Intel®Desktop Board
D925XCV
Specification Update
Release Date: March 2005
Order Number: C80897-006
The Intel®Desktop Board D925XCV may contain design defects or errors known as errata, which
may cause the product to deviate from published specifications. Current characterized errata are
documented in this Specification Update.

INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL®PRODUCTS. NO LICENSE,
EXPRESS OR IMPLIED, BY ESTOPPEL OR OTHERWISE, TO ANY INTELLECTUAL PROPERTY RIGHTS IS GRANTED
BY THIS DOCUMENT. EXCEPT AS PROVIDED IN INTEL’S TERMS AND CONDITIONS OF SALE FOR SUCH PRODUCTS,
INTEL ASSUMES NO LIABILITY WHATSOEVER, AND INTEL DISCLAIMS ANY EXPRESS OR IMPLIED WARRANTY,
RELATING TO SALE AND/OR USE OF INTEL PRODUCTS INCLUDING LIABILITY OR WARRANTIES RELATING TO
FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY, OR INFRINGEMENT OF ANY PATENT, COPYRIGHT OR
OTHER INTELLECTUAL PROPERTY RIGHT. INTEL PRODUCTS ARE NOT INTENDED FOR USE IN MEDICAL, LIFE
SAVING, LIFE SUSTAINING APPLICATIONS.
Intel may make changes to specifications and product descriptions at any time, without notice.
Designers must not rely on the absence or characteristics of any features or instructions marked “reserved” or “undefined”.
Intel reserves these for future definition and shall have no responsibility whatsoever for conflicts or incompatibilities arising from
future changes to them.
The Intel®desktop board D925XCV may contain design defects or errors known as errata which may cause the product to
deviate from published specifications. Current characterized errata are available on request.
Contact your local Intel sales office or your distributor to obtain the latest specifications before placing your product order.
Copies of documents which have an ordering number and are referenced in this document, or other Intel literature, may be
obtained from:
Intel Corporation
P.O. Box 5937
Denver, CO 80217-9808
or call in North America 1-800-548-4725, Europe 44-0-1793-431-155, France 44-0-1793-421-777,
Germany 44-0-1793-421-333, other Countries 708-296-9333
Intel, Pentium, Celeron, and the Intel logo are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the
United States and other countries.
* Other names and brands may be claimed as the property of others.
Copyright ©2004, 2005 Intel Corporation.

CONTENTS
REVISION HISTORY ................................................................................................................................... v
PREFACE................................................................................................................................................... vi
Specification Update for the Intel®Desktop Board D925XCV
GENERAL INFORMATION .......................................................................................................................... 3
ERRATA ......................................................................................................................................................5
DOCUMENTATION CHANGES ................................................................................................................... 6

Intel®Desktop Board D925XCV Specification Update
v
REVISION HISTORY
Date of Revision Version Description
July 2004 -001 This document is the first Specification Update for the
Intel®Desktop Board D925XCV.
September 2004 -002 Added Documentation Change 1.
October 2004 -003 Added Erratum 1. Added Documentation Change 2.
December 2004 -004 Removed Documentation Changes and incorporated them into
revision -002 of the Technical Product Specification.
February 2005 -005 Added Erratum 2.
March 2005 -006 Added Erratum 3.

Intel®Desktop Board D925XCV Specification Update
v
i
PREFACE
This document is an update to the specifications contained in the Intel
®
Desktop Board D925XCV Technical
Product Specification
(Order number C68597). It is intended for hardware system manufacturers and
software developers of applications, operating systems, or tools. It will contain Specification Changes, Errata,
Specification Clarifications, and Documentation Changes.
Refer to the
Intel
®
Pentium
®
4 Processor Specification Update (Order number 249199) for specification
updates concerning the Intel Pentium 4 processor and that may apply to the desktop board D925XCV.
Unless otherwise noted in this document, it should be assumed that any processor errata for a given stepping
are applicable to the Altered Assembly (AA) revision(s) associated with that stepping.
Refer to the
Intel
®
925X Chipset Specification Update (Order Number 301465) for specification updates
concerning the 82925X MCH Controller and that may apply to the desktop board D925XCV. Unless
otherwise noted in this document, it should be assumed that any MCH errata for a given stepping are
applicable to the Altered Assembly (AA) revision(s) associated with that stepping.
Refer to the
Intel
®
IO Controller Hub 6 (ICH6) Family Specification Update (Order Number 301474) for
specification updates concerning the 82801ER I/O Controller Hub and that may apply to the desktop board
D925XCV. Unless otherwise noted in this document, it should be assumed that any ICH 6 errata for a given
stepping are applicable to the Altered Assembly (AA) revision(s) associated with that stepping.
Nomenclature
Specification Changes are modifications to the current published specifications. These changes will be
incorporated in the next release of the specifications.
Errata are design defects or errors. Characterized errata may cause the desktop board D925XCV’s behavior
to deviate from published specifications. Hardware and software designed to be used with any given Altered
Assembly (AA) and BIOS revision level must assume that all errata documented for that AA and BIOS
revision level are present on all desktop boards.
Specification Clarifications describe a specification in greater detail or further highlight a specification’s
impact to a complex design situation. These clarifications will be incorporated in the next release of the
specifications.
Documentation Changes include typos, errors, or omissions from the current published specifications.
These changes will be incorporated in the next release of the specifications.

