise avec dispositif de sécurité.Dans
ce cas, contactez un électricien pour faire remplacer la prise murale. Évitez
d’endommager le cordon d’alimentation.Protégez le cordon d’alimentation.Assurez-
vous qu’on ne marche pas dessus et qu’on ne le pince pas en particulier aux prises.
N’UTILISEZ PAS L’APPAREIL si le cordon d’alimentation est endommagé. Pour
débrancher complètement cet appareil de l’alimentation CA principale, déconnectez le
cordon d’alimentation de la prise d’alimentation murale.Le cordon d’alimentation du
bloc d’alimentation de l’appareil doit demeurer pleinement fonctionnel.
Débranchez cet appareil durant les orages ou si inutilisé pendant de longues périodes.
Service
Consultez un technicien qualifié pour l’entretien de votre appareil.L'entretien est
nécessaire quand l'appareil a été endommagé de quelque façon que se soit.Par exemple
si le cordon d’alimentation ou la prise du cordon sont endommagés, si il y a eu du liquide
qui a été renversé à l’intérieur ou des objets sont tombés dans l'appareil, si l'appareil a été
exposé à la pluie ou à l'humidité, si il ne fonctionne pas normalement, ou a été échappé.
S2125A
Caution:hot surface
Attention:surface chaud
IEC 60417-5041

IMAX AM4 Power Amplifier
M1371 THE INPUT SECTION
The input board processes the audio signal from the input jacks to the indicator/control board,
(M1370) on the front panel.
Each channel consists of a balanced gain stage, subsonic filter, and a stereo / mono switch.
Looking at the left channel, the balanced input, (XLR Jack) and input (phone jack) are wired
in parallel to the input of a balanced operational amplifier, (U2:B). The gain of this stage is 0.82
(-1.3dB) balanced and 1.6 (4.0dB) unbalanced. Resistors R1, R3 along with capacitors C3 and
C4 form a radio interference elimination filter.
The subsonic filter provides a 20Hz high pass filter. The filter consists of a tee network on
the input of U2:A along with R13, R19, C6 and C8. The gain is 1 (0dB) in the passband, (above
20 Hz).
The audio signals from the input board M1371 pass through the 14 conductor cable and the
16 conductor DIP cable to the front panel board M1370.
M1370 FRONT PANEL BOARD AND LIMITERS
This board contains:
 the front panel indicating LEDs (signal and clip).
Circuit Explanation:
 The left channel of the circuit is explained. (Refer to the schematic of M1370 as the sections
of the circuit are explained.)
 The audio signal out of M1371 passes through the front panel board and then enters U1:A
through pin 2. U1:A is set for a gain of 1 (0dB)
The AM4's limiter is built around U2:A&B and U1:B. When clipping is detected in the amplifier a signal is
fed to ACLIP. The current from ALIM acts to increase the gain of U2 and this audio voltage gets subtracted
from the signal on the input and less signal appears on the output of U1:B. Transistors Q5C and Q6C
along with the surrounding passive parts provide the attack and release time constants. When an audio
signal on the output of the power amplifier section enters clipping, pulses representing the duration of the
clipped portion appear at ACLIP. These pulses turn on transistor Q6C, and Q6C provides current pulses to
turn on clip LED LD6C. The pulses also pass through R7C and D6C to charge C3C and C36C. When the
voltage across C3C reaches 0.5 volts then Q5C turns on providing a current into pins 1 and 16 of U2
limiting the audio signal at U1:B. The charging (attack) and discharging (release) times of the limiter are
30mS and 0.5 seconds respectively. Resistors R50C and R7C provide the charging path, and resistor
R51C provides the discharge path.
The Signal LED circuit consists of Q1C and the surrounding circuitry. The audio signal
enters the activity LED circuit through R2C. R2C and C21C form a differentiator that turns Q1C
on illuminating the activity LED whenever the audio signal increases in amplitude. A constant
current flows through R55AC, R55BC and when Q1C is off, the collector current then flows
through D1C. From M1371 the audio signal passes through a 12-conductor ribbon cable to
circuit board M1370.

On M1370 an operational amplifier U3A:B re-references the ground for the audio signal from
LVGND to the corresponding GNDB (left output ground) or (right output ground). U3A:B also
provides DC correction for DC offsets appearing on the output binding posts. Feedback from the
output binding posts appears through R54B or R60&61B where the DC offset achieves a gain of -1
from U3A:B. The DC offset of opposite polarity on the output of U3A:B will compensate for the DC
offset in the amplifier section on M1370 resulting in 0 volts DC on the output binding posts.
M1370 The Voltage Amplifier and Current Amplifier
This board contains:
 a voltage amplifier section
 a current amplifier section
 amplifier current limit section
 heatsink temperature sensing
Voltage Amplifier Section
The voltage amplifier amplifies the audio signals voltage from 6.8 volts peak (at the output of U3A:B) to
approximately 98v peak, which is required to drive the current amplifier section. The current amplifier
provides the current required for the 98v peak signal to drive 1200 watts into 4 ohms out of the binding
posts. Before the circuit is described in detail here is a quick rundown on the signals path through the
voltage amplifier stage. Refer to the schematic of M1370. Lets consider that a positive going AC signal is
present at pin7 of U3A:B. The positive going signal will turn on the positive side of the voltage amplifier. The
signal at the input turns on Q7B (through R57B, D11B and D12B). The collector of Q7B pulls down on the
base of Q10B turns this transistor on further and allows a greater current to flow out of Q10Bs collector.
This increase in current passes through Q11B and its collector to emitter voltage decreases. The collector
of Q11B now being more positive in voltage turns the base of Q17B on causing an increase in Q17Bs
collector current resulting in the output of the voltage amplifier (net00156) going positive. As the positive
side of the amplifier was turning on the negative side would have been turning off. This is how the output
was able to move positive following the input signal. The reverse would hold true if a negative going signal
were present on the input of the voltage amplifier.
Circuit Description
The voltage amplifier is a mirrored image with circuitry connected to the positive power supply rail being
identical (but opposite polarity) to the circuitry connected to the negative power supply rail. For this reason
we will look in detail at the positive side of the amplifier. The audio signal enters the voltage amplifier. The
signal passes through R57B, D11B and D12B to the base of Q7B. Diodes D11B and D12B set up the DC
bias on Q7B to approximately 0.6 mA. The first voltage gain stage consists of Q7B along with the resistor
chain on its collector and the emitter resistor (R66B). Transistor Q7B drives the base of Q10B through the
resistor chain. A DC current of approximately 4 mA should flow through the collector of Q10B. The voltage
drop across Q10B remains constant and is derived from the voltage drop across the voltage reference
Q15B, resistor R77B, and the base/emitter junction of Q11B. This total voltage should equal a roximately 3 VDC.
Transistor Q10B is the second gain stage and its out ut current flows through Q11B. Transistor Q11B is a common
base stage with the collector driving the base of out ut buffer Q17B. Diode D20B is a clam ing diode that revents the
maximum eak of the audio signal from coming within 4V of the 144 VDC rail. This is to revent the out ut current
am lifier from going into saturation during cli ing and therefore having storage delay roblems. Transistor Q17B
buffers the high im edance resent on the collector of Q11B. The out ut of the buffer rovides a low out ut im edance
at the junction of R83B and R84B and is current limited to 30mA through the clam ing action of D17B, D18B and
D19B. The signal at the junction of R83B and R84B drives the succeeding current am lifier.

Current Amplifier Section
The current amplifier receives a high voltage audio signal from the voltage amplifier and provides the
current drive necessary to drive speaker cabinets. The current amplifier is a two-tier complimentary output
driver design controlled by a complimentary darlington stage.
[CIRCUIT DESCRIPTION - REFER TO THE SIMPLIFIED SCHEMATIC #1]
Quiescent Condition
This design is class A/B and therefore the output driver transistors must be forward biased to provide low
crossover distortion. In most class A/B designs, a diode chain or VBE multiplier is used to control the bias
voltage and provide a means of adjusting the bias. This design is different, as there isnt a diode chain or
VBE multiplier. For simplicity lets consider only the positive side of the current amplifier, that is all parts
between the positive power supply rails and the audio signal output/input terminals. The negative side is
the same as the positive, except for polarity changes.
To bias Q35B, greater than 0.5V is needed from base to emitter, (or for simplicity from base
to amplifier output). Points A and B are at the same potential, so consider them to be
connected. If this is true then 0.5V from test point 2 to the amplifier output must appear across
R104B. There must be some way of developing this voltage across R104B, and there is using
the darlington (Q23B and Q25B) driver along with local feedback.
Simplified schematic #1 shows the biasing circuit. The current needed to develop 0.5V across
R104B comes from the emitter of Q25B. When the amplifier is first turned on the current source
(Q19B) turns on Q23B and Q25B and current flows through R104B developing a voltage. When this

voltage approaches 0.5V Q20B turns on and robs current from the base of Q23B. This causes Q23B
to turn off until the reduced current flowing through Q25B maintains 0.5V across R104B. Q20B will
turn off slightly causing Q23B and Q25B to increase their collector currents. The circuit reaches a
point of equilibrium with approximately 0.5V across R104B.
Because all output devices are not identical and base emitter voltages vary, some adjustment
must be available to slightly adjust the 0.5V across R104B. This is accomplished with RTB. RTB
causes Q20B to turn on slightly more or less resulting in Q23B and Q25B turning on slightly more or
less and therefore R104Bs voltage will be slightly more or less than 0.5v. The proper quiescent
current voltage is 4mV (to be measured between test points 8 and 9).
The Second Tier and Tier Switching
Refer to the simplified schematic Fig. #1 while reading the following text. One way of making an amplifier
more efficient is to vary the Power Supply Voltage on the collectors of the output transistors (Q35B &
Q36B). The lower the voltage from collector to emitter, the lower the device dissipation. During quiescent
conditions, there is 55VDC on the collectors of output transistors Q14 and Q22. The peak AC voltage that
can appear on the amplifiers output is approximately 139V peak. How can an output transistor deliver a
139V peak when its collector is only at 55VDC? It can if its collector is pulled up to 144VDC as the output
signals peak rises above 55VDC. Refer to Fig. #2. The second tier voltage must remain above the
amplifiers output voltage by amount Vm. Therefore the circuitry controlling the second tier voltage must
increase the tier voltage before the amplifiers output voltage reaches 55VDC. This leading voltage is
necessary to compensate for time lag of the second tier circuit during fast rising amplifier output signals.
The voltage between the amplifiers output and test point 4 is approximately 14VDC derived
from the voltage drop across ZD4B. We call this voltage the floating battery because it floats
on top of the output audio signal with test point 4 always being 14VDC greater than the peak of
the output signal. Test point 4 drives the gate of mos-fet Q32B. Q32B controls the transistors of
the upper tier. As Q32B turns on its source forward biases the base of Q33B and Q33B pulls the
collector of Q35B towards the 144 volt rail. The gate to source voltage needed to turn on Q32B
is approximately 3.5 volts. When the peak output signal is about 44.5vp (55v-(14v-3.5v)) then
Q32B will start to turn on the second tier. The second tier voltage will remain about 13 volts
(Vm) above the peak of the output signal to the point of clipping where this voltage is reduced to
about 6 volts (measured driving an 8 ohm load). Zener ZD10B protects the gate source junction
of Q11 and also provides a supply current path through R38 for the floating battery.

NOTE: The Power supply voltages given are those when the amplifier is not driving a speaker load.
This will allow you to check the tier switching with the cover of the amplifier off and the amplifier,
therefore, running cool.
Current Limit Protection Circuitry
To have an amplifier drive 3000 watts into practically any combination of speaker cabinets and know what
is a safe load and what is not is a very difficult task. An extensive amount of time was spent on the current
limit circuitry so that it may simulate the safe operating area of the output transistors (SOAR curve). No
matter how reactive the load may be the phase shift that it presents, along with its resistive component is
used to set the output current limit of the output transistor stage. Refer to the schematic of board M1370
while reading the following text. The current limit circuitry is a mirrored image with circuitry connected to the
positive power supply rail being identical (but opposite polarity) to the circuitry connected to the negative
power supply rail. For this reason we will look at the positive side of the circuitry.
Transistor Q46B measures the peak current flowing through resistor R146B. The voltage across
R146B (as a result of the current flowing through it) is scaled down by R173B, R167B, R134B,
R135B, R136B, D25B and D27B these parts make up the safe operating area along with the time
constants of C31B, R120B, C37B and R152B. Fig. #3 shows a waveform of the current that passes
through R146B and R147B when the output of the amplifier is shorted to ground. This can only be
seen by using an oscilloscope to measure differentially across R146B and R147B. The conditions of
the measurement are contained on the diagram. During current limit when Q46B turns on it reduces
the voltage across R119B. R119B is in series with a 20 volt zener (ZD7B) and is also in parallel with
the junction of Q29B. The current that flows through R110B, ZD7B, R119B, and R111B normally
saturates Q29B. When Q46B reduces the voltage across ZD7B and R119B to below 20.6 volts,
Q29B turns off allowing a charge to build up on C28B through resistors R116B and R118B. If current
limiting occurs for a long enough duration to allow C28B to charge to 1.2 volts then Q28B will turn on
tripping the relay circuit. As soon as the relay is tripped the audio signal will be turned off at the output
of the voltage amplifiers and will remain off for about 5 seconds before the relay turns on and allows
the audio signal to pass through the amplifier. If a current limit condition is still present then the whole
cycle will occur again and repeat until the load conditions on the amplifiers output are safe for the
amplifier. When a safe load appears the amplifier will automatically reset and drive that load (the
speaker cabinet).
DC Protection
If a DC voltage greater than 8 volts appears on the output of the amplifier for more than 200 milliseconds
then triac Q16 will turn on holding the output at ground potential. MBS4992 is a device that turns on at
either + or - 8 volts DC.

NOTE: Every time you replace blown output transistors on a M1370 board test the DC protection triac
with the following circuit.
Conditions of test:
A) Pass a 100Hz 25v peak signal through the M1370 board under test with no load connected
to the amplifier output.
B) Connect points 1 and 2 as shown in the diagram. The amplifier should go into protect mode
as the triac (if working) shorted the output of the amplifier to ground, and the amplifier goes
into current limit.
C) Disconnect the triac test circuit and allow the amplifier to complete its protect cycle.
D) Reverse connections 1 to 2 and 2 to 1 and test again. The same results as in B) should be
observed if the triac is working.
Only test the triac for one protect cycle as prolonged testing will heat the triac to a high temperature.
Shutdown Circuit, Fan Control Circuit and Soft Turn On Circuit
 The shutdown relay and its associated drive circuitry have two possible operating states.
 Amplifier on under normal operating conditions.
 Amplifier power switch has just been turned OFF/ON, or the amplifier is in current limit
protecting the amplifiers output transistors, or the amplifier has overheated.

