Intergraph ImageStation ZIII and use Quick start guide

ImageStation ZIII
Installation and Use
August 1998
DHA033600

Copyright
1998 Intergraph Computer Systems. All rights reserved. This document contains information protected by copyright, trade secret,
and trademark law. This document may not, in whole or in part, be reproduced in any form or by any means, or be used to make any
derivative work, without written consent from Intergraph Computer Systems.
Use, duplication, or disclosure by the United States Government is subject to restrictions as set forth in subdivision (c)(1)(ii) of the
rights in technical data and computer software clause at DFARS 252.227-7013. Unpublished rights are reserved under the copyright
laws of the United States.
Intergraph Computer Systems, Huntsville AL 35894-0001
Notice
Information in this document is subject to change without notice and should not be considered a commitment by Intergraph Computer
Systems. Intergraph Computer Systems shall not be liable for technical or editorial errors in, or omissions from, this document.
Intergraph Computer Systems shall not be liable for incidental or consequential damages resulting from the furnishing or use of this
document.
All warranties given by Intergraph Computer Systems about equipment or software are set forth in your purchase contract. Nothing
stated in, or implied by, this document or its contents shall be considered or deemed a modification or amendment of such warranties.
Trademarks
Intergraph Computer Systems and the Intergraph Computer Systems logo are registered trademarks of Intergraph Computer Systems.
ImageStation ZIII and TDZ are trademarks of Intergraph Corporation.
Other brands and product names are trademarks of their respective owners.

Contents
1 Introduction.......................................................................................................................... 1
2 Getting Started ..................................................................................................................... 2
Unpack the Equipment.............................................................................................................. 2
Gather the Tools........................................................................................................................ 2
3 Installing the Hardware.......................................................................................................3
Equipment Cautions .................................................................................................................. 3
Assemble the Cyborg Chair.......................................................................................................3
Assemble the Monitor Table ..................................................................................................... 4
Assemble the Digitizer Table....................................................................................................4
Install the Base Unit and Keyboard........................................................................................... 4
Install the Monitor..................................................................................................................... 4
Install the Interface PEM........................................................................................................... 5
Install the Stereoscopic Display Subsystem .............................................................................. 7
4 Completing the Installation ................................................................................................. 8
Maintain the Equipment............................................................................................................ 8
Activate the Stereoscopic Display............................................................................................. 9
Customize the Screen Tracking Area...................................................................................... 10
5 Troubleshooting the Installation....................................................................................... 11
Troubleshoot in Windows NT................................................................................................. 11
Troubleshoot in MS-DOS ....................................................................................................... 11
6 Installing the Altek Driver................................................................................................. 14
7 Adjusting System Ergonomics........................................................................................... 15
Adjust the Cyborg Chair.......................................................................................................... 15
Adjust the Digitizer Table....................................................................................................... 16
Adjust the Monitor Table ........................................................................................................16
Adjust the Monitor Position .................................................................................................... 16
Adjust the Keyboard Position.................................................................................................. 16
Adjust the Two-Handed Controller......................................................................................... 17
Adjust the Stereoscopic Glasses.............................................................................................. 17

1
1 Introduction
ImageStation ZIII is a softcopy production system that lets you view and process color
imagery. It features a D-sized digitizing surface and stereoscopic viewing using specially
designed glasses. The complete system consists of a TDZ workstation, KI furniture, and other
equipment. Separate documents help you set up the TDZ workstation and assemble the KI
workstation furniture.
This document describes how to install the hardware and software for an ImageStation ZIII
system. It describes how to adjust and troubleshoot the installation.
WARNING Only Intergraph Computer Systems field service personnel may perform the installation
procedures in this document.
CAUTION To successfully install the equipment, read all of the instructions carefully before proceeding
with the installation.
NOTE Cyborg chair, Interface PEM, AC Adapter, and stereoscopic glasses are not shown.
Monitor Table
D-sized Digitizer
Table Top
TDZ
Workstation
Base Unit
Two-Handed
Controller
Digitizer
Stand
Infrared Transmitter
PEM Bracket
(underside)
Monitor
Keyboard
Height
Adjustment
Handle and
Grommet

