InCoax D2508 Instructions for use

InCoax D2508
DPU
Hardware User Manual
InCoax D2508 EU
InCoax D2508 UK
InCoax D2508 US
InCoax D2508 ER EU
InCoax D2508 ER UK
InCoax D2508 ER US
InCoax D2508 RPF EU
InCoax D2508 RPF UK
InCoax D2508 RPF US
InCoax D2508 RPF ER EU
InCoax D2508 RPF ER UK
InCoax D2508 RPF ER US

InCoax DPU – Hardware User Manual
2
Disclaimer
InCoax Networks AB makes no representations or warranties with respect to this manual and, to the maximum
extent permitted by law, expressly limits its liability for breach of any warranty that may be implied to the
replacement of this manual with another. Furthermore, InCoax Networks AB reserves the right to revise this
publication at any time without incurring an obligation to notify any person of the revision.
The information provided in this documentation contains general descriptions and/or technical characteristics
of the performance of the products contained herein. This documentation is not intended as a substitute for
and is not to be used for determining suitability or reliability of these products for specific user applications. It
is the duty of any such user or integrator to perform the appropriate and complete risk analysis, evaluation and
testing of the products with respect to the relevant specific application or use thereof. Neither InCoax
Networks AB nor any of its affiliates or subsidiaries shall be responsible or liable for misuse of the information
that is contained herein. If you have any suggestions for improvements or amendments or have found errors in
this publication, please notify us.
All pertinent state, regional, and local safety regulations must be observed when installing and using this
product. For reasons of safety and to help ensure compliance with documented system data, only the
manufacturer shall perform repairs to components.
Failure to observe this information can result in injury or equipment damage.
Copyright © 2022 InCoax Networks AB. All rights reserved. Confidential under NDA.
No part of this publication may be reproduced, distributed, or transmitted in any form or by any means,
including photocopying, recording, or other electronic or mechanical methods, without the publisher's
prior written permission

InCoax DPU – Hardware User Manual
3
Document Revisions
Date
Rev
Originator
Description
2022-05-27 V.1 Leif Ekman Initial version.
2022-05-30 V.2 Leif Ekman Updated PA and size/weight.
2022-08-16 V.2.1 Robert Morau Updated product data.
2022-09-21 V.2.2 Robert Morau Updated product data.

InCoax DPU – Hardware User Manual
4
Contents
PREFACE .....................................................................................................................5
CONVENTIONS USED IN THIS MANUAL................................................................................................... 5
EXPLANATIONS OF THE SAFETY WARNINGS ........................................................................................... 5
SAFETY INSTRUCTIONS ............................................................................................................................ 5
WHEN USING THE DPU............................................................................................................................ 6
TEMPERATURE WARNING ....................................................................................................................... 6
INSTALLATION ENVIRONMENT................................................................................................................ 6
STORAGE ENVIRONMENT........................................................................................................................ 7
THEFT AND VANDALISM.......................................................................................................................... 7
1ABBREVIATIONS AND DEFINITIONS .....................................................................8
1.1 ABBREVIATIONS ........................................................................................................................... 8
1.2 DEFINITIONS................................................................................................................................. 9
2PACKAGE CONTENT ...........................................................................................10
3INTRODUCTION .................................................................................................10
3.1 INCOAX D2508 MOCA ACCESS DPU SYSTEM.............................................................................. 10
3.2 THE DPU ..................................................................................................................................... 11
3.2.1 D2508 Input Power alternatives............................................................................................ 11
3.2.2 D2508 ER extended range ..................................................................................................... 12
4COAXIAL NETWORK USE CASES..........................................................................12
5DPU WEB INTERFACE ACCESS ............................................................................12
5.1ACCESSING THE DPU WEB INTERFACE ....................................................................................... 12
6SPECIFICATIONS.................................................................................................12
7LEGAL INFORMATION ........................................................................................15
7.1 REGULATORY NOTICE AND STATEMENT (CLASS A).................................................................... 15
7.1.1 Canada ................................................................................................................................... 15
7.1.2 European Union..................................................................................................................... 15
7.1.3 United States of America....................................................................................................... 15
7.1.4 TUV SUD NRTL ................................................................................................................ 16
7.1.5 Great Britain .......................................................................................................................... 16
8DISPOSAL OF EQUIPMENT .................................................................................16
8.1 WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT .................................................................. 16
8.2 FOR BUSINESS USERS IN THE EUROPEAN UNION ...................................................................... 16
8.3 DISPOSAL IN COUNTRIES OUTSIDE THE EUROPEAN UNION ...................................................... 17
8.4 BATTERY SYMBOL....................................................................................................................... 17
9REFERENCES ......................................................................................................17

