IMOUMLIVE DLJ04 User manual

Please read all safety rules and instructions carefully before operating this tool.
Dear Customer：
USER MANUAL
IMOUMLIVE 4-INCH MINI CHAINSAW
MODELS:DLJ04
Product Questions or Concerns？Contact US：[email protected]

Product Information
Understanding the composition of your chainsaw
How to properly use the security lock
How to lubricate the chain
How to adjust the chain tightness
How to remove the chain
How to replace the replacement chain
How to charge the battery with the charger
How to troubleshoot
The use and care of chainsaws and precautions
The use and maintenance of battery tools
Safety Warnings for Charger
Maintenance & Cleaning
Environmental Protection
Warranty Terms
Extend Your Warranty by 1 Year
WEEE Recycling Instructions
Extended function
EN.1
EN.2
EN.3
EN.4
EN.5
EN.6
EN.7
EN.8
EN.9
EN.10
EN.11
EN.11
EN.12
EN.12
EN.12
EN.13
EN.13
EN.14
CATALOG

Product Information
Intended Use
This machine is suitable for garden
pruning, shrub pruning, small
branch pruning, wood cutting,
widely used in gardens, parks,
farms, roads, pastures, orchards,
greenhouses.
NOTICE: Any other uses or modifi-
cations to the machine are deemed
to be improper usage and may
result in serious physical injury. The
manufacturer accepts no responsi-
bility for damages attributable to
misuse.
EN.1
Always check the voltage of the power supply corresponds to the voltage
on rating plate.
4 INCH MINI CHAINSAW
BATTERY PACK
Model No.
Guide Plate Length
Weight
Technical Specifications
Battery Pack Type
Voltage
Capacity
Working time
Charging time
DLJ04
100 mm
4 Inch
2.4 Lbs
Lithium-Ion
21 V
2.0 AH
50 Min
1.5 H
Max. Cutting Diameter
Electrical Safety

Understanding the composition of
your chainsaw
EN.2
Protective Baffle
Safety Button
Guide Bar
Cover Fixing Nut
L-Shaped Chain Screwdriver
Battery Pack
Start Switch
Chain
To reduce the risk of serious personal injury, turn the unit off and remove
the battery pack before making any adjustments or removing/installing
attachments or accessories. An accidental start-up can cause injury.
NOTICE：
Lubrication Button Oil Can
Brushless Motor

How to properly use the security lock
EN.3
LOCKUNLOCK UNLOCK
NOTICE：
When not using the chainsaw, please move the safety lock to
the "Lock" position to prevent accidental injuries.
1. It can be easily operated by users, whether they prefer using
their left hand or right hand.
2. Our chainsaw only requires the safety lock to be released,
allowing the device to be operated by simply pressing the
"Start" button. This reduces hand fatigue and improves work
efficiency compared to traditional safety locks.
Our Safety Switch Advantages：

How to lubricate the chain
Oiling System-Oiling the Chain
EN.4
Press
Oil Box
1. Add ordinary chain oil & lubricating oil to the oil box.
2. During the chain rotation, press the oil pump to deliver
lubricating oil to lubricate the chain.
We recommend lubricating every 10 cuts.
NOTICE：

How to adjust the chain tightness
EN.5
NOTICE：If the chain is slightly loose during the constant
cutting process, please don't worry, we can follow the steps
below to adjust the chain tightness.
1. Counterclockwise loosen the cover
fixing nut can be, without removing
the cover its.
3. Tighten the cover fixing nut clock-
wise to finish the adjustment.
2. Turn the cover screw by L-type chain
screwdriver to adjust the chain tightness,
make sure there is only about 0.3cm gap
when pulling the chain, otherwise the chain
will fall off or cause the machine to jam.
Slowly turn the screw to adjust the chain. If you want to fix the
gap between the chain and the guide plate to ensure that it will not
loosen during use, then forcefully tighten the cover plate nut.
Please adjust the tightness of the chain before using the device.lf the chain
is too loose or too tight, it is easy to cause the chain to fall off or the device
to jam.
Please adjust according to the following tips：
Do not continue to loosen the
tightening screws!
Do not use an electric drill to
loosen the screws!
NOTICE：

How to remove the chain
1. Loosen the cover retaining nut counterclockwise.
2. Lift up the protective baffle and remove the side cover.
3. Remove the guide plate and chain.
Remove the chain：
EN.6

How to replace the replacement chain
Install the chain：
EN.7
1. Clean the motor and make sure
there is no debris. (With Cleaning
Brush)
2. Install the guide plate and chain,
make sure the chain plate is oriented
correctly.
3. Adjust the position of the fasteners
on the baffle and tighten the chain in
advance to facilitate the installation
of the cover.(With L-Chaped Chain
Screwdriver)
4. Lift up the protective baffle, put
the cover on and tighten the cover
fixing nut clockwise.
Direction of the chain blade
Confirm the chain tightness is proper. The appropriate tension is when the
chain is tightly attached to the guide plate and can be pulled by hand with
0.1 inch. Please pull the guide plate by hand to ensure that it is fully fixed.
If not, continue to tighten the bar tightening knob.
NOTICE：

