2gig Technologies WIRELESS SMOKE/HEAT/FREEZE ALARM Configuration guide

2GIG‐SMKT3‐345
WIRELESS SMOKE/HEAT/FREEZE ALARM
INSTALL INSTRUCTIONS
FCCID:ZFH‐SMKT3345
IndustryCanadaID:9640A‐SMKT3345
2GIG’sWirelessSmoke/Heat/FreezeAlarmisa3xAAAbattery‐poweredwirelessalarmintended
foruseina2GIGsystem.Thealarmhasabuilt‐inwirelesstransmitter,whichcommunicates
withthe2GIGControlPanel.Whensmoke,excessiveheatorcoldisdetected,thealarmsounds
aloudlocalalarmandthebuilt‐intransmittersendsasignaltotheControlPanel.Thisalarmis
designedtoprovideprotectionwithina35‐footradiusoftheunit.The2GIG‐SMTK3‐345can
sendalarm,tamperandbatteryconditionmessagestotheControlPanel.
Box Contents
•WirelessSmoke/HeatAlarm
•Packofscrewsandfixings
•3AAAEnergizerE92batteries(1.5V1100mAh)orequivalent
TheWirelessSmoke/HeatAlarmcontainsasounderthatgeneratestheASHIs3.41temporal3
patterninanalarmcondition.
Inalarm,amessageisalsosenttotheControlPanelandthealarm’szonetypeandnameare
displayedatthepanel.Duringanalarmcondition,pressingthealarm’shushbuttonsilencesthe
sounder.TricoloredLED(red,yellow,green)andasounderonthealarmprovidelocalvisualand
audibleindicationofthealarm’sstatus.
Afterpower‐uphascompletedandthealarmisfunctioningnormally,thegreenLEDblinksevery12
seconds.
AlarmTrouble:Whenthealarmhasageneralfault,theyellowLEDblinksonceeveryfourseconds
andthereisachirpevery48seconds.After4hoursthe2GIGControlPaneldisplaysalossof
supervisionmessage.
AlarmDirtyFeature:Whenthealarmhasbeencontaminated,theyellowLEDblinksonceevery8
secondsandthereisachirpevery48seconds.After4hoursthe2GIGControlPaneldisplaysaloss
ofsupervisionmessage.
LowBatteryDetection:TheWirelessSmoke/HeatAlarmispoweredby3AAAbatteries.Thealarm
regularlychecksforalowbattery.Ifalowbatteryisdetected,thetransmittersendsalowbattery
messagetothe2GIGControlPanel,thatdisplaysthealarm’sIDatlowbattery.Inaddition,the
yellowLEDofthealarmblinksevery12seconds.Thealarm’ssounderchirpsevery48seconds
(yellowLEDcontinuestoblink)untilthebatteriesarereplaced.Pressingthehushbuttonsilences
thechirpingfor12hoursifnoothertroubleconditionsexist.Replacethebatterieswhenthe
chirpingbegins.Replacetheoldbatterieswithnewones.
Ifyouareexperiencinglowbatteryissues,checktomakesurethatyouhavethecorrectbatteries
installed(3AAAEnergizerE92).
Inserting and Replacing Batteries
1. Removethealarmfromitsbasebytwistingtheitcounter‐clockwise.Removeanddisposeof
thebatteriesaccordingtoyourlocalregulations.
2. Toensureproperpower‐downsequence,waitaminimumof20secondsbefore
insertingnewbatteries.
3. Insert3AAAEnergizerE92batteriesinthebatterycompartment.Followthepolaritydiagram
insidethecompartment.Ifthebatteriesareinsertedincorrectly,removegentlywithanon‐
conductivetoolandcorrectlyreinsert.
4. Reinstallthealarmontothemountingbasebyturningthealarmclockwiseuntilthemating
marksalign.
5. Afterthepower‐upsequence,thegreenLEDshouldblinkaboutonceevery12secondsto
indicatenormaloperation.Ifthebatteriesarenotinsertedcorrectly,thealarmwillnotoperate
andthebatteriesmaybedamaged.Ifthealarmdoesnotpower‐up,checkforcorrectbattery
insertionandforfullychargedbatteries.
Constantexposuretohighhumiditymayreducebatterylife.
Programming
Thefollowingstepsdescribegeneralguidelinesforprogramming(learning)theWireless
Smoke/HeatAlarm(2GIG‐SMKT3‐345)intothe2GIGControlPanel.Scrollbetweenoptions
usingthe←and→arrows.Movetothepreviousornextpromptbypressingthe↑and↓
arrows.FormoredetailsregardinghowtoprogramtheControlPanel,refertothe2GIG
ControlPanelInstallGuide.
