INSAFE INSAFE Origin User manual

1. RECOMMENDED PLACES TO MOUNT THE DETECTOR
Depending on the layout and the surface area of the dwelling, several smoke detectors may be required to ensure minimum
protection and guarantee efcient detection, the range of the alarm and quick evacuation of the dwelling.
Recommended installation Standard installation
Locate the detector in line with the current building standards.
Ceiling mounting:
Install the detector to the ceiling in the centre of the room,
minimum 30 cm from corners, walls, beams or any other obstacles.
Wall mounting:
Install the detector to the wall at a distance ranging between
30 cm and 60 cm from the ceiling.
Mounting on a sloped ceiling:
Install the detector at a distance ranging between 30 cm
and 60 cm vertically from the highest point of the ceiling.
30 cm
min.
30 cm
min.
60 cm
max.
Compliant
location
NEVER
HERE
CEILING
WALL
30 cm
min.
60 cm
max.
NEVER
HERE
Install in this area
CEILING
WALL
2. PLACES TO BE AVOIDED
Do not install the smoke detector:
Outside In a place where the alarm will be difcult to hear (room with closed door) In a place where the detector
will be difcult to reach, in particular to perform tests In a place where the temperature is lower than 4°C or higher than
45°C In a place where humidity is less than 10% or exceeds 95% (bathroom, kitchen, laundry room, etc.) In a place
subject to high and/or rapid temperature, pressure or humidity variations In a place where the sunlight hits directly on the
detector In a dusty or dirty area (garage, workshop, etc.) In a place where there are a lot of insects In a place where
spurious smoke may disturb the smoke detector: kitchen, chimney, garage (exhaust gas), furnaces, boiler rooms, combustion
3. INSTALLATION
Commissioning the smoke detector
Comply with the following commissioning procedure:
Activate the single-use switch (1)
Wait a few seconds then press the button of the detector for 3 seconds until
the alarm sounds, then release it for the alarm to stop (2)
The detector initialises for 10 minutes. At the end of the 10 minutes,
the detector is operational. The red diode will then ash every 5 and
a half minutes indicating that the detector is working properly.
Mounting the smoke detector
The screws and wall plugs supplied with the detector should preferably be used
to mount your smoke detector.
Comply with the following procedure:
Select an appropriate location on the ceiling or the wall to mount the detector
Remove the mounting base (3)
Use a pencil to mark the screw holes in the intended place on the ceiling or the wall
Drill two holes to match the screws with equipment suited to the type of ceiling
Insert the nylon wall plugs supplied
Clean the area with a dry cloth to remove any dust
Screw the mounting base into the ceiling(4)
(1)
(2)
The drawing inside the mounting base shows how to position
the detector across from its mounting base and the nal position
of the detector once it is clipped in
Place your detector on the mounting base by aligning the single-use switch with
the circular hole of the mounting base (5)
Turn it slightly towards the right. The detector must t into the mounting base
Turn the detector by a quarter turn towards the right to clip it in: you must hear
a click indicating that your detector has been properly secured into
its mounting base (6)
Make sure that your detector is completely secured to the ceiling
(3)
(4)
(5)
(6)
“clic”
4. BATTERY
The smoke detector has a maximum service life of 10 years. Beyond this limit,
it will no longer operate at peak efciency. Your detector and its remote control
are tted with a high-performance battery that has a duration of 10 years*. This
battery cannot be replaced. The detector and the remote control are sealed and
will operate throughout their entire service life The end of the battery life means
that you must change your detector and/or remote control.
