Emerson SolaHD SDU 500A User manual

SDU AC-A Series
A272-290
Rev. 5 07/2018
Uninterruptible Power Supply

SDU AC-A Series
A272-290 Rev. 5 07/2018
Page: B
What’s Included
The SDU UPS is shipped with the following items:
•User manual
•UPSMON software CD
NOTE: Monitoring/diagnostic software is included on the UPSMON CD. The software is compatible
with Windows XP, 7, 8, 10, Server-2000, 2003, 2008 and Linux.
•PSMON High speed 2.0 Standard Type A-B USB cable, 6 ft (1.8 m)
•One SDUCOMMCVR the SDU AC-A Series communication slot cover.
•One warning label. (Refer to Installation Instructions, Item 6).
Accessories (Optional)
• SDU-PMBRK: Mounting brackets to secure the UPS to the wall, back of the panel or enclosure
• SDUEDC: Side Mount Enhanced DIN Rail Clip
• SDUCFRELAYCARD: Dry contact relay status with LED diagnostics and standby Mode capability
(Please refer to SDU A-Series COMM Cards Manual)
• SDUENETIPCARD: Network communication module is a high performance communication solution for
industrialelddevices.ItisdesignedforusewithhighperformancenetworkssuchasrealtimeEthernet
and synchronized applications such as servo drive systems (Please refer to SDU A-Series COMM Cards
Manual)

SDU AC-A Series
A272-290 Rev. 5 07/2018
Page: C
CONTENTS
1.0 Introduction . . . . . . . . . . . . . . . . . . . . . . 1
2.0 Important Safety Instructions . . . . . . . . . . . . . . 2
3.0 Installation Instructions . . . . . . . . . . . . . . . . . 3
4.0 Specifications . . . . . . . . . . . . . . . . . . . . . . 5
5.0 General Description . . . . . . . . . . . . . . . . . . . 6
6.0 System Block Diagram . . . . . . . . . . . . . . . . . 8
7.0 Operating Instructions . . . . . . . . . . . . . . . . . 9
8.0 Diagnostics . . . . . . . . . . . . . . . . . . . . . . 11
9.0 Battery Back-Up Times . . . . . . . . . . . . . . . . 12
10.0 Software and Interface . . . . . . . . . . . . . . . 13
11.0 Storage . . . . . . . . . . . . . . . . . . . . . . . 14

SDU AC-A Series
A272-290 Rev. 5 07/2018
Page: D
FIGURES
Figure 1: Transition to Back-Up Mode Due to Power Outage . 1
Figure 2: Input/Output Terminals . . . . . . . . . . . . . . 3
Figure 3: Mounting the UPS DIN Rail . . . . . . . . . . . . . 3
Figure 4: Front Panel . . . . . . . . . . . . . . . . . . . . 6
Figure 5: Product Dimensions . . . . . . . . . . . . . . . . 7
Figure 6: SDU A-Series UPS System Block Diagram . . . . . . 8
Figure 7: UPS Control Panel, Configuration . . . . . . . . 10
Figure 8: Connecting UPS to Computer . . . . . . . . . . 13
Figure 9: UPSMON Control Panel, Monitor System . . . . . 13
TABLES
Table 1: Green Mode Setting Table. . . . . . . . . . . . . . 9
Table 2: Diagnostics LED/Alarms. . . . . . . . . . . . . . 11
Table 3: Battery Back-Up Time Chart. . . . . . . . . . . . 12

Page: 1
SDU AC-A Series
A272-290 Rev. 5 07/2018
1.0 Introduction
The SDU AC - A Series is a compact, “Off-Line” DIN rail mountable UPS, which provides conditioned power to
sensitive electronic equipment in an industrial environment. It supplies connected equipment with stepped
approximation to sinewave input during power outage to simulate the power generated by the utility.
Figure 1: Transition to Back-Up Mode Due to Power Outage
AC Mode AC Loss
of Power Battery Mode
Input voltage range is 80% to 110% (ideal protection for the critical connected loads). Battery charging occurs
automatically when ac power is applied, no need to switch ON the UPS. When power fails, the UPS can be
automatically turned OFF, as long as the connected loads are not operating to save the battery energy. The
SDU also includes an automatic self-test feature to test the UPS function and battery. If the battery is no longer
useful, the unit will sound an alarm and an LED indicator will illuminate
This SDU AC - A Series has a communication port that can accommodate an optional communication card.
Contact a SolaHD Technical Support representative for a list of currently available communication cards.

