Insignia NS-OTR16SS8Q User manual

Before using your new product, please read these instructions to prevent any damage.
USER GUIDE
1.6 Cu. Ft.
Over-the-Range
Microwave
NS-OTR16SS8Q

www.insigniaproducts.com
2
Contents
SAFETY INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Precautions to avoid possible exposure to excessive microwave energy: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
IMPORTANT SAFETY INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Unpacking instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Grounding instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Cookware and cooking materials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Materials you can use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Materials to be avoided . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Package contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Microwave oven . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Setting up your microwave oven . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Installing the turntable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Using your microwave . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Cooking in your microwave . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Setting the clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Using the kitchen timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Cooking quickly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Defrosting in your microwave . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Cooking with the auto menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Cooking kids’ meals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Using energy saver (eco) mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Checking the time and power level while cooking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Using the oven rack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Using the light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Using the vent fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Using the child lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Cleaning and maintaining your microwave . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Cleaning the outside of your microwave . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Cleaning the inside of your microwave . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Cleaning and replacing the filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Changing the light bulbs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Obtaining replacement parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Legal notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
ONE-YEAR LIMITED WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

3
1.6 Cu. Ft. Over-the-Range Microwave
www.insigniaproducts.com
SAFETY INFORMATION
Precautions to avoid possible exposure to excessive microwave energy:
1Do not attempt to operate this microwave with the door open because this can result in harmful exposure to
microwave energy. It is important not to defeat or tamper with the safety interlocks.
2Do not place any object between the microwave front face and the door or allow soil or cleaner residue to
accumulate on sealing surfaces.
3Do not operate the microwave if it is damaged. It is particularly important that the microwave door closes
properly and that there is no damage to the:
(a) DOOR (bent)
(b) HINGES and LATCHES (broken or loosened)
(c) DOOR SEALS and SEALING SURFACES
4The microwave should not be adjusted or repaired by anyone except properly qualified service personnel.
IMPORTANT SAFETY INSTRUCTIONS
Warning
To reduce the risk of burns, electric shock, fire, injury to persons, or exposure to
excessive microwave oven energy when using your oven, follow these basic
safety precautions.
1Read all instructions before using the oven.
2Read and follow the specific: “Precautions to avoid possible exposure to excessive microwave energy:” on
page 3.
3This appliance must be grounded. Connect only to a properly grounded outlet. See “Grounding instructions” on
page 4.
4Install or locate this appliance only in accordance with the provided installation instructions.
5Some products such as whole eggs and sealed containers (closed glass jars, for example) are able to explode and
should not be heated in this oven.
6Use this appliance only for its intended use as described in this manual. Do not use corrosive chemicals or vapors
in this appliance. This type of oven is specifically designed to heat, cook, or dry food. It is not designed for
industrial or laboratory use.
7As with any appliance, close supervision is necessary when used by children.
8To reduce the risk of fire in the oven cavity:
a) Do not overcook food. Carefully monitor the appliance when paper, plastic, or other combustible materials
are placed inside the oven to facilitate cooking.
b) Remove wire twist-ties from paper or plastic bags before placing the bag in the oven.
c) If materials inside the oven should ignite, keep the oven door closed, turn the oven off, and disconnect the
power cord or shut off power at the fuse or circuit breaker panel.
d) Do not use the cavity for storage purposes. Do not leave paper products, cooking utensils, or food in the
cavity when not in use.
9Liquids, such as water, coffee, or tea can be overheated beyond the boiling point without appearing to be
boiling. Visible bubbling or boiling when the container is removed from the microwave oven is not always
present. THIS COULD RESULT IN VERY HOT LIQUIDS SUDDENLY BOILING OVER WHEN THE CONTAINER IS
DISTURBED OR A SPOON OR OTHER UTENSIL IS INSERTED INTO THE LIQUID.
a) Do not overheat the liquid.
b) Stir the liquid both before and halfway through heating it.
c) Do not use straight-sided containers with narrow necks.
d) After heating, allow the container to stand in the microwave oven for a short time before removing the
container.
e) Use extreme care when inserting a spoon or other utensil into the container.
10 Do not heat oil or fat for deep-frying. It is difficult to control the temperature of oil in the microwave oven.
11 Pierce foods with heavy skins such as potatoes, whole squash, apples, and chestnuts before cooking.
12 The contents of feeding bottles and baby jars should be stirred or shaken and the temperature should be
checked before serving in order to avoid burns.

