IMOUMLIVE LLJ50 User manual
20-Inch Hedge Trimmer
User Manual (LLJ50)
Read all safety rules and instructions carefully before operating this tool.
Questions or Concerns?
English
Product Information
Component
Hedge Trimmer Use Safety Warning
Assemble The Hedge Trimmer
Insert The Battery
Charge The Battery
Start to Use
01
02
02
04
05
06
07
Product Information
Specifications
Model Number
Blade Length
Cutting Speed
Product Length
Product Weight
Horsepower
LLJ50
20 inch
2000/2500/3000 min
31.2 inch
4.4 Pounds
120W
Battery Specification
Battery Type
Voltage
Battery Capacity
Charging Time
Charger Output
Working Time
Li-ion Battery
21V
2.0Ah 37wh
2 Hours
21V 1.2A
60 Min
The liquid on the blade is the lubricating oil we added in advance,
please don't worry about it and it can be used normally.
NOTE
EN.01EN.01
Component
Hedge Trimmer Use Safety Warning
1. Keep all parts of the body at a certain distance from the blade.
Do not move away from the cutting material or hold down on the
material to be cut while the blade is moving. Make sure the switch
is off when clearing jammed material. Distraction during operation
of the hedge trimmer could result in serious personal injury.
2. Carry the hedge trimmer by the tool handle with the blade stopped.
When transporting or storing the hedge.
3. Carry the hedge trimmer by the tool handle with the blade stopped.
When transporting or storing the hedge trimmer, always keep the
cutting unit cover on. Proper handling of your hedge will reduce the
chance of personal injury from the blades.
4. Because the blade may touch hidden wires, only hold the insulated
handle when operating the power tool. When the blade contacts a live
wire, the exposed metal part of the power tool may also become live
and electrocute the operator.
5. Danger: Hands should be kept away from the blade. Contact with
the blade will result in serious personal injury.
6. Do not use the hedge trimmer in rain, water or in a very humid
environment. The motor is not waterproof.
7. When the user uses it for the first time, an experienced hedge
trimmer user should show him how to use the device.
20inch Blade
Splash Guards
(installation required)
Grip
(installation required)
Safer Switch 2.0Ah Battery
Brushless Motor
Aluminum Base
EN.02
8. Children or teenagers under the age of 18 are not allowed to use
the hedge trimmer. Juveniles over the age of 16 are exempt from this
restriction if they have trained under professional supervision.
9. Please only use the hedge trimmer in good physical condition.
Fatigue can lead to decreased concentration of the user. This should
be especially noted towards the end of the working day. All work
should be done calmly and carefully. All losses caused to third parties
shall be borne by the user.
10. Never use a hedge trimmer under the influence of alcohol, drugs,
or medical treatment.
11. Sturdy leather work gloves are one of the basic equipment when
operating a hedge trimmer, and must be worn at all times when
operating a hedge trimmer. Also wear sturdy boots with non-slip soles.
12. Before starting work, please check that the trimmer is in good and
safe working condition. Make sure the protective cover is in place.
Hedge trimmers should not be used until they are fully in place.
13. KMake sure your footing is firm before starting to operate.
14. Hold the tool firmly when using it.
15. Do not operate the tool without a load unless necessary.
16. If the blade touches the guide plate or other hard objects, please
immediately turn off the motor and remove the battery pack. Check
the blade for damage and repair it immediately if damaged.
17. Always turn off the trimmer and remove the battery pack before
inspecting the blades, troubleshooting, or removing material stuck
on the blades.
18. Switch off the trimmer and remove the battery pack before
performing maintenance work.
19. Be sure to remove the battery pack when moving the hedge trimmer
to another location (including during work). Never move or carry the
trimmer with the blades running. Never grab the blade with your hands.
20. Clean the hedge trimmer (especially the blade) after use and before
storing the trimmer for a long time. Apply a small amount of oil to the
blade and put the guard on. The stand that comes with the machine
can be hung on the wall, providing a safe and practical way to store the
hedge trimmer.
21. When storing the machine, cover it and store it in a dry room which
is out of the reach of children. Do not store the trimmer outdoors.
EN.03
22. When using the power supply, do not unplug the AC power cord,
which may damage components. Do not place the power supply in
a high humidity and/or high temperature environment.
23. There is high voltage inside the power supply. Do not open the power
supply enclosure unless you are an authorized service technician or
electrician. Unauthorized opening of the case will void the warranty.
24. The power supply should be powered by the power indicated on
the nameplate.
25. Failure to observe any warnings or precautions stated in this
manual will void all warranties and guarantees.
1. Install the handle with the included screws.
2. Install the splash guards with an included screw.
Assemble The Hedge Trimmer
The liquid on the blade is the lubricating oil we have added, which
is convenient for you to use right out of the box.
Please make sure the handle and splash guard are secured tightly.
NOTE
EN.04
Insert The Battery
To install the battery pack into
the tool handle, align the battery
pack with the rails inside the tool’s
handle and slide it into the handle
until the battery pack is firmly
seated in the tool and ensure that
it does not disengage.
To remove the battery pack from
the tool, press the release button
and firmly pull the battery pack
out of the tool handle.
For best results, make sure your battery pack is fully charged.
NOTE
EN.05
Charge The Battery
Use our included adapter to charge the battery, and it takes about 2
hours for a single full charge (note: the charging interface is at the
position shown in the above figure).
Indicator Light
Red
Green
Status
Charging
Full Charged
Charge the battery pack with the included adapter by inserting it into
the charging jack.
Release buon
LED Light Switch Baery Indicator Light
Charging Po
EN.06
Mode SPM
Start to Use
(1) Hold the hedge machine as
shown in the picture
(3) Horizontal left and right cutting. (4) Up and down cutting.
(2) Start the machine and
choosing the appropriate mode
Low Speed
Medium Speed
High Speed
2000/ min
2500/ min
3000/ min
EN.07
Compatible extension pole need to bought separately from IMOUMLIVE.
NOTE
(5) High hedge trimming. Compatible with IMOUMLIVE Extension Pole
EN.08
Brand: IMOUMLIVE
Product name: 20 inch Hedge Trimmer
Model number: LLJ50
WEEE-Reg.-Nr. DE 95546078
Manufacture: Chongqing Mouma Keji You Xian GongSi
Address: 4-1, 131Ha0, Tian Chi Da Dao, Ba Nan Qu,
401320,Chongqing, China
Contact Us:support@imoum.com
EU Responsible Person：C&E Connection
E-Commerce (DE) GmbH
Address：Zum Linnegraben 20, 65933, Frankfurt am
Main,Germany
E-mail：[email protected]
