Innovative Dehumidifier WH120 User manual

WH120
Whole House Dehumidifier
Installation and Operations Manu al
Innovative Dehumidifier Systems
6260 Hwy West
Ocean Isle Beach, NC 28469
[phone]

Table of Contents
Important Notes
Warranty Registration
Specifications
How it Works
Installation Requirements
Installation
Key Functions
Indicator Lights
Remote Control
Operating Instructions
Unit Diagram
Maintenance
Dehumidifier Storage
Ducted Applications
Troubleshooting
Spare Parts
Limited Warranty
Warranty Exclusions
3
3
4
4
4
5
5-6
7
8
9
10
10-11
12
12
13
14
15
2
16

Important Notes
Date Of Purchase:
Model Number:
Serial Number:
For additional questions concerning your dehumidifier, contact your local
installer or call Innovative Dehumidifier Systems customer service at
910-579-3348.
•Always connect your dehumidifier using a grounded, dedicated
electrical connection that is GFCI protected with at least 15 amp
capacity.
oThe use of any other type of wiring will void your warranty.
•Install dehumidifier according to all applicable local, state, and
national codes.
•Be sure to follow your GFCI manufacturer’s maintenance instructions.
You will typically need to test the operation of the trip circuit monthly.
oFor ease of testing and operation, it may be helpful to put the test
switch and indicator lights in a convenient location.
•Your dehumidifier should only be repaired by a qualified technician.
•Do not insert objects or your fingers into the inlet or discharge.
•Do not use water to clean the exterior of the dehumidifier. To clean
unit, unplug from power, then use a damp cloth to wipe the exterior.
•Do not stand on dehumidifier or place objects on it.
•Do not use with extension cord or plug adapter.
•Unless otherwise noted, all maintenance should be done with the unit
powered off.
Warranty Registration
Your dehumidifier comes with an extensive warranty. To register your unit,
simply fill out and return the warranty form provided in your dehumidiier
box.
For future reference, write down the model, serial number, and date of
purchase for your dehumidifier. This information is necessary for seeking
assistance in the future and can be found on the data label on the side of
the unit.
3

Model Number: Date Of Purchase:
• Always connect your dehumidifier using a grounded, dedicated
electrical connection that is GFCI protected with at least 15 amp capacity.
•The use of any other type of wiring will void your warranty.
• Install dehumidifier according to all applicable local, state, and national
codes
• Be sure to follow your GFCI manufacturer’s maintenance instructions.
You will typically need to test the operation of the trip circuit monthly.
• For ease of testing and operation, it may be helpful to put the test
switch and indicator lights in a convenient location.
• Your dehumidifier should only be repaired by a qualified technician.
• Do not insert objects or your fingers into the inlet or discharge.
• Do not use water to clean the exterior of the dehumidifier. To clean unit,
unplug from power, then use a damp cloth to wipe the exterior.
• Do not stand on dehumidifier or place objects on it.
• Do not use with extension cord or plug adapter.
• Unless otherwise noted, all maintenance should be done with the unit
powered off.
Specifications
±Ť±ÏЃDžƐÄƐíǑà8xƌǑŨB×Ɛ120 Pints Per Day
irflow @ 0.0” SP: 300CFM
Operating Temp. Range: 33-105°F
Operating Relative Humidity Range: 36%-90%
COP: 2.8 L/kWh
Refrigerant: R410A
Amperage Usage: 7.6 Amps
Power Supply: 115V/60Hz/Single Phase
Outlet Requirement: 15 Amp, 3 prong, GFCI
Sound Level: 60 dBa
Dimensions LxWxH: 23.75” x 14” x 16”
ETL Listed: Yes
How It Works
WH120 Dehumidifiers use an integrated humidistat to monitor the
conditioned space. When the relative humidity goes above the selected
setpoint, the dehumidifier will energize. Air is then drawn across an
evaporator coil, which is cooler than the dew point of air. This means
moisture will condense out of the air. The air is then reheated through the
condenser coil and distributed back into the room.
Installation Requirements
xThe area where the dehumidifier is located should be sealed with a
vapor barrier.
xIf the unit is installed in a crawl space, all vents should be sealed.
xFor proper ventilation, neither the inlet or discharge should be
positioned against a wall. The inlet needs a minimum of 12” clearance
and the discharge requires a minimum of 36” clearance.
xFor the best air diffusion, install the unit so that a side panel faces the
wall.
xWH120 Dehumidifiers are only intended for operation when the unit is
upright and level with the feet on the ground.
4