4
NS-OTR16SS8Q
www.insigniaproducts.com
13 Cooking utensils may become hot because of heat transferred from the heated food. Potholders may be needed
to handle the utensil.
14 Do not cover or block any openings on the appliance.
15 Do not store or use this appliance outdoors. Do not use this product near water, for example, near a kitchen sink,
in a wet basement, near a swimming pool, or similar locations.
16 Do not operate this appliance if it has a damaged cord or a plug, if it is not working properly, or if it has been
damaged or dropped.
17 Do not immerse the cord or plug in water. Keep the cord away from heated surfaces. Do not let the cord hang
over the edge of a table or counter.
18 Use only thermometers which are specifically designed for use in microwave ovens.
19 Be certain the glass tray and roller rings are in place when you operate the oven
20 This appliance should be serviced only by qualified service personnel. Contact the nearest authorized service
facility for examination, repair, or adjustment.
21 When cleaning surfaces of the door and oven that come together on closing the door, use only mild,
nonabrasive soaps, or detergents applied with a sponge or soft cloth.
22 VENTILATING HOODS:
a) Clean Ventilating Hoods Frequently-Grease should not be allowed to accumulate on hood or filter.
b) When flaming foods under the hood, turn the fan on.
23 Use care when cleaning the vent-hood filter. Corrosive cleaning agents, such as lye-based oven cleaners, may
damage the filter.
24 To reduce the risk of fire and electric shock, install only above electric cooking equipment. If the
over-the-cooktop microwave oven is intended to be used with either a gas or electric range, the following words
or the equivalent shall be included: Suitable for use above both gas and electric cooking equipment.
Unpacking instructions
Carefully remove the microwave from the box. Save the box as it may make installation easier.
1Remove all packing materials from inside the oven cavity; however, DO NOT REMOVE THE WAVEGUIDE COVER,
which is located on the ceiling in the oven cavity. Make sure that you have all items from the “Package contents”
on page 7. Read and save the instructions.
2Remove the feature sticker from the outside of the door, if there is one.
3Check the oven for any damage, such as misaligned or bent door, damaged door seals and sealing surfaces,
broken or loose door hinges and latches, and dents inside the cavity or on the door. If there is any damage, do
not operate the oven and contact your dealer.
See the Installation Guide for more information.
Grounding instructions
This appliance must be grounded. In the event of an electrical short circuit, grounding reduces the risk of electric
shock by providing an escape wire for the electric current. This appliance is equipped with a cord having a
grounding wire with a grounding plug. The plug must be plugged into an outlet that is properly installed and
grounded.
Warning
Improper use of the grounding plug can result in a risk of electric shock. Consult a
qualified electrician or serviceman if the grounding instructions are not
completely understood or if doubt exists as to whether the appliance is properly
grounded.
Electrical requirements
The electrical requirements are a 120 volt 60 Hz, AC only, 20 amp outlet. It is recommended that a separate circuit
serving only the oven be provided. The oven is equipped with a 3-prong grounding plug. It must be plugged into a
wall receptacle that is properly installed and grounded.
Power Supply Cord
1A short power supply cord is provided to reduce the risks resulting from becoming entangled in or tripping over
a longer cord.
2Longer cord sets or extension cords are available and may be used if care is exercised in their use.

5
1.6 Cu. Ft. Over-the-Range Microwave
www.insigniaproducts.com
3If a long cord or extension cord is used:
a) The marked electrical rating of the cord set or extension cord should be at least as great as the electrical
rating of the appliance.
b) The extension cord must be a grounding-type 3-wire cord, and the longer cord should be arranged so that it
will not drape over the counter top or table top where it can be pulled on by children or tripped over
unintentionally.
c) If it is necessary to use an extension cord, use only a 3-wire extension cord that has a 3-blade grounding plug,
and a 3-slot receptacle that will accept the plug on the appliance. The marked rating of the extension cord
shall be equal to or greater than the electrical rating of the appliance.
Notes
• If you have any questions about the grounding or electrical instructions, consult a
qualified electrician or service person.
• Insignia does not accept any liability for damage to the oven or personal injury
resulting from failure to observe the electrical connection procedures.
Radio or TV interference
Should there be any interference caused by the microwave oven to your radio or TV, make sure that the microwave
oven is on a different circuit. Relocate the radio or TV as far away from the oven as feasible or check the position and
signal of the receiving antenna.
Cookware and cooking materials
Warning
Personal Injury Hazard
Tightly-closed containers could explode. Closed containers should be opened
and plastic pouches should be pierced before cooking.
Cookware and other materials must fit on the turntable. Always use oven mitts or pot holders because cookware
may become hot.
Refer to the Materials you can use and Materials to be avoided tables as a guide, then test before using.
Cookware and Materials Test:
1Fill a microwave-safe container with 1 cup (250 ml) of cold water, along with the cookware or materials in
question.
2Cook on maximum power for one minute. Do not exceed one minute cooking time.
3Carefully feel the cookware or material. If the empty cookware or material is warm, do not use it for microwave
cooking.

