Infiniton 36YA2 User manual

Instruction Manual
Steam Combi Oven
HORNO 36YA2

Please read these instructions carefully before attempting to install or use this appliance.
I t is advisable to keep these instructi ons i n a safe place f or future ref erence.
I ntroducti on
T hank y ou for choosi ng thi s appl iance.
I t has been designed to give years of trouble-free use provi ded i t is instal l ed and
maintained correctly.
Please read these instructions carefully before installing or using your appliance. I t is
advisable to keep your purchase and installation receipts with these instructions in a
safe place for f uture reference. I ncluded is some important safety i nformati on i n
addition to guidelines and recommendations that will enable you to take full advantage
of all the functions available.
T his quality appliance has been tested and certified to meet all applicable electrical and
safety standards.
T his appliance must be installed and connected i n accordance with current regulations.

A fter unpacki ng the appliance ensure that there is no visible damage. I f the appliance
has been damaged during transit, do not install or use it, contact your retailer
i mmedi atel y.
C ontent
1. C ontent………………………………………………………………………………………………………1
2. G eneral warni ngs …………………………………………………………………………………………2-3
3. R epl aci ng oven l amp………………………………………………………………………………………4
4. Pl aci ng of accessori es i n the cavi ty … …………………………………………………………………………5
5. E nvi r onmental ef f ect repor t ………………………………………………………………………………6
6. S af ety cauti ons ………………………………………………………………………………………………6
7. A ccessori es……………………………………………………………………………………………………7
8. Pr oduct overv i ew ……………………………………………………………………………………………8
9. Pr oduct D i mensi on …………………………………………………………………………………………8

10. Product specification …………………………………………………………………………………………..9
11. I nstal l ati on precauti on………………………………………………………………………………………10
12. I nstal l ati on ……………………………………………………………………………………………………10
13. Production cauti on ……………………………………………………………………………………………11
14. C ontrol panel …………………………………………………………………………………………………12
15. Qui ck start……………………………………………………………………………………………………13
16. How to use …………………………………………………………………………………………14
17. S el ecti on of f ood contai ner ………………………………………………………………………………14
18. S uggested steami ng ti me……………………………………………………………………………………15
19. M ai ntenance and r epai r ………………………………………………………………………………………16
20. T r oubl eshooti ng………………………………………………………………………………………………17
G eneral warni ngs
1. This appliance shall not be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction on how to use the appliance in a safe
way and understand the
hazards involved. Children shall not play with the appliance. Cleaning and user maintenance
shall not be made by children without supervision.
2. If the power supply cord is damaged, it must be replaced by the manufacturer, it’s service
agent or similarly qualified persons in order to avoid a hazard.
3. Please make sure that the power is well connected after installation.
4. The product will become hot when its in use, do not put any flammable products inside the
oven.
5. Caution: the accessories or parts of the oven will become very hot when it is in use. Please
keep away from children.
6. Do not use other abrasive cleaners and/or wire wool or metal tools with sharp edge to clean
the oven door glass, as this may scratch the surface which may lead to damage of the oven
door
7. Do not use steam clearer to clean the oven.
8. Please make sure that the power is disconnected before replacing the oven lamp to avoid
electric shock.
9. Disposal must be carried out in accordance with local environmental regulations for waste
disposal.

10.For more detailed information about treatment, recovery and recycling of this product, please
contact your local authority, your household waste disposal service or the retailer where you
purchased the product.
R eplacing of oven lamp
•D i sconnect wi th power suppl y
•Unscrew the glass cover attached to the lamp holder
•U nscrew the lamp and replace i t with another high-temperature lamp (300°C) with the following
characteristics:
•R emount the glass cover and reconnect the appli ance to the power supply
W A R NI NG : E nsure that the appli ance i s unplugged before replaci ng the l amp to avoid the possibility of electric
shock.
V ol tage: A C220V -240V
Wattage: 15W
Socket: E 14

