INIM Electronics Air2-MC200 Assembly instructions

"JS.$
.BHOFUJD DPOUBDU XJUI TIPDL BOE UJMU TFOTPS
E
EN 50131-1
EN 50131-2-6
EN 50131-5-3
EN 50130-4
EN 50130-5
INCERT
CEB T031
*OTUBMMBUJPO BOE QSPHSBNNJOH NBOVBM

Table of contents
1. Air2 system description 3
2. Description Air2-MC200 4
2.1 Description of parts 5
2.2 Air2-MC200 technical specifications 5
3. Installation of Air2-MC200 6
3.1 Enrolling a wireless device 7
3.2 Battery replacement 7
4. Programming wireless terminal 8
4.1 Wireless terminal parameters 8
4.2 Real-time 8
5. General information 10
5.1 About this manual 10
5.2 Manufacturer's details 10
5.3 Notes from the Manufacturer 10
5.4 Simplified EU Declaration of Conformity 10
5.5 Documents for the users 11
5.6 WEEE 11
2Installation and programming manual- 100-DRAFT

Air2-MC200 | © 2020 Inim Electronics S.r.l. 3
1. Air2 system description
All anti-intrusion systems INIM can manage the two-way wireless system Air2 characterized by a MHz carrier
frequency 868 MHz.
The system components Air2 are:
Air2-BS200/50 transceiver module, 50 terminals
Air2-BS200/30 transceiver module, 30 terminals
Air2-BS200/10 transceiver module, 10 terminals
Air2-KF100 4 button remote-control key
Air2-Ergo 4 button remote-control key
Air2-Pebble 4 button remote-control key
Air2-MC200 magnetic contact with shock and tilt sensor in white or brown
Air2-MC300 magnetic contact with two I/O terminals, in white or brown
Air2-FD100 smoke detector
Air2-Aria/W keypad with graphic display
Air2-Hedera outdoor sounder, in white or chrome effect
Air2-Smarty/W indoor sounderflasher
Air2-DT200T dual technology curtain detector, in white or brown
Air2-XIR200W PIR detector, 12 m
Air2-XDT200W dual technology curtain detector
Air2-UT100 universal transceiver
Air2-ODI100W outdoor wireless dual-infrared detector
Air2-OTT100W outdoor wireless triple-technology detector
Technicalspecifications of the system Air2
Operatingfrequency
range 868.0 - 868.6 MHz
selectable channels 868.1, 868.3, 868.5 MHz
RF output power 25mW e.r.p.
Communication type Two-way
Modulation GFSK
Device supervision from 12 to 250 minutes
/PUF
In order tocomply withtheEN 50131-1 standards thealarm systemsupervision time must be below 120 minutes.

2. Description Air2-MC200
2. Description Air2-MC200
The magnetic contact Air2-MC200 is supplied with a magnet which is to be secured (by means of two
screws)to the side of the contact, in the position indicated by the two notches.
Air2-MC200 it also integrates a shock and a tilt sensor that allow its use without the need of the magnet.
Air2-MC200 it is equipped with open and dislodgement tamper protection.
The device uses separate channels for the different types of signalling, thus allowing precise identification of
the alarm source.
.BHOFUEFUFDUJPOSBOHF
The following table indicates the distance in millimeters of the operating capacity of the magnet depending
on the side in use and the axes illustrated in the figure (values starting from a nominal distance of 10mm,
except for axis y-):
Axis Distance between magnet and contact (mm)
Near Withdrawn
x +/- 14 18
y - 14 18
z +/- 18 22
4IPDLEFUFDUJPO
Signalling of shock waves is achieved through a tri-axial vibration detector. The vibration sensibility can be
set either from a keypad or via the programming software application.
5JMU EFUFDUJPO
Signalling of tilting (angle change) is achieved through tri-axial tilt sensing. The tilt-variation value (angle) can
be set in relation to the standby position, which is saved to the memory during the reset-after -alarm phase.
/PUF
The device programmingallows, besides magnet detection, theuse of only oneother type of detection, to be
enabled betweenthe detection of shocks and that of tilting.
The shock andtilt sensors are not subject tocertification of this product.
4Installation and programming manual- 100-DRAFT

Air2-MC200 | © 2020 Inim Electronics S.r.l. 5
2.1 Description of parts
2.1 Description of parts
<">LJ Backbox
<#>LJ Mounting screw hole
<$>LJ Tamper-screw location
<%>LJ Securing screws
<&>LJ Magnet position notches
<'>LJ PCB board
<(>LJ Battery
<)>LJ Signalling LED - red (on rear)
<*>LJ Microswitch: open/dis-
lodgement/ENROLL
<+>LJ Reed contact
2.2 Air2-MC200 technical specifications
Battery
type Lithium CR2 3V
estimatedlife 4 years
“Low battery” fault voltage Less than 2.4V
Current draw
during standby 10µA
maximum 30mA
Operating environmental conditions
Temperature from -10 to +40 °C
Relative humidity ≤93% without condensation
Security rating 2
Environmentalclass II
Dimensions (W x H x D) 35 x 58 x 23mm
Weight 30 g
Magnet dimensions 13 x 40 x 14mm
Colours White, Brown

