Ingersoll-Rand P33N Series User manual

47626630001
Edition 2
July 2018
Save These Instructions
Product Information
EN Product Information
Especicaciones del producto
Spécications du produit
Προδιαγραφές προϊόντος
Especicações do Produto
Tuote-erittely
Produktspesikasjoner
Produktspecikationer
Produktspecikationer
Productspecicaties
Technische Produktdaten
Speciche prodotto
Ierices specikacijas
Gaminio techniniai duomenys
A termék jellemzői
Toote spetsikatsioon
Specikace výrobku
Špecikácie produktu
Specikacije izdelka
ES
FR
IT
DE
NL
DA
SV
NO
FI
PT
EL
SL
SK
제품 상세
製品仕様
产品信息
Технические характеристики изделия
Informacje Macje o Produkcie
PL
RU
ZH
JA
KO
Informaţii Privind Produsul
Информация за Продукта
BG
RO
LV
LT
HU
ET
CS
Podaci o proizvodu
HR
Air Drill
P33N Series (Angle)

2 47626630001_ed2
4
7
5
32
1
9
6
10
48h
1m
PMAX
10
1m
24h
8
6
PMAX
11
11
10
18h
11 18h
11 18h
18h
1m
6
PMAX
(Dwg. 16595274)
13
25
6
9
10
11
IR # - NPT IR # - BS inch (mm) NPT IR # IR # cm3IR # cm3
C38331-800 C383C1-800 3/8 (9) 1/4 10 90 3 90 3

47626630001_ed2 EN-1
EN
Product Safety Information
Intended Use:
These Air Drills are designed for drilling, honing, reaming and hole sawing.
For Additional information refer to Product Safety Information Manual Form 04580353.
Manuals can be downloaded from ingersollrandproducts.com
Product Specications
Models Angle
Free
Speed
Sound Level dB(A)
(ISO15744)
Vibration (m/s²)
(ISO28927)
rpm † Pressure (Lp) ‡ Power (Lw)Level *K
P33N006-DASL030P45 30° 660 75.5 --- 2.3 1.3
P33N006-DASL030P64 30° 660 75.5 --- 2.3 1.3
P33N006-DASL090P45 90° 660 75.5 --- 2.3 1.3
P33N006-DASL090P64 90° 660 75.5 --- 2.3 1.3
P33N006-DASL180P45 180° 660 75.5 --- 2.3 1.3
P33N006-DASL180P64 180° 660 75.5 --- 2.3 1.3
P33N011-DASL030P45 30° 1,100 75.5 --- 2.3 1.3
P33N011-DASL030P64 30° 1,100 75.5 --- 2.3 1.3
P33N011-DASL090P45 90° 1,100 75.5 --- 2.3 1.3
P33N011-DASL090P64 90° 1,100 75.5 --- 2.3 1.3
P33N011-DASL180P45 180° 1,100 75.5 --- 2.3 1.3
P33N011-DASL180P64 180° 1,100 75.5 --- 2.3 1.3
P33N016-DASL030P45 30° 1,600 75.5 --- 2.3 1.3
P33N016-DASL030P64 30° 1,600 75.5 --- 2.3 1.3
P33N016-DASL090P45 90° 1,600 75.5 --- 2.3 1.3
P33N016-DASL090P64 90° 1,600 75.5 --- 2.3 1.3
P33N016-DASL180P45 180° 1,600 75.5 --- 2.3 1.3
P33N016-DASL180P64 180° 1,600 75.5 --- 2.3 1.3
P33N022-DASL030P45 30° 2,200 75.5 --- 2.3 1.3
P33N022-DASL030P64 30° 2,200 75.5 --- 2.3 1.3
P33N022-DASL090P45 90° 2,200 75.5 --- 2.3 1.3
P33N022-DASL090P64 90° 2,200 75.5 --- 2.3 1.3
P33N022-DASL180P45 180° 2,200 75.5 --- 2.3 1.3
P33N022-DASL180P64 180° 2,200 75.5 --- 2.3 1.3
P33N032-DASL030P45 30° 3,200 75.5 --- 2.3 1.3
P33N032-DASL030P64 30° 3,200 75.5 --- 2.3 1.3
P33N032-DASL090P45 90° 3,200 75.5 --- 2.3 1.3
P33N032-DASL090P64 90° 3,200 75.5 --- 2.3 1.3
P33N032-DASL180P45 180° 3,200 75.5 --- 2.3 1.3
P33N032-DASL180P64 180° 3,200 75.5 --- 2.3 1.3
P33N054-DASL030P45 30° 5,400 75.5 --- 2.3 1.3
P33N054-DASL030P64 30° 5,400 75.5 --- 2.3 1.3
P33N054-DASL090P45 90° 5,400 75.5 --- 2.3 1.3
P33N054-DASL090P64 90° 5,400 75.5 --- 2.3 1.3
P33N054-DASL180P45 180° 5,400 75.5 --- 2.3 1.3
P33N054-DASL180P64 180° 5,400 75.5 --- 2.3 1.3
† KpA = 3dB measurement uncertainty
‡ KwA = 3dB measurement uncertainty
* K = Vibration measurement uncertainty

EN-2 47626630001_ed2
EN
WARNING
Sound and vibration values were measured in compliance with internationally recognized
test standards.The exposure to the user in a specic tool application may vary from these
results. Therefore, on site measurements should be used to determine the hazard level in
that specic application.
Installation and Lubrication
Size air supply line to ensure tool’s maximum operating pressure (PMAX) at tool inlet. Drain
condensate from valve(s) at low point(s) of piping, air lter and compressor tank daily. Install a
properly sized Safety Air Fuse upstream of hose and use an anti-whip device across any hose
coupling without internal shut-o, to prevent hose whipping if a hose fails or coupling
disconnects. See drawing 16595274 and table on page 2. Maintenance frequency is shown in a
circular arrow and dened as h=hours, d=days, and m=months of actual use. Items identied as:
1. Air lter 7. Coupling
2. Regulator 8. Safety Air Fuse
3. Lubricator 9. Oil
4. Emergency shut-o valve 10. Grease
5. Hose diameter 11. Grease
6. Thread size
Parts and Maintenance
When the life of the tool has expired, it is recommended that the tool be disassembled,
degreased and parts be separated by material so that they can be recycled.
Original instructions are in English. Other languages are a translation of the original instructions.
Tool repair and maintenance should only be carried out by an authorized Service Center.
Refer all communications to the nearest Ingersoll Rand Oce or Distributor.

