InSinkErator F-H1100C-1H User manual

The Emerson logo is a trademark and a service mark of Emerson Electric Co.
InSinkErator may make improvements and/or changes in the specifications
at any time, in its sole discretion,without notice or obligation and further
reserves the right to change or discontinue models.
© 2015 InSinkErator, InSinkErator® is a business unit of
Emerson Electric Co. All rights reserved.
InSinkErator
Emerson Electric Co.
4700 21st Street
Racine, WI 53406-5093
USA
Sales/Service Tel: [phone]
www.insinkerator.com/worldmap.html
InSinkErator
Suite 6, Building 6
Hatters Lane, Croxley Green Business Park
Watford WD18 8YH
United Kingdom
Sales Tel: [phone]
Service Tel: [phone]
www.insinkerator.co.uk
45029 REV A
Steaming Hot Water Tap
Owner’s Manual
Installation, Care & Use
F-H1100C-1H
F-HC1100C-1H
HWT-1H

Unpack tap components.
On a firm, flat surface, carefully
straighten the copper tubing using
hands only.
a
Property Damage: Do not pinch or break copper
tubing. Do not distort the last 1 inch of tubing.
We are delighted that you have chosen the InSinkErator®steaming hot water tap
to be a part of your home. This unique appliance will save you time and effort in the kitchen,
and you’ll enjoy discovering new uses for it each day. That’s exactly why millions of people are
now using an InSinkErator steaming hot water tap.
We are confident that by following our step-by-step instructions, you’ll soon be enjoying the
convenience of instant hot water.
For your satisfaction and safety, read all instructions, cautions and warnings before installing or using this
steaming hot water tap.
This particular unit is not intended for commercial use.
Make sure that all electrical wiring and connections conform to local codes.
A standard grounded electrical outlet is required under the sink for the tap’s electrical power.
The wall outlet powering your tap must have power supplied to it continuously.
This outlet must be fused and should not be controlled by the same wall switch that operates the disposer,
unless you have a SinkTop Switch™from InSinkErator®.
Tap must be installed such that the outlet opening is greater than 25mm above the overflow rim of the sink.
It is recommended that a dedicated control valve be installed on the cold water line supplying water to this system.
If you suspect elevated levels of chlorine in your water, or your water has a rusty appearance before the
installation of this unit, it is recommended to use our water filtration system.
This product contains stainless steel. The manufacturer cannot guarantee against rusty water because of the
number of factors that are involved beyond the manufacturer’s control. However, the sudden appearance of rusty
water discharged from the hot water tap may indicate the need for service or replacement of this product.
The use of a water filter should NOT result in a drop in water pressure below 25 psi (172kPa). If it does, this will
prevent your unit from operating properly.
Moving parts inside the tank causing a rattling noise is normal.
WHAT YOU SHOULD KNOW BEFORE YOU BEGIN
n Phillips and flat blade screwdrivers
n Pencil
n Tape measure
n Level
Equipment You May Need:
Equipment Required:
n Drill
n T-fitting
n Dedicated control valve
n Adjustable wrench
n Phillips and flat blade screwdrivers
n Pencil
n Tape Measure / Ruler
n Level
Anchors for drywall
Hole saw
Basin wrench
Hole punch
If you intend to use the sprayer hole in your sink for your tap, you may need a basin wrench and a
3mm plug or a 6mm cap (not supplied) for the sink spray hose line. See Step 1-B.
If you need to cut a mounting hole in your stainless steel sink, you may need a 32mm – 38mm hole
saw made for cutting stainless steel or a hole punch. Consult a professional if you are drilling into a
surface other than stainless steel.
WHAT YOU NEED TO GET STARTED
HOW TO USE THIS INSTRUCTION MANUAL
These instructions are separated into main sections, indicated by numbers, and
subsections, indicated by capital letters. The manual is setup this way to allow you to
take a break at any point after completing a section or subsection without affecting
the installation process.
What you’ll see in the
instruction manual:
1
2
Provides a step-by-step narrative describing the installation step, with check boxes
that can be marked as you progress through the installation.
Contains simple illustrations that provide visual instruction to support the narrative.
IMPORTANT SAFETY MESSAGES that will require your attention during the step.
1
2
3
OVERVIEW OF A
COMPLETED SETUP
3
2
Warning indicates a hazardous situation, which, if not avoided, could result in death or
serious injury.
