Inepro 275707 User manual
© 2016 Inepro B.V. All rights reserved
Operator Manual | Uninteruptable Power Supply ~
275707
Uninteruptable Power
Supply ~ 275707
Product Version: N / A
Version of this manual: 1.1.0
Functional description of the UPS
Part
I
2 - Uninteruptable Power Supply ~ 275707
Functional description of the UPS
Functional description of the UPS
The UPS powers the PayCon when the net adaptor does not do this any longer.
The UPS consists of:
§2 batteries;
§a switching transistor to connect the power line from the battery to the PayCon;
§a microcontroller controlling the unit
The microcontroller compares the net adaptor’s voltage with a reference voltage. When during a transaction the net
adaptor’s voltage is lower than the reference voltage, than the transistor is being switched on. After finalizing the
transaction, the transistor is switched off.
The connection with the PayCon consists of 3 signals. Two towards and one coming from the PayCon.
Signal
Direction
Indicating
Function
1
Towards the PayCon
Voltage of battery
High signal;
Battery capacity sufficient.
Switching signal (1 Hz);
Battery almost empty, replacement necessary.
No signal;
Battery empty. The PayCon does not start up a
transaction.
2
Towards the PayCon
UPS battery power active
The PayCon finalizes the current transaction. After
that the UPS will be switched off.
3
From the PayCon
Battery power necessary if net adaptor fails
This active signal switches the UPS.
After finalizing the transaction, the PayCon switches
the signal off. The UPS switches the battery off
through the transistor. After that the PayCon is
switched off.
The batteries in the UPS can not be recharged. Empty batteries must be replaced. Use two new (same brand and type).
In test a 75 minutes operational lifespan of both batteries at continuous use on 1 PayCon is measured. Real lifespan
depends on used PayCon configuration.
Note: Batteries are chemical waste and must be disposed of according the applying national and local regulations
Connections
Part
II
4 - Uninteruptable Power Supply ~ 275707
Connections
Connections
Connecting the UPS
Cable
Function
8 wired cable
PayCon control cable
2 wired cable
Power cable to
PayCon
Black wire
Power cable from
net adaptor
Connecting the PayCon
Cable
Function
White / brown
PayCon power from
UPS
Red / blue
Power for UPS (5V).
Can be plugged in any
of the serial connector.
Grey / brown /
Yellow / green
Status signals from UPS
White / pink
Activation
request-signal to UPS
Programming connector and LED
Part
III
6 - Uninteruptable Power Supply ~ 275707
Programming connector and LED
Programming connector and LED
Programming connector
For loading a programme in the microcontroller.
LED
Long signal; power from net adaptor
Short signal; power from batteries
Cables
Part
IV
8 - Uninteruptable Power Supply ~ 275707
Cables
Cables
Power cable between UPS and PayCon
Interface cable between UPS and PayCon
Adjusting the UPS
Part
V
10 - Uninteruptable Power Supply ~ 275707
Adjusting the UPS
Adjusting the UPS
The UPS is shipped fully adjusted.
Requirements for adjusting the UPS
§Controllable power supply
§Load
§PayCon adaptor
§Fluke scope meter
§Software (must be loaded before the UPS can be adjusted.)
Perform the following actions:
§Load the software in the UPS.
§Connect the controllable power supply to the UPS where normally the batteries are placed.
§Connect the load on the JST connector where normally the PayCon is connected.
§Power the net adaptor in a wall socket.
§Set the power supply Voltage on 13.7 Volt.
§Turn the pot meter R18 till the led D11 (right side UPS) switches on.
§Measure with the Fluke scope meter the tension on the load. Turn the Fluke scope meter to trigger
tension 11 Volt. (Time base 20 milliseconds)
§Remove the adaptor from the wall socket and monitor if the tension towards the load does not reach
under the 10 Volt. Adjust the value of R13 till the tension dip stays above the 10 Volt before the UPS
battery takes over the power. (see photo)
After these actions the UPS is adjusted and the preset pots can be sealed. Now load the final UPS software
Test unit India
Part
VI
12 - Uninteruptable Power Supply ~ 275707
Test unit India
Test unit India
§Connect the UPS on the test box.
§Push the start test button.
§Load the UPS with test software.
§Turn pot meter R18 till leds 1 and 2 switch on.
§Turn pot meter R13 till leds 3 and 4 switch on.
§Seal the setting with nail polish.
§Press the print ticket button. (a ticket will be printed)
§Load the UPS with the final software.
§Push the stop button.
§Remove the UPS and place the UPS together with the ticket in an anti static (transport) bag
Version 1.1.0 - 13
