Intel KEMX-2030 User manual

I
KEM
X
-
2030
User’s Manua
l
KEMX-2030
Industrial Motherboard in Mini-ITX form factor
with Intel® Atom N270
User’s Guide

II
KEM
X
-
2030
User’s Manua
l
Contact Info: Quanmax Inc.
4F, No. 415, Ti-Ding Blvd. Sec. 2NeiHu District,
Taipei 114Taiwan
Tel: [phone]
Fax: [phone]
Visit our site at: www.quanmax.com
© 2008 Quanmax Inc. All rights reserved.
The information in this user’s guide is provided for reference only. Quanmax does not assume any
liability arising out of the application or use of the information or products described herein. This user’s
guide may contain or reference information and products protected by copyrights or patents and does
not convey any license under the patent rights of Quanmax, nor the rights of others.
Quanmax is a registered trademark of Quanmax. All trademarks, registered trademarks, and trade
names used in this user’s guide are the property of their respective owners. All rights reserved. This
user’s guide contains information proprietary to Quanmax. Customers may reprint and use this user’s
guide in other publications. Customers may alter this user’s guide and publish it only after they remove
the Quanmax name, cover, and logo.
Quanmax reserves the right to make changes without notice in product or component design as
warranted by evolution in user needs or progress in engineering or manufacturing technology.
Changes which affect the operation of the unit will be documented in the next revision of this user’s
guide.
Revision Date Edited by Changes
1.0 12/31/2008 SLee Initial Release
1.01 2/16/2009 SLee Add LPT
1.02 4/06/2009 SLee Add I/O Shield in packing list
1.03 7/27/2009 SLee Add COM1 RS422/485 pin out
1.04 12/16/2009 SLee Correct RS232/422/485 pin
assignment

Content
3
KEM
X
-
2030
User’s Manua
l
Content
Content....................................................................................................................... 3
Figures ....................................................................................................................... 5
Tables......................................................................................................................... 6
Safety Instructions...................................................................................................... 8
Before You Begin...................................................................................... 8
When Working Inside a Computer............................................................ 8
Preventing Electrostatic Discharge........................................................... 9
Preface..................................................................................................................... 11
How to Use This Guide........................................................................... 11
Unpacking .............................................................................................. 11
Regulatory
Compliance Statements ....................................................... 11
Warranty Policy ...................................................................................... 12
Maintaining Your Computer .................................................................... 13
Chapter 1 Introduction ........................................................................................... 16
Overview ................................................................................................ 16
Product Specifications ............................................................................ 17
System Block Diagram ........................................................................... 18
Mechanical Dimensions.......................................................................... 19
Chapter 2 Hardware Settings ................................................................................ 20
Overview
................................................................................................ 20
Jumper Settings and Pin Definitions....................................................... 21
Jumper Settings ......................................................................................... 22
Rear Panel Pin Assignments...................................................................... 24
Main Board Pin Assignments ..................................................................... 27
Chapter 3 System Installation................................................................................ 37
Expansive Interfaces .............................................................................. 37
Memory Module Installation.................................................................... 37
Chapter 4 AMI BIOS Setup.................................................................................... 39
Overview ................................................................................................ 39
Main
Menu.............................................................................................. 40
Advanced Menu ..................................................................................... 41
Boot Menu .............................................................................................. 45
Chipset Menu ......................................................................................... 46
Power Menu ........................................................................................... 48

Content
4
KEM
X
-
2030
User’s Manua
l
Security Menu ........................................................................................ 49
Exit Menu ............................................................................................... 50
Chapter 5 Driver Installation .................................................................................. 52
Appendix A System Resources.............................................................................. 53
Appendix B DIO (Digital I/O) KIT User Guide........................................................... 56

Figures
5
KEM
X
-
2030
User’s Manua
l
Figures
Figure 1 Block Diagram ............................................................................. 18
Figure 2 Mechanical Dimensions ............................................................... 19
Figure 3 Jumper Connector ....................................................................... 20
Figure 4 Jumper and Connector Locations ................................................ 21
Figure 5 Rear Panel IO .............................................................................. 24
Figure 6 Expansive Interfaces.................................................................... 37
Figure 7 Align the SO-DIMM Memory Module with the onboard socket..... 38
Figure 8 Press down on the SO-DIMM Memory Module to lock it in place 38

Tables
6
KEM
X
-
2030
User’s Manua
l
Tables
Table 1 KEMX-2030 Specification .............................................................. 17
Table 2 Jumper List.................................................................................... 22
Table 3 JP1 Backlight Enable Selection .................................................. 22
Table 4 JP2 Backlight & Panel Power Selection...................................... 22
Table 5 JP3 Clear CMOS Selection......................................................... 22
Table 6 JP4 COM1 Signal / Power Selection .......................................... 23
Table 7 JP5/ 6/ 7 COM2/ 3/ 4 Signal / Power Selection .......................... 23
Table 8 JP8 For Quanmax internal test only............................................ 23
Table 9 JP9 Power Mode Selection......................................................... 23
Table 10 Rear Panel Connector List .......................................................... 24
Table 11 AUDIO1, 3-Port Audio phone jack................................................ 24
Table 12 USB2, USB2.0 Port 2 , 3 Type A Connector ................................ 24
Table 13 CN9, USB2.0 Port 0, 1 Connector & Ethernet RJ-45 Connector . 25
Table 14 CN1 VGA Connector & RS-232 Port A DB-9 Connector ........... 25
Table 15 CN 10, PS/2 KB/MS Connector................................................... 26
Table 16 J1, +12V Power Input Connector................................................. 26
Table 17 Internal Connector List ................................................................ 27
Table 18 CN2, Panel Backlight Wafer ........................................................ 27
Table 19 CN3, Digital Input / Output Pin Header........................................ 28
Table 20 CN4, Front Panel Audio Pin Header ............................................ 28
Table 21 CN5, CD-In Connector ................................................................ 28
Table 22 CN6, S/PDIF Pin Header............................................................. 28
Table 23 CN7, Audio AMP Right Output Wafer .......................................... 29
Table 24 CN8, Audio AMP Left Output Wafer............................................. 29
Table 25 CN11, AT Power Output Wafer .................................................... 29
Table 26 FP1, Front Panel 1 Pin Header ................................................... 29
Table 27 FP2, Front Panel 2 Pin Header ................................................... 30
Table 28 LVDS1, LVDS Panel Connector................................................... 30
Table 29 IDE1, Primary 44-pin IDE Box Header ........................................ 31
Table 30 SATA1,2, SATA Connector .......................................................... 31
Table 31 USB3, USB2.0 Port 4, 5 Pin Header ........................................... 32
Table 32 USB4, USB2.0 Port 6, 7 Pin Header ........................................... 32
Table 33 COMx RS-232 Port-x Box Header（x = 2, 3, 4）..................... 32
Table 34 PCIE1 PCIE slots...................................................................... 33