6
NS-OTR16SS8Q
www.insigniaproducts.com
Materials you can use
MATERIAL REMARKS
Aluminum foil
Use as shielding only. Small, smooth pieces can be used to cover thin parts of meat or
poultry to prevent overcooking. Arcing can occur if the foil is wrinkled or too close to
oven walls. The foil should be at least 1 inch (2.5 cm) away from oven walls.
Browning dish
Follow the manufacturer’s instructions. The bottom of the browning dish must be at
least 3/16-in. (5mm) above the turntable. Incorrect usage may cause the turntable to
break.
Dinnerware Use microwave-safe only. Follow the manufacturer's instructions. Do not use cracked or
chipped dishes.
Glass jars Always remove the lid. Use only to heat food until just warm. Most glass jars are not heat
resistant and may break.
Glassware Use heat-resistant oven glassware only. Make sure there is no metallic trim. Do not use
cracked or chipped dishes.
Oven cooking bags Follow the manufacturer’s instructions. Do not close with a metal tie. Make slits to allow
steam to escape.
Paper plates and
cups
Use for short–term cooking/warming only. Do not leave the oven unattended while
cooking.
Paper towels Use to cover food for reheating and absorbing fat. Use with supervision for short-term
cooking only.
Parchment paper Use as a cover to prevent splattering or a wrap for steaming.
Plastic
Use only if labeled “Microwave Safe.” Follow the manufacturer’s instructions. Some
plastic containers soften as the food inside gets hot. “Boiling bags” and tightly closed
plastic bags should be slit, pierced, or vented, as indicated on the package.
Plastic wrap Use microwave-safe only. Use to cover food during cooking to retain moisture. Do not
allow plastic wrap to touch food.
Thermometers Use microwave-safe only (such as meat and candy thermometers).
Wax paper Use as a cover to prevent splattering and retain moisture.
Materials to be avoided
MATERIAL REMARKS
Aluminum tray May cause arcing. Use a microwave-safe dish instead.
Food carton with
metal handle May cause arcing. Use a microwave-safe dish instead.
Metal or metal
trimmed utensils Metal shields the food from microwave energy. The metal trim may cause arcing.
Metal twist ties May cause arcing and could cause a fire in the oven.
Paper bags May cause a fire in the oven.
Plastic foam Plastic foam may melt or contaminate the liquid inside when exposed to high
temperature.
Wood Wood will dry out when used in the microwave oven and may split or crack.

7
1.6 Cu. Ft. Over-the-Range Microwave
www.insigniaproducts.com
Features
• 10 auto-cook settings
• 10 variable power levels
• 950 watts of power
• 30-second express cooking
• Energy saving (eco) mode
• Exhaust fan with two speeds
• Removable oven rack
• Hidden vent
•Tasklighting
•Childlock
• 12.4-inch glass turntable
Package contents
• 1.6 cu. ft. over-the-range microwave oven
• Turntable (with ring)
•Ovenrack
• Installation hardware
• Grease filter
•Exhaustdamper
• Installation Guide
•UserGuide
Microwave oven
#ITEM DESCRIPTION
1Safety interlock system Prevents the microwave from operating when the door is open.
2Turntable ring assembly Allows the turntable to rotate to cook food evenly.
3Waveguide cover Covers the waveguide. DO NOT REMOVE.
4Control panel Use to set cooking times and enter other information as needed.
5Turntable shaft Rotates the turntable assembly.
6Glass turntable Allows food to cook evenly.