Shutdown Circuit
Here is how the circuit accomplishes these functions. The relays normally closed contacts short the output
of the voltage amplifiers to ground when the power switch is off. When the power switch is turned on, the
relay remains off (normally closed) for about 6 seconds. C7 charges to 35V and results in Q1 turning off
allowing Q2 to turn on. As Q1 turns on, it connects the negative terminal of the relays coil (Pin 16) to
ground energizing the relay and opening the normally closed contacts. If prolonged current limiting occurs
on the amplifiers output transistors then D21B will be forward biased turning on Q28B (from its off state).
Now +144VDC appears on the collector of Q3 and through R21 and R23 turn on Q2 therefore turning off
Q1 by shorting its base emitter junction. Q1 turning off will turn the relay off and the normally closed
contacts (off state) will short the outputs of the voltage amplifiers to ground so as not to continuously stress
the amplifiers output transistors. A cycle now occurs. With the voltage amplifiers now disabled there is no
signal driving the output transistors (Q35A to Q44B). The current limit circuit protecting the output
transistors (Q35A to Q44B) turns off and D5B is not forward biased and Q3 turns off. Through Q1 and Q2
the relay is turned back on and the voltage amplifiers are now active again, driving the output transistors. If
current limiting still occurs, then the same cycle will occur. If the cause of current limiting (low impedance or
short on the speaker output terminals) has been removed, then the amplifier will continue to operate
normally. The third operation that the relay provides is overheat shutdown. If for some reason the fan
cannot keep the heat-sinks in a safe operating temperature area then the temperature sensing circuit will
deliver through ZD2 a positive current to turn Q2 on and turn Q1 off to turn off the relay and disable the
voltage amplifiers. When the fan has cooled down the temperature of the amplifier, then the signal through
ZD2 will disappear and the relay circuit will turn on the relay to resume normal operation. Anytime the relay
is in the protect mode (due to the abnormal states) then contact pin of the relay will illuminate LD1 (the
protect LED on the front panel).
Soft Turn On Circuit
To reduce the inrush current that flows through the line cord from the AC power source (typical with large
linear power supplies), a circuit provides a soft turn on function. When the power switch is turned on, the
current that initially flows through the primary of the transformer must flow through R27 and R29. These
are surgistors that reduce the peak inrush current flow. After about 500 milliseconds a relays contacts
short across the surgistors so that they are not stressed by the current flowing through them under normal
operation. A circuit consisting of Q13, Q14, C77, and the associated resistors provides the time delay for
the turn on cycle of the relay. The circuit is very similar to the shutdown time delay circuit. Refer to the
section on the shutdown circuit for a circuit description.
Fan Circuit
Looking at the schematic to board M1371, here is a quick explanation of the fan control circuit. There is a
temperature sensor (AS35) on each M1370 board. When the amplifier is first turned on, Q11 and Q23 are
off. The AS35 temperature sensors are configured as temperature controlled current sources. As either
temperature sensor begins to heat up, more current flows through D18 or D19 increasing the voltage drop
across R63 or R64. The hotter temperature sensor will provide more current than the cooler sensor and
therefore develop a higher voltage across its associated 13K resistor. The higher voltage will forward bias
D18 or D19 reverse biasing the cooler temperature sensors diode so that the hotter sensor will control the
fan speed. At 40 degrees C there is 10 volts across R63 or R64 which is enough to turn on Q23 and Q11
providing 10 DC volts to the fan. Further heating the temperature sensors results in a larger DC voltage
across the fan. To lower the dissipation of Q11, D11 and D12 form a full wave rectifier in series with Q11.
The DC filtering is provided at the output of Q11. The maximum fan voltage is 28 VDC. D20 and R70
provide a current limiting function.
Thermal Shutdown Circuit
The ZD2 is the measuring point for the shutdown voltage. As the temperature sensing devices (AS35) that
control the fan circuit heat up the voltage on ZD2 rises until at 85 degrees Celsius on the M1370 heat-

sinks. The voltage reaches 33.6 (85 degrees C) VDC and the amplifier must be shutdown to protect the
output power transistors. ZD2 becomes forward biased and Q2 turns on turning the relay off and muting
the audio signal. After the amplifier cools down the voltage will decrease until Q2 turns off turning the relay
back on enabling the amplifier.
Identifying Defective Boards in the AM4
STEP 1: Visual Inspection of Front Panel and Fan
 Check to see whether the green power LED is lit. If not, the amplifier has a power supply
(M1371 board), transformer, A.C. switch or line cord problem.
 If the red protect LED stays on or samples off and on, this usually indicates a problem with
the voltage amplifier or current amplifier sections on one or both of the M1370 boards. Check
for misaligned pin connections or see if the ribbon cables have been cut or pinched through
their insulation.
 If the fan is running at full speed at power up this usually indicates a problem with the fan
circuitry on the M1371 board, but it can also be caused by M1370 circuit problems. A
damaged AS35 temperature sensor located under the M1370 heat-sinks can cause erratic fan
behavior.
 No output on either or both channels could be caused by intermittent push switches on the
input board.
STEP 2: Visual Inspection of Internal Chassis and Initial Testing
After removing the lid, look for any signs of smoke, charring or burnt components. Before powering up
replace the burnt components, and check the associated circuitry for damaged parts. Disconnect one
M1370 board and test one board at a time to reduce the possibility of further damage. Use a variac to
slowly increase the AC voltage up from 0 volts while monitoring the quiescent current with a meter and the
speaker output with an oscilloscope. Watch the speaker output for large DC offsets, or oscillation. Watch
the meter for large collector currents flowing. Remember under quiescent conditions, there should only be
3 to 5 millivolts across test points 8 and 9 on the output stage of the amplifier.

AM-4 Parts Parts List 3/27/2014
YS # Descriptio
n
Qty. YS # Descriptio
n
Qty. YS # Descriptio
n
Qty. YS # Descriptio
n
Qty.
6478 AS35FN-TO92 TEMPERATURE SENSOR 2 2448 15.00 AMP CIRCUIT BREAKER 1 4864 W250 2K7 5% T&R RES 2 3587 DPST ROKR SW QUIK 250"AC/PWR ON-OF 1
5906 RED 3MM LED 1V9 20MA.4SPCER T&R 3 3820 ___4UH COIL 14AWG ZOBEL HORIZONTAL 2 6124 W250 3K 5%MINI T&R RES 6
5908 GRN 3MM LED 1V9 20MA.4SPCER T&R 3 8521 RUBBER BUMPER WITH WASHER VERYSMALL 2 6136 W250 3K3 5%MINI T&R RES 4
6419 BRIDGE 35A 400V WIRE LEAD GI3504 3 3434 FERRULE .28" X 16GA. 3 5032 5W00 3K6 5% STANDOFF BLK RES 1
6425 BAV21 200V 0A25 DIODE T&R 20 3441 CLIP 250X032 16-14AWG RIGHT ANGLE 30 4982 W250 4K7 5%MINI T&R RES 20
6825 1N4148 75V 0A45 DIODE T&R 52 3485 CLIP 250X032 18-22AWG RIGHT ANGL 3 6128 W250 4K99 1%MINI MF T&R RES 4
6438 1N4007 1000V 1A0 DIODE T&R 13 3526 CLIP 250X032 12-10AWG DISCO-LOK 8 4978 W250 6K8 5%MINI T&R RES 2
6934 MR854 400V 3A0 DIODE FASREC 28 3601 RING TERMINAL 16AWG WIRE & #8 SCREW 2 6121 W250 6K98 1%MINI MF T&R RES 4
6432 1N5248B 18V0 0W5 ZENER 5% T&R 2 3618 STAR RING TERMINAL14-16AWG #10SCREW 4 4887 W250 7K5 5% T&R RES 2
6433 1N5257B 33V0 0W5 ZENER 5% T&R 4 3410 RED:LEFT/BLACK:RIGHT BIND POST TPP5 1 4663 W500 8K2 5% T&R RES 2
6436 1N753ARL 6V2 0W5 ZENER 5% T&R 4 3415 RED:RIGHT/BLACK:LEFT BIND POST TPP5 1 4990 W250 8K2 5%MINI T&R RES 4
6439 1N5225B 3V0 0W5 ZENER 5% T&R 2 3498 1/4" JCK PCB MT HORZ 2 4762 W250 9K760 0.1% *** T&R RES 8
6440 1N750ARL 4V7 0W5 ZENER 5% T&R 4 4053 NEUTRIK 3 POLE LOCKING POWERCON 1 4829 W250 10K 5% T&R RES 2
6463 1N5251BRL 22V0 0W5 ZENER 5% T&R 2 6956 SPKON 4C PCB MT HORZ GRY #4 2 4983 W250 10K 5%MINI T&R RES 8
6465 1N5250B 20V0 0W5 ZENER 5% T&R 2 3922 XLR FEML PCB MT HORZ THIN SNAP-IN 2 6116 W250 10K0 1%MINI MF T&R RES 14
6466 1N5256B 30V0 0W5 ZENER 5% T&R 2 2354 2 CIR XH-HEADER RA 0.098IN 1 4856 W250 12K 5% T&R RES 4
6486 1N5244B 14V0 0W5 ZENER 5% T&R 2 4056 2 CIR XH-HEADER 0.098IN 1 4901 W250 13K 5% T&R RES 2
6824 1N5246B 16V0 0W5 ZENER 5% T&R 8 2337 4 CIR XH-HEADER 0.098IN 1 4630 W500 15K 5% T&R RES 4
6822 1N4745A 16V0 1W0 ZENER 5% T&R 8 2357 4 CIR XH-HEADER RA 0.098IN 1 4830 W250 15K 5% T&R RES 10
5101 BC550C TO92 NPN TRAN T&R TB 16 2329 12 CIR XH-HEADER 0.098IN 4 4771 W250 17K8 1% T&R RES 2
5102 BC560C TO92 PNP TRAN T&R TB 14 2330 14 CIR XH-HEADER 0.098IN 2 6125 W250 18K 5%MINI T&R RES 6
5103 MPSA06 TO92 NPN TRAN T&R TA 3 3040 PATCH 04 22AWG 23.0 XH FLAT 1 6123 W250 20K0 1%MINI MF T&R RES 8
5107 2N5551 TO92 NPN TRAN T&R TA 2 3038 PATCH 12 22AWG 10.0 XH 1 6118 W250 22K 5%MINI T&R RES 4
5108 2N5401 TO92 PNP TRAN T&R TA 6 3041 PATCH 12 22AWG 26.0 XH FLAT 1 4633 W500 27K 5% T&R RES 3
6854 2N6517 TO92 NPN TRAN TA 5 3039 PATCH 14 22AWG 13.0 XH FLAT 1 6129 W250 27K 5%MINI T&R RES 4
5105 MPSA13 TO92 NPN DARL T&R TA 1 3864 FAN 92MM X 92MM 60CFM 24VDC 2 4840 W250 33K 5% T&R RES 9
5106 MPSA63 TO92 PNP DARL T&R TA 1 3501 B52200F006 COMP WASH #4 SMALL 18 4634 W500 47K 5% T&R RES 1
6814 MJF6668 T221D PNP TRAN DARL TJ 1 3518 CLEAR PVC TUBING .500" DIA. 105'C 0.35 4834 W250 47K 5% T&R RES 10
6815 MJF6388 T221D NPN TRAN DARL TJ 2 3799 ROUND BUMPER BUTTON BLACK 1 4835 W250 56K 5% T&R RES 4
6873 MJE340 TO126 NPN TRAN TG 6 3810 4" NYLON CABLE TIE 21 4760 W250 75K 5% T&R RES 8
6874 MJE350 TO126 PNP TRAN TG 6 3827 SQUARE BUMPER BUTTON BLACK 9 4838 W250 100K 5% T&R RES 5
6752 MTP10N15L TO220 NCH MFET TN 4 8661 KNOB BUTTON FLAT GREY 2 4851 W250 120K 5% T&R RES 3
6925 IRF9520PBF TO220 PCH MFET TN 4 3471 8' 3/16 SJT AC LINE CORD 250 CLIPS 1 4894 W250 130K 5% T&R RES 2
6909 MJ21196 TO3 NPN TRAN TH 24 3821 STRAIN RELIEF HEYCO #1200 1 4668 2W00 220K 5%10MM BODY T&R RES 2
7004 2SA2121-0 TO3P PNP TRAN TK 2 8701 4-40 KEPS NUT ZINC 19 4841 W250 220K 5% T&R RES 1
7005 2SC5949-0 TO3P NPN TRAN TK 2 8666 6-32 X 1/4" PEM THRD SPACER 0.213 4 6126 W250 220K 5%MINI T&R RES 10
6910 MJ21195 TO3 PNP TRAN TH 24 8760 6-32 KEPS NUT TIN PLATED 96 4842 W250 330K 5% T&R RES 1
6840 MC33078P IC DUAL OP AMP 2 8800 6-32 KEPS NUT ZINC 10 6127 W250 470K 5%MINI T&R RES 6
6884 NE5532N IC DUAL OP AMP 4 8844 6-32 PEMNUT 6 4844 W250 1M 5% T&R RES 2
6745 LM13600N IC XCONDUCTANCE AMP 2 8854 6-32 X 1/4" 0.D. HEX NUT ZINC CLEAR 2 4888 W250 4M7 5% T&R RES 2
5190 MBS4992 TO92 8V5 DIAC T&R 2 8841 10-32 KEPS NUT TIN PLATED 3 6132 W250 8M2 5%MINI T&R RES 2
6517 BTB24-600 TO220AB 25A TRIAC 600V 2 3797 TO-247 THERMO CONDUCTIVE PAD 4 4809 W250 10M 5% T&R RES 2
6880 4N35 OPTO-COUPLER 4 3846 TO220 THERMO PAD LARGE HOLE 56359B 8 3673 14" 16C-28AWG DIP HDR CABLE .05" 1
6489 __5R 20% THERM-SURGR NTC KNK LEADS 2 3916 TO3 SIL-PAD REPLACES MICA 48 3019 RELAY 1C 30AMP DC110 08MA PC-C 1
5401 _10P 500V 5%CAP T&R RAD CER.2NPO 4 4124 SILPAD 1500ST 1.100 X0.820 BERQUIST 6 3696 RELAY 1C 02AMP DC24 006MA PC-S 2
5199 100P 100V 2%CAP T&R RAD CER.2NPO 2 4745 5W0 0R1 5% BLK RES 22 8729 #4 X 3/8 FLAT QUAD TYPE A JS500 BLK 8
5197 220P 100V 2%CAP T&R RAD CER.2NPO 16 4749 5W0 0R15 5% BLK RES 4 8753 #10 X 1/2 PAN QUAD TY A JS500 BLACK 3
5412 220P 100V 10%CAP T&R BEAD NPO 2 2005 1W00 0R47 5%FLAME PROOF T&R RES 2 8861 4-40 X 3/8 PAN PH MS JS500 3
5211 330P 100V 5%CAP T&R RAD CER.2NPO 4 2006 1W00 1R 5%FLAME PROOF T&R RES 1 8871 4-40 X 5/8 PAN PH MS JS500 22
5201 470P 100V 5%CAP T&R RAD CER.2NPO 6 2007 W250 1R 5%FLAME PROOF T&R RES 24 8902 4-40 X 3/4 PAN PHIL MS B/O & WAX 4
5206 __1N 400V 5%CAP T&R RAD .2FLM 4 4677 W500 1R 5% T&R RES 8 8832 6-32 X 1/4 PAN PH TAPTITE JS500 7
5273 __1N5 200V 5%CAP T&R RAD CER.2NPO 4 4911 W250 2R2 5% T&R RES 8 8807 6-32 X 5/16 PAN PH MS JS500 4
5208 __2N2 400V 5%CAP T&R RAD .2FLM 4 4748 2W00 3R9 5% T&R RES 2 8801 6-32 X 3/8 PAN PH TAPTITE JS500 4
5274 __2N2 200V 5%CAP T&R RAD CER.2NPO 2 4733 5W00 5R6 5% BLK RES 2 8829 6-32 X 3/8 FLAT PH TAPTITE BO#C HEA 78
6451 __4N7 250V 20%CAP BLK 'Y' 10MM AC 1 2009 W250 10R 2%FLAME PROOF T&R RES 2 8761 6-32 X 1/2 PAN PHIL MS ZINC CLEAR 96
5210 _22N 100V 10%CAP T&R RAD .2FLM 9 2010 W600 10R0 2%FLAME PROOF T&R RES 6 8824 8-32 X 5/16 PAN QUAD TAPTITE JS500 2
5840 _22N 400V 10%CAP BLK RAD POLY FLM 2 4875 W250 10R 5% T&R RES 2 8999 8-32 X 5/8 PAN PH TAPTITE JS500 20
6435 _22N 275V 20%CAP BLK 'X2' 15MM AC 1 2039 W250 22R0 FUSIBLE T&R RES 2 8809 10-32 X 1/4 PAN PH TAPTITE JS500 8
5226 _68N 100V 5%CAP T&R RAD .2FLM 4 2040 W250 33R FUSIBLE T&R RES 4 8773 10-32 X 1 1/4 PN PH TT FULL THD JS5 3
5212 100N 63V 5%CAP T&R RAD .2FLM 6 2016 W600 39R 2%FLAME PROOF T&R RES 26 8772 1/4-20 X 1 TRUSS PH MS JS500 BLACK 2
5228 100N 100V 5%CAP T&R RAD .2FLM 8 2041 W250 39R0 FUSIBLE T&R RES 4 3351 16 PIN SCKT CLOSED FRAME DIP ONLY 1
5229 150N 63V 10%CAP T&R RAD .2FLM 4 4811 W250 68R 5% T&R RES 2 8663 11/64 NYLON SPACER (MICRO PLASTIC) 96
5231 220N 63V 5%CAP T&R RAD .2FLM 2 2019 W125 100R0 1%FLAME PROOF T&R RES 18 3752 SNAP IN 1/4 SPACER RICHCO 3
5882 220N 250VDC 10%CAP BLK RAD PLY FLM 8 4987 W250 120R 5%MINI T&R RES 2 8851 .250 SPACER ID.190 OD.31 ALUMINUM 6
5322 470N 50V 20%CAP T&R BEAD Z5U 2 2020 W600 150R 2%FLAME PROOF T&R RES 5 3744 SNAP IN .375 SPACER RICHCO 4
5266 680N 250V 20%CAP BLK 'X2' 27MM AC 1 4984 W250 150R 5%MINI T&R RES 10 3743 SNAP ON 0.5" SPACER RICHCO 14
5255 __1U 63V 20%CAP T&R RAD .2EL 2 2023 W600 220R0 1%FLAME PROOF T&R RES 4 3851 1/2 PCB PLASTIC SPACER 7
5259 __4U7 63V 20%CAP T&R RAD .2 4 4977 W250 220R 5%MINI T&R RES 12 3417 6-32 SCREW TERM RA PC MNT SNAP IN 2
5269 __4U7 100V 20%CAP T&R RAD LESR2 2 2046 W250 240R FUSIBLE T&R RES 4 8629 10-32 X 1/4 SPACER PHENOLIC 8
5629 _10U 160V 20%CAP BLK 10X13MM EL 5 4867 W250 270R 5% T&R RES 2 3865 1/2 PLASTIC HEX SPACER #6 2
5945 _10U 63V 20%CAP T&R RAD .2EL 4 4855 W250 330R 5% T&R RES 2 8667 SHOULDER WASHER SWS-229 LENGTH 1/8 8
5959 _10U 450V 20%CAP BLK EL 1 2048 W250 470R FUSIBLE T&R RES 4 3511 #6 FLAT WASHER NYLON 2
5260 _22U 50V 20%CAP T&R RAD .2EL 7 4980 W250 470R 5%MINI T&R RES 8 8485 #6 SPLIT WASHER ZINC 6
5961 _33U 16V 20%CAP T&R RAD .2IN NP 12 2033 W600 1K 2%FLAME PROOF T&R RES 8 8852 #6 INTERNAL TOOTH LOCKWASHER 1
5267 100U 25V 20%CAP T&R RAD .2EL 2 4823 W250 1K 5% T&R RES 3 8818 3/4 OD X 3/8 ID X .080 THICK WASHER 1
5630 330U 25V 20%CAP BLK 10X13MM EL 6 4718 5W00 1K5 5% BLK RES 4 3517 NYLON WASHER #8 0.062 5
5618 470U 25V 20%CAP BLK 10X15MM EL 1 4988 W250 1K5 5%MINI T&R RES 8 8820 #8 FLAT WASHER JS500 4
5899 3300U 100V 20%CAP BLK 25X50MM ELS 12 4791 W250 1K54 1% T&T RES 4 8921 #3MM ID3.2MM OD7.0MM THICK 5MM 8
5895 6800U 63V 20%CAP BLK 25X50MM 12 6113 W250 2K 5%MINI T&R RES 6 3705 4P3T SLID SW PCMT H 1
4520 _10K TRIM PO
T
2 6104 W250 2K2 5%MINI T&R RES 4 3436 DPDT PUSH SW PCMT H BREAK B4 MAKE 1