3. Installation of Air2-MC200
3. Installation of Air2-MC200
1. Choose a suitable mounting placement.
"UUFOUJPO
Ferromagnetic materials which are located in the vicinity of the mounting position can
influence the magnetic field and can result in the reduced operating capacity of the
device.
2. Using a flat-bladed screwdriver in the enclosure screw location, push open the enclosure and sep-
arate the two parts.
3. Hold the base to the chosen mounting placement and mark the screw holes and tamper protection
position.
4. Using the screws, secure the base and the tamper protection in position.
5. Insert the battery, ensure you respect the proper polarity.
6. Enroll the device.
7. If you wish to fit the magnet by means of the screws (included), remove the magnet base by means of
a flat-bladed screwdriver.
8. Position the base of the magnet at a distance of about 2 mm from the detector, centering the notches
on the side of the detector base.
9. Using the screws or the adhesive tape, attach the magnet.
10. Re-attach the cover to the base of the contact and replace the enclosure screw.
6Installation and programming manual- 100-DRAFT

Air2-MC200 | © 2020 Inim Electronics S.r.l. 7
3.1 Enrolling a wireless device
3.1 Enrolling a wireless device
The enrolling procedure allows you to associate a wireless device INIM with the transceiver Air2-BS200
which acts in conjunction with the intrusion control panel.
This procedure varies depending on the control panel in use and the programming software orapplication:
1. Access the control panel programming.
2. Select the device to be enrolled in accordance with its type:
an input terminal, for a detector (motion detector, magnetic contact, etc.)
an output terminal, for an output device connected to a terminal of a magnetic contact Air2-
MC300
a keypad
a sounder/flasher
a key, for a remote control device, selecting as the associated reader the one simulated by the
transceiver
3. Set the device as “Wireless”.
4. Start the learning phase from the control panel.
5. Press the ENROLL button on the wireless device.
3.2 Battery replacement
When changing the battery, it is advisable to press the ENROLL button in order to be sure that the device is
synchronized with the wireless transceiver.

4. Programming wireless terminal
4. Programming wireless terminal
The programming of a wireless terminal can only be done through the control panel programming software.
On accessing the software, it is necessary to open a solution, configuration of the real system to be
designed. Successively a terminal previously configured or to be configured as “wireless”must be selected.
After which it will be possible to access the device programming in order to select or change the device type
and its parameters.
4.1 Wireless terminal parameters
Use detector LED The red LED on the device provides visual signalling of alarm or tamper conditions on the device itself.
Bypass tamper This option disables open/dislodgement tamper signalling.
Disable wireless mon-
itoring
Enabling this option (disabled at default), disables wireless monitoring on the detector.
In the event of the loss of the specific detector, no event will be generated and no fault signal will be
signalled on the keypad.
Disable detector on par-
tition disarming
In order to increase battery life, the PIR detector will deactivate when the partitions it belongs disarm
and activate when the partitions it belongs to arm.
When the detector is deactivated it will not generate alarms.
From the moment the partitions arm, there may be a delay of up to 3 minutes before the detector
receives the activation command.
Alarm pulses
This is the number of pulses (each lasting as long as the programmed “Alarm pulse duration”) neces-
sary to generate a zone alarm event.
If this value is more than 1, you must also program the “Multi-pulse time” parameter.
Multi-pulse time
This parameter applies only when the “Alarm pulse num.” is higher than 1.
This is the window during which a number of alarm pulses must be detected (each lasting as long as
the programmed “Alarm pulse duration”) equal to the value programmed for “Alarm pulses” in order
for the system to generate an alarm.
This time window can be expressed in seconds or minutes.
Alarm pulse duration
This is the length of time (after detection of alarm conditions) the zone will allow before generating an
alarm.
Expressed in multiples of 15 milliseconds or minutes.
Shock detectorsens-
itivity from least sensitive to most sensitive
Maximum angle allowed
before signalling of tilt-
ingoccurs. from 5° to 70° (the default value depends on the control panel)
Shock/Tilt time
If the device is set to detect shock waves (bangs or vibration), this parameter refers to the time within
which the shock waves must be detected.
If the device is set to detect tilting, this parameter refers to the time with which the change in the angle
will be signalled.
from 1 to 125 (100msec or sec)
4.2 Real-time
For each configured device the software provides a direct software-to-device connection which allows visu-
alization of the real-time values of the following features of the wireless sounder:
8Installation and programming manual- 100-DRAFT

Air2-MC200 | © 2020 Inim Electronics S.r.l. 9
4.2 Real-time
Readinglevel The value read by each detector of the device is displayed on a bar which indicates the alarm threshold by means of a colour change from green to red.
Signalrecep-
tion The series of notches represent the reception level of the wireless signal of the device as received by the trans- ceiver Air2-BS200.
Battery
charge level Percentage of the device battery charge.
RFanalysis Function to monitor the variation of the signal transmitted by the device and the background noise detected through time.

