infrasave IEP-1520 Operating instructions

IM110526
RD: JUNE 2011
RL; 1A
BA
InfraSave IEP-1520 Manual
INSTALLATION / OWNER’S MANUAL
Read all instructions before using this heater.
Read and understand all installation and maintenance
instructions thoroughly before installing or servicing this equipment.
Improper installation, operation, adjustment, alteration, service or mainte-
nance can result in the risk of fire and electrical shock, and may cause
property damage, injury or death.
SAFETY ALERT:
This heater must be serviced only by a qualified electrician. Failure to com-
ply could result in personal injury, death, fire and/or property damage.
Do not operate this heater unless it is properly installed.
Always disconnect the heater from the power source prior to servicing.
Do not store or use gasoline or other flammable vapours and liquids in
the vicinity of this or any other hot surface appliance.
INDOOR USE ONLY - Do not use this heater outdoors
Do not use or locate this model where it could fall into a bathtub or other
water container.
Do not cover or block any surface of this appliance.
Do not touch this appliance while in operation
- Allow to cool after use.
Read the IMPORTANT INFORMATION section of
this manual before using this appliance.
SAVE THESE INSTRUCTIONS
WARNING
INSTALLER: PRESENT THIS MANUAL TO THE END USER. Keep this manual in a secure place.
Record the following information for future reference if service is required:
Model #: IEP-1520
Serial #: (located on heater rating label)
Model IEP-1520
Wall Fixed Electric Room Heater
INDOOR USE ONLY
Conforms to ANSI/UL 2021
Certified to CAN/CSA C22.2 No.46
3154365

2 IM110526
RD: JUNE 2011
RL; 1A
BA
InfraSave IEP-1520 Manual
NOTICE:
This contents of this manual are current for this product at the date of manufacture. Occa-
sional revision of the product Certification Standard may require changes to the product and/
or the content in the product manual. The product must be installed according to the content
of this manual, and/or all local and national code requirements.
This publication is the intellectual property of Schwank. This publication, or parts thereof, may
not be reproduced in any form, without prior written consent from The Manufacturer. Unau-
thorized use or distribution of this publication is strictly prohibited.
Schwank Group
Schwank and InfraSave brands
5285 Bradco Boulevard
Mississauga, Ontario,L4W 2A6
2 Schwank Way
Waynesboro, Georgia 30830
Customer & Technical Services
Phone: [phone]
Fax: [phone]
e-mail: [email protected]
www.schwankgroup.com
www.infrasave.com

3 IM110526
RD: JUNE 2011
RL; 1A
BA
InfraSave IEP-1520 Manual
IEP 1520
Wall Fixed Electric Room Heater
For INDOOR USE ONLY
Table of Contents
1. IMPORTANT INSTRUCTIONS: ..................................4
2. Heater Dimensions, Wiring, Specifications..................6
3. Project Design Considerations & Guidelines ...............7
4. Installation Instructions:
General Information ...............................................9
Locating the Heater................................................9
Minimum Required Clearances............................10
Heater Mounting...................................................10
5. Operating Instructions................................................12
6. Grounding..................................................................12
7. Maintenance Instructions...........................................13
8. Cleaning.....................................................................13
9. Heater Parts...............................................................14
10. Heat Lamp Replacement...........................................15
11. Warranty Statement...................................................18
FIGURE 1: Minimum Required Clearances.................7
FIGURE 2: Mounting Bracket......................................8
FIGURE 3: Heater Bracket..........................................8
FIGURE 4: Grounded Electrical Connection................9
FIGURE 5: Heater Parts............................................11
Read First !!

