Indesit INC 871 User manual

Instructions for use
EN
DE Gebrauchsanweisung
FR Mode d’emploi
IT Istruzioni per l'uso

ENGLISH Instructions for use Page 4
DEUTSCH Gebrauchsanweisung Seite 26
FRANÇAIS Mode d’emploi Page 48
ITALIANO Istruzioni per l’uso Pagina 70

4
SAFETY INSTRUCTIONS IMPORTANT TO BE READ
AND OBSERVED
Before using the appliance, read
these safety instructions. Keep
them nearby for future reference.
These instructions and the
appliance itself provide important
safety warnings, to be observed at
all times. The manufacturer
declines any liability for failure to
observe these safety instructions,
for inappropriate use of the
appliance or incorrect setting of
controls.
Very young children (0-3 years)
should be kept away from the
appliance. Young children (3-8
years) should be kept away from
the appliance unless continuously
supervised. Children from 8 years
old and above and persons with
reduced physical, sensory or
mental capabilities or lack of
experience and knowledge can
use this appliance only if they are
supervised or have been given
instructions on safe use and
understand the hazards involved.
Children must not play with the
appliance. Cleaning and user
maintenance must not be carried
out by children without
supervision.
Children aged from 3 to 8 years
are allowed to load and unload
refrigerating appliances.
PERMITTED USE
CAUTION: The appliance is not
intended to be operated by means
of an external switching device,
such as a timer, or separate remote
controlled system.
This appliance is intended to be
used in household and similar
applications such as: sta kitchen
areas in shops, oces and other
working environments; farm
houses; by clients in hotels, motels,
bed & breakfast and other
residential environments.
This appliance is not for
professional use. Do not use the
appliance outdoors.
The bulb used inside the
appliance is specically designed
for domestic appliances and is not
suitable for general room lighting
within the home (EC Regulation
244/2009).
The appliance is designed for
operation in places where the
ambient temperature comes
within the following ranges,
according to the climatic class
given on the rating plate. The
appliance may not work properly
if it is left for a long time at a
temperature outside the specied
range.
Climatic class ambient
temperatures:
SN: From 10°C to 32°C ;
N: From 16°C to 32°C
ST: From 16°C to 38°C ;
T: From 16°C to 43°C .
This appliance does not
contain CFCs. The refrigerant
circuit contains R600a (HC).
Appliances with Isobutane
(R600a):

5
isobutane is a natural gas
without environmental
impact, but is ammable.
Therefore, make sure the
refrigerant circuit pipes are
not damaged, especially
when emptying the
refrigerant circuit.
WARNING: Do not damage the
appliance refrigerant circuit pipes.
WARNING: Keep ventilation
openings, in the appliance
enclosure or in the built-in
structure, clear of obstruction.
WARNING: Do not use
mechanical, electric or chemical
means other than those
recommended by the
Manufacturer to speed up the
defrost process.
WARNING: Do not use or place
electrical devices inside the
appliance compartments if they
are not of the type expressly
authorised by the Manufacturer.
WARNING: Ice makers and/or
water dispensers not directly
connected to the water supply
must be lled with potable water
only.
WARNING: Automatic ice-
makers and/or water dispensers
must be connected to a water
supply that delivers potable water
only, with mains water pressure
between 0.17 and 0.81 MPa (1.7
and 8.1 bar).
Do not store explosive
substances such as aerosol cans
and do not place or use gasoline
or other ammable materials in or
near the appliance.
Do not swallow the contents
(non-toxic) of the ice packs
(provided with some models). Do
not eat ice cubes or ice lollies
immediately after taking them out
of the freezer since they may cause
cold burns.
For products designed to use
an air lter inside an accessible fan
cover, the lter must always be in
position when the refrigerator is in
function.
Do not store glass containers
with liquids in the freezer
compartment since they may
break.
Do not obstruct the fan (if
included) with food items.
After placing the food check that
the door of compartments closes
properly, especially the freezer
door.
Damaged gaskets must be
replaced as soon as possible.
Use the refrigerator
compartment only for storing
fresh food and the freezer
compartment only for storing
frozen food, freezing fresh food
and making ice cubes.
Avoid storing unwrapped food
in direct contact with internal
surfaces of the refrigerator or
freezer compartments.
Appliances could have special
compartments (Fresh Food
Compartment, Zero Degree
Box,...).
Unless dierently specied in the
specic booklet of product, they
can be removed, maintaining
equivalent performances.

