Inalto IVD7 User manual

USER MANUAL
V 1.0
MODEL
IVD7
VENTED DRYER
7KG

User Manual inalto.com.au02 03
Congratulations on purchasing your new appliance. The InAlto brand is
proudly distributed within Australia by esidentia Group Pty Ltd.
Please refer to the warranty card at the rear of this manual for information
regarding your product’s parts and labour warranty, or visit us online at
www.residentia.group
At esidentia Group, we are customer obsessed and our Support Team are
there to ensure you get the most out of your appliance. Should you want
to learn more about the various features of your new appliance, and
importantly taking care of your appliance when cleaning, our Support
Team are here to help. You can use our online Support Centre at anytime
by visiting http://support.residentiagroup.com.au, or you can contact us via
calling us on 1300 11 HELP (4357).
It is important that you read through the following use and care manual
thoroughly to familiarise yourself with the installation and operation
requirements of your appliance to ensure optimum performance.
Again, thank you for choosing an InAlto appliance and we look forward to
being of service to you.
Kind Regards,
The esidentia Team
Residentia Group
—
Head Office.
165 Barkly Avenue
Burnley, Victoria
Australia 3121
—
ACN.
600 546 656
—
Online.
residentia.group
WELCOME
Contents 02
Welcome
04
Safety
Instructions
05
Your InAlto
Dryer
05
Before
First Use
06
Accessory
Kit Contents
07
Control Panel
07
Quick Start
Guide
08
Installation
Instructions
11
Operating Your
Vented Dryer
13
Cleaning &
Maintenance
13
Troubleshooting
17
Purchase Details
18
Warranty
Information

User Manual inalto.com.au04 05
• This appliance is only intended for use indoors only
within a domestic environment.
• This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience
and knowledge, unless they have been given
supervision or instruction concerning use of the
appliance by a person responsible for their safety.
• Children should be supervised to ensure that they
do not play with the appliance.
• The dryer is not to be used with any clothing
articles which have had industrial chemicals used
for cleaning.
• The lint trap must be cleaned frequently—we
recommend after each use.
• Adequate ventilation must be provided.
• Never dry unwashed items with your clothes dryer.
• Items that have been soiled with substances
including cooking oils, alcohol, petrol, waxes, etc,
should be thoroughly washed in hot water with
detergent before being dried within your clothes
dryer.
• Never use your clothes dryer to dry items such
as latex, foam rubber, waterproof textiles, rubber
backed articles, or pillows fitted with foam.
• The final cycle of your clothes dryer programs is a
cool down cycle to reduce the temperature of your
clothes. This is incredibly important to ensure that
your clothing items won’t be damaged. NEVER
stop your clothes dryer before the end of its drying
program unless all items are quickly removed and
spread out to ensure the heat is dissipated.
• Ensure all objects are removed from pockets.
• If the power cord is in any way damaged it must be
replaced by the manufacturer, its service agent or
a qualified and licensed electrician.
UNPACKING
• During transportation, protective packaging was
used to protect the appliance against any damage.
After unpacking, please dispose of all elements of
packaging in a way that will not cause damage to
the environment. All materials used for packaging
the appliance are environmentally friendly; they
are 100% recyclable and are marked with the
appropriate symbol.
Caution! During unpacking, the packaging
materials (polythene bags, polystyrene
pieces, etc.) should be kept out of reach
of children.
DISPOSAL OF THE APPLIANCE
• Old appliances should not simply be disposed
of with normal household waste, but should be
delivered to a collection and recycling centre for
electric and electronic equipment. A symbol shown
on the product, the instruction manual or the
packaging shows that it is suitable for recycling.
• Materials used inside the appliance are recyclable
and are labeled with information concerning this.
By recycling materials or other parts from used
devices you are making a significant contribution
to the protection of our environment.
• Information on appropriate disposal centres
for used devices can be provided by your local
authority.
Safety Instructions Your InAlto Vented Dryer
Before First Use
Technical Specications
Key
1. Top-board 2. Control Panel 3. Door 4. Front Panel
5. Side panel 6. Filter 7. Power Plug 8. Door lock/switch
9. Tumbling Drum 10. Front vent
Step 1. Power source and grounding
The dryer employs alternative current with the rated voltage and frequency. When the voltage
fluctuates between 6% of rated voltage, the dryer can work normally. Your clothes dryer should
be on a dedicated power socket for both convenience and safety.
Step 2. Precautions
• Ensure all packaging, user manuals, paper and plastic are removed from within the clothes
dryer before operation.
• Ensure the vents aren’t blocked and adequate air-flow exists.
• Always check your clothing articles care instructions to ensure they are suitable for use
within a clothes dryer. Not all clothes are suitable for use within clothes dryers. The table
below explains common symbols on care instructions for clothing:

