Intel® Desktop Board
DX58OG
Specification Update
April 2011
Part Number: G22442-002
The Intel®Desktop Board DX58OG may contain design defects or errors known as errata, which may cause the product to deviate
from published specifications. Current characterized errata are documented in this Specification Update.

2 Intel Desktop Board DX58OG Specification Update
Revision History
Revision Revision History Date
-001 This document is the first Specification Update for the Intel®Desktop
Board DX58OG November 2010
-002 Update to the General Information Section April 2011
INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL®PRODUCTS. NO LICENSE,
EXPRESS OR IMPLIED, BY ESTOPPEL OR OTHERWISE, TO ANY INTELLECTUAL PROPERTY RIGHTS IS
GRANTED BY THIS DOCUMENT. EXCEPT AS PROVIDED IN INTEL’S TERMS AND CONDITIONS OF SALE FOR
SUCH PRODUCTS, INTEL ASSUMES NO LIABILITY WHATSOEVER, AND INTEL DISCLAIMS ANY EXPRESS OR
IMPLIED WARRANTY, RELATING TO SALE AND/OR USE OF INTEL PRODUCTS INCLUDING LIABILITY OR
WARRANTIES RELATING TO FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY, OR INFRINGEMENT
OF ANY PATENT, COPYRIGHT OR OTHER INTELLECTUAL PROPERTY RIGHT. INTEL PRODUCTS ARE NOT
INTENDED FOR USE IN MEDICAL, LIFE SAVING, LIFE SUSTAINING APPLICATIONS.
Intel may make changes to specifications and product descriptions at any time, without notice.
Designers must not rely on the absence or characteristics of any features or instructions marked “reserved”
or “undefined”. Intel reserves these for future definition and shall have no responsibility whatsoever for
conflicts or incompatibilities arising from future changes to them.
The Intel®Desktop Board DX58OG may contain design defects or errors known as errata which may cause
the product to deviate from published specifications. Current characterized errata are available on request.
Contact your local Intel sales office or your distributor to obtain the latest specifications before placing your
product order.
Intel, the Intel logo, and Intel Core are trademarks of Intel Corporation in the U.S. and other countries.
* Other names and brands may be claimed as the property of others.
Copyright ©2010, 2011 Intel Corporation.

Intel Desktop Board DX58OG Specification Update 3
Contents
Specification Update for the Intel®Desktop Board DX58OG
Terminology ............................................................................................ 5
General Information .................................................................................5
Summary of Changes ............................................................................... 6

4 Intel Desktop Board DX58OG Specification Update
Specification Update for the
Intel®Desktop Board DX58OG
This document is an update to the specifications contained in the Intel®Desktop Board
DX58OG Technical Product Specification (Order Number: G13833). It is intended for
hardware system manufacturers and software developers of applications, operating
systems, or tools. It will contain Specification Changes, Errata, Specification
Clarifications, and Documentation Changes.
For specification updates concerning the Intel processor that may apply to this desktop
board, refer to the Intel®Core™ i7 Processor Extreme Edition Series and Intel®Core™
i7 Processor Specification Update (Order Number: 320836)
Unless otherwise noted in this document, it should be assumed that any processor
errata for a given stepping are applicable to the Altered Assembly (AA) revision(s)
associated with that stepping.
Refer to the Intel®X58 Express Chipset Specification Update (Order Number: 320839)
for specification updates concerning the X58 IOH Controller and that may apply to the
desktop board DX58OG. Unless otherwise noted in this document, it should be
assumed that any IOH errata for a given stepping are applicable to the Altered
Assembly (AA) revision(s) associated with that stepping.
Refer to the Intel®I/O Controller Hub 10 (ICH10) Family Specification Update (Order
Number: 319974) for specification updates concerning the 82801GB ICH10 and
82801GR ICH10R I/O Controller Hub and that may apply to the desktop board. Unless
otherwise noted in this document, it should be assumed that any ICH 10 errata for a
given stepping are applicable to the Altered Assembly (AA) revision(s) associated with
that stepping.

Intel Desktop Board DX58OG Specification Update 5
Terminology
Specification Changes are modifications to the current published specifications.
These changes will be incorporated in the next release of the specifications.
Errata are design defects or errors. Characterized errata may cause the desktop
board behavior to deviate from published specifications. Hardware and software
designed to be used with any given Altered Assembly (AA) and BIOS revision level
must assume that all errata documented for that AA and BIOS revision level are
present on all desktop boards.
Specification Clarifications describe a specification in greater detail or further
highlight a specification’s impact to a complex design situation. These clarifications
will be incorporated in the next release of the specifications.
Documentation Changes include typos, errors, or omissions from the current
published specifications. These changes will be incorporated in the next release of the
specifications.
General Information
Basic Desktop Board DX58OG Identification Information
AA Revision BIOS Revision Notes
G10926-203 SOX5820J.86A Initial Production
Notes:
1. The AA number is found on a small label on the component side of the board.
2. The X58 Chipset kit used on this AA revision consists of two components as follows:
Device Stepping S-Spec Numbers

6 Intel Desktop Board DX58OG Specification Update
Summary of Changes
The following table indicates the Specification Changes, Errata, Specification
Clarifications, or Documentation Changes that apply to the Intel®Desktop Board
DX58OG. Intel intends to fix some of the errata in a future revision of the desktop
board, and to account for the other outstanding issues through documentation or
specification changes as noted.
The following notations are used in the table:
Doc: Document change or update that will be implemented.
PlanFix: This erratum may be fixed in a future revision of the desktop board, driver, or BIOS.
Fixed: This erratum has been previously fixed.
NoFix: There are no plans to fix this erratum.
Shaded: This erratum is either new or modified from the previous version of the document.
No. Plans Errata
There is no characterized erratum for this product