Installation
1. Place dehumidifier on a level surface.
•Do not place unit directly on vapor barrier. For example, use blocks
or pavers to create a level surface.
•If unit has been turned or flipped so that the compressor did not
remain upright, place the unit on a level surface and wait a minimum
of 2 hours before proceeding.
2. Set up the drain line.
•The drain line should be routed to a suitable drain on the outside.
•THE DRAIN MUST FLOW DOWN WITH NO LOOPS OR DIPS.
•Recommended Drain Option - Transition to PVC Pipe
1. Cut a piece of 3/4”OD PVC that is approx. 6” long.
2. Insert cut PVC into a 3/4” elbow.
3. Attach PVC+elbow to a 3/4”OD length of PVC to drain.
Keep the length of PVC as short as possible.
4. Insert the open end of dehumidifier drain tube into 6”
piece of PVC so that it does not extend into elbow fitting.
5. For a proper flow, a minimum downward slop of 1” per
10’ run is required.
6. Support the PVC tubing so that it maintains a smooth downward flow to drain.
3. Plug unit into a dedicated, 15 amp GFCI protected circuit.
Key Functions
1. Power Key
•Use this button to turn the dehumidifier on and off.
•Press once to turn machine on. You will hear two beeps and
the light will illuminate green (solid or flashing depending on
mode).
•Press the power button a second time and you will hear one
beep as the machine shuts down. Note that there is a 1 minute
fan delay.
5

1. Place dehumidifier on a level surface.
• Do not place unit directly on vapor barrier. For example, use blocks
or pavers to create a level surface.
• If unit has been turned or flipped so that the compressor did not
remain upright, place the unit on a level surface and wait a
minimum of 2 hours before proceeding.
2. Set up the drain line
• The drain line should be routed to a suitable drain on the outside.
• THE DRAIN MUST FLOW DOWN WITH NO LOOPS OR DIPS.
• Recommended Drain Option- Transition to PVC Pipe
1. Cut a piece of 3/4”OD PVC that is approx. 6” long.
2. Insert cut PVC into a 3/4” elbow.
3. Attach PVC+elbow to a 3/4”OD length of PVC to drain.
Keep the length of PVC as short as possible.
4. Insert the open end of dehumidifier drain tube into 6”
piece of PVC so that it does not extend into elbow fitting.
5. For a proper flow, a minimum downward slop of 1” per
10’ run is required.
6. Support the PVC tubing so that it maintains a smooth downward flow to drain.
3. Plug unit into a dedicated 15 amp GFCI protected outlet.
• Use this button to turn the dehumidifier on and off.
• Press once to turn machine on. You will hear two beeps and
the light will illuminate green (solid or flashing depending on
mode).
• Press the power button a second time and you will hear one beep
as the machine shuts down. Note that there is a 1 minute fan delay.
2. Arrow Buttons
4. Auxillary Terminals A5/A6
•Use the up and down arrows to set the desired humidity setpoint on
the display screen.
•The setpoint can be any number between 36%-90%. When the indoor
humidity is higher than the setpoint, the unit will operate.
•Keep in mind that the displayed humidity levels are approximate
(=/-5%).
3. Continuous Mode
•To set the unit to run continuously regardless of humidity, simply use
the down arrow key to set the humidity below 36%.
•The continuous light will illuminate green and the display will show
"CO".
•To switch back to normal humidistat operation, use the arrow keys to
move the setpoint above 36%.
•The A5/A6 on the terminal strip can be used as a safety switch for an
external float switch.
•It should be set to N/O (normally open) at the accessory float switch.
•If an E4 error occurs immediately, switch the wiring to N/C (normally
closed) on the external device. Note that you may need to unplug the
unit to reset the error code.
6