47626630001_ed2 ES-1
ES
Información de Seguridad Sobre el Producto
Uso Indicado:
Estos taladros neumáticos están diseñados para taladrar, escariar y recticar oricios.Para más
información, consulte el formulario 04580353 del Manual de información de seguridad
del producto.
Los manuales pueden descargarse en ingersollrandproducts.com
Especicaciones del Producto
Modelo Angular
Velocidad
Libre
Nivel Sonoro dB(A)
(ISO15744)
Vibración (m/s²)
(ISO28927)
rpm † Presión (Lp) ‡ Potencia (Lw) Nivel *K
P33N006-DASL030P45 30° 660 75.5 --- 2.3 1.3
P33N006-DASL030P64 30° 660 75.5 --- 2.3 1.3
P33N006-DASL090P45 90° 660 75.5 --- 2.3 1.3
P33N006-DASL090P64 90° 660 75.5 --- 2.3 1.3
P33N006-DASL180P45 180° 660 75.5 --- 2.3 1.3
P33N006-DASL180P64 180° 660 75.5 --- 2.3 1.3
P33N011-DASL030P45 30° 1,100 75.5 --- 2.3 1.3
P33N011-DASL030P64 30° 1,100 75.5 --- 2.3 1.3
P33N011-DASL090P45 90° 1,100 75.5 --- 2.3 1.3
P33N011-DASL090P64 90° 1,100 75.5 --- 2.3 1.3
P33N011-DASL180P45 180° 1,100 75.5 --- 2.3 1.3
P33N011-DASL180P64 180° 1,100 75.5 --- 2.3 1.3
P33N016-DASL030P45 30° 1,600 75.5 --- 2.3 1.3
P33N016-DASL030P64 30° 1,600 75.5 --- 2.3 1.3
P33N016-DASL090P45 90° 1,600 75.5 --- 2.3 1.3
P33N016-DASL090P64 90° 1,600 75.5 --- 2.3 1.3
P33N016-DASL180P45 180° 1,600 75.5 --- 2.3 1.3
P33N016-DASL180P64 180° 1,600 75.5 --- 2.3 1.3
P33N022-DASL030P45 30° 2,200 75.5 --- 2.3 1.3
P33N022-DASL030P64 30° 2,200 75.5 --- 2.3 1.3
P33N022-DASL090P45 90° 2,200 75.5 --- 2.3 1.3
P33N022-DASL090P64 90° 2,200 75.5 --- 2.3 1.3
P33N022-DASL180P45 180° 2,200 75.5 --- 2.3 1.3
P33N022-DASL180P64 180° 2,200 75.5 --- 2.3 1.3
P33N032-DASL030P45 30° 3,200 75.5 --- 2.3 1.3
P33N032-DASL030P64 30° 3,200 75.5 --- 2.3 1.3
P33N032-DASL090P45 90° 3,200 75.5 --- 2.3 1.3
P33N032-DASL090P64 90° 3,200 75.5 --- 2.3 1.3
P33N032-DASL180P45 180° 3,200 75.5 --- 2.3 1.3
P33N032-DASL180P64 180° 3,200 75.5 --- 2.3 1.3
P33N054-DASL030P45 30° 5,400 75.5 --- 2.3 1.3
P33N054-DASL030P64 30° 5,400 75.5 --- 2.3 1.3
P33N054-DASL090P45 90° 5,400 75.5 --- 2.3 1.3

ES-2 47626630001_ed2
ES
Modelo Angular
Velocidad
Libre
Nivel Sonoro dB(A)
(ISO15744)
Vibración (m/s²)
(ISO28927)
rpm † Presión (Lp) ‡ Potencia (Lw) Nivel *K
P33N054-DASL090P64 90° 5,400 75.5 --- 2.3 1.3
P33N054-DASL180P45 180° 5,400 75.5 --- 2.3 1.3
P33N054-DASL180P64 180° 5,400 75.5 --- 2.3 1.3
† KpA = 3dB de error * K = de error (Vibración)
‡ KwA = 3dB de error
ADVERTENCIA
Los valores de ruido y vibración se han medido de acuerdo con los estándares para prue-
bas reconocidos internacionalmente. Es posible que la exposición del usuario en una apli-
cación especíca de herramienta diera de estos resultados. Por lo tanto, la mediciones in
situ se deberían utilizar para determinar el nivel de riesgo en esa aplicación especíca.
Instalación y Lubricación
Diseñe la línea de suministro de aire para asegurar la máxima presión de funcionamiento (PMAX)
en la entrada de la herramienta. Vacíe el condensado de las válvulas en los puntos inferiores de
la tubería, ltro de aire y depósito del compresor de forma diaria. Instale una contracorriente de
manguera de fusil de aire de seguridad de tamaño adecuado y utilice un dispositivo
antilatigazos en cualquier acoplamiento de manguera sin apagador interno para evitar que
las mangueras den latigazos en caso de que una manguera falle o de que el acoplamiento se
desconecte. Consulte la dibujo 16595274 y la tabla en la página 2. La frecuencia de
mantenimiento se muestra dentro de una echa circular y se dene como h = horas, d = días y
m = meses de uso real. Los elementos se identican como:
1. Filtro de aire 5. Diámetro de la manguera 9. Aceite
2. Regulador 6. Tamaño de la rosca 10. Grasa
3. Lubricador 7. Acoplamiento 11. Grasa
4. Válvula de corte de emergencia 8. Fusil de aire de seguridad
Piezas y Mantenimiento
Una vez agotada la vida útil de la herramienta, se recomienda desarmarla, desengrasarla y
agrupar las piezas en función del material del que están fabricadas para reciclarlas.
Las instrucciones originales están en inglés. Las demás versiones son una traducción de las
instrucciones originales.
Las labores de reparación y mantenimiento de las herramientas sólo puede ser realizadas por un
Centro de Servicio Autorizado.
Toda comunicación se deberá dirigir a la ocina o al distribuidor Ingersoll Rand más próximo.