InCoax DPU – Hardware User Manual
5
List of Figures
Figure 1— Overview of the Management System ....................................................................................................... 11
List of Tables
Table 1 — Abbreviations................................................................................................................................................ 8
Table 2 — Definitions of the Terminology ..................................................................................................................... 9
Table 3 — Contents of the package. ............................................................................................................................ 10
Preface
Conventions Used in this Manual
The references to another document or websites are labeled with lower case bold and italic characters within
curly brackets { }.
All references in the text to a section, figure, and table are denoted in bold and italic.
Explanations of the Safety Warnings
Danger indicates a hazard with a high level of risk which, if not avoided, will result in death or serious injury.
Warning indicates a hazard with a medium level of risk which, if not avoided, could result in death or serious
injury.
Caution indicates a hazard with a low level of risk which, if not avoided, could result in minor or moderate
injury.
Indicates information considered important, but not hazard-related.
Safety Instructions
Always make sure to connect all coaxial cables and network cables to DPU before connecting the power cable.
Ground the DPU enclosure in the DPU earth terminal with coaxial network earth terminal. This must be done to
avoid electrical shock and to avoid damage to the unit. Ground loops might build up enough electrical charge to
give an electrical shock if not properly connected before connecting the power cord. Make sure to connect the
CATV amplifier’s ground connection to the DPU unit if both the CATV amplifier and DPU are installed in the
same physical location.

InCoax DPU – Hardware User Manual
6
When using the DPU
The DPU is designed to operate on 100/230 VAC or Reverse Power Feeding. To enable RPF, an InCoax RPF
modem must be used.
Please observe the following:
•Do not stick any foreign objects, like metal or flammable objects into the DPU, as this can cause fire or
electric shock.
•Do not remove the inner cover sheets or modify them in any way.
-High voltages which can cause severe electric shocks are present inside the DPU enclosure. For any
inspection, adjustment, and repair work please contact the local InCoax dealer. The warranty may be
void if the cover to the high voltage DPU area has been opened.
-Never attempt to repair this product yourself. Improper repair work can be dangerous. Never
disassemble or modify this product. Tampering with this product may result in injury or fire.
The warranty is void if the cover to the low voltage DPU area has been opened.
•Do not handle the power supply plug with wet hands as this may cause electric shocks.
•Do not use in locations subject to high humidity or dust levels exceeding IP certification, as this may cause
damage to the equipment or start a fire.
•Do not do anything that may damage the power cable. When disconnecting the power cable, pull on the
plug body, not the cable.
•Do not damage a power cable, make any modifications to it, place heavy objects on top of it, heat it, place
it near any hot objects, twist it, bend it excessively, or pull it. To do so may cause fire and electric shock.
The whole power cord should be discarded if the cable is damaged in any way.
•The power cord shall also be discarded if the plug is damaged.
•Do not place heavy objects on top of the DPU.
•Securely insert the power supply plug as far as it will go.
•Unplug all cables connected to the DPU before moving it.
It is recommended to unplug the power cord from the wall outlet if the DPU is not going to be used for any
prolonged length of time.
Never have management port connected while using management VLAN!
Temperature Warning
If the DPU is installed in an environment where the surrounding temperature is 70 oC (158 oF) or more,
the coax connectors can reach a temperature of more than 85 oC (185 oF). In this case the coax connectors
must not be covered or in contact with combustible materials due to the risk of fire.
Installation Environment
Install the DPU in a site free from strong electromagnetic field generators (such as motors), vibration, dust, and
direct exposure to sunlight.
Install the DPU in a cool and dry place for the acceptable temperature and humidity operating ranges.
See section 6 on page 12 for the actual temperature ranges.
Install the DPU on a sturdy, level surface that can support at least 5 kg (11 lbs) of weight. Leave at least 10 cm
(4 inches) of space at the front for the coax cable F-connectors.
Make sure that there are no insulating materials that can cover the DPU by accident.
Please also make sure that there are no corrosive liquids or materials that can emit any corrosive gases in the
same room as the DPU.

InCoax DPU – Hardware User Manual
7
Storage Environment
The ideal storage location is a dry and well-ventilated location, e.g. in a space with climate-control. Please refer
to section 6 on page 12 for more details about the specified environmental storage conditions.
Theft and Vandalism
Depending on the circumstances for the installation it may be appropriate to mount the equipment (i.e.
the DPU, Diplexersand Switches) in a cabinet that can be locked securely.

