Intel EMB-H61A User manual

Industrial Motherboard
EMB-H61A
EMB-H61A
Manual 3rdEd.
January 2016

Industrial Motherboard
EMB-H61A
i
Copyright Notice
This document is copyrighted, 2012. All rights are reserved. The
original manufacturer reserves the right to make improvements to the
products described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated, or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in this
manual is intended to be accurate and reliable. However, the original
manufacturer assumes no responsibility for its use, or for any in-
fringements upon the rights of third parties that may result from its
use.
The material in this document is for product information only and is
subject to change without notice. While reasonable efforts have been
made in the preparation of this document to assure its accuracy, the
original manufacturer assumes no liabilities resulting from errors or
omissions in this document, or from the use of the information
contained herein.
The original manufacturer reserves the right to make changes in the
product design without notice to its users.

Industrial Motherboard
EMB-H61A
ii
Acknowledgments
All other products’name or trademarks are properties of their
respective owners.
AMI is a trademark of American Megatrends Inc.
CompactFlash™is a trademark of the Compact Flash
Association.
Intel®is a trademark of Intel®Corporation.
Microsoft Windows®is a registered trademark of Microsoft Corp.
ITE is a trademark of Integrated Technology Express, Inc.
IBM, PC/AT, PS/2, and VGA are trademarks of International
Business Machines Corporation.
SoundBlaster is a trademark of Creative Labs, Inc.
All other product names or trademarks are properties of their
respective owners.

Industrial Motherboard
EMB-H61A
iii
Packing List
Before you begin installing your card, please make sure that the
following materials have been shipped:
1 Industrial Motherboard
1 SATA Cable
1 SATA Power Cable
1 Metal I/O Bracket
1 DVD-ROM for Manual (in PDF Format) and
Drivers
If any of these items should be missing or damaged, please
contact your distributor or sales representative immediately.

Industrial Motherboard
EMB-H61A
iv
Contents
Chapter 1 General Information
1.1 Features..................................................................1-2
1.2 Specifications..........................................................1-3
Chapter 2 Quick Installation Guide
2.1 Safety Precautions ..................................................2-2
2.2 Location of Connectors and Jumpers.......................2-3
2.3 Mechanical Drawing................................................2-5
2.4 List of Jumpers........................................................2-7
2.5 List of Connectors...................................................2-7
2.6 Setting Jumpers......................................................2-9
2.7 Clear CMOS (CLRTC1).........................................2-10
2.8 LVDS Panel Voltage Selection (J1) .......................2-10
2.9 Inverter Voltage Selection (J2)...............................2-10
2.10 Mode Selection for Back Light Control of Inverter (J3)
...................................................................................2-10
2.11 AT/ATX Mode Selection (J4) ...............................2-10
2.12 COM1 Ring/+5V/+12V Selection (J5)...................2-11
2.13 Internal COM Serial Port Connector (COM2 ~ COM6)
...................................................................................2-11
2.14 PS/2 Keyboard/Mouse Connector with Dock USB 2.0
Connector (CON19)....................................................2-11
2.15 1000Base-T Ethernet Connector with Dock USB 2.0
Connector (CON17/CON18)........................................2-12

Industrial Motherboard
EMB-H61A
v
2.16 Digital I/O Connector (DIO)..................................2-12
2.17 Debug Connector (DEBUG).................................2-13
2.18 Front Panel Connector (F_PANEL)......................2-13
2.19 Inverter Connector (INV)......................................2-14
2.20 LVDS Panel Signal Connector (LVDS) ................2-14
2.21 SATA Power Connector (PWR1).........................2-15
2.22 FAN Connector (S_FAN1/S_FAN2).....................2-15
2.23 BIOS Programmable Connector (SPI) .................2-16
2.24 Internal USB 2.0 Connector (USB1).....................2-16
Chapter 3 AMI BIOS Setup
3.1 System Test and Initialization..................................3-2
3.2 AMI BIOS Setup......................................................3-3
Chapter 4 Driver Installation
4.1 Installation...............................................................4-3
Appendix A Programming The Watchdog Timer
A.1 Watchdog Timer Initial Program .......................A-2
Appendix B I/O Information
B.1 I/O Address Map..................................................B-2
B.2 1stMB Memory Address Map................................B-4
B.3 IRQ Mapping Chart..............................................B-5
B.4 DMA Channel Assignments ................................B-7
Appendix C Mating Connector
C.1 List of Mating Connectors and Cables................. C-2