4 IM110526
RD: JUNE 2011
RL; 1A
BA
InfraSave IEP-1520 Manual
1. IMPORTANT INSTRUCTIONS
When using electrical appliances, basic precautions should always be
followed to reduce the risk of fire, electric shock, injury to persons or
death, and property damage including the following :
1. Read all instructions before using this heater.
2. CAUTION: HIGH TEMPERATURE - RISK OF FIRE. Keep electrical cords,
and combustible materials, such as furniture, pillows, bedding, papers,
clothes, and curtains at least 3 feet (36 inches) [90 cm] from the front of the
heater and keep them away from the sides and rear.
3. This heater is hot when in use. To avoid burns, do not let bare skin touch
hot surfaces.
4. Extreme caution is necessary when any heater is used by or near children
or infirm persons. Always supervise children and instruct and ensure that
they do not play with the heater.
5. Always unplug heater when not in use. Never leave the heater unattended
during operation.
6. Do not operate any heater with a damaged cord or plug or after the heater
malfunctions, has been dropped or damaged in any manner. Return heater
to an authorized service facility for examination, electrical or mechanical
adjustment, or repair.
7. Do not use outdoors or in wet environments.
8. This heater is not intended for use in bathrooms, laundry areas, and similar
indoor locations. Never locate heater where it may fall into a bathtub or
other water container.
9. Do not run cord under carpeting. Do not cover cord with throw rugs, runners,
or the like. Arrange cord away from traffic areas where it will not be tripped
over.
10. Arrange the cord at the side and back of the heater - do not allow cord to
drape over the heater.
11. To disconnect heater, turn controls to off, then remove plug from outlet.
12. Only connect the heater to a 115 - 120Vac outlet that is properly grounded.
Ensure the electrical outlet is readily accessible to be able to disconnect the
heater when needed.
13. Do not insert or allow foreign objects to enter the heater or any ventilation
continued ...

5 IM110526
RD: JUNE 2011
RL; 1A
BA
InfraSave IEP-1520 Manual
or exhaust opening as this may cause an electric shock, fire, or damage the
heater - death, personal injury or property damage could result.
14. To prevent a possible fire, do not block air intakes or exhaust in any manner.
Do not use on a soft surface, like a bed, where openings may become
blocked.
15. To reduce the risk of fire - Do not store or use gasoline, paint, or other
flammable liquids or vapors in the vicinity of the heater.
16. Use this heater only as described in this manual. Any other use not
recommended by the manufacturer may cause fire, electric shock, and
death or injury to persons and property damage.
17. Avoid the use of an extension cord because the extension cord may
overheat and cause a risk of fire. IMPORTANT: However, if you have to use
an extension cord, the cord shall be No. 14 AWG minimum size and rated
not less than 1875 watts.
18. Do not touch an operating heater or live parts - burns, electric shock and
death or personal injury can result.
19. Do not adjust the heater on the swivel bracket during operation. Allow
heater to cool before making any adjustment to heater position.
20. Do not stare at the heater Lamp - damage to your eyes could occur.
21. After use, allow the heater to cool down before moving or storing.
22. These instructions belong with the heater for ready reference. Keep this
manual in a safe place near the heater.
23. “SAVE THESE INSTRUCTIONS”
IMPORTANT INSTRUCTIONS continued

6 IM110526
RD: JUNE 2011
RL; 1A
BA
InfraSave IEP-1520 Manual
2. HEATER DIMENSIONS, WIRING, SPECIFICATIONS - IEP 1520
115 - 120 Vac, 60Hz, 13Amps

7 IM110526
RD: JUNE 2011
RL; 1A
BA
InfraSave IEP-1520 Manual
3. PROJECT DESIGN CONSIDERATIONS & GUIDELINES:
NOTE: Also refer to Section 4. Installation, and Table 2 and Figure 2 regarding the
Minimum Required Clearances.
The size and quantity of heaters (amount of heat input) required over an area to provide com-
fort is affected by the following factors:
 General:
 Amount of air movement in the area: “wind chill” requires additional heat input
 Provide wind breaks wherever possible
 ‘Spot heating’ comfort is most effective if people are heated from at least two sides
 Available mounting height for heaters at the project site
 Indoor application:
 ‘Space heat’ the entire structure1(accurate heat loss calculation required), or
 ‘Spot heat’ only part of a cold indoor area
 The activity level of the people: seated at rest, hard physical labor, etc.
 Outdoor application: Any area heated outdoors is ‘Spot heat’
 NOTE: Model IEP 1520 is for INDOOR USE ONLY
 Ensure that the heater model is suitable and approved for outdoor use
 Desired temperature rise:
 What is the coldest ambient air temperature that the design must consider?
 Then what comfort temperature rise is desired? (Indoor to 65°?) (Outdoor to …?)
 Calculate the required input to get the desired average temperature rise:
 Input = Site Length x Site Width x Temperature Rise x Heat Density per Degree
 Example: (use a heater approved for Outdoor use for outdoor applications)
 Outdoor Patio: 30 ft long by 10 feet wide
 Desired temperature rise: 20°F (average over the area)
 30 x 10 x 20 x 2 = 12,000 Watts total input required
 Compare the values of the available mounting height and area dimensions at the
project site to the recommended mounting heights, length and width of coverage
area, and typical average heat distribution in Figure 1 & Table 1 (next page)
 Layout:
 Space the heaters uniformly around the perimeter (and if required, in the center
or throughout the area) to provide sufficient heat density to accomplish the de-
sired temperature rise or spot heat only specific locations within the area
 Provide heat from at least two sides wherever possible
1Contact Schwank Design Services for assistance at [email protected].
Heat Density
per Degree F
w/(ft2)/F°
Heat Density
per Degree C
w/(m2)/C°
Outdoor Heating 2 40 Up to 10 mph wind
Indoor Spot Heat 0.75 14 Protected area - low air movement
Input Required per Area per Degree Comfort Temperature Rise

