Inateck mercurybox BP2101 User manual

MercuryBox
InstructionManual
BP2101Bluetooth®Speaker

English
Overview
○Mic ○Play/
PauseButton
○Next/VolumeUP
○Previous/VolumeDown
○PowerButton/
Batteryindicator
○MultifunctionButton
A C E
F
DB
○MicroUSBPort
○AUX
○Reset
AUX
DC-IN
G
I
H
1

D
E
F
G
H
I
Bluetoothre-pairing:Pressandholdthebuttonto
interruptcurrentBluetoothconnectionand
re-pairadevice
Handsfreecalling:presstoansweracall,press
againtoendacall
Bluetoothindicator:blinkingbluelight‒
discoverableandreadytopairorreconnectwitha
device;solidbluelight-connectedtoapaired
device
Presstoplaynextsong,pressandholdthebutton
tocontinuouslyincreasespeakervolume
Presstoplayprevioussong,pressandholdthe
buttontocontinuouslytodecreasespeaker
volume
Forcharging
Toresetthespeaker
Presstoselectthesource(smartphone,iPadand
othermusicplayer)connectedtotheAUXinput
via3.5mmaudiocable
MultifunctionButton
Next/VolumeUp
Previous/
VolumeDown
Micro-USB-Anschluss
Reset
AUX
A
B
C
No. ButtonName Function
MicrophoneforBluetoothmode
Pressandholdthebuttonfor3secondstoturn
thespeakeronoroff;Blinkingredlightindicates
lowbattery;Solidredlightindicatescharging
state
Presstoplayorpausemusic
Mic
PowerButton/
Batteryindicator
Play/PauseButton
Packagecontents
Howtopairadevicetothespeaker
•1*MercuryBoxspeaker
•1*1.2m/4Ftaudiocable
•1*1.2m/4FtUSBchargingcable
•1*PUprotectioncase
•1*Handstrap
•2*Customizedcableties
•1*Instructionmanual
1.Press and holdthe power button (ButtonB) for 3seconds to turn the
speakeron.(Thisoperationwillturnitoffwhenthespeakerison.)
2.Thespeakerwillautomaticallygointodiscoverablemodeindicatedby
Bluetoothparingbutton(ButtonD)blinkingbluelight.
3.FromtheBluetoothdevicelist,selectthedevicenamed“InateckMercury-
Box” to connect. The speaker indicates pairing is complete when the
Bluetoothindicator(ButtonD)changesfromblinkingbluetosolidblue
andthespeakeremitsatone.
2

Howtoansweracallonthespeaker
HowtouseAUXmode
Pressmultifunctionbutton(ButtonD)toansweracall,pressitagaintoenda
call.Yourphoneisstillabletoansweracalldirectly.
Notes:
•DuetoAUXʼshigherpriority,Bluetoothwilldisconnectwhenplugging
audiocabletoAUXinput.
•HaveabetterexperiencetoansweracallviaAUXconnection.
•PressthePlay/Pausebuttonwillmutethespeakerinsteadofpausing.
•Previous/NextsongisnotaccessibleunderAUXmode.
1.Plugtheincluded3.5mmaudiocablefromtheaudiodeviceintotheAUX
input on the side of the speaker, the connection is complete when
multifunctionbutton(ButtonD)indicatessolidbluelight.
2.Playmusic.
Notes:Tore-pairadevice,pressandholdmultifunctionbutton(ButtonD)for
3-4secondsuntilBluetoothindicatorblinksbluelight.
4.Thespeakerisgoodtogoandstreambeautifulmusic.
3
Bluetooth
Bluetooth
Inateck MercuryBox
Bluetooth
Inateck MercuryBox
Hello

Batteryindicator(ButtonB) Speakerstate
Lowbattery
Charging
Fullycharged
Blinkingredlight
Solidredlight
Redlightgoesoff
Waterprooflevel
Howtochargethespeaker
ThisspeakeriscompliantwithIPX5waterproofstandard“splashproofinall
directions”.Neitherput“MercuryBox”underjet-waternorsinkintowater.
Tips:
•Powersaving mode:Thespeaker willturn offautomaticallyaftermore
than 10 minutes of zero activity from both, the Bluetooth and AUX-IN
sources.
•Thereasonwhyitdoesnotcomewithacharger:USBchargersofmost
smartphones (apple/android/windows) and tablets all meet the
requirementsof5V/1Aoutput,tabletsevenreachupto5V/2A,andallwill
chargethespeaker efficiently.Tolessenneedlessrepeat purchaseand
reduceenvironmentaldamagecausedbyindustrialmanufacture,wedo
notsupplychargerforthespeaker.
1. Plug the included Micro USB charging cable from the speaker to a USB
charger.
2.AllUSBchargersof5Vvoltagecanchargethespeaker,chargersofover1A
currentarerecommendedforsavingchargingtime.
3.Afterfullycharging,thespeakerdeliversupto9-15hoursofplaytimebased
ondifferentmusicalstylesandvolumes.
IPX5waterproof
4
(Notincluded)

