Inotek UT-6405W User manual

UT-6405W
100M 5
UT-6405W 5
IEEE 802.3 10BaseT
IEEE 802.3u 100BaseT(X) 100Base FX
RJ45 5 10/100BaseT X / MDI/
MDI-X
LED PWR 1 5 RJ-45
12/24/48VDC(10.8~52.8VDC)
100mA@24Vmax
13
IP30
\
-40 85
-40 85
0 95% ( )
EMI FCC Part 15 Subpart B classA EN55022 class A
EMS
IEC(EN)61000-4-2(ESD)
IEC(EN)61000-4-3(RS)
IEC(EN)61000-4-4(EFT)
IEC(EN)61000-4-5(Surge)
IEC(EN)61000-4-6(CS)
IEC(EN)61000-4-8
IEC 60068-2-27(Shock)
IEC 60068-2-32(Freefall)
IEC 60068-2-6(Vibration)
a. PWR 1
PWR
b. RJ-45 100 Base
10 Base
12/24/48VDC(10.8~52.8VDC)
12
UT-6405W
1. V+ V-
2. DC
12/24/48VDC
(10.8~52.8VDC)
1
23 1
V+V
1
2
3
150mm
5.90in
100mm
3.93in
37mm
1.45in
37mm
1.45in
37mm
1.45in
150mm
5.90in
37mm
1.45in
150mm
5.90in

UT-6405W
10/100M 5-Port Ethernet Switch
User manual
UT-6405Wis a 5-port industrial grade unmanaged Ethernet switch
with reverse polarity protection of DC input for avoidingbeing
damaged. It has ingenious appearance design and supportsindustrial
standard DIN-Rail and wall-mounted installation, so it'svery easy to be
installed and used in any industrial networks.
Standards:
Ports
RJ-45 ports: 5x10/100BaseT(X) ports, autodetection, auto
MDI/MDI-X
LED indicators: PWR,1~5 RJ-45 portsindicators
Power requirements:
Voltage input: 12/24/48VDC(10.8~52.8VDC)
Power consumption: 100mA@24Vmax
Terminal block:1x3-pin, pluggable
Overload protection:Yes
Reverse polarity protection:Yes
Characteristics:
IP rating:IP30
Installation: DIN-Rail/wall-mounted
Environment:
Operating temperature:
Storage temperature:
Relative humidity: 0%~95%(non-condensing)
Industrial standards
IEEE 802.3 10BaseT
IEEE 802.3u 100BaseT(X)and 100Base FX
:
-40 85
-40 85
:
EMI FCC Part 15Subpart B classA EN55022 classA
EMS
IEC(EN)61000-4-2(ESD)
IEC(EN)61000-4-3(RS)
IEC(EN)61000-4-4(EFT)
IEC(EN)61000-4-5(Surge)
IEC(EN)61000-4-6(CS)
IEC(EN)61000-4-8
IEC 60068-2-27(Shock)
IEC 60068-2-32(Freefall)
IEC 60068-2-6(Vibration)
a. PWR: When12/24/48VDC(10.8~52.8VDC) power supply
connected as shown in figure1, the powerlight on, theswitch
operates normally.
b. RJ-45: When network cableis connected, thegreen indicator on
the left is on when connected with 100Base, itwill not onwhen
connected with 10Base network; theyellow indicator onthe right
is network indication,it will flickerwhen internet access;the
yellow and green indicatorwill not onif without internetaccess
12
UT-6405Wseries industrial gradeEthernet switch supports
12/24/48VDC(10.8~52.8VDC) input, andthe reverse polarity
protection enables itfrom damage.
1.Connect thepositive/negative polarity toV+ and V-terminals
respectively
2. Tightenthe screws toavoid loose connection and bad contact.
Figure 1 Powerinput terminal
1. DIN-Rail
Push the topof the devicerail to fixedrail.
Then push itinto the railslightly again
2.Wall-mounted
.Tighten the metal fixation strip by screwsas shown inthe
above figure.
.Then hangthe machine withlocked metal strip onto wall or
machine cabinet.
3
150mm
5.90in
100mm
3.93in
37mm
1.45in
37mm
1.45in
37mm
1.45in
150mm
5.90in
37mm
1.45in
150mm
5.90in
23 1
V+V