Caution indicates a hazardous situation which, if not avoided, could result in
minor or moderate injury.
Notice is used to address practices not related to personal injury.
NOTICE
NOTICE
NOTICE
NOTICE
3

COMPONENTS IN THIS PACKAGE
The wall outlet for your tap must have power supplied to it continuously
and must be fused. It should not be controlled by the same wall switch
that operates your disposer, unless using an InSinkErator SinkTop Switch™.
PREPARATION
START HERE
Identify locations for the tap, tank
and filter (if applicable).
Check to make sure counter is
76mm thick or less.
Make sure there is a grounded
electrical outlet under the sink.
Turn off water supply.
If using the sink sprayer hose hole,
remove nut that connects sprayer hose
at bottom of tap.
Using adjustable wrench, remove nut
connecting sprayer washer flange in
sprayer hole.
Plug hose opening with either a 3mm
plug or a 6mm cap (not supplied).
1a
b
If you have to drill through sink or
countertop, you may need to rent or
purchase the appropriate tools.
Consult a professional before drilling into
a surface other than stainless steel.
cWhat if you don’t have a sprayer hole
or don’t want to use it?
Many homeowners replace the
soap dispenser in their sink with a
steaming hot water tap.
If drilling a hole into a stainless steel
sink or counter top, you can cut a
mounting hole for the tap with a hole
saw for stainless steel, or you can
use a hole punch.
H1100 83mm
HC1100 67mm
76mm
H1100 32mm – 38mm
HC1100 35mm – 38mm
Required minimum from
center of hole to wall
Maximum counter thickness is
Required Hole Size
HWT-1H
Filter Head
6mm Tubes (2)
Filter Cartridge
Mounting Plate
Hex Tool
Rubber O-Ring
19mm (4)
Quick Connector
H1100
HC1100
Hex Nut
5
4

Property Damage: Do not pinch or break copper
tubing. Do not distort the last 25mm of tubing.
2H1100/HC1100
Unpack hot water tap components.
On a firm, flat surface, carefully
straighten the copper tubing.
Ensure that the black O-ring is
properly seated in the base of
the tap head (the groove on the
underside of the tap).
H1100/HC1100
Feed tubes down through the hole
in the sink or countertop until the
base is at rest.
From under the sink, place the
mounting plate and hex nut onto
the threaded stud. Ensure tap head
is at desired angle.
Insert screwdriver into hole on side
of hex tool (creating a “T”), and use
tool to tighten nut and secure tap.
INSTALLING THE TAP -H1100/HC1100
b
a
NOTICE
aSelect a spot under the sink to mount
tank vertically within reach
of both plumbing and electrical
connections. The tank should be
within 400mm or less of tap water
lines and within 760mm or less of a
standard grounded outlet.
While holding tank in place on
the spot selected for installation,
use a pencil to mark locations for
2 hanging screws.
Property Damage: Tank must be located
within 400mm of tap and within 760mm or less
of a standard grounded outlet. DO NOT
extend plumbing or electrical lines.
3
Tank must be
mounted level
to ensure
proper operation.
Mount tank vertically in an area that allows
clearance on the underside of the tank for drainage,
if necessary. DO NOT over tighten screws.
Pre-drill 3mm pilot holes at marks.
Turn screws into pre-drilled holes,
leaving 6mm exposed.
Hang the tank on the screws.
Tighten the screws with only
1/2 turn clockwise.
bScrews provided are for use in wood
studs or cabinets only. Use wall anchors
(not supplied) for installation into drywall.
Leave 6mm for
hanging tank.
MOUNTING THE TANK
NOTICE
Without depressing the gray button,
place the snap-connect fitting at
the end of the blue 6mm tube onto
the left fitting on the tank, pushing
until it clicks into place. (1)
Slip the flexible white 11mm tube
over barbed steel fitting and slide
down approximately 13mm. (2)
Slip the clear 8mm tube over the
smooth plastic fitting and slide down
approximately 13mm. (3)
Visually check for pinched or
crimped tubes.
4a
Property Damage: Pinched or blocked water
lines may cause damage to the tap tank. Check
to make sure tubes are connected
properly and are pushed down as far as possible.
Hose clamps are not needed for any
of the connections.
