Intel D865GBF User manual

C24486-002
Intel®Desktop Board
D865GBF/D865GLC
Quick Reference
This guide is written for technically qualified personnel with experience
installing and configuring desktop boards.
Before You Begin
Warning and Cautions........................................................................ 3
Safety and Regulatory Notice ............................................................ 3
Desktop Board Components ...................................................... 4
Supported Components
Processors .......................................................................................... 6
Memory Module Requirements.......................................................... 6
Installation Steps
1. Installing the I/O Shield............................................................ 7
2. Installing the Desktop Board..................................................... 8
3. Installing the Processor ............................................................. 9
4. Installing Memory Modules...................................................... 9
5. Installing an AGP Card........................................................... 11
6. Attaching IDE Drives ............................................................. 12
7. Attaching Serial ATA (SATA) Drives.................................... 13
8. Connecting Internal Headers................................................... 14
9. Connecting Hardware Control Cables..................................... 15
10. Connecting Power Cables ....................................................... 15
Using the BIOS Setup Program............................................... 16
Setting the BIOS Configuration Jumper Block............... 16
Troubleshooting .............................................................................. 17
Customer Support Links............................................................. 18
Items on the Intel®Express Installer CD-ROM
• Product warranty
• Intel Express Installer
• Intel®Desktop Board D865GBF/D865GLC Product Guide
• Software utilities and drivers
• Software license agreement
• Readme file
Part Number: C24486-002

2 Intel Desktop Board D865GBF/D865GLC Quick Reference
INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH
INTEL®PRODUCTS. NO LICENSE, EXPRESS OR IMPLIED, BY ESTOPPEL
OR OTHERWISE, TO ANY INTELLECTUAL PROPERTY RIGHTS IS GRANTED
BY THIS DOCUMENT. EXCEPT AS PROVIDED IN INTEL’S TERMS AND
CONDITIONS OF SALE FOR SUCH PRODUCTS, INTEL ASSUMES NO
LIABILITY WHATSOEVER, AND INTEL DISCLAIMS ANY EXPRESS OR
IMPLIED WARRANTY, RELATING TO SALE AND/OR USE OF INTEL
PRODUCTS INCLUDING LIABILITY OR WARRANTIES RELATING TO
FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY, OR
INFRINGEMENT OF ANY PATENT, COPYRIGHT OR OTHER INTELLECTUAL
PROPERTY RIGHT. INTEL PRODUCTS ARE NOT INTENDED FOR USE IN
MEDICAL, LIFE SAVING, OR LIFE SUSTAINING APPLICATIONS. INTEL MAY
MAKE CHANGES TO SPECIFICATIONS AND PRODUCT DESCRIPTIONS AT
ANY TIME, WITHOUT NOTICE.
Intel®Desktop Board D865GBF/D865GLC may contain design defects or errors
known as errata which may cause the product to deviate from published
specifications. Current characterized errata are available on request.
Contact your local Intel sales office or your distributor to obtain the latest
specifications and before placing your product order.
Copies of documents which have an ordering number and are referenced in this
document, or other Intel literature, may be obtained from Intel Corporation by
going to the World Wide Web site at: http://www.intel.com or by calling
1-800-548-4725.
Intel, Pentium and Celeron are trademarks or registered trademarks of Intel
Corporation or its subsidiaries in the United States and other countries.
*Other names and brands may be claimed as the property of others.
Copyright © 2003, Intel Corporation