InCoax DPU – Hardware User Manual
8
1Abbreviations and Definitions
1.1 Abbreviations
The abbreviations that are used in this document are defined in Table 1.
Table 1— Abbreviations
Abbreviation
Description
CATV Cable TV.
CE CE marking is a certification mark that indicates conformity with health, safety, and
environmental protection standards for products sold within the European Economic Area.
CPE Customer-Premises Equipment or Customer-Provided Equipment.
C-VLAN Customer VLAN is the VLAN that the customer uses or sees (the inner tag). C-VLAN is the VLAN
tag the customer is using on their own devices. (See QinQ.)
DHCP Dynamic Host Configuration Protocol is an automatic configuration protocol used to
automatically assign IP addresses to devices on a TCP/IP network.
DPU Data Processing Unit; often referred to as an Access Node or Control Unit.
EMC Electro Magnetic Compatibility.
FCC
The Federal Communications Commission is an independent agency of the United States
government created by statute to regulate interstate communications by radio, television, wire,
satellite, and cable.
IGMP Internet Group Management Protocol is a protocol used to establish multicast group
membership.
MAC Address
Media Access Control address is a unique identifier assigned to a Network Interface DPU (NIC)
for communications at the data link layer of a network segment. MAC addresses are used as a
network address for most IEEE 802 network technologies, including Ethernet, Wi-Fi, and
Bluetooth.
MGMT Denotes the Management port on the DPU.
OFDM Orthogonal Frequency-Division Multiplexing is a method of encoding digital data on multiple
carrier frequencies.
PA Power amplifier
PHY Physical Layer of the OSI model.
PPPoE Point-to-Point Protocol over Ethernet is a network protocol for encapsulating PPP frames inside
Ethernet frames.
PON Passive Optical Network with its variants XGS-PON, GPON and EPON.
QAM
Quadrature Amplitude Modulation is the name of a family of digital modulation methods and a
related family of analog modulation methods widely used in modern telecommunications to
transmit information.
QinQ
An Ethernet networking standard informally known as QinQ, was incorporated into the base
IEEE 802.1Q standard in 2011. The IEEE 802.1Q technology improves the utilization of VLANs by
adding another IEEE 802.1Q tag to tagged packets. (See C-VLAN and S-VLAN.) See reference {a}.
QoS Quality of Service is the ability to provide different priority to different applications, users, or
data flows, or to guarantee a certain level of performance to a data flow.
QPSK Quadrature Phase-Shift Keying.
RPF
Reverse power feeding (RPF) is a technology being standardized by ETSI and the Broadband
Forum. It allows sending power from the customer CPE to a distribution point (DP), in order to
power the distribution point unit (DPU).
RoHS Restriction of Hazardous Substances. This is a directive on the restriction of the use of certain
hazardous substances in electrical and electronic equipment. See reference {b}.
SerDes Serializer/Deserializer is a pair of functional blocks commonly used in high-speed
communications to compensate for limited input/output.
SFP/SFP+ Small Form factor Pluggable transceiver. SFP ≤ 1 Gbps and SFP+/Enhanced ≤ 10 Gbps.

