INTRODUCTION
The Infinity US-1 is a compact, efficient 2-way universal satellite speaker system that is ideal
for reproducing home-theater sound for front or rear channels. With their versatile design, US-1
speakers can be placed virtually anywhere on shelves or stands, or mounted on a wall or ceiling,
using the integral 4-way mounting bracket. It has crossholes for mounting and also acts as a door
which hides the mounting terminals. The US-1 Theater Pac contains five US-1 satellite speakers.
To start enjoying your new US-1 Theater Pac, first read and then perform all instructions
listed in this manual, as well as those found in the owner’s manuals of associated components in
your audio system. Save all instructions for future reference. These speakers are covered by
a limited five-year warranty, so save the bill of sale to protect your purchase and aid in any
service-related questions.
UNPACKING THE SPEAKERS
Carefully unpack the speakers. If you suspect damage from transit, report it immediately to your
dealer and/or delivery service. Keep the shipping cartons and packing materials for future use.
Open the accessory pack and verify the following contents:
◆(5) US-1 Speakers
◆Owner’s Manual and Warranty Registration Card
◆Hex wrench, 5⁄32" (4mm)
You may also need the following tools and supplies:
◆High-quality speaker wire (also see Wiring the System on page 7)
◆Necessary wall-mounting hardware
◆Wire strippers
INF1446 3/22/99 9:58 AM Page 2

US-1 Theater Pac – Owner’s Manual ◆3
Figure 1. In this overhead view of a typi-
cal 6-piece home entertainment system,
US-1 speakers are used to reproduce
sound for the front, center and surround
channels. An Infinity powered subwoofer
(optional) is shown providing extra
bass for effects and music.
F RONT C HANNELS ...
C
ENTER C
HANNEL ...
S
URROUND C HANNELS ...
PLANNING YOUR SYSTEM
US-1 speakers can be used to reproduce sound for either front or surround channels. Before
deciding where to place your US-1 speakers, survey your room and study Figure 1 to determine
the best placement.
PLACEMENT
NOTE: US-1 speakers can be placed directly on a shelf or mounted on a wall, using the built-in
bracket (see Figures 2 through 5).
For front left and right channels, place one US-1 speaker on the left and another on the right,
along either side of the television monitor.
For the center channel, place one US-1 speaker directly on top of, or below, your
television, either vertically or horizontally.
Since the speakers are magnetically shielded, you can place them very close to the TV without
worrying about the magnetic field distorting the TV picture.
For surround left and right channels, place one US-1 speaker on the left and another on the right,
to the side of, or behind the listening area.
TELEVISION
SOFA
US-1 SPEAKER
For Left Channel
INFINITY POWERED
SUBWOOFER
(optional)
US-1 SPEAKER
For Right Channel
US-1 SPEAKER
For Left Surround US-1 SPEAKER For Right Surround
US-1
SPEAKER
On Top of Television
For Center Channel
INF1446 3/22/99 9:58 AM Page 3

4◆US-1 Theater Pac – Owner’s Manual
V ERTICAL P OSITION ...
Figure 2. This illustration shows how to
vertically position US-1 speakers
two ways.
H ORIZONTAL P OSITION ...
Figure 3. This illustration shows how to
horizontally position US-1 speakers
three ways.
SHELF PLACEMENT OF US-1
US-1 speakers can be positioned vertically in two positions on a shelf or stand, as shown in
Figure 2. Set each US-1 flat, with the logo at the bottom and the bracket facing inward.
You can also push the speakers gently back for a 20° tilt.
US-1 speakers can be positioned horizontally in three positions on a shelf or stand, as shown
in Figure 3. Set each US-1 flat, or push the speakers gently back for a 20° tilt. Rotate the logo
to match the orientation of the speaker. To provide a 10° tilt-down angle, loosen the bracket
screw on the rear door with the hex wrench (included) and adjust the bracket to Bracket Open,
Position #1. Tighten the bracket screw when you have reached the desired angle.
NOTE: You may want to route the wires before tightening the bracket screw (see Figure 7 on page 7).
US-1 VERTICAL PLACEMENT ON A SHELF
Flat
Position
US-1
(side view) US-1
(side view)
20°Tilt-Up
Position
US-1 HORIZONTAL PLACEMENT ON A SHELF
Flat Position
(Bracket Closed)
US-1
(rear view)
20°Tilt Up
(Bracket Closed) 10°Tilt Down (Bracket Open,
Position #1)
US-1 Positions
(side view)
❶Loosen Screw
❷Rotate Bracket
❸Tighten Screw
Screw
Bracket
INF1446 3/22/99 9:58 AM Page 4