6
C-Pentane is used as blowing
agent in the insulation foam
and it is a ammable gas.
The most appropriate
compartments of the appliance
where specic types of food are to
be stored, taking into account
dierent temperature distribution
in dierent compartments in the
appliance, are as follows:
- Refrigerator compartment:
1) Upper area of the refrigerator
compartment&door-temperature
zone: Store tropical fruit, cans,
drinks, eggs, sauces, pickles,
butter, jam
2) Middle area of the refrigerator
compartment - cool zone: Store
cheese, milk, dairy food, deli food,
yoghurt
3) Lower area of the refrigerator
compartment - coldest zone: Store
cold cuts, desserts, meat and sh,
cheesecake, fresh pasta, sour
cream, pesto/salsa, home-cooked
food, pastry cream, pudding and
cream cheese
4) Fruit & vegetable drawer at the
bottom of the refrigerator
compartment: Store vegetables
and fruits (excluding tropical fruits)
5) Chiller compartment: Only store
meat and sh in the coldest drawer
- Freezer compartment:
4 star zone (****) compartment is
suitable for freezing foodstus
from ambient temperature and for
storing frozen food as the
temperature is evenly distributed
throughout the entire
compartment.
Purchased frozen food has the
storage expiration date stated on
the packaging. This date takes into
account the type of food being
stored and therefore this date
should be respected. Fresh food
should be stored for the following
time periods: 1-3 months for
cheese, shellsh, ice cream, ham/
sausage, milk, fresh liquids; 4
months for steak or chops (beef,
lamb, pork); 6 months for butter or
margarine, poultry (chicken,
turkey); 8-12 months for fruits
(except citrus), roast meat (beef,
pork, lamb), vegetables. Expiration
dates on the packaging of foods in
the 2-star zone must be respected.
To avoid food contamination,
please observe the following:
– Opening the door for long
periods can cause a signicant
increase of the temperature in the
compartments of the appliance.
– Regularly clean surfaces that
may come into contact with food
and accessible drainage systems.
– Clean water tanks if they have
not been used for 48 h; ush the
water system connected to a
water supply if water has not been
drawn for 5 days.
– Store raw meat and sh in
suitable containers in the
refrigerator, so that it does not
come into contact with or drip
onto other food.
– Two-star frozen food
compartments are suitable for
storing pre-frozen food, storing or
making ice cream and ice cubes.
– Do not freeze fresh food in one,
two or three-star compartments.

7
– If the refrigerating appliance is
left empty for long periods, switch
o, defrost, clean, dry, and leave
the door open to prevent mould
developing inside the appliance.
INSTALLATION
The appliance must be handled
and installed by two or more
persons - risk of injury. Use
protective gloves to unpack and
install - risk of cuts.
Installation, including water
supply (if any), electrical
connections and repairs must be
carried out by a qualied
technician. Do not repair or replace
any part of the appliance unless
specically stated in the user
manual. Keep children away from
the installation site. After
unpacking the appliance, make
sure that it has not been damaged
during transport. In the event of
problems, contact the dealer or
your nearest After-sales Service.
Once installed, packaging waste
(plastic, styrofoam parts etc.) must
be stored out of reach of children
- risk of suocation. The appliance
must be disconnected from the
power supply before any
installation operation - risk of
electrical shock.
During installation, make sure the
appliance does not damage the
power cable - risk of re or
electrical shock. Only activate the
appliance when the installation
has been completed.
Be careful not to damage the
oors (e.g. parquet) when moving
the appliance. Install the appliance
on a oor or support strong
enough to take its weight and in a
place suitable for its size and use.
Make sure the appliance is not
near a heat source and that the
four feet are stable and resting on
the oor, adjusting them as
required, and check that the
appliance is perfectly level using a
spirit level. Wait at least two hours
before switching the appliance on,
to ensure that the refrigerant
circuit is fully ecient.
WARNING: When positioning
the appliance, ensure the supply
cord is not trapped or damaged.
WARNING: To avoid a hazard
due to instability, positioning or
xing of the appliance must be
done in accordance with the
manufacturer instructions.
It's forbidden to place the
refrigerator in such way that the
metal hose of gas stove, metal gas
or water pipes, or electrical wires
are in contact with the refrigerator
back wall (condenser coil).
All dimensions and spacing
needed for installation of the
appliance are in the Installation
Instruction booklet.
Please remove the power cord
from condenser hook during
installation before connecting
product to power supply.
ELECTRICAL WARNINGS
It must be possible to
disconnect the appliance from the
power supply by unplugging it if
plug is accessible, or by a multi-
pole switch installed upstream of
the socket in accordance with the

