Intel SR1475 Configuration guide

Intel®Server Chassis SR1475 / Intel®
Server System SR1475NH1-E
Technical Product Specification
Intel order number D54566-001
Revision 1.0
March 2006
Enterprise Platforms and Services Marketing

Revision 1.0 ii
Revision History
Date Revision
Number
Modifications
March 2006 1.0 Initial Release

Revision 1.0 iii
Disclaimers
Information in this document is provided in connection with Intel® products. No license, express
or implied, by estoppel or otherwise, to any intellectual property rights is granted by this
document. Except as provided in Intel's Terms and Conditions of Sale for such products, Intel
assumes no liability whatsoever, and Intel disclaims any express or implied warranty, relating to
sale and/or use of Intel products including liability or warranties relating to fitness for a particular
purpose, merchantability, or infringement of any patent, copyright or other intellectual property
right. Intel products are not intended for use in medical, life saving, or life sustaining
applications. Intel may make changes to specifications and product descriptions at any time,
without notice.
Designers must not rely on the absence or characteristics of any features or instructions marked
"reserved" or "undefined." Intel reserves these for future definition and shall have no
responsibility whatsoever for conflicts or incompatibilities arising from future changes to them.
This document contains information on products in the design phase of development. Do not
finalize a design with this information. Revised information will be published when the product
is available. Verify with your local sales office that you have the latest datasheet before
finalizing a design.
The Intel® Server Chassis SR1475 and Intel® Server System SR1475NH1-E may contain
design defects or errors known as errata which may cause the product to deviate from
published specifications. Current characterized errata are available on request.
This document and the software described in it is furnished under license and may only be used
or copied in accordance with the terms of the license. The information in this manual is
furnished for informational use only, is subject to change without notice, and should not be
construed as a commitment by Intel Corporation. Intel Corporation assumes no responsibility or
liability for any errors or inaccuracies that may appear in this document or any software that may
be provided in association with this document.
Except as permitted by such license, no part of this document may be reproduced, stored in a
retrieval system, or transmitted in any form or by any means without the express written consent
of Intel Corporation.
Intel, Pentium, Celeron and Xeon are trademarks or registered trademarks of Intel Corporation.
*Other brands and names may be claimed as the property of others.
Copyright © Intel Corporation 2006.

Revision 1.0 iv
Table of Contents
1. Intel®Server Chassis SR1475 Feature Summary ........................................................- 13 -
1.1 Chassis Views ...................................................................................................- 13 -
1.2 Chassis Dimensions ..........................................................................................- 14 -
1.3 Intel®Server Chassis SR1475 System Components.........................................- 14 -
1.4 Rear Panel Components ...................................................................................- 15 -
1.5 Hard Drive and Peripheral Bays ........................................................................- 15 -
1.6 Control Panel .....................................................................................................- 16 -
1.7 Power Sub-system.............................................................................................- 18 -
1.8 System Cooling..................................................................................................- 18 -
1.9 Chassis Security ................................................................................................- 18 -
1.10 Rack and Cabinet Mounting Options .................................................................- 18 -
1.11 Front Bezels.......................................................................................................- 18 -
2. Cooling Sub-System ......................................................................................................- 20 -
2.1 System Fans......................................................................................................- 21 -
2.2 Power Supply Fans............................................................................................- 22 -
2.3 CPU/Memory Air Duct and Side Air Baffle.........................................................- 22 -
3. Peripheral and Hard Drive Support...............................................................................- 24 -
3.1 Slim-line Drive Bay ............................................................................................- 24 -
3.1.1 Floppy Drive Support With or Without Backplane Present ................................- 25 -
3.1.2 Optional Floppy Drive Configuration..................................................................- 26 -
3.1.3 CD-ROM or DVD-CDR Drive Use With or Without Backplane Present.............- 26 -
3.2 Hard Disk Drive Bays.........................................................................................- 28 -
3.2.1 Hot-Swap Hard Disk Drive Trays.......................................................................- 28 -
3.2.2 Fixed Drive Trays...............................................................................................- 29 -
3.2.3 Drive Blanks.......................................................................................................- 29 -
3.3 Hot-Swap SCSI Backplane................................................................................- 30 -
3.3.1 SCSI Backplane Board Layout ..........................................................................- 30 -
3.3.2 SCSI Backplane Functional Architecture...........................................................- 31 -
3.3.3 SCSI Backplane Connector Definitions .............................................................- 34 -
3.4 Hot-Swap SATA Backplane...............................................................................- 37 -
3.4.1 SATA Backplane Layout....................................................................................- 38 -
3.4.2 SATA Backplane Functional Architecture..........................................................- 39 -
3.4.3 SATA Backplane Connector Definitions ............................................................- 41 -
4. Standard Control Panel .................................................................................................- 44 -