8
NS-OTR16SS8Q
www.insigniaproducts.com
Control panel
#ITEM DESCRIPTION
1Display In standby mode, displays the time. In cooking mode, displays cooking time,
weight, and other information.
2Auto menu Press one of these buttons to automatically cook the item indicated. See
“Cooking with the auto menu” on page 11
31 lb. defrost Quickly defrost one pound (16 oz.) of food. See “Quickly defrosting one
pound” on page 10
4Number pad Press to enter cook time, defrost time, clock time, and other information.
5Clock Press to set or check the clock. See “Setting the clock” on page 10
6Power level
Press to set the power level of your microwave, then press the number
buttons to set the level you want (0-10). See “Cooking in your microwave”
on page 9.
7Energy saver
mode
Puts the microwave in the lowest power consumption mode which turns off
the display, cooking lights, and fans. See “Using energy saver (eco) mode”
on page 12
8Weight defrost Press this button, then enter the weight of the item you want to defrost. The
cooking time is set automatically. See “Defrosting by weight” on page 10.
9Time defrost Press this button, then enter the time you want for an item to defrost. See
“Defrosting by time” on page 10.
10 Stop Press to stop the cooking process. Press again to cancel the cooking
operation.
11 Start In standby mode, press this button to begin cooking.
While cooking, press this button to add 30 seconds to cooking time.
12 Timer Press this button, then enter the time you want to count down. See “Using
the kitchen timer” on page 10.
13 Kids meals Press to cook kids’ foods. See “Cooking kids’ meals” on page 11.
14 Time cook Press this button, then enter the time you want for an item to cook. See
“Cooking in your microwave” on page 9.
15 Light Press to turn on/off the light underneath your microwave. See “Using the
light” on page 12.
16 Vent Press to turn on/off your vent fan and remove odors from cooking. See
“Using the vent fan”on page 13.

9
1.6 Cu. Ft. Over-the-Range Microwave
www.insigniaproducts.com
Setting up your microwave oven
See the Installation Guide (included in your box) to install and set up your microwave.
You can also find the Installation Guide online at www.insigniaproducts.com by searching for NS-OTR16SS8Q. On
your microwave’s product page, select Support & Downloads, then next to Installation Guide, select the language
you want.
Installing the turntable
Hub (underside)
Glass turntable
Turntable ring
Turntable shaft
Notes
• Never place the glass tray upside down. The glass tray should never be restricted.
• Both the glass tray and turntable ring must always be used during cooking.
• Always place all food and containers of food on the glass tray for cooking.
• If the glass tray or turntable ring cracks or breaks, contact your nearest authorized
service center.
1Place the turntable ring in the round depression in the bottom of the microwave oven so that it turns freely.
2Place the glass turntable (flat side up) on the turntable ring so that the hub engages the turntable shaft in the
bottom of the oven. The glass turntable should not turn freely when it is correctly installed.
Using your microwave
Cooking in your microwave
1Press Time Cook, then use the number pad to enter the cooking time that you want.
Note
For example, to enter 3 minutes and 15 seconds, press 3, 1, and then 5.
2Press Power Level, then enter the power level that you want (0-10).
LEVEL 10 9876543210
Power 100% 90% 80% 70% 60% 50% 40% 30% 20% 10% 0%
Display PL10 PL-9 PL-8 PL-7 PL-6 PL-5 PL-4 PL-3 PL-2 PL-1 PL-0
Note
• You can check the power level during cooking by pressing Power Level. To
change it, enter a new power level (1-10).
• If “PL-0”is selected, the microwave fan turns on with 0% power. You can use this
level to remove an odor in the microwave.
3Press Start to begin heating.
OR
For two-stage cooking, repeat steps 1-2 to program the second stage.
Note
Two-stage cooking lets you program two cook times and power levels at the same
time.

10
NS-OTR16SS8Q
www.insigniaproducts.com
Setting the clock
1Press Clock. The display shows “Hr 12” for 12-hour mode. If you want to use 24-hour mode (“Hr 24”), press Clock
again.
2Use the number pad to enter the current time (1:00–12:59), then press Start to confirm the setting.
If the microwave beeps twice, then numbers input are not invalid.
Note
During cooking, press Clock to check the time.
Using the kitchen timer
1In standby mode, press Timer. The display shows “00:00” and “TIMER”.
2Use the number pad to enter the time (the maximum time is 99 minutes and 99 seconds), then press Start. When
the time reaches 0, the buzzer rings once.
Cooking quickly
1Press Start to instantly cook something at 100% power for 30 seconds.
2To increase the time in 30 second increments (except auto cook and defrost), press Start repeatedly. The
maximum cooking time is 99 minutes and 99 seconds.
Defrosting in your microwave
Defrosting by weight
1Press Weight Defrost. The display shows “0” and “DEF.”
2Use the number pad to enter the weight of the item to be defrosted (in ounces). Input the weight must be
between 1~96 ounces.
3Press Start to start defrosting. The remaining cooking time is displayed.
Note
While defrosting, the microwave pauses and beeps to remind you to open the
door and check the food. Turn your food over for uniform defrosting, then press
Start to defrost for the remaining time.
Defrosting by time
1Press Time Defrost. The display shows “00:00” and “DEF.”
2Use the number pad to enter the defrosting time you want. The time range must be between 00:01 and 99:99.
3Press Start to start defrosting. The remaining cooking time is displayed.
Note
While defrosting, the microwave pauses and beeps to remind you to open the
door and check the food. Turn your food over for uniform defrosting, then press
Start to defrost for the remaining time.
Quickly defrosting one pound
• Press 1 LB Defrost. Your microwave starts defrosting.
Note
While defrosting, the microwave pauses and beeps to remind you to open the
door and check the food. Turn your food over for uniform defrosting, then press
Start to defrost for the remaining time.

