Ingrid GEC1000 User manual

Grid Extender Installation Instructions
Model GEC1000
InGrid Grid Extender Kit Contents
GEC1000 Grid Extender
IG180 Ni-MH Rechargeable Battery Pack
Phone Cord
Determine the Location
Place the Grid Extender in a location that is
spread a part from the Console and Base.
Having these devices spread throughout the
home will maximize system coverage.
Power and phone outlets are required to
operate the Grid Extender.
Install the Grid Extender
1) Install Battery Pack - The battery pack is
shipped inside the Grid Extender, but
not connected.
a. Open the battery compartment of
device and remove the battery
b. Insert the battery cable plug into the
two-pin jack, and insert the battery.
c. Replace the battery cover.
2) Plug the Grid extender into the electrical
wall outlet with the phone jack facing
down.
3) Plug one end of the phone cord into the
phone jack on the bottom of the Grid
Extender and the other into an active
phone wall jack.
Optional – Securing Grid Extender
1) Turn power to outlet off at circuit
breaker.
2) Mount Grid Extender to Wall Outlet –
Leave the wall plate on the outlet but
remove the center screw.
CAUTION
RISK OF EXPLOSION
IF BATTERY IS
REPLACED BY AN
INCORRECT TYPE.
DISPOSE OF USED
BATTERIES
ACCORDING TO THE
INSTRUCTIONS
Plug the Grid Extender into the electrical
outlet with the phone jack facing down.
3) Replace the center screw by inserting it
through the tab on the Grid Extender.
4) Turn the power back on at the circuit
breaker.
Add the Grid Extender to your
InGrid System
After the initial installation of the InGrid
System, components may be added to
enhance access or performance.
These devices may be added to the InGrid
System up to the number shown in the table:
Note:
oUse only InGrid IG180
rechargeable battery packs
supplied with your various
Home Protection components.
oReplacement battery packs are
also available through the
InGrid’s customer service at 1-
877-INGRID7 or on-line at
www.InGridHome.comUse
only the supplied AC power
adapter. Do not use any other
adapter.
Device Device
Maximum System Maximum
Handsets 6
Consoles 4 9*
Grid Extenders 4
*The system will allow a maximum of 9
Handset/Console or Grid Extender combinations
After the hardware is hooked up, use a
Handset or Console that is currently

registered on the System to enter the
Security Menu and follow the steps for
installing new hardware.
After installing the hardware, enter Menu on
your Handset or Console.
oScroll to Setup and press SELECT
oScroll to Security and press
SELECT
oEnter Master Code and press
SELECT
Add the Grid Extender
1. Start by following the instructions
outlined in grid extender installation
section of this guide.
2. Using the scroll and SELECT buttons on
your existing handset or console,
navigate to GC or Handset
(Menu/Setup/Security/GC or
Handset/<Add New>).
SELECTBACK
<Add New>
GCs or Handset
3. Press the SELECT key to <Add New>.
The system will begin searching for the
new Grid Extender you are looking to
add.
4. On the Grid Extender press the center
button until the light flashes green.
Add Button
Flashing Light
5. The system will inform you when it has
found and added the Grid Extender.
Press OK when you have been informed
that the GE has been added.
6. You will then be given the option to edit
the default name.
OKDELETE
Edit Name
GE 1
7. Press OK
FCC Information
FCC Part 15
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2)
this device must accept any interference received,
including interference that may cause undesired
operation.
CAUTION:
Changes and modifications to this product not
expressly approved by InGrid, Inc. could void not only
the user’s authority to operate this device, but also the
limited warranty.
Note:
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to
radio communications. However, three is no guarantee
that interference will not occur in a particular
installation. If this equipment does cause harmful
interference to radio or television reception, which can
be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by
one or more of the following measures:
oReorient or relocate the receiving antenna
oReorient or relocate and increase the
separation between the equipment and
receiver
oConnect the equipment into an outlet on a
circuit different from that to which the receiver
is connected.
Some cordless telephones operate at frequencies that
may cause interference to nearby TVs or VCRs. To
minimize or prevent such interference, the base or the
cordless telephone should not be placed near or on top
of a TV or VCR. If interference is experienced, move
the cordless telephone further away from the TV or
VCR. This will often reduce, or eliminate, interference.
Consult an experienced radio/TV technician for help if
these measures do not eliminate the interference.
OKCANCEL
GE Added
The antenna used with this product must be installed to
provide a separation distance of at least 20 cm from all
persons and must not be co-located or operating in
conjunction with any other antenna or transmitter.
This equipment should be serviced only by Ingrid, Inc.
or its authorized agents.

FCC Part 68
This equipment complies with Part 68 of the FCC rules
and the requirements adopted by the ACTA. On the
equipment there is a label that contains, among other
information, a product identifier in the format
US:AAAEQ##TXXXX. If requested, this number must
be provided to the telephone company.