Revision 1.0 v
4.1 Standard Control Panel Buttons .......................................................................- 44 -
4.2 Standard Control Panel LED Indicators.............................................................- 45 -
4.2.1 Power / Sleep LED ............................................................................................- 46 -
4.2.2 Drive Activity LED ..............................................................................................- 46 -
4.2.3 System Identification LED..................................................................................- 47 -
4.3 Control Panel Connectors..................................................................................- 47 -
4.4 Internal Control Panel Assembly Headers.........................................................- 47 -
5. PCI Riser Cards and Assembly.....................................................................................- 49 -
5.1 Riser Card Options ............................................................................................- 50 -
6. Power Sub-system .........................................................................................................- 51 -
6.1 Mechanical Specifications .................................................................................- 51 -
6.2 Airflow Requirements.........................................................................................- 52 -
6.3 Acoustics ...........................................................................................................- 52 -
6.4 Temperature ......................................................................................................- 53 -
6.5 Output Connectors.............................................................................................- 53 -
6.5.1 P1 Main power connector ..................................................................................- 54 -
6.5.2 P2 Processor Power Connector ........................................................................- 54 -
6.5.3 HD Power Connector (P3) .................................................................................- 55 -
6.5.4 Slim-line Power Connector (P4) ........................................................................- 55 -
6.6 AC Inlet Connector ............................................................................................- 55 -
6.7 Marking and Identification..................................................................................- 55 -
6.8 AC Input Voltage................................................................................................- 56 -
6.9 AC Line Transient Specification.........................................................................- 56 -
6.10 Susceptibility......................................................................................................- 57 -
6.10.1 Electrostatic Discharge Susceptibility ................................................................- 57 -
6.10.2 Fast Transient/Burst ..........................................................................................- 57 -
6.10.3 Radiated Immunity.............................................................................................- 57 -
6.10.4 Surge Immunity..................................................................................................- 57 -
6.11 AC Line Fast Transient (EFT) Specification ......................................................- 58 -
6.12 AC Line Dropout / Holdup..................................................................................- 58 -
6.12.1 AC Line 5VSB Holdup .......................................................................................- 58 -
6.13 Power Recovery ................................................................................................- 58 -
6.13.1 Voltage Brown Out.............................................................................................- 59 -
6.13.2 Voltage Interruptions..........................................................................................- 59 -
6.14 AC Line Inrush ...................................................................................................- 59 -
6.15 AC Line Isolation Requirements ........................................................................- 59 -
6.16 AC Line Leakage Current ..................................................................................- 59 -