CONNECTING TAP TO TANK
(1) (2) (3)
NOTICE
7
6
An assistant may be needed to hold
the tap in place while securing.

nMark hole locations for filter head
and bracket in a spot that allows for
filter replacement.
nDrill 3mm starter holes and attach
bracket to wall with wood screws,
turning until snug.
nRemove red filter cap, insert filter
cartridge into filter head and twist
clockwise until “LOCK” arrow on the
filter aligns with arrow on bracket.
Personal Injury: Do not locate filter above an outlet or other
electrical device. Install head and bracket so that connections
require no stretching, kinking or pinching of tubing.
5
nDetermine length of tubing
required, then cut to length making
sure the cut is perpendicular and
burr-free.
nInsert a white 9.5mm tube into
inlet side of filter head until it stops.
Press in again to ensure a
secure fit.
n Insert the other white tube into
outlet side of filter head until it
stops. Press in again to ensure
a secure fit.
Property Damage: Tube runs need to form to the cabinet’s
contours to allow storage space with no sharp bends. Tubes
need clean, perpendicular, burr-free cuts to ensure a true fit.
From water
supply line To tap
nHC1100 only: Remove plug from
“Y” quick connector by holding
grey release ring and gently pulling
plug out.
nInsert the copper tube(s) from the
tap into the 9.5mm to 6.35mm
quick-connector. Press in again to
ensure a secure fit.
nConnect the white tube from the
right outlet on the filter head into the
quick-connector until it stops. Press
in again to ensure a secure fit.
Property Damage: Do not extend the
copper lines farther than the 40cm provided.
nTo redirect filter replacement water
discharge, place 150mm clear tube
over vent hole on the left side of
filter head.
It is normal for approximately 60 ml of
water to discharge when filter is removed.
Discharge tube
From water
supply line
To tap
INSTALLING FILTRATION
From filter or
water supply line
NOTICE
NOTICE
a
bnTurn on the cold water supply.
nDepress the tap’s hot handle and
hold it until water flows from the
spout (approximately 1 to 2 minutes).
nRun the water for at least 4minutes
to flush lines (both the hot and cool
handles on HC1100 independently).
7FILL TANK & THEN CONNECT POWER
a
Scalding Hazard: The tap dispenses
near-boiling water which can
instantly cause scalds or burns. Use care
when operating this appliance.
nCheck all connections to ensure they
are tight and that there are no leaks.
nPlug in instant hot water tank.
Water will be cold at first.
Allow 12-15 minutes for water to reach
target temperature.
Gurgling or hissing is normal during
the initial heating cycle.
Electric Shock Hazard: A standard grounded
outlet within 760mm of the tap is
required under the sink. Do not use an
extension cord set with the tap.
b
Property Damage: Join remaining
tube to cold water supply only.
nAt the other end of the white tube
from the filter, install a 9.5mm to
15mm connection to the water supply.
nPress in again to ensure a
secure fit.
FINAL WATER CONNECTION
6a
c
D
9
8
NOTICE
HC1100H1100
From filter or
water supply line
Plug

11
10
IMPORTANT SAFETY INFORMATION
Fire Hazard: To minimise possibility of fire, DO NOT store
flammable items such as rags, paper or aerosol cans near the
tank. DO NOT store or use petrol or other flammable vapours
and liquids in the vicinity of this or any other appliance.
Leak Hazard: Regularly inspect tap and plumbing fittings
for leaks, which can cause property damage and could
result in personal injury.
A steaming hot water tap, like any water heater, has a limited life and will
eventually fail. To avoid possible property damage and personal injury,
this steaming hot water tap should be regularly examined for leakage and/
or corrosion and replaced when necessary. A drain pan, plumbed to an
appropriate drain or outfitted with a leak detector, should be used in those
applications where any leakage could cause property damage.
nUse this water heater only for its intended use as described in this manual.
nThis appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
nDo not operate this product if it has been or appears to be damaged in
any manner or after the product malfunctions, or is dropped. Return the
complete product immediately to your retail dealer for inspection, and
if necessary, adjustment or repair.
nIf the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard.
Important: Always arrange the power cord so that it cannot come in contact
with hot surfaces.
nDo not disconnect the product from the power supply by pulling on the cord.
nDo not use the product for other than its intended use as described in
these instructions. The use of accessory attachments other than those
recommended by the manufacturer may cause safety hazards.
nThe recommended connection may be made to an existing cold water line
with a branch terminating with a shutoff valve, a pressure relief and dual
check non-return valve sited adjacent to the product.
