Walker Edison W58CSP User manual

Item #: W58CSP
Assembly Instructions
For our most current instructions, to request missing, lost or broken parts, or for any other Customer
Service issues, please visit our website at www.walkeredison.com or call us at 877-207-5906.
Revised 03/2012

General Assembly Guidelines
I. Insure that all parts and hardware are available before beginning assembly.
II. Follow each step carefully to insure the proper assembly of this product.
III. Two people are recommended for ease in the assembly of this product.
IV. The main types of hardware used to assemble this product are: wood dowels,
cam bolts and locks, bolts and screws.
V. The provided glue is to secure wood dowels in place. When first inserting dowels,
locate the appropriate hole for the dowel, place a small amount of glue in the hole
and insert the dowel. Wipe away excess glue immediately.
In future assembly steps when dowels are necessary to attach assembly parts
together, place a small amount of glue on the end of the dowel before attaching
parts together. Wipe away excess glue immediately.
VI. A Phillips head screwdriver is required for the assembly of this product.
VII. Power tools should not be used to assemble this product.
P.2

Parts List

Hardware List

Insert dowels (A) into panel (2). Screw cam bolts (B) into panels (1,2).
Insert dowels (A) into panel (4) and slats (6,7). Screw cam bolts (B) into slat (5).

Insert dowels (A) into legs (11,12,13,14) and panels (3). Screw cam bolts (B) into legs (11,12,13,14).
Attach legs (11,13) to panel (3) using cam bolts and dowels as guides. Insert cam locks (C) into panel (3)
and tighten with a screwdriver.

Attach legs (12,14) to second panel (3) using cam bolts and dowels as guides. Insert cam locks (C) into
panel (3) and tighten with a screwdriver.
Attach slat (7) to panel (2) using cam bolt and dowels as guides. Insert cam lock (C) into slat (7) and tighten
with a screwdriver.

Attach support leg (8) to panel (2) using bolts (D). Tighten bolts (D) with wrench (H).
Attach slat (5) to panel (4) using cam bolts and dowel as guides. Insert cam locks (C) into panel (4) and
tighten with a screwdriver.

Attach panel (4) to panel (2) using bolts (D). Tighten bolts (D) with wrench (H).
Attach slat (6) to slat (5) using dowel as guide.

Attach panel (3) with legs (11,13) to the assembly from the previous step using cam bolts and dowels as
guides. Insert cam locks (C) into panel (2) and slat (6) and tighten with a screwdriver.
Attach second panel (3) with legs (12,14) to the assembly from the previous step using cam bolts and
dowels as guides. Insert cam locks (C) into panel (2) and slat (6) and tighten with a screwdriver.

Carefully slide panels (10) into place along the back of the assembly.
Carefully attach panel (1) to the assembly using cam bolts and dowels as guides. Insert cam locks (C) into
the assembly as shown above and tighten with a screwdriver.

Secure panels (10) with plastic wedges (E) and screws (F).
Cover all visible cam locks with stickers (K) as desired.

Insert shelf support pins (G) into the assembly at desired shelf heights. Carefully place shelves (9) on shelf
support pins (G).