47626630001_ed2 FR-1
FR
Informations de Sécurité du Produit
Utilisation Prévue:
Ces perceuses pneumatiques sont conçues pour les opérations de perçage, d’alésage et de
découpe circulaire.
Pour des informations complémentaires, utilisez le formulaire 04580353 pour obtenir le
manuel d’information de sécurité du produit Perceuse pneumatique.
Les manuels peuvent être téléchargés à l’adresse ingersollrandproducts.com
Spécications du Produit
Modèle Angle
Vitesse
Libre
Niveau Acoustique dB(A)
(ISO15744)
Vibration (m/s²)
(ISO28927)
t/m † Pression (Lp) ‡ Puissance (Lw) Niveau *K
P33N006-DASL030P45 30° 660 75.5 --- 2.3 1.3
P33N006-DASL030P64 30° 660 75.5 --- 2.3 1.3
P33N006-DASL090P45 90° 660 75.5 --- 2.3 1.3
P33N006-DASL090P64 90° 660 75.5 --- 2.3 1.3
P33N006-DASL180P45 180° 660 75.5 --- 2.3 1.3
P33N006-DASL180P64 180° 660 75.5 --- 2.3 1.3
P33N011-DASL030P45 30° 1,100 75.5 --- 2.3 1.3
P33N011-DASL030P64 30° 1,100 75.5 --- 2.3 1.3
P33N011-DASL090P45 90° 1,100 75.5 --- 2.3 1.3
P33N011-DASL090P64 90° 1,100 75.5 --- 2.3 1.3
P33N011-DASL180P45 180° 1,100 75.5 --- 2.3 1.3
P33N011-DASL180P64 180° 1,100 75.5 --- 2.3 1.3
P33N016-DASL030P45 30° 1,600 75.5 --- 2.3 1.3
P33N016-DASL030P64 30° 1,600 75.5 --- 2.3 1.3
P33N016-DASL090P45 90° 1,600 75.5 --- 2.3 1.3
P33N016-DASL090P64 90° 1,600 75.5 --- 2.3 1.3
P33N016-DASL180P45 180° 1,600 75.5 --- 2.3 1.3
P33N016-DASL180P64 180° 1,600 75.5 --- 2.3 1.3
P33N022-DASL030P45 30° 2,200 75.5 --- 2.3 1.3
P33N022-DASL030P64 30° 2,200 75.5 --- 2.3 1.3
P33N022-DASL090P45 90° 2,200 75.5 --- 2.3 1.3
P33N022-DASL090P64 90° 2,200 75.5 --- 2.3 1.3
P33N022-DASL180P45 180° 2,200 75.5 --- 2.3 1.3
P33N022-DASL180P64 180° 2,200 75.5 --- 2.3 1.3
P33N032-DASL030P45 30° 3,200 75.5 --- 2.3 1.3
P33N032-DASL030P64 30° 3,200 75.5 --- 2.3 1.3
P33N032-DASL090P45 90° 3,200 75.5 --- 2.3 1.3
P33N032-DASL090P64 90° 3,200 75.5 --- 2.3 1.3
P33N032-DASL180P45 180° 3,200 75.5 --- 2.3 1.3
P33N032-DASL180P64 180° 3,200 75.5 --- 2.3 1.3
P33N054-DASL030P45 30° 5,400 75.5 --- 2.3 1.3
P33N054-DASL030P64 30° 5,400 75.5 --- 2.3 1.3
P33N054-DASL090P45 90° 5,400 75.5 --- 2.3 1.3

FR-2 47626630001_ed2
FR
Modèle Angle
Vitesse
Libre
Niveau Acoustique dB(A)
(ISO15744)
Vibration (m/s²)
(ISO28927)
t/m † Pression (Lp) ‡ Puissance (Lw) Niveau *K
P33N054-DASL090P64 90° 5,400 75.5 --- 2.3 1.3
P33N054-DASL180P45 180° 5,400 75.5 --- 2.3 1.3
P33N054-DASL180P64 180° 5,400 75.5 --- 2.3 1.3
† KpA = incertitude de mesure de 3 dB * K = incertitude de mesure (Vibration)
‡ KwA = incertitude de mesure de 3 dB
AVERTISSEMENT
Les valeurs sonores et vibratoires ont été mesurées dans le respect des normes de tests
reconnues au niveau international. L’exposition de l’utilisateur lors d’une application
d’outil spécique peut diérer de ces résultats. Par conséquent, il faut utiliser des mesures
sur site an de déterminer le niveau de risque de cette application spécique.
Installation et Lubrication
Dimensionnez l’alimentation en air de façon à obtenir une pression maximale (PMAX) au niveau
de l’entrée d’air de l’outil. Drainez quotidiennement le condensat des vannes situées aux points
bas de la tuyauterie, du ltre à air et du réservoir du compresseur. Installez un raccordement à
air de sûreté dont la taille est adaptée au tuyau et placez-le en amont de celui-ci, puis utilisez
un dispositif anti-débattement sur tous les raccords pour tuyaux sans fermeture interne, an
d’empêcher les tuyaux de fouetter si l’un d’entre eux se décroche ou si le raccord se détache.
Reportez-vous à l’illustration 16595274 et au tableau de la page 2. La fréquence des opérations
d’entretien est indiquée dans la èche circulaire et est dénie en h=heures, d=jours, et m=mois
de fonctionnement. Eléments identiés en tant que:
1. Filtre à air 5. Diamètre du tuyau 9. Huile
2. Régulateur 6. Taille du letage 10. Graisse
3. Lubricateur 7. Raccord 11. Graisse
4. Vanne d’arrêt d’urgence 8. Raccordement à air de sûreté
Pièces Détachées et Maintenance
A la n de sa durée de vie, il est recommandé de démonter l’outil, de dégraisser les pièces et de
les séparer en fonction des matériaux de manière à ce que ces derniers puissent être recyclés.
Les instructions d’origine sont en anglais. Les autres langues sont une traduction des instructions
d’origine.
La réparation et la maintenance des outils ne devraient être réalisées que par un centre de
services autorisé.
Adressez toutes vos communications au Bureau Ingersoll Rand ou distributeur le plus proche.

47626630001_ed2 IT-1
IT
Informazioni Sulla Sicurezza del Prodotto
Uso Consentito:
I trapani pneumatici sono adatti per operazioni di foratura, levigatura, e forature con seghe.
Per ulteriori informazioni, consultare il modulo 04580353 del Manuale informazioni sulla
sicurezza prodotto relativo ai trapani pneumatici.
I manuali possono essere scaricati da internet al sito ingersollrandproducts.com
Speciche del Prodotto
Modelli Angolo
Velocità
a Vuoto
Livello Acustico dB(A)
(ISO15744)
Vibrazioni (m/s²)
(ISO28927)
giri al
minuto † Pressione (Lp) ‡ Potenza (Lw) Livello *K
P33N006-DASL030P45 30° 660 75.5 --- 2.3 1.3
P33N006-DASL030P64 30° 660 75.5 --- 2.3 1.3
P33N006-DASL090P45 90° 660 75.5 --- 2.3 1.3
P33N006-DASL090P64 90° 660 75.5 --- 2.3 1.3
P33N006-DASL180P45 180° 660 75.5 --- 2.3 1.3
P33N006-DASL180P64 180° 660 75.5 --- 2.3 1.3
P33N011-DASL030P45 30° 1,100 75.5 --- 2.3 1.3
P33N011-DASL030P64 30° 1,100 75.5 --- 2.3 1.3
P33N011-DASL090P45 90° 1,100 75.5 --- 2.3 1.3
P33N011-DASL090P64 90° 1,100 75.5 --- 2.3 1.3
P33N011-DASL180P45 180° 1,100 75.5 --- 2.3 1.3
P33N011-DASL180P64 180° 1,100 75.5 --- 2.3 1.3
P33N016-DASL030P45 30° 1,600 75.5 --- 2.3 1.3
P33N016-DASL030P64 30° 1,600 75.5 --- 2.3 1.3
P33N016-DASL090P45 90° 1,600 75.5 --- 2.3 1.3
P33N016-DASL090P64 90° 1,600 75.5 --- 2.3 1.3
P33N016-DASL180P45 180° 1,600 75.5 --- 2.3 1.3
P33N016-DASL180P64 180° 1,600 75.5 --- 2.3 1.3
P33N022-DASL030P45 30° 2,200 75.5 --- 2.3 1.3
P33N022-DASL030P64 30° 2,200 75.5 --- 2.3 1.3
P33N022-DASL090P45 90° 2,200 75.5 --- 2.3 1.3
P33N022-DASL090P64 90° 2,200 75.5 --- 2.3 1.3
P33N022-DASL180P45 180° 2,200 75.5 --- 2.3 1.3
P33N022-DASL180P64 180° 2,200 75.5 --- 2.3 1.3
P33N032-DASL030P45 30° 3,200 75.5 --- 2.3 1.3
P33N032-DASL030P64 30° 3,200 75.5 --- 2.3 1.3
P33N032-DASL090P45 90° 3,200 75.5 --- 2.3 1.3
P33N032-DASL090P64 90° 3,200 75.5 --- 2.3 1.3
P33N032-DASL180P45 180° 3,200 75.5 --- 2.3 1.3
P33N032-DASL180P64 180° 3,200 75.5 --- 2.3 1.3
P33N054-DASL030P45 30° 5,400 75.5 --- 2.3 1.3
P33N054-DASL030P64 30° 5,400 75.5 --- 2.3 1.3
P33N054-DASL090P45 90° 5,400 75.5 --- 2.3 1.3