11
1.6 Cu. Ft. Over-the-Range Microwave
www.insigniaproducts.com
Cooking with the auto menu
Cheese, ice cream, or butter
1Press the food item (Cheese, Ice Cream, or Butter) that you want to heat.
2Press 1or 2on the number pad, depending on weight (oz.) of the item (see table below).
3Press Start.
FOOD AMOUNT NUMBER
PAD
TOTAL
TIME
Cheese 4 oz. 11:00
8 oz. 21:30
Ice Cream
1 serving
(4 oz.) 10:30
2 servings
(8 oz.) 20:45
Butter
1 serving
(4 oz.) 11:00
2 servings
(8 oz.) 21:30
Pizza, potato, meat, reheat, or veggies
1Press the food item (Pizza, Potato, Meat, Reheat, or Veggies) that you want to heat.
2Enter the food weight (in ounces) with the number pad. The weight must be within the range in the table below.
3Press Start.
FOOD WEIGHT
Pizza 10–28 oz.
Potato 1–48 oz.
Meat 1–32 oz.
Reheat 1–37 oz.
Veggies 1–48 oz.
Popcorn
When cooking a 3.5 oz. popcorn bag:
1Press Popcorn. The display shows “2:05” and “START.”
2Press Start.
Beverage
1Press Beverage.
2Use the number pad (1-6) to enter the amount from1-6 cups (6.8 oz./cup).
3Press Start.
Cooking kids’ meals
Hot dogs or frozen sandwiches
When cooking one serving of hot dogs or frozen sandwiches:
1Press Kids Meals. The display shows “1”and “START.”
2Use the number pad to enter the number for your food:
• Press 2for hot dogs.
• Press 4for frozen sandwiches.
3Press Start to confirm. The display shows “1.”
4Press Start again to cook.

12
NS-OTR16SS8Q
www.insigniaproducts.com
Chicken nuggets or french fries
1Press Kids Meals. The display shows "1" and "START".
2Use the number pad to enter the number for you food:
• Press 1for chicken nuggets.
• Press 3for french fries.
3Press Start to confirm the food type. The display shows "4" and "START"
4Press 1or 2on the number pad, depending on the weight(oz.) of the food:
• Press 1for 4 oz.
• Press 2for 8 oz.
5Press Start.
Using energy saver (eco) mode
Energy saver mode puts the microwave in the lowest power consumption mode which turns off the display, cooking
lights, and fans.
• To enter the energy saver mode, press Eco Mode. The display, cooking lights, and fans turn off.
• To use your microwave, press any button. The microwave enters standby mode for one minute and you can use
your microwave as usual.
• To exit energy saver mode, press any button to awaken the display, then press Eco Mode.
Checking the time and power level while cooking
• To check the time while cooking a meal, press Clock. The display shows the current time for five seconds, then
returns to the cooking time remaining.
• To check the power level while cooking a meal, press Power Level. The display shows the power level being used
for five seconds, then returns to the cooking time remaining.
Note
You can change the power level by pressing Power Level, then entering the new
power level (1-10).
Using the oven rack
The rack lets you reheat multiple dishes of food at the same time. When using the rack, switch the food (on the
turntable or rack) around after half of the cook time has expired.
Caution
• Do not use the rack without the turntable.
• Do not use the microwave with the rack on microwave floor. This could damage
the microwave.
• Do not use a microwave browning dish on the rack. The rack could overheat.
• Use pot holders when handling the microwave.
• Do not use the rack while cooking popcorn.
Using the light
• Press Light to turn on or off the light underneath your microwave.
Note
To change a light bulb, see “Changing the light bulbs” on page 15.

