QUICK SETUP GUIDE
13.8 Cu.Ft. Upright
Freezer
NS-UZ14XWH7 / NS-UZ14XWH7-C
Before using your new product, please read these instructions to prevent any damage.
PACKAGE CONTENTS
• 13.8 cubic foot upright freezer
• Door handle and screws
• Bottom decorative cover and screws
• Quick Setup Guide
FIND YOUR USER GUIDE ONLINE!
Go to www.insigniaproducts.com, enter your model
in the search box, then press ENTER. Next to
Features, click Support & Downloads, then next to
User Guide, click the language you want.
SETTING UP YOUR FREEZER
Before using your freezer
• Remove the exterior and interior packing.
• Let the freezer stand upright for approximately two hours
before connecting it to power.
• Wipe the inside.
• When moving your freezer, do not tilt it beyond 45° from
upright.
Finding a suitable location
• This freezer is designed to be free standing only, and
should not be recessed or built-in.
• Place your freezer on a oor that is strong enough to
support the freezer when it is fully loaded.
• Allow 7.9 inches (20 cm) of space between the sides of the
freezer and the walls, 3.9 inches (10 cm) between the back
of the freezer and the wall, and 11.8 inches (30 cm)
between the top of the freezer and the ceiling.
• If you locate the freezer next to a xed wall, allow sucient
space on the hinge side for the door to swing open.
• Locate the freezer away from direct sunlight and sources of
heat, such as a stove, heater, or radiator. Direct sunlight
may aect the acrylic coating and heat sources may
increase electrical consumption. Extremely cold tempera-
tures may also prevent the freezer from performing
properly.
• Avoid locating the freezer in moist areas.
Leveling your freezer
• If the feet are not adjusted during installation, the doors
may not close or seal properly, causing cooling, frost, or
moisture problems.
• To level your freezer, rotate the leveling feet clockwise (to
raise) the freezer or counter-clockwise (to lower). The front
of the freezer may be slightly higher than the back.
Installing the door handle
1Unplug the freezer.
2Screw the extended-head screws into the door holes using
the included wrench. Do not overtighten. The screw heads
should extend above the surface of the door.
3Place the door handle over the heads of the screws.
4Install the remaining two screws into the holes in the side
of the handle, then tighten them securely.
Installing the bottom decorative cover
1Remove the cover plate on the hinge side of the decorative
cover.
2Install the bottom decorative cover by using the three
screws provided.
Final at size: 406.4 × 266.7 mm Final folded size: 203.2 × 266.7 mm
USING YOUR FREEZER
1Plug in your freezer. Wait for 30 minutes, then open the
freezer door to determine if the freezer is working properly.
2Press and hold the Lock button for three seconds, then +or
-to set the temperature inside the freezer. A beep sounds
when the MAX or MIN temperatures are reached.
Using the Lock button
• To prevent accidental activation, the control panel
automatically locks after a period of inactivity. To use the
control panel, press and hold the Lock button for three
seconds.
Switching between Freezer and Refrigerator modes
This freezer has an advanced design feature that lets you
change it from a freezer to a refrigerator.
1Press and hold the Lock button for three seconds.
2Press and hold the Freezer/Fridge button for three
seconds. The panel beeps and the indicator changes to the
new mode.
Quick Freezing foods
• The quick freeze mode lowers the temperature below the
normal operating temperature to quickly freeze foods. Press
the Quick Freeze button to enter quick freeze mode. The
blue snowake turns on.
• The quick freeze mode turns o after three hours if the
temperature falls below -13° F (-25° C). If the temperature
does not fall below -13° F (-25° C), the quick freeze mode
turns o after 24 hours. You can press the button a second
time to exit quick freeze mode.
Switching between Fahrenheit and Celsius
1Press and hold the Lock button for three seconds.
2Press and hold +and -at the same time for three seconds.
A beep sounds and the display changes.
