Dissimilar media types, protocols and duplex settings can
make LAN internetworking and Fiber-to-the-Subscriber
projects challenging undertakings. For example, if the service
provider network infrastructure is 100 Mbps or Gigabit fiber
but the customer wants to receive a standard 10 Mbps
Ethernet interface to their LAN, making the connection
between the two network segments can be difficult. The
complexity of today's mixed media networks and the
increasing demand for bandwidth requires access equipment
that is both flexible in connecting different media types and
scalable between different speeds.
Convert speed, media and duplex mode:
The iMcV MediaLinX series of switching media converters
offers service providers and enterprise networks unparalleled
flexibility in connecting copper-based networks to Fast
Ethernet or Gigabit fiber optic infrastructures. The SNMP-
manageable MediaLinX converters allow device managers to
use Auto-Negotiation functionality on the twisted pair port for
plug-and-play operation, or to manually configure the port
for the desired speed and duplex mode. What's more, you
can even set the fiber port for Half- or Full-Duplex operation
(10/100 Mbps only). The iMcV-MediaLinX series includes
two models:
iMcV-MediaLinX:
One 10/100 twisted pair port with an RJ-45 connector.•
One 100 Mbps fiber port with ST or SC•
iMcV-Giga-MediaLinX:
One 10/100/1000 twisted pair port with an RJ-45•
connector.
One 1000 Mbps fiber port with SC connector(s).•
iThe iMcV MediaLinX series also includes troubleshooting
features and LEDs to assist in network diagnostics as well
as make isolating cable breaks easier should they occur. In
addition, hot-swappable MediaLinX modules significantly
reduce operation costs by allowing other modules within
the same chassis to remain up and running during product
upgrades, maintenance and troubleshooting.
Features and Benefits
Same unit converts speed, media and
duplex mode!
Available in 10/100 and 10/100/1000•
models
Configure twisted pair port for Auto-•
Negotiation or force the speed
Twisted pair and fiber ports can be•
individually configured for Half- or Full-
Duplex operation
Easy to configure and manage with
GUI-based iView²
Up and running in less than 5 minutes•
Easily adjust settings when user•
requirements change
Easy upgrades; no user intervention or•
visits to remote locations required
Monitor and control all connections•
Meets a variety of installation
requirements
Available for multi-mode or single-mode•
fiber
Available for single-strand fiber•
Eases Troubleshooting
LinkLoss, FiberAlert, SNMP management•
and LEDs assist in diagnosing problems
on fiber optic networks
iMcV-MediaLinX
10/100 and 10/100/1000 Mbps Ethernet SNMP-Manageable, Switching Media Converters
The iMcV-MediaLinX series offers the most flexible Ethernet
switching media converters in the industry.

DS-iMcV-MediaLinX-0804
Copyright © 2007 IMC Networks. All rights
reserved. The information in this document is
subject to change without notice. IMC Networks
assumes no responsibility for any errors that may
appear in this document. Specific product names
may be trademarks or registered trademarks and
are the property of their respective companies.
IMC Networks
Fiber Consulting Services
For information call:
TEL: [phone]
1-800-624-1070 (US/CAN)
[phone] (Europe)
[email protected]
IMC Networks
Headquarters
19772 Pauling
Foothill Ranch, CA 92610
TEL: [phone]
FAX: [phone]
[email protected]
www.imcnetworks.com
IMC Networks
Europe
Herseltsesteenweg 268
B-3200 Aarschot | Belgium
TEL: [phone]
FAX: [phone]
[email protected]
IMC Networks
Eastern US/Latin America
18840 US Hwy. 19 North Suite 400
Clearwater, FL 33764
TEL: [phone]-8071 (Latin)
FAX: [phone]
[email protected]
iMcV-MediaLinX
IEEE 802.3 10Base-T•
IEEE 802.3u 100Base-TX•
IEEE 802.3u 100Base-FX or SX fiber•
Supports jumbo packets up to 1916 bytes•
iMcV-Giga-MediaLinX
IEEE 802.3 10Base-T•
IEEE 802.3u 100Base-TX•
IEEE 802.3ab 1000Base-T twisted pair•
IEEE 802.3z 1000Base-LX or SX fiber•
Supports packets up to 1536 bytes•
All Modules
IEEE 802.3x Flow Control•
AutoCross for MDI-II/MDI-X•
Features LinkLoss and FiberAlert•
Features Auto-Negotiation and Selective Advertising•
Layer 2 packet switching, store and forward operation•
Forwarding rate: 14,880pps for 10 Mbps; 148,800pps for•
100 Mbps; 1,488,000pps for 1000 Mbps (Gig only)
50/125µm or 62.5/125µm multi-mode fiber•
9/125µm single-mode fiber•
Available for single-strand fiber•
Connectors: RJ-45, and ST or SC•
Installs in any iMediaChassis, iMediaCenter or•
MediaChassis
Supports GUI-Based iView²•
Supports Half- and Full-Duplex operation•
Includes diagnostic LEDs•
Includes hot-swappable architecture•
Regulatory Approvals:
• FCC Class A
• UL/cUL,
• CSA,
• CE
Shipping Weight:
0.30 lbs (.11 kg)
Operating Temperature:
32° to 122°F (0° to +50°C); 5% to 90% (non-condensing),
0 – 10,000 ft. altitude
Storage Temperature:
-13° to +158°F (-25° to +70°C); 5 to 90% (non-condens-
ing)
Ordering Information
Technical Specifications
*These products have single-strand fiber technology. For more information go to:
www.imcnetworks.com/products/SSFX.cfm
Fiber Optics Specifications
For each product listed below in the Ordering Information section, the DISTANCE represents an approximate fiber distance based on industry-standard
fiber attenuation specifications. Actual distances will vary for each installation. For complete power budgets and information on calculating specific
distances, visit www.imcnetworks.com/go/fcs or contact IMC Networks Fiber Consulting Services at 949-465-3000.
