Insignia NS-CF30SS9 User manual

Before using your new product, please read these instructions to prevent any damage.
USER GUIDE
2-Door Compact
Refrigerator
NS-CF30SS9
NS-CF30SS9_18-0222_MAN_V2_EN.fm Page 1 Monday, April 16, 2018 12:36 PM
Final Trim Size: 5.512 x 8.268 in. (140 x 210 mm)

www.insigniaproducts.com
2
Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Grounding requirement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Package contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Main components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Preparing to install your refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Before using your refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Finding a suitable location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Leveling your refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Providing proper ventilation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Providing a proper power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Setting the thermostat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Using the freezer compartment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Making ice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Defrosting your refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Reversing the door position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Before you begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Removing the door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Reinstalling the doors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Maintaining your refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Cleaning the interior of your refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Changing the interior light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Turning off your refrigerator for extended periods . . . . . . . . . . . . . . . . . . . . . .14
Moving Your Refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Tips on saving energy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
ONE-YEAR LIMITED WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
NS-CF30SS9_18-0222_MAN_V2_EN.fm Page 2 Monday, April 16, 2018 12:36 PM

3
2-Door Compact Refrigerator
www.insigniaproducts.com
Introduction
Congratulations on your purchase of a high-quality Insignia product. Your
NS-CF30SS9 represents the state of the art in compact refrigerator design and is
designed for reliable and trouble-free performance.
Important Safety Instructions
WARNING
1Read these instructions.
2Keep these instructions.
3Heed all warnings.
4Follow all instructions.
5Do not use this appliance near water.
6Clean only with a damp cloth.
7Do not block any ventilation openings. Install in accordance with the
manufacturer's instructions.
8Do not install near any heat sources, such as radiators, heat registers, stoves, or
other apparatuses (including amplifiers) that produce heat.
9Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other. A
grounding-type plug has two blades and a third grounding prong. The wide
blade or the third prong is provided for your safety. If the provided plug does
not fit into your outlet, consult an electrician for replacement of the obsolete
outlet.
10 Protect the power cord from being walked on or pinched, particularly at plugs,
convenience receptacles, and the point where they exit from the appliance.
11 Do not attempt to modify or extend the power cord of this appliance.
12 Unplug this appliance during lightning storms or when it will not be used for
long periods of time.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
This symbol indicates that
dangerous voltage constituting a
risk of electric shock is present
within your compact refrigerator.
This symbol indicates that there
are important operating and
maintenance instructions in the
literature accompanying your
compact refrigerator.
NS-CF30SS9_18-0222_MAN_V2_EN.fm Page 3 Monday, April 16, 2018 12:36 PM

4
NS-CF30SS9
www.insigniaproducts.com
13 Make sure that the available AC power matches the voltage requirements of
this appliance.
14 Do not handle the plug with wet hands. This could result in an electric shock.
15 Unplug the power cord by holding the plug, never by pulling the cord.
16 Do not turn the appliance on or off by plugging or unplugging the power
cord.
17 Turn off the appliance before unplugging it.
18 Refer all servicing to qualified service personnel. Servicing is required when
the appliance has been damaged in any way, such as when the power-supply
cord or plug is damaged, when liquid has been spilled or objects have fallen
into the appliance, or when the appliance has been exposed to rain or
moisture, does not operate normally, or has been dropped.
19 To reduce the risk of fire or electric shock, do not expose this appliance to rain,
moisture, dripping, or splashing, and do not place objects filled with liquid on
top of it.
20 If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent, or a similarly qualified person in order to avoid a hazard.
WARNING
Electric Shock Hazard
Failure to follow these instructions can result in
electric shock, fire, or death.
1WARNING–Keep ventilation openings, in the appliance
enclosure or in the built-in structure, clear of obstruction.
2WARNING–Do not touch the interior of the freezer
compartment with wet hands. This could result in frost bite.
3WARNING–Do not use mechanical devices or other means to accelerate the
defrosting process, other than those recommended by the manufacturer.
4WARNING–Do not damage the refrigerant circuit when handling, moving, or
using the refrigerator.
5WARNING–Do not use electrical appliances inside the food storage
compartment of the refrigerator unless they are of the type recommended by
the manufacturer.
6WARNING–DANGER—Never allow children to play with, operate, or crawl
inside the refrigerator.
7Risk of child entrapment. Before you throw away your old refrigerator or
freezer:
1) Take off the doors
2) Leave the shelves in place so that children may not easily climb inside
8Unplug the refrigerator before carrying out user maintenance on it.
NS-CF30SS9_18-0222_MAN_V2_EN.fm Page 4 Monday, April 16, 2018 12:36 PM