IT-2 47626630001_ed2
IT
Modelli Angolo
Velocità
a Vuoto
Livello Acustico dB(A)
(ISO15744)
Vibrazioni (m/s²)
(ISO28927)
giri al
minuto † Pressione (Lp) ‡ Potenza (Lw) Livello *K
P33N054-DASL090P64 90° 5,400 75.5 --- 2.3 1.3
P33N054-DASL180P45 180° 5,400 75.5 --- 2.3 1.3
P33N054-DASL180P64 180° 5,400 75.5 --- 2.3 1.3
† KpA = incertezza misurazione 3dB * K = incertezza misurazione (Vibrazioni)
‡ KwA = incertezza misurazione 3dB
AVVERTIMENTO
I valori relativi a suoni e vibrazioni sono stati misurati in conformità agli standard di test
riconosciuti a livello internazionale. L’esposizione all’utente nell’applicazione di uno
specico strumento può variare rispetto ai presenti risultati. Pertanto, sarebbe necessario
utilizzare le misurazioni in loco per determinare il livello di pericolo della specica ap-
plicazione.
Installazione e Lubricazione
La linea di alimentazione dell’aria deve essere dimensionata in maniera tale da assicurare
all’utensile la massima pressione di esercizio (PMAX) in ingresso. Scaricare quotidianamente la con-
densa dalla valvola o dalle valvole sulla parte bassa della tubatura, dal ltro dell’aria e dal serbatoio
del compressore. Installare un fusibile di sicurezza di dimensioni adatte a monte del tubo essibile
e utilizzare un dispositivo antivibrazioni su tutti i manicotti senza arresto interno per evitare i colpi
di frusta dei essibili, se questi si guastano o se si staccano gli accoppiamenti. Vedere il disegno
16595274 e la tabella a pagina 2. La frequenza di manutenzione viene illustrata da una freccia
circolare e denita con h=ore, d=giorni (days) e m=mesi di uso eettivo. Componenti:
1. Filtro aria 7. Accoppiamento
2. Regolatore 8. Fusibile di sicurezza
3. Lubricatore 9. Olio
4. Valvola di arresto di emergenza 10. Ingrassaggio
5. Diametro tubo essibile 11. Ingrassaggio
6. Dimensione della lettatura
Ricambi e Manutenzione
Quando l’attrezzo diventato inutilizzabile, si raccomanda di smontarlo, sgrassarlo e separare i
componenti secondo i materiali in modo da poterli riciclare.
Le istruzioni originali sono in lingua inglese. Le altre lingue sono una traduzione delle istruzioni
originali.
Riparazioni e manutenzione degli utensili devono essere eseguite esclusivamente da un Centro
di Assistenza Autorizzato.
Indirizzare tutte le comunicazioni al più vicino concessionario od ucio Ingersoll Rand.

47626630001_ed2 DE-1
DE
Hinweise zur Produktsicherheit
Vorgesehene Verwendung:
Diese Druckluft-Bohrmaschinen wurden zum Bohren, Honen, Ausbohren und Lochsägen
entwickelt.
Für zusätzliche Informationen siehe das Formblatt 04580353 im Handbuch,
Produktsicherheitsinformationen Druckluft-Bohrmaschinen.
Handbücher können von ingersollrandproducts.com heruntergeladen werden.
Technische Produktdaten
Modelle Winkel
Nenn-
drehzahl
Schallpegel dB(A)
(ISO15744)
Schwingungs (m/s²)
(ISO28927)
U/min † Druck (Lp) ‡ Stromzufuhr (Lw) Spegel *K
P33N006-DASL030P45 30° 660 75.5 --- 2.3 1.3
P33N006-DASL030P64 30° 660 75.5 --- 2.3 1.3
P33N006-DASL090P45 90° 660 75.5 --- 2.3 1.3
P33N006-DASL090P64 90° 660 75.5 --- 2.3 1.3
P33N006-DASL180P45 180° 660 75.5 --- 2.3 1.3
P33N006-DASL180P64 180° 660 75.5 --- 2.3 1.3
P33N011-DASL030P45 30° 1,100 75.5 --- 2.3 1.3
P33N011-DASL030P64 30° 1,100 75.5 --- 2.3 1.3
P33N011-DASL090P45 90° 1,100 75.5 --- 2.3 1.3
P33N011-DASL090P64 90° 1,100 75.5 --- 2.3 1.3
P33N011-DASL180P45 180° 1,100 75.5 --- 2.3 1.3
P33N011-DASL180P64 180° 1,100 75.5 --- 2.3 1.3
P33N016-DASL030P45 30° 1,600 75.5 --- 2.3 1.3
P33N016-DASL030P64 30° 1,600 75.5 --- 2.3 1.3
P33N016-DASL090P45 90° 1,600 75.5 --- 2.3 1.3
P33N016-DASL090P64 90° 1,600 75.5 --- 2.3 1.3
P33N016-DASL180P45 180° 1,600 75.5 --- 2.3 1.3
P33N016-DASL180P64 180° 1,600 75.5 --- 2.3 1.3
P33N022-DASL030P45 30° 2,200 75.5 --- 2.3 1.3
P33N022-DASL030P64 30° 2,200 75.5 --- 2.3 1.3
P33N022-DASL090P45 90° 2,200 75.5 --- 2.3 1.3
P33N022-DASL090P64 90° 2,200 75.5 --- 2.3 1.3
P33N022-DASL180P45 180° 2,200 75.5 --- 2.3 1.3
P33N022-DASL180P64 180° 2,200 75.5 --- 2.3 1.3
P33N032-DASL030P45 30° 3,200 75.5 --- 2.3 1.3
P33N032-DASL030P64 30° 3,200 75.5 --- 2.3 1.3
P33N032-DASL090P45 90° 3,200 75.5 --- 2.3 1.3
P33N032-DASL090P64 90° 3,200 75.5 --- 2.3 1.3
P33N032-DASL180P45 180° 3,200 75.5 --- 2.3 1.3
P33N032-DASL180P64 180° 3,200 75.5 --- 2.3 1.3
P33N054-DASL030P45 30° 5,400 75.5 --- 2.3 1.3
P33N054-DASL030P64 30° 5,400 75.5 --- 2.3 1.3
P33N054-DASL090P45 90° 5,400 75.5 --- 2.3 1.3