1. Place dehumidifier on a level surface.
• Do not place unit directly on vapor barrier. For example, use blocks
or pavers to create a level surface.
• If unit has been turned or flipped so that the compressor did not
remain upright, place the unit on a level surface and wait a
minimum of 2 hours before proceeding.
2. Set up the drain line
• The drain line should be routed to a suitable drain on the outside.
• THE DRAIN MUST FLOW DOWN WITH NO LOOPS OR DIPS.
• Recommended Drain Option- Transition to PVC Pipe
1. Cut a piece of 3/4”OD PVC that is approx. 6” long.
2. Insert cut PVC into a 3/4” elbow.
3. Attach PVC+elbow to a 3/4”OD length of PVC to drain.
Keep the length of PVC as short as possible.
4. Insert the open end of dehumidifier drain tube into 6”
piece of PVC so that it does not extend into elbow fitting.
5. For a proper flow, a minimum downward slop of 1” per
10’ run is required.
6. Support the PVC tubing so that it maintains a smooth downward flow to drain.
3. Plug unit into a dedicated 15 amp GFCI protected outlet.
Indicator Lights
1. Humidity Display Screen
3. Continuous Mode/Auto Defrost Light
•When the light illuminates green, it indicates that the
dehumidifier
is set to continuous operation mode.
•When the light illuminates red, it indicates the compressor has
been initiated but is currently warming up.
4. Compressor Light
•When the light illuminates red, it indicates the compressor has
been initiated but is currently warming up.
•Once the light switches to green, it means the compressor is
currently in working status.
1.
The display screen has two functions:
2.
When the unit is powered on, it shows the humidity of the
space.
•
When setting the desired humidity level, the screen will show
the set point. After a brief delay, it will revert to current humidity
of the space.
•
Power Indicator Light
•
This light indicates that the unit is properly powered on and ready
to operate.
•
Always make sure the unit is "off" prior to performing any service,
unless otherwise indicated.
If the humidity is above the setpoint, the light will be solid green
and the machine will operate.
If the humidity is below the setpoint, the unit will be in standby
mode and the light will be flashing.
7

• The area where the dehumidifier is located should be sealed with a vapor
barrier.
• If the unit is installed in a crawl space, all vents should be sealed.
• For proper ventilation, neither the inlet or discharge should be positioned
against a wall. The inlet needs a minimum of 12” clearance and the discharge
requires a minimum of 36” clearance.
• For the best air diffusion, install the unit so that a side panel faces the wall.
• WatchDog dehumidifiers are only intended for operation when the unit
is upright and level with the feet on the ground (unless using a WatchDog
Hanging Kit).
1. Place dehumidifier on a level surface.
• Do not place unit directly on vapor barrier. For example, use blocks
or pavers to create a level surface.
• If unit has been turned or flipped so that the compressor did not
remain upright, place the unit on a level surface and wait a
minimum of 2 hours before proceeding.
2. Set up the drain line
• The drain line should be routed to a suitable drain on the outside.
• THE DRAIN MUST FLOW DOWN WITH NO LOOPS OR DIPS.
• Recommended Drain Option- Transition to PVC Pipe
1. Cut a piece of 3/4”OD PVC that is approx. 6” long.
2. Insert cut PVC into a 3/4” elbow.
3. Attach PVC+elbow to a 3/4”OD length of PVC to drain.
Keep the length of PVC as short as possible.
4. Insert the open end of dehumidifier drain tube into 6”
piece of PVC so that it does not extend into elbow fitting.
5. For a proper flow, a minimum downward slop of 1” per
10’ run is required.
6. Support the PVC tubing so that it maintains a smooth downward flow to drain.
3. Plug unit into a dedicated 15 amp GFCI protected outlet.
• The display screen has two functions:
1. When the unit is powered on, it shows the humidity of the space
2. When setting the desired humidity level, the screen will show the
set point. After a brief delay, it will revert to current humidity of the
space.
• This light indicates that the unit is properly powered on and ready to
operate.
• Always make sure the unit is “off” prior to performing any service, unless
otherwise indicated.
• If the humidity is above the setpoint, the light will be solid green and the
machine will operate.
• If the humidity is below the setpoint, the unit will be in standby mode and
the light will be flashing.
• When the light illuminates green, it indicates that the dehumidifier
is set to continuous operation mode.
• When the light illuminates red, it means the unit is in auto defrost mode
and clearing the evaporator coils of any ice buildup.
• When the light illuminates red, it indicates the compressor has been
initiated but is currently warming up.
• Once the light switches to green, it means the compressor is currently
in working status.
f
Remote Control Instructions
WH120 Dehumidifiers can be controlled using an optional remote
accessory. The remote connects to your dehumidifier via a 25' CAT 5 cable,
with the integrated sensor giving you multiple options for monitoring
surrounding conditions.
Example #1- Install the dehumidifier in the laundry room and
duct it into the living room. Mount the remote in the living room and use the
remote sensor.
Example #2- Install the dehumidifier in your crawl space with
the remote mounted in your garage.
NOTE: The symbols indicated below only
show when the remote is powered on.
1. On/Off (Power) Button
Press the on/off button and the
machine will start running. Press
the button again to turn the
machine off.
2. Up Button/Down
Button
Use the up and down arrows to
adjust the humidity level.
3. Mode
Use the mode button to switch between dehumidifier and a
ducted application.
The symbol on the display indicates the sensor on the remote
control is being utilized.
The symbol on the display indicates the sensor on the dehumidifier
is being utilized.
4. Temperature
The T button changes the temperature reading on your remote. The remote
comes from the factory in Celsius. Press this button once to switch to
Fahrenheit.
5. Continuous
Press this button to switch the unit into continuous mode. “CONT.” will
appear on the display screen.
6. Drain Pump
This button is not applicable for WH120 models.
8