SDU AC-A Series
A272-290 Rev. 5 07/2018
Page: 2
2.0 Important Safety Instructions
2.1 Safety Precautions—SAVE THESE INSTRUCTIONS
This manual contains important safety instructions that should be followed during the installation of
the Uninterruptible Power Supply (UPS). Please read all safety, installation, and operating instructions
before attempting to install or operate the UPS. Follow all warnings on the unit and in this manual
during installation and operation.
• Topreventtheriskofreorelectricshock,installtheUPSinatemperatureandhumiditycontrolled
ventilatedenclosure,freeofconductivecontaminants,moisture,flammableliquids,gases,andcorrosive
substances.
• To reduce the risk of electric shock, do not remove the cover, as it has no user-serviceable parts inside.
Somecomponentsarelive,evenwhenacpowerisdisconnected.Forservice,contactaqualied
technician.
• Although your UPS has been designed and manufactured to assure personal safety, improper use can
resultinelectricalshockorre.Toensuresafety,pleaseobservethefollowingrules:
• Turn OFF UPS and disconnect the ac supply before cleaning. Do not use liquid or aerosol cleaners.
A dry cloth is recommended to remove dust from the surface of your UPS.
• Do not install or operate the UPS in or near water.
• Do not place the UPS on an unstable cart, stand, or table.
• Do not place the UPS under direct sunlight or close to heat-emitting sources.
• To allow proper ventilation of the UPS, do not block or cover the top and bottom sides of the unit.
Do not insert any objects into the ventilation holes or other openings of the UPS. Keep all vents free of
dustaccumulationthatcouldrestrictairflow.
• Donotdisposeofbatteriesinare;theymayexplode.Donotopenordamagethebattery.Released
electrolyte is harmful to the skin and eyes and may be toxic.
• This equipment is suitable for use in Class I, Division 2, Groups A, B, C, D, T3. When installed in a
hazardous location, adhere to the following:
!WARNING
• EXPLOSION HAZARD - Do not disconnect equipment unless power has been removed or the area is known
to be non-hazardous.
• EXPLOSION HAZARD - Batteries must only be replaced in an area known to be non-hazardous.
• EXPLOSION HAZARD - Do not reset circuit breaker unless power has been removed from the equipment or
the area is free of ignitible concentrations.
If your UPS demonstrates any of the following conditions, turn OFF the UPS, disconnect the ac supply
and contact your local distributor, SolaHD representative or SolaHD Technical Support at
1-800-377-4384.
• The circuit breaker opens frequently.
• The UPS does not operate in accordance with the user manual.

Page: 3
SDU AC-A Series
A272-290 Rev. 5 07/2018
3.0 Installation Instructions
!WARNING
To reduce risk of fire, connect only to a circuit provided with 20A maximum branch circuit overcurrent
protection in accordance with the NEC, ANSI/NFPA 70, and the CEC Part 1, C22.1.
Protective
Earth
Bottom
View
Protective
Earth
Neutral Neutral
Line Line
Figure 2: Input/Output Terminals
1. Placement:InstalltheUPSinaprotectedareawithadequateairflowandfreeofexcessivedust.
Do not operate the UPS outdoors. The products are suitable for a Pollution Degree 3 environment.
2. COMM CARD Installation: To install the optional card, remove the COMM PORT cover and insert the
card. Refer to the SDU COMM CARD Manual for more details. (Refer to inside cover for COMM CARD
options or contact your SolaHD representative).
3. DIN Rail Mounting: Follow instructions below.
A) Tilt unit as illustrated.
B) Put it onto the DIN rail.
C) Push downwards until stopped.
D) Push at the lower front edge to lock.
E) Shake the unit slightly to ensure that the unit
is secure.
F) Check if UPS is facing upright and not tilting
downward.
Figure 3: Mounting the UPS DIN Rail