8 IM110526
RD: JUNE 2011
RL; 1A
BA
InfraSave IEP-1520 Manual
ft [m] ft [m] ft [m] ft [m] ft2[m2] watts / ft2
Min. 7 [2.1] 8.8 [2.7] 8.5 [2.6] 16 [4.9] 108 [10.1] 13.9
Max. 8 [2.4] 9.8 [3.0] 9.2 [2.8] 18 [5.5] 133 [12.4] 11.3
Min. 8 [2.4] 9.8 [3.0] 9.2 [2.8] 18 [5.5] 133 [12.4] 15.0
Max. 9 [2.7] 11 [3.4] 10 [3.0] 20 [6.1] 165 [15.3] 12.1
Min. 10 [3.0] 12 [3.6] 11.2 [3.4] 23 [7.0] 205 [19.0] 19.5
Max. 11.5 [3.5] 13.5 [4.1] 14 [4.3] 27.5 [8.4] 275 [25.4] 14.5
Min. 12 [3.7] 14 [4.3] 15 [4.6] 29.5 [9.0] 315 [29.2] 19.0
Max. 15 [4.6] 14.4 [4.4] 17.7 [5.4] 32 [9.8] 360 [33.4] 16.7
IEP 6024 6000
IEP 1520/4 1500
IEP 2024
E
A
verage Heat
Density
IEP 4024 4000
D
Heated
Area
2000
C
Outer
Perimeter
A
Distance
Out
B
Under
Heater
Min /
Max
Input
Watts
Model
.
H
Height Above
Floor/Deck
FIGURE 1: RECOMMENDED MOUNTING: COMFORT AREA COVERAGE
TABLE 1: RECOMMENDED MOUNTING FOR SAFETY AND COMFORT AREA COVERAGE
Angle of Heat Dispersion
The design information presented here is intended as a guideline. The accuracy of determin-
ing or estimating all factors above will affect performance and satisfaction. Air movement in
particular affects creature comfort.
 Refer to design guidelines on previous page.
 Refer to Required Minimum Clearances: Table 2 & Figure 2, Page 10