8
wiring rules and the appliance
must be earthed in conformity
with national electrical safety
standards.
Do not use extension leads,
multiple sockets or adapters. The
electrical components must not
be accessible to the user after
installation. Do not use the
appliance when you are wet or
barefoot.
Do not operate this appliance if it
has a damaged power cable or
plug, if it is not working properly,
or if it has been damaged or
dropped.
If the supply cord is damaged, it
must be replaced with an identical
one by the manufacturer, its
service agent or similarly qualied
persons in order to avoid a hazard
- risk of electrical shock.
WARNING: Do not locate
multiple portable socket-outlets
or portable power supplies at the
rear of the appliance.
CLEANING AND MAINTENANCE
WARNING: Ensure that the
appliance is switched o and
disconnected from the power
supply before performing any
maintenance operation. To avoid
risk of personal injury use
protectivegloves(riskoflaceration)
andsafety shoes (riskof contusion);
be sure to handle by two persons
(reduce load); never use steam
cleaning equipment (risk ofelectric
shock).
Non-professional repairs not
authorised by the manufacturer
could result in a risk to health and
safety, for which the manufacturer
cannot be held liable. Any defect
or damage caused from non-
professional repairs or
maintenance will not be covered
by the guarantee, the terms of
which are outlined in the
document delivered with the unit.
Do not use abrasive or harsh
cleaners such as window sprays,
scouring cleansers, ammable
uids, cleaning waxes,
concentrateddetergents,bleaches
or cleansers containing petroleum
products on plastic parts, interior
and door liners or gaskets. Do not
use paper towels, scouring pads,
or other harsh cleaning tools.
DISPOSAL OF PACKAGING
MATERIALS
The packaging material is 100% recyclable and is
marked with the recycle symbol . The various
parts of the packaging must therefore be
disposed of responsibly and in full compliance
with local authority regulations governing
waste disposal.
DISPOSAL OF HOUSEHOLD
APPLIANCES
This appliance is manufactured with recyclable
or reusable materials.
Dispose of it in accordance with local waste
disposal regulations.
For further information on the treatment,
recovery and recycling of household electrical
appliances, contact your local authority, the
collection service for household waste or the
store where you purchased the appliance.
This appliance is marked in compliance with
European Directive 2012/19/EU, Waste Electrical
and Electronic Equipment (WEEE) and with
the Waste Electrical and Electronic Equipment
regulations 2013 (as amended). By ensuring
this product is disposed of correctly, you will
help prevent negative consequences for the
environment and human health.

9
The symbol on the product or on the
accompanying documentation indicates that
it should not be treated as domestic waste but
must be taken to an appropriate collection
center for the recycling of electrical and
electronic equipment.
ENERGY SAVING TIPS
To guarantee adequate ventilation follow
installation instructions.
Insucient ventilation at the back of the product
increases energy consumption and decreases
cooling eciency.
Frequent door opening might cause an increase
in Energy Consumption.
The internal temperature of the appliance and
the Energy Consumption may be aected also
by the ambient temperature, as well as location
of the appliance. Temperature setting should
take into consideration these factors. Reduce
door opening to minimum.
When thawing frozen food, place it in the
refrigerator. The low temperature of the frozen
products cools the food in the refrigerator.
Allow warm food and drinks to cool down
before placing in the appliance.
Positioning of the shelves in the refrigerator has
no impact on the ecient usage of energy. Food
should be placed on the shelves in such way to
ensure proper air circulation (food should not
touch each other and distance between food
and rear wall should be kept).
You can increase storage capacity of frozen food
by removing baskets and, if present, Stop Frost
shelf.
Do not worry about noises coming from the
compressor which are normal operation noises.
This product contains a light source of energy
eciency class F.