InCoax DPU – Hardware User Manual
9
Abbreviation
Description
SOAP Simple Object Access Protocol is a protocol for exchanging structured information.
S-VLAN Service VLAN is the VLAN that the service provider network sees (the outer Q-tag). S-VLAN is the
VLAN the service provider puts the entire customer traffic in. (See QinQ.)
TCP/IP Transmission Control Protocol/Internet Protocol is the architecture for data communication over
networks.
TDD Time Division Duplex is the topology adopted to make communication between two wireless
devices at one frequency but with two different time instants.
TDMA Time-Division Multiple Access is a channel access method for shared-medium networks.
URL Uniform Resource Locator is the address of a resource on the Internet.
UTP Unshielded Twisted Pair.
Web GUI Web Graphical User Interface is a user interface that allows users to interact with in:xtnd
electronic devices through a web page.
WEEE Waste Electrical and Electronic Equipment.
XML eXtensible Markup Language is languages which describe the information.
1.2 Definitions
Table 2 shows the terminology and definitions that are being used in this document.
Table 2— Definitions of the Terminology
Term
Definition
Access Modem
The InCoax Modems is a series of Ethernet over Coax network terminals providing 1 Gbps
Ethernet. The modems communicate with the InCoax D2508 DPU based on the MoCA Access™
2.5 standard. The Access Modems are installed in the subscribers’ premises.
The in:xtnd™ Access A101 is a 1 Gbps Ethernet port Modem.
These devices will be referred to as the Modem in this document.
DPU
The InCoax D2508 is a eight-channel Ethernet over Coax Access Node, capable of 2.5 Gbps on
the RF port supporting up to 4 Modems. The communication with the Modems is based on the
MoCA Access™ 2.5 standard.
This device will be referred to as the DPU in this document.
Customer End user or subscriber of broadband services.
Diplexer
The in:xtnd™ Combine(diplexer) is a series of high-performance bidirectional
frequency combiners, i.e. for combining and splitting frequencies. The
combiners/diplexers are used for connecting one or two MoCA Access broadband
frequency spectrum signals from an in:xtnd™ DPU with Radio/TV frequency
spectrum signals into a single coaxial cable. The bidirectional diplexer also protects
the DPU from receiving RF signal disturbances outside of the MoCA Access broadband
frequency spectrum and should always be installed.
These devices will be referred to as the Diplexer in this document.
Management
System
The InCoax Management System is a Linux-based, advanced element manager with features for
DPU deployment, control, and supervision of the coax link conditions. It includes essential
functions for service provisioning and network management.
This software will be referred to as the Management System in this document.
MoCA Access
The MoCA Access™ 2.5 standard is a point-to-multipoint access technology over coaxial
network. It is designed to co-exist with legacy services such as TV and DOCSIS 3.0/3.1.
The operating frequency range is between 400 MHz and 1675 MHz. See reference {c}.
Trunk The Trunk is the uplink port from the DPU. It uses SFP modules.

InCoax DPU – Hardware User Manual
10
2Package Content
Check that all the accessories and items, as shown in Table 3, are present in the package.
Table 3— Contents of the package.
Product
Item Description
Item picture
MoCA Access DPU D2508
XGS-PON, GPON, EPON and Ethernet
Access Node, capable of 2.5 Gbps (max.
3.2 Gbps aggregated) on each coax RF
port.
Warranty
Warranty coverage, Technical
specification, Disposal & Recycling
document.
Additional Information
Power cord with EU plug, order DPU
with article D2508 EU If Reverse Power Feed
(RPF) is used, the Power
Cord may be disconnec-
ted from power outlet
(if not used for back-up
power). The cord can be
detached from the Power
Supply unit and
disconnected from the
enclosure. Please fill the
Power Input bushing with
the rubber plug.
Power Supply
Power cord with UK plug, order DPU
with article D2508 UK
Power cord with US plug, order DPU
with article D2508 US
.
3Introduction
This document describes some of the features of an InCoax D2508 model. It also includes a technical
specification, as well as information about the regulatory statements and the proper disposal of the
equipment.
This specific model of the DPU provides a throughput of 2.5 Gbps (max. 3.2 Gbps) on each coax port.
3.1 InCoax D2508 MoCA Access DPU System
InCoax™ is a provider of broadband access solutions leveraging existing in-building coaxial cable networks.
The InCoax D2508 MoCA Access DPU System consists of a Persistent Management Agent Aggregator (PMAA) if
NETCONF/YANG communication protocol is used or Automatic Configuration Server (ACS) if Configuration
WLAN Management Protocol (CWMP) is used, hereafter called Management System, which manages the DPUs
installed in, or near, buildings and Modems installed in the customers’ homes. An illustration of the
Management System can be seen in Figure 1.
The Modem is easily connected by the customers without any requirements for customer configuration. This
architecture makes the MoCA Access DPU System very flexible supporting different types of networks.