Revision 1.0 vi
6.17 AC Line Fuse .....................................................................................................- 60 -
6.18 Power Factor Correction....................................................................................- 60 -
6.19 Efficiency ...........................................................................................................- 60 -
6.20 Grounding ..........................................................................................................- 60 -
6.21 Remote Sense ...................................................................................................- 60 -
6.22 Output Power / Currents ....................................................................................- 61 -
6.22.1 Standby Outputs ................................................................................................- 61 -
6.22.2 Fan Operation in Stand-By Mode ......................................................................- 61 -
6.23 Voltage Regulation ............................................................................................- 61 -
6.23.1 Dynamic Loading ...............................................................................................- 62 -
6.24 Capacitive Loading ............................................................................................- 62 -
6.25 Closed loop stability...........................................................................................- 62 -
6.26 Common Mode Noise ........................................................................................- 63 -
6.27 Ripple / Noise ....................................................................................................- 63 -
6.28 Soft Starting .......................................................................................................- 63 -
6.29 Zero Load Stability Requirements .....................................................................- 63 -
6.30 Timing Requirements.........................................................................................- 63 -
6.31 Residual Voltage Immunity in Standby mode ....................................................- 66 -
6.32 Protection Circuits..............................................................................................- 66 -
6.33 Over-Current Limit (OCP) ................................................................................- 67 -
6.34 Over-Voltage Protection (OVP) ........................................................................- 67 -
6.35 Over-Temperature Protection (OTP) ................................................................- 68 -
6.36 Control and Indicator Functions.........................................................................- 68 -
6.37 PSON# Input Signal ..........................................................................................- 68 -
6.38 PWOK (Power OK) Output Signal .....................................................................- 69 -
6.39 Environmental Requirements ............................................................................- 70 -
6.39.1 Temperature ......................................................................................................- 70 -
6.39.2 Humidity.............................................................................................................- 70 -
6.39.3 Altitude...............................................................................................................- 70 -
6.39.4 Mechanical Shock..............................................................................................- 70 -
6.39.5 Random Vibration ..............................................................................................- 70 -
6.39.6 Thermal Shock (Shipping) .................................................................................- 70 -
6.39.7 Ecological Requirements ...................................................................................- 70 -
6.39.8 Catastrophic Failure...........................................................................................- 70 -
7. Electromagnetic Compatibility......................................................................................- 71 -
7.1 EMI ....................................................................................................................- 71 -
7.2 Input Line Current Harmonic Content (PFC) ....................................................- 71 -

Revision 1.0 vii
7.3 Magnetic Leakage Fields...................................................................................- 72 -
7.4 Voltage Fluctuations and Flicker........................................................................- 72 -
7.5 Reliability / Warranty / Service...........................................................................- 72 -
7.5.1 Component De-rating ........................................................................................- 72 -
7.5.2 Component Life requirement .............................................................................- 72 -
7.6 Mean Time Between Failures (MTBF)...............................................................- 72 -
7.6.1 Warranty Period.................................................................................................- 72 -
7.6.2 Serviceability......................................................................................................- 73 -
7.7 Power Supply Returned for Repair ....................................................................- 73 -
7.8 Modifications / Change Control..........................................................................- 73 -
7.9 Power Supply Compliance Overview.................................................................- 73 -
7.10 Power Supplies Compliance Information...........................................................- 74 -
7.11 EMC Compliance Information............................................................................- 74 -
7.12 Immunity Compliance Information .....................................................................- 75 -
7.13 Harmonics & Voltage Flicker Compliance Information ......................................- 75 -
7.14 Environmental / Ecology Compliance Information .............................................- 75 -
7.15 Other Safety Requirement Notations.................................................................- 76 -
7.15.1 Certification Conditions......................................................................................- 76 -
7.15.2 Isolation Between Primary - Secondary.............................................................- 76 -
7.15.3 Creepage & Clearance Requirements...............................................................- 76 -
7.15.4 Leakage Current Maximums..............................................................................- 76 -
7.15.5 Max Surface Temperatures ...............................................................................- 76 -
7.15.6 Date Coded Serial Numbers..............................................................................- 76 -
7.15.7 Power Input Electrical Ratings...........................................................................- 76 -
7.15.8 Maximum Allowable Temperatures on Inlet Receptacles..................................- 76 -
7.15.9 Maximum Allowable Temperatures on Power Cords.........................................- 76 -
8. Supported Intel®Server Boards....................................................................................- 77 -
8.1 Intel®Server Board SE7230NH1-E Feature Set................................................- 77 -
9. Regulatory, Environmentals, and Specifications........................................................- 80 -
9.1 Product Regulatory Compliance ........................................................................- 80 -
9.1.1 Product Safety Compliance ...............................................................................- 80 -
9.1.2 Product EMC Compliance .................................................................................- 80 -
9.1.3 Product Regulatory Compliance Markings ........................................................- 81 -
9.2 Electromagnetic Compatibility Notices ..............................................................- 81 -
9.2.1 USA ...................................................................................................................- 81 -
9.2.2 FCC Verification Statement ...............................................................................- 82 -
9.2.3 ICES-003 (Canada) ...........................................................................................- 82 -