Intel Desktop Board D865GBF/D865GLC Quick Reference 3
Before You Begin
Warning and Cautions
WARNING
Disconnect the desktop board’s power supply from its AC power
source before you connect or disconnect cables, or install or remove
any board components. Failure to do this can result in personal
injury or equipment damage. Some circuitry on the desktop board
can continue to operate even though the front panel power switch is
off.
CAUTION
Electrostatic discharge (ESD) can damage desktop board components.
Install the board at an ESD-controlled workstation. If such a workstation
is not available, wear an antistatic wrist strap or touch the surface of the
antistatic package before handling the board.
CAUTION
Many of the midboard and front panel connectors provide operating
voltage (+5 V DC and +12 V DC, for example) to devices inside the
computer chassis, such as fans and internal peripherals. These
connectors are not overcurrent protected. Do not use these connectors
for powering devices external to the computer chassis. A fault in the load
presented by the external devices could cause damage to the computer,
the interconnecting cables, and the external devices themselves.
Safety and Regulatory Notice
See the Intel®Desktop Board D865GBF/D865GLC Product Guide for all
applicable regulatory compliance statements, product certification markings, and
safety and electromagnetic compatibility (EMC) standards and regulations the
desktop board is compliant with.
Replacement battery warning label provided:Place the label inside the chassis
in an easy-to-see location near the battery but not on the board itself.
Intended uses: This product was evaluated as information technology
equipment (ITE) for home or office use when installed into an appropriate
computer chassis. Other end uses or locations may require further evaluation.

4 Intel Desktop Board D865GBF/D865GLC Quick Reference
Desktop Board Components
ABE
F
H
G
I
K
L
M
N
O
P
Q
U
D
W
X
OM15242
J
S
C
13
Reset
HD LED
Power LED
No Connection
2
1
USB 2.0
Devices
Line
In
USB 2.0
Devices
V
R
TDIMM 1
DIMM 0
Channel B
Channel A
DIMM 0
DIMM 1
On
/Off
Power LED
Figure 1. Desktop Board Components
continued
NOTE
Refer to the “Connecting Internal Headers” heading on page 14 for
pin-outs.

Intel Desktop Board D865GBF/D865GLC Quick Reference 5
Desktop Board Components (continued)
Label Description
A CD-ROM connector (ATAPI-style)
B Front panel audio connector
C Auxiliary line-in connector (ATAPI-style)
D AGP connector
E Rear chassis fan header
F 12 V processor core voltage connector
G Processor socket
H Processor fan header
I Intel®82865G (GMCH)
J DIMM sockets
K Main power connector
L Diskette drive connector
M Primary IDE connector
N Secondary IDE connector
O Front chassis fan header
P Chassis intrusion header
Q Speaker
R BIOS configuration jumper block
S Front panel USB 2.0 header
T Serial ATA connectors
U Intel®82801EB (ICH5)
V Front panel USB 2.0 header
W Battery
X PCI bus add-in card connectors
NOTE
The number of PCI connectors on your board may differ from those in the
illustrations. Desktop Board D865GBF has six and Desktop Board
D865GLC has three PCI connectors.

6 Intel Desktop Board D865GBF/D865GLC Quick Reference
Supported Components
Processors
The board supports a single processor with the following features:
Type
Designation
(GHz)
FSB1Frequency
(MHz)
L2 Cache
(KB)
3, 2.80C, 2.60C, and
2.40C
800 512Intel®Pentium®4
processor supporting
Hyper-Threading
Technology 3.06 533 512
2.8, 2.66, 2.53, 2.4B,
and 2.26
533 512Intel Pentium 4
processor
2.6, 2.5, 2.4, 2.2, 2A,
1.80A, and 1.60A
400 512
Intel®Celeron®
processor
2.2, 2.1, and 2.0 400 128
1Front side bus
For the latest information on processors supported by Desktop Board
D865GBF/D865GLC, refer to the Intel World Wide Web site at:
http://support.intel.com/support/motherboards/desktop
Memory Module Requirements
The desktop board supports system memory as defined below:
Memory
Speed Processor
Front Side Bus
Frequency
Memory Speed
Outcome
DDR400 Pentium 4 processor 800 MHz 400 MHz
Pentium 4 processor 800 MHz 320 MHz
Pentium 4 processor 533 MHz 333 MHz
DDR333
Pentium 4 processor or
Celeron processor
400 MHz 266 MHz
Pentium 4 processor 533 MHz or
400 MHz
266 MHzDDR266
Celeron processor 400 MHz 266 MHz