User Manual inalto.com.au06 07
ACCESSORY KIT CONTENTS
Accessory Kit Contents
Mix
Cotton
Synthetic
1 Hour
Extra
Standard
Light
Program Dryness Anti-Crease
Play/Pause
Control Panel
1
2345
Key 1. Power button
2. Start or Pause drying program
3. Drying program selector: 1 Hour, Synthetic, Cotton, Mixed Items
4. Dryness level selector: Light, Standard, Extra Dry
5. Anti-crease mode
Quick Start Guide
QUICK START:
1. Ensure the dryer is switched on at the power outlet and add your wet clothes into the tumble drum.
2. Press the “Power” button to switch the dryer on.
3. Press the “Program” button to select your desired drying program. The LED light will indicate which
program you select.
4. Press the “Dryness” button to select your desired level of dryness for your clothes.
5. Press the “Anti-crease” button to add the optional mode.
6. Press the “Start/Pause” button to begin your selected drying program.
7. If you would like to activate the Child Lock safety feature, simply press both the “Program” and “Dryness”
button simultaneously for 3 seconds. The LED indicator next to the lock symbol will alight.
8. When your dryer completes its last heating cycle, a buzzer will sound for 1 second and then begin the
cooling cycle. Once this cooling cycle is complete, the dryer’s buzzer will sound once more.
9. Remove your clothes from the dryer, Press the “Power” button to turn the dryer off and for safety reasons,
remove the power cord from the power outlet.
10. Clean the filter and inner tumble drum.

User Manual inalto.com.au08 09
Installation Instructions
INSTALLATION INSTRUCTIONS
INSTALLATION INSTRUCTIONS

User Manual inalto.com.au10 11
INSTALLATION INSTRUCTIONS
Operating Your Vented Dryer
DETAILED OPERATION:
1. PREPARATION BEFORE DRYER
• Clothes should be washed before use within the dryer.
• Always ensure the same types of clothes are dried together.
• Try to sort your clothes to be dried into load that take a similar time to dry (for example heavier items
separate from light items).
• Make sure any decorations or buttons on your clothing items are safe for high temperatures and well
protected.
• It is recommended to turn your clothes inside-out.
• Please ensure that the power cord is in perfect condition before use. Should there be any damage
to the power cord or plug, please immediately isolate the dryer from power and contact us on
1300 11 HELP (4357).
2. CHECK THE FILTER
• Make sure that the filter is always clean and in the correct position.
• The filter must be cleaned regularly.
3. LOAD THE DRYER
• For faster drying results, load the dryer to 1/2 -> 2/3 capacity of the drum. This will allow the clothes and
air to circulate evenly.
• When drying a small load of clothes or even expensive clothes, it’s best to add some towels that won’t
lose fibers, as this will help the wet clothes to dry more evenly.
• To avoid creases or static charges on your clothes, it’s important to ensure you don’t over-dry your items.
REFERENCE WEIGHTS OF CLOTHING (WHEN DRY):
4. CLOSE THE DRYER DOOR
5. SET YOUR DESIRED DRYER PROGRAM