How to charge the battery with the charger
EN.8
Before using for the first time,the battery needs to be fully charged.
Do not expose the battery to extreme conditions such as high temperature
or shock, otherwise there is a risk of personal injury due to electrolyte leakage.
Before charging, please check the surface of the battery to make sure it is
clean and dry.
Use our included adapter to charge the battery, and it takes about
1.5 hours for a single full charge (note: the charging interface is at
the position shown in the above figure).
Indicator Light
Red
Green Charging completed
Charging
Status
LED Light Switch
Release Button

How to troubleshoot
EN.9
What is the reason
why the squeeze
button does not pop
up when squeezing
the oil pot?
I give the battery
fully charged state,
the chainsaw can
not start properly,
how should I solve it?
I poured oil into the
jug and it leaked a
little when I was
cutting, is this
normal?
How should I solve
the problem when
the chain gets stuck
when the chainsaw
is cutting?
There are too many
wood chips inside the
cover, causing the
chain to get stuck
We will remove the cover, clean the wood chips
inside can be used normally, there are instructions
in the user manual EN.6 how to remove the cover.
The lid of the oil
reservoir is too tight
Please loosen the lid slightly to keep air
from entering the oiler
Pour out a little oil and leave 1/3 of the
space in the oil reservoir to ensure the
internal pressure work
Check if the transparent tube connecting
the oil pot is bent, if is, it needs to be
adjusted to maintain the normal flow of oil
For the above problems, there may be a variety of
reasons leading to, we recommend direct message
our after-sales email: [email protected] , we let
the professional team dock with you, to give you a
satisfactory solution.
We pour about 2/3 of oil into the oil pot, it is
normal to have a little oil leakage when lubricating
the chain, if there is too much oil leakage, please
contact our after-sales team in time, we will
provide you with a solution at the first time.
You can take a picture and then contact our
after-sales team via after-sales email, and we will
give you a satisfactory solution.
The oiler is overfilling
The oiler tube is bent
Battery causes
Chainsaw causes
Pouring too much
oil into the oil pot
Other reasons
Is it normal for the
chainsaw to stop
automatically
when I am cutting
for a long time?
Check whether the battery power is sufficient, if
the battery indicator shows only 1 cell of electricity,
we recommend that the battery is fully charged
before continuing to work.
When the chainsaw is working for a long time, the
motor may automatically trigger the overheating
protection function to stop cutting, effectively
protecting the life of the chainsaw and allowing it
to continue normal use after cooling down.
Low battery
Chainsaw overheating
protection
How do I tighten
the chain when it is
slightly loose while
cutting?
The chain is not
installed in place / the
chain is slightly loose
due to too much
torque when cutting
The guide bar did not
fixed completely
Dear, you can check the user manual EN.5,
which has detailed instructions on how to
tighten the chain.
Firmly tighten the bar locking knob
Problem Possible Reason Possible Solution

The use and care of chainsaws
1. Do not forced use the chainsaw. Apply the correct power tool for your applica-
tion. The correct power tool will do the job better and safer at the rate for which
it was designed.
2. Do not use the chainsaw if the switch can not be turned on and off. Any chain-
saw that cannot be controlled with the switch is dangerous and must be
repaired.
3. Disconnect the plug from the power source and/or the battery pack from the
chainsaw before making any adjustments, changing accessories, or storing
chainsaw. Such preventive safety measures reduce the risk of unexpected start.
4. Store unused chainsaws out of the reach of children. Do not allow people
unfamiliar with chainsaws or these instructions to operate them. Chainsaws are
dangerous in the hands of untrained users.
5. Maintain the chainsaw. Check for misalignment or binding of moving parts,
broken parts and any other conditions that may affect chainsaw operation. If
there is damage, have the chainsaw repaired before use. Many accidents are
caused by poorly maintained chainsaws.
6. Keep cutting tools sharp and clean. Properly maintained cutting tools have
sharp cutting edges that are less prone to knotting and easier to control.
7. Use the chainsaw and accessories in accordance with these instructions,
taking into account the working conditions and the work to be performed. Using
the chainsaw for operations different from its intended use may result in hazard-
ous situations.
8. Children should be supervised to ensure that they do not play with chainsaws.
Cutting Skills
When the chainsaw is running, keep your other hand at least 6 inches away
from the cutting area of the blade, and the hand must not be put into the
cutting edge.
To ensure the best service life of the chain saw, please do not overload the
equipment and do not cut branches with a diameter of more than 90mm(3.5
inches). Otherwise the chain may become stuck.
To protect the battery pack in cold or wet weather, place it under waterproof
clothing.
Be sure to unplug the battery pack after the cutting is completed.
Do not use this equipment on rainy days.
EN.10