5. MAINTENANCE
Clean the detector every month:
Remove dust from the detector with an antistatic cloth or with the brush end-tting of your vacuum cleaner
Clean the upper edges of the detector with an antistatic cloth
Immediately remove any insect, spider web or dust accumulated around your detect
CAUTION: Do not use a compressed air spray or equivalent
Standard installation
- on each oor
- in hallways and/or stairwells
- between rest areas (bedrooms), the possible ignition sources
(garage, area with a high electrical system, etc.) and exits
leading outside of your home (door, window)
Recommended installation
Place a detector:
- on each oor, every 7 m
- in each stairwell per level
- in each room (1 for 50 m²), except in the kitchen
and the bathroom (refer to paragraph 2: Places to
be avoided)
It is recommended to install smoke detectors:
- less than 7 m from possible ignition sources
- less than 7 m from rest areas (3 m if the doors are closed)
- less than 7 m from exits
radiators, etc. Close to heating appliances, windows, ventilation ducts, air conditioners, fans or any other item of equipment
that may produce air ows Close to an area that is hotter or cooler than the rest of the room (non-insulated walls, hatches,
etc.) Less than 1.5 m from obstacles preventing the smoke from accessing the detector (decorative objects, walls, doors,
plants, chandeliers, curtains, etc.) Less than 1.5 m from lighting appliances (ceiling light, incandescent lamps, halogen or
uorescent lamps, etc.) Less than 1.5 m from electrical appliances or their wiring.
6. PRECAUTIONS AND LIMITS OF USE
For your safety, please comply with the following measures:
You must follow all instructions in this manual. Please bear in mind that it may be dangerous to mute or switch off the
detector or to refuse to replace your detector when specied by the manual. Do not install the detector in one of the
situations described in paragraph 2 “Places to be avoided”.Do not paint or cover the detector.Do not block the detector
openings. Do not disassemble, modify or damage the detector. Do not place bare ignition sources such as lighted candles
underneath the detector. The detector must remain in place at all times. The detector is not a transportable product. To
avoid accidents, the detector must be safely secured to the ceiling or wall in accordance with the installation instructions. 
The detector is unable to detect res outside of the dwellings. The detector will not be able to detect a re if an insufcient
quantity of smoke reaches the detector sensor (smouldering re, re too far away, etc.). It is recommended to install several
detectors for optimum safety. The detector cannot be used for people who are hearing impaired. The manufacturer recom-
mends a monthly maintenance of the detectors. It is dangerous to suspect a false alarm as the smoke preceding the onset
of the ames are toxic and may cause you to lose consciousness: despite the absence of ames, a re may blaze up in a few
minutes. If false alarms are frequent, you may need to change the location of your detector and move it further away from
the sources of false alarms. The maximum date of commissioning must not exceed 5 years after the date of manufacture
afxed to the detector. The detector must not be used after the maximum specied use-by date: the maximum use-by date
is equal to the date of manufacture afxed to the detector + 10 years. The detector must no longer be used and must be
replaced subsequent to a re or after a signicant amount of smoke or under abnormal conditions.
The detector is designed to have a service life of 10 years* enabling it:
To detect res for 10 years To power the alarm signal for 4 minutes at 85 dB. To perform weekly tests for 10 seconds.
To indicate that the battery is low via an audible signal for 30 days.
The detector is designed to operate in a normal household environment:
Temperature: 15°C to 35°C. Humidity: 25% to 75%. Atmospheric pressure: 86 to 106 kPa.
The detector may be used in an exceptional household environment:
Temperature ranging between 4°C and 45°C. Humidity ranging between 10% and 95%. Recurrent and/or prolonged
use in this exceptional environment may reduce the battery life and consequently the service life of the detector..
INSAFE Origin and INSAFE+ Control are Smoke Detection and Alarm Devices for household use.
A smoke detection and alarm device is a product designed to give off an audible signal to warn that a re has started.
The detector will only trigger the alarm in due time if it is properly located, installed and maintained in accordance with the
instructions in this manual.
INSAFE Origin and INSAFE+ Control are designed and manufactured by NEXELEC, 67 COURS MIRABEAU
13100 AIX-EN-PROVENCE FRANCE
D232E_EN
INSTRUCTION MANUAL
Smoke detector
Please read this instruction manual carefully before use!
The documentation supplied with this product must be retained throughout its service life..