SDU AC-A Series
A272-290 Rev. 5 07/2018
Page: 4
!WARNING
Risk of electric shock, disconnect AC main power source before wiring. Ensure proper grounding
4. I/O Wiring: Make sure the UPS and the AC Supply is OFF (disconnected) before installation. Wire the
UPS terminals with 90 °C rated copper wire according to the table below. Connect the AC input ground
terminal to the main supply ground. Connect line in neutral supply conductors. Connect the loads to the
output hardwire connector. Verify proper wiring connections then apply power to the UPS.
Reference Figure 2.
Wire Gauge 10-18 AWG
Screw Torque 9 lb-in. (101.7 N-cm)
5. Internal Battery: Charge the UPS battery for a minimum of 8 hours before initial use. The UPS charges
its battery whether the UPS is on or off, when it is connected to AC power.
6. Warning Label: Apply the provided electrical shock warning label to the panel, making it clearly visible
to the user.
Risk of electrical shock—
hazardous live parts inside this
panel may be energized from the
battery supply, even when the
input ac power is disconnected.
7. Do not connect Ground to Neutral on either input or output terminals of the UPS unit.

Page: 5
SDU AC-A Series
A272-290 Rev. 5 07/2018
4.0 Specifications
Description Catalog Number
SDU 500A SDU 850A SDU 500A-5 SDU 850A-5
INPUT
Capacity VA/Watts 500/300 850/510 500/300 850/510
Voltage Vac 120 V + 10%, -20% 230 V +/ -15%
Frequency 50 or 60 Hz, +/ -10% (auto-sensing)
Harmonic Distortion THD:42.1%;maximumsingleharmonicdistortionof:25.6%
OUTPUT (Back-Up Mode)
Voltage Vac Simulated sine wave
120 V +/-5% 230 V +/-5%
Frequency 50 or 60 Hz, +/-0.5% auto-sensing
Transfer Time Typical <8 ms
PROTECTION
Unit Input (internal) 10A 5A
Overload Protection UPSshutdownifoverloadexceeds105%ofnominalat20s,120%at10s,130%at3s;auto-recovery
Short Circuit UPS shutdown, auto-recovery
BATTERY
Type Sealed, maintenance-free, lead acid batteries
Typical Recharge
Time 8 hours
Back-Up Time
(at full load) 4 min. 2 min. 4 min. 2 min.
ALARM
ON Battery Slow beeping every 4 seconds
Battery Low Rapid beeping every second
Overload Continuous beeping sound
ENVIRONMENT
Ambient Operation 0–95% humidity, non-condensing. 50 °C up to 6,600 ft. (2000m)
Audible Noise <40 dBA (1 m from surface)
Vibration
Operating - IEC60068-2-6, Sine Wave: 10Hz to 500Hz @19.6m/S²,
displacement of 0.35mm, 60 min per axis for all X, Y, Z direction.
Non-operating-IEC60068-2-6,Random:5hzto500Hz(2.09Grms);20minperaxisforallX,Y,Z
Shock Operating - IEC60068-2-27, Half Sine Wave: 10G for a duration of 11ms, shock for 1 direction (X axis)
Non-operating - IEC60068-2-27, Half Sine Wave : 30G for duration of 11ms, 3 shocks for all 3 axes
WEIGHT & DIMENSIONS
Net Weight, lb. (kg) 10.6 (4.8) 11.5 (5.2) 10.6 (4.8) 11.5 (5.2)
H x W x D, in. (mm) 4.87 x 11.1 x 4.81 (123.7 x 281.9 x 122.3)
CERTIFICATIONS
Safety
: UL 1778, 5th Ed./CSA 107.3. UPS evaluated for use in UL 508/CSA 107.1 industrial applications
overvoltage category 3, pollution degree 3 with no output derating
: ISA 12.12.01/CSA 213 Class I, Div 2, Groups A, B, C, D, T3
CE;LowVoltageDirective-EN62040-1
EMC FCCPart15,SubpartB;EN62040-2;EN55032;EN55024-ClassA

SDU AC-A Series
A272-290 Rev. 5 07/2018
Page: 6
5.0 General Description





   

Communication Card Options
SDUCFRELAYCARD
SDUENETIPCARD
Figure 4: Front Panel
1. POWER ON/OFF/TEST:
ON - To turn the UPS ON, press and release the button for more than 2 seconds until you hear “3 quick
beeps” and the LEDs light. SELF-TEST - Press the button for less than one second to activate the self-testing.
OFF-PressformorethanvesecondstoturnOFFLED,UPSturnon.
2. Battery Warning/Overload Indicator (Red LED):
TheLEDflasheswhenthebatteryneedstoberechargedandtested.
The LED will illuminate when the unit is subjected to an overload condition.
If the unit shuts down due to overload, the LED and alarm will continue for two minutes.
3. ON Battery Indicator (Yellow LED): The LED illuminates when the UPS is supplying battery power to the
loads.
4. AC Input Normal Indicator (Green LED): The LED illuminates when the line input voltage is normal.
5. Input: IP20-rated Input Screw Terminals.
6. Output: IP20-rated Output Screw Terminals.