Specification Update for the
Intel®Desktop Board D925XCV

Intel®Desktop Board D925XCV Specification Update
3
GENERAL INFORMATION
Basic Desktop Board D925XCV Identification Information
AA Revision BIOS Revision Notes
C57587-401 CV92510A.86A.0193 1-5
C57587-402 CV92510A.86A.0193 1-5
C57587-403 CV92510A.86A.0210 1-5
C57587-404 CV92510A.86A.0249 1-5
C67680-401 CV92510A.86A.0183 1-5
C67680-402 CV92510A.86A.0193 1-5
C67680-403 CV92510A.86A.0210 1-5
C67680-404 CV92510A.86A.0249 1-5
NOTES:
1. The AA number is found on a small label on the component side of the board.
2. The 82925X Chipset kit used on this AA revision consists of two components as follows:
Device Stepping S-Spec Numbers
82925X MCH B1
B2
SL7LZ
SL7RC
82801FR ICH6 B1 SL79N
3. Refer to the Intel
®
Pentium
®
4 Processor Specification Update (Order Number 249199) for errata related to the Pentium 4
processor and that may apply to the desktop board D925XCV.
4. Refer to the
Intel
®
925X Chipset Specification Update (Order Number 301465) for errata related to the 82925X MCH that
may apply to the desktop board D925XCV.
5. Refer to the
Intel
®
IO Controller Hub 6 (ICH6) Family Specification Update (Order Number 301474) for errata related
to the 82801FB I/O Controller Hub that may apply to the desktop board D925XCV.

Intel®Desktop Board D925XCV Specification Update
4
Summary Table of Changes
The following table indicates the Specification Changes, Errata, Specification Clarifications, or Documentation
Changes that apply to the Intel®Desktop Board D925XCV. Intel intends to fix some of the errata in a future
revision of the desktop board, and to account for the other outstanding issues through documentation or
specification changes as noted. This table uses the following notations:
CODES USED IN SUMMARY TABLE
Doc: Document change or update that will be implemented.
PlanFix: This erratum may be fixed in a future revision of the desktop board, driver, or
BIOS.
Fixed: This erratum has been previously fixed.
NoFix: There are no plans to fix this erratum.
Shaded: This erratum is either new or modified from the previous version of the document.
NO. PLANS ERRATA
1 Plan Fix Alert Standard Format (ASF) is non-functional
2 Plan Fix BIOS corruption may occur if power is interrupted during the BIOS flash procedure,
resulting in the system’s inability to POST
3 Plan Fix Wake On LAN may not function after loss and restore of AC power
NO. PLANS DOCUMENTATION CHANGES
3 Doc All previous Documentation Changes incorporated

Intel®Desktop Board D925XCV Specification Update
5
ERRATA
1. Alert Standard Format (ASF) is Non-Functional
PROBLEM:BIOS and device driver support is currently not implemented to support Alert Standard Format
(ASF).
IMPLICATION:ASF, an interface that provides access and manageability in OS-absent environments, is
currently not supported.
WORKAROUND:None.
STATUS:This erratum may be fixed in a future BIOS and driver revision.
2. BIOS Corruption May Occur if Power is Interrupted During the
BIOS Flash Procedure, Resulting in the System’s Inability to POST
PROBLEM:Power interruption during BIOS flash process may corrupt certain non-bootblock areas in the
Firmware Hub.
IMPLICATION:If power fails during the flash process, the new BIOS image should be preserved. In some
instances, a power failure during the flash process may instead cause corruption and not save the new image
to the Firmware Hub resulting in a no POST condition; a POST card will indicate a halt at POST code D7h.
WORKAROUND:If power fails during the BIOS flash process and a no POST condition exists upon
subsequent boot, implementing the BIOS flash recovery procedure will return the BIOS to a stable state.
STATUS:This erratum may be fixed in a future BIOS revision.
3. Wake On LAN May Not Function After Loss and Restore of AC
Power
PROBLEM:If AC power is removed, Wake On LAN may not function until the LAN circuit is re-initialized.
The sequence of events is as follows:
• AC power removed (AC power cord disconnected, for example)
• AC power restored. +5V Standby voltage is re-applied to the board
• Wake On LAN may not be functional
• Switch power on
• Switch power off to put system back into Standby mode (S5 state)
• Wake On LAN functionality restored
IMPLICATION:Wake on LAN will not function if AC power is interrupted.
WORKAROUND:In the BIOS Setup program, set After Power Failure to “Power On” in the Power Menu.
STATUS:This erratum may be fixed in a future BIOS revision.

Intel®Desktop Board D925XCV Specification Update
6
DOCUMENTATION CHANGES
The Documentation Changes listed in this section apply to the Intel
®
Desktop Board D925XCV Technical
Product Specification
(Order Number C68597). All Documentation Changes will be incorporated into a future
version of that specification.
1. All previous Documentation Changes incorporated
The Documentation Changes listed in previous versions of this document have been incorporated into a
revision of the
Intel
®
Desktop Board D925XCV Technical Product Specification (Order number C68597).
