Induction Dynamics SW4.iw User manual

SW4.iw
Dual 10” In-Wall Subwoofer

Table of Contents
Introduction
General Information
Check Speaker and Parts
General Care of Your Subwoofer and Amplifier
Bass and Loudness Contour Controls
SW4.iw Location; Multiple Subs Location
Amplifier Location
Speaker Wire
Speaker Information
Subwoofer Design
Installing the SW4.iw With A2 Amplifier
Installing the SW4.iw With A3 Amplifier
SW4.iw Specifications
A2 Subwoofer Specifications
A3 Subwoofer Specifications
Warranty
Contacts
2
3
3
3
3
3
4
4
5
5
6
8
10
11
12
13
1
14

Audio Perfection Realized ™
2
Introduction
Congratulations on your selection of the Induction Dynamics™ SW4.iw dual 10” in-wall
subwoofer. The SW4.iw is a powered subwoofer, requiring the A2 subwoofer amplifier or a
similar design
Built to the highest standards of perfection, the SW4.iw makes an excellent addition to any
home theater, but to achieve the highest quality sound, we recommend using it in conjunction
with Induction Dynamics speakers. For a full catalog, contact Induction Dynamics at sales@
inductiondynamics.com or by calling toll free [phone].
WARNINGS:
WARNING! - SHOCK HAZARD
WARNING! - DO NOT OPEN
NO USER-SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED PERSONNEL

3
General Information
Please read these instructions thoroughly before attempting to install and operate the SW4.
iw subwoofer.
Check Speaker and Parts
Unpack and carefully check each loudspeaker. If you suspect damage from transit, report
the problem immediately to your dealer and/or delivery service.
If possible, save the shipping cartons for future use. Please ship the foam packing material
to: Induction Dynamics, 10661 René, Lenexa KS 66215.
General Care of Your Loudspeaker and Amplifier
Whenever changing speaker wires, interconnect wires, or power cords, always turn off all
equipment. To prevent fire or shock hazard, do not expose the amplifier to rain or excessive
moisture. To avoid electric shock, do not open the amplifier. There are no user-serviceable
parts inside.
Your subwoofer and amplifier come in a high quality finish that is both attractive and durable.
To clean, use a soft, damp cloth. If your drivers become dusty, dust them with a paintbrush
or a brush vacuum attachment. Do not use a strong or abrasive cleaner.
The grille is covered in acoustic cloth. To keep your grille clear of debris, we recommend
you use a lint roller (like you would use on clothes).
Bass and Loudness Contour Controls
Do not use bass or loudness contour controls. Induction Dynamics’ subwoofers produce
very low frequencies without these controls. Use of these controls will make the bass sound
“boomy”, obscure higher frequencies, and possibly cause damage due to excessive cone
excursion.
SW4.iw Location
The SW4.iw is designed to be built into walls. Since humans do not hear bass frequencies as
directional, placement is flexible, but it is best to locate the subs near the front sound stage.
Where possible, it is generally best to use two subwoofers, each located in a different area of
the room. In addition to improving efficiency and doubling the power handling, using two
subwoofers creates a more even distribution of the low frequencies by reducing peaks and
nulls. Two SW4.iws must be connected in series.

4Audio Perfection Realized ™
Amplifier Location
The A2 amplifier is best located in an equipment rack or shelving with other audio and
video equipment. It is not recommended for placement behind walls or other limited access
locations, where service may be restricted.
Speaker Wire
Use approved wire designed for in-wall or exposed use, as appropriate for your installation.
For the SW4.iw, we recommend using high-quality speaker wire that is 12 gauge or lower,
with easily visible polarity coding to make your connections. The following chart identifies
minimum gauge requirements for various lengths. See your local dealer or installation
contractor for more information.