Revision 1.0 viii
9.2.4 Europe (CE Declaration of Conformity) .............................................................- 82 -
9.2.5 Japan EMC Compatibility ..................................................................................- 83 -
9.2.6 BSMI (Taiwan) ...................................................................................................- 83 -
9.3 Replacing the Back up Battery ..........................................................................- 84 -
9.4 System Level Environmental Limits...................................................................- 85 -
9.5 Serviceability......................................................................................................- 85 -
Appendix A: Intel®Server Chassis SR1475 Integration and Usage Tips...........................- 3 -
Glossary...................................................................................................................................- 4 -

Revision 1.0 ix
List of Figures
Figure 1. Front Chassis View with Bezel ................................................................................- 13 -
Figure 2. Front Chassis View without Bezel ...........................................................................- 13 -
Figure 3. Rear Chassis View ..................................................................................................- 13 -
Figure 4. Major Chassis Components.....................................................................................- 14 -
Figure 5. Back Panel Feature Overview .................................................................................- 15 -
Figure 6. Front Panel Feature Overview.................................................................................- 16 -
Figure 7. Control Panel Module ..............................................................................................- 17 -
Figure 8. Standard Control Panel Overview ...........................................................................- 17 -
Figure 9. Optional Front Bezel ................................................................................................- 19 -
Figure 10. Front Bezel Options ...............................................................................................- 19 -
Figure 11. Intel®Server Chassis SR1475 Cooling Subsystem ...............................................- 20 -
Figure 12. Intel®Server Chassis SR1475 System Fans 4, 5, 6, 7, 8 ......................................- 21 -
Figure 13. Intel®Server System SE7230NH1-E System Fan Headers 4, 5, 6, 7, 8 ...............- 21 -
Figure 14. Air Baffle ................................................................................................................- 22 -
Figure 15. CPU/Memory Air Duct ...........................................................................................- 23 -
Figure 16. Intel®Server Chassis SR1475 Peripheral Bay Configuration Options...................- 24 -
Figure 17. View of Slim-line Drive Bay....................................................................................- 24 -
Figure 18. Optional Floppy Drive Configuration......................................................................- 26 -
Figure 19. Hard Disk Drive Bay ..............................................................................................- 28 -
Figure 20. Hard Drive Tray Assembly.....................................................................................- 29 -
Figure 21. Drive Tray with Drive Blank ...................................................................................- 29 -
Figure 22. SCSI Backplane Layout.........................................................................................- 30 -
Figure 23. SCSI Backplane Functional Diagram ....................................................................- 31 -
Figure 24. Intel®Server Chassis SR1475 SCSI HSBP I2C Bus Connection Diagram ...........- 33 -
Figure 25. 68-Pin SCSI Cable Connector ...............................................................................- 34 -
Figure 26. 80-pin SCA2 SCSI Interface ..................................................................................- 36 -
Figure 27. SATA Backplane Layout........................................................................................- 38 -
Figure 28. SATA Backplane Layout........................................................................................- 38 -
Figure 29. SATA Backplane Functional Block Diagram..........................................................- 39 -
Figure 30. Intel®Server Chassis SR1475 SATA HSBP I2C Bus Connection Diagram ..........- 40 -
Figure 31. Standard Control Panel Assembly Module ............................................................- 44 -
Figure 32. Standard Control Panel Buttons ............................................................................- 44 -
Figure 34. PCI Riser Bracket and Optional PCI-X* and PCI Express* Risers ........................- 49 -
Figure 35. 1U Full Height PCI-X* Riser Card Mechanical Drawing.........................................- 50 -