Page: 7
SDU AC-A Series
A272-290 Rev. 5 07/2018
7. Input Circuit Breaker: Protection from AC overload and short circuit.
8. USB Port: High speed 2.0 Standard USB Type B Peripheral Communication Port used to establish control and
monitoring with UPSMON software.
9. COMM PORT: Communication card slot.
COMM CARDS: SDUCFRELAYCARD and SDUENETIPCARD NETWORK COMM CARD can be purchased
separately.
The UPS can detect the presence of a COMM CARD and identify what kind of COMM CARD is inserted.
USB communication will have precedence over COMM CARDS.
10. REMOTE ON/OFF TERMINALS: Use a switch to remotely toggle ON/OFF state. Non-Polarized terminals.
No external voltage is required. We recommend using stranded UTP (Unshielded Twisted Pair) wire for
connections.
!WARNING
Remote ON/OFF is grounded to the UPS internal signal ground so it should be isolated from the
chassis ground to prevent any ground potentials that may cause a unit malfunction or damage. In
addition, isolate the Remote ON/OFF wiring away from high current, high voltage, and high frequency
components to prevent any magnetically coupled noise on the Remote On/Off connections.
Screw M3.0;Currentrating=30A,AC300V
Insulation Withstands Volts Ac 2000 V min.
Preferred AWG 10–18 AWG
Screw Torque 9 lb-in (101.68 N-cm)
Screw Terminals Description
Catalog Number Dimensions in Inches (Millimeters)
H W D
SDU AC - A SERIES 4.87 (123.7) 11.10 (281.9) 4.81 (122.3)
Figure 5: Product Dimensions

SDU AC-A Series
A272-290 Rev. 5 07/2018
Page: 8
6.0 System Block Diagram
Figure 6: SDU AC - A Series UPS System Block Diagram

Page: 9
SDU AC-A Series
A272-290 Rev. 5 07/2018
7.0 Operating Instructions
7.1 TURNING ON THE UPS
• Press the POWER ON/OFF/TEST button for more than 2 second until you hear the “3 quick beeps” and
the LEDs turn ON.
Note: If utility power is not present, the UPS will be in back-up mode. The load will be powered from the
internal batteries until the discharge point is reached.
7.2 TURNING OFF THE UPS
• Hold the POWER ON/OFF/TEST button until the LEDs turn OFF.
7.3 ALARM
• Factory default setting is alarm enabled.
• To enable/disable Alarm:
• When the UPS is in back-up mode, press the POWER ON/OFF/TEST button for at least 1 second to silence
the alarm (this function is disabled when the UPS status is either LOW BATTERY or OVERLOAD MODE). To
re-enable the alarm, press the POWER ON/OFF/TEST button for at least 1 second. Additionally, you can
enable/disable the alarm via UPSMON Software.
7.4 SELF TEST
• ThisUPShasaselfdiagnosticfeaturethatveriesboththeoperationoftheUPSandtheconditionofthe
battery.
• In AC mode, press and release the POWER ON/OFF/TEST button for at least 1 second to perform a self-
test. During the self-test, the UPS momentarily operates in back-up mode (YELLOW LED will illuminate
momentarily then goes back to GREEN). If the UPS passes the self-test, it returns to AC mode.
• If the YELLOW LED does not illuminate momentarily, please contact SolaHD Technical Support or your
local SolaHD distributor for a replacement.
• Additionally a self-test can be ran via UPSMON software.
7.5 GREEN MODE
• Factory default setting is Green Mode disabled.
• Green Mode is a feature to reserve battery energy in low load conditions. In back-up mode and if the
load level is less than approximately 2% ~ 4% (or 60W), the UPS will shutdown to save battery in 180
seconds. If power is restored within 180 seconds, the UPS will return to AC mode.
• Green Mode Enable/Disable:
• Green Mode can be ENABLED or DISABLED by pressing the POWER ON/OFF/TEST at start-up per TABLE 2:
Green Mode Alarm Signal
Enabled press POWER ON/OFF/TEST button and release until “3 beeps” are heard
Disabled press POWER ON/OFF/TEST button and release until the “2 beeps” are heard
Table 1. Green Mode Setting Table