2
2 Getting Started
Follow the instructions in this section to prepare to install an ImageStation ZIII system.
Unpack the Equipment
Unpack all equipment from the shipping cartons. In addition to the TDZ workstation base
unit, a keyboard, and a 21-inch, 24-inch, or 28-inch monitor, verify you have the following:
u Monitor table (FFUR0530)
u Digitizer stand (FFUR0540), D-sized digitizer table top with an Altek digitizer controller
(CTIS1410), a 15-pin to 9-pin Analog to Digital Converter, three 9-pin RS-232 cables,
PEM bracket (CFAB806F), and Handle Grommet (CGEN534A)
u Wood screws (CPHW8760) for installing the PEM bracket
u Interface PEM (MESAN360)
u Two-Handed controller (MESAL150)
u Cyborg chair (FFUR0080)
u AC Adapter (CPWS1720)
Verify that you have the following components of the stereoscopic display subsystem.
u Stereoscopic glasses (CINF0110)
u Infrared transmitter (CINF0120)
u Stereo sync interface cable (MCBLV320)
If any of the listed items are missing or damaged, notify the Customer Response Center at
1-800-633-7248.
Gather the Tools
Gather the following tools to use when installing the system:
u Phillips screwdrivers, #2 (for PEM bracket assembly) and #3 (for furniture assembly)
u Flat-bladed screwdriver, 1/4-inch, common (for cable installation)
u Wrench, 1/2-inch, box-end or small adjustable (for table casters)

3
3 Installing the Hardware
You will set up the components of the ImageStation ZIII hardware in the following order:
1. Cyborg chair
2. Monitor table
3. D-sized digitizer table with Altek digitizer controller
4. TDZ workstation base unit and keyboard
5. Monitor
6. Interface peripheral equipment module (PEM), two-handed controller, and cabling
7. Stereoscopic display subsystem
To connect the power cords and set the switches, refer to Chapter 4. Chapter 6 includes
instructions to install and customize the Altek driver.
Equipment Cautions
WARNING Do not sit or lean on the digitizer table during or after assembly, or equipment damage
may result.
Note the following cautions when installing and using ImageStation ZIII hardware:
u The digitizer table work surface is a non-load bearing surface. Damage to sensitive parts
may occur if used for purposes other than intended.
u The stereoscopic glasses are fragile. Handle them carefully. When not in use, store the
glasses in the box they came in or another suitable container.
u Do not immerse the stereoscopic glasses in water or other liquids. Consult the documents
delivered with the glasses for more information on the care and cleaning of the glasses.
Assemble the Cyborg Chair
To assemble the Cyborg chair:
1. Remove the installation and assembly instructions from the packing box and review them.
2. Remove the Chair Base/Casters assembly from the packing box and place it on the floor
with the casters down.
3. Remove the Chair Seat/Arms assembly from the packing box.

4
4. Insert the Chair Seat/Arms assembly post into the center hole of the Chair Base/Casters
assembly. Apply firm, even pressure to seat the post into the Base/Caster assembly.
Assemble the Monitor Table
Remove the monitor table from the packing box. Refer to the documents delivered with the
KI workstation furniture for detailed instructions for assembling the monitor table.
Assemble the Digitizer Table
To assemble the digitizer table:
1. Remove the digitizer table top assembly and all packing materials from the packing box.
Place the table top assembly face down on a carpeted floor or on the packing materials.
2. Install the peripheral equipment module (PEM) bracket onto the underside of the digitizer
table top. Place the PEM bracket upside down with the open side of the PEM bracket
facing away from the table top. Install the four #5x 0.75-inch Phillips wood screws to
mount the bracket to the table top.
NOTE Position the angled side of the bracket toward the front of the digitizer table top.
3. Remove the digitizer stand from the packing box. Remove all packing materials and
place the digitizer stand on the digitizer table top.
4. Refer to the documents delivered with the KI workstation furniture for instructions for
securing the digitizer stand to the digitizer table top.
5. Turn the assembled digitizer table upright.
6. Push the handle grommet into the opening for the height adjustment handle, and then
install the handle.
Install the Base Unit and Keyboard
Remove the TDZ workstation base unit and keyboard from their packing boxes, and set up the
TDZ workstation hardware. Refer to the workstation’s documentation for setup instructions.
Install the Monitor
WARNING The monitor is extremely heavy and could cause serious personal injury if dropped.
Two persons are required to lift and mount the monitor into place.
Remove the monitor from the packing box and place it on the monitor table.