DE-2 47626630001_ed2
DE
Modelle Winkel
Nenn-
drehzahl
Schallpegel dB(A)
(ISO15744)
Schwingungs (m/s²)
(ISO28927)
U/min † Druck (Lp) ‡ Stromzufuhr (Lw) Spegel *K
P33N054-DASL090P64 90° 5,400 75.5 --- 2.3 1.3
P33N054-DASL180P45 180° 5,400 75.5 --- 2.3 1.3
P33N054-DASL180P64 180° 5,400 75.5 --- 2.3 1.3
† KpA = 3dB Messunsicherheit * K = Messunsicherheit (Schwingungs)
‡ KwA = 3dB Messunsicherheit
WARNUNG
Schall- und Vibrationswerte wurden gemäß den international anerkannten Teststandards
gemessen. Die tatsächlichen Werte, denen der Benutzer während der Anwendung eines
bestimmten Werkzeugs ausgesetzt ist, können von diesen Ergebnissen abweichen. Vor
Ort sollten daher Maßnahmen getroen werden, um die Gefahrenstufe der jeweiligen
Anwendung zu bestimmen.
Montage und Schmierung
Druckluftzufuhrleitung an der Druckluftzufuhr des Werkzeugs gemäß des maximalen
Betriebsdrucks (PMAX) bemessen. Kondensat an den Ventilen an Tiefpunkten von Leitungen,
Luftlter und Kompressortank täglich ablassen. Eine Sicherheits-Druckluftsicherung gegen die
Strömungsrichtung im Schlauch und eine Anti-Schlagvorrichtung an jeder Verbindung ohne
interne Sperre installieren, um ein Peitschen des Schlauchs zu verhindern, wenn ein Schlauch
fehlerhaft ist oder sich eine Verbindung löst. Siehe Zeichnung 16595274 und Tabelle auf
Seite 2. Die Wartungshäugkeit mit einem Pfeil eingekreist und ist deniert in h=Stunden,
d=Tagen und m=Monaten der tatsächlichen Verwendung.Teile:
1. Luftlter 5. Schlauchdurchmesser 9. Ölen
2. Regler 6. Gewindegröße 10. Fetten
3. Schmierbüchse 7. Verbindung 11. Fetten
4. Notabsperrventil 8. Sicherheits-Druckluftsicherung
Teile und Wartung
Zur Entsorgung ist das Werkzeug vollständig zu demontieren, zu entfetten und nach
Materialarten getrennt der Wiederverwertung zuzuführen.
Die Originalanleitung ist in englischer Sprache verfasst. Bei anderen Sprachen handelt es sich um
ein Übersetzung der Originalanleitung.
Die Werkzeug-Reparatur und -Wartung darf nur von einem autorisierten Wartungszentrum
durchgeführt werden.
Wenden Sie sich bei Rückfragen an Ihre nächste Ingersoll Rand Niederlassung oder den
autorisierten Fachhandel.

47626630001_ed2 NL-1
NL
Productveiligheidsinformatie
Bedoeld Gebruik:
Deze pneumatische boormachines zijn bedoeld voor boren, honen, naboren en gaten zagen.
Raadpleeg formulier 04580353 in de productveiligheidshandleiding van de pneumatische
boormachines voor aanvullende informatie.
Handleidingen kunnen worden gedownload vanaf ingersollrandproducts.com
Produktspesikasjoner
Model Haaks
Onbelast
Toerental
Geluidsniveau dB(A)
(ISO15744)
Trillings (m/s²)
(ISO28927)
omw/min † Druk (Lp)‡ Vermogen (Lw) Niveau *K
P33N006-DASL030P45 30° 660 75.5 --- 2.3 1.3
P33N006-DASL030P64 30° 660 75.5 --- 2.3 1.3
P33N006-DASL090P45 90° 660 75.5 --- 2.3 1.3
P33N006-DASL090P64 90° 660 75.5 --- 2.3 1.3
P33N006-DASL180P45 180° 660 75.5 --- 2.3 1.3
P33N006-DASL180P64 180° 660 75.5 --- 2.3 1.3
P33N011-DASL030P45 30° 1,100 75.5 --- 2.3 1.3
P33N011-DASL030P64 30° 1,100 75.5 --- 2.3 1.3
P33N011-DASL090P45 90° 1,100 75.5 --- 2.3 1.3
P33N011-DASL090P64 90° 1,100 75.5 --- 2.3 1.3
P33N011-DASL180P45 180° 1,100 75.5 --- 2.3 1.3
P33N011-DASL180P64 180° 1,100 75.5 --- 2.3 1.3
P33N016-DASL030P45 30° 1,600 75.5 --- 2.3 1.3
P33N016-DASL030P64 30° 1,600 75.5 --- 2.3 1.3
P33N016-DASL090P45 90° 1,600 75.5 --- 2.3 1.3
P33N016-DASL090P64 90° 1,600 75.5 --- 2.3 1.3
P33N016-DASL180P45 180° 1,600 75.5 --- 2.3 1.3
P33N016-DASL180P64 180° 1,600 75.5 --- 2.3 1.3
P33N022-DASL030P45 30° 2,200 75.5 --- 2.3 1.3
P33N022-DASL030P64 30° 2,200 75.5 --- 2.3 1.3
P33N022-DASL090P45 90° 2,200 75.5 --- 2.3 1.3
P33N022-DASL090P64 90° 2,200 75.5 --- 2.3 1.3
P33N022-DASL180P45 180° 2,200 75.5 --- 2.3 1.3
P33N022-DASL180P64 180° 2,200 75.5 --- 2.3 1.3
P33N032-DASL030P45 30° 3,200 75.5 --- 2.3 1.3
P33N032-DASL030P64 30° 3,200 75.5 --- 2.3 1.3
P33N032-DASL090P45 90° 3,200 75.5 --- 2.3 1.3
P33N032-DASL090P64 90° 3,200 75.5 --- 2.3 1.3
P33N032-DASL180P45 180° 3,200 75.5 --- 2.3 1.3
P33N032-DASL180P64 180° 3,200 75.5 --- 2.3 1.3
P33N054-DASL030P45 30° 5,400 75.5 --- 2.3 1.3
P33N054-DASL030P64 30° 5,400 75.5 --- 2.3 1.3
P33N054-DASL090P45 90° 5,400 75.5 --- 2.3 1.3
P33N054-DASL090P64 90° 5,400 75.5 --- 2.3 1.3