1. SelectRFsensor#(01to48).AssigntheWirelessSmoke/HeatAlarmtoanewzone.
2. SelectRFsensortype.
(09)24‐hourfire(recommendedforsmokeandfire)
(16)24‐hourfirewithverification(optional)
(23)noresponsetype(optionalwithfreeze)
3. SelectRFequipmenttype.
4. SelectRFsensorequipmentcode.Enter1058fortheSMKT3‐3452GIGSmoke/HeatAlarm.
5. EnterRFsensorserialnumber(7digits).
ManualEntry:Typeinthelast7digitsoftheTXIDthatisfoundoutsidetheboxoronthe
bottomoftheheadunitbyremovingthebase.
AutoEntry:WiththepanelinLearn‐inmode(pressShiftthenLearn)causeatamperonthe
alarmbytwistingthebaseunitcounter‐clockwiseandremovingit.ThecorrectTXIDshould
appear.AcceptthecorrectTXIDbypressingok.
Remembertopressthe↓arrowtocontinuethroughthesystemconfigurationprompts.
6. SelectRFsensorequipmentage.
(0)new(productisnew)
(1)existing(productalreadyexists).
7. SelectRFsensorloopnumber.Selectwhichloopyouwouldliketosetup.
(1)Smoke
(2)Heat
(3)Freeze
NOTE:Eachloopmustbesetupasadifferentzone.Ifyouwanttoutilizeallthreefeatures
(smoke,heat,freeze)youwillneedtosetupthreedifferentzonesanduseeachloop.
8. SelectRFsensor1dialerdelay
(0)disabled(thereshouldneverbeadialerdelayonthistypeofalarm)
9. ConstructRFsensordescriptor.PressInsertthenpressanynumberbetween002and255to
addaword.Forexample,ifyouwantedtonamethisalarmas“smokealarm,”pressInsertthen
press208forSMOKE.PressInsertthenpress005forALARM.
10. SelectRFsensorreports(0to1).
(0)disabled(sensordoesnotreporttocentralstation)
(1)enabled(sensorreportstothecentralstation)
11. SelectRFsensorsupervised(0to1).
(0)disabled(sensordoesnotreportlossofsupervisionorlowbattery)
(1)enabled(sensorreportslossofsupervisionorlowbattery)
12. SelectRFsensorchime(0to13).
(0)disabled(panelwillnotchimewhensensorisactivated)
(1)‐(13)(selectsavoiceandchimetosoundwhensensorisactivated)
13. Toprogramanothersensor,clicknext.
14. Toexitprogramming,clickskipthenendandexit.Uponexit,thepaneltakesafewsecondsto
reset.
Testing
Beforetesting,putthepanelintotestmodesothecentralstationisnotnotifiedtoprevent
unwantedalarms.TestingthealarmactivatesanalarmsoundandsendsasignaltotheControl
Panel.Thetestfunctioncannotbeusedifthealarmhasatroublecondition.
Testalarmsounder,LEDsandtransmitter
1.HoldtheTestbuttonfor4beeps(approximately6seconds).
2.ReleasetheTestbutton.
3.Oncereleased,theproductwillcontinuetobeep5moretimes.Beforethebeepsstop,a
signalwillbesenttriggeringthealarm.
SmokeTest
Holdacottonwickatthesideofthealarmandgentlyblowsmokethroughthealarmuntilthe
smoketriggersthealarm.Youcanalsousesmokeaerosol.
DirectHeatTest(UseHairDryer1000‐1500Watts)
Directheattowardthealarm.Holdtheheatsourceabout12inchesfromthealarmtoavoid
damagetotheplastic.Thealarmresetsonlyafterithastimetocool.
Ifanalarmfailsanyofthesetests,seeMaintenanceforhowtocleanthealarm.
Mounting the Alarm
1. Seethediagramtoinstallthemountingbaseontheceilingoronthewall.Usethe2screwsand
anchorsprovided.Maneuverthebasesothescrewsareattheelbowofthescrewslotsand
secure.
2. Fitthealarminsidethebasebyaligningitoverthebaseasshown(alarm’salignmentnotch
shouldbeslightlyoffsetfromthemountingbasetamperreleasetab),thenturnthealarm
clockwiseuntilthealarmclicksintothebase.

NFPA Recommended Locations for Alarm
AccordingtotheNationalFireProtectionAssociation(NFPA)themajorthreatfromfireina
dwellingunitoccursatnightwheneveryoneisasleep.Theprincipalthreattopersonsin
sleepingareascomesfromfiresintheremainderofthehouse;thereforesmokealarmsare
bestlocatedbetweenthebedroomareasandtherestofthehouse.