InCoax DPU – Hardware User Manual
11
Once the DPU has been installed in, or near, the building the only required operation to connect new
customers is to provide them with a Modem.
(Please refer to the InCoax handbook System Design Guidelines for Cable Technicians for guidance).
As soon as the Modem has been connected to the coaxial network, it will automatically be detected and
configured by the DPU through the Management System (if such setup has been enabled in the Management
System).
The typical MoCA Access DPU System consists of distributed Management System Architecture which handles
thousands of DPUs and millions of Modems. If there is a legacy cable-TV service in the building the TV signal
must be combined with the broadband signal using the Diplexer Filter. The Management System is used as a
customer configuration, monitoring, and provisioning tool through a web interface or be accessed by
provisioning system or Operating Support System through NETCONF or TR-069 interface.
Figure 1— Overview of the Management System
3.2 The DPU
The DPU acts as a bridge between the incoming XGS-PON, GPON, EPON or Ethernet access network and
customers’ Ethernet Modem port, using the in-building coaxial network as transport for data traffic to the
Modems. The DPU communicates with all Modems, over dedicated RF bands, in the coaxial network to manage
their individual configuration, enforces traffic, and security policies. It also collects and stores traffic statistics
data from the network.
3.2.1 D2508 Input Power alternatives
The DPU is powered by the AC Power cord connected to the public power grid (100 – 120VAC or 200 –
240VAC). It can also be powered through the coax cable by Reverse Power Feeding (RPF) from a customer
modem. To offer this powering, an InCoax Reverse Powering modem must be used. If Reverse Power Feeding is
to be utilized, only one modem per RF port can be connected. DPU with RPF capabilities is named D2508 RPF or
D2508 RPF ER.
When powered by RPF, the AC power cord can then be detached from the AC outlet. To ensure continuous
power, the AC power cord can still be connected to AC power. AC power will be prioritized when present.

InCoax DPU – Hardware User Manual
12
3.2.2 D2508 ER extended range
The DPU is communicating with the InCoax Access (CPE) modems using RF signals. The standard DPU RF signal
strength is normally sufficient within a common P2P (Point-To-Point/Homerun) coaxial network. If the distance
between the DPU and modem is long or multiple modems are connected to an individual RF-port (P2MP –
Point-To-Multipoint), an ER (Extended Range) DPU version is available. The ER functionality increases the
individual RF output signal strength. To access the ER functionality, the DPU version must be marked InCoax
D2508 ER or InCoax D2508 RPF ER. The ER functionality can be switched off by configuration of the DPU in ER
versions.
4Coaxial Network Use Cases
In general, the D2508 can be used for different coaxial network use cases depending on the used spectrum for
the current TV/DOCSIS services. MoCA Access have five default frequency bands and InCoax has added two
additional frequency bands as presented hereunder:
•Band A-A 400-900 MHz for residential networks with specified spectrum up to 1002 MHz
•Band A-AH 550-850 MHz for hotel networks with specified spectrum up to 862 MHz
•Band A-AS 400-800 MHz co-existence in satellite networks with spectrum up to 2150 MHz
•Band A-B 800-1300 MHz co-existence in TV networks with a spectrum up to 1300 MHz
•Band A-C 1025-1675 MHz co-existence in TV / DOCSIS 3.0 networks with a spectrum up to 1800 MHz
•Band A-D 1125-1675 MHz co-existence in TV / DOCSIS 3.0 networks with a spectrum up to 1800 MHz
•Band A-E 1375-1675 MHz co-existing in TV/DOCSIS 3.1 networks with a spectrum up to 1800 MHz
5DPU Web Interface Access
The DPU can be managed via the management port using a web interface. Please refer to the InCoax document
“Configuration Manual” for a more detailed description of the web interface and how to set up the DPU. See
reference {f}.
5.1 Accessing the DPU Web Interface
Connect a computer with an Ethernet cable to the Management port on the DPU.
For best user experience, InCoax recommends to enable JavaScript.
6Specifications
The electrical, physical, and functional specifications for the D2508 DPU. Please note that the specification may
be subject to change.
Performance
•Based on MoCA Access 2.5 Profile D. See reference {c}
•2.5 Gbps throughput on the MoCA port with 30dB SNR
•3.2 Gbps throughput on the MoCA port with 40dB SNR
•Max 4 Modems
•MoCA Bands: A - A, A - AH, A - AS, A - B, A - C, A - D and A - E
•Frequency range: 400 to 1675 MHz
•RF channel bandwidth: 100 MHz
•Bonded operation supporting 3, 4, or 5 RF channels
•17 dBm maximum output power; automatically adjusted per modem
•Configurable beacon frequency
•Modulation: OFDM, QAM 8, 16, 32, 64, 128, 256, 512, or 1024; BPSK and QPSK
•Multiplexing methods: TDMA/TDD
•Communication: Half-duplex