User Manual inalto.com.au12 13
PROGRAM FUNCTIONS:
Note: At the completion of a drying program, the clothes dryer will circulate cold air.
This ensures that your clothing is left at a temperature and that your clothes aren’t damaged.
The Anti-Crease function adds a short amount of time at the end of your drying program
to shake the clothes and reduce creasing.
Note: The energy rating was calculated using the Cotton program and Extra dryness level
WARNING! Always follow the care instructions on each of your garments.
6. END OF THE DRYING PROGRAM
• At the completion of the program, an audible tone will sound to remind you to remove the clothes from
the dryer.
7. TAKE OUT THE PLUG
• Just to be safe, always unplug the dryer after each use.
8. CLEAN THE FILTER AND INNER DRUM
• Accumulated dust and fibers will effect the air circulation inside the dryer and will cause longer drying
times.
• Always ensure the dryer is switched off and unplugged before cleaning.
Cleaning and Maintenance
Troubleshooting
By ensuring proper cleaning and maintenance of your InAlto Vented Dryer, you can ensure that it will have a
long and fault free operation.
WARNING! To avoid an electric shock, always unplug your dryer before cleaning.
CLEANING THE FILTER
• Remove the lint filter, located within the door opening.
• Clean the filter by wiping it with a damp cloth.
• Once dry, re-fit the lint filter into the door opening.
Important! Clean the filter after each use.
CLEANING THE INNER DRUM
• Use a soft damp cloth to wipe the inner drum and cabinet.
• Ensure that the cloth is only slightly damp and never use excessive amounts of water.
• Do not use scouring pads or other abrasives as these will cause damage to your dryer.
• Do not use alcohol wipes or harsh cleaning chemicals.
OPERATION IN CASE OF EMERGENCY
In the event of an emergency you should:
• Switch off the clothes dryer using the Power button
• Switch the clothes dryer off at the power point and unplug the unit. If the power point isn’t accessible,
switch the relevant circuit off at your fuse box/switch board.
• Call our support team on 1300 11 HELP (4357).
Some minor faults can be fixed by referring to the instructions given in the Troubleshooting section below
and on the following page.

User Manual inalto.com.au14 15
Further problem solving:
Safety Reset
1. These dryers have a safety cut out switch which is activated by temperature.
2. The safety reset button is on the backboard. If your dryer not heating this button must be reset before
the dryer will operate again. You may need to wait 10 minutes for cooling to occur.
3. The most common reason for the dryer to overheat is a blocked filter. Clean the lint filter after each load
to prevent overheating of the dryer.
It will only be necessary to press the safety reset button if the dryer not heating. Allow the dryer at least
10 minutes to cool down before pressing the button .Press the white button in until you feel the reset
click. Cleaning the filter after each load will avoid repetitive operation of the safety cut out switch.
The cut out switch may operate for the following reason:
1. Lint filter is blocked.
2. Exhaust outlets blocked at the back of the dryer.
3. Poor ventilation in the laundry or room-open a window or door
4. Lightweight garment eg. Handkerchief, sucked over the filter.
Safety Reset Button:
Use your nger or a pencil to press the button in until you feel it click.
Purchase Details
For future reference, please record the following
information which can be found on the rating plate and the
date of purchase which can be found on your sales invoice.
The rating plate of your hob is located on the underneath
of the appliance. Therefore please t the duplicate data
plates or label on the outside of the cupboard to sure that
the label can be easily seen during operation.
STORE DETAILS
STORE NAME
|
ADDRESS
|
TELEPHONE
|
PURCHASE DATE
|
PRODUCT DETAILS
MODEL NO.
|
SERIAL NO.*
|
Attach your receipt
to this page