US-1 Theater Pac – Owner’s Manual ◆5
NOTE: The customer is responsible for
the correct selection and use of mounting
hardware (available through hardware
stores) that will ensure the proper and
safe wall-mounting of the speakers.
V ERTICAL M OUNTING ...
Figure 4. This illustration shows how to
mount a US-1 speaker vertically on a wall
or ceiling four different ways.
WALL-MOUNTING THE US-1
US-1 speakers can be wall- or ceiling-mounted, as shown in Figures 4 and 5. You can mount the
speakers with #6 wood screws (not included), using the built-in mounting bracket.
Use the enclosed template to mark the desired position of each US-1 on a wall or ceiling.
Locate a stud for secure mounting and use heavy-duty wood screws with long threads. Test
the mounting thoroughly before installation.
To mount the US-1 speaker vertically on a wall, fasten the wood screws (not included) to a
wall stud, leaving a 3⁄16" clearance between the base of the screw head and the wall. If desired,
loosen the bracket screw, adjust the bracket angle, and tighten the bracket screw.
NOTE: You may want to route the wires before tightening the bracket screw (see Figure 7 on page 7).
Then orient the speaker vertically, align the crossholes on the rear of the US-1 with the wood
screws, and slide the speaker down.
#6 Wood Screws
(fasten to wall stud)
US-1 VERTICAL MOUNTING USING BRACKET
Slide Speaker Down
Onto Wood Screws
US-1
(rear view)
Screw
(inside hole)
US-1 Positions
(top view)
45°From Wall
(Bracket Open,
Position #1)
20°From Wall
(Bracket Closed) 67.5°From Wall
(Bracket Open,
Position #2)
90°From Wall
(Bracket Open,
Position #3)
❶Loosen Screw
❷Rotate Bracket
❸Tighten Screw
3/16"
wall
wood
screw
(side view)
INF1446 3/22/99 9:58 AM Page 5

6◆US-1 Theater Pac – Owner’s Manual
H ORIZONTAL M OUNTING ...
Figure 5. This illustration shows how to
mount a US-1 speaker horizontally on a
wall or ceiling four different ways.
For horizontal mounting, fasten the #6 wood screws (not included) to a wall stud, leaving a 3⁄16"
clearance between the base of the screw head and the wall. If desired, loosen the bracket screw,
adjust the bracket angle, and tighten the bracket screw.
NOTE: You may want to route the wires before tightening the bracket screw (see Figure 7 on page 7).
Then orient the speaker horizontally, align the crossholes on the rear of the US-1 with the screws,
and slide the speaker down. Rotate the logo to match the orientation of the speaker.
Slide Speaker Down
Onto Wood Screws
#6 Wood Screws
(fasten to wall stud)
US-1 HORIZONTAL MOUNTING USING BRACKET
❶Loosen Screw
❷Rotate Bracket
❸Tighten Screw
Screw
(inside hole)
US-1
(rear view)
US-1 Positions
(side view)
45°Tilt Up
(Bracket Open,
Position #1)
20°Tilt Up
(Bracket Closed) 67.5°Tilt Up
(Bracket Open,
Position #2)
90°Tilt Up
(Bracket Open,
Position #3)
3/16"
wall
wood
screw
(side view)
INF1446 3/22/99 9:58 AM Page 6

US-1 Theater Pac – Owner’s Manual ◆7
WIRING THE SYSTEM
After placing the speakers, you are ready to connect your system. First turn off all audio system
power. Use high-quality speaker wire to make your connections. For speaker connections, use at
least #18 gauge speaker wire (or #16 for runs over 25 feet) with polarity coding. The side of the
wire with a ridge or other coding is usually considered positive polarity (i.e., + ). Also, consult
the owner’s manuals that were included with your amplifier, receiver, or television to confirm
connection procedures.
On the back of the US-1, loosen the bracket screw and rotate the bracket to access terminals.
Observe polarities when making speaker connections, as shown in Figure 6. Connect each +
terminal on the back of the amplifier, receiver, or television to the respective + (red) terminal
on each US-1 speaker. Similarly, connect the – (black) terminals in the same way.
Do not reverse polarities (i.e., + to – or – to +) when making connections. Doing so will cause
poor imaging and diminished bass response.
After making your connections, route the wires through either hole in the door, as shown in
Figure 7.
NOTE: You may need to loosen the bracket screw to open the door further.
After you finish connecting your system, return the door to the desired angle and tighten the
bracket screw.
T URN O FF A LL P OWER ...
I
MPORTANT !
Figure 6. Wiring diagram shows polarity
connections for one channel of a stereo or
home theater system.
R OUTING T HE W IRES ...
Figure 7. This illustration shows how to
route the wires through either hole in the
US-1 bracket and connect them to
the terminals.
+–
US-1
(rear view)
Receiver or Amplifier
(rear view)
Output
One Channel Shown Bracket Not Shown
red terminal = +
+–
black terminal = –
Output From
Amplifier or Receiver
Route Speaker
Wire Through
Either Hole
US-1
(rear view)
❷Insert Bare End;
Tighten Terminal
❶Loosen Terminal
+
–
blk red
INF1446 3/22/99 9:58 AM Page 7