Bathroom Kitchen
Living room
Bedroom
Bedroom
Bedroom
Dining room
16
EN14604:2005/AC:2008
1922-CPR-0582
Product model: I740SX
Product model: I730FW
INSAFE Origin
INSAFE+ Control
Notice D232E_EN.indd 1 31/05/2016 08:43

on the residence. The malfunction or failure of the detector to operate due to contamination by dust and/or by insects despite
maintenance that complies with this manual is considered as normal wear of the device and cannot be covered by the warranty
asitisunpredictableanddependsontheresidence.Thewarrantyisnotaninsurancepolicy.This warranty is a complement to your
legalwarranties of conformity and those relatingtodefects of the things sold.Iftheproduct is found to bedefective,theapplication
ofthe warranty under the conditionsmentionedinthe user manual willresultinthe repair or replacement ofthedefective detector.
9. AFTER-SALES SERVICE
Prior to requesting the application of the contractual warranty, you must consult the information available on the Insafe
website www.insafe.fr/support and obtain a return number. The warranty will not be applied if you do not have a return
number.
If a defect is found during the warranty period, the purchaser must dispatch the detector by post to the NEXELEC Customer
Service Department. The detector must be accompanied by dated proof of purchase and a letter requesting application of the
warranty and explaining the defect found.
10. ACTIONS TO BE TAKEN IF THE SMOKE DETECTOR ALARM SOUNDS
BEFORE AN ALARM
Familiarise yourself with the sound of the alarm Devise an evacuation plan, learn the evacuation itinerary, do test runs
IN THE EVENT OF AN ALARM FURTHER TO A FIRE
A. Keep calm
B. Immediately evacuate your family from the dwelling, without taking anything with you,
in accordance with the evacuation plan
C. Be careful of the heat and smoke, keep your head down, cool air is close to the ground; cover your nose and mouth
with a wet cloth
D. Close the door of the room on re and the entrance door
E. Once outside, call the reghters by dialling 112 (single European emergency number)
State the reason for the call (type of re)
Give your exact address and state whether there are victims and the severity of their injuries
Answer all questions asked by the reghters. Do not hang up before being told to do so
F. Do not try to go back inside the house
G. Never take the lift
CAUTION: If all ways or staircases are completely engulfed in smoke:
H. Stay inside
I. Take shelter in a room
J. Close all inside openings (doors, air vents, etc.)
K. Call the reghters by dialling 112 (single European emergency number)
L. Place wet rags at the base of the doors and in front of inner openings
M. Go to the window so that emergency response personnel can see you
SUSPECTED FALSE ALARM
Suspecting a false alarm is dangerous as the smoke preceding the breakout of ames are toxic and may cause you to lose
consciousness. Despite the absence of ames, a re may break out in a matter of minutes. It is recommended not to suspect
a false alarm and to systematically follow the above instructions (A to G).
11. FEATURES OF THE SMOKE DETECTOR
Smoke detector using the light scattering or transmission principle
Absence of radioactive substances
Delivered with battery
Environmental protection: membership in an eco-friendly waste management organisation
Associated service: customer helpline
* According to the declaration of performance in force
Type of mounting: Wall or ceiling
Ceiling only
Wall only
YES NO
YES NO
YES NO
Main power supply Within the device
Battery life 1 year 5 years 10 years
Individual alarm indicator YES NO
Alarm silence facility YES NO
Suitable for installation in a mobile home YES NO
Interconnectable device YES NO
Connection to external auxiliary devices YES NO
Radio link YES NO
INSAFE accessibility YES NO
INSAFE + accessibility YES NO
12. OPERATION OF THE DETECTOR AND THE REMOTE CONTROL
The button must be pressed and held for 5 seconds for the remote control to operate..
After installation, the red diode will ash every 5 and a half minutes thereby indicating proper operation of the detector.
In the event of an alarm, the alarm tone sounds and the red diode starts ashing several times per second.
CAUTION: Keep the detector away from your ears or wear ear plugs.
It is recommended to carry out a visual check of the detector every week, to perform a functional test of the detector every
month and a functional test of the detector with a test aerosol every 3 month.
CAUTION: Only use test aerosols recommended by the manufacturer for the smoke detector
Certain conditions may damage the detector, reduce the battery sensitivity and/or life and therefore
the service life of the detector:
Exposing the detector to temperatures, humidity or atmospheric pressures that differ from the normal environment
dened above. Performing additional tests or a high number of real or false alarms which trigger the alarm tone.
