AL4001
4-PortRapidCarCharger
InstructionManual

AL40014-PortRapidCarCharger
Productintroduction
This handy car charger is a device which plugs the
cigarette lighter to power smartphones and tablets
electronicsfastandsafely.Beingsmoothandsleek,it
featured with four 2.4amps USB charging ports
containedintelligentICchip,whichcoulddetectthe
devicesanddeliverfastcharge.Fourmobileelectron-
icslikeiPhone,iPad,GPScouldbefedsimultaneously.
With premium ABS+PC fireproof materials, this car
charger is functioned with short circuit, over-watt,
over-current and overheat protections, this ensures
safeandhigh-efficiencyuse.ItiscertifiedbyCE,FCC&
RoHS.
Components
This car chargerʼs integrating body was made from
plastic shell and its spring positive plate was
constructedwithcopper,whilezincalloymadeofthe
negativeplate.

ProductSpecifications
Input:
Output:
Surfacecrafts:
Material:
LEDindicatorlight:
Size:
Storagetemperature:
Color:
DC12-18V
DC5.0V9.6A(4x2.4A)
UV
ABS+PC
Blue
47.9x27.4x83.8(mm)/1.88x1.07x3.29(inch)
1month(-20℃~60℃);3months(-20℃~50℃)
Unibodydesignwithblackandwhitecolors,
themetalringofUSBportsarepaintedwith
silverandgold
LEDindicator
USBport

Instructions
Plugthecarchargerincigarettelighter;LEDlightturns
bluemeans thechargerisreadytogo.It can power
fourmobiledevicesatthesametime.IftheLEDlight
goes out in the process of charging, then it may
causedbytheoutputover-currentprotection.Allyou
havetodoistopulloutthechargerandre-plugit.
Circuitperformancequota
DCinputvoltagerange:
USBoutputvoltagerangewithoutload:
USBfull-loadoutputrippleof5V/9.6A:
USBfull-loadoutputaverageefficiencyof5V/9.6A:
TheUSBoutputovervoltageprotection:
USBoutputover-currentprotection:
10-18V
5.05V-5.25V
≤250mV
≥90%
6.25±0.25V
≥12A
PackageContents
4-Portrapidcarcharger*1
MicroUSBchargingcable*2
Nylonstickerribbons*2
Instructionmanual*1

Notes
1.12/18VDCinputvoltagemaynotworkwithsome
24 volt output cigarette lighter sockets. Please use
original charging cord or the onewithathird party
certification.
2. Please plug the charger after starting the car
engine;
3.Pleasepulloutthechargeraftershutdownthecar
engine;
4. Charging stops automatically in the event of
overcharging, lower/over voltage, overheating,
overcurrent,andshortcircuit.(Chargerwillbacktolife
afterpullingoutthedevices)
5.Itʼsnormalforthechargertobedissipatedwithin60
degreesunderthecommonroomtemperaturewhen
inuse.