User Manual inalto.com.au16 17
WARRANTY TERMS & CONDITIONS
DRYER
This document sets out the terms and conditions of the
product warranties for Residentia Group Appliances. It is
an important document. Please keep it with your proof of
purchase documents in a safe place for future reference
should you require service for your Appliance.
1. IN THIS WARRANTY
(a) ‘acceptable quality’ as referred to in clause 10 of this
warranty has the same meaning referred to in the
ACL;
(b) ‘ACL’ means Trade Practices Amendment (Australian
Consumer Law) Act (No.2) 2010;
(c) ‘Appliance’ means any Residentia Group product
purchased by you accompanied by this document;
(d) ‘ASR’ means Residentia Group authorised service
representative;
(e) ‘Residentia Group’ means Residentia Group Pty Ltd
of 165 Barkly Ave, Bunrley VIC 3121, ACN 600 546 656
in respect of Appliances purchased in Australia;
(f ) ‘major failure’ as referred to in clause 10 of this
warranty has the same meaning referred to in the ACL
and includes a situation when an Appliance cannot
be repaired or it is uneconomic for Residentia Group,
at its discretion, to repair an Appliance during the
Warranty Period;
(g) ‘Warranty Period’ means:
(i) where the Appliance is used for personal,
domestic or household use (i.e. normal
single family use) as set out in the instruction
manual, the Appliance is warranted against
manufacturing defects for 24 months, following
the date of original purchase of the Appliance;
(h) ‘you’ means the purchaser of the Appliance not having
purchased the Appliance for re-sale, and ‘your’ has a
corresponding meaning.
2. This warranty only applies to Appliances purchased
and used in Australia and is in addition to (and does
not exclude, restrict, or modify in any way) any
non-excludable statutory warranties in Australia.
3. During the Warranty Period Residentia Group or its
ASR will, at no extra charge if your Appliance is readily
accessible for service, without special equipment
and subject to these terms and conditions, repair or
replace any parts which it considers to be defective.
Residentia Group or its ASR may use remanufactured
parts to repair your Appliance. You agree that any
replaced Appliances or parts become the property
of Residentia Group. This warranty does not apply
to light globes, batteries, lters or similar perishable
parts.
4. Parts and Appliances not supplied by Residentia
Group are not covered by this warranty.
5. You will bear the cost of transportation, travel and
delivery of the Appliance to and from Residentia
Group or its ASR. If you reside outside of the service
area,
you will bear the cost of:
(a) travel of an authorised representative;
(b) transportation and delivery of the Appliance to and
from Residentia Group or its ASR, in all instances,
unless the Appliance is transported by Residentia
Group or its ASR, the Appliance is transported at
the owner’s cost and risk while in transit to and from
Residentia Group or its ASR.
6. Proof of purchase is required before you can make
a claim under this warranty.
7. You may not make a claim under this warranty unless
the defect claimed is due to faulty or defective parts
or workmanship. Residentia Group is not liable in the
following situations (which are not exhaustive):
(a) the Appliance is damaged by:
(i) accident
(ii) misuse or abuse, including failure to properly
maintain or service
(iii) normal wear and tear
(iv) power surges, electrical storm damage or
incorrect power supply
(v) incomplete or improper installation
(vi) incorrect, improper or inappropriate operation
(vii) insect or vermin infestation
(viii) failure to comply with any additional instructions
supplied with the Appliance;
(b) the Appliance is modied without authority from
Residentia Group in writing;
(c) the Appliance’s serial number or warranty seal has
been removed or defaced;
(d) the Appliance was serviced or repaired by anyone
other than Residentia Group, an authorised repairer
or ASR.
8. This warranty, the contract to which it relates and the
relationship between you and Residentia Group are
governed by the law applicable where the Appliance
was purchased.
9. To the extent permitted by law, Residentia Group
excludes all warranties and liabilities (other than as
contained in this document) including liability for any
loss or damage whether direct or indirect arising from
your purchase, use or non use of the Appliance.
10. For Appliances and services provided by Residentia
Group in Australia, the Appliances come with a
guarantee by Residentia Group that cannot be
excluded under the Australian Consumer Law. You
are entitled to a replacement or refund for a major
failure and for compensation for any other reasonably
foreseeable loss or damage. You are also entitled
to have the Appliance repaired or replaced if the
Appliance fails to be of acceptable quality and
the failure does not amount to a major failure. The
benets to you given by this warranty are in addition
to your other rights and remedies under a law in
relation to the Appliances or services to which the
warranty relates.
11. At all times during the Warranty Period, Residentia
Group shall, at its discretion, determine whether
repair, replacement or refund will apply if an
Appliance has a valid warranty claim applicable to it.
12. To enquire about claiming under this warranty, please
follow these steps:
(a) carefully check the operating instructions, user
manual and the terms of this warranty;
(b) have the model and serial number of the Appliance
available;
(c) have the proof of purchase (e.g. an invoice) available;
(d) telephone the numbers shown below.
13. You accept that if you make a warranty claim,
Residentia Group and its ASR may exchange
information in relation to you to enable Residentia
Group to meet its obligations under this warranty.
IMPORTANT
Before calling for service, please ensure that the steps
in point 12 have been followed.
→ Service: Please call us on 1300 11 HELP (4357)
The Australian Consumer Law requires the inclusion of the following statement with this warranty: Our goods come with guarantees that cannot
be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and for compensation for any other
reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure.
Warranty Information

User Manual 18
TEL. [phone]
[e-mail]
WWW.RESIDENTIA.GROUP
AN INITIATIVE BY
RESIDENTIA GROUP
