Inax ECOCARAT+ User manual

As fish can live only in water,
we cannot live without air.
Separating the air with walls,
a public place turns into a private space.

As the walls are put together and
become “a box of air”,
a home is born there.
As the place to give you peace of mind.
Put furniture and plants
into “a box of air” and
a living is produced.
1

Start making a home from
thinking about air.

4

Air cleaning wall
ECOCARAT is an interior wall material that beautifully arranges your
home and air. The Nanoporous ceramics*, that have its roots in mud
walls well-suited to the Japanese climate, inhale and exhale the air
in homes keeping comfortable humidity throughout all seasons and
reducing household odors and harmful substances. ECOCARAT PLUS
that has more air holes and capacity than ECOCARAT is now available.
The air purifying power has increased more than ever.
*Nanoporous ceramics: Highly porous material that has many invisible fine holes
ECOCARAT, known as “Breathing wall”,
evolved to ECOCARAT PLUS.
By increasing the number of air holes,
its air purifying power became more powerful.
NEW
5

4 FREE Declarations of
ECOCARAT PLUS
For heartful living
to fill up your mind and body with comfort.
ECOCARAT PLUS promises to
support the solutions for “worries of home and air”.
6

FREE from
Everyday stains and dirt
Easy cleaning of daily stains and dirt especially
in water-exposed places.
FREE from
Humidity trouble
Maintains comfortable humidity throughout the year
helping to control dew condensation, mold and mites.
FREE from
Household odors
Deodorizes and reduces odors from garbage, pets and
toilets absorbing the causes of odors.
FREE from
Harmful substances
Absorbs and reduces harmful substances in the air
to support the safety of all family members.
1
2
3
4
ECOCARAT PLUS is a collaborative research product of the Ministry of International Trade and Industry National Industry Research Institute
of Nagoya (Currently, National Institute of Advanced Industrial Science and Technology Chubu Center) (Patent No. 2948133 and others)
7

FREE from Humidity trouble
1
The humidity level in a room changes depending on the
temperature and climate not only through the seasons but
also during the course of a day. Humidity that influences
your family member’s health and durability of the home
can be used as a comfort level indicator of your home.
ECOCARAT PLUS absorbs excessive humidity to control
dew condensation on windows, and the generation of mold
and mites. Also, it prevents extreme dryness and supports to
provide an environment that is gentle for your throat and skin.
5 to 6 times the humidity absorption capability of
diatomaceous earth wall.
Provides gentle air to family members and the home
by keeping a comfortable humidity level.
FREE from Household odors
2
Household odors you feel when you open the front door. It
is one of those things you don’t want your guests to notice.
It is something you want to control for your own comfortable
living, too. The cause of household odors is a collection of
various smells produced in daily living*1. ECOCARAT PLUS
deodorizes and reduces unpleasant odors by absorbing
the causing components of each household odor. It is also
suitable for health care facilities such as hospitals, since it is
effective for eliminating body odors and odors produced in
nursing care environments.*2
*1: Pet odor (methyl mercaptan), household garbage odor (trimethl amine), toilet
odor (ammonia) and smoking odor (hydrogen sulfide)
*2: Body odors and odors in nursing care environments (nonenal and hydrogen
sulfide)
Provides fresh air to family and guests with
odor absorption power
superior to diatomaceous earth wall
Amount of
moisture absorbed
and released
Reduction rate of
odors in nursing
care environments
3 times
3 times
ECOCARAT
PLUS
Diatomaceous
earth wall
Conditioning
wallpaper
8

In daily living, stains and dirt are always there from
water splashes, fi nger marks, and rubbing from shoes
and bags. The double-layer surface of ECOCARAT
PLUS has a very fi ne structure through which only
humidity can pass, and water and dirt have a hard time
penetrating into. Even if stained or it becomes dirty, it is
very simple to clean.
FREE from Harmful substances
3
Such harmful substances fl oating in the air as
formaldehyde and toluene which are emitted by furniture
and other building materials are known to strongly
stimulate mucous membranes of humans causing
asthma, atopic dermatitis and other skin problems.
ECOCARAT PLUS absorbs and reduces these harmful
substances lowering its concentration level in the air,
which changes the home to a safe space for your family.
*Accredited from the Building Center of Japan Foundation. It is given only to
materials which meet strict standards.
Absorbs and reduces the materials that cause
SICK HOUSE SYNDROM.
Acquired “Formaldehyde Reduction Building
Material Accreditation*”.
FREE from Everyday stains
and dirt
4
The surface hole that let moisture pass through
easily is nanosize.
Since dirt and water are hard to penetrate into
the tiles, it is easy to clean.
Compared with ECOCARAT at
in-company research
Cleaning power
Toluene
reduction rate
3 times
3 times
Humidity
Water
Stain
9