10
Thermostat setting
• TThe thermostat automatically
regulates the inside temperature
of the refrigerator compartment
and freezer compartment. By
rotating the knob from position 1.
to 5., colder temperatures can be
obtained.
• The “ •“ position shows thermostat is closed and no cooling will take place.
• For short-term storage of food in the freezer compartment, you can set the knob between
minimum and medium positions (1-3).
• For long-term storage of food in the freezer compartment, you can set knob to the
• medium position (3-4).
Note that: The ambient temperature, temperature of the freshly stored food and how often the
door is opened, affects the temperature in the refrigerator compartment. If required, change the
temperature setting.
• When you first switch on the appliance, leave the appliance running continuously for 24 hours in
order to reach operating temperature.
• During this time, try to limit the number of times that the door is opened and do not store a large
quantity of food in the appliance.
• If the unit is switched off or unplugged, you must allow at least 5 minutes before restarting or
plugging the unit in. This avoids damage to the compressor.
• The freezer of the refrigerator can cool up to -18°C .
• This appliance is designed for use at an ambient temperature within the 16°C - 32°C range.
Super switch (If super switch is available)
• Normally set this switch to ‘0’ position. Except when the ambient temperature is low like in
winter. (ie.below 16°C) or when the freezer temperature
needs to be maintained lower. In that case, turn the switch
to ‘1’ position ON.
• To set super switch ON that is on the thermostat box, press
the switch down to ‘1’ position. The switch will lit.
• When the freezer compartment is cooled down to sufficient
temperature, or the weather gets hot, turn the super switch
off to save electrical consumption.
• When you first switch on the appliance, for starting a suitable cooling, the appliance should work
24 hours continuously until it cools down to sufficient temperature.
• In this time do not open the door so often and place a lot of food inside the appliance.
If the unit is switched off or unplugged, you must allow at least 5 minutes before restarting or
re-plugged the unit in order not to damage the compressor.
Super freezing: If ambient temperature is more than 16°C, this switch must be used as superfreeze
switch.For maximum freezing capacity, the switch must be turned on 24h before the placing fresh
foods. After placing fresh food in the freezer, 24 hours ON position is generally sufficient. In order to
save energy, please turn off this switch after 24 hours from placing fresh food.
Warnings for Temperature Settings
• The ambient temperature, temperature of the freshly stored food and how often the door
is opened, affects the temperature in the refrigerator compartment. If required,change the
temperature setting.
HOW TO OPERATE THE APPLIANCE

11
• It is not recommended that you operate your fridge in environments colder than 10°C in terms of
its efficiency.
• The thermostat setting should be done by taking into consideration how often the fresh food
and freezer doors are opened and closed, how much food is stored in the refrigerator, and the
environment in which the refrigerator is located.
• Your fridge should be operated up to 24 hours according to the ambient temperature without
interruption after being plugged in to be completely cooled. Do not open doors of your fridge
frequently and do not place much food inside it in this period.
• A 5 minute delaying function is applied to prevent damage to the compressor of your fridge,
when you take the plug off and then plug it on again to operate it or when an energy breakdown
occurs. Your fridge will start to operate normally after 5 minutes.
• Your fridge is designed to operate in the ambient temperature intervals stated in the standards,
according to the climate class stated in the information label. It is not recommended that your
fridge is operated in the environments which are out of the stated temperature intervals in terms
of cooling efficiency.
• This appliance is designed for use at an ambient temperature within the 16°C - 32°C range.
Accessories
“Door Open” Indicator;
• The « Door Open » indicator on the handle shows whether the door has
closed properly or whether it is still open.
• If the indicator is red, the door is still open.
• If the indicator is white, the door is properly closed.
• Observe that the freezer’s door should always be kept closed. This will
prevent food products from defrosting; it will avoid heavy ice and frost build-
up inside the freezer and an unnecessary increase in energy consumption.
Making Ice cubes;
Ice tray ;
• Fill the ice tray with water and place in the freezer compartment.
• After the water has completely turned into ice, you can twist the tray as shown below to remove
the ice cubes.