EN.11
The use and maintenance of battery tools
1. Try to use the battery provided by the manufacturer to connect the device to use, to
prevent the use of other batteries lead to the device can not work properly, or even can
burn the device.
2. Try to use the charger specified by the manufacturer for charging. A charger suitable
for one battery pack may create a fire hazard when used with another battery pack.
3. Do not disassemble the battery pack to prevent damage to the battery or even the risk
of short circuit.
4. Protect the battery from heat, such as continuous strong sun-light, fire, water and
moisture. Prevent the danger of explosion.
5. Use the chainsaw only with specifically designated battery packs. Use of any other
battery packs may create a risk of injury and fire.
6. When the battery pack is not in use, keep it away from other metal objects, like paper
clips, coins, keys, nails, screws or other small metal objects that can make a connection from
one terminal to another. Shorting the battery terminals together may cause burns or fire.
7. Under abusive conditions, liquid may be ejected from the battery, please avoid
contact. If contact accidentally occurs, flush with water. If liquid contacts eyes, seek
medical help immediately. Liquid ejected from the battery may cause irritation or burns.
Safety Warnings for Charger
CAUTION! RISK OF EXPLOSION!
Never charge non-rechargeable batteries!
Protect the rechargeable battery from heat,such as
continuous strong sun-light,fire,water and moisture.
Prevent the danger of explosion.
Max.50°c
Do not allow any liquid to come into contact with the charger. Danger of electric shock
may occur.
Do not place tools or chargers near the sink, washbasin, toilet, or any other places near
water.
Do not spill liquid of any kind on the chainsaw or the charger. Doing so may short out
parts, cause damage to the product and create the risk of fire or electric shock.
The most suitable temperature to charge the battery packs are between 68°F-77°F.
During charging, batteries must be placed in well ventilated area.
The chainsaw is not to be used by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge unless they have
been given supervision instructions.
Children must being supervised not to play with the appliance.
Do not recharge non-rechargeable batteries!

Environment
Warranty Terms
EN.12
Maintenance & Cleaning
Before cleaning and maintenance,always switch off the
chainsaw and remove the battery.
Clean the chain carefully after each use.
Wipe the chain with lubricating oil and spray with metal protection spray.
Do not spray the equipment with water or break it into the water, other-
wise it may cause electric shock.
Clean the machine casings regularly with a soft cloth, preferably after each
use, keep the ventilator, motor room and equipment handle clean.
Remove persistent dirt using a soft cloth moistened with soapsuds. Do not
use any solvents such as gasoline, alcohol, ammonia, etc. Chemicals such
as these will damage the synthetic components.
Faulty and/or discarded electrical of electronic apparatus
have to be collected at the appropriate recycling locations.
1.Any natural wear and tear, overload work.
2.Damage caused by lack of daily maintenance.
3.Improper use and other man-made damage.
4.A product modified or dismantled by an illegal repairman.
5.Severe impact damage.
6.Use non-original accessories and batteries.
The warranty period of this product is 12 months, this
clause does not include the following points:

EN.13
Extend Your Warranty by 1 Year
WEEE Recycling Instructions
Register your product within 14 days of purchase at www.imoum.com
to extend your 1-year warranty by an additional year.
Information on electrical and electronic equipment.
The following information is intended for private end users who use
electrical and/or electronic equipment.
1.Separate collection of waste equipment.
Electrical and electronic equipment that has become waste is referred to
as old equipment. Owners of waste equipment must dispose of it separately
from unsorted municipal waste. In particular, old appliances do not belong
in the household waste, but in special collection and return systems.
2.Batteries and rechargeable batteries.
As a rule, owners of old appliances must separate old batteries and accumula-
tors
that are not enclosed in the old appliance from the latter before handing them
in at a collection point. This does not apply if the waste equipment is handed
over to public waste management authorities and separated from other waste
equip ment there for the purpose of preparation for reuse.
3.Options for returning old equipment.
If you have old equipment, you can hand it in at the facilities set up and
available by public waste management authorities for the return or collection
of old equipment for the purpose of proper disposal of the old equipment.
If necessary, it is also possible to hand in electrical and electronic equipment
there for the purpose of reusing the equipment. For more information, please
contact the respective collection or take-back point.

Extended function
EN.14
This product can be combined with a tall pole to form a pole saw, allow-
ing you to use the most cost-effective cost to meet the needs of users in
different scenarios：
8-inch Chainsaw
6-inch Chainsaw Leaf Blower
Hedge Trimmer
Cordless Electric Drill
Pruning Shear
The package does not include the extension height bar, you
can visit the IMOUMLIVE brand store on Amazon to purchase
this accessory!
NOTICE：

Brand: IMOUMLIVE
Product name: 4-INCH MINI CHAINSAW
Model number: DLJ04
WEEE-Reg.-Nr. DE 95546078
Manufacture：Chongqing Mouma Keji You Xian GongSi
Address: 4-1，131Hao，Tian Chi Da Dao，Ba Nan Qu，401320，
Chongqing，China
Contact Us:[e-mail]
EU Responsible Person：C&E Connection E-Commerce (DE) GmbH
Address：Zum Linnegraben 20, 65933, Frankfurt am Main,Germany
E-mail：[email protected]