InCoax DPU – Hardware User Manual
13
Physical
•Northbound fiber SFP+ port inside enclosure
•Multi Source Agreement (MSA) compliant, SerDes – 10 Gbps data rate, SFF-8472 (see reference
•{h}) – Diagnostics interfacea
•Supporting XGS-PON, XG-PON, GPON, EPON and Ethernet
•Management Ethernet port : 10 / 100 / 1000 Mbps, configuration and statistics port
•RJ-45 connector supports type CAT5 UTP (as a minimum)
•Eight coax MoCA ports
•F-female connector - 3/8-UNEF32, 75 Ω
•F-female connector - 3/8-UNEF32, 75 Ω for 56VDC, 0.368A max power feed
Indicators
• Power on, Management, Trunk, Coax Link traffic and alerts
Dimensions
• 326 × 123 × 204 mm (W × H × D)
•Wall mount
Weight
• 7 kg
Environmental
• Outdoor equipment, IP67
• Type 4X enclosure
• Operating temperature: -30 °C to +70 °C
Relative humidity: 20 % to 80 %
Altitude: maximum 2000 m
Dynamic temperature control with cooling redundancy
Abnormal operation conditions alarms
Storage (non-condensing): -40 °C to +70 °C and 5 % to 90 % relative humidity
RoHS and RoHS 2. See reference {b}
UL 94 V-0. See reference {i}
Power
• 100-120VAC, 50/60Hz, 1.2A max
or
• 200-240VAC, 50/60Hz, 0.6A
Power consumption 45 W nominal when PA is activated
Automatic power on after power grid failure
IEEE Standards
• IEEE 802.3 (Ethernet) {k}
•IEEE 802.3u (Fast Ethernet) {m}
•IEEE 802.1p (Priority tags) {g}
•IEEE 802.1q (VLAN with full VLAN-ID range. Up to 200 VLAN Configurable internal VLAN for policing,
shaping and prioritization for ingress untagged frames) {a}
•IEEE 802.1ad (QinQ) {j}
aInCoax recommends using the SFP+ module:
Fiber MM: Ubiquiti 10G UF-MM-10G
Fiber SM: InCoax 10G OS-SP96-3110D/ Ubiquiti 10G UF-SM-10G/ Ubiquiti Bi-Di UF-SM-10G-S/ Finisar
FTLX1475D3BTL/ NorthLab NORT-1031-LRT/ FS 10GBASE-BX BiDi SFP+ 1330nm-TX/1270nm-RX 10km DOM
Transceiver Module/
FS 10GBASE-BX BiDi SFP+ 1270nm-TX/1330nm-RX 10km DOM Transceiver Module
Copper: MikroTik 10G S+RJ10/ Ubiquiti 10G UDC-2

InCoax DPU – Hardware User Manual
14
Approvals
• FCC ID 2ATQM1000-0577 {s}
Marking: CE (see section 7.1.2), FCC (see section 7.1.3), IC, TUV SUD NRTL (see section 7.1.4),
UKCA (see section 7.1.5)
EMC: EN55032:2015 Class A, EN55035:2017 {p}, FCC Part 15 B Class A, ICES-003 Class A (see
section 7.1.1)
Safety: IEC62368-1:2014, EN62368-1:2014 {q}+ A11:2017, AS/NZS 62368.1:2018, CSA/UL
62368-1:2014, IEC60950-22:2016
ROHS: ROHS 2.0
Security
•DHCP snooping, Option 82 rewrite and trusted/untrusted clients, limit setting, configurable options
per VLAN
Blocking of unknown CPE
Broadcast storm protection from clients
Support for PPPoE IA option 0x105 Remote ID
Multicast
• IGMP snooping (v2, v3)
IGMP filtering per VLAN
Configurable IGMP timeout
Multicast VLAN Registration
Bandwidth reservation per multicast group
Max. 256 Multicast groups and MAC addresses
QoS
• Traffic classification
Mapping and remarking
Congestion management
Strict priority, four separate queues for broadcast, multicast, and unicast
Configurable rate limitation per queue
Configurable upstream/downstream ratio
Management
• IPv4 WEB GUI via https
NETCONF / YANG
CWMP -TR069
MoCA Access MIB and TR-181
Statistics and system/version information
Configuration
Define and assign service profiles
Built in spectrum analyzer
Access through management VLAN or separate management Ethernet port
Remotely upgradable