PART NUMBER DESCRIPTION DISTANCE
iMcV-MediaLinX Module
856-14913 iMcV-MediaLinX, TX/FX-MM850-ST 2 km
856-14914 iMcV-MediaLinX, TX/FX-MM850-SC 2 km
856-14911 iMcV-MediaLinX, TX/FX-MM1300-ST 2 km
856-14912 iMcV-MediaLinX, TX/FX-MM1300-SC 2 km
856-14915 iMcV-MediaLinX, TX/FX-SM1310/PLUS-ST 40 km
856-14916 iMcV-MediaLinX, TX/FX-SM1310/PLUS-SC 40 km
856-14917 iMcV-MediaLinX, TX/FX-SM1310/LONG-ST 80 km
856-14918 iMcV-MediaLinX, TX/FX-SM1310/LONG-SC 80 km
856-14921 iMcV-MediaLinX, TX/FX-SM1550/LONG-SC 100 km
iMcV-MediaLinX Single-Strand Fiber*
56-14944 iMcV-MediaLinX, TX/SSFX-SM1310-SC (1550rcv) 20 km
56-14945 iMcV-MediaLinX, TX/SSFX-SM1550-SC (1310rcv) 20 km
56-14946 iMcV-MediaLinX, TX/SSFX-SM1310/PLUS-SC (1550rcv) 40 km
56-14947 iMcV-MediaLinX, TX/SSFX-SM1550/PLUS-SC (1310rcv) 40 km
56-14948 iMcV-MediaLinX, TX/SSFX-SM1310/LONG-SC (1550rcv) 60 km
56-14949 iMcV-MediaLinX, TX/SSFX-SM1550/LONG-SC (1310rcv) 60 km
PART NUMBER DESCRIPTION DISTANCE
iMcV-Giga-MediaLinX Module
856-14950 iMcV-Giga-MediaLinX, TX/SX-MM850-SC 550 m
856-14951 iMcV-Giga-MediaLinX, TX/LX-SM1310-SC 15 km
856-14952 iMcV-Giga-MediaLinX, TX/LX-SM1310/PLUS-SC 40 km
856-14953 iMcV-Giga-MediaLinX, TX/LX-SM1550/LONG-SC 70 km
856-14958 iMcV-Giga-MediaLinX, TX/LX-SM1550/XLONG-SC 120 km
iMcV-Giga-MediaLinX Single-Strand Fiber*
56-14940 iMcV-Giga-MediaLinX, TX/SSLX-SM1310-SC (1550rcv) 15 km
56-14941 iMcV-Giga-MediaLinX, TX/SSLX-SM1550-SC (1310rcv) 15 km
56-14942 iMcV-Giga-MediaLinX, TX/SSLX-SM1310/PLUS-SC (1550rcv) 40km
56-14943 iMcV-Giga-MediaLinX, TX/SSLX-SM1550/PLUS-SC (1310rcv) 40 km
56-14954 iMcV-Giga-MediaLinX, TX/SSLX-SM1490/LONG-SC (550rcv) 60 km
56-14955 iMcV-Giga-MediaLinX, TX/SSLX-SM1550/LONG-SC (1490rcv) 60 km
56-14956 iMcV-Giga-MediaLinX, TX/SSLX-SM1490/XLONG-SC (1550rcv) 70 km
56-14947 iMcV-Giga-MediaLinX, TX/SSLX-SM1550/XLONG-SC (1490rcv) 70 km