Revision 1.0 x
Figure 36. 1U Full Height PCI Express* Riser Card Mechanical Drawing ..............................- 50 -
Figure 37. Power Supply Enclosure Drawing .........................................................................- 51 -
Figure 38. Airflow Characteristics ...........................................................................................- 52 -
Figure 39. Output Voltage Timing ...........................................................................................- 64 -
Figure 40. Turn On/Off Timing (Power Supply Signals)..........................................................- 66 -
Figure 41. PSON# Required Signal Characteristic. ................................................................- 69 -
Figure 42. SE7230NH1-E (LX) Board Layout .........................................................................- 78 -

Revision 1.0 xi
List of Tables
Table 1. Chassis Dimensions .................................................................................................- 14 -
Table 2. Major Chassis Components......................................................................................- 15 -
Table 3. Individual Fan Assembly Pin-out (J5J1, J4J1, J4J3, J4J2).......................................- 22 -
Table 4. 4-pin Floppy Power Connector Pin-out (J3)..............................................................- 25 -
Table 5. 34-pin Floppy Connector Pin-out (J2) .......................................................................- 25 -
Table 6. 50-pin CD-ROM Connector Pin-out (J6) ...................................................................- 26 -
Table 7. 4-pin CD-ROM Power Connector Pin-out (J5)..........................................................- 27 -
Table 8. 40-pin CD-ROM Connector Pin-out (J1) ...................................................................- 27 -
Table 9. SCSI Backplane Power Connector Pin-out (J1) .......................................................- 34 -
Table 10. UltraWide (SE) and Ultra2 (LVD) Ultra320 SCSI Connector Pin-out (J8)...............- 35 -
Table 11. 80-pin SCA2 SCSI Interface Pin-out.......................................................................- 36 -
Table 12. LED Function ..........................................................................................................- 41 -
Table 13. SATA Backplane Power Connector Pin-out............................................................- 41 -
Table 14. 7-Pin SATA Connector Pin-out (J2, J3, J4, J5, J6).................................................- 42 -
Table 15. 22-Pin SATA Connector Pin-out .............................................................................- 42 -
Table 16. Standard Control Panel Button Functions...............................................................- 45 -
Table 17. Standard Control Panel LED Functions ..................................................................- 46 -
Table 18. SSI Power LED Operation ......................................................................................- 46 -
Table 19. External USB Connector (J2)..................................................................................- 47 -
Table 20. 50-pin Control Panel Connector (J3) ......................................................................- 48 -
Table 21. Internal USB Header (J9F2) ...................................................................................- 48 -
Table 22. Acoustic Requirements ...........................................................................................- 53 -
Table 23. Environmental Requirements.................................................................................- 53 -
Table 24. Cable Lengths.........................................................................................................- 53 -
Table 25. P1 Main Power Connector .....................................................................................- 54 -
Table 26. P2 Processor Power Connector.............................................................................- 54 -
Table 27. HD Power Connector .............................................................................................- 55 -
Table 28. Slim-line Power Connector ....................................................................................- 55 -
Table 29. AC Input Rating.......................................................................................................- 56 -
Table 30. AC Line Sag Transient Performance ....................................................................- 56 -
Table 31. AC Line Surge Transient Performance .................................................................- 57 -
Table 32. Performance Criteria...............................................................................................- 57 -
Table 33. Dropout Criteria.......................................................................................................- 58 -
Table 34. Load Ratings..........................................................................................................- 61 -

Revision 1.0 xii
Table 35. Voltage Regulation Limits .......................................................................................- 61 -
Table 36. Transient Load Requirements.................................................................................- 62 -
Table 37. Capacitve Loading Conditions ................................................................................- 62 -
Table 38. Ripple and Noise.....................................................................................................- 63 -
Table 39. Output Voltage Timing ............................................................................................- 64 -
Table 40. Turn On/Off Timing .................................................................................................- 65 -
Table 41. Over Current Protection (OCP)...............................................................................- 67 -
Table 42. Over-Voltage Protection (OVP) Limits ....................................................................- 67 -
Table 43. PSON#Signal Characteristic...................................................................................- 68 -
Table 44. PWOK Signal Characteristics .................................................................................- 69 -
Table 45. Harmonic Limits, Class A equipment ......................................................................- 71 -
Table 46: Baseboard Layout Reference .................................................................................- 79 -
Table 47. System Office Environment Summary ....................................................................- 85 -
Table 48. Mean Time To Repair Estimate ..............................................................................- 86 -