5
2-Door Compact Refrigerator
www.insigniaproducts.com
9This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the
appliance. Cleaning and maintenance should not be performed by children
without supervision.
10 If a component part is damaged, it must be replaced by the manufacturer, its
service agent, or similar qualified persons in order to avoid a hazard.
11 Follow local regulations regarding disposal of the appliance due to flammable
refrigerant and gas. All refrigeration products contain refrigerants, which
under the guidelines of federal law must be removed before disposal. It is the
consumer's responsibility to comply with federal and local regulations when
disposing of this product.
12 This appliance is intended to be used in household and similar environments.
13 Do not store or use gasoline or any flammable liquids inside or in the vicinity
of this refrigerator.
14 Do not use extension cords or ungrounded (two prong) adapters with this
appliance. If the power cord is too short, have a qualified electrician install an
outlet near the appliance. Use of an extension cord can negatively affect the
refrigerator’s performance.
15 Do not store explosive substances, such as aerosol cans with a flammable
propellant, in this appliance
16 This appliance is intended to be used in household and similar applications
such as:
• Staff kitchen areas in shops, offices, and other working environments;
• Farm houses and by clients in hotels, motels, and other residential type
environments;
• Bed and breakfast type environments;
• Catering and similar non-retail applications.
17 Lamp replacement by professionals.
Grounding requirement
This appliance must be grounded. This appliance is equipped with a cord having a
grounding wire with a grounding plug. The plug must be inserted into an outlet
that is properly installed and grounded.
Improper use of the grounding plug can result in a risk of electric shock. Consult a
qualified electrician or service person if the grounding instructions are not
completely understood, or if doubt exists as to whether the appliance is properly
grounded.
NS-CF30SS9_18-0222_MAN_V2_EN.fm Page 5 Monday, April 16, 2018 12:36 PM

6
NS-CF30SS9
www.insigniaproducts.com
Features
Package contents
• 2-door compact refrigerator
• Adjustable shelves
•Icecubetray
• Defrost shovel
•User Guide
Main components
Note: To remove a refrigerator shelf, lift it up, then slide it out.
Ice tray
Interior
light switch
Refrigerator
section
shelves
Crisper
Leveling
feet
Freezer
door
Refrigerator
door
Thermostat
Ice shovel
Door hinge
cover
Can
storage
NS-CF30SS9_18-0222_MAN_V2_EN.fm Page 6 Monday, April 16, 2018 12:36 PM

7
2-Door Compact Refrigerator
www.insigniaproducts.com
Dimensions
Preparing to install your refrigerator
Before using your refrigerator
• Remove the exterior and interior packaging.
• Let the refrigerator stand upright for approximately four hours before
connecting it to power. This reduces the possibility of a malfunction in the
cooling system from improper handling during transportation.
• Clean the interior surface with a damp, warm cloth.
Finding a suitable location
• This refrigerator is designed to be free standing only, and should not be
recessed or built-in.
• Place your refrigerator on a floor that is strong enough to support the
refrigerator when it is fully loaded.
• Allow 5 in. (12.7 cm) of space between the back and sides of the refrigerator
and any surrounding walls. This allows for proper air ventilation. Adjust the
feet to keep the refrigerator level.
19.1 in. (48.5 cm)
37.4 in. (94.9 cm)
33.4 in. (84.8 cm)
20.5 in. (52 cm)
NS-CF30SS9_18-0222_MAN_V2_EN.fm Page 7 Monday, April 16, 2018 12:36 PM