13
1.6 Cu. Ft. Over-the-Range Microwave
www.insigniaproducts.com
Using the vent fan
Your microwave’s vent fan works as a range hood to filter out smoke and other odors from cooking.
• Press Vent repeatedly to cycle between low speed, high speed, or off.
Note
You can use the vent fan while cooking in the microwave.
• When the fan automatically starts, you can press Vent to switch to high speed. The fan runs at high speed for
eight minutes, then returns to its low speed.
• If you turned the fan on, it doesn't turn off automatically when cooking is finished. Press Vent/2 Speed to turn it
off.
Using the child lock
• To lock the microwave, press and hold Stop for three seconds. The microwave beeps and a lock indicator appears
on the display.
• To unlock the microwave, press and hold Stop until the lock indicator disappears (about three seconds).
Cleaning and maintaining your microwave
Cleaning the outside of your microwave
Exterior
The outside surface is precoated steel and plastic. Clean the outside with mild soap and water, then rinse and dry
with a soft cloth. Do not use any type of household or abrasive cleaner.
Door
Wipe the window on both sides with a damp cloth to remove any spills or spatters. Metal parts will be easier to
maintain if wiped frequently with a damp cloth. Avoid the use of spray and other harsh cleaners as they may stain,
streak, or dull the door surface.
Control panel
If the control panel is dirty, open the microwave door before cleaning. Wipe the panel with a cloth dampened
slightly with water only. Dry with a soft cloth. Do not scrub or use any sort of chemical cleaners. Close the door and
press Stop to clear any buttons you may have pressed.
Cleaning the inside of your microwave
Interior
Wipe with a soft cloth and warm water. Do not use abrasive or harsh cleaners or scouring pads. For baked-on food,
use baking soda or a mild soap, then rinse thoroughly with hot water.
Waveguide cover
The waveguide cover is located on the ceiling inside the microwave cavity. It is made from mica so requires special
care. Keep the waveguide cover clean to assure good microwave performance. Carefully wipe with a damp cloth any
food spatters from the surface of the cover immediately after they occur. Built-up splashes may overheat and cause
smoke or possibly catch fire. DO NOT REMOVE THE WAVEGUIDE COVER.
Removing odors
Occasionally, a cooking odor may remain in the microwave. To remove, combine one cup water, grated peel and
juice of one lemon, and several whole cloves in a two-cup glass measuring cup. Boil for several minutes using 100%
power, then let it cool in the microwave. Wipe the interior with a soft cloth.
Turntable and turntable support
Remove the turntable and turntable support and wash them in mild, sudsy water. For stubborn stains, use a mild
cleanser and non-abrasive scouring sponge. You can also wash them in the top rack of a dishwasher.
The turntable motor shaft is not sealed, so excess water or spills should be wiped up immediately.

14
NS-OTR16SS8Q
www.insigniaproducts.com
Cleaning and replacing the filters
Cleaning the grease filters
Clean the filters at least once a month. Never use the fan or microwave without the filters in place.
1Pull down slightly on the tab toward the front of the microwave to remove the filter. Repeat for the other filter.
2Soak the filter in a sink or dish pan filled with hot water and detergent.
CAUTION
DO NOT use ammonia or other alkali. They will react with the filter material and
darken it.
3Agitate and scrub the filter with a brush to remove embedded dirt.
4Rinse thoroughly and shake dry.
5Replace by fitting the filter back into the opening.
Grease filters
BOTTOM
Replacing the charcoal filter
A charcoal filter is used for nonvented, recirculated installation. The filter should be changed every 6 to 12 months
depending on use.
1Disconnect power to the microwave at the circuit breaker or by unplugging it.
2Remove the louver mounting screws from the top center of the louver, then push down on the tabs at each end
of the louver to disengage it.
3Pull the louver away from the unit.
4Replace the charcoal filter. Make sure that the wire mesh is visible from the front.
5Carefully push the louver back into place and replace the louver mounting screws.
Louver mounting screws
Charcoal filter
Louver

15
1.6 Cu. Ft. Over-the-Range Microwave
www.insigniaproducts.com
Changing the light bulbs
Countertop light (exterior)
1Disconnect power to the microwave at the circuit breaker or by unplugging it.
2Remove the screw holding the light cover in place, then remove the light cover.
CAUTION
The light cover may become very hot. Do not touch the glass when the light is on.
3Remove the old light bulb, then replace with a new bulb.
CAUTION
Do not use a bulb larger than 30 watts.
4Replace the light cover and secure it with the screw.
Light cover Light bulbs
Screw
BOTTOM

16
NS-OTR16SS8Q
www.insigniaproducts.com
Microwave light (interior)
1Disconnect power to the microwave at the circuit breaker or by unplugging it.
2Remove the louver mounting screws from the top center of the louver, then push down on the tabs at each end
of the louver to disengage it.
3Pull the louver away from the unit.
Louver mounting screws
Louver
4Open the light cover located behind the filter by removing the light cover screw, then carefully pulling up on the
front edge.
Light cover screw
Light cover
FRONT
5Remove the old light bulb, then replace with a new bulb.
CAUTION
Do not use a bulb larger than 30 watts.
6Replace the microwave light cover by carefully pushing it into place.
7Push the louver back into place and replace the louver mounting screws.