5
Install the Interface PEM
The interface PEM is the electronics interface for the two-handed controller and the digitizer
table.
To install the interface PEM:
1. Remove the interface PEM and its power cord from the packing box. Temporarily place
the interface PEM on top of the digitizer table in preparation for connecting the cables to
the PEM.
2. Refer to the following figure. Connect the three RS-232 cables between the interface
PEM, the Altek digitizer controller, and the TDZ workstation base unit as described in
this section.
RS-232 Cable
Altek Digitizer Controller
TDZ
Workstation
Base Unit
Power Cursor RS-232
Two-Handed Controller
with 25-pin Cable
Interface PEM
Tablet RS-232 RS-232 Cable
RS-232 Cable
COM 1
COM 2
HC Power
A to D Converter
To connect the cables:
1. Connect one end of an RS-232 cable to the port labeled RS-232 on the interface PEM.
Connect the other end of the cable to COM 2 port on the TDZ workstation base unit.
Tighten the cable screws.
2. Connect the 25-pin cable from the two-handed controller to the port labeled Hand
Controller (HC) on the interface PEM. Tighten the cable screws.
3. Connect one end of an RS-232 cable to the port labeled Tablet on the interface PEM.
Tighten the cable screws. The other end of this cable is attached in Step 5.

6
4. Slide the interface PEM into the PEM bracket mounted to the underside of the digitizer
table. Refer to the following figure.
PEM
Bracket
Interface PEM
NOTE Ensure that the cables extend to the back of the interface PEM. Verify that the front feet of the
interface PEM install into the holes provided in the PEM bracket. These holes provide a
positive lock-down to prevent unwanted movement of the interface PEM.
5. The Altek digitizer controller is pre-mounted on the underside of the table as shown in the
following figure. Connect the 15-pin to 9-pin Analog to Digital converter to the port
labeled Cursor on the Altek digitizer controller. Connect the other end of the RS-232
cable from Tablet of the Interface PEM (which you connected in step 3), to the 15-pin to
9-pin Analog to Digital converter. Tighten the cable screws.
15-pin to 9-pin
Analog to Digital
Converter AC Power Cord
Receptacle
To Two-Handed Controller
To COM 1
To AC
Adapter
Altek Digitizer
Controller Interface PEM
From Tablet of
Interface PEM
To COM 2

7
6. Connect one end of an RS-232 cable to the port labeled RS-232 on the Altek digitizer
controller. Connect the other end of the cable to COM 1 port on the TDZ workstation
base unit. Tighten the cable screws.
7. Connect the round DIN end of the cable from the AC adapter to the power cord
receptacle on the Altek digitizer controller.
8. Connect the interface PEM power cord to the AC power cord receptacle on the back of
the interface PEM.
Install the Stereoscopic Display Subsystem
The stereoscopic display subsystem lets you view three-dimensional computer generated
images. It consists of an infrared transmitter, a cable assembly, and stereoscopic glasses.
To install the stereoscopic display subsystem:
1. Place the infrared transmitter on top of the monitor and face the infrared disperser panel
towards the user. No special mounting is required.
2. Set the infrared transmitter switch to the High position.
3. Connect one end of the stereo sync interface cable to the 9-pin port on the infrared
transmitter. Connect the other end (round mini-DIN) to the stereo port of the graphics
board in the TDZ workstation base unit. Refer to the following figure.
4. Connect one end of the video cable to the monitor, and connect the other end to the Video
Out port on the graphics board. Refer to the following figure.
Infrared Transmitter
Monitor
Stereo
Port
Video In Port
(not used)
Video Cable
Video Out Port
of Workstation
Graphics Board
Stereo Sync
Interface Cable