8◆US-1 Theater Pac – Owner’s Manual
C HECKING P LAYBACK ...
S
URROUND M ODES ...
OPERATING THE SYSTEM
Check the speakers for playback by first setting the audio system volume control for a
minimum level, and then applying power to your system. Play a favorite music or video
segment and increase the volume control to a comfortable level.
NOTE: You should hear balanced audio reproduction across the entire frequency spectrum. If not,
check all wiring connections and see In Case of Trouble for more help.
When using the US-1 Theater Pac in a Dolby* Pro Logic* home-theater system, make sure
the receiver’s center-channel mode is set to “Normal”. When using the US-1 Theater Pac in a
Dolby Digital or DTS®home-theater system, make sure the receiver’s speaker mode is
set to “Small”.
CARE OF YOUR SPEAKER SYSTEM
The US-1 enclosure finish does not require any routine maintenance. When needed, use a soft
cloth, dampened with water only, to remove any fingerprints or to wipe off dust. Clean the grille
by gentle vacuuming or with a damp cloth.
NOTE: Do not use any cleaning products or polishes on the enclosure or grille.
INCASE OF TROUBLE
Before consulting your dealer, try these simple troubleshooting steps:
• If the sound quality is distorted, listen to each speaker separately.
• If distortion is present in both, the problem is probably somewhere else in your system.
• If only one channel is distorted, switch the left and right speaker leads at the receiver.
• If the distortion moves to the other speaker, the problem is not in the speaker.
• If you need further assistance, contact your local Infinity retail dealer.
INF1446 3/22/99 9:58 AM Page 8

US-1 Theater Pac – Owner’s Manual ◆9
P ERFORMANCE D ATA
D RIVE U NITS
D IMENSIONS
SPECIFICATIONS – US-1
Frequency Range: 70 ~ 20,000Hz
Sensitivity: 86dB spl @ 1m/2.83 V (anechoic conditions)
Impedance: 8 Ωnominal
Maximum Peak Output: 104dB (spl on program)
Recommended Maximum 10 ~ 100W
Amplifier Power:
Low/Mid Frequency: One 4" (100mm) magnetically
shielded, polypropylene cone
High Frequency: One 1⁄2" (12.5mm) magnetically
shielded, polycarbonate dome tweeter
Width: 4-1⁄2" (114mm)
Height: 8-1⁄2" (216mm)
Depth: 5-1⁄2" (140mm)
Weight: 3.4 lb or 1.6 kg (each)
INF1446 3/22/99 9:58 AM Page 9

10 ◆US-1 Theater Pac – Owner’s Manual
2.52"
(64 mm)
Bracket
Crosshole
Bracket
Crosshole
US-1 M OUNTING
T EMPLATE ...
INF1446 3/22/99 9:58 AM Page 10

US-1 Theater Pac – Owner’s Manual ◆11
Declaration of Conformity
We, Infinity Systems A/S
Kongevejen 194B
DK-3460 Birkerød
DENMARK
declare in own responsibility, that the products described
in this owner’s manual are in compliance with technical
standards:
EN 50081-1:1992
EN 50082-1:1992
Steen Michaelsen
Infinity Systems A/S
Birkerød. DENMARK. 3/99
INF1446 3/22/99 9:58 AM Page 11

Infinity continually strives to update and improve existing products, as well as create new ones.
The specifications and construction details in this and related Infinity publications are therefore
subject to change without notice.
©1999 Infinity Systems, Inc., 250 Crossways Park Drive, Woodbury, NY 11797 USA
[phone]
www.infinitysystems.com
Infinity is a registered trademark of Infinity Systems, Inc.
*Trademarks of Dolby Laboratories.
DTS is a trademark of Digital Theater Systems, Inc.
INF1446 3/22/99 9:58 AM Page 12