SDU AC-A Series
A272-290 Rev. 5 07/2018
Page: 10
7.5 GREEN MODE (continued)
UPSMON Software: If UPS is connected to a computer with UPSMON software running, the user can change the Green
Mode setting. On the UPSMON software screen, “UPS Control Panel” (see Figure 7 below), you can to enable and disable
GreenModeControlbyclickingtheappropriateboxhighlightedinthegure.
Figure 7: UPS Control Panel, Configuration
7.6 STANDBY MODE
This feature is only available during back-up mode. Standby mode can be executed remotely using the
COMM CARDs. This feature puts the UPS on standby in 3 minutes and auto-recovers once AC power returns.
This 3 minute window (or maximum run time depending on loading) allows the user to shut off or place
equipment into safe mode.
7.7 REMOTE ON/OFF
• Allows the user to perform remote power ON/OFF functions using a switch on terminals
(non-polarized) to toggle ON/OFF state.
• To Enable the UPS, close the switch that is connected to the terminals.
• To Disable the UPS, open the switch that is connected to the terminals.
Remote Enable/Disable of UPS
SDU-A Remote
ON/OFF Switch Wired UPS Condition/State Switch or Terminal Condition
UPS-A ON
UPS-A OFF
Remote ON/OFF Terminals : Shorted (closed) for ON, Open for OFF Non-Polarized terminals.
No external voltage is required. We recommend using stranded UTP (Unshielded Twisted Pair)
wire for connections.

Page: 11
SDU AC-A Series
A272-290 Rev. 5 07/2018
8.0 Diagnostics
Condition Description LED Diagnostics Alarm
BACK-UP MODE UPS in on back-up mode due
to AC Loss YELLOW Slow beeping. UPS sounds until AC utility power recovers.
AC MODE Normal condition source
supplied by AC Mains GREEN No Alarm
AC MODE OVERLOAD
Load around 110% of it's rated
capacity GREEN/RED
Alarm is ON for 4 seconds / OFF for 0.8
seconds, until load is removed. UPS
will not shut down.
Load > 120% of it's rated
capacity GREEN/RED
After continuous alarm for 30 seconds,
the UPS will be on standby mode.
Next, the alarm will sound for 2
minutes, and the UPS will shut down.
BACK-UP MODE OVERLOAD
Load around 105% of it's rated
capacity YELLOW/RED
After continuous alarm for 3 seconds,
the UPS will be on standby mode.
Next, the alarm will sound for 2
minutes, and the UPS will shut down.
Load > 120% of it's rated
capacity YELLOW/RED
After continuous alarm for 3 seconds,
the UPS will be on standby mode.
Next, the alarm will sound for 2
minutes, and the UPS will shut down.
LOW BATTERY YELLOW
During back-up mode when the
battery charge runs low, the UPS
beeps rapidly (ON 0.25 seconds, OFF
0.25 seconds) until the UPS shuts
down or returns to AC Mode.
GREEN MODE ENABLED
If load < 60W or approximately
2% ~ 4% of the Wattage
capacity of the UPS Unit will
shutdown
Flashing GREEN LED, every
5 seconds
Alarm sounds every 30 seconds after
UPS enters idle mode.
Table 2: Diagnostics LED/Alarms

SDU AC-A Series
A272-290 Rev. 5 07/2018
Page: 12
9.0 Battery Back-Up Time
The UPS has an internal 12V sealed Valve Regulated Lead Acid (VRLA) rechargeable battery.
Models SDU 500A, SDU 500A-5 SDU 850A, SDU 850A-5
VA/Watts 500/300 850/510
Battery YUASA NPW36-12 YUASA NPW45-12
Load Level Approximate Back-Up Time (Minutes) Back-Up Time (Minutes)
10% 120 78
20% 51 34
30% 29.5 17
40% 19.5 11
50% 16 9
60% 11 6.5
70% 8 5
80% 6.5 3.5
90% 5 2.5
100% 4 2
Table 3. Battery Back-Up Time Chart
!WARNING
• Do not attempt to open the UPS or replace the battery.
• Call SolaHD Technical Support for further instructions.
• Do not mount the UPS in upside down orientation.
Note: Run times in this table are approximate. They are based upon new, fully charged standard battery modules at a temperature
of 25°C (77°F) with 100% resistive UPS loading. Run times listed above can vary due to manufacturing variances of the individual
batteries.

