InfoCase Toughmate S1 User manual

1
Introduction
Thank you for purchasing a Toughmate S1 Mobility Bundle from
InfoCase. Your Toughmate S1 Mobility Bundle is uniquely designed to
provide ease in transportation for your TOUGHBOOK S1 device.
Mobility Bundle for the TOUGHBOOK S1
User Guide
TBCS1MBBDL-P

User Guide
2
Features
1
2
1) Acetal O-Rings
2) Ergonomic Handle
3) Quick Connect Clips
4) Shoulder Strap
5) Spring Clip
Before installation, make sure that your TOUGHBOOK S1 is
laid face down on a soft surface.
Before installation, please ensure that both the quick connect
clips (3) are disconnected.
There are 4 device slots
on the TOUGHBOOK S1.
The Toughmate S1 Mobility
Bundle can be installed
so that the device faces
up or down. Depending
on preference, the quick
connect clip cords (3) will
feed through the two slots
from either Group A or
Group B.
Group A
Group BGroup B
Group A
1
3
1
3
4
2
5

User Guide
3
3
4
5
6
7
To instal, connect both of the quick connect clips (3) with the
plastic buckles. Your mobility bundle is now installed.
Once Group A or Group B has been decided, feed the cord of
the quick connect clip (3) into the chosen device slot.
With the cord through the device slot, loop the cord back
around the plastic buckle on the quick connect clip (3). Pull on
the buckle to tighten the quick connect clip (3) to the device.
Repeat Steps 3 and 4 for the other device slot, which is
determined if Group A or Group B was chosen at Step 2.
With the two quick
connect clips (3) installed
on either the Group A or
Group B device slots, the
Handle Assembly (2) is
ready to be installed.

User Guide
4
InfoCase products are dynamic, consistently improved and reinvented to bring
you the best products on the market. We use only the highest quality materials to
meet your mobile technology demands.
InfoCase o󰀨ers a warranty on defects and workmanship on this product. Please
visit: http://www.InfoCase.com/warranty or call 1-800-248-4844 to obtain more
information on the InfoCase warranty.
Additional Information
1. When taking a photo with the rear facing camera built into
the TOUGHBOOK S1, users can disconnect the mobility
bundle with the quick connect clips (3). The quick connect
clips allow for easy and fast installation at any time.
2. The included Shoulder Strap (4) is adjustable via a Webbing
Glide located near the end of the strap. The Shoulder Strap
is also removable via Spring Clips (5) and Acetal O-Rings (1).
3. The Mobility Bundle is designed to be small and out of the
way so it can remain on your device at all times.
4. NOTE: While the Mobility Bundle may be connected to
either the Group A and Group B device slots on the
TOUGHBOOK S1 (see page 2), while connected to Group
B, then the user will need to pay attention when inserting
into the cradle or vehicle dock to ensure the retention
straps do not get pinched and to ensure the device is
properly seated in the cradle or vehicle dock. Improper
installation may result in damage to the device, dock and/or
mobility bundle, as well as failure to charge the device via
the vehicle dock or cradle.
c2021
Warranty