8
NS-CF30SS9
www.insigniaproducts.com
• Locate the refrigerator away from direct sunlight and sources of heat (stove,
heater, radiator, and so on). Direct sunlight may affect the acrylic coating
and heat sources may increase electrical consumption. Ambient
temperature below 50°F (10°C) or above 85°F (29.4°C) will hinder the
performance of this refrigerator. This refrigerator can be placed in a garage
as long as the ambient temperature in the garage is between 50°F (10°C)
and 85°F (29.4°C). It is not designed for use outside.
• Avoid locating the refrigerator in moist areas.
• This refrigerator can be placed on carpet, but care should be taken not to
damage the carpet when moving the refrigerator.
Leveling your refrigerator
• It is very important for the refrigerator to be level in order to function
properly. If the refrigerator is not leveled during installation, the doors may
not close or seal properly, causing cooling, frost, or moisture problems.
• To level your refrigerator, you may either turn the leveling foot clockwise to
raise that side of the refrigerator or turn it counter-clockwise to lower that
side.
Providing proper ventilation
Place the refrigerator at lease 5 in. (12.7 cm) from the wall to ensure proper airflow
to the compressor. Do not place the refrigerator near any heat sources, such as a
heater or stove, as this may put strain on the compressor.
Providing a proper power supply
Check your local power source. This refrigerator requires a 110V-120V, 60Hz power
supply.
Use a receptacle that accepts the grounding prong. The power cord is equipped
with a 3-prong (grounding) plug which goes into a standard 3-prong (grounding)
wall outlet to minimize the possibility of electric shock.
Note: Having someone push against the top of the refrigerator helps to take
some weight off the leveling foot, making it easier to adjust.
Notes:
• The refrigerator should always be plugged into its own individual electrical
outlet which has a voltage rating that matches the rating plate.
• Never unplug your refrigerator by pulling on the power cord. Always grip the
plug firmly and pull straight out from the outlet.
3-prong receptacle
Receptacle box cover
3-prong plug
Grounding lead
Grounding adapter Receptacle box cover
Screw
Receptacle
Using a 3-prong plug and outlet Using a grounding adapter
NS-CF30SS9_18-0222_MAN_V2_EN.fm Page 8 Monday, April 16, 2018 12:36 PM

9
2-Door Compact Refrigerator
www.insigniaproducts.com
Setting the thermostat
1The first time you turn the refrigerator on, adjust the thermostat to “7”and run
for at least two hours before putting food in.
2After it is fully cooled, test it and adjust towards “4”to make it less cool, to best
suit your needs. The “4”setting should be appropriate for home or office
refrigerator use.
Using the freezer compartment
The freezer compartment is designed for the long-term storage of frozen foods.
The storage life of frozen foods varies and the recommended storage time should
not be exceeded.
Place frozen food into the freezer as quickly as possible after purchasing. If there
are instructions on the packet, carefully follow these instructions regarding
storage times.
Making ice
1Set the thermostat to “7”.
2Fill the ice cube tray (2/3 capacity) with cold water and place the tray on the
bottom of the freezer compartment to freeze properly.
3When the water in the ice cube tray has hardened, remove the ice tray from
the freezer, then twist slightly to eject the ice cubes from the tray.
4Re-set the thermostat to “4”when you are done making ice.
Notes:
• Turning the thermostat to the “0” position stops the cooling cycle but does
not shut off the power to the refrigerator.
• If the refrigerator is unplugged or loses power, you must wait three to five
minutes before restarting it. If you attempt to restart before this time delay,
the refrigerator will not start.
• Large amounts of food will lower the cooling efficiency of the refrigerator.
• If you choose to change the thermostat setting, adjust it by one increment at
a time. Allow several hours for the temperature to stabilize between
adjustments.
NS-CF30SS9_18-0222_MAN_V2_EN.fm Page 9 Monday, April 16, 2018 12:36 PM

10
NS-CF30SS9
www.insigniaproducts.com
Defrosting your refrigerator
This refrigerator is not designed to defrost automatically. In order to prevent
damage to the interior liner of the refrigerator from excessive frost build-up,
defrost the refrigerator every three months or when ice or frost is approximately
¼” (6 mm) thick inside the freezer compartment.
1Set the thermostat to “0”, then remove all contents from the freezer
compartment.
2Leave the freezer door open to allow accumulated ice and frost to melt.
Remove large pieces of ice as needed.
3After defrosting, remove accumulated ice and water, then wipe the freezer
compartment dry with a soft cloth.
4Even though ice is not visibly present in the freezer compartment, allow the
evaporator, located behind the freezer wall, to completely defrost for
approximately two hours (total) before restarting the refrigerator.
5Restart following the instructions in “Setting the thermostat” on page 9.
Reversing the door position
Your refrigerator is built with a reversible door. Based on the location where you
plan to use your compact refrigerator, you may find it more convenient to reverse
the position of the door, to have it open from right to left instead of left to right.
Before you begin
You will need: A 10 mm socket driver and a Phillips screw driver.
• Make sure that your refrigerator is unplugged and empty.
• Have someone available to assist you in the process.
• Keep all of the parts you remove to reuse them later.
• Removing the door requires that the refrigerator be tilted backwards. Rest the
refrigerator on something solid, such as a chair, just below the top panel.
• Do not lay the refrigerator completely flat so that you do not damage the
coolant system.
Removing the door
1Remove the screw holding the top hinge cover to the top of your refrigerator,
then remove the top hinge cover.
2Remove the screws holding the top hinge to your refrigerator, then remove
the hinge. Pull the freezer door upwards and remove it from the refrigerator.
CAUTION:
• Do not use hot water or electric heating devices to melt the accumulated ice.
• The refrigerator door must remain closed while defrosting the freezer.
CAUTION: To avoid injury to yourself or your property, we recommend that
someone assist you during the door reversal process.
NS-CF30SS9_18-0222_MAN_V2_EN.fm Page 10 Monday, April 16, 2018 12:36 PM