W arni ng: Do not operate appliance wi th damaged cord or plug or after the appli ance mal f unctions, or has been
damaged i n any manner, return appliance to the nearest A uthori zed Service C enter for examination, repair, or
adjustment.
F i tti ng Oven S hel ves
T he deep pan and wired shelf have a side edge, there edges can match with the sl i ding rack on the sides of the cavity.
I t can prevent the rack or tray from slipping out from the oven.
Deep pan and wi red shel f in the posi tion 1-4 marked

E nvi ronmental effect report
Please protect the environment, avoid pollution.
Please dispose the product as below：
Packing box, pl asti c material and other recyclable materi al should be disposed to recycle center. B attery or other
dangerous materi al may lead to pol l ution and need to be disposed in envi ronmental friendly and healthy way.
Safety precauti ons

1. Please use power cable with 10Aor above, and please ensure that it i s earthed. Do not use any cable wi th
loose connection to avoid el ectric shock or even fi re hazard. Do not share the power supply with other
appliance to avoi d overheating.
2. W hen disconnecting the power, please make sure that it is fully unplugged. Do not leave the power cable on
the socket. Or it may cause electric shock or short circuit.
3. Do not place the product in water or make it wet, or i t may cause electri c shock or short circuit.
4. Do not use power wi th vol tage of A C 187-242V ，or i t may cause electri c shock or short circuit.
5. Please keep your children away from this product and do not let them play with the product, or it may cause
electric shock or short circuit.
6. T he product can only be repaired by technician from designated service agent. Do not try to open or repair
the uni t on your own.
7. I f the product will not be used for a period of time, please disconnect with power supply.
8. I f the power socket is damaged, please contact qual i f i ed technici an to repair or replace.
Accessories
Main Unit
1 unit
Steam tray
1 pi ece
Grill rack
1 pi ece
Water absorbing accessory
1 pi ece
C leaning f oam
1 pi ece

Detergents
2 packs
I nstruction manual
1 pi ece
Product overvi ew
1. C ontrol panel
2. Sliding rack
3. Grill rack
4. Steam tray
5. Oil collecting plate
6. Door hinge

7. W ater col l ecti on tray
8. Oven door
9. W ater tank
Product Dimension
Product Specification
M odel
HOR NO 36Y A2
V ol tage
220V －240V －50HZ
R ated power
3020W
Product di mensi on － W X H X D－
595 X 455 X 540 mm
A perture dimension －W X H X D－
560 X 450 X 550 mm
Packi ng dimensi on －W X H X D－
660 X 512 X 650 mm
I nstallation precaution
1. T he steam oven shoul d be i nstalled i n a position which is convenience for operation, mai ntenance, and
sui table for repair.

2. Do not i nstall the steam oven or power cord in a humi d place or place with water.
3. Please make sure that the power cable is well earthed.
4. Please do not hol d the handle if you need to l i ft up the unit.
5. Please reserve enough space around the oven.
6. W hen the steam oven is in use, do not touch the steam from the oven to avoid scald.
7. I f you fit the steam oven in the cabinet, please make sure that sufficient space is reserved for ventil ation, or
it may affect the normal operation of the unit. T he rear panel of the cabinet must be removed so that air can
ci rculate f reely.
Fitting the appliance
1. For the most effici ent ai r circulation, the oven should be fitted according to the dimension as below：
A perture dimension （W X H X D）
560 X 450 X 550 mm