Intel® Server Chassis SR1475/ Intel® Server System SR1475NH1-E
- 13 -
1. Intel®Server Chassis SR1475 Feature Summary
The Intel®Server Chassis SR1475 is a 1U server chassis specifically designed to support the
Intel®Server Board SE7230NH1-E. The Intel®Server Chassis SR1475 is available as a
standalone chassis solution from Intel, and as an integrated system. The Intel®Server System
SR1475NH1-E consists of the Intel®Server Board SE7230NH1-E integrated into the Intel®
Server Chassis SR1475. The server board and the server chassis have feature sets designed to
support the high-density server market.
The Intel®Server Board SE7230NH1-E is available in two different configurations, the
SE7230NH1LC version and the SE7230NH1LX version. Only the SE7230NH1LX version is
available for integration into the Intel®Server Chassis SR1475, and all references to the Intel®
Server Board SE7230NH1-E in this document refers to the SE7230NH1LX version of the server
board. This document provides details on the server chassis feature set and technical
specifications. For technical details related to the Intel®Server Board SE7230NH1-E, please
refer to the Intel®Server Board SE7230NH1-E Technical Product Specification.
1.1 Chassis Views
Figure 1. Front Chassis View with Bezel
Figure 2. Front Chassis View without Bezel
Figure 3. Rear Chassis View

Intel® Server Chassis SR1475 / Intel® Server System SR1475NH1-E
Revision 1.0 - 14 -
1.2 Chassis Dimensions
Table 1. Chassis Dimensions
Height 43.25 mm 1.703”
Width 430 mm 16.930”
Depth 672 mm 26.457”
Max. Weight 14.1 kg 31 LBS
1.3 Intel®Server Chassis SR1475 System Components
Figure 4. Major Chassis Components
A
B
C
D
E
F
G
H
I
J

Intel® Server Chassis SR1475 / Intel® Server System SR1475NH1-E
Revision 1.0 - 15 -
Table 2. Major Chassis Components
A Power Supply F Control Panel
B Chassis Intrusion Switch G Hard Drive Bays
C PCI Riser Card Assembly Placement H Slim-line Drive Bay
D CPU Air Duct Placement I PS / Electronics Bay Isolation Air Baffle
E System Fan Module J Power Supply Fans
1.4 Rear Panel Components
On the back of the chassis are cutouts for all external I/O connectors found on the server board.
The I/O connector locations are pre-cut, so the use of an I/O shield is not required.
A PS2 keyboard connector G USB 2 connector
B PS2 mouse connector H NIC 1 connector (RJ45)
C Serial port A connector (DB9) I PCI card bracket (full-height)
D Video connector J Rear chassis venting holes
E NIC 2 connector (RJ45) K Power Supply fans
F USB 1 connector L AC Power Receptacle
Figure 5. Back Panel Feature Overview
1.5 Hard Drive and Peripheral Bays
The server chassis is designed to support several different hard drive and peripheral
configurations. The hard drive bay is designed to support up to three fixed SATA or SCSI
drives, or three hot-swappable SATA or SCSI drives. SATA and SCSI hot-swap configurations
require an orderable accessory kit which includes the necessary cables, drive trays and
backplane. Reference the Intel®Server Chassis SR1400 Spares/Parts and Configuration List for
detailed accessory information.
The slim-line peripheral bay is capable of supporting any of the following slim-line devices: CD-
ROM drive, DVD Drive, DVD/CDR Drive, or floppy drive. If both a CD-ROM or DVD/CDR and
floppy drive are required, an optional kit is available to convert the first 1” hard drive bay to a
floppy drive bay. The kit includes the necessary cables and slim-line floppy drive mounting tray.