11
2-Door Compact Refrigerator
www.insigniaproducts.com
3Remove the screw hole covers from the top left side of your refrigerator. Keep
the screw hole covers in a handy place. You need them later.
4Remove the screw holding the pivot pin on the bottom right side of the
freezer door, then remove the pivot pin.
5Remove the two screws holding the middle hinge to the refrigerator body,
then remove the hinge.
6Pull the refrigerator door upwards and remove it from the refrigerator.
7Tilt the refrigerator back.
8Unscrew the right and left leveling feet, then remove them.
Screw
Top hinge cover
Screws (2)
Top hinge
Screw
Pivot pin
Freezer door
Screw hole covers
Middle hinge and
screws (2)
NS-CF30SS9_18-0222_MAN_V2_EN.fm Page 11 Monday, April 16, 2018 12:36 PM

12
NS-CF30SS9
www.insigniaproducts.com
9Remove the two screws holding the bottom hinge on the refrigerator and
remove the hinge.
10 Remove the baffle block from the bottom-right side of the door.
Reinstalling the doors
1Install the baffle block on the bottom-left side of the door.
2Install the leveling foot you removed from the left side into the right-bottom
of your refrigerator and install the leveling foot you removed from the right
side into the left bottom.
3Align the hole in the bottom left of the refrigerator door with the bottom
hinge pin and install the door on the hinge pin.
4Install the bottom hinge on the left bottom of your refrigerator using the
screws you previously removed. Tighten the screws.
Bottom hinge
Screws (2)
Right leveling foot
Left leveling foot
Baffle
Bottom hinge
Screws (2)
Refrigerator door
Baffle block
Left leveling foot
Right leveling foot
NS-CF30SS9_18-0222_MAN_V2_EN.fm Page 12 Monday, April 16, 2018 12:36 PM

13
2-Door Compact Refrigerator
www.insigniaproducts.com
5Place the middle hinge pin into the left top of the refrigerator door, then
install the middle hinge on the left of the refrigerator with the screws your
previously removed. Do not fully tighten the screws.
6Check the fit and alignment (vertical and horizontal) of the door and make
sure that it opens and closes freely, then tighten the screws holding the
middle hinge.
7Install the pivot pin on the bottom-left of the freezer door using the screw you
previously removed.
8Align the hole on the bottom-left of the freezer door with the top pin on the
middle hinge, then install the freezer door on the hinge pin.
9Place the top hinge pin into the top of the freezer door, then install the top
hinge on the top left side of the refrigerator with the screws you previously
removed.
10 Check the fit and alignment (vertical and horizontal) of the door and make
sure that it moves freely open and closed, then tighten the screws holding the
top hinge.
11 Install the screw hole covers you removed previously from the holes on the
top left side of your refrigerator into the holes on the top right of your
refrigerator.
12 Adjust the leveling feet to level the refrigerator.
Middle hinge
Screws (2)
Screw
Top hinge
Freezer door
Pivot pin
Screw
Screws (2)
Top hinge cover
Screw hole covers
NS-CF30SS9_18-0222_MAN_V2_EN.fm Page 13 Monday, April 16, 2018 12:36 PM

