IMG LIGHTING VEGA User manual

TO CREATE IMPRESSIVE RESULTS
img-lighting.ru
[email protected]
VEGA
User manual
1.The luminaire shall be installed by a qualified electrician and wired in accordance with the latess IEE
electrical regulations or the national requirements.
2. No supplied water-proof box, installation should be adviced by qualified professional.
3.The external flexible cable can not be replaced. If the cable is damaged, the luminaire should be
discarded.

TO CREATE IMPRESSIVE RESULTS
img-lighting.ru
[email protected]
Instruction Manual
LED Street Light
60W/90W/120W/150W

TO CREATE IMPRESSIVE RESULTS
img-lighting.ru
[email protected]
Warranty
Troubleshooting
?
Problem Possible Cause Solutions
LEDs stop working
LEDs flash on and off
The power line is improperly connected.
The power plug is loose.
The LED driver malfunctions.
The LED chip is damaged.
The output of the driver is abnormal.
The LED chip breaks down.
Reconnect the power cable.
Firmly plug the power in.
Replace with new driver.
Replace with new LEDs.
Replace with new driver.
Replace with new LED chip.
5 years warranty for original purchaser of LED product that is identified on seller's invoice
reflecting its original purchase (the "Product").
1. In order to make a warranty claim, you must notify seller in writing within sixty(60) days after your
discovery of the defect, provide proof of purchase such as the invoice and comply with seller's other
warranty requirements. Upon receiving that notice, to ascertain why fixtures stop working, evidences
would be needed for seller's QC Team to analyze. Seller may require you to promptly return the Product
to Seller when necessary, freight prepaid.
2. The determination of whether the Product is defective shall be made by Seller in its sole discretion with
consideration given to the over all performance of the Product.
3. If seller determines the Product is defective, Seller will elect, in its sole discretion, repair the Product
or replace the Product. Seller reserves the right to utilize new, reconditioned, refurbished, repaired or
remanufactured products or parts in the warranty repair or replacement process. Such products and
parts will be comparable in function and performance to an original product or part, as determined by
Seller in its sole discretion, and warranted for the remainder of the original warranty period. However,
cost of labor and equipment to remove the defective product and install a repaired or a replacement
Product at the end-user facility are excluded. Supplier's aggregate liability with respect to a defective
product shall in any event be limited to the money paid to buyer for that defective product.
The following circumstances will not be warranted:
1. Damage caused by force majeure such as war, riots, sabotage, cyclones, earthquakes, tidal waves,
flooding, lighting strikes, explosions, fire, flood, etc.
2. Damage caused by user's improper delivery, defects caused by wrong operation, wrong treatment
and destruction of machinery.
3. Dismantling or modification or improper maintenance or repairing of the products without the
supplier's authorization.
4. Damage caused by buyer or installer using bad quality cable or other mismatching electronic parts.
5. This warranty is invalid if the product is not used for the purpose for which is originally designed. Any
disputes occurred shall be applied to the laws and regulations of P.R.C.
The seller has the sole right to interpret and amend the above articles.

TO CREATE IMPRESSIVE RESULTS
img-lighting.ru
[email protected]
Check inside the lamp
2
1
4

TO CREATE IMPRESSIVE RESULTS
img-lighting.ru
[email protected]
We appreciate your purchase!
Please read the instruction manual before installation and keep it for future reference.
Reminder
Application
Warning
1. To avoid damage, falling, electric shock or fire, please do not modify the lamp or replace accessories without
confirming with the supplier first.
2. Please authorize only qualified personnel to install the lamp and ensure they follow the instructionmanual.
Any improper installation might cause falling, electric shock, fire, or other injury, damage or hazard.
3. Please disconnect power before installation or any maintenance of the lamp.
4. Please disconnect power if it begins to smoke or emit odors, since fire or electric shock may occur. Ask
qualified person to inspect and maintain the luminaire.
5. Please do not dismantle the lamp without the supplier’s authorization.
6. Please do not touch the power supply when the lamp is operating.
7. If the external flexible cable or cord of the luminaire is damaged, it should only be replaced by the supplier,
a service agent or qualified person.
8. Terminal block not included. Instal lation may require advice from a qualified person.
9. The light source contained in this luminaire shall only be replaced by the manufacturer or his service agent
or a similar qualified person.
10. Only to be installed outside arms reach.
11. For use in environments where an accumulation of non-conductive dust on the luminaire may be expected.
12.Note: We suggest mounting heights of light s not higher than 15m.
Caution risk of electric shock
With aluminum heat sink, high-brightness SMD chip, high-effciency constant current and voltage power
driver, LED Street Light is designed for highway, main roads, secondary roads, small roads, etc.

TO CREATE IMPRESSIVE RESULTS
img-lighting.ru
[email protected]
Installation Instruction
Pole Mounting
Physical Dimensions(mm)
557
Ø460
216
683
Ø460
89
Ø93
173
A B
15°
15°
15°
M10x16 5
2
1
3
83

TO CREATE IMPRESSIVE RESULTS
img-lighting.ru
[email protected]
84
66
Rated Voltage 120-277VAC
Applicable Voltage Range 105-305VAC
Rated Frequency 50/60Hz
Rated Loading 1000W Tungsten, 1800VA Ballast
Power Consumption 1.0VA
Turn-On Level / Time-Delay 10Lx / 15~120s
Turn-Off Level / Time-Delay 60Lx / 2~15s
Ambient Temp. -40° ~ +70°
Related Humidity 99%
Service Life 5000 times
Overall Size 84(Dia.) x 66mm
Weight Approx. 88g
Connect wires as requested
Da1/DIM+
Da2/DIM-
Da1/DIM+
Da2/DIM-
1.
2.
Shorting cap
Under the status of power-on, the light will not turn on without the shorting cap.
It will turn on after installing the shorting cap.
1
2
74
42
50
Photocell
