Pinnacle SUBcompact 6 User manual

Pinnacle Speakers owns the copyrights to the content of this literature which includes photographs, descriptive copy,
tradenames, logos, layouts etc.Any unauthorized use of this material is an infringement of our copyrights and we will
protect our copyrights to the fullest extent of the law.
SUBcompact 6
The WThe W
The WThe W
The World’orld’
orld’orld’
orld’
s Smallest Powers Smallest Power
s Smallest Powers Smallest Power
s Smallest Powered Subwoofered Subwoofer
ed Subwoofered Subwoofer
ed Subwoofer
WARNING: DON’T LET THE SIZE FOOL YOU.WARNING: DON’T LET THE SIZE FOOL YOU.
WARNING: DON’T LET THE SIZE FOOL YOU.WARNING: DON’T LET THE SIZE FOOL YOU.
WARNING: DON’T LET THE SIZE FOOL YOU.
THIS TINY SUB PRODUCES GREATHIS TINY SUB PRODUCES GREA
THIS TINY SUB PRODUCES GREATHIS TINY SUB PRODUCES GREA
THIS TINY SUB PRODUCES GREAT BASS!T BASS!
T BASS!T BASS!
T BASS!
Pinnacle engineers did it again! Housed in a cabinet approximately an 8" cube, the
SUBcompact 6SUBcompact 6
SUBcompact 6SUBcompact 6
SUBcompact 6 delivers deep, tight bass response down to 28 Hz in a stylish cabinet sure to please
the most discerning eye. Ideal for apartments, condos, medium and small living areas where the
subwoofer needs to be heard but not seen. The front firing configuration allows for placement in
built-in wall units and other custom situations. For larger living areas, try our more powerful dual
woofer designs, Subsonic or Baby Boomer with dual woofer configurations.
Special Features
SUBcompact 6
•Anti-Clipping Circuit for High Level Undistorted Bass!
•Auto On/Off Circuit with LED Indicator
•Includes High Quality Gold-plated 6' Interconnect Cable for Easy Hook-Up
• Phase & Crossover Bypass Switches
•Includes Non-Skid Rubber Feet for Stability
•Satellite Speaker Crossover: First Order @ 80 Hz
•Line Level Inputs and Speaker Level Inputs & Outputs
•Stylish Rounded Edge Cabinet Design
•Variable Crossover 50-150 Hz
•Volume Control
•2-Year Transferable Warranty on Amplifier
•7-Year Transferable Warranty on Parts & Labor for the Rest of the System
Component DriversComponent Drivers
Component DriversComponent Drivers
Component Drivers: (1) 6.5" Heavyweight Fibercone Woofer with Butyl Surround,
2" Voice Coil and 30 ounce Magnet
Subwoofer Low End Frequency ResponseSubwoofer Low End Frequency Response
Subwoofer Low End Frequency ResponseSubwoofer Low End Frequency Response
Subwoofer Low End Frequency Response: 28 Hz (- 3 dB)
VV
VV
Variable Subwoofer Low Pass Filterariable Subwoofer Low Pass Filter
ariable Subwoofer Low Pass Filterariable Subwoofer Low Pass Filter
ariable Subwoofer Low Pass Filter: 50-150 Hz
Satellite Speaker CrossoverSatellite Speaker Crossover
Satellite Speaker CrossoverSatellite Speaker Crossover
Satellite Speaker Crossover: First Order @ 80 Hz
System PowerSystem Power
System PowerSystem Power
System Power: 200 Watts
DimensionsDimensions
DimensionsDimensions
Dimensions: 7 7/8” Wide x 8” High x 9 3/8" Deep (with Amp & Grille)
FinishFinish
FinishFinish
Finish: Premium Black Vinyl
WeightWeight
WeightWeight
Weight: 16 lbs. each
Only an 8” Cube!Only an 8” Cube!
Only an 8” Cube!Only an 8” Cube!
Only an 8” Cube!
Specifications