Page: 13
SDU AC-A Series
A272-290 Rev. 5 07/2018
10.0 Software and Interface
Power Monitoring Software (UPSMON SOFTWARE)
The CD that comes with the UPS contains the UPSMON monitoring/diagnostic software. Install the UPSMON
software on your computer. Connect the UPS to your computer via the 2.0 Standard Type A-B USB cable
provided.
Figure 8: Connecting UPS to Computer
With the UPSMON software, users can perform monitoring functions and an orderly shutdown of protected
equipment in the event of power failure. UPSMON displays diagnostic information such as: voltage, frequency
andbatterylevels.ItalsoallowscongurationoftheUPSfeatures
Additional details available by selecting the “Help and Support” button of the control panel, as shown in
Figure 9.
Figure 9: UPSMON Control Panel, Monitor System

SDU AC-A Series
A272-290 Rev. 5 07/2018
Page: 14
11.0 Storage
Ambient temperature range is -15 °C to +45 °C (5 °F to 113 °F). It is recommended to charge the UPS for
at least 8 hours then store the UPS covered and upright in a cool, dry location. Remove accessories and
disconnect cables connected to the UPS to avoid unnecessary draining of the battery.
Extended Storage
During extended storage in environments where the ambient temperature is:
-15 °C to +30 °C (+5 °F to +86 °F), charge the UPS battery every six months.
During extended storage in environments where the ambient temperature is:
+30 °C to +45 °C (+86 °F to +113 °F), charge the UPS battery every three months.

Page: 15
SDU AC-A Series
A272-290 Rev. 5 07/2018
The information in this manual is provided as a guide for installation, operation, and maintenance. It does not
affect or exceed our obligations under the Terms and Conditions of Sale.
Notethatunitspecicationsaresubjecttochangewithoutnotice.
Contact Information
Website: www.solahd.com
Technical Services E-Mail: solahd.technicalservice[email protected]
Warranty
Please see the “Terms & Conditions of Sale”.
While every precaution has been taken to ensure accuracy and completeness in this manual, Appleton Grp LLC d/b/a Appleton Group assumes no responsibility,
and disclaims all liability for damages resulting from use of this information or for any errors or omissions.

SDU AC-A Series
A272-290 Rev. 5 07/2018
The Emerson logo is a trademark and service mark of Emerson Electric Co.
Appleton Grp LLC d/b/a Appleton Group. SolaHD is a registered trademark of Appleton Grp LLC.
All other marks are the property of their respective owners. © 2018 Emerson Electric Co. All rights reserved.
United States
(Headquarters)
Appleton Grp LLC
9377 W. Higgins Road
Rosemont, IL 60018
United States
T [phone]
Australia Sales Office
Bayswater, Victoria
T [phone]
Europe
ATX SAS
Espace Industriel Nord
35, rue André Durouchez,
CS 98017
80084 Amiens Cedex 2
France
T [phone]
China Sales Office
Shanghai
T [phone]
Canada
EGS Electrical Group Canada
Ltd.
99 Union Street
Elmira ON, N3B 3L7
Canada
T [phone]
Middle East Sales Office
Dammam, Saudi Arabia
T [phone]
Chile Sales Office
Las Condes
T [phone]
India Sales Office
Chennai
T [phone]
Korea Sales Office
Seoul
T [phone]
Asia Pacific
EGS Private Ltd.
Block 4008, Ang Mo Kio
Ave 10,
#04-16 TechPlace 1,
Singapore 569625
T [phone]
Latin America
EGS Comercializadora
Mexico S de RL de CV
Calle 10 N°145 Piso 3
Col. San Pedro de los Pinos
Del. Álvaro Obregon
Ciudad de México. 01180
T [phone]