Excessive cleaning of the detector. The presence of recurrent smoke and/or a signicant amount of smoke in conditions
considered normal with the detector in Pause mode or not.
7. SCRAPPING AND RECYCLING
This symbol, afxed to the detector and packaging, means that the product must not be scrapped with
household waste, in accordance with European Directive 2002/96/EC on Waste electrical and electronic
equipment (WEEE).
The detector must be handed over to an appropriate collection point for the recycling of electrical and
electronic equipment. Comply with the laws of the state with regard to scrapping.
By cooperating with these instructions, you are helping to eliminate the potential effects of hazardous
materials on the environment and human health as well as enhancing reuse, recycling and other forms of recovery of
such waste. NEXELEC is a member of the following eco-friendly waste management organisation: Ecologic
CAUTION: The detector contains a lithium battery: do not throw on re, melt or incinerate.
8.WARRANTY
NEXELEC offers a contractual warranty of the INSAFE and INSAFE+ “Smoke Detection and Alarm Devices” on the EU
territory, covering the features for which the devices were designed, in accordance with Regulation and applicable European
Directives, for a period of 5years as from the date of purchase.
This warranty does not cover damage caused to the detector due to voluntary re, negligence, poor or inappropriate
storage conditions, mishandling, improper fastening, incorrect use, lack of maintenance (refer to the User Manual), disas-
sembly,modication, failure to comply with the precautions of use of the smoke detector recommended in the user manual.
This warranty does not apply to damage caused by the use of incorrect mounting means or failure to comply with the
mounting process or faulty mounting operations. Since many factors may inuence the mounting quality of the detector,
only the user is able to control the risks inherent to mounting the detector, as these factors are unpredictable and depend
BUTTON RED DIODE BUZZER DETECTOR CONDITION ACTION
Test Press the detector button or press the remote
control button for 5s. until the alarm sounds
then release
1 Flash several times per
second if the test is working
Alarm sound signal if
the test works
OPERATIONAL
after 10minutes
If the test does not work, the detector probably detected an operating defect. Firstly make sure that
you have properly complied with the precautions of use of the detector. If such is the case, carry out
the operation again (twice) if necessary. If the test still does not work, wait 15minutes and carry out
the operation again (twice) if necessary. If the test still does not work, the detector must be replaced.
Pausing the
alarm
Press the detector button or press the remote
control button for 5s. until the red diode starts
to ash
1 Flash every 10s. for
approximately 10minutes
OPERATIONAL
after 10minutes
Your detector then starts to operate automatically.
Pausing the alarm helps to control a pending false alarm in advance (e.g.: smoke or steam when cooking,
use of candles or incense, cigarette smoking, etc.)
Stopping the
alarm
Press the detector button or press the remote
control button for 5s. until the alarm stops 1 Flash every 10s. for
approximately 10minutes OPERATIONAL
after 10minutes
Your detector then resumes automatic operation..
Low battery
indicator
1 Flash for 45s. for at least
30days 1 Beep every 45s. for at least 30days NON-OPERATIONAL The detector must be replaced
Pausing the low
battery warning
Press the detector button or press the remote
control button for 5s. until the red diode starts
to ash
1 Flash every 45s. for 8hours
approximately NON-OPERATIONAL The detector must be replaced
Smoke detector
end-of-life
warning
1 Beep every 45s. until
the batteries are dead NON-OPERATIONAL After 10years of use, the detector must be replaced
Defect 1 Flash every 45s. 1 or 2 Beeps every
45s.. NON-OPERATIONAL Make sure that you have properly complied with the precautions of use. If such is the case and the defect
alarm continues after 15minutes, then the detector must be replaced
Test, Stop,
Pause button
Red
diode
Operation of the remote control (INSAFE+)
The remote control is available and only operates with the INSAFE+ detector
The remote control can only be used underneath the detector, perpendicular to its mounting axis
When you press the button, the green diode comes to indicate proper operation of the remote control
Test, Stop, Pause
button
Green diode
Notice D232E_EN.indd 2 31/05/2016 08:43