9 IM110526
RD: JUNE 2011
RL; 1A
BA
InfraSave IEP-1520 Manual
4. INSTALLATION INSTRUCTIONS
General: READ ALL INSTRUCTIONS AND PLAN THE INSTALLATION
BEFORE PROCEEDING
This appliance conforms to ANSI/UL 2021 and is certified to CAN/CSA C22.2 No.46. This ap-
pliance is approved for indoor use only. Do not use this heater outdoors or in wet environ-
ments such as bathrooms and laundry rooms.
The heater is supplied with an 8 ft [2.4 m] cord with a three prong plug that must connect to a
properly grounded 115 - 120 Vac outlet on a copper wire electrical supply circuit.
A mounting bracket is supplied with the heater, and can be mounted to a wall or post. The
heater must be mounted to this bracket during operation. Hardware to fasten the mounting
bracket to the structure is determined by site conditions, and is field supplied by the installer.
IMPORTANT: Always maintain the minimum clearances from the floor, ceiling,
side walls, and combustible materials. Refer to Table 2 and Figure 2 next page.
IMPORTANT: Avoid the use of an extension cord because the extension cord may
overheat and cause a risk of fire. However, if you must use an extension cord, the
cord shall be No. 14 AWG minimum size and rated not less than 1875 watts.
Locating the Heater:
Warning: Use of this heater in coastal salt-air regions can result in corrosion of the aluminum
body and reflector, and premature failure the heat lamp. Corrosion and failure resulting from
use in coastal areas represents normal use in that environment and is not covered by war-
ranty.
1. The heater is designed for wall or post mounting and operation with plug-in cord (8 ft [2.4
m]) connection and must be installed at least 6 feet (1.8 m) above the floor.
2. Ensure that clearances from the heater meet or exceed the minimum required clearances
in Table 2, and Figure 2 below: Above; to the Floor; to a Side wall; and to Combustible
materials.
3. The heater must plug in to a properly grounded 115 - 120 Vac outlet. Ensure the electrical
outlet is readily accessible to be able to disconnect the heater when needed.
4. The heater should never be placed nor mounted directly under a wall electrical outlet.
5. A minimum distance of 3 ft (36 inches) [90 cm] must be maintained between the front grille
and flammable items (e.g. curtains), walls and other structures.
6. Do not allow the electrical cord to pass in front of the heater or to touch any hot surface.
7. The appliance must not be mounted directly on flammable materials (no wood or similar).
8. Do not expose the heater to rain or other moisture.
9. Since the appliance radiates heat, no obstruction or object such as furniture should be
placed between the heater and the person being heated. continued ...

10 IM110526
RD: JUNE 2011
RL; 1A
BA
InfraSave IEP-1520 Manual
TABLE 2: MINIMUM REQUIRED CLEARANCES
IEP 1520 Above ‘A’
Inches [cm] Floor ‘F’ Inches [cm] Clearance ‘C’ Inches [cm]
1500 W, 115-120V, 60 Hz, 13 Amps 12” [30] 72” [180] 36” [90]
Spacing ‘D’
Inches [cm]
More than
36” [90]
10. Do not use heater on a soft surface, like a bed, where air openings may become blocked.
11. A heater has hot surfaces and potentially arcing or sparking parts inside. Do not use in
areas where gasoline, paint, or flammable vapors or liquids are used or stored.
Heater Mounting:
1. Mount the heater on a non-combustible surface or structural member, and maintain at
least all minimum clearances indicated in Table 2 and Figure 2 above.
2. Use the Mounting Bracket supplied with the heater - see Figure 3 next page.
3. Hardware to fasten the Mounting Bracket to the structure is field supplied by the installer
since the type of hardware fastening is determined by site conditions.
4. If at all possible, locate the mounting bracket so that the electrical cord (8 ft [2.4 m]) can
be plugged into an electrical outlet (grounded 115 - 120 Vac) without stretching the elec-
trical cord taught. See important notice (previous page) regarding the use of
LONG AXIS: HORIZONTAL
UP TO
45°
FIGURE 2: MINIMUM Required Clearances
MOUNT BRACKET TO STRUCTURAL MEMBER OF A
NON-COMBUSTIBLE WALL / SURFACE
DO NOT PLACE ANYTHING CLOSER THAN 3 ft (90 cm)
(CLEARANCE ‘C’) IN FRONT OF OR BELOW THE HEATER
CORD LENGTH 8 FT [2.4 m].
CONNECT TO A GROUNDED 120 Vac OUTLET.
ALLOW SLACK IN THE CORD - DO NOT PULL CORD TIGHT.
continued ...
D