8
4 Completing the Installation
You can adjust the monitor and digitizer tables and the Cyborg chair to meet the needs of the
individual user. Refer to Chapter 7 “Adjusting System Ergonomics” in this document.
Arrange the furniture with the monitor table centered behind and over the digitizer table.
Center the Cyborg chair in front of the digitizer table.
CAUTION Do not use auxiliary power outlets or extension cords when connecting to AC power.
To connect the remaining power cords:
1. Attach one end of the power cord to the monitor, and the other end to an AC power outlet.
2. Attach one end of the power cord to the TDZ workstation, and the other end to an AC
power outlet.
3. Attach the power cord from the Altek digitizer controller to an AC power outlet.
4. Connect the interface PEM power cord to an AC power outlet.
To verify the installation:
1. Place the interface PEM power switch in the ON ( | ) position.
CAUTION After installation, the 3-position interface PEM power switch should always remain in the ON
( | ) position.
2. Verify that the two-handed controller is on the active area of the digitizer table.
NOTE You should remove the two-handed controller from the digitizing surface when using the
system’s mouse. Otherwise, the cursor may snap back to the original location as defined by
the two-handed controller.
3. Verify the proper Altek digitizer controller connection to the workstation.
NOTE The system must be powered up with the two-handed controller on top of the active area
(center) of the digitizer table for proper operation.
4. Turn on power to the monitor, and then turn on power to the TDZ workstation base unit.
5. Verify that the green LED is lit on front of the interface PEM to ensure its power switch is
in the ON ( | ) position.
Maintain the Equipment
To maintain the equipment:
1. Each week, clean the bottom of the two-handed controller with a cloth or paper towel
dampened with a glass cleaning solution.

9
2. Periodically clean the table surface with a glass cleaning solution.
3. Clean the monitor screen as required with a glass cleaning solution.
Activate the Stereoscopic Display
Verify that the stereo sync interface cable connects properly to the stereo port on the graphics
board (in the TDZ workstation base unit). Then follow the instructions in this section to view
images displayed by a 3D software application running on the system.
To activate the stereoscopic display:
1. From the Windows NT Start menu, go to Settings/Control Panel/Display/Intergraph
Monitor (tab).
2. Select the type of monitor connected to the system. The choices of monitor types for
ImageStation ZIII are as follows:
− Intergraph 21sd115 (MDSP14709) is the 21-inch monitor
− Intergraph 24hd96 (MDSP15104) is the 24-inch monitor
− Intergraph 28hd96 (MDSP14305) is the 28-inch monitor
3. Select Apply.
4. Select Intergraph Settings (tab) and select the Advanced button.
5. Select Enable Stereo Display and set the Monitor Scan to Interlaced; then select OK.
6. Select Apply.
7. Select Settings (tab) and set the resolution to 1280 x 1024.
8. Select Test. After the test completes, select Apply.
9. Restart the system.
10. In the Display Properties dialog, select the Settings tab and set the appropriate monitor
resolution. The recommended settings are 1280 x 1024 for a 21-inch monitor and 1920 x
1080 for the 24-inch and 28-inch monitors.
11. Select Test. After the test completes, select Apply.
12. Exit from the Display Properties dialog.
To view images in 3D:
1. Activate the infrared glasses by opening the ear frames. The lenses turn black when they
are on and have a reddish-gold tint when they are off.
2. Put on the infrared glasses to view images in 3D.

10
When using the stereoscopic display subsystem, combat the effects of stress on your eyes by
periodically taking a break. Stand up, stretch, and look away at something distant to change
focal depth and to relax your eyes.
NOTE For information on battery installation in the infrared glasses, refer to the documents delivered
with the glasses.
Customize the Screen Tracking Area
Customizing defines a small rectangle on the digitizer’s surface to represent the entire screen
tracking area. The digitizer ships with the screen tracking area defined as the entire active
tracking area. This requires a user to move the two-handed controller across the entire length
of the digitizer’s active tracking area to move the on-screen pointer from one corner of the
screen to the other.
NOTE The active tracking area is the section of the digitizer in which the two-handed controller
operates. It is identified on the digitizer surface as a rectangular outline on the mylar cover.
To select on-screen icons with less effort than using the two-handed controller, you can
customize the screen tracking area.
To customize the screen tracking area:
1. From the Windows NT Start menu, go to Programs/Altek/Wintab Control Panel.
2. Double click the Customization icon.
3. Clear the Whole Tablet check box.
4. Place a data point in the grey rectangle of the Tracking Area menu.
5. Place a data point on the lower left corner of the desired tracking area in the digitizer
active tracking area.
6. Place a data point on the upper right corner of the desired tracking area in the digitizer
active tracking area.
7. Select OK to complete the operation.