InCoax DPU – Hardware User Manual
15
7Legal Information
7.1 Regulatory Notice and Statement (Class A)
Model List:
InCoax D2508 EU
InCoax D2508 UK
InCoax D2508 US
InCoax D2508 ER EU
InCoax D2508 ER UK
InCoax D2508 ER US
InCoax D2508 RPF EU
InCoax D2508 RPF UK
InCoax D2508 RPF US
InCoax D2508 RPF ER EU
InCoax D2508 RPF ER UK
InCoax D2508 RPF ER US
7.1.1 Canada
The following information applies if the product is used within the Canada area.
Industry Canada ICES Statement
CAN ICES-003 Class A. See reference
{r} WEEE Directive 2012/19/EU - This is the European Community Directive on Waste Electrical and Electronic
Equipment (WEEE) which, together with the RoHS Directive 2011/65/EU, became European Law in February
2003.
ec.europa.eu/environment/waste/weee/index_en.htm
and
eur-lex.europa.eu/legal-content/EN/TXT/?uri=CELEX:32012L0019
{s} Battery Directive 2013/56/EU - This is an amendment to the Directive 2006/66/EC of the European Parliament and of
the Council of 6 September 2006 on batteries, accumulators, waste batteries, and accumulators.
https://eur-lex.europa.eu/legal-content/EN/TXT/?uri=celex%3A32013L0056
7.1.2 European Union
The following information applies if the product is used within the European Union.
CE EMC Statement
Warning: This equipment is compliant with Class A of EN 55032. In a residential environment this equipment
may cause radio interference. See reference {n}.
7.1.3 United States of America
FCC Part 15 B Class A
The following information applies if the product is used within the USA area.
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to
part 15 of the FCC Rules. See reference {s}. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful interference to radio communications.

InCoax DPU – Hardware User Manual
16
Operation of this equipment in a residential area is likely to cause harmful interference in which case the user
will be required to correct the interference at the user's own expense.
Caution: Changes or modifications not expressly approved by the party responsible for the compliance could
void the user’s authority to operate the equipment.
7.1.4 TUV SUD NRTL
This equipment is compliant with the UL62368-1, CAN/CSA-C22.2 NO. 62368-standard.
TÜV SÜD is an OSHA recognized Nationally Recognized Test Laboratory (NRTL), a Certified Body
and Inspection Body with SCC (Standards Council of Canada), an accredited EMC Testing laboratory
with A2LA, and many others. TÜV SÜD is authorized by OSHA (Occupational Safety & Health
Administration) as a NRTL capable of performing product safety testing to UL/ANSI Standards.
7.1.5 Great Britain
The UKCA (UK Conformity Assessed) product marking is used for goods being placed on the market
in Great Britain (England, Wales and Scotland). The UKCA marking alone cannot be used for goods
placed on the Northern Ireland market, which require the CE marking or UKCA marking.
It corresponds to the EU CE marking and covers most goods which previously required the CE marking.
UKCA (CE) EMC Statement
Warning: This equipment is compliant with Class A of EN 55032. In a residential environment this equipment
may cause radio interference. See reference {n}.
8Disposal of Equipment
8.1 Waste Electrical and Electronic Equipment
The Waste Electrical and Electronic Equipment Directive (WEEE Directive) is the European Community Directive
2002/96/EC on waste electrical and electronic equipment which, together with the Restriction of Hazardous
Substances Directive (RoHS Directive) 2002/95/EC (also known as RoHS 1) became European Law in February
2003. The WEEE Directive was amended into the Directive 2012/19/EU and the RoHS 1 has been evolved into
the RoHS 2 Directive 2011/65/EU. See references Error! Reference source not found.}and {b}, respectively.
The symbol adopted by the European Council to represent WEEE comprises of a crossed-out wheelie
bin. The black rectangle below the wheelie bin indicates that the product has been placed on the
market after 2005, when the WEEE Directive came into force. The symbol shall be placed on the
products, packaging, and/or accompanying documents. It means that used electrical and electronic
products and batteries should not be mixed with general household waste but taken to a designated
collection site as indicated by the local authorities. In accordance with national legislation and the
WEEE Directives 2002/96/EC and 2012/19/EU, and the Battery Directive 2006/66/EC amended by
2013/56/EU. See reference Error! Reference source not found.}.
For more information about collection and recycling of old products and batteries, please contact the local
municipality, the local waste disposal service, or the point of sale where the item was purchased. Penalties may
be applicable for incorrect disposal of this waste, in accordance with national legislation.
8.2 For Business Users in the European Union
Please contact the dealer or supplier for further information to discard electrical and electronic equipment.

