Inline SmartHome 59903S User manual

Art.-No.: 59903S/W
LED TABLE LAMP
WITH QI

2
www.inline-info.com
VALIDITY
This user manual applies to the following
products:
59903S InLine® SmartHome LED Table
lamp with Qi, black
59903W InLine® SmartHome LED Table
lamp with Qi, white
MANUFACTURER
INTOS ELECTRONIC AG
Siemensstraße 11
D-35394 Gießen
DATE
February 2020
CONTENT OF DELIVERY
1x SmartHome LED Table lamp with Qi
1x Power cable, approx. 1,5m
1x User manual DE+EN
Please check the content of delivery for
completeness. If individual components
are missing, please contact your dealer.
GENERAL WARNINGS
• Keep the device away from children and pets.
• Do not use outdoors - for indoor use only.
• Only place the device on firm and level ground.
TECHNICAL CHARACTERISTICS
Colour: black or white (depending on model)
Material: plastic
LEDs: 112 LEDs
Power consumption of LEDs: 7 Watt
Max. luminous flux: < 400 lumen
CRI: Ra >= 90
Dimmer: Yes, by touch button on the foot of the device or app
Colour temperatures: cold white, natural white, warm white (by touch key)
(infinitely variable per App 2700-6500K)
Timer: 40 min. countdown at the touch of a button,
(more complex scenarios can be set via app)

3
[email protected]
Output Wireless Charging: 5V/1A max. at the stand
USB output: 5V/1.5A
WiFi signal: WiFi 2.4GHz
WiFi standard: IEEE802.11b/g/n
Range: Up to 15m (with visual contact)
Protocols: DHCP/IP/TCP/UDP
WiFi security: WPA/WPA2 encryption
Antenna: Built-in omnidirectional antenna
Power supply: Input AC100-240V 50/60Hz, Output DC24V/1A
Power consumption: 24 watts max.
Standby power consumption: 1 watt
Product dimensions (LxWxH): 340x170x435mm
Net weight: 445g
Operating temperature: 0° - 40°C
Operating humidity: 0% - 90% non-condensing
Storage temperature: 0° - 40°C
Storage humidity: 0% - 90% non-condensing
App: Smart Life
Compatible with: Amazon Alexa, Google Home
INTENDED USE
The InLine® SmartHome LED Table lamp with Qi combines the functions desk lamp and
wireless charger, which can be operated individually or in combination. It also provides an
USB output, to charge a terminal device via cable.
The control is done either on the device itself or via APP, if a successful integration into the
WiFi network has taken place.
IMPROPER USE
Improper use within the meaning of foreseeable misuse applies:
• Do not disassemble the device.

4
www.inline-info.com
• Only use the device indoor, not outdoor.
• Do not expose the device to excessive heat.
• Do not subject the device to vibrations.
• Do not place the device within the reach of children and/or pets.
• Do not place the device at an angle.
RADIO FREQUENCY NOTES
General Allocation of Frequencies for Use in Local Networks; Wireless Local Area Net-
works (WLAN Radio Applications)
Based on § 55 of the German Telecommunications Act (Telekommunikationsgesetz - TKG)
we herewith assign frequencies in the range 2400.0 – 2483.5 MHz for use of the general
public in local networks, Wireless Local Area Networks (WLAN Radio Applications). With
this General Allocation, we fulfil the compulsive implementation of the Decision by the
European Commission on Harmonisation of the Radio Spectrum for Use by Short-Range
Devices dated 2006/11/09 (2006/771/EG), as amended by implementing the decision of
the Commission dated 2011/12/08 (2011/829/EU), published in the Official Journal of the
European Union L 329, page 10 ff. dated 2011/12/13 in Germany. If you intend to use this
product outside of Germany, please read up in advance on the respective regulations in
your host country.
OPERATION OF THE INLINE® SMARTHOME LED TABLE LAMP WITH QI
PREPARATION
• Place the device on a flat, stable surface.
• Insert one plug of the power cord into the socket on the unit and the other into the
power outlet.
• The blue status LED on the back of the device flashes.

5
[email protected]
MANUAL OPERATION VIA KEYS
• Briefly press the power button to turn on the lamp. The lighting starts with natural light.
• As soon as the lamp is turned on, you can switch between the three color temperatures
cold white, natural and warm white by briefly pressing the „M“ button.
• To dim the brightness, press and hold the power button until the desired brightness is
reached. The first hold down decreases, the second increases the brightness.
• To activate the countdown, hold down the timer button until the lamp blinks twice. It will
now switch off automatically after 40 minutes.
MANUAL OPERATION VIA APP
REGISTER AND LOGIN THE APP
1. Open the „Smart Life“ APP on your phone.
2. Register with your mobile phone number or email address.
3. Select the router and confirm the WiFi password if necessary.
4. This connects the APP to your network.
ADD/CONNECT DEVICE
1. Press the „M“ button for about 5 seconds until the blue status LED on the back of
the device flashes (if it is not already flashing).
2. In the APP, press the „+“ sign (top right).
Download the „Smart Life“ APP from the
Google Play Store and launch the APP.
Download the „Smart Life“ APP from APP
Store and launch the APP.