11
5 Troubleshooting the Installation
This section provides information to troubleshoot the installation of the Altek hardware.
Troubleshoot in Windows NT
If the two-handed controller is not tracking in Windows NT, try the following.
u Verify cable connections.
u Turn the power to the interface PEM off, and then on.
u Disconnect and re-connect power to the Altek controller.
u Select Reset from the command strip at the upper left hand corner of the tablet.
u Reset memory to the default settings, as follows:
− Load the Altek Auxiliary menu by placing the auxiliary menu on the active area of
the digitizer.
− With any cursor button, select “Setup Menu” from the command strip.
− First, digitize the lower left corner and then the lower right corner of the Auxiliary
menu using any cursor button.
− Select Reset 1, Reset 2, Reset 3, and Reset 4 from the memory section of the
Auxiliary menu; then select Reset from the command strip.
u If the two-handed controller still does not track, try reinstalling the Altek driver.
Troubleshoot in MS-DOS
The diagnostic software product must be version 4.20 or later. Keyboard commands are case
sensitive. You can press the F1 function key at any time to obtain help on using the
commands. Refer to the AC32 Digitizer Controller User’s Manual and Technical Reference
for detailed explanation of the available functions.
To run the Altek diagnostic:
1. Ensure the boot sequence in the system BIOS is A, C. Refer to the hardware documents
delivered with the TDZ workstation base for instructions to change the boot sequence.
2. Insert an MS-DOS boot diskette in the system’s floppy disk drive.
3. Restart the system. When prompted for the date and time, press RETURN to accept the
default values.

12
4. Insert the diskette containing the Altek software utility programs in the system’s floppy
disk drive.
5. At the command prompt, key in cd terminal.
6. At the command prompt, key in terminal. Ignore the data stream that displays
continuously. This is normal.
To verify the two-handed controller buttons and X, Y data transmission:
1. Set terminal to com1, 9600, N, 8, 1, raw as shown on the screen menu, using the
following keyboard commands:
Press
ALT+Nsuccessively to select com1.
Press
ALT+Bsuccessively to select the proper baud rate (9600).
2. Set terminal to point mode by typing SHIFT+Pand then pressing ENTER. The continuous
data stream stops.
3. Verify the cable connections to the Altek digitizer controller by typing SHIFT+Tand then
pressing ENTER. The following displays:
X axis size = 93 wires
Y axis size = 63 wires
If the wire count is not displayed, then verify all cable connections to the Altek digitizer
controller.
4. Display digitizer data transmission by typing SHIFT+Fand 1, and then pressing ENTER.
Press any button on the two-handed controller, and the X and Y location data begins to
scroll. This indicates the button is transmitting data. Test all of the buttons by pressing
each one. The data format is of the form
F + xxxxx + yyyyy
where Fidentifies the button, and where xand yare numerical values.
5. Display data transmission in a continuous data stream by typingSHIFT+Sand 2, then
pressing ENTER. The data displays continuously.
To verify the force stick functionality:
1. Set terminal to com2, 9600, N, 8, 1, raw as shown on the screen menu using the
following keyboard commands:
Press
ALT+Nsuccessively to select com2.
Press
ALT+Bsuccessively to select the proper baud rate (9600).
2. Display version information by typing SHIFT+Vand pressing ENTER. The following
displays:
Intergraph Imaging Systems Stereo Cursor, Software version 1.2
PCBC080 ECO level 1

13
3. Activate the microprocessor to decode the force stick data by pressing CTRL+Q. Verify
force stick operation by moving the force sticks to watch the numbers change. This
indicates the force sticks are transmitting data. The data format is of the form
H:AA X:nnn nnn Y:nnn nnn
where nis a numerical value.
The Altek digitizer controller provides you with significant capabilities for customization. It
is relatively easy to disable the Altek digitizer controller from the terminal program. Refer to
the AC32 Digitizer Controller User’s Manual and Technical Reference for information on
resetting memory to the factory settings using lowercasew1, w2, w3, w4 terminal commands.
CAUTION If resetting the digitizer to the factory settings, be careful not to use uppercase W1, W2, W3,
W4 terminal commands.
NOTE You can also reset the Altek digitizer controller to the factory settings by loading the Altek
Auxiliary Menu and selecting the Reset 1-4 commands as described in “Troubleshoot in
Windows NT.”
If only one COM port is functional, first verify proper cable connections. Second, try
swapping the RS-232 COM port cables (replace the COM 1 cable with the COM 2 cable). If
this changes which COM port is functional, replace the cable. Third, try replacing the two-
handed controller or the interface PEM.
If neither COM port is functional, verify the ribbon cable connections between the digitizer
and the Altek digitizer controller. If both COM ports still do not function, consider replacing
the digitizer and the Altek digitizer controller.
If the two-handed controller fails to operate in the Windows NT environment, and the two-
handed controller is verified -- buttons, force sticks, and X, Y data transmission -- in the
terminal program, then the problem is not the digitizer. Try the following:
1. Activate the two-handed controller in the Windows NT environment by selecting Reset
from the Altek command menu at the upper left corner of the digitizer.
2. Disconnect and reconnect the Altek digitizer controller power cord and toggle the
interface PEM power switch.
3. Reinstall the Altek driver.