12
Refrigerator Compartment
The refrigerator compartment is used for storing fresh food for few days.
• Do not place food in directly in contact with the rear wall of the refrigerator compartment.
Leave some space around the food to allow air to circulate.
• Do not place hot food or evaporating liquid in the refrigerator.
• Always make sure food is wrapped or stored in closed containers before placing in the
refrigerator.
• To reduce humidity and avoid formation of frost, never place liquids in unsealed containers in the
refrigerator.
• We recommend that you loosely wrap meat and store it on the glass shelf just above the
vegetable bin, where the air is cooler.
• Store fruit and vegetable items loose in the crisper containers.
• To prevent the cold air from escaping, try not to open the door too often and do not leave it
open for a long time.
Freezer Compartment
The freezer compartment is used for freezing fresh food and for storing frozen food for the period of
time indicated on packaging and for making ice cubes.
• When freezing fresh food, wrap and seal the food properly; that is the packaging should be air
tight and shouldn’t leak. Special freezer bags, aluminum foil (heavy grade, if in doubt double
wrap), polythene bags and plastic containers are ideal.
• Do not allow the fresh food to come into contact with the already frozen food.
• Always mark the date and the content on the pack and do not exceed the stated storage time.
• In case of a power failure or malfunction, the freezer compartment will maintain a sufficiently
low temperature for food storage. However, avoid opening the freezer door to slow down the
temperature rise within the freezer compartment.
• The maximum amount of fresh food that can be stored in the freezer within 24 hours is indicated
on the name plate (see Freezing Capacity).
• Never place warm food in the freezer compartment.
• When purchasing and storing frozen food products, ensure that the packaging is not damaged.
• The storage time and the recommended temperature for storing frozen food is indicated on
the packaging. For storing and using, follow the manufacturer’s instructions. If no information is
provided, food should not be stored for more than 3 months.
• Place frozen food in the freezer compartment as soon as possible after buying it.
• Once the food has thawed, it must not be refrozen. You must cook it as quickly as possible. In
order to consume or to freeze once again.
FOOD STORAGE IN THE APPLIANCE

13
• Disconnect the unit from the power supply before cleaning.
• Do not wash your Fridge Freezer by pouring water on it.
• Make sure that no water enters the lamp housing and other electrical components.
• The refrigerator should be cleaned periodically using a solution of bicarbonate of soda and
lukewarm water.
• Clean the accessories separately with soap and water Do not clean them in the dishwasher.
• Do not use abrasive products, detergents or soaps. After washing, rinse with clean water and dry
carefully. When you have finished cleaning, reconnect the plugto the mains supply with dry hands.
• Clean the condenser with a broom at least twice a year. This will help you to save on energy
costs and increase productivity.
THE POWER SUPPLY MUST BE DISCONNECTED.
Defrosting the Refrigerator Compartment:
• Defrosting occurs automatically in
refrigerator compartment during
operation; the defrost water is collected
by the evaporating tray and evaporates
automatically.
• The evaporating tray and the defrost water
drain hole should be cleaned periodically with defrost drain plug to prevent the water from
collecting on the bottom of the refrigerator instead of flowing out.
• You can also pour ½ glass of the water to drain hole to clean inside.
Defrosting the Freezer Compartment:
WARNING: Never use sharp metal tools, unless recommended by manufacturer, for this operation
as they can damage the refrigeration circuit.
After a period of time, frost will build up in certain areas in the freezer compartment. The frost,
accumulated in the freezer compartment, should be removed periodically (use the plastic scraper if
available).
Complete defrosting will become necessary if the frost layer exceeds 3-5 mm to maintain the
efficiency of the freezer.
• The day before you defrost, set the thermostat dial to position “5” to freeze the foods
completely.
• During defrosting, frozen foods should be wrapped in several layers of paper and kept in a cool
place. The inevitable rise in temperature will shorten their storage life. Remember to use these
foods within a relatively short period of time.
• Set the thermostat knob to position “•” and switch off the appliance.
• Leave the door open to accelerate defrosting. Remove the defrost water from the compartment.
• Clean the interior by hand with lukewarm water and a little detergent.
Never use abrasive products or aggressive cleaning agents.
• Dry the inside of the unit, plug on the mains, and set the thermostat knob to position “5”. After
24 hours, reset the thermostat to the desired position.
Replacing the light bulb
CLEANING AND MAINTENANCE