Intel® Server Chassis SR1475 / Intel® Server System SR1475NH1-E
Revision 1.0 - 16 -
Figure 6. Front Panel Feature Overview
A Slim-line drive bay (CD-ROM or DVD/CDR or
Floppy)
B Control Panel
C Hard Drive Fault/Activity LED
D 1” Hard Drive Bays
E Chassis Handle
1.6 Control Panel
The server chassis control panel assembly is pre-assembled and modular in design. The entire
module assembly slides into a predefined slot in the front of the chassis.

Intel® Server Chassis SR1475 / Intel® Server System SR1475NH1-E
Revision 1.0 - 17 -
Figure 7. Control Panel Module
The control panel supports several push buttons and status LEDs, and includes USB and video
ports to centralize system control, monitoring, and accessibility to within a common compact
design. The following diagram overviews the layout and functions of the control panel.
Figure 8. Standard Control Panel Overview
A Power / Sleep Button G System Identification LED
B NIC #2 Activity LED H System Identification Button
C NIC #1 Activity LED I System Reset Button
D Power / Sleep LED J USB 2.0 Connector
E Not Used K Recessed NMI Button (Tool Required)
F Hard Drive Activity LED L Video connector (not supported on SR1475)
A
B
C D E
F
G
H
I
J
L K

Intel® Server Chassis SR1475 / Intel® Server System SR1475NH1-E
Revision 1.0 - 18 -
1.7 Power Sub-system
The power sub-system of the server chassis consists of a single non-redundant 350 W power
supply (PS) and provides several integrated management features including:
•Status LED
•Over-temperature protection circuitry
•Over-voltage protection circuitry
The power supply operates within the following voltage ranges and ratings: 100-127VAC (V) ∼
at 50/60 Hertz (Hz), 6 Ampere (A) maximum (max); 200-240VAC∼at 50/60 Hz, 3 A maximum.
1.8 System Cooling
The server chassis provides non-redundant system fans and dual non-redundant power supply
fans to provide sufficient air flow for fixed and hot-swap drive configurations, processors,
memory, and an add-in card, when external ambient temperatures remain within specified limits.
1.9 Chassis Security
The server chassis provides support for several system security features including a lockable
front bezel, chassis intrusion switch, and a Kensington* style lock attach point.
1.10 Rack and Cabinet Mounting Options
The server chassis was designed to support 19” wide by up to 24”-30” deep server cabinets.
The chassis can be configured to support either a relay rack / cabinet mount kit that can be
configured to support both 2-post racks and 4-post cabinets; or a tool-less sliding rail kit that is
used to mount the chassis into a standard (19” by up to 30” deep) EIA-310D compatible server
cabinet.
1.11 Front Bezels
The optional front bezel is made of molded plastic and uses a snap-on design. When installed,
its design allows for maximum airflow.

Intel® Server Chassis SR1475 / Intel® Server System SR1475NH1-E
Revision 1.0 - 19 -
Figure 9. Optional Front Bezel
Light pipes in the front bezel supporting the standard control panel allow the system status
LEDs to be monitored with the bezel installed
Figure 10. Front Bezel Options

Intel® Server Chassis SR1475/ Intel® Server System SR1475NH1-E
- 20 -
2. Cooling Sub-System
The cooling sub-system on the server chassis is compromised of four 40x40x56mm dual rotor
fans, one 40x40x28mm single rotor fan, two 40x40x28mm power supply fans, a CPU/memory
air duct, and a PS/electronics bay isolation air baffle, to provide the necessary cooling and
airflow to the system. A fan on the processor heat sink is not necessary in this chassis. In
order to maintain the necessary airflow within the system, the air baffle, CPU/memory air duct,
and the top cover need to be properly installed.
Note: The Intel®Server Chassis SR1475 does not support redundant cooling. Should a fan fail,
the system should be brought down as soon as possible to replace the failed fan.
Figure 11. Intel®Server Chassis SR1475 Cooling Subsystem
A System Fan #4 D Air Baffle
B Fans 5, 6, 7, 8 E Processor Heat Sink
C CPU / Memory Air Duct