Electric Shock Hazard: To reduce the risk of electric shock,
do not immerse or expose the product, flexible cord or plug to
rain, moisture or any liquid or when standing in or on damp
or wet surfaces. If any electrical product falls into water,
UNPLUG it immediately. DO NOT REACH INTO THE WATER.
Important: Prior to reconnecting to the power supply, the
product should be inspected by a qualified technician.
To reduce the risk associated with the ingestion of
contaminants: Do not use with water that is microbiologically
unsafe or of unknown quality without adequate disinfection
before or after the system.
Personal Injury/Property Damage: To reduce the risk
associated with hazardous voltage due to an installer drilling
through existing electric wiring in the area of installation: Do
not install near electric wiring which may be in path of a drilling
tool when selecting the position to mount the system bracket.
Also avoid the risk of drilling into water pipes which may
result in property damage.
This appliance must be earthed (grounded). This steaming hot water tap is
equipped with a cord that has a grounding conductor and earth ground pin. The
plug must be connected to an appropriate outlet that is properly installed and
earthed (grounded) in accordance with all local codes and ordinances. Do not
modify the plug provided with the appliance – if it will not fit the outlet, have a
proper outlet installed by a qualified electrician. Check with a qualified electrician
or tradesman if you are in doubt as to whether the steaming hot water tap is
properly earthed (grounded).
Electric Shock Hazard: Using an ungrounded (no earth
ground) or improperly connected appliance can result in
serious injury or death from electrical shock.
To reduce the risk associated with choking: Do not allow
children under 3 years of age to have access to small parts
during the installation of this product.
Personal Injury/Property Damage: This tank is a non-
pressurised tank. DO NOT modify this system. DO NOT
close vent tube or connect other types of taps or valves to
the tank. Use only the InSinkErator tap supplied. Use only
parts provided. Contact an authorised InSinkErator Service
agent for repairs or replacement components.
Property Damage: To reduce the risk associated with
property damage due to water leakage or flooding, and to
ensure optimal performance:
•Read and follow Use Instructions before installation and use
of this system.
• Installation and use MUST comply with all state and local plumbing codes.
System Requirements (Hot Water Tank, Filtration System and Tap):
• The flexible vent and outlet tubes must be correctly connected to
the tap supplied by the manufacturer. They must not be
obstructed or connected to a normal type tap or any other type.
• Do not install on hot water supply lines. The maximum operating water
temperature of this system is 37.8°C. Attach to cold water supply only.
NOTICE

Taps: 1-year warranty
Stainless Steel Tank: 1-year warranty
Filtration System (excluding replaceable filtration cartridge): 1-year warranty
This warranty is provided by InSinkErator, a business unit of Emerson Electric Co., (“InSinkErator” or “Manufacturer” or
“we” or “our” or “us”) to the original consumer owner of the InSinkErator product with which this warranty is provided (the
“InSinkErator Product”), and any subsequent owner of the residence in which the Product was originally installed (“Customer”
or “you” or “your”).
InSinkErator warrants to Customer that your InSinkErator Product will be free from defects in materials and workmanship, subject
to the exclusions described below, for the “Warranty Period”, commencing on the later of: (a) the date your InSinkErator Product
is originally installed, (b) the date of purchase, or (c) the date of manufacture as identified by your InSinkErator Product serial
number. You will be required to show written documentation supporting (a) or (b). If you are unable to provide documentation
supporting either (a) or (b), the Warranty Period commencement date will be determined
by Manufacturer, in its sole and absolute discretion, based upon your InSinkErator Product serial number.
What is Covered
This warranty covers defects in materials or workmanship, subject to the exclusions below, in InSinkErator Products used by a
consumer Customer for residential use only, and includes all replacement parts and labor costs. YOUR SOLE AND EXCLUSIVE
REMEDY UNDER THIS LIMITED WARRANTY SHALL BE LIMITED TO REPAIR OR REPLACEMENT OF THE INSINKERATOR
PRODUCT.