NL-2 47626630001_ed2
NL
Model Haaks
Onbelast
Toerental
Geluidsniveau dB(A)
(ISO15744)
Trillings (m/s²)
(ISO28927)
omw/min † Druk (Lp)‡ Vermogen (Lw) Niveau *K
P33N054-DASL180P45 180° 5,400 75.5 --- 2.3 1.3
P33N054-DASL180P64 180° 5,400 75.5 --- 2.3 1.3
† KpA = 3dB meetonnauwkeurigheid * Meetonnauwkeurigheid bij K (Trillings)
‡ KwA = 3dB meetonnauwkeurigheid
WAARSCHUWING
Geluids- en vibratiewaarden worden gemeten in overeenstemming met internationaal
erkende testnormen. De blootstelling van een gebruiker bij een specieke toepassing van
gereedschap kan afwijken van deze resultaten. Daarom moeten er op locatie metingen
worden genomen om het gevaarniveau in die specieke toepassing te bepalen.
Installatie en Smering
Om de maximale bedrijfsdruk ( PMAX) bij de luchtinlaat van het toestel te garanderen, moet
de luchttoevoerleiding hierop geselecteerd zijn. Tap dagelijks condensaat af van kleppen bij
lage punten van het leidingwerk, de luchtlter en de compressortank. Monteer een beveiliging
met de juiste afmeting bovenstrooms van de slang en gebruik een antislingerinrichting op
elke slangkoppeling zonder interne afsluiter om te voorkomen dat de slang gaat slingeren
als een slang valt of een koppeling losraakt. Zie tekening 16595274 en tabel op pagina 2. De
onderhoudsfrequentie wordt weergegeven in een cirkelvormige pijl met h=uren, d=dagen en
m=maanden reëel gebruik. Aangegeven onderdelen:
1. Luchtlter 5. Slangdiameter 9. Olie
2. Regelaar 6. Soort van schroefdraad 10. Smeren
3. Smeerinrichting 7. Koppeling 11. Smeren
4. Noodafsluitklep 8. Beveiliging
Onderdelen en Onderhoud
Wanneer de levensduur van het gereedschap verstreken is, wordt u aangeraden het
gereedschap te demonteren en ontvetten, en de delen gescheiden naar materialen op te bergen
zodat zij gerecycled kunnen worden.
De originele instructies zijn opgesteld in het Engels. Andere talen zijn een vertaling van de
originele instructies.
Reparatie en onderhoud van dit gereedschap mogen uitsluitend door een erkend
servicecentrum worden uitgevoerd.
Voor alle communicatie wendt u zich tot de dichtstbijzijnde Ingersoll Rand vestiging of dealer.

47626630001_ed2 DA-1
DA
Produktsikkerhedsinformation
Anvendelsesområder:
Trykluftsborene er udformet til boring, honing, fræsning og hulsavning.
For yderligere oplysninger henvises der til formular 04580353 i vejledningen med
produktsikkerhedsinformation til trykluftsborene.
Vejledningerne kan hentes ned fra ingersollrandproducts.com
Produktspecikationer
Model Vinkel Fri Hastighed Lydniveau dB(A)
(ISO15744)
Vibrations (m/s²)
(ISO28927)
o/min. † Tryk (Lp) ‡ Eekt (Lw) Niveau *K
P33N006-DASL030P45 30° 660 75.5 --- 2.3 1.3
P33N006-DASL030P64 30° 660 75.5 --- 2.3 1.3
P33N006-DASL090P45 90° 660 75.5 --- 2.3 1.3
P33N006-DASL090P64 90° 660 75.5 --- 2.3 1.3
P33N006-DASL180P45 180° 660 75.5 --- 2.3 1.3
P33N006-DASL180P64 180° 660 75.5 --- 2.3 1.3
P33N011-DASL030P45 30° 1,100 75.5 --- 2.3 1.3
P33N011-DASL030P64 30° 1,100 75.5 --- 2.3 1.3
P33N011-DASL090P45 90° 1,100 75.5 --- 2.3 1.3
P33N011-DASL090P64 90° 1,100 75.5 --- 2.3 1.3
P33N011-DASL180P45 180° 1,100 75.5 --- 2.3 1.3
P33N011-DASL180P64 180° 1,100 75.5 --- 2.3 1.3
P33N016-DASL030P45 30° 1,600 75.5 --- 2.3 1.3
P33N016-DASL030P64 30° 1,600 75.5 --- 2.3 1.3
P33N016-DASL090P45 90° 1,600 75.5 --- 2.3 1.3
P33N016-DASL090P64 90° 1,600 75.5 --- 2.3 1.3
P33N016-DASL180P45 180° 1,600 75.5 --- 2.3 1.3
P33N016-DASL180P64 180° 1,600 75.5 --- 2.3 1.3
P33N022-DASL030P45 30° 2,200 75.5 --- 2.3 1.3
P33N022-DASL030P64 30° 2,200 75.5 --- 2.3 1.3
P33N022-DASL090P45 90° 2,200 75.5 --- 2.3 1.3
P33N022-DASL090P64 90° 2,200 75.5 --- 2.3 1.3
P33N022-DASL180P45 180° 2,200 75.5 --- 2.3 1.3
P33N022-DASL180P64 180° 2,200 75.5 --- 2.3 1.3
P33N032-DASL030P45 30° 3,200 75.5 --- 2.3 1.3
P33N032-DASL030P64 30° 3,200 75.5 --- 2.3 1.3
P33N032-DASL090P45 90° 3,200 75.5 --- 2.3 1.3
P33N032-DASL090P64 90° 3,200 75.5 --- 2.3 1.3
P33N032-DASL180P45 180° 3,200 75.5 --- 2.3 1.3
P33N032-DASL180P64 180° 3,200 75.5 --- 2.3 1.3
P33N054-DASL030P45 30° 5,400 75.5 --- 2.3 1.3
P33N054-DASL030P64 30° 5,400 75.5 --- 2.3 1.3
P33N054-DASL090P45 90° 5,400 75.5 --- 2.3 1.3