Operating Instructions
1. Start the machine.
•Press the power key to turn the dehumidifier on.
2. Adjust the settings.
•Use the up and down arrow keys to adjust your desired
setpoint (typically 50-55%).
3. Stop the machine.
•Press the power button again and the dehumidifier will stop.
Note that the fan will continue to operate for 1 minute after
the unit has shut off. DO NOT DISCONNECT THE POWER
CORD TO FORCE THE UNIT TO STOP.
4. Water drainage.
9

Unit Diagram
• During normal operation, the dehumidifier will automatically drain due
to gravity.
• If you want to move or store the machine, wait at least 10 minutes to
allow the unit to completely defrost.
• Once defrosted, lean the dehumidifier gently towards the drain to
ensure it is completely dry.
Maintenance
WARNING: Always unplug the unit before doing any maintenance.
Cleaning the Machine Body
•Use a soft, damp cloth to clean the exterior of unit. Do not use any
soap or solvents.
Coil Maintenance
•Once per year, clean the coils with an approved coil cleaner. The coil
cleaner should be a self-rinsing, foaming, cleaner, such as WEB® Coil
Cleaner.
10

**For more detailed instructions, visit www.SeairaGlobal.com**
WARNING: Always unplug the unit before doing any maintenance.
Cleaning the Filter
1. Unplug the unit.
2. For PreFilter:
a. Remove prefilter from inlet of machine.
b. Vacuum or wash with warm water (no soap).
3. For MERV-10/HEPA/Carbon Filters:
a. Replace as necessary- we recommend checking the
filter at least 1x/year
Electrical Access
•Unscrew the 13 screws on the side
panel.
•Remove the screw on the
control board cover.
• Mix a 16 ounce solution of bleach (1 oz bleach + 15 oz water) OR
vinegar (4 oz white vinegar + 12 oz water).
•Remove filter(s) so you have access to the drain tray.
•Disconnect power to dehumidifier.
•Pour the cleaning solution into the drain tray at the base of the
coils. If any cleaning solution gets on the coils, flush with water.
•Allow solution to soak for 15 minutes.
•Pour in 16-32 ounces of clean water to flush out the drain line.
Cleaning the Gravity Drain
Complete about once a year, depending on environment.
11

Dehumidifier Storage
If the unit will be stored for an extended period of time, complete the
following steps:
1. Turn off the unit and allow it to dry.
2. Wrap and secure the power cord.
3. Cover the filter mesh.
4. Store in a clean, dry space.
Ducted Applications
Ducting the dehumidifier allows the unit to be in one room while
conditioning an adjacent room. Both the inlet/return grille and the
supply grille are designed for 10” flex ducting.
Ducting Installation Notes
•Be sure to secure the ducting with tie wrap.
•Maximum total length of duct run = 10’.
•Inlet and outlet duct adapters are optional accessories.
Duct Adapter Installation
•Screw in the 4 screws on each
duct adapter.
Flex Duct Installation
•Slide ducting over adapter and
secure with tie wrap or clamps.
12

Troubleshooting
13

Spare Parts
14

shipment are borne by the customer. In addition, all ancillary charges related to freight shipments, including but not limited to palletizing, wrapping, labeling, and pickup are associated with customer.
Limited Warranty
All warranty benefits apply to the original owner only. Warranty cannot be transferred or assigned.
5 Years (From Date of Purchase):
Innovative Dehumidification Systems (IDS) warrants the WH85 Dehumidifier will operate free of
defects in workmanship and materials. At its discretion, IDS will repair or replace any malfunctioning
components, free of charge (excluding transportation costs).
Customer Responsibilities:
In order to take advantage of the warranty service, the customer must do the following:
1. Customer must provide normal care and maintenance (including, but not limited to cleaning
filters, coils and pumps).
2. Removal and re-installation of unit is the sole responsibility of owner.
3. If customer cannot return unit to certified repair center, all costs associated with freight shipment
are borne by the customer. In addition, all ancillary charges related to freight shipments, including
but not limited to palletizing, wrapping, labeling, and pickup are associated with the customer,
4. If shipped, customer is responsible for all risk of loss or damage.
Warranty Procedure:
1. Customer must mail in warranty registration card to IDS. If no card is submitted, warranty period
will begin the day the shipment left the warehouse. Please be sure to record serial # and date of
installation in the spaces provided on page 3 of the manual. You will need this information to
receive a Return Authorization (RA) number.
2. If warranty service is necessary, customer must contact IDS' customer service support at
910-660-0962 to receive an RA number.
3. Once an RA has been issued, it is the customer’s job to bring the unit to a certified repair center. If
this is not an option, shipping will be arranged to bring the unit back to our service warehouse (at
the expense of the customer).
4. After the unit has been received, an initial inspection will be completed. If it is determined to be an
invalid warranty claim (see exclusions below), unit repair will only be completed after receiving
payment from customer for all associated costs.
5. If unit is defective, the necessary parts will be repaired or replaced and the unit will be available
for pickup at certified repair center or returned via freight shipment (at customer’s expense). Keep
in mind that work is only done during normal working hours. After being repaired, all units are
required to go through a rigorous testing process prior to being returned to customer.
6. Once a part is repaired and the dehumidifier is returned, the original warranty period still applies
(no extensions).
15
15