Intel Desktop Board D865GBF/D865GLC Quick Reference 7
• Up to four 184-pin Double Data Rate (DDR) SDRAM Dual Inline Memory
Module (DIMM) connectors with gold-plated contacts.
• Support for:
 Unbuffered, non-registered single or double-sided DIMMs
 Serial Presence Detect (SPD) memory only
 Support for Suspend to RAM (STR), S3 ACPI state
 Non-ECC RAM
 2.5 V memory
NOTES
System Resources (such as PCI and AGP) require physical memory
address locations that reduce available memory addresses above 3 GB.
This may result in less than 4 GB of memory being available to the
operating system and applications.
All memory components and DIMMs used with the desktop board must
comply with the PC SDRAM specifications. These include the PC
SDRAM Specification (memory component specific) and the PC
Unbuffered DIMM Specification. To view or download these
specifications, refer to this Intel World Wide Web site:
http://developer.intel.com/technology/memory/pcsdram/spec/
For information about vendors that support these memory requirements,
refer to the Desktop Board D865GBF/D865GLC link on this Intel World
Wide Web site:
http://support.intel.com/support/motherboards/desktop/
Installation Steps
1. Installing the I/O Shield
The board comes with an I/O shield that is used to block radio frequency
transmissions, necessary to pass emissions (EMI) certification testing, protect
internal components from dust and foreign objects, and promote correct airflow
within the chassis.

8 Intel Desktop Board D865GBF/D865GLC Quick Reference
Install the I/O shield before installing the board in the chassis. Place the shield
inside the chassis as shown Figure 2. Press the shield into place so that it fits
tightly and securely. If the shield doesn’t fit, obtain a properly sized shield from
the chassis supplier.
OM12116
Figure 2. I/O Shield
2. Installing the Desktop Board
Refer to your chassis manual for specific instructions on installing and removing
the desktop board.
Secure Desktop Board D865GLC to the chassis using eight screws. Secure
Desktop Board D865GBF to the chassis using 11 screws. Refer to the board
illustration on page 4 for the location of the mounting screw holes.

Intel Desktop Board D865GBF/D865GLC Quick Reference 9
3. Installing the Processor
To install the processor, follow these steps (see Figure 3):
1. Observe the precautions in “Before You Begin”on page 3.
2. Lift the processor socket lever.
3. Install the processor so that the corner with the triangle marking (A) is
aligned with the corner where the lever is attached to the socket.
4. Lower the lever back to its original position.
OM12078
mPGA478B
mPGA478B
mPGA478B
A
Figure 3. Installing the Processor
5. The desktop board has an integrated processor fan heat sink retention
mechanism (RM). For instructions on how to install the processor fan heat
sink, refer to the boxed processor manual or the Intel World Wide Web
site at:
http://support.intel.com/support/processors/pentium4/intnotes478.htm
4. Installing Memory Modules
CAUTION
Install memory in the DIMM sockets prior to installing the AGP video card
to avoid interference with the memory retention mechanism.
Desktop Board D865GBF/D865GLC’s four DIMM sockets are arranged as
DIMM 0 and DIMM 1 in both Channel A and Channel B, as shown in Figure 4.
Dual Channel Configuration
Install a matched pair of DIMMs (equal in speed: DDR266, DDR333, or
DDR400; density: 64 MB, 128 MB, 256 MB, 512 MB, or 1 GB; and
technology: 128 Mb, 256 Mb, or 512 Mb) in DIMM 0 in both Channels A and B.
If additional memory is to be used, install another matched pair of DIMMs in
DIMM 1 in both Channels A and B.
NOTE
All other memory configurations will result in single channel memory
operation.

10 Intel Desktop Board D865GBF/D865GLC Quick Reference
To install DIMMs, follow these steps:
1. Observe the precautions in “Before You Begin”on page 3.
2. Remove the AGP video card if it interferes with the DIMM clips from
being easily opened and closed.
3. Align the small notch at the bottom edge of the DIMM with the key in the
socket.
4. Insert the bottom edge of the DIMM into the socket.
5. Push down on the top edge of the DIMM until the retaining clips snap into
place. Make sure the clips are firmly in place.
OM15245
DIMM 1
DIMM 0
Channel B
Channel A
DIMM 0
DIMM 1
Figure 4. Installing DIMMs