2. A fter fi tting the steam oven in the cabinet, it must be fixed with screw.
I mportant notes
1. I f you want to take out the food from the oven immediately after cooking finish, please use cooking gloves
or other tools to avoid scald.
2. T here wi ll be water drop from the unit when it is in use, please clean them.
3. Do not open the oven door immediately after cooki ng end to avoid scald by the steam.
4. Do not use water to clean the oven, and do not let any petrol oil or other oil material to be in contact with
the body of the oven.
5. A lways clean or descale the cavity and food tray or racks.
6. I f the power socket is damaged, to avoid hazard, please contact quali fied technici an to replace.
7. A ll the sockets must be earthed.
8. I f the product will not be used for a long period of time, please cl ean up the water in the oven, and
disconnect with power supply.
9. Do not put excess food in the oven, to avoid uneven steam circulation in the cavi ty.
10. I t is recommended to use distilled water or bottled water to steaming.
Control panel

1 ON/OFF 2 Program 3 Ov en l amp
4 T emperature 5 T i mer 6 D i spl ay
7 “+”increase 8 “ -” decrease 9 OK
10 Quick start 11 Start/stop
Quick start
1. A ctivate the steam function
S tep 1 ：Press “ ON/OFF ” button, the control panel wil l l i ghts up, the oven is in standby mode
S tep 2 ：Press the T imer key twice to enter the cooking time, cooking time will bli nk at the left bottom of the panel.

S tep 3：Press “ +” and “ -“ to adjust the cooking time.
Press “ OK ” to confirm
S tep 4：L astly, press “ Start/stop” to start cooking
How to use
1. Date/Cooking time/finish time setting. T he sequence of cooking tie modes will be displayed in the screen as
bel ow:
1.1 Clock: Press “ Timer” for 2 seconds, then press “ +” or “ -“ key to adjust the time, press OK to
confi rm

1.2 Alarm clock: Press “ T i mer” , then press “ +” or “ -“ key to adjust the time, press OK to confirm
1.3 C ooki ng ti me: Press “ T imer” twi ce, then press “ +” or “ -“ key to adjust the time, press OK to
confi rm
1.4 Fi ni sh time: I f you want to set up the fi nish cooking time, press “ T i mer” three times to set it. T he
oven wi ll end cooking when the ti me i s reached.
2. C ooki ng F uncti ons
2.1 Press “ Program” to start operating, continue to press this key to select the function that you desi re.
2.2 T emperature can be adjusted by pressing “ T emperature” key, press ，“+” or“-“ key to adjust
the temperature, press OK to confirm. Once the functi on is selected, press “ Start/stop” key to start
cooking. Press it again to stop and start cooking.
3. D escal i ng F uncti on
T ake out the water tank, pour i n the descal i ng pack add water until it is half full. Put the water tank in place agai n.
C lose the door and press “ P” to select “ “ to start working. ””will appear on the display. Descale
unti l the “ “ si gn appear wi th beep sound.
W hen “ ” si gn appear, take out the water tank again, pour in water unti l it is half full, put it back. C lose the
door and press “ ” again to start the second part of cleaning. Do the same as the above for third time cleaning.
W hen it f inish, the descaling is completed.
4. R api d heating
W hen the setting temperature exceeds 100 degree and the pre-heat functi on is not fini shed, user can press the
key to start rapi d heating model. T he display will show the symbol.
5. C hi l d L ock F uncti on

Press the “ ” key for 2 seconds, the oven will be locked. Press i t again for two seconds, it will be unlocked.
6. T emperature Setting. In standby mode, press , then press “ +” or “ -” to set desired temperature,
press OK to confirm.

Demo Mode:
In the standby mode, press and hold the start/pause button for 5 seconds. The buzzer will give a short “beep” for 3
times the system will enter the demo mode. The display shows “de” on top right corner of the display and other
icons are shown as normal
In demo mode, the normal operation of the cooling fan, circulation fan, and lighting work normally and other
output(like grill, steam) are supspended.
To turn off the display, this setting can be saved. The demo mode still works after turn on the display again.
In the off state, the demo mode will be turn off too.
In demo mode, turn off the display to standby mode, press and hold the start/pause key for 5 seconds. The buzzer
will give a short “beep” for 3 times and the system will exit the demo mod