A plug and jack used to connect this equipment to the
premises wiring and telephone network must comply
with the applicable FCC Part 68 rules and requirements
adopted by the ACTA. A compliant telephone cord and
modular plug is provided with this product. It is
designed to be connected to a compatible modular jack
that is also compliant.
Registration No.: Found on the bottom of the unit.
The REN is used to determine the number of devices
that may be connected to a telephone line. Excessive
RENs on a telephone line may result in the devices not
ringing in response to an incoming call. In most but not
all areas, the sum of RENs should not exceed five (5.0).
To be certain of the number of devices that may be
connected to a line, as determined by the total RENs,
contact the local telephone company. For products
approved after July 23, 2001, the REN for this product
is part of the product identifier that has the format
US:AAAEQ##TXXXX. The digits represented by ## are
the REN without a decimal point (e.g., 03 is a REN of
0.3).
If this equipment causes harm to the telephone
network, the telephone company will notify you in
advance that a temporary discontinuance of service
may be required. But if advance notice isn’t practical,
the telephone company will notify you as soon as
possible. Also, you will be advised of your right to file a
complaint with the FCC if you believe it is necessary.
The telephone company may make changes in its
facilities, equipment, operations or procedures that
could affect the operation of the equipment. If this
happens, the telephone company will provide advance
notice in order for you to make necessary modifications
to maintain uninterrupted service.
If trouble is experienced with this equipment, for repair
or warranty information, please contact InGrid, Inc. at
877-INGRID7 or [email protected]. If the
equipment is causing harm to the telephone network,
the telephone company may request that you
disconnect the equipment until the problem is resolved.
Connection to a party line service is subject to state
tariffs. Contact the state public utility commission,
public service commission or corporation commission
for information.
You must not connect your phone to:
oCoin operated systems
oMost electronic key telephone systems
If you home has specially wired alarm equipment
connected to the telephone line, ensure the installation
of this equipment does not disable your alarm
equipment. If you have questions about what will
disable the equipment, consult your telephone company
or a qualified installer.
Caution – To ensure proper operation, this equipment
must be installed according to the enclosed installation
instructions. To verify that the equipment is operating
properly and can successfully report an alarm, this
equipment must be tested immediately after installation,
and periodically thereafter, according to the enclosed
test instructions.
Caution – This equipment cannot report an alarm when
other equipment (telephone, answering system,
computer modem, etc.) connected to the same line is in
use.
Functionally equivalent equipment or wiring used to
provide
Line Seizure capability without the use of an RJ31X or
RJ38X jack may be used. See Line Seizure
instructions.
Caution – Verification of line Seize capability should be
made immediately after installation, and periodically
thereafter, in order to ensure that this equipment can
initiate a call even when other equipment (telephone,
answering system, computer modem, etc.) connected
to the same line is in use.
Industry Canada (I.C.) Notice
Terminal Equipment
Notice: This equipment meets the applicable Industry
Canada Terminal Equipment Technical Specifications.
This is confirmed by the registration number. The
abbreviation, IC, before the registration number
signifies that registration was performed based on a
Declaration of Conformity indicating that Industry
Canada technical specifications were met. It does not
imply that Industry Canada approved this equipment.
Notice: The Ringer Equivalence Number (REN) for this
terminal equipment is marked on the equipment itself.
The REN assigned to each terminal equipment
provides and indication of the maximum number of
terminals allowed to be connected to a telephone
interface. The termination on an interface may consist
of any combination of devices subject only to the
requirement that the sum of the Ringer Equivalence
Numbers of all the devices not exceed five.
Radio Equipment
The term “IC:” before the radio certification number only
signifies that Industry Canada technical specifications
were met.
Operation is subject to the following two conditions: (1)
this device may not cause interference, and (2) this
device must accept any interference, including
interference that my cause undesired operation of the
device. “Privacy of communications may not be
ensured when using this telephone”.
Telephone Line Jacks
There are two types of jacks:
Modular Jack – Most phone equipment available now
uses modular jacks. Phone cords are fitted with a
molded plastic connector which plugs into this type of
jack. If you don not have modular jacks, contact your

local telephone company for information about their
installation.
Hardwired Jack – Some equipment is wired directly to a
phone jack, and these types of installations require a
modular jack converter. This type of installation is not
difficult; however, you should contact your telephone
supply store for advice about the proper adapter or
converter for your particular situation.
Connecting the Telephone Cords
CAUTION! Consider these safety guidelines before
connecting the telephone cords:
oNever install telephone wiring during a
lightning storm
oNever touch uninsulated telephone wires or
terminals unless the telephone line has been
disconnected.
oUse caution when installing or modifying
telephone lines
Warranty
One Year Limited Warranty
For Consumer Products and Accessories purchased in
the United States and Canada.