11 IM110526
RD: JUNE 2011
RL; 1A
BA
InfraSave IEP-1520 Manual
an extension cord.
5. Never allow the electrical cord to pass in front of the heater or to come into contact with
any hot surface of the heater.
6. The Mounting Bracket fastens to the structure using field supplied bolts or lag screws
through two holes in one side of the bracket. The heater bracket fastens to the Mounting
Bracket through the outermost hole on the other leg of the Mounting Bracket, using the
bolt, lock washer and nut supplied.
7. Fasten the Mounting Bracket ‘plumb’ and level so that the heater is oriented horizontally
on the long axis.
8. Ensure that the mounting bracket is firmly fastened to the structure with bolts or lag
screws (field supplied) of sufficient strength and integrity to support the weight and pre-
vent movement of the heater. It is recommended to fasten the mounting bracket to a
structural member (wall stud, etc.).
9. Attach the heater bracket to the Mounting Bracket (outermost hole), using the bolt, lock
washer and nut supplied - tighten securely.
10. The bracket attached to the top of the heater allows rotation up to 45° on the short axis
by loosening the attachment bolt.
11. Once heater position is established, tighten all nuts and bolts at mounting and heater
bracket connections to maintain the heater in a secure and stable position.
12. Read and follow all warnings, and the following section on Operation to enjoy safe op-
eration of the heater.
FIGURE 3: MOUNTING BRACKET FIGURE 4:
END VIEW WITH
HEATER BRACKET

12 IM110526
RD: JUNE 2011
RL; 1A
BA
InfraSave IEP-1520 Manual
5. OPERATING INSTRUCTIONS
1. The heater must be properly installed prior to use.
2. Always ensure the heater is located at a safe distance from the floor, ceiling, side walls,
and combustible materials - refer to Table 2 and Figure 2.
3. Maintain a minimum distance of 36 inches [90 cm] from heater to combustible material.
4. Always be aware and careful of the risk of fire and electric shock.
5. The power cord must not come into contact with hot appliance parts or surfaces and
must not pass in front of the heater.
6. Never pull the plug out of the outlet using the cord. Grasp the plug directly to remove.
7. Never move the appliance by pulling at the cord or use the cord for carrying purposes.
8. Do not coil the cord around the appliance.
9. Do not use the appliance with the cord coiled.
10. Do not crush the cord, nor drag it over sharp edges, nor place it over a heated hotplate
or open flame.
11. Read, understand, and explain and describe to other users the location, function, and
operation of each control of the heater, including all user-operated devices intended to
reduce the risk of fire, electric shock, or injury to persons and warn against tampering
with such.
12. Connect the heater only to a grounded 115 - 120 Vac outlet. A time delayed fuse may be
necessary for circuit protection.
13. If the supply cord is damaged, it must be replaced by a qualified electrician in order to
avoid a hazard.
14. High heat is generated from the front of the heater.
15. Do not allow children to touch or play with the heater.
16. Do not use the heater to dry wet materials or clothing.
6. GROUNDING
This heater must be connected only to a properly grounded 115 - 120 Volt AC power outlet.
The cord has a 3 pronged plug as shown below in Figure 5.
If you do not have a grounded power outlet, DO NOT REMOVE the ground pin from the plug
- have a qualified electrician install a properly grounded outlet.
FIGURE 5: GROUNDED 115 - 120 Vac ELECTRICAL CONNECTION
3 Pronged Plug
with Ground Pin
Grounded
115 - 120 Vac Outlet

13 IM110526
RD: JUNE 2011
RL; 1A
BA
InfraSave IEP-1520 Manual
7. MAINTENANCE INSTRUCTIONS
WARNING
Heater service should only be performed by a qualified electrician. Fail-
ure to comply could result in personal injury, death, fire and/or property
damage.
Tampering with the heater by an unqualified person will void the warranty.
WARNING
Always unplug or disconnect the heater from the electrical power supply
prior to any cleaning, maintenance or service work.
Never immerse the appliance in water! Danger to life!
CAUTION: The Heat Lamp is fragile. Handle the heater with care so as
not to damage the Heat Lamp. Never touch the Lamp with bare fingers. Oils
from your skin will damage the Lamp.
Inspect the heater and cord prior to each use:
 Clean any accumulation of dust or dirt from surfaces and in particular from the reflector
and any air openings in the heater body (refer to Cleaning section below).
 Any damaged parts or components must be repaired or replaced prior to operation.
Service and Repair:
 Disconnect the heater from the power source prior to servicing
 Important: All repairs must be referred to qualified electrician!
 Repairs carried out improperly or by an unqualified person may have serious conse-
quences for the user!
 Any tampering with the appliance will invalidate the warranty.
8. CLEANING
 Before cleaning - Disconnect the heater from the power supply and allow to cool.
 Do not touch the Heat Lamp with your fingers - oil from your skin will damage the Lamp.
 To clean the heater surface, reflector, and air inlets: Use only a dry or damp cloth or
low pressure air stream (computer ‘duster’ in a can).
 Do not use any abrasive or caustic cleaning agents.
 Never immerse the appliance in water! Danger to life!
 If a heater is exposed to water have a qualified electrician inspect and repair the heater
prior to use.
 Inspect the electrical cord and plug for damage or fraying.
 Do not operate the heater with a damaged cord or plug.
 Have damaged parts replaced by a qualified electrician