5
Subwoofer
Information
Subwoofer Design
Non-realistic, “boomy” bass frequencies are so prevalent in the home theater world that
some listeners have never heard a well-tuned subwoofer. The “boom” occurs because every
subwoofer has a natural resonance peak—that is, every subwoofer will naturally produce
a narrow range of low frequencies at a higher volume than the rest. This “boom” drowns
out higher frequencies your subwoofer produces, resulting in diminished performance and
muddy, poor-quality bass.
Induction Dynamics® engineers its subwoofers with high-performance drivers and
specialized filter circuits to eliminate resonance peaks and produce a fuller sound expressing
all bass frequencies.
Most subwoofers do not attempt to reproduce ultra-low frequencies because of the distortion
created by excess excursion. Induction Dynamics eliminates this distortion with a patented
frequency-selective excursion limiter. The excursion limiter allows the subwoofer to produce
ultra-low frequency sound but prevents the driver from overexerting and causing distortion
that could ruin your listening experience; the limiter itself is transparent, operating only at
specific frequencies without audibly switching on and off.

6Audio Perfection Realized ™

7

8Audio Perfection Realized ™

9

10 Audio Perfection Realized ™

11
Installing the SW4.iw
With A2 Amplifier
The A2 is designed to be used with audio/video pre-amplifiers and receivers that have their
own built-in low frequency crossover circuits. These circuits typically have a low pass rolloff
of 12dB/octave or 24 dB/octave. The best crossover frequency setting is usually 60 Hz (12
dB/octave low pass) or 70 Hz (24 db/octave low pass). Ultimately, the crossover frequency
setting is best determined by consulting your own ears.
Connecting the A2 to Your SW4.iw
1. Turn off the power to each piece of equipment before making any connections.
2. Using high-quality interconnect cables with RCA type terminations, connect the
“SUBWOOFER OUT” on the audio/video preamplifier or receiver to “IN” on the A2. If using
a single subwoofer, proceed to step 3; if using two subwoofers, skip step 3 and proceed to
step 4.
3. Using high-quality speaker wire (consult the chart on page 4), connect the black binding
post on the A2 to the black binding post on the SW4.iw subwoofer and connect the red
binding post on the A2 to the red binding post on the SW4.iw subwoofer. Proceed to step 5.
4. If using a single A2 with two subwoofers, the subs must be connected in series. In this
configuration, the two 4-ohm loads will combine to create an 8-ohm load. Connect the red
binding post of the A2 amplifier to the red binding post on the first subwoofer, and the black
binding post on the A2 amplifier to the black binding post on the second subwoofer. Then
connect the black binding post on first subwoofer to the red binding post on the second
subwoofer. Three subwoofer connection methods are shown on the opposite page. Proceed
to step 5.
5. Connect the amplifier to a 120-volt, single phase, 60-Hz, grounded power supply
using the power cord provided. For best results, use a dedicated power circuit for your
amplification equipment.
6. Phase Check: Listen to the subwoofer(s) and higher frequency speakers together. Then,
reverse the speaker wires on the back of the subwoofer (black to red and red to black).
This reverse connection is 180ºout of phase with the normal connection. One of these
two arrangements will sound noticeably louder in the low-frequency range. The louder
arrangement is the proper phase alignment for your installation.

12 Audio Perfection Realized ™
7. Volume Adjustment: The subwoofer volume level may be adjusted by using the control
in the menu of the audio/video preamplifier or receiver. The subwoofer volume level may
be measured using a sound level meter, a real time analyzer, or adjusted by ear. An easy
technique is to set the level just below where it starts to sound “boomy”.

13
SW4.iw Specifications
Type: Powered subwoofer
Driver Control: High-saturation filter circuit to eliminate resonance peaks
Nominal Impedance: 4 Ohms (2.5 minimum)
Frequency Response: 25 - 150 Hz
Sensitivity (2.83 V @ 1M): 81 dB
SPL (1 W / 1 m): 78 dB
Power Handling: 400 W
Magnetic Shielding: No
Drivers: dual 10” laminated cone with rubber surround and 54-
oz. magnet
Binding Posts: Gold-plated; #4 AWG Max
Enclosure: Sealed
Optional Accessories: ST2.SW4.iw dual-post subwoofer stand