AM-4 M1370A REF 1 Parts List 3/27/2014
REF PART DESCRIPTION REF PART DESCRIPTION REF PART DESCRIPTION REF PART DESCRIPTION REF PART DESCRIPTION
C01C 5228 100N 100V 5%CAP T&R RAD .2FLM D17B 6825 1N4148 75V 0A45 DIODE T&R Q35
A
6909 MJ21196 TO3 NPN TRAN TH R139B 4834 W250 47K 5% T&R RES R41 6127 W250 470K 5%MINI T&R RES
C02C 5228 100N 100V 5%CAP T&R RAD .2FLM D18B 6825 1N4148 75V 0A45 DIODE T&R Q35B 6909 MJ21196 TO3 NPN TRAN TH R14 6125 W250 18K 5%MINI T&R RES R41B 2040 W250 33R FUSIBLE T&R RES
C1 5197 220P 100V 2%CAP T&R RAD CER.2NPO D19B 6825 1N4148 75V 0A45 DIODE T&R Q36
A
6910 MJ21195 TO3 PNP TRAN TH R140
A
2007 W250 1R 5%FLAME PROOF T&R RES R41C 4983 W250 10K 5%MINI T&R RES
C10 5228 100N 100V 5%CAP T&R RAD .2FLM D2 6825 1N4148 75V 0A45 DIODE T&R Q36B 6910 MJ21195 TO3 PNP TRAN TH R140B 2007 W250 1R 5%FLAME PROOF T&R RES R42 4745 5W0 0R1 5% BLK RES
C10
A
5206 __1N 400V 5%CAP T&R RAD .2FLM D20B 6825 1N4148 75V 0A45 DIODE T&R Q37
A
6910 MJ21195 TO3 PNP TRAN TH R141
A
2007 W250 1R 5%FLAME PROOF T&R RES R42
A
4977 W250 220R 5%MINI T&R RES
C10B 5961 _33U 16V 20%CAP T&R RAD .2IN NP D21B 6825 1N4148 75V 0A45 DIODE T&R Q37B 6910 MJ21195 TO3 PNP TRAN TH R141B 2007 W250 1R 5%FLAME PROOF T&R RES R42C 6116 W250 10K0 1%MINI MF T&R RES
C11 5199 100P 100V 2%CAP T&R RAD CER.2NPO D22B 6825 1N4148 75V 0A45 DIODE T&R Q38
A
6909 MJ21196 TO3 NPN TRAN TH R142
A
2007 W250 1R 5%FLAME PROOF T&R RES R43 6123 W250 20K0 1%MINI MF T&R RES
C11B 5260 _22U 50V 20%CAP T&R RAD .2EL D23B 6825 1N4148 75V 0A45 DIODE T&R Q38B 6909 MJ21196 TO3 NPN TRAN TH R142B 2007 W250 1R 5%FLAME PROOF T&R RES R44 6123 W250 20K0 1%MINI MF T&R RES
C126C 5314 100N 50V 10%CAP T&R BEAD X7R D24B 6825 1N4148 75V 0A45 DIODE T&R Q39
A
6909 MJ21196 TO3 NPN TRAN TH R143
A
2007 W250 1R 5%FLAME PROOF T&R RES R44C 4983 W250 10K 5%MINI T&R RES
C127C 5314 100N 50V 10%CAP T&R BEAD X7R D25B 6425 BAV21 200V 0A25 DIODE T&R Q39B 6909 MJ21196 TO3 NPN TRAN TH R143B 2007 W250 1R 5%FLAME PROOF T&R RES R45 6116 W250 10K0 1%MINI MF T&R RES
C12B 5260 _22U 50V 20%CAP T&R RAD .2EL D26B 6425 BAV21 200V 0A25 DIODE T&R Q3C 5102 BC560C TO92 PNP TRAN T&R TB R144
A
2007 W250 1R 5%FLAME PROOF T&R RES R45C 4774 W250 4K12 1% T&R RES
C14B 5401 _10P 500V 5%CAP T&R RAD CER.2NPO D27B 6425 BAV21 200V 0A25 DIODE T&R Q4 5108 2N5401 TO92 PNP TRAN T&R TA R144B 2007 W250 1R 5%FLAME PROOF T&R RES R46 6116 W250 10K0 1%MINI MF T&R RES
C15B 5401 _10P 500V 5%CAP T&R RAD CER.2NPO D28B 6425 BAV21 200V 0A25 DIODE T&R Q40
A
6910 MJ21195 TO3 PNP TRAN TH R145
A
2007 W250 1R 5%FLAME PROOF T&R RES R46C 4830 W250 15K 5% T&R RES
C16B 5259 __4U7 63V 20%CAP T&R RAD .2 D29
A
6934 MR854 400V 3A0 DIODE FASREC Q40B 6910 MJ21195 TO3 PNP TRAN TH R145B 2007 W250 1R 5%FLAME PROOF T&R RES R47C 4980 W250 470R 5%MINI T&R RES
C17B 5259 __4U7 63V 20%CAP T&R RAD .2 D29B 6934 MR854 400V 3A0 DIODE FASREC Q41
A
6910 MJ21195 TO3 PNP TRAN TH R146
A
4745 5W0 0R1 5% BLK RES R48C 4982 W250 4K7 5%MINI T&R RES
C17C 5410 100P 100V 10%CAP T&R BEAD NPO D3 6825 1N4148 75V 0A45 DIODE T&R Q41B 6910 MJ21195 TO3 PNP TRAN TH R146B 4749 5W0 0R15 5% BLK RES R49C 4830 W250 15K 5% T&R RES
C18B 5629 _10U 160V 20%CAP BLK 10X13MM EL D30
A
6934 MR854 400V 3A0 DIODE FASREC Q42
A
6909 MJ21196 TO3 NPN TRAN TH R147
A
4745 5W0 0R1 5% BLK RES R4C 6127 W250 470K 5%MINI T&R RES
C18C 5410 100P 100V 10%CAP T&R BEAD NPO D30B 6934 MR854 400V 3A0 DIODE FASREC Q42B 6909 MJ21196 TO3 NPN TRAN TH R147B 4745 5W0 0R1 5% BLK RES R5 4978 W250 6K8 5%MINI T&R RES
C19B 5629 _10U 160V 20%CAP BLK 10X13MM EL D31
A
6934 MR854 400V 3A0 DIODE FASREC Q43
A
6909 MJ21196 TO3 NPN TRAN TH R148
A
4745 5W0 0R1 5% BLK RES R50B 6128 W250 4K99 1%MINI MF T&R RES
C1C 5412 220P 100V 10%CAP T&R BEAD NPO D31B 6934 MR854 400V 3A0 DIODE FASREC Q43B 6909 MJ21196 TO3 NPN TRAN TH R148B 4745 5W0 0R1 5% BLK RES R50C 4830 W250 15K 5% T&R RES
C2 5197 220P 100V 2%CAP T&R RAD CER.2NPO D32
A
6934 MR854 400V 3A0 DIODE FASREC Q44
A
6910 MJ21195 TO3 PNP TRAN TH R149
A
4745 5W0 0R1 5% BLK RES R51B 4775 W250 14K0 1% T&R RES
C20B 5630 330U 25V 20%CAP BLK 10X13MM EL D32B 6934 MR854 400V 3A0 DIODE FASREC Q44B 6910 MJ21195 TO3 PNP TRAN TH R149B 4749 5W0 0R15 5% BLK RES R51C 6126 W250 220K 5%MINI T&R RES
C21B 5274 __2N2 200V 5%CAP T&R RAD CER.2NPO D33
A
6934 MR854 400V 3A0 DIODE FASREC Q45
A
6910 MJ21195 TO3 PNP TRAN TH R15 2019 W125 100R0 1%FLAME PROOF T&R RES R52B 6128 W250 4K99 1%MINI MF T&R RES
C21C 5231 220N 63V 5%CAP T&R RAD .2FLM D33B 6934 MR854 400V 3A0 DIODE FASREC Q45B 6910 MJ21195 TO3 PNP TRAN TH R150
A
4745 5W0 0R1 5% BLK RES R52C 4980 W250 470R 5%MINI T&R RES
C22B 5208 __2N2 400V 5%CAP T&R RAD .2FLM D34
A
6934 MR854 400V 3A0 DIODE FASREC Q46B 5101 BC550C TO92 NPN TRAN T&R TB R150B 4745 5W0 0R1 5% BLK RES R53B 4775 W250 14K0 1% T&R RES
C22C 5231 220N 63V 5%CAP T&R RAD .2FLM D34B 6934 MR854 400V 3A0 DIODE FASREC Q47B 5102 BC560C TO92 PNP TRAN T&R TB R151
A
4745 5W0 0R1 5% BLK RES R53C 4977 W250 220R 5%MINI T&R RES
C23B 5208 __2N2 400V 5%CAP T&R RAD .2FLM D35
A
6934 MR854 400V 3A0 DIODE FASREC Q4C 5102 BC560C TO92 PNP TRAN T&R TB R151B 4745 5W0 0R1 5% BLK RES R54B 4834 W250 47K 5% T&R RES
C24B 5945 _10U 63V 20%CAP T&R RAD .2EL D36
A
6934 MR854 400V 3A0 DIODE FASREC Q5C 5102 BC560C TO92 PNP TRAN T&R TB R152B 4987 W250 120R 5%MINI T&R RES R55AC 4977 W250 220R 5%MINI T&R RES
C25B 5945 _10U 63V 20%CAP T&R RAD .2EL D37 6438 1N4007 1000V 1A0 DIODE T&R Q6C 5102 BC560C TO92 PNP TRAN T&R TB R153B 4867 W250 270R 5% T&R RES R55B 4982 W250 4K7 5%MINI T&R RES
C25C 5961 _33U 16V 20%CAP T&R RAD .2IN NP D37B 6425 BAV21 200V 0A25 DIODE T&R Q7B 5107 2N5551 TO92 NPN TRAN T&R TA R156B 4748 2W00 3R9 5% T&R RES R55BC 4977 W250 220R 5%MINI T&R RES
C26B 5630 330U 25V 20%CAP BLK 10X13MM EL D38 6438 1N4007 1000V 1A0 DIODE T&R Q8B 5108 2N5401 TO92 PNP TRAN T&R TA R16 2019 W125 100R0 1%FLAME PROOF T&R RES R56B 4982 W250 4K7 5%MINI T&R RES
C26C 5961 _33U 16V 20%CAP T&R RAD .2IN NP D38B 6425 BAV21 200V 0A25 DIODE T&R R04C 4830 W250 15K 5% T&R RES R160B 6126 W250 220K 5%MINI T&R RES R57B 4977 W250 220R 5%MINI T&R RES
C27B 5630 330U 25V 20%CAP BLK 10X13MM EL D4 6438 1N4007 1000V 1A0 DIODE T&R R1 6116 W250 10K0 1%MINI MF T&R RES R162B 4911 W250 2R2 5% T&R RES R58B 4982 W250 4K7 5%MINI T&R RES
C28B 5255 __1U 63V 20%CAP T&R RAD .2EL D5B 6825 1N4148 75V 0A45 DIODE T&R R10 2019 W125 100R0 1%FLAME PROOF T&R RES R165B 4911 W250 2R2 5% T&R RES R59B 4982 W250 4K7 5%MINI T&R RES
C29
A
5882 220N 250VDC 10%CAP BLK RAD PLY FLM D6B 6825 1N4148 75V 0A45 DIODE T&R R100B 2046 W250 240R FUSIBLE T&R RES R167B 2033 W600 1K 2%FLAME PROOF T&R RES R5C 6132 W250 8M2 5%MINI T&R RES
C29B 5882 220N 250VDC 10%CAP BLK RAD PLY FLM D6C 6825 1N4148 75V 0A45 DIODE T&R R101B 6116 W250 10K0 1%MINI MF T&R RES R168B 2033 W600 1K 2%FLAME PROOF T&R RES R6 4982 W250 4K7 5%MINI T&R RES
C2C 5412 220P 100V 10%CAP T&R BEAD NPO D7 6825 1N4148 75V 0A45 DIODE T&R R102B 4840 W250 33K 5% T&R RES R17 4856 W250 12K 5% T&R RES R60B 6116 W250 10K0 1%MINI MF T&R RES
C3 5211 330P 100V 5%CAP T&R RAD CER.2NPO D8 6438 1N4007 1000V 1A0 DIODE T&R R103B 2039 W250 22R0 FUSIBLE T&R RES R170B 2023 W600 220R0 1%FLAME PROOF T&R RES R60C1 6118 W250 22K 5%MINI T&R RES
C30
A
5882 220N 250VDC 10%CAP BLK RAD PLY FLM D9 6825 1N4148 75V 0A45 DIODE T&R R104B 2016 W600 39R 2%FLAME PROOF T&R RES R173B 2023 W600 220R0 1%FLAME PROOF T&R RES R61B 4771 W250 17K8 1% T&R RES
C30B 5882 220N 250VDC 10%CAP BLK RAD PLY FLM D9B 6825 1N4148 75V 0A45 DIODE T&R R105B 2016 W600 39R 2%FLAME PROOF T&R RES R177 4809 W250 10M 5% T&R RES R61C 6125 W250 18K 5%MINI T&R RES
C31B 5210 _22N 100V 10%CAP T&R RAD .2FLM D9C 6825 1N4148 75V 0A45 DIODE T&R R106B 2019 W125 100R0 1%FLAME PROOF T&R RES R18 4834 W250 47K 5% T&R RES R62B 6124 W250 3K 5%MINI T&R RES
C32B 5210 _22N 100V 10%CAP T&R RAD .2FLM EC25 3865 1/2 PLASTIC HEX SPACER #6 R107B 2005 1W00 0R47 5%FLAME PROOF T&R RES R19 4983 W250 10K 5%MINI T&R RES R63B 6113 W250 2K 5%MINI T&R RES
C33B 5208 __2N2 400V 5%CAP T&R RAD .2FLM EC26 3865 1/2 PLASTIC HEX SPACER #6 R108B 2048 W250 470R FUSIBLE T&R RES R1C 4838 W250 100K 5% T&R RES R66B 2033 W600 1K 2%FLAME PROOF T&R RES
C34B 5273 __1N5 200V 5%CAP T&R RAD CER.2NPO K1 3696 RELAY 1C 02AMP DC24 006MA PC-S R109B 2048 W250 470R FUSIBLE T&R RES R2 6116 W250 10K0 1%MINI MF T&R RES R67B 2033 W600 1K 2%FLAME PROOF T&R RES
C35B 5201 470P 100V 5%CAP T&R RAD CER.2NPO LD1C 5908 GRN 3MM LED 1V9 20MA.4SPCER T&R R11 2019 W125 100R0 1%FLAME PROOF T&R RES R20 4982 W250 4K7 5%MINI T&R RES R7 4983 W250 10K 5%MINI T&R RES
C35C 5260 _22U 50V 20%CAP T&R RAD .2EL LD2C 5908 GRN 3MM LED 1V9 20MA.4SPCER T&R R110B 6124 W250 3K 5%MINI T&R RES R21 6126 W250 220K 5%MINI T&R RES R70B 6113 W250 2K 5%MINI T&R RES
C36
A
5201 470P 100V 5%CAP T&R RAD CER.2NPO LD5C 5906 RED 3MM LED 1V9 20MA.4SPCER T&R R111B 6124 W250 3K 5%MINI T&R RES R22 4988 W250 1K5 5%MINI T&R RES R71B 2020 W600 150R 2%FLAME PROOF T&R RES
C36B 5201 470P 100V 5%CAP T&R RAD CER.2NPO LD6C 5906 RED 3MM LED 1V9 20MA.4SPCER T&R R112B 6104 W250 2K2 5%MINI T&R RES R23 4983 W250 10K 5%MINI T&R RES R74B 2020 W600 150R 2%FLAME PROOF T&R RES
C36C 5260 _22U 50V 20%CAP T&R RAD .2EL P1C 4390 _10K AUD 16MM DETENT P22 R113B 4982 W250 4K7 5%MINI T&R RES R24 4844 W250 1M 5% T&R RES R75B 4990 W250 8K2 5%MINI T&R RES
C37B 5210 _22N 100V 10%CAP T&R RAD .2FLM P2C 4390 _10K AUD 16MM DETENT P22 R114B 6104 W250 2K2 5%MINI T&R RES R25 4988 W250 1K5 5%MINI T&R RES R76B 6136 W250 3K3 5%MINI T&R RES
C37C 5412 220P 100V 10%CAP T&R BEAD NPO Q1 5103 MPSA06 TO92 NPN TRAN T&R TA R115B 4982 W250 4K7 5%MINI T&R RES R26 4887 W250 7K5 5% T&R RES R77B 2016 W600 39R 2%FLAME PROOF T&R RES
C38B 5210 _22N 100V 10%CAP T&R RAD .2FLM Q10B 5102 BC560C TO92 PNP TRAN T&R TB R116B 6126 W250 220K 5%MINI T&R RES R27 4988 W250 1K5 5%MINI T&R RES R78B 2016 W600 39R 2%FLAME PROOF T&R RES
C38C 5412 220P 100V 10%CAP T&R BEAD NPO Q11B 6874 MJE350 TO126 PNP TRAN TG R117B 6125 W250 18K 5%MINI T&R RES R28 4988 W250 1K5 5%MINI T&R RES R79B 6136 W250 3K3 5%MINI T&R RES
C39B 5840 _22N 400V 10%CAP BLK RAD POLY FLM Q12B 6873 MJE340 TO126 NPN TRAN TG R118B 6126 W250 220K 5%MINI T&R RES R29 4980 W250 470R 5%MINI T&R RES R7C 4983 W250 10K 5%MINI T&R RES
C39C 5211 330P 100V 5%CAP T&R RAD CER.2NPO Q13B 5101 BC550C TO92 NPN TRAN T&R TB R119B 4982 W250 4K7 5%MINI T&R RES R29C 4977 W250 220R 5%MINI T&R RES R8 2019 W125 100R0 1%FLAME PROOF T&R RES
C3C 5322 470N 50V 20%CAP T&R BEAD Z5U Q15B 5101 BC550C TO92 NPN TRAN T&R TB R12 2019 W125 100R0 1%FLAME PROOF T&R RES R2C 4838 W250 100K 5% T&R RES R80B 4990 W250 8K2 5%MINI T&R RES
C4 5228 100N 100V 5%CAP T&R RAD .2FLM Q16B 5102 BC560C TO92 PNP TRAN T&R TB R120B 4984 W250 150R 5%MINI T&R RES R3 6116 W250 10K0 1%MINI MF T&R RES R81B 4668 2W00 220K 5%10MM BODY T&R RES
C40B 5961 _33U 16V 20%CAP T&R RAD .2IN NP Q17B 6873 MJE340 TO126 NPN TRAN TG R121B 4980 W250 470R 5%MINI T&R RES R30 4838 W250 100K 5% T&R RES R82B 2010 W600 10R0 2%FLAME PROOF T&R RES
C40C 5211 330P 100V 5%CAP T&R RAD CER.2NPO Q18B 6874 MJE350 TO126 PNP TRAN TG R122
A
4677 W500 1R 5% T&R RES R30C 4980 W250 470R 5%MINI T&R RES R83B 2016 W600 39R 2%FLAME PROOF T&R RES
C42 5273 __1N5 200V 5%CAP T&R RAD CER.2NPO Q19B 5102 BC560C TO92 PNP TRAN T&R TB R122B 4677 W500 1R 5% T&R RES R31 4855 W250 330R 5% T&R RES R84B 2016 W600 39R 2%FLAME PROOF T&R RES
C4C 5322 470N 50V 20%CAP T&R BEAD Z5U Q1C 5105 MPSA13 TO92 NPN DARL T&R TA R123
A
4677 W500 1R 5% T&R RES R31C 6126 W250 220K 5%MINI T&R RES R85B 2010 W600 10R0 2%FLAME PROOF T&R RES
C5 5197 220P 100V 2%CAP T&R RAD CER.2NPO Q2 5101 BC550C TO92 NPN TRAN T&R TB R123B 4677 W500 1R 5% T&R RES R32 4977 W250 220R 5%MINI T&R RES R86B 2010 W600 10R0 2%FLAME PROOF T&R RES
C5C 5314 100N 50V 10%CAP T&R BEAD X7R Q20B 5101 BC550C TO92 NPN TRAN T&R TB R124B 2019 W125 100R0 1%FLAME PROOF T&R RES R32C 4830 W250 15K 5% T&R RES R87B 2016 W600 39R 2%FLAME PROOF T&R RES
C6 5197 220P 100V 2%CAP T&R RAD CER.2NPO Q21B 5102 BC560C TO92 PNP TRAN T&R TB R125
A
2041 W250 39R0 FUSIBLE T&R RES R33 4977 W250 220R 5%MINI T&R RES R88B 4811 W250 68R 5% T&R RES
C6C 5314 100N 50V 10%CAP T&R BEAD X7R Q22B 5101 BC550C TO92 NPN TRAN T&R TB R125B 2016 W600 39R 2%FLAME PROOF T&R RES R33C 4982 W250 4K7 5%MINI T&R RES R89B 4984 W250 150R 5%MINI T&R RES
C7 5269 __4U7 100V 20%CAP T&R RAD LESR2 Q23B 6873 MJE340 TO126 NPN TRAN TG R126B 2019 W125 100R0 1%FLAME PROOF T&R RES R34 4760 W250 75K 5% T&R RES R8C 4983 W250 10K 5%MINI T&R RES
C8 5211 330P 100V 5%CAP T&R RAD CER.2NPO Q24B 6874 MJE350 TO126 PNP TRAN TG R127
A
2041 W250 39R0 FUSIBLE T&R RES R34C 4980 W250 470R 5%MINI T&R RES R9 6125 W250 18K 5%MINI T&R RES
C8B 5961 _33U 16V 20%CAP T&R RAD .2IN NP Q25B 7005 2SC5949-0 TO3P NPN TRAN TK R127B 2016 W600 39R 2%FLAME PROOF T&R RES R35 4760 W250 75K 5% T&R RES R90B 4911 W250 2R2 5% T&R RES
C9 5228 100N 100V 5%CAP T&R RAD .2FLM Q26B 7004 2SA2121-0 TO3P PNP TRAN TK R13 4856 W250 12K 5% T&R RES R35C 6116 W250 10K0 1%MINI MF T&R RES R91B 4911 W250 2R2 5% T&R RES
C9B 5961 _33U 16V 20%CAP T&R RAD .2IN NP Q27B 6854 2N6517 TO92 NPN TRAN TA R130B 4718 5W00 1K5 5% BLK RES R36 4760 W250 75K 5% T&R RES R92B 4984 W250 150R 5%MINI T&R RES
D1 6825 1N4148 75V 0A45 DIODE T&R Q28B 6854 2N6517 TO92 NPN TRAN TA R131B 4718 5W00 1K5 5% BLK RES R36C 6132 W250 8M2 5%MINI T&R RES R93B 6121 W250 6K98 1%MINI MF T&R RES
D10 6425 BAV21 200V 0A25 DIODE T&R Q29B 5101 BC550C TO92 NPN TRAN T&R TB R132
A
2016 W600 39R 2%FLAME PROOF T&R RES R37 4760 W250 75K 5% T&R RES R94B 4984 W250 150R 5%MINI T&R RES
D10B 6825 1N4148 75V 0A45 DIODE T&R Q2C 5106 MPSA63 TO92 PNP DARL T&R TA R132B 2016 W600 39R 2%FLAME PROOF T&R RES R38 6129 W250 27K 5%MINI T&R RES R95B 4864 W250 2K7 5% T&R RES
D11 6425 BAV21 200V 0A25 DIODE T&R Q3 5108 2N5401 TO92 PNP TRAN T&R TA R133
A
2016 W600 39R 2%FLAME PROOF T&R RES R39 6129 W250 27K 5%MINI T&R RES R96B 4984 W250 150R 5%MINI T&R RES
D11B 6825 1N4148 75V 0A45 DIODE T&R Q32
A
6752 MTP10N15L TO220 NCH MFET TN R133B 2016 W600 39R 2%FLAME PROOF T&R RES R39C 4830 W250 15K 5% T&R RES R97B 6121 W250 6K98 1%MINI MF T&R RES
D12 6425 BAV21 200V 0A25 DIODE T&R Q32B 6752 MTP10N15L TO220 NCH MFET TN R134B 4834 W250 47K 5% T&R RES R3C 6127 W250 470K 5%MINI T&R RES R98B 6116 W250 10K0 1%MINI MF T&R RES
D12B 6825 1N4148 75V 0A45 DIODE T&R Q33
A
6925 IRF9520PBF TO220 PCH MFET TN R135B 6118 W250 22K 5%MINI T&R RES R4 6116 W250 10K0 1%MINI MF T&R RES R99B 2046 W250 240R FUSIBLE T&R RES
D13 6425 BAV21 200V 0A25 DIODE T&R Q33B 6925 IRF9520PBF TO220 PCH MFET TN R136B 4830 W250 15K 5% T&R RES R40 6127 W250 470K 5%MINI T&R RES RTB 4520 _10K TRIM POT
D13B 6825 1N4148 75V 0A45 DIODE T&R Q34
A
6909 MJ21196 TO3 NPN TRAN TH R137B 4830 W250 15K 5% T&R RES R40B 2040 W250 33R FUSIBLE T&R RES TP1
A
5299 24AWG SOLID SC WIR RAD JMP
D14B 6825 1N4148 75V 0A45 DIODE T&
R
Q34B 6909 MJ21196 TO3 NPN TRAN T
H
R138B 6118 W250 22K 5%MINI T&R RES R40C 4774 W250 4K12 1% T&R RES TP2B 5299 24AWG SOLID SC WIR RAD JMP