14 IM110526
RD: JUNE 2011
RL; 1A
BA
InfraSave IEP-1520 Manual
9. HEATER PARTS
1 2
3
4
5
6
7
8
9 12 13
11
1. Heater Body - cast aluminum
2. Polished Aluminum Reflector Assembly
3. Protective Screen
4. Assembly Screws
5. End Covers
6. Face Plates
7. Heater Mounting Bracket
8. Center Cover Plate (top side)
9. Power Cord Retainer Plate
10.Terminal Block for electrical connections
11.Power Cord with factory assembled 3 Pronged Plug
12.Lamp Retainer Clips
13.Heat Lamp - 1500 Watts - Part # JE-1500-XX
10
FIGURE 6:
NOTE: Heater is shown with white
finish for clarity in photograph.
Actual heater has black finish.

15 IM110526
RD: JUNE 2011
RL; 1A
BA
InfraSave IEP-1520 Manual
ALWAYS WEAR COTTON OR OTHER FABRIC GLOVES WHEN REPLACING HEAT LAMP.
DO NOT TOUCH THE LAMP SURFACE WITH YOUR BARE HANDS - OILS FROM YOUR
SKIN WILL CAUSE DAMAGE TO THE LAMP.
The heater requires some disassembly to access electrical connections when replacing lamp.
Use a container to securely store disassembled components and screws.
Step 1
Compress the width of the protective screen to retract the
wire tabs from under one edge of the heater body.
Rotate the lose edge of the screen up and away from
heater body.
Pull the screen away from heater remove from other edge
of heater body - place safety screen in secure storage.
Step 2
Remove end cover at both ends of heater.
Six (6) Phillips screws hold the end cover in place.
Remove the screws to secure storage.
Step 3
Slide out the face plate at each end
of heater to expose both ends of the
heat lamp.
10. HEAT LAMP REPLACEMENT
The Heat Lamp will operate for approximately 5000 hours under normal conditions.
WARNING
Heater service should only be performed by a qualified electrician. Failure
to comply can result in personal injury, death, fire and property damage.
Always unplug or disconnect the heater from the electrical power supply
prior to any cleaning, maintenance or service work.

16 IM110526
RD: JUNE 2011
RL; 1A
BA
InfraSave IEP-1520 Manual
Heat Lamp Replacement:… continued
Step 4
Turn heater face down, and slide the center cover plate
and the heater mounting bracket out of the heater.
Step 5
Disconnect electrical supply cord spade connectors
from terminals.
Step 6
Disconnect ground wire (electrical supply cord) from the
heater body by removing the anchor screw from the eye
of the ground terminal.
Step 7
Slide power cord retainer plate from heater body.

17 IM110526
RD: JUNE 2011
RL; 1A
BA
InfraSave IEP-1520 Manual
Heat Lamp Replacement:… continued
Step 8
Turn heater face up.
Each end of the lamp has a rectangular retainer block.
Remove the stainless steel clips that secure the retainer
blocks at each end of the lamp.
Step 9
Pull the lamp wires up and out from the heater body at
each end of the lamp.
Step 10
Slide the lamp out through
the reflector end plate.
Properly and safely dis-
pose of lamp.
Step 11
The Heat Lamp is fragile - handle with care!
Wear gloves. Do not touch lamp with bare fingers! Oils from your skin will damage the lamp.
Install the new replacement lamp and reassemble heater in reverse order of steps above.