Living Room
With relaxing space and
comfortable clean air, a
Living room is produced
for everybody to gather.
10

Wall: ECOCARAT PLUS GRANAS VAGUE P18
ECP-315/VAG1
Wall: ECOCARAT PLUS GRANAS HART P19
ECP-250/HRT1
Wall: ECOCARAT PLUS SHAILY P21
ECP-30NET/SHY1
Top
Down
Left
11

Bedroom
The Bedroom, where you spend hours
may become humid with dew.
High quality of air should be there for
a good night sleep and fresh waking up.
12

Wall: ECOCARAT PLUS STONEⅡ P23
ECP-SETA/STN3
Wall: ECOCARAT PLUS ROUGHSAWN P20
ECP-275NET/RGS3
Wall: ECOCARAT PLUS ROCKⅡ P22
ECP-SET2/RCK1
Top
Down
Left
13

Entrance
If unpleasant household odors and
humidity can be refreshed,
Your family can enjoy and
welcome guests in clean air.
14

Wall: ECOCARAT PLUS ROCKⅡ P22
ECP-SET2/RCK3
Wall: ECOCARAT PLUS GRANAS HART P19
ECP-250/HRT2
Wall: ECOCARAT PLUS STONEⅡ P23
ECP-SETC/STN2
Top
Down
Left
15

Bathroom
To make a day fresh,
clean the bathroom diligently.
It makes me happy,
when it is easy to clean and free from odor.
16

Wall: ECOCARAT PLUS SILKLINE P29
ECP-303/SLA2N
Wall: ECOCARAT PLUS NUNOGARA P27
ECP-303/NU4N
Wall: ECOCARAT PLUS REFRAIN P24
ECP-SET/REF1N
Top
Down
Left
17

151.5
303
9.0
303 x 151 mm
(relief)
ECP-315/VAG1〜VAG3
22.6 pcs./m2 22 pcs./ctn.
303 x 151 mm
(rib)
ECP-315/VAG1A〜VAG3A
22.6 pcs./m2 26 pcs./ctn.
303 x 151 mm
for narrow edges
ECP-3151/VAG1A（R）〜VAG3A（R）
3.4 pcs./m 26 pcs./ctn.
Example of
wall corner mounting
ECP-315/VAG1・VAG1A、
ECP-3151/VAG1A（R）
Example of
wall internal mounting
ECP-315/VAG1・VAG1A
ECP-315/VAG2
The continuous curved surface generates a rhythm
on the wall producing an impressive space.
GRANAS VAGUE
●
Because VAG1 to VAG3 has a designated destination for right and left, install according to the example layout.
●
VAG1 to VAG3 should be laid out and installed without cutting. The thickness changes depending on the cutting point and the side may become visible.
●
VGA1 and VGA1A has white as its base color to avoid staining after installation as stains may appear conspicuous.
●
Because 303 x 151 mm for narrow edges (right side) is available for filler parts, the vertical installation is recommended.
●
In the case of wall corner mounting, please use 303×151 mm (rib) and for narrow edges (right side).
●
In the case of wall internal mounting, please use 303 x 151 mm (rib). However, it does not become completely flat due to the design.
151.5
303
6.
0
303
6.0
151.5
Side glazed
When installing 303 x 151 mm (relief),
place the ECOCARAT PLUS alternately so
that the orientation of adjacent
ECOCARAT PLUS does not point to the
same direction, as shown in the
illustration on the left.
Example layout
↑
↑
↑
↑
↑
↑
↑
↑
↑
↑
↑
↑
↑
↑
↑
↑
↑
↑
27 20
The relief pattern has a designated
orientation. As shown in the illustration
on the left, the orientation can be
judged as up when placing the relief and
the narrow width side comes to the
right.
Designated orientation of
303 x 151 mm (relief)
ECP-315/VAG1
（White）
ECP-315/VAG2
（Gray）
ECP-315/VAG3
（Dark gray）
ECP-315/VAG1A
（White）
ECP-315/VAG2A
（Gray）
ECP-315/VAG3A
（Dark gray）
Due to the design, the side may be partially
visible in 303 x 151 mm (relief), because the relief
does not connect on the upper side.
G series