DA-2 47626630001_ed2
DA
Model Vinkel Fri Hastighed Lydniveau dB(A)
(ISO15744)
Vibrations (m/s²)
(ISO28927)
o/min. † Tryk (Lp) ‡ Eekt (Lw) Niveau *K
P33N054-DASL090P64 90° 5,400 75.5 --- 2.3 1.3
P33N054-DASL180P45 180° 5,400 75.5 --- 2.3 1.3
P33N054-DASL180P64 180° 5,400 75.5 --- 2.3 1.3
† KpA = 3dB måleusikkerhed * K = måleusikkerhed (Vibrations)
‡ KwA = 3dB måleusikkerhed
ADVARSEL
Lyd- og vibrationsværdier blev målt i overensstemmelse med internationalt anerkendte
teststandarder. Brugerens eksponering under en specik værktøjsanvendelse kan adskille
sig fra disse resultater. Derfor bør der anvendes stedspecikke målinger til at bedømme
fareniveauet for denne specikke anvendelse.
Installation og Smøring
Sørg for at lufttilførselsledningen har den korrekte størrelse for at sikre maksimalt driftstryk
(PMAX) ved værktøjsindgangen. Tøm dagligt ventilen(-erne) for kondensat ved rørenes,
luftlterets og kompressortankens lavpunkt(er). Montér en sikkerhedstryksikring i korrekt
størrelse i opadgående slange og brug en anti-piskeanordning tværs over enhver slangekobling
uden intern aukning for at forhindre at slangen pisker, hvis en slange svigter eller kobling
adskilles. Se tegning 16595274 og tabel på side 2. Vedligeholdelseshyppigheden vises med
en rund pil og deneres som t=timer, d=dage og m=måneder for reel brug. Elementerne er
identiceret som:
1. Luftlter 5. Slangediameter 9. Olie
2. Regulator 6. Gevindstørrelse 10.Fedt
3. Smøreapparat 7. Kobling 11.Fedt
4. Nødafspærringsventil 8. Sikkerhedstryksikring
Reservedele og Vedligeholdelse
Efter værktøjets levetid anbefales det at demontere og aedte værktøjet, og opdele de adskilte
komponenter ud fra materialetypen, så de kan genbruges.
Den originale vejledning er på engelsk. Andre sprog er en oversættelse af den originale vejledn-
ing.
Reparationsarbejde og vedligeholdelse må kun udføres af et autoriseret servicecenter.
Al korrespondance bedes stilet til Ingersoll Rands nærmeste kontor eller distributør.

47626630001_ed2 SV-1
SV
Produktsäkerhetsinformation
Avsedd Användning:
Dessa luftdrivna borrmaskiner är utformade för borrning, honing, brotschning och
hålsågning.
För mer information, se Luftdrivna borrmaskiners produktsäkerhetsinformation
Form 04580353.
Handböcker kan laddas ner från ingersollrandproducts.com
Produktspecikationer
Model Vinkel
Fri
Hastighet
Ljudstyrkenivå dB(A)
(ISO15744)
Vibrations (m/s²)
(ISO28927)
varv/min † Tryck (Lp) ‡ Eekt (Lw)Niva *K
P33N006-DASL030P45 30° 660 75.5 --- 2.3 1.3
P33N006-DASL030P64 30° 660 75.5 --- 2.3 1.3
P33N006-DASL090P45 90° 660 75.5 --- 2.3 1.3
P33N006-DASL090P64 90° 660 75.5 --- 2.3 1.3
P33N006-DASL180P45 180° 660 75.5 --- 2.3 1.3
P33N006-DASL180P64 180° 660 75.5 --- 2.3 1.3
P33N011-DASL030P45 30° 1,100 75.5 --- 2.3 1.3
P33N011-DASL030P64 30° 1,100 75.5 --- 2.3 1.3
P33N011-DASL090P45 90° 1,100 75.5 --- 2.3 1.3
P33N011-DASL090P64 90° 1,100 75.5 --- 2.3 1.3
P33N011-DASL180P45 180° 1,100 75.5 --- 2.3 1.3
P33N011-DASL180P64 180° 1,100 75.5 --- 2.3 1.3
P33N016-DASL030P45 30° 1,600 75.5 --- 2.3 1.3
P33N016-DASL030P64 30° 1,600 75.5 --- 2.3 1.3
P33N016-DASL090P45 90° 1,600 75.5 --- 2.3 1.3
P33N016-DASL090P64 90° 1,600 75.5 --- 2.3 1.3
P33N016-DASL180P45 180° 1,600 75.5 --- 2.3 1.3
P33N016-DASL180P64 180° 1,600 75.5 --- 2.3 1.3
P33N022-DASL030P45 30° 2,200 75.5 --- 2.3 1.3
P33N022-DASL030P64 30° 2,200 75.5 --- 2.3 1.3
P33N022-DASL090P45 90° 2,200 75.5 --- 2.3 1.3
P33N022-DASL090P64 90° 2,200 75.5 --- 2.3 1.3
P33N022-DASL180P45 180° 2,200 75.5 --- 2.3 1.3
P33N022-DASL180P64 180° 2,200 75.5 --- 2.3 1.3
P33N032-DASL030P45 30° 3,200 75.5 --- 2.3 1.3
P33N032-DASL030P64 30° 3,200 75.5 --- 2.3 1.3
P33N032-DASL090P45 90° 3,200 75.5 --- 2.3 1.3
P33N032-DASL090P64 90° 3,200 75.5 --- 2.3 1.3
P33N032-DASL180P45 180° 3,200 75.5 --- 2.3 1.3
P33N032-DASL180P64 180° 3,200 75.5 --- 2.3 1.3
P33N054-DASL030P45 30° 5,400 75.5 --- 2.3 1.3
P33N054-DASL030P64 30° 5,400 75.5 --- 2.3 1.3
P33N054-DASL090P45 90° 5,400 75.5 --- 2.3 1.3

SV-2 47626630001_ed2
SV
Model Vinkel
Fri
Hastighet
Ljudstyrkenivå dB(A)
(ISO15744)
Vibrations (m/s²)
(ISO28927)
varv/min † Tryck (Lp) ‡ Eekt (Lw)Niva *K
P33N054-DASL090P64 90° 5,400 75.5 --- 2.3 1.3
P33N054-DASL180P45 180° 5,400 75.5 --- 2.3 1.3
P33N054-DASL180P64 180° 5,400 75.5 --- 2.3 1.3
† KpA = 3dB mätosäkerhet * K = mätosäkerhet (Vibrations)
‡ KwA = 3dB mätosäkerhet
VARNING
Värden för ljud och vibrationer har mätts upp i enlighet med etablerade internationella
teststandarder. Användarens exponering vid en viss användning av ett verktyg kan skilja
sig från dessa resultat. Därför bör mätningar göras på plats för att bedöma risken vid den
specika användningen.
Installation och Smörjning
Dimensionera luftledningen för att säkerställa maximalt driftstryck (PMAX) vid verktygets
ingångsanslutning. Dränera dagligen kondens från ventiler placerade vid ledningens lägsta
punkter, luftlter och kompressortank. Installera en säkerhetsventil av lämplig storlek uppström
från slangen och använd en anti-ryckenhet över alla slangkopplingar som saknar intern
avstängning, för att motverka att slangen rycker till och en slang går sönder eller koppling lossar.
Se illustrationen 16595274 och tabellen på sidan 2. Underhållsintervallen visas i runda pilar och
denieras som h=timmar, d=dagar och m=månader av faktisk brukstid. Posterna denieras som:
1. Luftlter 7. Koppling
2. Regulator 8. Säkerhetsventil
3. Smörjare 9. Olja
4. Nödstoppsventil 10. Fett
5. Slangdiameter 11. Fett
6. Gängdimension
Delar och Underhåll
Då verktyget är utslitet, rekommenderar vi att det tas isär och avfettas, samt att de olika delarna
sorteras för återvinning.
Originalinstruktionerna är skrivna på engelska. Andra språk utgör en översättning av originalin-
struktionerna.
Reparation och underhåll av verktygen får endast utföras av ett auktoriserat servicecenter.
Alla förfrågningar bör ske till närmaste Ingersoll Rand kontor eller distributör.