14
6 Installing the Altek Driver
The Altek driver software controls the operation of the Altek digitizer. This section describes
how to install and customize the Altek driver software.
To install the Altek driver:
1. Start the TDZ workstation base unit and monitor, and log on to Windows NT.
2. Insert the diskette containing the Altek driver in the system’s floppy disk drive.
3. From the Windows NT Start menu, select Run.
4. Key in the path to the Install program on the diskette (typically a:\install.bat).
5. Select Continue to install the Wintab driver.
6. Set the device size to be 24-inch x 36-inch.
7. Select Continue to accept the settings.
8. Select Yes to confirm the installation, and then select OK after successful installation.
The following appears:
Intergraph hardware requires a tablet size of 34 inches by 22
inches. The necessary changes will be made to the registry now.
9. Select OK to accept the changes.
10. Select OK and then restart the system.
11. Proceed with customizing the Altek driver.
To customize the Altek driver:
1. From the Windows NT Start menu, go to Programs/Altek/Wintab Control Panel.
2. Under Features/Cursor Type, select 16-button cursor; then select OK.
3. Under Customization, de-select the default button assignments. Set button 7 to left click.
Set button 8 to right click. Set all other buttons to none; then select OK.
NOTE Button 7 corresponds to the index finger of the right hand resting on the two-handed
controller. The buttons range from 1 on the far left (not counting the force sticks) to 10 on the
far right.
If this is a first-time setup, activate the stereoscopic display and customize the screen tracking
area as described in previous sections of this document.

15
7 Adjusting System Ergonomics
This section provides human factors (ergonomic) recommendations you should follow when
setting up and using the ImageStation ZIII system. Perform the following steps in the order
presented.
Adjust the Cyborg Chair
Use the reference material provided with the Cyborg chair to make the following adjustments.
To adjust the chair:
1. Adjust the seat height so that your feet are flat on the floor and your knees are bent
approximately 90 degrees.
NOTE If needed, use a footrest to allow feet to rest on a flat surface. Do not use the table as a
footrest.
CAUTION The digitizer table work surface is a non-load bearing surface. Damage to sensitive parts,
mechanical damage, or operator injury may occur if used for purposes other than intended.
2. Adjust the seat to distribute the weight of the upper body comfortably over the seat. The
seat should be nearly level.
3. Adjust the height and angle of the backrest to maintain contact with the lumbar area of the
back when you are sitting in a normal working posture.
4. Adjust the height of the armrests to support the arms when your shoulders are relaxed and
your upper arms are at your side.

16
Adjust the Digitizer Table
Adjust the height of the digitizer table so that your arms are comfortably at your side when
using the two-handed controller or keyboard.
Your elbows should be bent at approximately 90 degrees when your hands are resting on the
two-handed controller or at the keyboard. If the table is at the lowest setting, you may need to
raise the chair height to place your hands at a proper height. A footrest may be required if
your feet do not rest flat on the floor.
To adjust the digitizer table:
1. Move the digitizer table out from under the monitor table when using the entire digitizing
area.
2. Lock the casters on the digitizer table to prevent it from moving unintentionally.
Adjust the Monitor Table
The monitor table should be centered along the back edge of the digitizer table so that the
monitor screen will be directly in front of you.
Adjust the height of the monitor table so that the center of the monitor screen is slightly below
eye level.
Adjust the Monitor Position
The monitor should be placed on the monitor table. The monitor base should be centered on
the table top to evenly distribute the weight of the monitor on the table. This position allows
enough room for the placement of the keyboard in front of the monitor, if desired.
NOTE Avoid placing the monitor so that it reflects glare from room lights.
Adjust the Keyboard Position
The keyboard can be placed in any position on the digitizer table, or on the front of the
monitor table, according to your preference.
To use the keyboard:
1. For periods of infrequent keyboard input, place the keyboard on the front edge of the
monitor table in front of the monitor.