5. General information
5. General information
5.1 About this manual
Manual code:DCMIINE0A2MC2008E
Revision: 100-DRAFT
Copyright: The information contained in this document is the sole property of Inim Electronics S.r.l.. Copy-
ing, reprinting or modification of this document, in part or as a whole, is not permitted without prior autho-
rization in writing from Inim Electronics S.r.l.. All rights reserved.
5.2 Manufacturer's details
Manufacturer: Inim Electronics S.r.l.
Production plant:Centobuchi, via Dei Lavoratori 10
63076 Monteprandone (AP),Italy
Tel.: [phone]
Fax: [phone]
E-mail [e-mail]
Web: www.inim.biz
The persons authorized by the manufacturer to repair or replace the parts of this system have authorization
to work only on devices marketed underthe brand Inim Electronics.
5.3 Notes from the Manufacturer
The devices Air2 are certified by IMQ-Sistemi di sicurezza (Italian certification body).
The information relating to the power-supply batteries required by the devices Air2 are provided in the fol-
lowing Technical Specification table.
The manufacturer cannot guarantee the declared battery life.
"UUFOUJPO
Do not use batteries other than those indicated by the manufacturer as they may
explode.
5.4 Simplified EU Declaration of Conformity
Hereby, Inim Electronics S.r.l. declares that the radio equipment type Air2-MC200 is in compliance with
Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet
address: www.inim.biz.
10 Installation and programming manual- 100-DRAFT

Air2-MC200 | © 2020 Inim Electronics S.r.l. 11
5.5 Documents for the users
5.5 Documents for the users
Declarations of Performance, Declarations of Conformity and Certificates concerning to Inim Electronics
S.r.l. products may be downloaded free of charge from the web address www.inim.biz, getting access to
Extended Access and then selecting "Certifications" or requested to the e-mail address [e-mail] or
requested by ordinary mail to the address shown in this document.
Manuals may be downloaded free of charge from the web address www.inim.biz, getting access to the
reserved area, afterthe login, and then to the section of each product.
5.6 WEEE
Informative notice regarding the disposal of electrical and electronic equipment (appli-
cable in countries with differentiated waste collection systems)
The crossed-out bin symbol on the equipment or on its packaging indicates that the product must be
disposed of correctly at the end of its working life and should neverbe disposed of together with gene-
ral household waste. The user, therefore, must take the equipment that has reached the end of its working
life to the appropriate civic amenities site designated to the differentiated collection of electrical and elec-
tronic waste. As an alternative to the autonomous-management of electrical and electronic waste, you can
hand over the equipment you wish to dispose of to a dealer when purchasing new equipment of the same
type. You are also entitled to convey for disposal small electronic-waste products with dimensions of less
than 25cm to the premises of electronic retail outlets with sales areas of at least 400m2, free of charge and
without any obligation to buy. Appropriate differentiated waste collection for the subsequent recycling of the
discarded equipment, its treatment and its environmentally compatible disposal helps to avoid possible
negative effects on the environment and on health and favours the re-use and/or recycling of the materials it
is made of.
Information about disposal of batteries and accumulators (applicable in Countries
with separate collection systems)
This marking on batteries and/or their manual and/or their packaging, indicates that batteries of this
products, at the end of their working life, should not be disposed of as unsorted municipal waste, but must
be object of a separate collection. Where marked, the chemical symbols Hg, Cd o Pb indicate that the bat-
tery contains mercury, cadmium or lead above the reference levels of the directive 2006/66/EC. If batteries
are not properly disposed of, these substances, together with other ones contained, can cause harm to
human health and to the environment. To protect human health and the environment, to facilitate treatment
and recycling of materials, separate batteries from other kind of waste and use the collection scheme stated
in your area, in accordance to current laws. Before disposing of the above, it's appropriate to remove them
from their holders avoiding to damage them or causing short circuits.

[email protected] _ www.inim.biz
Via dei Lavoratori 10, Loc. Centobuchi
63076 Monteprandone (AP) ITALY
Tel. [phone] _ Fax [phone]
DCMIINE0A2MC2008E-100-20200525-DRAFT