6
www.inline-info.com
3. Select „Automatic Scan“ at the top. After a few seconds „InLine SmartHome LED
Office Light“ should be found.
4. Please select to connect the device.
5. To add the appliance manually, please select the „Lighting (Wi-Fi)“ from the „Light-
ing“ section.
6. Select your WiFi and enter your WiFi password. Confirm to allow the device to con-
nect to your network.

7
[email protected]
7. The APP now connects to the device, wait until the display of your smartphone
confirms this.
8. After successful connection, the blue status LED stops flashing and now lights up.
9. You can assign your connected device directly to a room, but you can also simply
ignore it. The device then appears in the device overview under „All devices“.
Basically, settings/scenarios/automations for several families can be stored in this APP.
The administrator has authorization to create families and access all families.
DEVICE CONFIGURATION
Select the device to be set from your connected devices by clicking on it in the list.
Bulb symbol (in the middle) switches the device on
Schedule (down in the
middle)
here you can program timer scenarios for switching on and off.

8
www.inline-info.com
DEVICE DATA (PENCIL TOP RIGHT)
The following names and assignments make it easier for you to create automatisms and
scenarios.
Name (of the device) Please assign a name which will appear later in the device list,
automatisms and scenarios.
Location (location of the
device)
Here you can optionally assign a room name in which the device is
located.
Check device network This allows you to check the quality of your WiFi network.
Third-party control If you want to use the device via a language assistant, select it from
the suggested options to initiate the connection.
Share device Here you can share your set automatisms/scenarios with other
Smart Life App users and grant them access.
Create group Create a group of products of the same type that can react simulta-
neously to actions.
Device information Informations about the connection to the main server.
FAQ & Feedback This stands for help, here you get first help with any problems that
may arise during setup.
Check for firmware up-
date:
Click on it to search for the latest version.
Remove device Removes the device from your Smart Home WiFi network
Restore factory defaults The device is set to the delivery status. All individual settings are
deleted.

9
[email protected]
WIRELESS CHARGING
Place a compatible smartphone in the middle of the marked area of the InLine® SmartHome
LED Table lamp with Qi to start wireless charging. As soon as the wireless charging begins,
the green status LED on the back of the device lights up. Your smartphone to be charged
also confirms that charging has started. To cancel the charging process, simply remove your
smartphone from the InLine® SmartHome LED Table lamp with Qi. The green LED, which
signals the wireless charging process, goes out.
TROUBLESHOOTING (FAQ)
THE DEVICE CANNOT BE SWITCHED ON
Make sure that the power is supplied.
NO WIFI CONNECTION POSSIBLE
Make sure that the router and the device to be connected are turned on. Check the availa-
ble WiFi standard of the device. The InLine® Smart Home product supports WiFi 2.4GHz /
IEEE802.11b/g/n.
NETWORK IS FOUND, BUT NO CONNECTION POSSIBLE
Make sure that you have entered your WiFi password correctly. Make sure that the encryption
method of your WiFi network is WPA2-PSK and the authentication type is AES or both are
set to automatic.
Check whether you have selected the correct device type from the selection list when adding
manually (for this product, please select the „Lighting (Wi-Fi)“ from the list under „Lighting“).
WIRELESS CHARGING DOES NOT WORK
Make sure that your device to be charged supports wireless charging. Place your compatible
device centrally on the marked area.

10
www.inline-info.com
CONTACT / CURRENT PRODUCT INFORMATION
If you have any questions about the product or if you have any problems, you can contact the
manufacturer directly via live.inline-info.com or via email at [email protected].
MAINTENANCE AND CLEANING
We recommend cleaning the InLine® SmartHome LED Table lamp with Qi as follows:
1. Switch off the device and pull out the mains plug.
2. Wipe the device clean with a soft, damp cloth.
3. Dry the device with a soft cloth.
DISPOSAL
Electrical and electronic equipment and batteries must not be disposed of with household
waste. The consumer is obliged by law to return electrical and electronic equipment and bat-
teries at the end of their service life to the designated public collection points or to the point
of sale. Dispose of the packaging material sorted by type.
DISCLAIMER
1. EDITION ENGLISH 6/2020
Documentation © 2020 INTOS ELECTRONIC AG
All rights reserved. No part of this manual may be reproduced in any form or duplicated
or processed using electronic, mechanical or chemical processes without the publisher´s
written consent. It is possible that this manual may still contain typographical defects or
printing errors. However, the information in this manual is reviewed regularly and correc-
tions will be made in the next edition. We accept no liability for technical or typographical
errors and their consequences. All trademarks and industrial property rights are acknow-
ledged. Changes in the sense of technical progress can be made without prior notice.
Our products, including packaging, are not toys; they may contain small parts and sharp
objects. Keep away from children, please.