18 IM110526
RD: JUNE 2011
RL; 1A
BA
InfraSave IEP-1520 Manual
The Manufacturer warrants to the original consumer that this product is free from defects in material and/or
workmanship under normal use and service for a period of one year (12 months) from the date of pur-
chase, and subject to the conditions and limitations stated herein. Warning: Use of this heater in coastal
salt-air regions can result in corrosion of the aluminum body and reflector, and premature failure of the
heat lamp. Possible corrosion and failure resulting from use in coastal areas represents normal use in that
environment and is not covered by warranty.
ONE YEAR (12 Month) WARRANTY
Subject to the conditions and limitations stated herein and defined below, during the term of this limited
warranty, we will supply any component part of the heater, excluding any labor , which the Manufacturer’s
examination determines to be defective in workmanship or material for a period of one year (12 months)
from the date of purchase. This warranty applies to the heater’s original owner, and only if the unit is in-
stalled and operated in accordance with the printed instructions accompanying the unit and in compliance
with all applicable installation, building codes and good trade practices. Failure to maintain the equipment
through regular maintenance or service by a qualified service technician shall void the warranty.
WHAT IS NOT COVERED
The Manufacturer shall not be responsible for any expenses, including service, labor, diagnosis, analysis,
material or transportation/shipping charges incurred during removal, repair, or reinstallation of this product,
or any of its components or parts. All labor, shipping, and/or service charges shall be paid by the owner.
This warranty does not cover products that have been modified after leaving the factory, improperly in-
stalled, misused, exposed to abuse or damaged by acts of God, negligence, accident, corrosive or con-
taminated atmosphere, water, excessive thermal shock, impact, abrasion, normal wear due to use, altera-
tion or operation contrary to the owner’s manual or if the serial number has been altered, defaced or re-
moved. This warranty shall not apply if the voltage to the heater exceeds the rated voltage on the rating
plate by more than 10%. The Manufacturer shall not be liable for consequential damages arising out of, or
in connection with, the use or performance of the product, or other indirect damages with respect to loss of
property, revenues, or profit, or costs of removal, installation or reinstallation, or for any default or delay in
performance by its warranty caused by any contingency beyond its control, including war, government re-
strictions, or restraints, strikes, fire, flood, acts of God, or short or reduced supply of raw materials or prod-
ucts. WARRANTY PROCEDURE
To establish the date of purchase for any purpose under this Limited Warranty, you must retain the original
receipt that can establish the purchase date of your unit. If you do not provide such documents, the start
date of the term of this Limited Warranty will be based upon the date of unit manufacture, plus thirty (30)
days. Do not ship a heater back to InfraSave for repair. Contact your local supplier / installer of the
heater, or a local qualified electrician for warranty service or repair.
LIMITATIONS AND EXCLUSIONS
This document contains all warranties made by the Manufacturer and may not be varied, altered or ex-
tended by any person. There are no promises, or agreements extending from the Manufacture other than
the statements contained herein. THIS WARRANTY IS IN LIEU OF ALL WARRANTIES EXPRESSED OR
IMPLIED, TO THE EXTENT AUTHORIZED BY THE LAWS OF THE JURISDICTION, INCLUDING SPE-
CIFICALLY THE WARRANTIES OR MERCHANTIBILITY OF FITNESS FOR A PARTICULAR PURPOSE.
All warranties are limited in duration to 12 months.
It is understood and agreed that the Manufacturer’s obligation hereunder is limited to repairing or replacing
parts determined to be defective as stated above. In no event shall the Manufacturer be responsible for
any alleged personal injuries or other special, incidental or consequential damages. As to property dam-
ages, contract, tort or other claim the Manufacturer’s responsibility shall not exceed the purchase priced
paid for the product.
All replacement parts will be warranted for the unused portion of the warranty coverage period remaining
on the applicable unit.
Some States and authorities do not allow certain warranty exclusions or limitations on how long a warranty
lasts or the exclusions or limitations of incidental or consequential damages. In such cases, the above
limitations or exclusions may not apply to you and are not intended to do so where prohibited by law. This
warranty gives you specific legal rights. You may also have other rights which vary by each jurisdiction.
InfraSave IEP SERIES HEATERS - LIMITED WARRANTY CERTIFICATE