14
NS-CF30SS9
www.insigniaproducts.com
Maintaining your refrigerator
Your refrigerator is designed for year-round use with only minimal cleaning and
maintenance.
When you first receive it, wipe the case with a mild detergent and warm water,
then wipe dry with a dry cloth. Do this periodically to keep your refrigerator
looking new.
Cleaning the interior of your refrigerator
1Turn off the refrigerator and unplug it from the wall outlet.
2Remove all food.
3Wash the inside with a damp, warm cloth.
4Dry the interior and exterior with a soft cloth.
Changing the interior light
1Hold the lamp cover and push toward the inside of the cabinet to remove it
from the refrigerator compartment.
2Unscrew the old bulb, then install the new bulb (10W/12E).
3Re-install the lamp cover.
Turning off your refrigerator for extended periods
1Turn off the refrigerator and unplug it from the wall outlet.
2Remove all food.
3Clean the refrigerator.
4Leave the door open slightly to avoid possible formation of condensation,
mold, or odor.
CAUTION: To prevent damage to the finish, do not use:
• Gasoline, benzine, thinner, or other similar solvents.
• Abrasive cleaners.
Note: It is recommended that you soak your cloth in a baking soda solution
before washing the interior. Mix one quart of warm water and two tablespoons
of baking soda.
CAUTION:
• All parts removed must be saved to reinstall the light bulb.
• Before removing the light bulb, unplug the refrigerator from the power
supply. Failure to do so could result in electrical shock or personal injury.
CAUTION: Use extreme caution with children. The refrigerator should not be
accessible to child's play.
NS-CF30SS9_18-0222_MAN_V2_EN.fm Page 14 Monday, April 16, 2018 12:36 PM

15
2-Door Compact Refrigerator
www.insigniaproducts.com
Moving your refrigerator
1Turn off the refrigerator and unplug it from the wall outlet.
2Remove all food.
3Securely tape down all loose items inside of your refrigerator.
4Tape the doors shut.
Tips on saving energy
• Place your refrigerator in the coolest area of the room, away from
heat-producing appliances or heating ducts, and out of direct sunlight.
• Let hot foods cool before placing them in the refrigerator. Overloading the
refrigerator forces the compressor to run longer. Foods that freeze too slowly
may lose quality or spoil.
• Wrap foods properly and wipe containers dry before placing them in the
refrigerator. This cuts down on frost build-up inside the refrigerator.
• Organize and label food to reduce door openings and extended searches.
Troubleshooting
Note: Make sure that your refrigerator stays in an upright position during
transportation.
CAUTION: Do not try to repair your refrigerator yourself. Doing so invalidates the
warranty.
PROBLEM SOLUTION
My refrigerator does not work. • Make sure that your refrigerator is securely
plugged into a working outlet.
• Make sure that your power source has the
correct voltage. Your refrigerator’s voltage rating
is on a label on the back of your refrigerator.
• Check the house fuse or circuit breaker box and
replace the fuse or reset the circuit breaker.
The refrigerator compartment
has a bad odor.
• Make sure that all food with a strong odor (like
onions) is wrapped or stored in airtight
packaging.
• Certain containers and wrapping materials (such
as paper, foil, or plastic) can cause odors. If you
think this might be the case, try using different
containers or a different brand of wrapping
material.
• Check for spoiled food and remove it.
• Clean the inside of your refrigerator. See
Maintaining your refrigerator on page 14.
NS-CF30SS9_18-0222_MAN_V2_EN.fm Page 15 Monday, April 16, 2018 12:36 PM

16
NS-CF30SS9
www.insigniaproducts.com
The refrigerator doors do not
close completely.
• Make sure that no food packages are in the way.
• Make sure that the door gaskets (seals) are clean.
See Maintaining your refrigerator on page 14.
• If the door gasket does not seal, try heating then
cooling the seal. You can use an electric hair
dryer to heat the seal.
• Make sure that your refrigerator is level. See
Leveling your refrigerator on page 8.
• Make sure that the top of your refrigerator is
tilted backward about 0.4" (10 mm) to 0.6"
(15 mm). See Leveling your refrigerator on
page 8.
The temperature is too hot. • You may have left the doors open too long or
opened them too frequently.
• Make sure that no obstacle is keeping the doors
from closing correctly.
• Adjust the refrigerator or freezer compartment
temperature. See Setting the thermostat on
page 9.
• Your refrigerator may not have enough
clearance from walls or the ceiling. See Providing
proper ventilation on page 8.
The temperature is too cold. • Adjust the refrigerator or freezer compartment
temperature. See Setting the thermostat on
page 9.
A layer of frost occurs in one
of the compartments.
• A layer of frost may occur on the compartment’s
interior walls if the freezer is opened frequently
or kept open too long.
• Make sure that the air outlets are not blocked by
food.
• Make sure that the doors are fully closed.
• To remove the frost, see Defrosting your
refrigerator on page 10.
The refrigerator door is hard
to open.
• When you open the refrigerator door, warm air
rushes inside. When you close the door, the
warm air rushes to the condenser which causes a
vacuum. This causes the door to be hard to open
for about 10 to 15 seconds after closing.
• If the door is hard to open at other times, try
rubbing paraffin wax or petroleum jelly along
the edges of the entire gasket. Paraffin wax is
used for canning and is safe for use around food.
PROBLEM SOLUTION
NS-CF30SS9_18-0222_MAN_V2_EN.fm Page 16 Monday, April 16, 2018 12:36 PM