AM-4 M1370A REF 2 Parts List 3/27/2014
REF PART DESCRIPTION REF PART DESCRIPTION REF PART DESCRIPTION REF PART DESCRIPTION REF PART DESCRIPTION
TP3
A
5299 24AWG SOLID SC WIR RAD JMP ZD1 6463 1N5251BRL 22V0 0W5 ZENER 5% T&R
TP3B 5299 24AWG SOLID SC WIR RAD JMP ZD10
A
6822 1N4745A 16V0 1W0 ZENER 5% T&R
TP4B 5299 24AWG SOLID SC WIR RAD JMP ZD10B 6822 1N4745A 16V0 1W0 ZENER 5% T&R
TP6B 5299 24AWG SOLID SC WIR RAD JMP ZD11
A
6822 1N4745A 16V0 1W0 ZENER 5% T&R
U1 6884 NE5532N IC DUAL OP AMP ZD11B 6822 1N4745A 16V0 1W0 ZENER 5% T&R
U2 6745 LM13600N IC XCONDUCTANCE AMP ZD1C 6439 1N5225B 3V0 0W5 ZENER 5% T&R
U2C 6840 MC33078P IC DUAL OP AMP ZD2 6433 1N5257B 33V0 0W5 ZENER 5% T&R
U3A 6884 NE5532N IC DUAL OP AMP ZD2C 6440 1N750ARL 4V7 0W5 ZENER 5% T&R
U4 6478 AS35FN-TO92 TEMPERATURE SENSOR ZD3 6433 1N5257B 33V0 0W5 ZENER 5% T&R
U5 6880 4N35 OPTO-COUPLER ZD3C 6439 1N5225B 3V0 0W5 ZENER 5% T&R
U6 6880 4N35 OPTO-COUPLER ZD4 6824 1N5246B 16V0 0W5 ZENER 5% T&R
W6 3562 16 PIN SOCKET W3116T WINSLOW ZD4B 6486 1N5244B 14V0 0W5 ZENER 5% T&R
W7 2329 12 CIR XH-HEADER 0.098IN ZD5 6824 1N5246B 16V0 0W5 ZENER 5% T&R
X1 4599 22AWG SOLID SC WIR T&R JMP ZD5B 6824 1N5246B 16V0 0W5 ZENER 5% T&R
X10 4599 22AWG SOLID SC WIR T&R JMP ZD6 6824 1N5246B 16V0 0W5 ZENER 5% T&R
X11 4599 22AWG SOLID SC WIR T&R JMP ZD6B 6440 1N750ARL 4V7 0W5 ZENER 5% T&R
X12 4599 22AWG SOLID SC WIR T&R JMP ZD7B 6465 1N5250B 20V0 0W5 ZENER 5% T&R
X13 4599 22AWG SOLID SC WIR T&R JMP ZD8 6436 1N753ARL 6V2 0W5 ZENER 5% T&R
X14 4599 22AWG SOLID SC WIR T&R JMP ZD9 6436 1N753ARL 6V2 0W5 ZENER 5% T&R
X15 4599 22AWG SOLID SC WIR T&R JMP
X17 4599 22AWG SOLID SC WIR T&R JMP
X18 4599 22AWG SOLID SC WIR T&R JMP
X19 4599 22AWG SOLID SC WIR T&R JMP
X2 4599 22AWG SOLID SC WIR T&R JMP
X20 4599 22AWG SOLID SC WIR T&R JMP
X21 4599 22AWG SOLID SC WIR T&R JMP
X22 4599 22AWG SOLID SC WIR T&R JMP
X23 4599 22AWG SOLID SC WIR T&R JMP
X24 4599 22AWG SOLID SC WIR T&R JMP
X25 4599 22AWG SOLID SC WIR T&R JMP
X26 4599 22AWG SOLID SC WIR T&R JMP
X27 4599 22AWG SOLID SC WIR T&R JMP
X28 4599 22AWG SOLID SC WIR T&R JMP
X29 4599 22AWG SOLID SC WIR T&R JMP
X3 4599 22AWG SOLID SC WIR T&R JMP
X30 4599 22AWG SOLID SC WIR T&R JMP
X31 4599 22AWG SOLID SC WIR T&R JMP
X32 4599 22AWG SOLID SC WIR T&R JMP
X33 4599 22AWG SOLID SC WIR T&R JMP
X34 4599 22AWG SOLID SC WIR T&R JMP
X35 4599 22AWG SOLID SC WIR T&R JMP
X36 4599 22AWG SOLID SC WIR T&R JMP
X37 4599 22AWG SOLID SC WIR T&R JMP
X38 5299 24AWG SOLID SC WIR RAD JMP
X39 5299 24AWG SOLID SC WIR RAD JMP
X3C 4599 22AWG SOLID SC WIR T&R JMP
X4 4599 22AWG SOLID SC WIR T&R JMP
X40 4599 22AWG SOLID SC WIR T&R JMP
X41 4599 22AWG SOLID SC WIR T&R JMP
X42 4599 22AWG SOLID SC WIR T&R JMP
X43 4599 22AWG SOLID SC WIR T&R JMP
X44 4599 22AWG SOLID SC WIR T&R JMP
X45 4599 22AWG SOLID SC WIR T&R JMP
X46 4599 22AWG SOLID SC WIR T&R JMP
X47 4599 22AWG SOLID SC WIR T&R JMP
X48 4599 22AWG SOLID SC WIR T&R JMP
X49 5299 24AWG SOLID SC WIR RAD JMP
X4C 4599 22AWG SOLID SC WIR T&R JMP
X5 5299 24AWG SOLID SC WIR RAD JMP
X50 5299 24AWG SOLID SC WIR RAD JMP
X51 4599 22AWG SOLID SC WIR T&R JMP
X52 4599 22AWG SOLID SC WIR T&R JMP
X53 4599 22AWG SOLID SC WIR T&R JMP
X54 4599 22AWG SOLID SC WIR T&R JMP
X55 4599 22AWG SOLID SC WIR T&R JMP
X56 4599 22AWG SOLID SC WIR T&R JMP
X57 4599 22AWG SOLID SC WIR T&R JMP
X6 4599 22AWG SOLID SC WIR T&R JMP
X60 4599 22AWG SOLID SC WIR T&R JMP
X63 4599 22AWG SOLID SC WIR T&R JMP
X63C 4599 22AWG SOLID SC WIR T&R JMP
X64 4599 22AWG SOLID SC WIR T&R JMP
X66 4599 22AWG SOLID SC WIR T&R JMP
X67 4599 22AWG SOLID SC WIR T&R JMP
X68 4599 22AWG SOLID SC WIR T&R JMP
X69 4599 22AWG SOLID SC WIR T&R JMP
X6C 4599 22AWG SOLID SC WIR T&R JMP
X7 4599 22AWG SOLID SC WIR T&R JMP
X8 4599 22AWG SOLID SC WIR T&R JMP
X9 4599 22AWG SOLID SC WIR T&R JMP