What this Warranty Covers
Subject to the exclusions contained below, InGrid, Inc.
warrants its products (“Products”) and InGrid-branded
or certified accessories sold for use with these Products
(“Accessories”) to be free from defects in materials and
workmanship under normal consumer usage for a
period of one (1) year as outlined below. This limited
warranty is a consumer's exclusive remedy, and applies
as follows to new InGrid Products and Accessories
purchased by consumers in the United States and
Canada which are accompanied by this written
warranty.
EXCLUSIONS
Normal Wear and Tear. Periodic maintenance, repair
and replacement of parts due to normal wear and tear
are excluded from coverage.
Batteries. Only batteries whose fully charged capacity
falls below 60% of their rated capacity and batteries
that leak are covered by this limited warranty.
Abuse & Misuse. Defects or damage that result from:
(a) improper operation, storage, misuse or abuse,
accident or neglect, such as physical damage (cracks,
scratches, etc.) to the surface of the product
resulting from misuse; (b) contact with liquid, water,
rain, extreme humidity or heavy perspiration, sand, dirt
or the like, extreme heat, or food; (c) use of the
Products or Accessories for commercial purposes
or subjecting the Product or Accessory to abnormal
usage or conditions; or (d) other acts which are not the
fault of Motorola, are excluded from coverage.
Use of Non-InGrid Products and Accessories.
Defects or damage that result from the use of Non-
InGrid branded or certified Products, Accessories or
other peripheral equipment are excluded from
coverage.
Unauthorized Service or Modification. Defects or
damages resulting from service, testing, adjustment,
installation, maintenance, alteration, or modification in
any way by someone other than InGrid Inc., or its
authorized service centers, are excluded from
coverage.
Altered Products. Products or Accessories with (a)
serial numbers or date tags that have been removed,
altered or obliterated; (b) broken seals or that show
evidence of tampering; (c) mismatched board serial
numbers; or (d) nonconforming or non-InGrid housings,
or parts, are excluded from coverage.
Who is Covered
This warranty extends only to the first consumer
purchaser, and is not transferable.
What InGrid Will Do
InGrid, at its option, will at no charge repair, replace or
refund the purchase price of any Products or
Accessories that does not conform to this warranty. We
may use functionally equivalent
reconditioned/refurbished/pre-owned or new Products
or Accessories.
Other Limitations
ANY IMPLIED WARRANTIES, INCLUDING WITHOUT
LIMITATION THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE, SHALL BE LIMITED TO THE DURATION OF THIS
LIMITED WARRANTY, OTHERWISE THE REPAIR,
REPLACEMENT, OR REFUND AS PROVIDED UNDER THIS
EXPRESS LIMITED WARRANTY IS THE EXCLUSIVE
REMEDY OF THE CONSUMER, AND IS PROVIDED IN LIEU
OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED. IN
NO EVENT SHALL INGRID BE LIABLE, WHETHER IN
CONTRACT OR TORT (INCLUDING NEGLIGENCE) FOR
DAMAGES IN EXCESS OF THE PURCHASE PRICE OF THE
PRODUCT OR ACCESSORY, OR FOR ANY INDIRECT,
INCIDENTAL, SPECIAL OR
CONSEQUENTIAL DAMAGES OF ANY KIND, OR LOSS OF
REVENUE OR PROFITS, LOSS OF BUSINESS, LOSS OF
INFORMATION OR DATA, SOFTWARE OR APPLICATIONS
OR OTHER FINANCIAL LOSS ARISING OUT OF OR IN
CONNECTION WITH THE ABILITY OR INABILITY TO USE
THE PRODUCTS OR ACCESSORIES TO THE FULL EXTENT
THESE DAMAGES MAY BE DISCLAIMED BY LAW. Some
states do not allow this exclusion or limitation of
incidental or consequential damages so the above
limitation or exclusion may not apply to you.
LEGAL REMEDIES: This warranty gives you specific
legal rights, and you may also have other rights which
vary from state to state. This warranty is void outside
the United States of America and Canada.
How to Obtain Warranty Service or Other
Information
If, after following the instructions in the owner's manual
you are certain that the Product (or Accessory) is
defective, pack the Product (or Accessory) carefully
(preferably in its original packaging). The Product
should include all parts and accessories originally
packaged with the Product. Include (a) a copy of your
receipt, bill of sale or other comparable proof of
purchase; (b) a written description of the problem; (c)
the name of your broadband service provider, if
applicable; and, most importantly; (d) your address and
telephone number. The Product (or Accessory) should
be shipped freight prepaid, by traceable means, to
InGrid at:
InGrid Incorporated
Parts and Service Division
920 Cassatt Road, Suite 200
Berwyn, PA
Part No: 100000302
Printed in China