47626630001_ed2 NO-1
NO
Sikkerhetsinformasjon for Produktet
Tiltenkt Bruk:
Trykkluftsbor er designet til boring, honing, opprømming og hullsaging.
For ytterligere informasjon henvises det til produktsikkerhetsinformasjonen i
trykkluftsborets håndboksskjema 04580353.
Håndbøker kan lastes ned fra ingersollrandproducts.com
Produktspesikasjoner
Model Vinkel
Fri
Hastighet
Lydnivå dB(A)
(ISO15744)
Vibrasjons (m/s²)
(ISO28927)
rpm † Trykk (Lp) ‡ Styrke (Lw)Nivå *K
P33N006-DASL030P45 30° 660 75.5 --- 2.3 1.3
P33N006-DASL030P64 30° 660 75.5 --- 2.3 1.3
P33N006-DASL090P45 90° 660 75.5 --- 2.3 1.3
P33N006-DASL090P64 90° 660 75.5 --- 2.3 1.3
P33N006-DASL180P45 180° 660 75.5 --- 2.3 1.3
P33N006-DASL180P64 180° 660 75.5 --- 2.3 1.3
P33N011-DASL030P45 30° 1,100 75.5 --- 2.3 1.3
P33N011-DASL030P64 30° 1,100 75.5 --- 2.3 1.3
P33N011-DASL090P45 90° 1,100 75.5 --- 2.3 1.3
P33N011-DASL090P64 90° 1,100 75.5 --- 2.3 1.3
P33N011-DASL180P45 180° 1,100 75.5 --- 2.3 1.3
P33N011-DASL180P64 180° 1,100 75.5 --- 2.3 1.3
P33N016-DASL030P45 30° 1,600 75.5 --- 2.3 1.3
P33N016-DASL030P64 30° 1,600 75.5 --- 2.3 1.3
P33N016-DASL090P45 90° 1,600 75.5 --- 2.3 1.3
P33N016-DASL090P64 90° 1,600 75.5 --- 2.3 1.3
P33N016-DASL180P45 180° 1,600 75.5 --- 2.3 1.3
P33N016-DASL180P64 180° 1,600 75.5 --- 2.3 1.3
P33N022-DASL030P45 30° 2,200 75.5 --- 2.3 1.3
P33N022-DASL030P64 30° 2,200 75.5 --- 2.3 1.3
P33N022-DASL090P45 90° 2,200 75.5 --- 2.3 1.3
P33N022-DASL090P64 90° 2,200 75.5 --- 2.3 1.3
P33N022-DASL180P45 180° 2,200 75.5 --- 2.3 1.3
P33N022-DASL180P64 180° 2,200 75.5 --- 2.3 1.3
P33N032-DASL030P45 30° 3,200 75.5 --- 2.3 1.3
P33N032-DASL030P64 30° 3,200 75.5 --- 2.3 1.3
P33N032-DASL090P45 90° 3,200 75.5 --- 2.3 1.3
P33N032-DASL090P64 90° 3,200 75.5 --- 2.3 1.3
P33N032-DASL180P45 180° 3,200 75.5 --- 2.3 1.3
P33N032-DASL180P64 180° 3,200 75.5 --- 2.3 1.3
P33N054-DASL030P45 30° 5,400 75.5 --- 2.3 1.3
P33N054-DASL030P64 30° 5,400 75.5 --- 2.3 1.3
P33N054-DASL090P45 90° 5,400 75.5 --- 2.3 1.3

NO-2 47626630001_ed2
NO
Model Vinkel
Fri
Hastighet
Lydnivå dB(A)
(ISO15744)
Vibrasjons (m/s²)
(ISO28927)
rpm † Trykk (Lp) ‡ Styrke (Lw)Nivå *K
P33N054-DASL090P64 90° 5,400 75.5 --- 2.3 1.3
P33N054-DASL180P45 180° 5,400 75.5 --- 2.3 1.3
P33N054-DASL180P64 180° 5,400 75.5 --- 2.3 1.3
† KpA = 3dB måleusikkerhet * K = måleusikkerhet (Vibrasjons)
‡ KwA = 3dB måleusikkerhet
ADVARSEL
Lyd- og vibrasjonsverdiene ble målt i samsvar med internasjonalt anerkjente teststand-
arder. Eksponeringen for brukeren i et bestemt bruksområde for verktøyet kan variere fra
disse resultatene. Derfor bør målingene på stedet benyttes for å avgjøre farenivået i det
bestemte bruksområdet.
Installasjon og Smøring
Luftforsyningsslangen skal ha en dimensjon som sikrer maksimalt driftstrykk (PMAX) ved
verktøysinntaket. Drener daglig kondens fra ventilen(e) ved lave rørpunkter, luftlter og
kompressortank. Monter en slangebruddsventil oppstrøms i slangen og bruk en antipiskeenhet
over slangekoblinger uten intern avstengning, for å forhindre slangen i å piske ved funksjons-
feil eller utilsiktet frakobling. Se tegning 16595274 og tabell på side 2. Vedlikeholdsfrekvens
vises i den sirkulære pilens retning og angis som h=timer, d= dager og m=måneder. Punkter
identiseres som:
1. Luftlter 7. Kobling Slangebruddsventil
2. Regulator 8. Sikkerhetsluftsikring
3. Smøreapparat 9. Olje
4. Nødstoppventil 10. Smørefett
5. Slangediameter 11. Smørefett
6. Gjengedimensjon
Deler og Vedlikehold
Når verktøyet ikke lenger er brukbart, anbefales det at verktøyet blir demontert, rengjort for olje
og sortert etter materialer i gjenvinningsøyemed.
De originale instruksjonene er på engelsk. Andre språk er en oversettelse av de originale
instruksjonene.
Reparasjon og vedlikehold av verktøyet skal bare utføres av et autorisert servicesenter.
Henvendelser skal rettes til nærmeste Ingersoll Rand- avdeling eller -forhandler.