22 22
21 21
20 20
19 19
18 18
17 17
16 16
15 15
14 14
13 13
12 12
11 11
10 10
9 9
8 8
7 7
6 6
5 5
4 4
3 3
2 2
1 1
A
A
B
B
C
C
D
D
E
E
F
F
G
G
H
H
I
I
J
J
K
K
L
L
M
M
N
N
O
O
P
P
Q
Q
R
R
S
S
T
T
U
U
V
V
W
W
X
X
Y
Y
Z
Z
AA
AA
AB
AB
AC
AC
AD
AD
AE
AE
AF
AF
AG
AG
AH
AH
3
X8002V900_001.sch2002
Date:
Product
PCB# of
Rev: Sheet 1 9V00
Filename:
Thu Oct 13, 2011 X8002
AM4CE POWER AMP 3
X8002V900_001.sch2002
Date:
Product
PCB# of
Rev: Sheet 1 9V00
Filename:
Thu Oct 13, 2011 X8002
C17B63V4U7 C16B63V4U7
R85B
1/8W
FLMP
10R0
R84B
1/8W
FLMP
39RC18B160V10UR82B
1/8W
FLMP
10R0
C21B200V2N2
R111B
1/4W
MINI
3K
R113B
1/4W
MINI
4K7
1N5246B16V0
ZD6 0W5 R144B
1/4W
FLMP
1R
R147A
5.0W
.
0R1
C39B400V22N
4148
D9B
4148
D10B
C19B160V10UR83B
1/8W
FLMP
39R
D33B
MR854
R150A
5.0W
.
0R1
D32A
MR854
M1176/M1178
4148
D12B
4148
D18B
R99B
1/4W
FUSIBLE
241R
D22B
4148
C35B 100V470P
BAV21
D38B
BAV21
D12
C8 100V330P
C3 100V330P
C11B50V22U
R59B
1/4W
MINI
4K7
4148
D14B
4148
D13B
4148
D11B
R56B
1/4W
MINI
4K7
R54B
1/4W
.
47K
C15B500V10P
Q8B
5108
TO92
2N5401
R67B
1/8W
FLMP
1K
Q7B
5107
TO92
2N5551
C14B500V10P
R63B
1/4W
MINI
2K
R74B
1/8W
FLMP
150R
R80B
1/4W
MINI
8K2
R78B
1/8W
FLMP
39R
4148
D20B
4148
D19B
D21B
4148
Q10B
5102
TO92
BC560C
R77B
1/8W
FLMP
39R
R71B
1/8W
FLMP
150R
R75B
1/4W
MINI
8K2
8
V+
4V-
U3A:C
R87B
1/8W
FLMP
39R
R88B
1/4W
.
68R
R100B
1/4W
FUSIBLE
241R
R96B
1/4W
MINI
150RC22B400V2N2
R98B
1/4W
MINI
10K0
R93B
1/4W
MINI
6K98
6874
Q24B
MJE350
TO126
{Function}
R104B
1/8W
FLMP
39R
R106B
1/8W
FLMP
100R0
R42A
1/4W
MINI
220R
4148
D23B
C26B25V330U
R41
1/4W
MINI
470K
R39
1/4W
MINI
27K
R131B
5.0W
.
1K5
4148
D24B
R115B
1/4W
MINI
4K7
R114B
1/4W
MINI
2K2
R112B
1/4W
MINI
2K2
R32
1/4W
MINI
220R
C30A 250V220N
R121B
1/4W
MINI
470R
TO92
BC550C
Q29B
5101
R117B
1/4W
MINI
18K
R116B
1/4W
MINI
220K
R118B
1/4W
MINI
220K
C29B 250V220N
C29A 250V220N
C33B 400V1N
D37B
BAV21
4
6
5
U6:B 4N35
6880
R127A
1/4W
FUSIBLE
39R0
4007
D37
R123A
1/2W
.
1R
TO92
BC560C
Q47B
5102
BAV21
D26B
R168B
1/8W
FLMP
1K
TO92
BC550C
Q46B
5101
R167B
1/8W
FLMP
1K
R122B
1/2W
.
1R
R122A
1/2W
.
1R
R33
1/4W
MINI
220R
R133A
1/8W
FLMP
39R
R143B
1/4W
FLMP
1R
C38B
100V22N
D27B
BAV21
C37B 100V22N
R173B
1/8W
FLMP
220R0
R132A
1/8W
FLMP
39R
BAV21
D10
R125A
1/4W
FUSIBLE
39R0
R37
1/4W
.
75K
R36
1/4W
.
75K
D32B
MR854
R170B
1/8W
FLMP
220R0
R153B
1/4W
.
270R
R146B
5.0W
.
0R15
MR854
D29B
R147B
5.0W
.
0R1
Q39B
6909
{Function}
MJ21196
TO3
MR854
D30B
R35
1/4W
.
75K
R34
1/4W
.
75K
D34B
MR854
R148B
5.0W
.
0R1
Q43B
6909
{Function}
MJ21196
TO3
R145A
1/4W
FLMP
1R
R148A
5.0W
.
0R1
R142A
1/4W
FLMP
1R
R144A
1/4W
FLMP
1R R141A
1/4W
FLMP
1R
R143A
1/4W
FLMP
1R
R140A
1/4W
FLMP
1R
MR854
D30A
MR854
D29A
U3A:B
NE5532N
C12B50V22U
C10B16V33U
R58B
1/4W
MINI
4K7
R55B
1/4W
MINI
4K7
R70B
1/4W
MINI
2K
C8B 16V33U
R66B
1/8W
FLMP
1K
Q13B
5101
TO92
BC550C
R79B
1/4W
MINI
3K3
4148
D17B
MJE350
6874
Q11B
TO126
{Function}
R76B
1/4W
MINI
3K3
B E
TO-92
BC560C
C
BC550C
R81B
2.0W
10MM
220K
C20B25V330U
R86B
1/8W
FLMP
10R0
C23B400V2N2 R95B
1/4W
.
2K7
R101B
1/4W
MINI
10K0
R97B
1/4W
MINI
6K98
R94B
1/4W
MINI
150R
R105B
1/8W
FLMP
39R
R103B
1/4W
FLMP
22R
R109B
1/4W
FUSIBLE
471R
6873
Q23B
MJE340
TO126
{Function}
R108B
1/4W
FUSIBLE
471R
C27B25V330U
1N5246B 16V0
ZD5B0W5 1N5244B 14V0
ZD4B0W5
4
6
5
U5:B 4N35
6880
TO92
2N6517
Q27B
6854
R160B
1/4W
MINI
220K
C30B 250V220N
1N5250B 20V0
ZD7B0W5
R120B
1/4W
MINI
150R
R123B
1/2W
.
1R
R165B
1/4W
.
2R2
BAV21
D25B
R162B
1/4W
.
2R2
BAV21
D28B
R140B
1/4W
FLMP
1R
R149B
5.0W
.
0R15
Q34B
6909
{Function}
MJ21196
TO3
Q35B
6909
{Function}
MJ21196
TO3
G
D
S
Q32A
6752
IRF630NPBF
NTO220
{Function}
Q41B
6910
{Function}
MJ21195
TO3
Q40B
6910
{Function}
MJ21195
TO3
R150B
5.0W
.
0R1
Q38B
6909
{Function}
MJ21196
TO3
Q44B
6910
{Function}
MJ21195
TO3
R151B
5.0W
.
0R1
Q42B
6909
{Function}
MJ21196
TO3
R142B
1/4W
FLMP
1R
R151A
5.0W
.
0R1
D34A
MR854
D33A
MR854
R156B
2.0W
.
3R9
B C E
MJL21194
MJL1302A
MJL3281A
MJL21193
2SA2121-0
2SC5949-0
IRF830
MTP12P10
MTP10N15L
IRL2910
IRF5210
MTP2P50E
MTP8P20
IRF720
MTP23P06
IRF822
IRF4905
G D S B C
TO-92
MPSA63
MPSA43
2N5551
E
MPSA56
MPSA06
MPSA13
2N5401
BOTTOM
VIEW
E
MJE11025
B
RTB
4520
M
Lin
10K
Function
C9B 16V33U R52B
1/4W
MINI
4K99
AmpInput[J5]
X3
M1370
AmpInput[M9]
C36B 100V470P
ZD11A
1N4745A 16V0
1W0
1N4745A16V0
ZD10B 1W0
C42 200V1N5
1N753ARL6V2
ZD9 0W5
R44
1/4W
MINI
20K0
R50B
1/4W
MINI
4K99
C40B16V33U
R41B
1/4W
FUSIBLE
33R
R57B
1/4W
MINI
220R
R62B
1/4W
MINI
3K
R61B
1/4W
.
17K8
R60B
1/4W
MINI
10K0
AM-4
R40B
1/4W
FUSIBLE
33R
AmpInput[N4]
AmpInput[P5]
TO92
BC550C
Q22B
5101
Q16B
5102
TO92
BC560C
TO92
BC560C
Q21B
5102
R90B
1/4W
.
2R2
TO92
BC550C
Q20B
5101
6873
Q17B
MJE340
TO126
{Function}
Q15B
5101
TO92
BC550C
C24B63V10U
R89B
1/4W
MINI
150R
ZD8
1N753ARL 6V2
0W5
R127B
1/8W
FLMP
39R
R126B
1/8W
FLMP
100R0
C32B 100V22N
D13
BAV21
7004
Q26B
2SA2121-0
TO3P
C28B63V1U
R119B
1/4W
MINI
4K7
R107B
1.0W
FLMP
0R47
R110B
1/4W
MINI
3K
7005
Q25B
2SC5949-0
TO3P
C10A
400V 1N
R125B
1/8W
FLMP
39R
R124B
1/8W
FLMP
100R0
R130B
5.0W
.
1K5
R40
1/4W
MINI
470K
1
2
U6:A
4N35
6880
C36A 100V470P
D S
G
Q33A
6925
P
IRF9520PBF
TO220
{Function}
Q36B
6910
{Function}
MJ21195
TO3
R145B
1/4W
FLMP
1R
R139B
1/4W
.
47K
R135B
1/4W
MINI
22K
R137B
1/4W
.
15K
R136B
1/4W
.
15K
R152B
1/4W
MINI
120R
R132B
1/8W
FLMP
39R
C34B 200V1N5
G
D
S
Q32B
6752
IRF630NPBF
NTO220
{Function}
1N4745A16V0
ZD10A 1W0
1N5246B16V0
ZD5 0W5
4007
D38
R146A
5.0W
.
0R1
Q35A
6909
{Function}
MJ21196
TO3
Q39A
6909
{Function}
MJ21196
TO3
Q43A
6909
{Function}
MJ21196
TO3
MR854
D31B
MR854
D31A
MR854
D35A
R43
1/4W
MINI
20K0
These parts are
not stuffed
on M1176/M1178
C25B63V10U
6874
Q18B
MJE350
TO126
{Function}
R102B
1/4W
.
33K
R91B
1/4W
.
2R2
R92B
1/4W
MINI
150R
TO92
BC560C
Q19B
5102
1
2
U5:A
4N35
6880
1N750ARL 4V7
ZD6B0W5
C31B 100V22N
TO92
2N6517
Q28B
6854
R38
1/4W
MINI
27K
D11
BAV21
Q37B
6910
{Function}
MJ21195
TO3
R133B
1/8W
FLMP
39R
R138B
1/4W
MINI
22K
D S
G
Q33B
6925
P
IRF9520PBF
TO220
{Function}
R141B
1/4W
FLMP
1R
R134B
1/4W
.
47K
Q37A
6910
{Function}
MJ21195
TO3
Q41A
6910
{Function}
MJ21195
TO3
Q45A
6910
{Function}
MJ21195
TO3
Q36A
6910
{Function}
MJ21195
TO3
Q40A
6910
{Function}
MJ21195
TO3
Q44A
6910
{Function}
MJ21195
TO3
R149A
5.0W
.
0R1
Q34A
6909
{Function}
MJ21196
TO3
Q38A
6909
{Function}
MJ21196
TO3
Q42A
6909
{Function}
MJ21196
TO3
MR854
D36A
BD139
BD237
BD238
MJE340
MJE350
MJE271
MJE270
BD140
E CB B C
TO-92
MPSA63
MPSA43
2N5551
E
MPSA56
MPSA06
MPSA13
2N5401
U3A:A
NE5532N
ZD11B
1N4745A 16V0
1W0
RefDes Value/YSpart# Value/YSpart#
MJE340
6873
Q12B
TO126
{Function}
R51B
1/4W
.
4775 612320K014K0R51B
Q45B
6910
{Function}
MJ21195
TO3
R53B
1/4W
.
477514K0 20K0 6123R53B
13
10
7
4
1
9
11
12
8
#
2
3
5
6
VER#
MODEL(S):-
DATE DESCRIPTION OF CHANGE
V
V
V
V
V
V
V
V
V
V
V
D
D
D
D
N
N
N
N
AM4CE / AP6020 / V62
D
D
D
D
D
D
D
N
N
N
N
N
N
N
M1370 / M1176 / M1178 Database History
02FEB2010 . PC#7935: Change C7 from #5259 to #5269 GG
12OCT2011 . ADDED PROD. NOTE 9, RE: INDICATING TARGET MODEL
13
10
7
4
1
9
11
12
8
#
2
3
5
6
VER#
MODEL(S):-
DATE DESCRIPTION OF CHANGE
.
5.00
.
2.00
V1P1
.
5.10
4.00
3.10
.
3.00
1.00
V1P2
.
AUG/27/02
.
FEB/08/00
MAY/12/99
->FUSIBLE, R132A/B, R125A/B, R127A/B, R77B, R87B,
MOVE TRACE TO ELIMINATE SHORT
FIXED PADSTACKS . ADD MACPINS
FIX MISSING TRACES. FIX DUPLICATE REF DES
PILOT RUN RELEASE
AM4CE
SEP/03/02
AUG/31/04
SEP/26/01
MAR/20/01
MAR/20/01
DEC/12/00
NOV/16/99
AUG/25/99
R100B, R99B 249R -> 241 FUSIBLE, R41B, R40B 33R->
PC#6565 D25B,D26B 4148 -> BAV21
PC#6454 C10A 470p -> 1n ADD R40, R41
PC#6377 R42A 470R -> 220R
PC#6377 C34B, C42 470p ->1n5, R102B 39K -> 33K
FIRST PRODUCTION
M1176 PROTOTYPE
M1370 / M1176 / M1178 Database History
REDUCE WIDTH .125" PC#6303 ADD C5C C6C CAPS
13
10
7
4
1
9
11
12
8
#
2
3
5
6
VER#
MODEL(S):-
DATE DESCRIPTION OF CHANGE
.
.
7.00
6.00
5.10
.
8.00
.
.
6.10
.
.
.
.
AUG/22/06
JUN/15/05
AUG/31/04
TACK A 100P 100V CAP #5199 ACROSS R177
Changed Q33B and Q24B to shorter pattern.
FIX AC CLEARANCE
PC#6869 CONVERT-TO PCAD2002
R104B, R133A/B, R104B, R78B, R105B 39R FUSIBLE
AM4CE
.
JAN/31/2008
.
.
JUL/07/06
.
.
PC#7658, CHANGE R177 FROM 22M TO 10M #4809
Changed to X8002. Complete force update. Solder fixes.
PC#7228, ADD AN EXTRA HOLE FOR ALUMINIUM SPACER
Q26B #6989 WITH #7004
HA, PC#7076, REPLACE Q25B #6990 WITH #7005 AND
R100B, R99B 249R -> 241R FUSIBLE
R108B, R109B -470R -> 471R - FUSIBLE
M1370 / M1176 / M1178 Database History
JUN/11/2009 9.00 PC#7467, Added R45, R46 to fix AM4CE phase.