17
1.6 Cu. Ft. Over-the-Range Microwave
www.insigniaproducts.com
Troubleshooting
If you have a problem with your microwave, review the following chart for a possible solution. If the microwave still
does not work properly, contact the nearest authorized service center.
PROBLEM POSSIBLE CAUSE POSSIBLE SOLUTION
Microwave will
not start
The electrical cord is not plugged in. Plug in the electrical cord.
The door is open. Close the door and try again.
The wrong operation is set. Check the instructions and try again.
Arching or
sparking in the
microwave
You are attempting to use incorrect
materials in the microwave. Use only microwave-safe materials.
You are attempting to use the microwave
when it’s empty.
Do not operate the microwave when it’s
empty.
Spilled food remains in the microwave. Clean the microwave with a wet towel.
Unevenly
cooked foods
You are attempting to use incorrect
materials in the microwave. Use only microwave-safe materials.
The food is not defrosted completely. Defrost the food completely before
attempting to cook it.
The cooking time or power level is not
adequate to cook the food.
Use the correct cooking time and power
level.
The food is not turned or stirred. Turn or stir the food.
Overcooked
foods
The cooking time or power level is not
adequate to cook the food.
Use the correct cooking time and power
level.
Undercooked
foods
You are attempting to use incorrect
materials in the microwave. Use only microwave-safe materials.
The food is not defrosted completely. Defrost the food completely before
attempting to cook it.
The cooking time or power level is not
adequate to cook the food.
Use the correct cooking time and power
level.
The microwave ventilation ports are
blocked or restricted.
Make sure that the ventilation ports are
not blocked or restricted.
Improper
defrosting
You are attempting to use incorrect
materials in the microwave. Use only microwave-safe materials.
The cooking time or power level is not
adequate to cook the food.
Use the correct cooking time and power
level.
The food is not turned or stirred. Turn or stir the food.
The vent fan
turns on by
itself
This protects the microwave from
excessive temperatures.
Your microwave is operating normally. The
fan cannot be turned off manually during
this time.

18
NS-OTR16SS8Q
www.insigniaproducts.com
Obtaining replacement parts
Call Insignia Customer Service at 1-877-467-4289.
Specifications
Model NS-OTR16SS8Q
Rated voltage 120V / 60 Hz
Rated input power 1500W
Rated output power 950W
Microwave capacity 1.6 cu. ft.
Turntable diameter 12.4 in. (31.5 cm)
External dimensions (HxWxD) 16.9 x 29.9 x 17.9 in. (42.9 x 75.9 x 45.5 cm)
Internal dimensions (HxWxD) 10.2 x 21.1 x 14.6 in. (25.9 x 54.1 x 37.1 cm)
Charcoal filter dimensions (L × W) 5.65 × 3.7 in. (14.4 × 9.4 cm)
Certifications UL and CUL approved
Power cord length 39.8 in. (101 cm)
Net weight 55.1 lbs. (25 kg)