Otherinformation
Troubleshooting
Safetyinformation
PleasetakeyourtimetofollowtheguidelinescarefullybeforeusingInateck
products.
Built-inbattery
•Donotdismantle,openorshredbatterypack.
•Thebatterypackshallnotbeexposedtoexcessiveheatsuchassunshine,fire
orthelike.
Notes: Due to the characteristic of Bluetooth wireless technology, it is
possiblethatthereisaslightdelayinaudioplaybackfromthetransmitting
BluetoothdevicetotheBluetoothreceiver.
1.Speakerdoesnotturnon.
•Batterymayrunoutandneedtobecharged.PlugtheUSBchargingcable
from the speaker to a working power supply or computer, charge the
speakerforatleast1hourbeforeuse.
2.SpeakerdoesnotpairorconnecttoBluetoothdevice.
•MakesureyourBluetoothdevicesupportstheA2DPprofile.
•Delete “Inateck MercuryBox”from the Bluetooth liston yourBluetooth
device.Thentryparingagain.
•Beforeparing,makesureneitherBluetoothdevicenorspeakerconnects
tootherdevices.
•Bluetoothrangeisupto10metersinopenspace.YourBluetoothdevice
maybeoutofrange.Trymovingitclosertothespeaker.
•Resetthespeaker.
3.Intermittentsoundorconnectionandplosivefromthespeaker.
•MoveyourBluetoothdeviceatleast10metersawayfromanydevicethat
generateselectromagneticinterference.
•Movethemobiledeviceclosertothespeaker.
•Ifpossible,turnoffanyinterference.
•DonotputBluetoothdeviceandspeakerinoronametalobject.
4. No audio or poor sound comes from the speaker when connecting to
AUX-insource.
•MakesuretheconnectedAUXdeviceisonandplaying.
•DecreasethevolumelevelontheAUXdevice.
•MakesuretheaudiocableisfirmlyconnectedtotheAUXinputandthe
sourcedevice.
•TryusingadifferentAUXcable.
•  Rather than connect to 4-pole stereo audio cable with Mic, please try
using3-polecable.
5

Specifications
Bluetooth4.0
2402-2480MHz
1800mAH
DC5V/1A
5W*2CH
0°C-45°C(32°F-113°F)
IPX5
A2DP,AVRCP,HFP,SPP,DIS,FMP,HRP,HRS,HTP,
HTS,IAS,LLS
*RefertoyourBluetoothdevice(notebook,PC,
mobiledevice)manufacturerʼsdocumentation/
websiteforsupportedprofiles.
SBC
ThespeakerʼsBluetoothrangeisupto10-15meters
inopenandunobstructedspace.Wallsand
structuresmayaffectrangeofdevice.
Bluetoothversion
Operatingfrequency
Batterycapacity
Input
Speakeroutputpower
Temperaturerange
Waterproofrange
SupportedBluetoothprofiles
SupportedCodec
Bluetoothrange
Compatibilitystatement
Wireless performance depends on your deviceʼs Bluetooth wireless
technology. (Please refer to your device manufacturerʼs manual.) Inateck
assumesnoresponsibilityforanydatalossorleakagecausedbyusingthese
devices.
AdditionalguidelinesforBluetoothdevices
•Theshortwaveradiofrequencysignalsofawirelessdevicemayimpairthe
operationofotherelectronicandmedicaldevices.
•Switchoffthedevicewhereitisprohibited.Donotusethedeviceinmedical
facilities,aircraft,refuelingpoints,closetoautomaticdoors,automaticfire
alarmsorotherautomaticallycontrolleddevices.
•Keepthisdeviceatleast20cmfrompacemakersandothermedicaldevices.
Radiowaves mayimpair the operationof pacemakers and other medical
devices.