11 11
10 10
9 9
8 8
7 7
6 6
5 5
4 4
3 3
2 2
1 1
A
A
B
B
C
C
D
D
E
E
F
F
G
G
H
H
I
I
J
J
K
K
L
L
M
M
N
N
O
O
P
P
Q
Q
of
Filename:
PCB# Sheet 32
Product
Date: Rev: YsType:{Company Name}
X8002V900_001.sch2002
X8002
AmpInput
Thu Oct 13, 2011 9V00
AM4CE POWER AMPof
Filename:
PCB# Sheet 32
Product
Date: Rev: YsType:{Company Name}
X8002V900_001.sch2002
X8002
AmpInput
Thu Oct 13, 2011 9V00
10K 14K7
V62
10K 14K7
1N5246B 16V0
ZD40W5
R27
1/4W
MINI
1K5
D4
4007
4148
D9
4148
D2
1N5257B 33V0
ZD30W5
4148
D1
D6B
4148
1N5257B 33V0
ZD20W5
1N5251BRL 22V0
ZD10W5
10
W7:J 12
{RefDes}
C6 100V220P
9
W7:I 12
12
W7:L 12
6
W7:F 12
{RefDes}
R46
1/4W
MINI
10K0
R45
1/4W
MINI
10K0
R3
1/4W
MINI
see table for value
R1
1/4W
MINI
see table for value
M1176
R29
1/4W
MINI
470R
C10 100V100N
R31
1/4W
.
330R
R8
1/8W
FLMP
100R0
R5
1/4W
MINI
6K8
U2:E
R7
1/4W
MINI
10K
R14
1/4W
MINI
18K
R18
1/4W
.
47K
R16
1/8W
FLMP
100R0
R11
1/8W
FLMP
100R0
R15
1/8W
FLMP
100R0
R12
1/8W
FLMP
100R0
R6
1/4W
MINI
4K7
TO92
2N5401
Q4
5108
R28
1/4W
MINI
1K5
TO92
MPSA06
Q1
5103
R20
1/4W
MINI
4K7
R19
1/4W
MINI
10K
R21
1/4W
MINI
220K
R23
1/4W
MINI
10K
TO92
2N5401
Q3
5108
4148
D7
R25
1/4W
MINI
1K5
C9 100V100N
GND
VCC OUT
U4
AS35FN
TO-92
6478
R9
1/4W
MINI
18K C5 100V220P
K1:A
3696
C7
100V 4U7
PwrAmp[H8]
4007
D8
R24
1/4W
.
1M
R26
1/4W
.
7K5
4148
D5B PwrAmp[H7]
7
W7:G 12
4
W7:D 12
1
W7:A 12
RefDes Value/YSpart# Value/YSpart#
4148
D3
C11 100V100P
C4 100V100N
C2 100V220P
R4
1/4W
MINI
10K0
11
W7:K 12
U1:A
NE5532N
R2
1/4W
MINI
10K0
These parts are not
stuffed on M1370.
3
W7:C 12
5
W7:E 12
8
W7:H 12
C1 100V220P
2
W7:B 12
M1178
R177
1/4W
.
10M
U2:B
LM13600N R13
1/4W
.
12K
U2:A
LM13600N R17
1/4W
.
12K
R10
1/8W
FLMP
100R0
U1:B
NE5532N
PwrAmp[H7]
TO92
BC550C
Q2
5101
R30
1/4W
.
100K
R22
1/4W
MINI
1K5
These parts are not
stuffed on M1176 or M1178
8
V+
4V-
U1:C
3696
K1:B
(VCC)
6745
U2:C
LM13600N
Dual VCA
{Function}
PwrAmp[C12]
(VCC)
6745
U2:D
LM13600N
Dual VCA
{Function}

22 22
21 21
20 20
19 19
18 18
17 17
16 16
15 15
14 14
13 13
12 12
11 11
10 10
9 9
8 8
7 7
6 6
5 5
4 4
3 3
2 2
1 1
A
A
B
B
C
C
D
D
E
E
F
F
G
G
H
H
I
I
J
J
K
K
L
L
M
M
N
N
O
O
P
P
Q
Q
R
R
S
S
T
T
U
U
V
V
W
W
X
X
Y
Y
Z
Z
AA
AA
AB
AB
AC
AC
AD
AD
AE
AE
AF
AF
AG
AG
AH
AH
3
X8002V900_001.sch2002
Date:
Product
PCB# of
Rev: Sheet 3 9V00
Filename:
Thu Oct 13, 2011 X8002
$M4CE POWER AMP 3
X8002V900_001.sch2002
Date:
Product
PCB# of
Rev: Sheet 3 9V00
Filename:
Thu Oct 13, 2011 X8002
R33C
1/4W
MINI
4K7
1N5225B 3V0
ZD1C0W5
C35C50V22U
1N5225B 3V0
ZD3C0W5
W6:I16
W6:H
16
W6:L16
W6:K16
W6:E
16W6:F
16
W6:O16
W6:N16
W6:B
16W6:C
16
C5C
50V 100N C38C
100V 220P
X4C
X6C
LD5C
RED
{Function}
5906
TO92
BC560C
Q3C
5102
R32C
1/4W
.
15K
ZD2C
1N750ARL 4V7
0W5
R30C
1/4W
MINI
470R
C4C 50V470N
4148
D9C
R31C
1/4W
MINI
220K
R48C
1/4W
MINI
4K7
R47C
1/4W
MINI
470R
R46C
1/4W
.
15K
R29C
1/4W
MINI
220R
W6:J16 W6:G
16
W6:M16
W6:P16
W6:D
16
W6:A
16
C01C100V100N
4148
D6C
C36C50V22U
C6C 50V100N
M
AUD P2C 4390 10K Function
C39C
100V 330P
R45C
1/4W
.
4K12
R44C
1/4W
MINI
10K
U2C:A
MC33078P
8
V+
4V-
U2C:C
C40C 100V330P
X3C
X63C
C22C 63V220N
R1C
1/4W
.
100K
R5C
1/4W
MINI
8M2
C21C 63V220N
LD2C
GRN
{Function}
5908
Q2C
5106
TO92
MPSA63
R55BC
1/4W
MINI
220R
R34C
1/4W
MINI
470R
C02C100V100N
TO92
BC560C
Q6C
5102
LD6C
RED
{Function}
5906
R52C
1/4W
MINI
470R
C3C 50V470N
R04C
1/4W
.
15K
P1C
4390
M
AUD
10K
Function
R40C
1/4W
.
4K12 C127C 50V100N
U2C:B
MC33078P
C2C 100V220P
R3C
1/4W
MINI
470K
C1C
100V220P
R55AC
1/4W
MINI
220R
X1
C17C
100V 100P
C26C 16V33U
R39C
1/4W
.
15K
R8C
1/4W
MINI
10K
R50C
1/4W
.
15K
R7C
1/4W
MINI
10K
Q5C
5102
TO92
BC560C
C37C 100V220P
R41C
1/4W
MINI
10K
R61C
1/4W
MINI
18K
C18C 100V100P
C25C 16V33U
These parts are not
stuffed on M1370.
R35C
1/4W
MINI
10K0
R36C
1/4W
MINI
8M2
R2C
1/4W
.
100K
Q1C
5105
TO92
MPSA13
LD1C
GRN
{Function}
5908
Q4C
5102
TO92
BC560C
R51C
1/4W
MINI
220K
R53C
1/4W
MINI
220R
R49C
1/4W
.
15K
R42C
1/4W
MINI
10K0
C126C
50V 100N
R60C1
1/4W
MINI
22K
R4C
1/4W
MINI
470K