Cover plates (remove one)
NS-UZ14XWH7_NS-UZ14XWH7-C_19-0026_QSG_V7_EN.ai 1 1/28/2019 11:20:12 AMNS-UZ14XWH7_NS-UZ14XWH7-C_19-0026_QSG_V7_EN.ai 1 1/28/2019 11:20:12 AM

V7 ENGLISH 19-0026
FEATURES
Interior
Touch pad controls
TROUBLESHOOTING
For troubleshooting information see your online User Guide.
SPECIFICATIONS
For specications see your online User Guide.
SAFETY INFORMATION
1 Read these instructions.
2 Keep these instructions.
3 Heed all warnings.
4 Follow all instructions.
5 Do not use this appliance near water.
6 Clean only with damp cloth.
7 Do not block any ventilation openings. Install in accordance
with the manufacturer’s instructions.
8 Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus that produce heat.
9 Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades with
one wider than the other. A grounding type plug has two
blades and a third grounding prong. The wide blade or the
third prong are provided for your safety. If the provided
plug does not t into your outlet, consult an electrician for
replacement of the obsolete outlet.
10 Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the
point where they exit from the appliance.
11 Do not attempt to modify or extend the power cord of this
appliance.
12 Unplug this appliance during lightning storms or when it
will not be used for long periods of time.
13 Make sure that the available AC power matches the voltage
requirements of this appliance.
14 Do not handle the plug with wet hands. This could result in
an electric shock.
15 Unplug the power cord by holding the plug, never by
pulling the cord.
16 Do not turn the appliance on or o by plugging or
unplugging the power cord.
17 Refer all servicing to qualied service personnel. Servicing is
required when the appliance has been damaged in any
way, such as the power-supply cord or plug is damaged,
liquid has been spilled or objects have fallen into the
appliance, the appliance has been exposed to rain or
moisture, does not operate normally, or has been dropped.
18 To reduce the risk of re or electric shock, do not expose
this appliance to rain, moisture, dripping, or splashing, and
no objects lled with liquids should be placed on top of it.
19 Do not use extension cords or ungrounded (two prong)
adapters.
20 This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
21 Children should be supervised to ensure that they do not
play with the appliance.
22 If the SUPPLY CORD is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualied person
in order to avoid a hazard.
23 Take o the doors
Leave the shelves in place so that children may not easily
climb inside.
Grounding requirement
This freezer must be grounded. This freezer is equipped with a
cord having a grounding wire with a grounding plug. The plug
must be inserted into an outlet that is properly installed and
grounded. Improper use of the grounding plug can result in a
risk of electric shock.
Consult a qualied electrician or service person if the
grounding instructions are not completely understood, or if
doubt exists as to whether the freezer is properly grounded.
LEGAL NOTICES
lf at any time in the future you should need to dispose of this
product, note that waste electrical products should not be
disposed of with household waste. Recycle where facilities
exist. Check with your Local Authority or retailer for recycling
advice. (Waste Electrical and Electronic Equipment Directive)
Owing to continuous improvement, no prior notice will be
given regarding changes on features and specications.
ONEYEAR LIMITED WARRANTY
Visit www.insigniaproducts.com for details.
CONTACT INSIGNIA:
For customer service, call 1-877-467-4289 (U.S. and Canada) or
01-800-926-3000 (Mexico)
www.insigniaproducts.com
INSIGNIA is a trademark of Best Buy and its aliated companies
Distributed by Best Buy Purchasing, LLC
7601 Penn Ave South, Richeld, MN 55423 U.S.A.
©2019 Best Buy. All rights reserved.
Made in China
Light switch
Light cover
Temperature
sensor
Wire shelf
Air ow outlet
Air ow inlet
Wire drawer
Door tray
Wire door tray
High temperature
indicator/alert
Lower
temperature
button
Temperature
indicator
Door open
indicator/alarm
Raise
temperature
button
Quick freeze
button
Control Panel
Lock/Unlock button
Freezer/Fridge
mode button
Leveling feet (2 - bottom front)
Wheels (2 - bottom back)