What is not Covered
This limited warranty does not extend to and expressly excludes:
• Losses or damages or the inability to operate your InSinkErator Product resulting from conditions beyond the
Manufacturer’s control including, without limitation, accident, alteration, misuse, abuse, neglect, negligence
(other than Manufacturer’s), failure to install, maintain, assemble, or mount the InSinkErator Product in accordance
with Manufacturer’s instructions or local electrical and plumbing codes.
• Wear and tear expected to occur during the normal course of use, including without limitation, cosmetic rust,
scratches, dents or comparable and reasonably expected losses or damages.
In addition to the above exclusions, this warranty does not apply to InSinkErator Products installed in a commercial or industrial
application.
No Other Express Warranty Applies
This warranty is the sole and exclusive warranty provided to the Customer identified above. No other express warranty, written or
verbal, applies. No employee, agent, dealer, or other person is authorized to alter this limited warranty or make
any other warranty on behalf of Manufacturer. The terms of this warranty shall not be modified by the Manufacturer, the original
owner, or their respective successors or assigns.
What we will do to Correct Problems
If your InSinkErator Product does not operate in accordance with the documentation provided to you, or you have questions
concerning your InSinkErator Product or how to determine when service is needed, please see attached Service Agency List.
The following information must be provided as part of your warranty claim: your name, address, phone number, your InSinkErator
Product model and serial number, and if necessary, upon request, written confirmation of either: (a) the date shown on your
installation receipt, or (b) the date shown on your purchase receipt.
Manufacturer or its authorized service representative will determine, in its sole and absolute discretion, if your InSinkErator
Product is covered under this warranty. You will be given the contact information for your closest authorized InSinkErator Service
Center. Please contact your InSinkErator Service Center directly to receive in home warranty repair or replacement service. Only
an authorized InSinkErator service representative may provide warranty service. InSinkErator is not responsible for warranty
claims arising from work performed on your InSinkErator Product by anyone other than an authorized InSinkErator service
representative.
If a covered claim is made during the Warranty Period, Manufacturer will, through its authorized service representative, either
repair or replace your InSinkErator Product. Cost of replacement parts or a new InSinkErator Product, and cost of labor for repair
or installation of the replacement InSinkErator Product are provided at no cost to you. Repair or replacement shall be determined
by Manufacturer or its authorized service representative in their sole discretion. All repair and replacement services will be
provided to you at your home. If Manufacturer determines that your InSinkErator Product must be replaced rather than repaired,
the warranty on the replacement InSinkErator Product will be limited to the unexpired term remaining in the original Warranty
Period.
Limitation of Liability
TO THE EXTENT PERMITTED BY LAW, IN NO EVENT SHALL MANUFACTURER OR ITS AUTHORIZED SERVICE
REPRESENTATIVES BE LIABLE FOR ANY INCIDENTAL, SPECIAL, INDIRECT, OR CONSEQUENTIAL DAMAGES, INCLUDING
ANY ECONOMIC LOSS, WHETHER RESULTING FROM NONPERFORMANCE, USE, MISUSE OR INABILITY TO USE THE
INSINKERATOR PRODUCT OR THE MANUFACTURER’S OR ITS AUTHORIZED SERVICE REPRESENTATIVE’S NEGLIGENCE.
MANUFACTURER SHALL NOT BE LIABLE FOR DAMAGES CAUSED BY DELAY IN PERFORMANCE AND IN NO EVENT,
REGARDLESS OF THE FORM OF THE CLAIM OR CAUSE OF ACTION (WHETHER BASED IN CONTRACT, INFRINGEMENT,
NEGLIGENCE, STRICT LIABILITY, OTHER SORT OR OTHERWISE), SHALL MANUFACTURER’S LIABILITY TO YOU EXCEED
THE PRICE PAID BY THE ORIGINAL OWNER FOR THE INSINKERATOR PRODUCT.
The term "consequential damages" shall include, but not be limited to, loss of anticipated profits, business interruption, loss of
use or revenue, cost of capital or loss or damage to property or equipment.
WARRANTY INFORMATION
System Requirements (Hot Water Tank, Filtration System and Tap):
•Do not install if water pressure exceeds 862 kPa. If your water
pressure exceeds 552 kPa, you must install a pressure limiting
valve. Contact a plumbing professional if you are uncertain how
to check your water pressure.
• Do not install where water hammer conditions may occur. If water hammer
conditions exist you must install a water hammer arrester. Contact a plumbing
professional if you are uncertain how to check for this condition.