17
2-Door Compact Refrigerator
www.insigniaproducts.com
The compressor runs for a
long time or turns on and off
frequently.
The compressor runs longer if:
• The room temperature is high.
• You just added a large amount of food. Wait for
the food to freeze, then check again.
• You open and close the door frequently.
• The door gasket is dirty. Clean the gasket. See
Maintaining your refrigerator on page 14.
• Your refrigerator has been disconnected for a
period of time. Wait for your refrigerator to cool
(about four hours) before adding food.
• You have the temperature set too low.
The light inside the
refrigerator does not turn on.
• Make sure that your refrigerator is plugged into
a working outlet.
• If a door stays open too long, your refrigerator
automatically turns off the light.
• Close then open the door again.
• Check to see if the light is damaged. If the light is
damaged, have it replaced by a qualified service
technician. See Changing the interior light on
page 14.
The refrigerator makes
unusual noises or vibrations.
The following sounds are normal:
• Compressor running noises.
• Air movement noise from the small fan motor in
the freezer compartment or other
compartments.
• Gurgling sound similar to water boiling.
• Clicking noise before the compressor starts.
Other unusual noises or vibrations may occur:
• If you have items on the top of your refrigerator.
Remove the items.
• If your refrigerator is not level. See Leveling your
refrigerator on page 8.
• If your refrigerator is touching walls. Move it
away from the walls.
• If the shelves or drawers are installed incorrectly.
The outside of the refrigerator
is hot.
Heat dissipation from the condenser may make the
outside feel hot. This is normal and happens if:
• The room temperature is high.
• You have too much food in your refrigerator.
• You open and close the doors excessively.
Water condenses on the
outside of the refrigerator.
• Condensation on the exterior surface and door
seal is normal when the room humidity is high.
• When you open the door, warm, moist outside
air meets the cold dry air inside your refrigerator.
This is normal.
PROBLEM SOLUTION
NS-CF30SS9_18-0222_MAN_V2_EN.fm Page 17 Monday, April 16, 2018 12:36 PM

18
NS-CF30SS9
www.insigniaproducts.com
Specifications
Dimensions (W x D x H) 19.1 x 20.5 x 33.4 in (48.5 x 52.0 x 84.8 cm)
Weight 55 lbs (24.92 kg)
Power requirements 115 V~60 Hz
Current 1.5 A
Power consumption (annual) 321 kwh
Power cord length 5 ft. 1 in. (+/- 2 in.)(1.55 m [+/- .05 m])
NS-CF30SS9_18-0222_MAN_V2_EN.fm Page 18 Monday, April 16, 2018 12:36 PM