14 Audio Perfection Realized ™
A2 Specifications
Type: Class AB Bipolar Subwoofer Amplifier
Driver Control: Patented non-distorting, frequeny-selective excursion
limiter
Frequency Response: 20 Hz - 20 kHz, +/- 0.25 dB
Harmonic Distortion: < 0.078% (@ 1 kHz, 1 Watt)
Voltage Gain (dB) S/N: 36 dB (internally switchable to 26 dB)
Damping Factor: 95 dBA
Input Impedance: 400 Ohms @ 60 Hz
Output Load: 2.5 K Ohms minimum
Power Output
(Continuous)
2.5 Ohms / 4 Ohms /
8 Ohms
700 Watts / 520 Watts / 300 Watts
Inputs: 1 RCA (RCA plus XLR optional)
Output Binding Posts: Gold Plated; #10 AWG max, or Banana Plugs
Power Requirements: 120 V AC, 6A slow-burn fuse
Auto On/Off Auto power down if no signal for 20 minutes (turn-on
sensitivity 2 mV)

15
Warranty
Phone: [phone]
Fax: [phone]
Induction Dynamics, Inc. warrants the SW4.iw subwoofer, A2 amplier, and/or A3 ampli-
er against defects in materials and workmanship for a period of seven years from the
date of original retail purchase. Induction Dynamics, Inc. will repair or replace any
SW4.iw subwoofer, A2 amplier, and/or A3 amplier that does not meet this warranty.
This warranty may be registered by mailing a copy of the retail sales receipt to Induction
Dynamics, Inc. at the address below. Please write the serial number along with the name
and address of the retailer from whom you purchased the speaker(s) and/or amplier(s).
This may be done at the time of purchase or before requesting repair service under this
warranty.
To obtain repair service, call or write to Induction Dynamics, Inc. at the phone number or
address below. You will be given a return authorization number. Please mark this number
clearly on the outside of the package(s) for identication. Packages that are not marked
with a return authorization number on the outside may not be accepted by Induction
Dynamics, Inc. Please pack each SW4.iw subwoofer, A2 amplier, and/or A3 amplier in
a substantial shipping container with plenty of protective foam. If possible, use the origi-
nal shipping container and packing material. For repairs covered by and performed under
this warranty, Induction Dynamics, Inc. will pay for the return shipping charges. This
warranty covers defects in materials and workmanship, and does not cover damage or
failure resulting from accident, misuse, or shipment. The warranty is void if the SW4.iw
subwoofer, A2 amplier, and/or A3 amplier is serviced or altered by anyone other than
Induction Dynamics, Inc. the sole remedy for breach of this warranty shall be repair or
replacement.
Limits and Exclusions: There are no warranties except as mentioned above. Neither
Induction Dynamics, Inc. nor anyone else who has been involved in the creation, pro-
duction, or sale of this product shall be liable for any direct, indirect, consequential or
accidental damages arising out of the use or inability to use this product, or arising out
of breach of this warranty. Induction Dynamics, Inc. makes no other warranties, express
or implied, including without limitation warranties of merchantability or tness for a
particular purpose. There are no warranties that extend beyond the description on the
face hereof.
Induction Dynamics
Customer Service Department
8005 W. 110th St., Suite 208
Overland Park, KS 66210
USA

16
Contacts
If you have any questions, contact Induction Dynamics by phone at 855-663-5600, 8:00
a.m.- 5:00 p.m. CST, fax at 913-663-3200, email at [email protected], or
write to:
Manufacturer Information
Retailer Information
Retailer name (company or individual):
Address:
City:
State:
Zip or Postal code:
Phone:
Email:
Date of purchase:
Serial number:
Induction Dynamics
Customer Service Department
8005 W. 110th St., Suite 208
Overland Park, KS 66210
USA
Note: Please do not ship your loudspeaker for service without obatining prior approval
and return authorization number. See warranty for further information.
To help simplify your record keeping, please ll out the following information about the
retailer you bought your Induction Dynamics products from. Additionally, you may staple,
tape, or glue a copy of your receipt to the next page.

™
8005 W. 110th Street, Suite 208
Overland Park, KS 66210
Tel: [phone]
Fax: [phone]
www.inductiondynamics.com
© Induction Dynamics®, August 2013
