InnoTops I-Brace 13 Assembly instructions

Installation Sheets
1) I-Brace 13 Guidelines
2) I-Brace 13 Instructions
3) I-Brace 20 Guidelines
4) I-Brace 20 Instructions
5) L-Brace 10 Guidelines
6) L-Brace 10 Instructions
7) L-Brace 15 Guidelines
8) L-Brace 15 Instructions
9) UpperBrace 10 Guidelines
10) UpperBrace 10 Instructions
11) UpperBrace 15 Guidelines
12) UpperBrace 15 Instructions
Visit us online @ InnoTops.com

2.5"
13"13"
2.5"
Minimum Overhang: 6"
6'' 16''
Recommended Spacing: 16" centers
16'' 24''
I-Brace 13
Maximum Overhang: 16"
Maximum Spacing: 24" centers
Visit us online @ innotops.com

TOOLS and MATERIALS 1
S
I
L
I
C
O
N
2 3
45 6
ATTACH 2x4 TO CABINET PANEL
TO INCREASE ITS STRENGTH
SECURE 2X4 WITH
SCREWS
SECURE I-BRACE
WITH 3 SCREWS
PLACE SILICONE ON I-BRACE
AND CABINET
SET STONE IN PLACE
AND CHECK FOR LEVEL
NOTCH WOOD 3/16"
DEEP, 2.5" WIDE
E
S
I
L
I
C
O
N
E
S
I
L
I
C
O
N
E
I-Brace 13
OR OR
7 x 2"
Visit us online @ innotops.com

20"
2,5"
20"
2,5"
22''
16'' 24''
12''
I-Brace 20
Minimum Overhang: 12"Maximum Overhang: 22"
Recommended Spacing: 16" centers Maximum Spacing: 24" centers
Visit us online @ innotops.com

TOOLS and MATERIALS 1
S
I
L
I
C
O
N
2 3
45 6
SECURE 2X4 WITH
SCREWS
SECURE I-BRACE
WITH 3 SCREWS
PLACE SILICONE ON I-BRACE
AND CABINET
SET STONE IN PLACE
AND CHECK FOR LEVEL
NOTCH WOOD 3/16"
DEEP, 2.5" WIDE
E
S
I
L
I
C
O
N
E
S
I
L
I
C
O
N
E
OR OR
7 x 2"
ATTACH 2x4 TO CABINET PANEL
TO INCREASE ITS STRENGTH
I-Brace 20
Visit us online @ innotops.com

2.5"
10"
2.5"
10"
5.5'' 12.5''
16'' 24''
L-Brace 10
Minimum Overhang: 5.5"
Recommended Spacing: 16" centers
Maximum Overhang: 12.5"
Maximum Spacing: 24" centers
Visit us online @ innotops.com

TOOLS and MATERIALS 1
345
IDENTIFY STUD AND
MARK FOR PLACEMENT
SECURE L-BRACE WITH 4
SCREWS AND 1 SCREW
INTO THE VERTICAL STUD
PLACE SILICONE ON L-BRACE
AND HALF-WALL
SET STONE IN PLACE AND
CHECK FOR LEVEL
NOTCH WOOD 1/4" DEEP, 2.5" WIDE.
NOTCH DRYWALL 2.5" WIDE AND 3.5" DOWN
S
I
L
I
C
O
N
E
OR
S
I
L
I
C
O
N
E
2
OR
5 x 2"
STUD
L-Brace 10
Visit us online @ innotops.com **Must have a half-wall for the product to function properly

2.5"
15"
2.5"
15"
10.5'' 17.5''
16'' 24''
L-Brace 15
Minimum Overhang: 10.5"
Recommended Spacing: 16" centers
Maximum Overhang: 17.5"
Maximum Spacing: 24" centers
Visit us online @ innotops.com

TOOLS and MATERIALS 1
345
IDENTIFY STUD AND
MARK FOR PLACEMENT
SECURE L-BRACE WITH 4
SCREWS AND 1 SCREW
INTO THE VERTICAL STUD
PLACE SILICONE ON L-BRACE
AND HALF-WALL
SET STONE IN PLACE AND
CHECK FOR LEVEL
NOTCH WOOD 1/4" DEEP, 2.5" WIDE.
NOTCH DRYWALL 2.5" WIDE AND 3.5" DOWN
S
I
L
I
C
O
N
E
OR
S
I
L
I
C
O
N
E
L-Brace 15
2
OR
5 x 2"
STUD
Visit us online @ innotops.com **Must have a half-wall for the product to function properly

10"
2,5"
10"
2,5"
5.5'' 12.5''
16'' 24''
UpperBrace 10
Minimum Overhang: 5.5"
Recommended Spacing: 16" centers
Maximum Overhang: 12.5"
Maximum Spacing: 24" centers
Visit us online @ innotops.com

TOOLS and MATERIALS 1
345
S
I
L
I
C
O
N
E
OR
S
I
L
I
C
O
N
E
2
OR
MARK FOR PLACEMENT
SECURE UPPERBRACE
WITH 4 SCREWS
PLACE SILICONE ON
UPPERBRACE AND HALF-WALL
SET STONE IN PLACE AND
CHECK FOR LEVEL
NOTCH WOOD 1/4" DEEP AND 2.5" WIDE
4 x 2"
UpperBrace 10
Visit us online @ innotops.com **Must have a half-wall for the product to function properly

15"
2,5"
15"
2,5"
10.5'' 17.5''
16'' 24''
UpperBrace 15
Minimum Overhang: 10.5"
Recommended Spacing: 16" centers
Maximum Overhang: 17.5"
Maximum Spacing: 24" centers
Visit us online @ innotops.com

TOOLS and MATERIALS 1
345
MARK FOR PLACEMENT
SECURE UPPERBRACE
WITH 4 SCREWS
PLACE SILICONE ON
UPPERBRACE AND HALF-WALL
SET STONE IN PLACE AND
CHECK FOR LEVEL
NOTCH WOOD 1/4" DEEP AND 2.5" WIDE
S
I
L
I
C
O
N
E
OR
S
I
L
I
C
O
N
E
UpperBrace 15
2
OR
4 x 2"
Visit us online @ innotops.com **Must have a half-wall for the product to function properly