WhereNOTtoinstalltheAlarm
•Directlyaboveasink,cooker,stoveoroven
• Donotlocatealarmwithin5feet(1.5m)ofanycookingappliance
•Nexttoadoororwindowthatwouldbeaffectedbydrafts(extractorfanorairvent)
• Outside
•Inorbelowacupboard
•Whereairflowwouldbeobstructedbycurtainsorfurniture
•Wheredirtordustcouldcollectandblockthesensor
•Whereitcouldbeknocked,damaged,orinadvertentlyremoved
DoNOTINSTALLthisalarminalocationwherethenormalambienttemperatureis
below40F(4.4C)orwhereitexceeds100F(37.8C)
INSTALLthisequipmentinaccordancewiththeNationalFireProtectionAssociation(NFPA)72.
Maintenance
Cleanthealarmonceayear.Tocleanthealarm,removeitfromthemountingbase.Youcan
cleantheinteriorusingcompressedairoravacuumcleaner.Bloworvacuumthroughthe
openingsaroundtheperimeterofthealarm.Theoutsideofthealarmcanbewipedwitha
dampcloth.Aftercleaning,testthealarmbypushingtheTestbutton.Ifcleaningdoesnot
restorethealarmtonormaloperationyouneedtoreplacethealarm.
WARNING:READTHEFOLLOWINGCAREFULLY
•NFPA72states:Fire‐warningequipmentforresidentialoccupanciesarecapableof
protectingabout50%oftheoccupantsinpotentiallyfatalfires.Victimsincludethe
elderly,children,andthephysicallyormentallyimpaired.Victimsincludeanyperson
thatcannotescapeevenwhenwarnedearlyenoughthatescapeshouldbepossible.For
thesepeople,otherstrategiessuchasprotection‐in‐placeorassistedrescueorescape
wouldbenecessary.
•StudiesshowthatSmoke/HeatAlarmsmaynotawakenallsleepingindividuals.Itisthe
responsibilityofindividualsinthehouseholdthatarecapableofassistingothersto
provideassistancetothosewhomaynotbeawakenedbytheaudiblealarmorthose
whomaybeincapableofsafelyevacuatingtheareaunassisted.
•Abattery‐poweredalarmmusthavethespecificbatterytypeinstalled,beingood
condition,andbemountedproperly.
•Theuseofalcoholordrugsmayalsoimpairone’sabilitytoheartheaudiblealarm.For
maximumprotection,ensurethatanaudiblealarmisinstalledoneveryfloorofthe
home.
•Smoke/HeatAlarmsonlyprovideprotectiontotheresidenceifsmokeactuallyreaches
thealarm.TheSmoke/HeatAlarmisnotasubstituteforaninsurancepolicy.
Homeownersandrentersshouldhaveadequateinsurancetoprotecttheirproperties.
Safety Tips
• MakeaFamilyEscapePlan.Drawamapofyourhomeshowingalldoorsandwindows.
Discusstheplanwitheveryoneinthehome.
•Knowatleast2waysoutofeveryroom,ifpossible.Makesurealldoorsthatleadtothe
outsideofhomeopeneasily.
•Haveanoutsidemeetingplace,likealightpole,mailbox,ortreeasafedistancefromthe
residencewhereeveryonemeets.
•PracticeyourFamilyEscapePlanor“FireDrill”atnightandduringthedayatleasttwicea
year.Onlypracticewheneverymemberofthehousecanattend.
•Practiceusingdifferentwaysout,ifpossible.
•Teachyourchildrenhowtoescapeontheirownincaseyoucannothelpthem.
•Closedoorsbehindyouasyouleave.
Family Escape Plan
AccordingtotheNationalFireProtectionAssociation(NFPA)thereoftenisverylittle
timebetweenthedetectionofafireandthetimeitbecomesdeadly.Thisintervalcanbe
aslittleas1minute.Planningandpracticingforfireconditionswithafocusonrapidexit
fromtheresidenceareimportant!Firedrillsshouldbeheldsothatallfamilymembers
knowtheactiontobetaken.
If the Alarm Sounds
•Getoutandstayout.Nevergobackinsideforpeopleorpets.
•Ifyouhavetoescapethroughsmoke,getlowandgounderthesmoke.
•Callthefiredepartmentfromoutsideyourhome.
FORMORESAFETYINFORMATIONSEE:www.nfpa.org/education
Specifications
Regulatory Information
ThisdevicecomplieswithPart15oftheFCC'sRules.Operationissubjecttothefollowing
twoconditions:
1Thisdevicemaynotcauseharmfulinterference,and
2Thisdevicemustacceptanyinterferencereceived,includinginterferencethatmay
causeundesiredoperation.
ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigital
device,pursuanttoPart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonable
protectionagainstharmfulinterferenceinaresidentialinstallation.