14
When replacing the bulb of the fridge;
1. Unplug the unit from the power supply,
2. Press the hooks on the sides of the light cover top
and remove the light cover
3. Change the present light bulb with a new one of not
more than 15 W.
4. Replace the light cover and after waiting 5 minutes
plug the unit.
Replacing LED Lighting
If your fridge has LED lighting contact the help desk as this should be changed by authorized
personnel only.
Transportation and Changing of Installation Position
• The original packages and foamed polystyrene (PS) can be retained if required.
• During transportation, the appliance should be secured with a wide string or a strong rope. The
instructions written on the corrugated box must be followed while transporting.
• Before transporting or changing the installation position, all the moving objects
(ie,shelves,crisper…) should be taken out or fixed with bands in order to prevent them from
getting damaged.
TRANSPORTATION AND CHANGING OF
INSTALLATION POSITION
If your refrigerator is not working properly, it may be a minor problem, therefore check the
following.
The appliance does not operate,
Check if:
• There is a power failure,
• The mains plug is not plugged in properly, or is loose
• The thermostat setting is on position “•”,
• The socket is defective. To check this, plug in another appliance that you know is working into
the same socket.
The appliance performs poorly,
Check if:
• You have overloaded the appliance,
• The doors are not closed properly,
• There are not enough ventilation ducts on the kitchen unit as mentioned in the Installation
Manual.
If there is noise:
The cooling gas which circulates in the refrigerator circuit may make a slight noise (bubbling sound)
even when the compressor is not running. Do not worry, this is quite normal. If you hear a different
sound,
check if:
• The appliance is installed firmly as described in the Installation Manual.
• The objects on the appliance are vibrating.
BEFORE CALLING YOUR AFTER SALES
SERVICE

15
If there is water in the lower part of the refrigerator,
Check if:
• TThe drain hole for the water is not clogged (use the defrost drain plug to clean the drain hole).
• If your fridge is not cooling sufficiently:
• Your fridge is designed to operate in the ambient temperature intervals stated in the standards,
according to the climate class stated on the information label. We do not recommend operating
your fridge out of stated temperatures value limits. This will reduce the cooling efficiency of the
fridge.
Recommendations
• Unplug the refrigerator during a power cut in order to prevent any damage to the compressor.
Wait 5-10 minutes before plugging the appliance in once power returns.
• If you unplug your refrigerator for any reason, wait al least 5 minutes before plugging it in. This
will avoid damage to the refrigerator’s components.
• The cooling unit of your refrigerator is hidden at the rear of the appliance. Therefore, water
droplets or icing may occur on the rear surface of your fridge due to the operation of the
compressor at specified intervals. This is normal, there is no need to perform a defrosting
operation unless the icing is excessive.
• If you do not intend to use your fridge for a long period of time (e.g. in summer holidays), put
the thermostat to “•” position. After defrosting, clean your fridge and leave the door open to
prevent humidity and smells.
• If a problem persists after you have followed all the instructions above, please consult the nearest
Authorised Service Centre.
• The appliance you have purchased is designed for domestic use and can only be used for the
stated purposes. It is not suitable for commercial use. If the consumer uses the appliance in a
way that does not comply with this, we emphasise that the manufacturer and dealer will not be
responsible for any repair or failure within the guarantee period.
Tips for saving energy
1. Install the appliance in a cool, well ventilated room , but not in direct sunlight and not near a heat
source (radiator, cooker.. etc). Otherwise use an insulating plate.
2. Allow warm food and drinks to cool down outside the appliance.
3. W hen thawing frozen food, place it in the refrigerator compartment. The low temperature of
the frozen food will help to cool the refrigerator compartment when it is thawing. This will help
to save energy. If the frozen food is put out, it results in a waste of energy.
4. Cover drinks or other liquids when placing them in the appliance Otherwise humidity increases
in the appliance. Therefore, the working time gets longer. Also covering drinks and other liquids
helps to preserve smell and taste.
5. Try to avoid keeping the doors open for long periods or opening the doors too frequently as
warm air will enter the cabinet and cause the compressor to switch on unnecessarily often.
6. Keep the covers of the different temperature compartments (crisper, chiller ...etc ) closed
7. Door gasket must be clean and pliable. Replace gaskets if worn.

16
THE PARTS OF THE APPLIANCE AND THE
COMPARTMENTS
1. Freezer room and freezer door
2. Ice tray
3. Fridge shelves
4. Crisper cover
5. Crispers
6. Levelling feet
7. Bottle shelf
8. Door middle shelves
9. Egg holder
10. Butter cheese shelf
11. Butter cheese shelf cover
12. Light button
13. Thermostat box
This presentation is only for information about the parts of the appliance.
Parts may vary according to the appliance model.