19
2-Door Compact Refrigerator
www.insigniaproducts.com
ONE-YEAR LIMITED WARRANTY
Definitions:
The Distributor* of Insignia branded products warrants to you, the original purchaser of this
new Insignia-branded product (“Product”), that the Product shall be free of defects in the
original manufacturer of the material or workmanship for a period of one (1) year from the
date of your purchase of the Product (“Warranty Period”).
For this warranty to apply, your Product must be purchased in the United States or Canada
from a Best Buy branded retail store or online at www.bestbuy.com or www.bestbuy.ca and
is packaged with this warranty statement.
How long does the coverage last?
The Warranty Period lasts for 1 year (365 days) from the date you purchased the Product.
Your purchase date is printed on the receipt you received with the Product.
What does this warranty cover?
During the Warranty Period, if the original manufacture of the material or workmanship of
the Product is determined to be defective by an authorized Insignia repair center or store
personnel, Insignia will (at its sole option): (1) repair the Product with new or rebuilt parts; or
(2) replace the Product at no charge with new or rebuilt comparable products or parts.
Products and parts replaced under this warranty become the property of Insignia and are
not returned to you. If service of Products or parts are required after the Warranty Period
expires, you must pay all labor and parts charges. This warranty lasts as long as you own your
Insignia Product during the Warranty Period. Warranty coverage terminates if you sell or
otherwise transfer the Product.
How to obtain warranty service?
If you purchased the Product at a Best Buy retail store location or from a Best Buy online
website (www.bestbuy.com or www.bestbuy.ca), please take your original receipt and the
Product to any Best Buy store. Make sure that you place the Product in its original packaging
or packaging that provides the same amount of protection as the original packaging.
To obtain warranty service, in the United States call 1-888-BESTBUY or in Canada call
1-866-BESTBUY. Call agents may diagnose and correct the issue over the phone.
Where is the warranty valid?
This warranty is valid only in the United States and Canada at Best Buy branded retail stores
or websites to the original purchaser of the product in the county where the original
purchase was made.
What does the warranty not cover?
This warranty does not cover:
• Customer instruction/education
•Installation
•Setupadjustments
• Cosmetic damage
• Damage due to weather, lightning, and other acts of God, such as power surges
• Accidental damage
•Misuse
•Abuse
•Negligence
• Commercial purposes/use, including but not limited to use in a place of business or in
communal areas of a multiple dwelling condominium or apartment complex, or
otherwise used in a place of other than a private home.
• Modification of any part of the Product, including the antenna
• Display panel damaged by static (non-moving) images applied for lengthy periods
(burn-in).
• Damage due to incorrect operation or maintenance
NS-CF30SS9_18-0222_MAN_V2_EN.fm Page 19 Monday, April 16, 2018 12:36 PM

20
NS-CF30SS9
www.insigniaproducts.com
• Connection to an incorrect voltage or power supply
• Attempted repair by any person not authorized by Insignia to service the Product
• Products sold “as is”or “with all faults”
• Consumables, including but not limited to batteries (i.e. AA, AAA, C, etc.)
• Products where the factory applied serial number has been altered or removed
• Loss or Theft of this product or any part of the product
• Display panels containing up to three (3) pixel failures (dots that are dark or incorrectly
illuminated) grouped in an area smaller than one tenth (1/10) of the display size or up to
five (5) pixel failures throughout the display. (Pixel based displays may contain a limited
number of pixels that may not function normally.)
• Failures or Damage caused by any contact including but not limited to liquids, gels or
pastes.
REPAIR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS YOUR EXCLUSIVE REMEDY
FOR BREACH OF WARRANTY. INSIGNIA SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR
CONSEQUENTIAL DAMAGES FOR THE BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON
THIS PRODUCT, INCLUDING, BUT NOT LIMITED TO, LOST DATA, LOSS OF USE OF YOUR
PRODUCT, LOST BUSINESS OR LOST PROFITS. INSIGNIA PRODUCTS MAKES NO OTHER
EXPRESS WARRANTIES WITH RESPECT TO THE PRODUCT, ALL EXPRESS AND IMPLIED
WARRANTIES FOR THE PRODUCT, INCLUDING BUT NOT LIMITED TO ANY IMPLIED
WARRANTIES OF AND CONDITIONS OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE, ARE LIMITED IN DURATION TO THE WARRANTY PERIOD SET FORTH ABOVE AND
NO WARRANTIES, WHETHER EXPRESS OR IMPLIED, WILL APPLY AFTER THE WARRANTY
PERIOD. SOME STATES, PROVINCES AND JURISDICTIONS DO NOT ALLOW LIMITATIONS ON
HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY TO
YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER
RIGHTS, WHICH VARY FROM STATE TO STATE OR PROVINCE TO PROVINCE.
Contact Insignia:
1-877-467-4289
www.insigniaproducts.com
INSIGNIA is a trademark of Best Buy and its affiliated companies.
*Distributed by Best Buy Purchasing, LLC
7601 Penn Ave South, Richfield, MN 55423 U.S.A.
©2018 Best Buy. All rights reserved.
Made in China
NS-CF30SS9_18-0222_MAN_V2_EN.fm Page 20 Monday, April 16, 2018 12:36 PM