VCD
CLINCH
ORIGIN LONGAXIS
SHORT AXIS
INSERT
ORIGIN
SEE NOTE 9
V9.00Pcb MechX8002
BlankSize - 18000x13000
M1370
AM4CEAV9.00
FOR TEST JIG
V9.00
HEAT SINK TOOLING PINS
Top Assy X8002
SEE LAYOUT DOCUMENTATION
+
-
GUIDE
ETCH
C2 NC
-
C1 NO
+
+
-
+
-
RT
V
E B
C
GUIDE
ETCH
BAR DOWN
E B
C
E B
C
BAR DOWN
1612
+
-
E B
C
E
B
C
.
.
.
..
.
BIAS ADJ.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
5906
6880
6934
6934
6934
6934
6934
3696
5906
5908
6934
6934
6934
6934
6934
6874
6880
5882
6752
6752
6934
6934
6934
6934
6925
6925
2329
5882
5908
6873
7005
5882
3562
5882
7004
1K5
470K
BAV21
BAV21
1N5
33V0
10K
220K
10K
120R
220R0
22N
270R
100N14V0
1R
4K71R
100PBAV21
220R22R
150R
100N2K88414
3K327K
4148
10K0
220P4148
4148
470R
4007
16V075K
1R 220R 1R 1N
BAV21
8M2 15K
BAV21 BAV21
47K
1K
22N
22N
470R
8M2
20V0
16V0
10K
15K1R
15K
1R
220K
220K
4K7 4K7
6V2
4007
BAV21
75K16V0
4K99
39R
150R
6K98
2R2
150R
150R
1K5
39R
4148
4148
22V0
10R0
471R
RED
22N
15K
22K
220N
10K
4K7
470R
3V0
220R
470K
150R
4V7
4148
39R0
470P
470P
3K
470P
10K0
4K7
2K
3K3
8K2
100N
2N5401
4N35
330R
16V0
16V0
BAV21
7K5
4007
1M
4K7
MR854
MR854
MR854
MR854
MR854
25V
330U
RELAY 1C
2K2
22U
50V
1R 1R
1R
47K
220K
100N
470N
BC560C
15K
BC560C
470N
4148
220K
50V
22U
MPSA63
BC550C
BC560C
220R0
2R2
220N
BC560C
RED
GRN
330U
25V
220P
1R
18K
2N6517
220R
39R
1R
1/2W
MR854
MR854
MR854
MR854
MR854
3K
2N6517
3K
16V0
16V0
4148
68R
100R010M
12K
4K99
4148
10R0
47K
10K0
BAV21
100R0
2N2
39R
241R
220P
100N
220P
33U
16V
4K7
22U
50V
4148
2K BC560C
160V
10U
10R0
4U7
63V
39R
10U
63V
BC560C
BC560C
MJE350
39R
MJE350
TO126
BC550C
1K5
27K
470K
4N35
AS35FN
TO-92
220N
250V
75K
TO220
IRF630NPBF
16V0
TO220
IRF630NPBF
MR854
BC550C
MR854
1R
MJE340
TO126
220P
470R
22K
BAV21
1K
BC550C
BC560C
4K7
100K
BC560C
1R
BC550C
220K
TO126
MJE350
MR854
MR854
471R
75K
TO220
IRF9520PBF
TO220
IRF9520PBF
4148
47K
1K
18K
BC550C
33U
16V
BC550C
160V
10U
10K0
10U
63V
33K
6K98
4K7
4148
63V
4U7
10K0
2N2
1K5
39R0
39R
220R
100R0
220R
470R
4V7
470K
220R
100K
15K
4148
4148
4148
220N
250V
4148
220P
100R0
6K8
100R0
4148
10K
4K7
100R0
10P
1K 150R
33R
150R
4148
4148
4148
220K
2.0W
241R
2N5401
MPSA06
4148
1N5
39R
1R
1/2W
33V0
6V2
MPSA13
100K
3V0
220R
GRN
15K
22N
400V3R9
2.0W
100R0
1.0W
0R47
15K
39R
39R
2N2
LM13600N
18K
NE5532N
100R0
100R0
12K
50V
22U
33U
16V
4K7
2N555133R
39R
10P
33U
16V
MJE340
TO126
2K7
10K
MJ21196
Body
4007
4U7
100V
MJ21196
Body
MJ21196
Body
MJ21196
Body
TO3P
2SC5949-0
1R
1/2W
5.0W
1K5
MJ21196
Body
4148
5.0W
0R1
5.0W
0R1
MJ21196
Body
MJ21196
Body
MJ21196
Body
5.0W
0R1
5.0W
0R1
5.0W
0R1
5.0W
0R1
5.0W
0R1
5.0W
0R1
25V
330U
2R2
220N
250V
MJ21195
Body
470R
NE5532N
16 PIN
220N
250V
MJ21195
Body
MJ21195
Body
MJ21195
Body
2SA2121-0
TO3P
1/2W
1R
1U
63V
2N5401
39R
TO126
MJE340
2R2
MJ21196
Body
MJ21196
Body
MJ21196
Body
MJ21196
Body
5.0W
0R15
5.0W
0R1
5.0W
0R1
0R155.0W
MJ21195
Body
MJ21195
Body
2K2
39R
17K8
5.0W
1K5
MJ21195
Body
MJ21195
Body
MJ21195
Body
MJ21195
Body
MJ21195
Body
MJ21195
Body
330P
20K0
20K0
330P
10K0
10K0
20K020K0
1/2
BRNRED
X8002 V9.00
M1178
V9.00
2/2
X8002
M1370
M1176
AP6020 / AM4CE / V62
METAL
NOTE:
BottomAmp
Top Amp
AM4CE
* THESE 2 RESISTORS ARE DIFFERENT *
R28 R41
D12
D10
X55
C34B
ZD2
R23
R21
R19
R152B R173B
X56
C38B
R153B
C02C
ZD4B
R143B
R33C
X52
R145BX39
X27
X46
C11 D13
R57B
R103B
X37
X34R94B
X23
C10
D9B
R75B
B67R02X R39
D17B
R4
C2 D19B
D6B
R29
D38
ZD5 R34
X31
R140A R42A R142AC10A
D27B
R5C R136B
D25B D28B
R139B
R167B
C31B
C32B
R121B
R36C
X29
ZD7B
ZD5B
R8C X51
R39CR143A
R32C
R145A
R116B
R118B
R115B R113B
ZD8
D37
D11
R36 ZD11B
X43
X66
X24
R50B
R105B
R89B
X10
X12
R97B
R91B
X49R96B
R92B
R25
X54
X68 R132B
D9D7
ZD1
X7
R86B
X14
R108B
LD6C
C37B
R137B
R135B
C21C
R7C
R48C
R30C
ZD3C
R55BC
X63CR4C
R120B
X69
ZD6B
D24B
R127A
C36A
X57
C36B
X11
R62B
C35B
R2
R58B
R70B
X9
R79B
R80B
X53
C4
Q4
U5
X40
R31
W8
+100V
RED
ZD4
X4
X2
ZD10A
D37B
C33B
R26
D8
R24
R20
X5
D30A
D31A
D31B
D30B
D29B
TP2B
C20B
K1
R112B
C36C
TP4B
R140B R142B
R141B
R134B
R51C
C01C
C3C
Q5C
R49C
Q6C
TP6B
C4C
D9C
R31C
C35C
Q2C
LOC
BEC
Q20B
Q47B
R170B
R165B
C22C
Q4C
LD5C
LD2C
X28
C27B
C2C
R144B
R117B
Q28B
R32
R133A
R123A
D33A
D34A
D34B
D33B
D32B
TP3B
R110B
X38
Q27B
R111B
ZD6
ZD11A
X36
D22B
R88B
R15
X35
R177
R17
R52B
D11B R82B
R18
R60B
D38B
R126B
C22B
X50
R104B
R99B
X19
C1
C9
C5
C10B
R55B
C11B
D10B
R63B
Q10B
C18B
R85B
C16B
R83B
X22
X45C25B
X44
Q19B
X21
Q16B
Q11BX63
R84B
Q18B
Q22B
R27
X17 R38
R40
U6
U4
C29A
R35
Q32A
ZD10B
Q32B
D29A
Q2
D35AX41
X33
R141A
Q23B
X30
C1C R47C
R138B
D26B
R168B
W2
BLU
SPKR OUT
Q46B
Q21BTP1A
R119B
R1C
Q3C
R144A
Q29B
R160B
Q24B
D32A
D36AR109B
R37
Q33A
X42
Q33B
D2
R54B
R67B
W4BLU
-100V
X48
R9
Q13B
C40B
Q15B
C19B
R98B
C24B
R102B
R93B
R59B
D1
W7
C17B
R101B
C23B
X15
R22
X13
X67
R125A
X6
R125B
R33 R124B
X3C
R53CR52C
ZD2C
X6C
R3C
R29C
R30
X4C
R04C
X18
D14B
D13B
D12B
X32
X26
C30B
D23B
C6
R10
R5
R11 D3
R7
R6
R16
C15B
R66BR74B
X47
R40B
R71B
D21B
D20B
D18B
R81B
R100B
Q3
Q1
D5B
X8
C42
R132A
R122A
ZD3
ZD9
Q1C
R2C
ZD1C
R55AC
LD1C
R50C
C39B
R156B
R106B
R107B
R46C
TP3A
R133B
X25
R127B
C21B
U2
R14
U1
R8
R12
R13
C12B
C9B
R56B
B14RB7Q
R77B
C14B
C8B
X64
Q17B
X60 R95B
RTB
TP1B
Q34A
D4
C7
Q38BQ42A Q42B
Q25B
R122B
R130B
W1
+55V
GRY
Q35A
D6C
R146A
R149A
Q39BQ43A Q43B
R151B
R148A
R148B
R147B
R151A
R150B
C26B
R162B
C29B
W3
BLK
GND
Q37A
R34C
U3A
W6
C30A
Q41BQ45A Q45B
Q26B
R123B
C28B
W5BRN
-55V
Q8B
R78B
Q12B
R90B
Q38A Q34B
Q39A Q35B
R146B
R147A
R150A
R149B
Q37B
Q41A
R114B
R87B
R61B
R131B
Q36A Q40BQ44BQ44AQ40A Q36B
X1 P2C P1C
X3
R51B
R53B
C3
R43
R44
C8
R46
R45
2N2

