INOKIM Mini 2 User manual

3

54
Accessories included
Handles * 2, charger, allen key set, small wrench, pump.
Product parts
MINI 2
Size Open (length*width*height): 100cm*38.4cm*113.5cm
Folded (length*width*height): 96cm*38.4*30cm
Weight (with battery) 10kg
Finish
Automotive grade paint + electrostatic spray + Adonized Anodize treatment
Suggested load Less than 75kg
Main material AL6061/6063 Aircraft aluminium
Battery 36V 7.8Ah 18650Cell
Maximum speed (km/h) 25km/h
Range 23-28km (75kg load, 15km/h, 25°C, at road conditions)
Charging time 4h
Motor power 250W, Gearless
Tire specication Front: 6 inch pnumatic tire Rear: 6 inch rubber tire
USB output 5V 1A
Brake EABS brake + rear wheel friction brake
Parameters of charger Rated input voltage: 100v-240V
Rated output voltage: 42V 2A
Product Parameters
Deck
Security lock
Steering locker hook
Motor
T-Bar
Rear wheel
Rear suspention
Charging port
Rear break - Mudguard
Control
USB charging port
Front mudguard
Front wheel
Trolly wheels
Folding mechanism
Quick release latch
mounted on the other side
Steering rod
Reective strip
Handlebars

76
Basic operation
Power on:
on/o long press for 3 seconds
Changes in maximum speed:
on/o long press
Acceleration: Press on the acceleration lever
Brake: Press on brake lever / step on rear fender
Shut down:
on/o double press
Tips
The green light is for the energy saving mode with a
maximum speed of 15KM/h.
The blue light is for the performance mode with a
maximum speed of 25KM/h.
Note: When starting, kick with one foot
whilst pressing the acceleration lever
A. Pull the red hook outward to release
the steering rod and unfold MINI-2
B. Pull the pole up and click, to lock the
folding mechanism in open position
C. Open the quick release and pull up the
T-bar to the appropriate height
D. Screw the left and right handle bars to
the T-bar
Deceleration
Power display
On/O
USB charger port
Acceleration
Controls
Operation
1
2
2. Lock the safety lock
Unfolding Mini-2

98
Charging port on/o
A. Open the quick release and push the T-bar
down
C. Pull the pole down to interlock with the rear
mudguard
B. Hold the bar with both hands, while slightly
pushing forward, then kick the safety lock
with your foot
Steering locker hook
Rear mudguard
Make sure the hook enters the
slot of the rear mudguard
Folding Mini-2 Carrying the MINI-2
Charging
Trolly mode
Red light: Charging Green light: full battery
Roll along mode
1
2. Pull up the safety lock
Carrying mode

1110
Be safe be aware
1. Always follow local laws and regulations.
2. Wear safety helmets and protective gear which has passed relevant quality verication.
3. Check your INOKIM every time you drive it and if you nd any loose or damaged parts do not
drive it until the fault is corrected.
4. Check air pressure in the front wheel, do not ride when air pressure is below 35psi.
5. Pay attention to surrounding people and objects.
6. Do not drive in the rain or in wet road conditions.
7. Do not drive if drinking, taking sedatives or other drugs within the previous six hours.
8. Develop good riding skills and habits to avoid rapid acceleration and emergency deceleration
braking.
9. When driving among a large number of pedestrian get o your scooter and walk.
10. Do not drive in bad visibility. If you decide to ride, reduce your speed, be vigilant and add external
lights to ensure a good vision.
11. Keep the body relaxed when driving, do not hold tightly to the handlebars, keep your knees and
elbows slightly bent and relaxed whilst keeping your body upright and leaning slightly forward.
12. Do not let others use your INOKIM unless the person has read this manual.
Routine Maintenance
Cleaning and storage
1. It is advisable to clean your INOKIM scooter every time after use to ensure that the scooter
remains in good condition.
2. You can use a soft cloth with a small amount of water to wipe your INOKIM scooter.
3. You can use a rag to wipe the scooters tires and mudguards. Wipe them with a dry cloth as soon
as possible and place the scooter in a well ventilated place to avoid corrosion of metal parts. Do
not wash the rear wheel as the motor is located inside.
4.
When cleaning your scooter, make sure the scooter is turned o, the charger has been unplugged
and the charging cover is fastened in order to avoid electric shocks and / or scooter malfunction.
5. It is strictly forbidden to rinse the INOKIM scooter directly with a high-pressure hose or to soak the
vehicle in water when cleaning. The above may cause the accumulation of water vapor or water
owing into the body of the scooter, resulting in an unrecoverable failure.
6. Do not use alcohol, gasoline, kerosene, acetone or other corrosive chemical solvents to clean the
body of the scooter otherwise it will lead to the damage of the appearance and internal structure.
7. When not in use, please keep the INOKIM scooter in a dry and cool environment. Avoid extended
outdoor storage.
Check if any of the screws are loose
All screws in INOKIM scooters contain glue on the threads to prevent loosening.
For safety please check the components such as quick release, hub, battery pack and mudguard by
hand or tool to see if they are loose. If they are loose, use the relevant tool to fasten them.
Check the pneumatic tire regularly
Check the front tire regularly, do not ride when air pressure is below 35psi.

1312
Maintenance of battery pack and its usage specication
1. Do not run the motor when charging.
2. The display on the panel can only indicate the approximate power range. It is for reference only and
is cannot accurately display the power range.
3. Avoid contact with substances which leak out of the battery and do not let minors touch the battery.
4. If battery usage is not in accordance with the instructions or there is unauthorized removal of the
battery, the damage caused is not within warranty.
5. Avoid keeping the battery empty or overcharged for more than two months.
6. It is prohibited to dismantle or insert any items into the battery. This may lead to electric shock,
injury, burns and re.
7. Any attempt to disassemble the battery will damage the battery and release toxic substances.
8. You can only use the charger provided by INOKIM.
9. Transport the battery of INOKIM according to the relevant laws and regulations of the country or
region.
10. Do not use under the following circumstances: battery damage, a strange smell, overheating or
there is a leakage.
11. Do not use your INOKIM scooter in an environment above 50°C or below -20°C.
12. The performance of the battery will be decreased when the temperature is below 0°C.