Warranty Exclusions
THE FOLLOWING IS NOT COVERED UNDER WARRANTY
1. ACTS OF NATURE- INCLUDING BUT NOT LIMITED TO:
• FLOODING
• FIRE
• WATER DAMAGE
•
HURRICANE/STORM DAMAGE
2. IMPROPER USAGE- INCLUDING BUT NOT LIMITED TO:
• POOL/SPA/TUB APPLICATIONS
• MISUSE, ABUSE, OR TAMPERING WHETHER INTENTIONAL OR ACCIDENTAL
• IMPROPER INSTALLATION OR DESIGN
• IMPROPER VOLTAGE
•LACK OF NORMAL CARE
• FAILURE TO FOLLOW INSTRUCTIONS
3. CORROSION
4. FREEZING
5. ANY ADDITIONAL COSTS DUE TO CHANGES IN LAWS OR BUILDING CODES
6. FREIGHT CHARGES
7. ANY COSTS DUE TO LOST PROFIT OR DELAY
8. DAMAGE TO PROPERTY
9. CAUSE BEYOND CONTROL
10. CONSUMABLE PARTS, INCLUDING BUT NOT LIMITED TO:
• FILTERS
• BATTERIES
• POWER CORDS
• VALVES
• SWITCHES
RUBBER PARTS
11. APPLICABLE LAW AND VENUE
ALL ASPECTS OF THIS AGREEMENT SHALL BE INTERPRETED BY AND UNDER THE LAWS OF THE STATE OF NORTH
CAROLINA. ANY LITIGATION, ENFORCEMENT OF ARBITRATION, OR LITIGATION RELATED TO SHALL BE BROUGHT
IN THE APPROPRIATE COURT IN NEW HANOVER COUNTY, NORTH CAROLINA.
12. DIRECT, INDIRECT, COLLATERAL OR INCONSEQUENTIAL DAMAGES OF ANY KIND
THE WARRANTIES AND LIABILITIES SET FORTH ARE IN LIEU OF ALL OTHER W ARRANTIES EXPRESSED OR IMPLIED,
IN LAW OR IN FACT, INCLUDING IMPLIEDWARRANTIES OF MERCHANTABILITY AND FITNESS FOR PAR TICULAR
PURPOSE. INNOVATIVE DEHUMIDIFIER SYSTEM'S TOTAL LIABILITY, REGARDLESS OF NATURE OF CLAIM SHALL
NOT EXCEED ORIGINAL PURCHASE PRICE OF THE PRODUCT. IF A PRODUCT OR COMPONENT IS REPLACED WHILE
UNDER WARRANTY, THE APPLICABLE WARRANTY PERIOD SHALL NOT BE EXTENDED BEYOND THE ORIGINAL
WARRANTY TIME PERIOD.
THE FOREGOING SHALL CONSTITUTE THE TOTAL LIABILITY OF SELLER IN THE CASE OF DEFECTIVE
PERFORMANCE OF ALL OR ANY OF THE EQUIPMENT OR SERVICES PROVIDED TO BUYER. BUYER AGREES
TO ACCEPT AND HEREBY ACCEPTS THE FOREGOING AS THE SOLE AND EXCLUSIVE REMEDY FOR ANY
BREACH OR ALLEGED BREACH OF WARRANTY BY SELLER.
ANY DISHONESTY OR FRAUD IN CONNECTION WITH INNOVATIVE DEHUMIDIFIER SYSTEMS WARRANTY
THOROUGHLY VOIDS ALL WARRANTY POLICIES. INNOVATIVE DEHUMIDIFIER SYSTEMS EXPRESSLY RESERVES
THE RIGHT TO PURSUE LEGAL ACTION IN THE EVENT OF DISHONESTY, FRAUD, OR ATTEMPTED FRAUD.
16