VCD
CLINCH
ORIGIN LONGAXIS
SHORT AXIS
INSERT
ORIGIN
SEE NOTE 9
V9.00Pcb MechX8002
BlankSize - 18000x13000
M1370
AM4CEAV9.00
FOR TEST JIG
V9.00
HEAT SINK TOOLING PINS
Top Assy X8002
SEE LAYOUT DOCUMENTATION
+
-
GUIDE
ETCH
C2 NC
-
C1 NO
+
+
-
+
-
RT
V
E B
C
GUIDE
ETCH
BAR DOWN
E B
C
E B
C
BAR DOWN
1612
+
-
E B
C
E
B
C
.
.
.
..
.
BIAS ADJ.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
5906
6880
6934
6934
6934
6934
6934
3696
5906
5908
6934
6934
6934
6934
6934
6874
6880
5882
6752
6752
6934
6934
6934
6934
6925
6925
2329
5882
5908
6873
7005
5882
3562
5882
7004
1K5
470K
BAV21
BAV21
1N5
33V0
10K
220K
10K
120R
220R0
22N
270R
100N14V0
1R
4K71R
100PBAV21
220R22R
150R
100N2K88414
3K327K
4148
10K0
220P4148
4148
470R
4007
16V075K
1R 220R 1R 1N
BAV21
8M2 15K
BAV21 BAV21
47K
1K
22N
22N
470R
8M2
20V0
16V0
10K
15K1R
15K
1R
220K
220K
4K7 4K7
6V2
4007
BAV21
75K16V0
4K99
39R
150R
6K98
2R2
150R
150R
1K5
39R
4148
4148
22V0
10R0
471R
RED
22N
15K
22K
220N
10K
4K7
470R
3V0
220R
470K
150R
4V7
4148
39R0
470P
470P
3K
470P
10K0
4K7
2K
3K3
8K2
100N
2N5401
4N35
330R
16V0
16V0
BAV21
7K5
4007
1M
4K7
MR854
MR854
MR854
MR854
MR854
25V
330U
RELAY 1C
2K2
22U
50V
1R 1R
1R
47K
220K
100N
470N
BC560C
15K
BC560C
470N
4148
220K
50V
22U
MPSA63
BC550C
BC560C
220R0
2R2
220N
BC560C
RED
GRN
330U
25V
220P
1R
18K
2N6517
220R
39R
1R
1/2W
MR854
MR854
MR854
MR854
MR854
3K
2N6517
3K
16V0
16V0
4148
68R
100R010M
12K
4K99
4148
10R0
47K
10K0
BAV21
100R0
2N2
39R
241R
220P
100N
220P
33U
16V
4K7
22U
50V
4148
2K BC560C
160V
10U
10R0
4U7
63V
39R
10U
63V
BC560C
BC560C
MJE350
39R
MJE350
TO126
BC550C
1K5
27K
470K
4N35
AS35FN
TO-92
220N
250V
75K
TO220
IRF630NPBF
16V0
TO220
IRF630NPBF
MR854
BC550C
MR854
1R
MJE340
TO126
220P
470R
22K
BAV21
1K
BC550C
BC560C
4K7
100K
BC560C
1R
BC550C
220K
TO126
MJE350
MR854
MR854
471R
75K
TO220
IRF9520PBF
TO220
IRF9520PBF
4148
47K
1K
18K
BC550C
33U
16V
BC550C
160V
10U
10K0
10U
63V
33K
6K98
4K7
4148
63V
4U7
10K0
2N2
1K5
39R0
39R
220R
100R0
220R
470R
4V7
470K
220R
100K
15K
4148
4148
4148
220N
250V
4148
220P
100R0
6K8
100R0
4148
10K
4K7
100R0
10P
1K 150R
33R
150R
4148
4148
4148
220K
2.0W
241R
2N5401
MPSA06
4148
1N5
39R
1R
1/2W
33V0
6V2
MPSA13
100K
3V0
220R
GRN
15K
22N
400V3R9
2.0W
100R0
1.0W
0R47
15K
39R
39R
2N2
LM13600N
18K
NE5532N
100R0
100R0
12K
50V
22U
33U
16V
4K7
2N555133R
39R
10P
33U
16V
MJE340
TO126
2K7
10K
MJ21196
Body
4007
4U7
100V
MJ21196
Body
MJ21196
Body
MJ21196
Body
TO3P
2SC5949-0
1R
1/2W
5.0W
1K5
MJ21196
Body
4148
5.0W
0R1
5.0W
0R1
MJ21196
Body
MJ21196
Body
MJ21196
Body
5.0W
0R1
5.0W
0R1
5.0W
0R1
5.0W
0R1
5.0W
0R1
5.0W
0R1
25V
330U
2R2
220N
250V
MJ21195
Body
470R
NE5532N
16 PIN
220N
250V
MJ21195
Body
MJ21195
Body
MJ21195
Body
2SA2121-0
TO3P
1/2W
1R
1U
63V
2N5401
39R
TO126
MJE340
2R2
MJ21196
Body
MJ21196
Body
MJ21196
Body
MJ21196
Body
5.0W
0R15
5.0W
0R1
5.0W
0R1
0R155.0W
MJ21195
Body
MJ21195
Body
2K2
39R
17K8
5.0W
1K5
MJ21195
Body
MJ21195
Body
MJ21195
Body
MJ21195
Body
MJ21195
Body
MJ21195
Body
330P
20K0
20K0
330P
10K0
10K0
20K020K0
1/2
BRNRED
X8002 V9.00
M1178
V9.00
2/2
X8002
M1370
M1176
AP6020 / AM4CE / V62
METAL
NOTE:
BottomAmp
Top Amp
AM4CE
* THESE 2 RESISTORS ARE DIFFERENT *
R28 R41
D12
D10
X55
C34B
ZD2
R23
R21
R19
R152B R173B
X56
C38B
R153B
C02C
ZD4B
R143B
R33C
X52
R145BX39
X27
X46
C11 D13
R57B
R103B
X37
X34R94B
X23
C10
D9B
R75B
B67R02X R39
D17B
R4
C2 D19B
D6B
R29
D38
ZD5 R34
X31
R140A R42A R142AC10A
D27B
R5C R136B
D25B D28B
R139B
R167B
C31B
C32B
R121B
R36C
X29
ZD7B
ZD5B
R8C X51
R39CR143A
R32C
R145A
R116B
R118B
R115B R113B
ZD8
D37
D11
R36 ZD11B
X43
X66
X24
R50B
R105B
R89B
X10
X12
R97B
R91B
X49R96B
R92B
R25
X54
X68 R132B
D9D7
ZD1
X7
R86B
X14
R108B
LD6C
C37B
R137B
R135B
C21C
R7C
R48C
R30C
ZD3C
R55BC
X63CR4C
R120B
X69
ZD6B
D24B
R127A
C36A
X57
C36B
X11
R62B
C35B
R2
R58B
R70B
X9
R79B
R80B
X53
C4
Q4
U5
X40
R31
W8
+100V
RED
ZD4
X4
X2
ZD10A
D37B
C33B
R26
D8
R24
R20
X5
D30A
D31A
D31B
D30B
D29B
TP2B
C20B
K1
R112B
C36C
TP4B
R140B R142B
R141B
R134B
R51C
C01C
C3C
Q5C
R49C
Q6C
TP6B
C4C
D9C
R31C
C35C
Q2C
LOC
BEC
Q20B
Q47B
R170B
R165B
C22C
Q4C
LD5C
LD2C
X28
C27B
C2C
R144B
R117B
Q28B
R32
R133A
R123A
D33A
D34A
D34B
D33B
D32B
TP3B
R110B
X38
Q27B
R111B
ZD6
ZD11A
X36
D22B
R88B
R15
X35
R177
R17
R52B
D11B R82B
R18
R60B
D38B
R126B
C22B
X50
R104B
R99B
X19
C1
C9
C5
C10B
R55B
C11B
D10B
R63B
Q10B
C18B
R85B
C16B
R83B
X22
X45C25B
X44
Q19B
X21
Q16B
Q11BX63
R84B
Q18B
Q22B
R27
X17 R38
R40
U6
U4
C29A
R35
Q32A
ZD10B
Q32B
D29A
Q2
D35AX41
X33
R141A
Q23B
X30
C1C R47C
R138B
D26B
R168B
W2
BLU
SPKR OUT
Q46B
Q21BTP1A
R119B
R1C
Q3C
R144A
Q29B
R160B
Q24B
D32A
D36AR109B
R37
Q33A
X42
Q33B
D2
R54B
R67B
W4BLU
-100V
X48
R9
Q13B
C40B
Q15B
C19B
R98B
C24B
R102B
R93B
R59B
D1
W7
C17B
R101B
C23B
X15
R22
X13
X67
R125A
X6
R125B
R33 R124B
X3C
R53CR52C
ZD2C
X6C
R3C
R29C
R30
X4C
R04C
X18
D14B
D13B
D12B
X32
X26
C30B
D23B
C6
R10
R5
R11 D3
R7
R6
R16
C15B
R66BR74B
X47
R40B
R71B
D21B
D20B
D18B
R81B
R100B
Q3
Q1
D5B
X8
C42
R132A
R122A
ZD3
ZD9
Q1C
R2C
ZD1C
R55AC
LD1C
R50C
C39B
R156B
R106B
R107B
R46C
TP3A
R133B
X25
R127B
C21B
U2
R14
U1
R8
R12
R13
C12B
C9B
R56B
B14RB7Q
R77B
C14B
C8B
X64
Q17B
X60 R95B
RTB
TP1B
Q34A
D4
C7
Q38BQ42A Q42B
Q25B
R122B
R130B
W1
+55V
GRY
Q35A
D6C
R146A
R149A
Q39BQ43A Q43B
R151B
R148A
R148B
R147B
R151A
R150B
C26B
R162B
C29B
W3
BLK
GND
Q37A
R34C
U3A
W6
C30A
Q41BQ45A Q45B
Q26B
R123B
C28B
W5BRN
-55V
Q8B
R78B
Q12B
R90B
Q38A Q34B
Q39A Q35B
R146B
R147A
R150A
R149B
Q37B
Q41A
R114B
R87B
R61B
R131B
Q36A Q40BQ44BQ44AQ40A Q36B
X1 P2C P1C
X3
R51B
R53B
C3
R43
R44
C8
R46
R45
2N2

+55V
-55V
BCP BCP
TORQUE 4 INCH/LBTORQUE 4 INCH/LB
Z217 CLAMPZ217 CLAMP
Z217 CLAMPZ217 CLAMP
HEATSPREADER
#8701 4-40 KEPS NUT
#8485 SPLIT WASHER
PCB
PCB
#4124 THERMO PAD
HEATSPREADER
T126 TYPE DEVICE
TB4
TB7
TB6 BLU
TB2
TB3RED GRY
V9.00
X8002
-145V
+145V
BCP BCP
HEATSPREADERHEATSPREADER
T264 DEVICET264 DEVICE
#3846 MICA
TORQUE 4 INCH/LB
Z217 CLAMP
TB5BRN
#8663 SPACER
AM4CE
FOR AM4CE (M1370A):
HEATSPREADERHEATSPREADER
T126 TYPE DEVICET126 TYPE DEVICE
#8485 ZINC #6 WASHER#8485 ZINC #6 WASHER
#8701 4-40 KEPS NUT
OUTPUT +
OUTPUT -
14AWG
T-220 DEVICE
14AWG
14AWG
#3501 BELL WASHER
8. TAB WIRE COLOURS
#8741 4-40X 1/2" BOLT
#8871 4-40X 5/8" BOLT
TO-3 TRANSISTOR
#8761 BOLT
#3517 #8 NYLON WASHER#3517 #8 NYLON WASHER
#8701 4-40 KEPS NUT#8701 4-40 KEPS NUT
#8902 - 4-40 X 3/4 PAN PHIL#8902 - 4-40 X 3/4 PAN PHIL
#8820 WASHERS
PRODUCTION NOTES
14AWG
#8760 6-32 KEPS NUT
MICAGREASE IS REQUIRED ON
BOTH SIDES OF THE MICAPAD
HEATSPREADER
#3915 THERMAL PAD
#3851 1/2 PCB PLASTIC SPACER#3851 1/2 PCB PLASTIC SPACER
3. MOUNTING HARDWARE FOR Q23B AND Q24B.3. MOUNTING HARDWARE FOR Q23B AND Q24B.
7. NOTE THAT R146B AND R149B ARE 0R15.
5. MOUNTING HARDWARE FOR Q32A, Q32B
Q33AANDQ33B
COOLED FROM WAVE SOLDER IS 6 INCH/LB
#3797 THERMO PAD#3797 THERMO PAD INITIAL TORQUE FOR TO-3'S IS 8 INCH/LB
FINAL TORQUE AFTER HEATSINK HAS
#4060 SIL THERMO PAD#4060 SIL THERMO PAD
9. INDICATING THE TARGET MODEL
INVALID PRODUCT MODELS MUST BE CROSSED OUT IN THE PCB TITLE BOX.
FOR EXAMPLE, IF THE PCB IS STUFFED FOR THE AP6020, THEN MODELS 'AM4CE'
AND 'V62' MUST BE CROSSED OUT WITH A BLACK MARKER.
#8667 SHOULDER WASHER
TORQUE 4 INCH/LB
2. MOUNTING HARDWARE FOR Q25B AND Q26B.2. MOUNTING HARDWARE FOR Q25B AND Q26B.
1. MOUNTING DETAILS FOR 5W ADD #8629 SPACERS ONLY ON
5 WATT RESISTORS R130A, R130B AND R131B.4. MOUNTING HARDWARE FOR Q17B AND Q18B.
SEE LAYOUT DIAGRAM
6. MOUNTING HARDWARE FOR TO3 OUTPUTS
M1370/M1370A
#8902
440- SCREW
#3851
SPCR
#8485
WASHER
#4060
SIL-PAD
#3517
WASHER
Z217
CLAMP
FLIPPED VERSION
CLAMP DETAIL - SEE NOTES 2 AND 3.
CLAMP DETAIL FOR NOTE 4.

SEE LAYOUT DIAGRAM
PIN CONFIGURATION
E CB
TO-92
MPSA63
MPSA43
MPSA13
2N5551
MPSA56
MPSA06
2N5401
BD139
BD237
BD238
MJE340
MJE350
MJE271
MJE270
BD140
E BC C EB
TO-92
BC560C
BC550C
E CB
TO-92
MPSA63
MPSA43
MPSA13
2N5551
MPSA56
MPSA06
2N5401
12
9
6
3
#
13
11
10
5
4
8
7
2
1DATE
MODEL(S):- VER# DESCRIPTION OF CHANGE
SEP/03/02
AUG/27/02
SEP/26/01 4.00
5.00
5.10
.
.
AUG/31/04
.
PC#6454 C10A 470p -> 1n ADD R40, R41
MOVE TRACE TO ELIMINATE SHORT
PC#6565 D25B,D26B 4148 -> BAV21
R100B, R99B 249R -> 241 FUSIBLE, R41B, R40B 33R->
->FUSIBLE, R132A/B, R125A/B, R127A/B, R77B, R87B,
MAR/20/01
.
MAR/20/01 .
.
3.10
V1P1
V1P2
1.00
2.00
3.00
MAY/12/99
AUG/25/99
NOV/16/99
FEB/08/00
DEC/12/00 REDUCE WIDTH .125" PC#6303 ADD C5C C6C CAPS
FIX MISSING TRACES. FIX DUPLICATE REF DES
FIRST PRODUCTION
M1176 PROTOTYPE
PILOT RUN RELEASE
PC#6377 C34B, C42 470p ->1n5, R102B 39K -> 33K
FIXED PADSTACKS . ADD MACPINS
PC#6377 R42A 470R -> 220R
M1370 / M1176 / M1178 Database History
AM4CE
12
9
6
3
#
13
11
10
5
4
8
7
2
1DATE
MODEL(S):- VER# DESCRIPTION OF CHANGE
D
D
D V
V
V
V
V
D
D
N
N
N
N
N
D
D
D V
V
V
.
V
06-MAR-2014
D N
PC8629: Change C33B from 1N to 2N2 #8208 GG
N
N
N
AM4CE
M1370 / M1176 / M1178 Database History
02FEB2010 . PC#7935: Change C7 from #5259 to #5269 GG
.12OCT2011 ADDED NOTE 9, RE: INDICATING TARGET MODEL
PC8481: CHANGED Q17B & Q18B MOUNTING. - ML.29-OCT-2012 IRF830
MTP12P10
MTP10N15L
IRL2910
IRF5210
MTP2P50E
MTP8P20
IRF720
MTP23P06
IRF822
IRF4905
DG S
B C E
MJL21194
MJL1302A
MJL3281A
MJL21193
2SA2121-0
2SC5949-0
12
9
6
3
#
13
11
10
5
4
8
7
2
1DATE
MODEL(S):- VER# DESCRIPTION OF CHANGE
. . R100B, R99B 249R -> 241R FUSIBLE
JUN/15/05
AUG/31/04
.
6.00
5.10
.
PC#6869 CONVERT-TO PCAD2002
R108B, R109B -470R -> 471R - FUSIBLE
R104B, R133A/B, R104B, R78B, R105B 39R FUSIBLE
JUL/07/06 6.10 HA, PC#7076, REPLACE Q25B #6990 WITH #7005 AND
. . Q26B #6989 WITH #7004
AUG/22/06 7.00 FIX AC CLEARANCE
PC#7228, ADD AN EXTRA HOLE FOR ALUMINIUM SPACER.. Changed to X8002. Complete force update. Solder fixes.
Changed Q33B and Q24B to shorter pattern.. .
9.00
8.00JAN/31/2008
PC#7467, Added R45, R46 to fix AM4CE phase.
. PC#7658, CHANGE R177 FROM 22M TO 10M #4809
TACK A 100P 100V CAP #5199 ACROSS R177..
AM4CE
M1370 / M1176 / M1178 Database History
JUN/11/2009
.
VIEW
BOTTOM
EB
MJE11025
MJE11025
MJE11025
MJE11025