• Where a backflow prevention device is installed on a water system, a device for
controlling pressure due to thermal expansion must be installed.
• Protect from freezing, shut off water supply, remove filter cartridge, drain hot
water tank and tubing when temperatures are expected to drop below 4.4° C;
see Seasonal Storage/Drainage section.
• Do not use a torch or other high temperature sources near system, cartridges,
plastic fittings or plastic plumbing.
• Do not install near water pipes which will be in path of a drilling tool when
selecting the position to mount the bracket.
• Mount system in such a position as to prevent it from being struck by other items
used in the area of installation.
• Ensure that the location and fasteners will support the weight of the system
when installed and full of water.
• Ensure all tubing and fittings are secure and free of leaks.
• Do not install using rigid piping. System intended for use with plastic water lines
(such as PEX tubing, PE tubing, PP tubing).
• Do not install this system if any of the quick connect collets are missing from
the filter head or Y-Quick Connector. Contact an authorised InSinkErator Service
agent if collets are missing from any fittings.
• For systems using two handle HC model taps, operate only one handle at a time.
• Important: Do not allow the unit to continuously boil.
• Regularly inspect the system. If there are signs of water leakage, turn off the
water supply and contact an authorised InSinkErator Service agent.
• A drain pan, plumbed to an appropriate drain or outfitted with a leak detector,
should be used in those applications where any leakage could cause property damage.
• For questions or concerns, please contact an authorised InSinkErator Service
agent (see back page for contact information).
Additional Consideration when Utilising Filtration System:
• The disposable filter cartridge MUST be replaced every 6 months, at the rated
capacity or sooner if a noticeable reduction in flow rate occurs.
• Failure to replace the disposable filter cartridge at recommended intervals may lead
to reduced filter performance and cracks in the filter housing, causing water leakage
or flooding.
• Protect from freezing, remove filter cartridge when temperatures are expected to
drop below 4.4°C.
• Do not install systems in areas where ambient temperatures may go above 43.3° C.
• Do not install in direct sunlight or outdoors.
• Flush filter for 4 minutes, 11.4 L before first use.
• Recommended water flow: 2.84 Lpm
NOTICE
IMPORTANT SAFETY INFORMATION

14
TROUBLESHOOTING
WHAT TO DO
Water and steam
spits forcefully from spout
without turning
on the tap.
• Unit is boiling.
May be normal during initial set-up.
• Depress the tap handle to release some water from the tank.
• Adjust water temperature using dial on tank front.
Remember that at higher altitudes, water boils at
lower temperatures.
Water is not hot. • The unit may not be plugged in.
• The electric outlet is inoperative.
• Make sure the unit is connected to a properly earthed
(grounded) electric outlet.
• Make sure the circuit breaker or fuses are
functioning properly.
• Check that the outlet is not switched off.
Water is too hot
or not hot enough.
• Thermostat is not adjusted to
your needs.
• Adjust the thermostat slowly, then depress the tap handle for
20 seconds to bring in fresh water to be heated
at the new setting. Allow 5-7 minutes for water to reach
new temperature.
Water comes out of vent
instead of spout
• Outlet tube is blocked. • Check that outlet tube is not kinked, twisted or pinched.
• Unscrew spout end piece and clean out any debris.
Water is dripping
from the spout/vent
intermittently.
• The expansion chamber is not
draining properly due to low
water pressure.
• The spout is blocked.
• Unplug the unit. If the dripping does not stop after a few
minutes, check the supply valve to ensure it is fully open
and there are no obstructions in the water line reducing
the pressure below 172 kPa (1.7 bar; 25 psi). i.e., a poorly
mounted saddle valve, a clogged water filter, or a partially
opened shut-off valve.
• Unscrew spout end piece and clean out any debris.
Water is dripping
from the spout/vent
constantly.
• Debris in the water line may be
in the tap valve seat causing a
slow water leak.
• Unscrew spout end piece and clean out any debris.
• Depress tap handle 7-10 times to flush tap & lines.
Divided stream. • Debris in the end piece. • Unscrew spout end piece and clean out any debris.
PROBLEM POSSIBLE CAUSE
Water discoloration/
rusty appearance.
• Corrosion of unit. • Unplug and drain as described in the Seasonal Storage/
Drainage Section on page 13 of this manual. If the water
discoloration remains after draining and refilling unit,
discontinue use and contact an authorised InSinkErator
service agent.