19
1.6 Cu. Ft. Over-the-Range Microwave
www.insigniaproducts.com
Legal notices
FCC statement
This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for
help.
Copyright
INSIGNIA is a trademark of Best Buy and its affiliated companies.
Registered in some countries. Distributed by Best Buy Purchasing,
LLC
7601 Penn Ave South, Richfield, MN 55423 U.S.A.
©2019 Best Buy. All rights reserved.
Made in China
ONE-YEAR LIMITED WARRANTY
Definitions:
The Distributor* of Insignia branded products warrants to you,
the original purchaser of this new Insignia-branded product
(“Product”), that the Product shall be free of defects in the
original manufacturer of the material or workmanship for a
period of one (1) year from the date of your purchase of the
Product (“Warranty Period”).
For this warranty to apply, your Product must be purchased in the
United States or Canada from a Best Buy branded retail store or
online at www.bestbuy.com or www.bestbuy.ca and is packaged
with this warranty statement.
How long does the coverage last?
The Warranty Period lasts for 1 year (365 days) from the date you
purchased the Product. Your purchase date is printed on the
receipt you received with the Product.
What does this warranty cover?
During the Warranty Period, if the original manufacture of the
material or workmanship of the Product is determined to be
defective by an authorized Insignia repair center or store
personnel, Insignia will (at its sole option): (1) repair the Product
with new or rebuilt parts; or (2) replace the Product at no charge
with new or rebuilt comparable products or parts. Products and
parts replaced under this warranty become the property of
Insignia and are not returned to you. If service of Products or
parts are required after the Warranty Period expires, you must
pay all labor and parts charges. This warranty lasts as long as you
own your Insignia Product during the Warranty Period. Warranty
coverage terminates if you sell or otherwise transfer the Product.
How to obtain warranty service?
If you purchased the Product at a Best Buy retail store location or
from a Best Buy online website (www.bestbuy.com or
www.bestbuy.ca), please take your original receipt and the
Product to any Best Buy store. Make sure that you place the
Product in its original packaging or packaging that provides the
same amount of protection as the original packaging.
To obtain warranty service, in the United States and Canada call
1-877-467-4289. Call agents may diagnose and correct the issue
over the phone.
Where is the warranty valid?
This warranty is valid only in the United States and Canada at Best
Buy branded retail stores or websites to the original purchaser of
the product in the country where the original purchase was
made.
What does the warranty not cover?
This warranty does not cover:
• Customer instruction/education
•Installation
•Setupadjustments
• Cosmetic damage
• Damage due to weather, lightning, and other acts of God,
such as power surges
• Accidental damage
•Misuse
•Abuse
•Negligence
• Commercial purposes/use, including but not limited to use in
a place of business or in communal areas of a multiple
dwelling condominium or apartment complex, or otherwise
used in a place of other than a private home.
• Modification of any part of the Product, including the antenna
• Display panel damaged by static (non-moving) images
applied for lengthy periods (burn-in).
• Damage due to incorrect operation or maintenance
• Connection to an incorrect voltage or power supply
• Attempted repair by any person not authorized by Insignia to
service the Product
• Products sold “as is”or “with all faults”
• Consumables, including but not limited to batteries (i.e. AA,
AAA, C etc.)
• Products where the factory applied serial number has been
altered or removed
• Loss or Theft of this product or any part of the product
• Display panels containing up to three (3) pixel failures (dots
that are dark or incorrectly illuminated) grouped in an area
smaller than one tenth (1/10) of the display size or up to five
(5) pixel failures throughout the display. (Pixel based displays
may contain a limited number of pixels that may not function
normally.)
• Failures or Damage caused by any contact including but not
limited to liquids, gels or pastes.
REPAIR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS
YOUR EXCLUSIVE REMEDY FOR BREACH OF WARRANTY. INSIGNIA
SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL
DAMAGES FOR THE BREACH OF ANY EXPRESS OR IMPLIED
WARRANTY ON THIS PRODUCT, INCLUDING, BUT NOT LIMITED
TO, LOST DATA, LOSS OF USE OF YOUR PRODUCT, LOST BUSINESS
OR LOST PROFITS. INSIGNIA PRODUCTS MAKES NO OTHER
EXPRESS WARRANTIES WITH RESPECT TO THE PRODUCT, ALL
EXPRESS AND IMPLIED WARRANTIES FOR THE PRODUCT,
INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTIES OF
AND CONDITIONS OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, ARE LIMITED IN DURATION TO THE
WARRANTY PERIOD SET FORTH ABOVE AND NO WARRANTIES,
WHETHER EXPRESS OR IMPLIED, WILL APPLY AFTER THE
WARRANTY PERIOD. SOME STATES, PROVINCES AND
JURISDICTIONS DO NOT ALLOW LIMITATIONS ON HOW LONG AN
IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT
APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL
RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS, WHICH VARY
FROM STATE TO STATE OR PROVINCE TO PROVINCE.
Contact Insignia:
1-877-467-4289
www.insigniaproducts.com
INSIGNIA is a trademark of Best Buy and its affiliated companies.
*Distributed by Best Buy Purchasing, LLC
7601 Penn Ave South, Richfield, MN 55423 U.S.A.
©2019 Best Buy. All rights reserved.
Made in China

www.insigniaproducts.com
1-877-467-4289 (U.S. and Canada) or 01-800-926-3000 (Mexico)
INSIGNIA is a trademark of Best Buy and its affiliated companies.
Distributed by Best Buy Purchasing, LLC
7601 Penn Ave South, Richfield, MN 55423 U.S.A.
©2019 Best Buy. All rights reserved.
Made in China.
V5 ENGLISH
19-0336