I ntroduction of functions and settings
Function
W or ki ng
parts
F an
tha
w
C onv ecti o
n
Full
gri l l
Full
gri l l
and
l ower
heati ng
el emen
t
Full
gri l l
and
l ower
heati ng
el emen
t with
fan
Pure
steam
Full
heati ng
wi th
convectio
n and
steam
C onv ecti o
n and
steam
Full
gri l l
and
heati n
g wi th
steam
D escal i n
g
D ef aul t
temperatur
e
200°C
200
200°C
200°C
100°C
120°C
120°C
120°C
A dj ustabl e
temperatur
e range
20-
60°
C
50-225°C
50-
225°C
50-
225°C
50-
225°C
40-
100°C
120—
220°C
120—
220°C
120—
220°C
Power
1680W
1450
W
2500W
2520W
1740
W
1980W
2180W
3020
W
Sel ect the right food contai ner:
Pl ease sel ect the correct contai ner for di fferent kind of f ood. A l l the tray and rack incl uded i n the oven are heat
resistant. B elow you can fi nd our suggesti on:
1. For food such as sweet potatoes, corn, tomato and egg, please pl ace on the steam tray, do not put it
directly on the metal rack.
2. Food such as seafood, chicken wings, chi cken steak or pumpkin, whi ch can be cooked wi th sauces, you
can use steam tray.
3. For food such as fish, ribs, whol e chi cken or beef, which you do not want to keep the juice or oil, then
you can use grill rack.
Suggested steaming ti me
Species
W ei ght
T i me
Fish
650g
15 mi nutes
Crab
500g
25mi nutes
S hri mp
500g
12mi nutes
C hicken leg
5pcs around 650g
30mi nutes
Chicken
1100g
35mi nutes
Beef
350g
40mi nutes

Pork
400g
20mi nutes
Soup
450g
15mi nutes
E gg
10pcs around 650g
15mi nutes
Pumpk i n
850g
20mi nutes
T omato
550g
30mi nutes
C orn
550g
30mi nutes
B read
10
18mi nutes
R ice
400g
30mi nutes
Dai l y mai ntenance
Note: I t has been designed to give years of trouble-free use provi ded i t i s i nstal l ed and
maintai ned correctly. Pl ease disconnect with power suppl y before mai ntenance.
1. Do not pull the cable to disconnect power.
2. W hen cleaning the cavity, please remove everything in the cavi ty i nclude the shelves
and use clean cloth to clean it.
3. Do not use water to spray on the unit directl y. Do not use abrasive material.
4. C avi ty must be clean every time after use, wait unti l the cavity i s fully cool down, use
dry cloth to clean the cavity, or keep the oven door oven to let the cavity dry out.
5. I t i s recommended to descal e the steam oven once every three months. F or detai ls you
can refer to the descal i ng function section.
6. Please clear the water tank regularly. W hen you clean the water tank. Please remove
the cover and use dry cloth to wipe it.

T roubl eshooting
I f you found the unit operating abnormal l y, please stop using it. Unplug the power and follow
the foll owing i nstructi on. Pl ease contact our service center for checking.
Status
Possible reasons
Sol uti on
L ack of water “ “ si gn
No water i n water tank
B ad pumps
Fill water into the tank
R epl acement of pump, pl ease
contact servi ce agent
C ontrol panel i s not worki ng
C hi ld L ock i s on
Defective control panel
Unl ock the uni t
Pl ease contact servi ce agent
Food are not cooked af ter steaming
T he food is sealing wi th cover
No steam i s generated
R emove the cover
C ontact servi ce agent
E2 appear on di spl ay
I nterior sensor error
Contact service agent
E3 appear on di spl ay
I nterior sensor overheat
Contact service agent
E4 appear on di spl ay
Steam heating plate sensor error
Contact service agent
E5 appear on di spl ay
Steam heating plate overheat
Contact service agent
E1 appear on di spl ay
No water tank or water tank not in
pl ace
Contact service agent