Thisequipmentgenerates,usesandcanradiateradiofrequencyenergyand,ifnotinstalled
andusedinaccordancewiththeinstructions,maycauseharmfulinterferencetoradio
communications.However,thereisnoguaranteethatinterferencewillnotoccurina
particularinstallation.Ifthisequipmentdoescauseharmfulinterferencetoradioor
televisionreception,whichcanbedeterminedbyturningtheequipmentoffandon,the
userisencouragedtotrytocorrecttheinterferencebyoneormoreofthefollowing
measures:
• Reorientorrelocatethereceivingantenna.
•Increasetheseparationbetweentheequipmentandreceiver.
•Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthe
receiverisconnected.
•Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
ThisproductcomplieswithFCCradiationexposurelimitsforanuncontrolledenvironment.
Avoidoperatingthisproductatadistancelessthan20cmfromtheuser.
Caution:Anychangedormodificationsnotexpresslyapprovedbythepartyresponsiblefor
compliancecouldvoidtheuser'sauthoritytooperatethisequipment.
IC approval
ThisdevicecomplieswithIndustryCanadalicense‐exemptRSSstandard(s).Operationis
subjecttothefollowingtwoconditions:(1)thisdevicemaynotcauseinterference,and(2)
thisdevicemustacceptanyinterference,includinginterferencethatmaycauseundesired
operationofthedevice.
RÉGLEMENTATIONIC:CetappareilestconformeavecIndustrieCanadaexemptsdelicense
standardRSS(s).L'opérationestsoumiseauxdeuxconditionssuivantes:(1)cetappareilne
peutcauserd'interférences,et(2)cetappareildoitacceptertouteinterférence,ycompris
lesinterférencesquipeuventcauserunmauvaisfonctionnementdul'appareil.
CetéquipementestconformeauxlimitesICexpositionaurayonnementpourun
environnementnoncontrôlé.Cetéquipementdoitêtreinstalléetutiliséavecdistance
minimumde20cmentrel'utilisateuretl'élémentrayonnantdel'appareil.
Remarque:lefabricantn'estpasresponsabledesinterférencesradiooutélévisioncausépar
desmodificationsnonautoriséesdecetéquipement.Unetellemodificationpourrait
annulerl'autoritédel'utilisateurd'exploitercetéquipement.
ThisClassBdigitalapparatuscomplieswithCanadianICES‐003
CetappareilnumériquedeclasseBestconformeIaánormeNMB‐003duCanada.
LIMITED WARRANTY
This2GIGTechnologiesproductiswarrantedagainstdefectsinmaterialandworkmanship
for1year.Thiswarrantyextendsonlytowholesalecustomerswhobuydirectfrom2GIG
Technologiesorthrough2GIGTechnologies’normaldistributionchannels.2GIG
Technologiesdoesnotwarrantthisproducttoconsumers.Consumersshouldinquirefrom
theirsellingdealerastothenatureofthedealer’swarranty,ifany.
Therearenoobligationsorliabilitiesonthepartof2GIGTechnologiesforconsequential
damagesarisingoutoforinconnectionwithuseorperformanceofthisproductorother
indirectdamageswithrespecttolossofproperty,revenue,orprofit,orcostofremoval,
installation,orreinstallation.Allimpliedwarrantiesforfunctionality,arevalidonlyuntilthe
warrantyexpires.This2GIGTechnologiesWarrantyisinlieuofallotherwarrantiesexpressed
orimplied.
For technical support in the USA and Canada
855-2GIG-TECH (855-244-4832)
For technical support outside of the USA and Canada
Contact your regional distributor
Visit 2gig.com for a list of distributors in your region
PN:77‐000012‐001Rev.D
2GIG Copyright © 2013. All rights reserved.
TransmitterFrequency 345.00MHz(crystalcontrolled)
TransmitterFrequencyTolerance +‐15kHz
TransmitterBandwidth 24kHz
ModulationType AmplitudeShiftKeying‐On/OffKeying(ASK‐OOK)
UniqueIDCodes Over1billiondifferentcodecombinations
SupervisoryInterval 70minutes
Dimensions .5”x2.5”high(125mmx63mmhigh)
Weight(includingbatteries) 8.57oz(243g)
Color White
SpacingRating 70ft
AudibleSignal(ANSITemporal3) 85dBAmin.inalarm
Sensitivity .5‐3.5%/foot
MaxCurrent 50mA
AlarmCurrent 20mA
SupervisoryCurrent 25uA
OperatingTemperature40°‐100F°(4.4°‐37.8°C)
RelativeHumidity 15‐90%Non‐Condensing
Batteries(included) 3AAAEnergizerE92orequivalent
RegulatoryListing UL217
Warranty 2years
IncludedAccessories MountingHardwarePackage