InCoax DPU – Hardware User Manual
17
8.3 Disposal in Countries Outside the European Union
The symbol has only validity in the European Union. Please contact the local authorities or dealer and ask for
the correct method of disposal.
8.4 Battery Symbol
The WEEE symbol can be supplemented with one or more chemical symbols to indicate what kind of battery is
used in the product. The chemical symbols will then be placed under the black rectangle.
9References
{a} IEEE 802.1Q - The IEEE Standard for Local and Metropolitan Area Networks—Bridges and Bridged Networks.
standards.ieee.org/standard/802_1Q-2018
{b} RoHS 2 Directive 2011/65/EU - This is a directive on the restriction of the use of certain hazardous substances in
electrical and electronic equipment.
ec.europa.eu/environment/waste/rohs_eee
{c} MoCA Access™ 2.5 standard.
mocalliance.org
{d} EN 60728 - The Cable networks for television signals, sound signals and interactive services.
ec.europa.eu/standards/iec-60728
{e} EN 50083-1 - Cabled Distribution Systems for Television, Sound and Interactive Multimedia Signals
Part 1: Safety Requirements.
standards.globalspec.com/std/178814/EN50083-1
{f} InCoax D2508 Software User Manual - A detailed description of the web interface and the setup of the DPU.
{g} IEEE 802.1p refers to a specification for giving Layer 2 switches the ability to prioritize traffic as well as perform dynamic
multicast filtering. Basically, it provides a mechanism for implementing Quality of Service at the MAC (Media Access Level)
level. Quality of Service is a mechanism that allows for better handling of data that passes through the network.
{h} SFF-8472 standard - Specification for Management Interface for SFP+
members.snia.org
{i} UL 94 - This is a standard for tests for flammability of plastic materials for parts in devices and appliances; Underwriters
Laboratories.
V-0 - burning stops within 10 seconds on a vertical specimen; drips of particles allowed as long as they are not inflamed.
standardscatalog.ul.com/standards/en/standard_94_6
{j} IEEE 802.1ad - This was an Ethernet networking standard informally known as “QinQ” and was an amendment to the
standard IEEE 802.1Q-1998. The IEEE 802.1ad was incorporated into the base standard IEEE 802.1Q in 2011.
{k} IEEE 802.3 - This is a working group and a collection of IEEE standards produced by the working group defining the
physical layer and data link layer's media access control (MAC) of wired Ethernet.
standards.ieee.org/standard/802_3-2018
{l} IEEE 802.3ac - IEEE Standard for Information technology - Telecommunications and information exchange between
systems - Local and metropolitan area networks - Specific requirements Part 3: Carrier sense multiple access with collision
detection (CSMA/CD) frame extensions for Virtual Bridged Local Area Networks (VLAN) tagging on IEEE 802.3 networks.
standards.ieee.org/standard/802_3ac-1998
{m} IEEE 802.3u - IEEE Standards for Local and Metropolitan Area Networks: Supplement - Media Access Control (MAC)
Parameters, Physical Layer, Medium Attachment Units, and Repeater for 100Mb/s Operation, Type 100BASE-T (Clauses 21-
30).
standards.ieee.org/standard/802_3u-1995
{n} FCC Class A part 15 of the FCC Rules
ecfr.gov/...47.1.15&rgn=div5#sp47.1.15.b
{o} EN 55035:2017 - Radio equipment Directive (2014/53/EU) - Electromagnetic compatibility of multimedia equipment -
Immunity requirements CISPR 35:2016 (Modified).
ce-marking.help/directive/radio-equipment/standard/5/en-550352017#

InCoax DPU – Hardware User Manual
18
{p} EN 62368-1:2014 - Low voltage (LVD) Directive (2014/35/EU) - Audio/video, information and communication
technology equipment - Part 1: Safety requirements.
ce-marking.help/directive/low-voltage-lvd/standard/1639/en-62368-12014
{q} CAN ICES-003 Class A - Information Technology Equipment (Including Digital Apparatus) — Limits and Methods of
Measurement.
ic.gc.ca/eic/site/smt-gst.nsf/eng/sf00020.html
{r} WEEE Directive 2012/19/EU - This is the European Community Directive on Waste Electrical and Electronic Equipment
(WEEE) which, together with the RoHS Directive 2011/65/EU, became European Law in February 2003.
ec.europa.eu/environment/waste/weee/index_en.htm
and
eur-lex.europa.eu/legal-content/EN/TXT/?uri=CELEX:32012L0019
{s} Battery Directive 2013/56/EU - This is an amendment to the Directive 2006/66/EC of the European Parliament and of
the Council of 6 September 2006 on batteries, accumulators, waste batteries, and accumulators.
https://eur-lex.europa.eu/legal-content/EN/TXT/?uri=celex%3A32013L0056

InCoax DPU – Hardware User Manual
19

InCoax DPU – Hardware User Manual
20
InCoax Networks Europe AB
Utmarksvägen 4
SE-802 91 Gävle
Sweden
[email protected]
Revision 2.2
