User Manual
Manual
DC UPS
POE4570P
1. Package Contents
You should have received the following items inside of package:
- UPS Unit
- User Manual
- AC power cord
- DC output cable( 2 ends)
2、Product
Introductions of components:
1). ON/OFF Switch
2). Work status indicator
3). 25%-100% BAT capacity LED Indicator from left to right
4). Output socket 5VDC
5). Output socket 12VDC
6). Ethernet output interface(POE output:15V, 24V)
7). AC input socket
8). Output socket 9VDC
9) Output Voltage Selector (15V/24V)
3、Features
1) High capacity lithium battery, provides long backup to the loads.
2) High compatibility, suitable for most digital products in the
market.
3) USB output (5V), can supply charging for digital products like
mobile phone, PDA, PSP, IPOD, MP4...etc.
4) Power Over Ethernet(POE) can transmit the data and power at
the same time to simplify wire set.
5) Intelligent circuit design with over-charging, over discharging and
short circuit protections.
6) Built-in adapter allows wide AC voltage range (100-240Vac).
7) Auto restart

4、High compatibilities
5、How to use
1). In order to prevent over-discharging of the lithium batteries,
please restart the UPS when AC is available after low battery cutoff.
2). Before connecting the loads to the UPS, it’s a must to check their
nominal working voltage, current and polarity which you can find on
there original adapters.
3). The output power of this model is controlled by total power
capacity. The total power of the loads which connect to all the ports
cannot exceed the maximum output power. Otherwise, the USE ports
will be closed, and the light of status will be in yellow flashing. If the
total power of the loads is still exceed the maximum power after the
USB ports are closed, all the output ports will be closed, and all the
lights of power indicator will be flashing. In this situation, please
remove the exceed loads.
4). Press and hold the power key for 2-3 seconds to boot the UPS. If
the output voltage indication light is green, this DC port is outputting
voltage, and the output voltage can be selected between 9Vand 12V
by moving the DC voltage switch. The output voltage of PEC port can
be selected between 15V and 24V by moving the POE voltage switch.
After pluging in the grid, the status light become green for charging,
100% means it’s full charge. In the process of charge, the power
indicator light indicators the capacity of the battery by 25%, 50%,
75% and 100% increasingly. When disconnect the grid, the status
light become red for battery backup status, and the power indicator
light will turn off one by one from 100%, 75%, 50% to 25%. When
the light of 25% is flashing, it means that the battery power is very
slow, then press and hold the power key for 2-3 seconds to turn off
the UPS and stop output voltage.
5). Plug-and-play USB provides stable charging to the digital
products with their original charging cables.
6). UPS shut down automatically when it is low battery, it will restart
with output power when AC recover.
7). If it’s not used for long period, please keep full charge and keep it
in a cool place. If the storage time is too long to turn on, please plug
in the grid for charging till the status light become green. It’s
recommend to charge battery once per month.
6、Specifications
*Products specification are subject to change without notice.
Warning
1. Do check the working voltage, current and polarity of the
loads before connecting them to the UPS, then choose the
corresponding voltage.
2. Please charge fully before initial use.
3. Dropping, hitting, disassembling and repairing privately are
forbidden.
4. Do not put the UPS into water or make it wet.
5. Do not dispose of the UPS in fire or heating it.
6. Do not use the UPS in any flammable environments.
7. Do not put the UPS in any places where Children can reach.
Model
POE6090P
Related working
voltage
100-240Vac/50-60Hz
Output power
(Max.)
60W
Output
DC interface
POE
interface
Output voltage
(selectable)
5Vdc
9Vdc
12Vdc
15Vdc/24Vd
c
Output polarity
+4,5pins-7,8
pins
Output power &
current (in
common)
2.0A/
10W
2.0A/
18W
3.0A/
36W
1A(15V
15W) or
(24V 24W)
Qty.& Capacity of
battery
12V/9AH
Unit
dimension(mm)
101*142*297
Net weight(kg)
3.7