FILTRATION ISSUES
Water taste or odour.
New filter does not fit.
The filter leaks.
No water flow or low
water flow.
• Filter water flow direction is wrong.
• Filter needs to be flushed out.
• Life of filter has expired.
• Head and bracket not fully rotated.
• Filter O-ring breach.
• Head and bracket not fully rotated.
• Filter O-ring breach.
• Life of filter has expired.
• Review filter tube connection instructions.
• Depress the tap handle and run until the water is cold.
• If there is no change, replace filter cartridge.
• Take out the new filter, put in old filter.
• Remove, inspect, reinstall filter cartridge.
• Test unit by reinstalling old filter and rotating to full stop.
Check for leaks.
• Replace filter cartridge. See page 13.
Electric Shock Hazard: To prevent electrical shock, disconnect power before
servicing unit. Use only a properly grounded and polarized electric outlet.
CARE AND USE
ADJUSTING THE THERMOSTAT
PROPERTY DAMAGE
SEASONAL STORAGE/DRAINAGE
approx. 93°C
Scalding Hazard: Do not allow
water to boil. May result in
severe burns.
CLEANING THE TAP AND TANK
Only use mild cleaners to clean the
tap and plastic components.
Cleaners with acids, abrasives,
alkaline or organic solvents will result in
deterioration of the plastic components and
void the warranty.
Regularly inspect the unit for any signs
of leakage. If there are signs of water
damage, immediately remove the unit
from service and contact an Authorized
InSinkErator Service Agent.
A drain pan, plumbed to an appropriate
drain or outfitted with a leak detector,
should be used in those applications
where any leakage could cause
property damage.
Anytime the steaming hot water tap is not used for
extended periods of time, unplug and drain unit. If
it is below freezing you will need to unplug the unit
and drain it.
Disconnect power from unit (unplug unit).
Push hot water tap handle and allow
water to flow until it is cool.
Shut the cold water supply off at the valve.
Disconnect tubes from the tank.
Unhook tank from wall.
Hold tank upside down and drain the
water into the sink.
Towel dry any water drippings from
tank area.
Reinstall tank to wall and reconnect tubes.
Remove and discard filter cartridge,
if applicable.
To put back into working order, install
new filter cartridge (if applicable) and turn
on cold water supply at valve. Push the
hot water tap tap handle and hold until
water flows from the spout. Reconnect
the electrical cord.
Personal Injury:
Regularly check for signs of corrosion
by examining the appearance of the
dispensed water every three (3) months.
If there is any discoloration or rusty
appearance, unplug and drain unit
as described in the Seasonal
Storage/Drainage section on this
page of the manual.
If the water discoloration remains after
draining and refilling unit, discontinue
use and contact an authorized
InSinkErator service agent.
Factory temperature pre-set
is approximately 93˚C
Adjust the thermostat
slowly, turning the dial
clockwise to increase
temperature or counter
clockwise to decrease
temperature, then activate tap handle
for 20 seconds to bring in fresh water
to be heated at the new setting. Allow
5-7 minutes for water to reach new
temperature.
To reset the thermostat to the factory pre-set, turn
the indicator two notches to the right of vertical.
Replace filter cartridge when there is an obvious
decrease in water flow to the tap or if there is an
objectionable taste or odor to the water.
When the inlet and outlet ports have been closed
and the filter’s internal pressure has been relieved,
water (about 60ml) will discharge from vent line.
If the new filter cartridge cannot be inserted, insert
the old one and turn until it stops, remove it and then
retry the new cartridge.
The disposable filter cartridge MUST be replaced
every 6 months, at the rated capacity or sooner if a
noticeable reduction in flow rate occurs.
FILTER GUIDE AND REPLACEMENT
Filter replacement instructions:
Replace with an InSinkErator®filter.
Place pan or dish towel under the filter to
catch water drainage during change.
Slowly turn the cartridge counter-clock-
wise completely until it stops (1/4 turn).
Pull cartridge straight down and discard.
Insert new cartridge into filter head.
Top surface of cartridge will become flush
with the bottom of the filter head when
fully engaged.
Turn the cartridge clockwise until it stops
(1/4 turn).
Open tap to expel trapped air.
Run water for 3 minutes before usage.