Tables
7
KEM
X
-
2030
User’s Manua
l
Table 35 MPCI1, Mini-PCI Socket.............................................................. 33
Table 36 PCI1, PCI slots ............................................................................ 35
Table 37 ATX1, +12V Power Input Connector ............................................ 36
Table 38 Parallel Port Wafer ...................................................................... 36
Table 39 BIOS Main Menu ......................................................................... 40
Table 40 IDE Device Setting Menu ............................................................ 40
Table 41 System Information...................................................................... 41
Table 42 Advanced Menu........................................................................... 41
Table 43 Onboard I/O Configuration .......................................................... 42
Table 44 OnBoard Peripherals Configuration Settings .............................. 43
Table 45 Trusted Computing ...................................................................... 44
Table 46 Hardware Health Configuration ................................................... 44
Table 47 Boot Menu ................................................................................... 45
Table 48 Chipset Menu .............................................................................. 46
Table 49 Video Function Configuration ...................................................... 47
Table 50 Power Menu ................................................................................ 48
Table 51 Security Menu ............................................................................. 49
Table 52 Exit Menu .................................................................................... 50

Safety Instructions
8
KEM
X
-
2030
User’s Manua
l
Safety Instructions
Before You Begin
Before handling the product, read the instructions and safety guidelines on the
following pages to prevent damage to the product and to ensure your own personal
safety. Refer to the “Advisories” section in the Preface for advisory conventions used
in this user’s guide, including the distinction between Warnings, Cautions, Important
Notes, and Notes.
Always use caution when handling/operating a computer. Only qualified,
experienced, authorized electronics service personnel should access the
interior of a computer. The power supplies produce high voltages and
energy hazards, which can cause bodily harm.
Use extreme caution when installing or removing components. Refer to the
installation instructions in this user’s guide for precautions and procedures.
If you have any questions, please contact Quanmax Post-Sales Technical
Support.
WARNING
High voltages are present inside the chassis when the unit’s power cord is
plugged into an electrical outlet. Turn off system power, turn off the power
supply, and then disconnect the power cord from its source before
removing the chassis cover. Turning off the system power switch does not
remove power to components.
When Working Inside a Computer
Before taking covers off a computer, perform the following steps:
1. Turn off the computer and any peripherals.
2. Disconnect the computer and peripherals from their power sources or
subsystems to prevent electric shock or system board damage. This does not
apply when hot swapping parts.

Safety Instructions
9
KEM
X
-
2030
User’s Manua
l
3. Follow the guidelines provided in “Preventing Electrostatic Discharge” on the
following page.
4. Disconnect any telephone or telecommunications lines from the computer.
In addition, take note of these safety guidelines when appropriate:
To help avoid possible damage to system boards, wait five seconds after
turning off the computer before removing a component, removing a system
board, or disconnecting a peripheral device from the computer.
When you disconnect a cable, pull on its connector or on its strain-relief loop,
not on the cable itself. Some cables have a connector with locking tabs. If you
are disconnecting this type of cable, press in on the locking tabs before
disconnecting the cable. As you pull connectors apart, keep them evenly
aligned to avoid bending any connector pins. Also, before connecting a cable,
make sure both connectors are correctly oriented and aligned.
CAUTION
Do not attempt to service the system yourself except as explained in this
user’s guide. Follow installation and troubleshooting instructions closely.
Preventing Electrostatic Discharge
Static electricity can harm system boards. Perform service at an ESD workstation
and follow proper ESD procedure to reduce the risk of damage to components.
Quanmax strongly encourages you to follow proper ESD procedure, which can
include wrist straps and smocks, when servicing equipment.
You can also take the following steps to prevent damage from electrostatic
discharge (ESD):
When unpacking a static-sensitive component from its shipping carton, do not
remove the component’s antistatic packing material until you are ready to install
the component in a computer. Just before unwrapping the antistatic packaging,
be sure you are at an ESD workstation or grounded. This will discharge any
static electricity that may have built up in your body.
When transporting a sensitive component, first place it in an antistatic container

Safety Instructions
10
KEM
X
-
2030
User’s Manua
l
or packaging.
Handle all sensitive components at an ESD workstation. If possible, use
antistatic floor pads and workbench pads.
Handle components and boards with care. Don’t touch the components or
contacts on a board. Hold a board by its edges or by its metal mounting bracket.
Do not handle or store system boards near strong electrostatic, electromagnetic,
magnetic, or radioactive fields.