Industrial Motherboard
EMB-H61A
vi
Appendix D Digital Input & Output
D.1 DIO Programming............................................... D-2
D.2 Digital I/O Register.............................................. D-3
D.3 Digital I/O Sample Program ................................ D-4

Industrial Motherboard
EMB-H61A
Chapter 1 General Information 1- 1
General
Information
Chapter
1

Industrial Motherboard
EMB-H61A
Chapter 1 General Information 1-2
1.1 Features
Intel®Socket 1155 for 3rd Generation and Generation
Core™ i5/Core™ i3 Processors Up to 35W
2 x 204-pin Dual-Channel DDR3 1333/1066MHz DIMM
Up to 16GB
Intel®integrated Graphics Engine Supports Dual View by
VGA, DVI, HDMI, LVDS
Realtek PCI-Express Gigabit Ethernet x 2
SATA 3.0Gb/s x 2 & CF Socket x 1 (Supports Both
CF-SATA Card and CF Type 1)
USB 2.0 x 8 & COM x 6
PCI-Express 2.0 [x4 ] x 1 & Mini-PCIe Socket with SIM
Slot x 1 for mSATA support (Optional)
EuP/ErP Compliance
12V DC-in Support
TPM Module Support (Optional)

Industrial Motherboard
EMB-H61A
Chapter 1 General Information
1-3
1.2 Specifications
System
Processor
Intel®2nd/3rd generation Core™i5/i3
Processor, up to 35W
System Memory
204-pin dual-channel DDR3
1333/1066 SODIMM x 2, Max. 16
GB
Chipset
Intel®H61 (B3)
I/O Chipset
Fintek F81866D
Ethernet
Realtek 8111E for
10/100/1000Base-T, RJ-45 x 2
BIOS
AMI BIOS, 64MB ROM
Wake On LAN
Yes
Watchdog Timer
System reset: 1~255 steps
programmable
TPM
Optional
H/W Status Monitoring
Monitoring System Temperature,
Voltage, and Cooling Fan status
Expansion Interface
PCI-Express 2.0 [x4] x 1, Mini PCIe
x 1 (full size for mSATA support,
optional)
Battery
Lithium battery
Power Requirement
4-pin connector for DC12V input x 1;
CPU fan x 1, System fan with 4-pin
wafer x 1;
SATA power with 4-pin wafer x 1
Power Compliance
Compliant with EuP/ErP
Board Size
6.7”(L) x 6.7”(W) (170 mm x 170
mm)

Industrial Motherboard
EMB-H61A
Chapter 1 General Information 1-4
Gross Weight
1.1 lb (0.5 Kg)
Operating Temperature
32˚F~ 140˚F (0˚C ~ 60˚C)
Storage Temperature
-4˚F~ 158˚F (-20˚C ~ 70˚C)
Operating Humidity
10%~80% relative humidity,
non-condensing
EMI
CE/FCC Class A
Display
Chipset
Integrated Graphics Processor
(CH7511B for eDP to dual 24-bit
LVDS)
Resolution
Shared System Memory up to
1748MB
Up to 1920x1200 @ 60Hz for
HDMI;
Up to 2048x1536 @ 75Hz for
RGB;
Up to 1920x1200 @ 60Hz for
DVI/LCD
LCD Interface
Dual 24-bit LVDS
Output Interface
Multi-VGA output support: HDMI/
RGB/ DVI-D/ LCD
I/O
Storage
SATA 3.0 Gb/s x 2, CF socket x 1
for CF-SATA support integrated
with PCIe to PATA bridge solution
Serial Port
RS-232 x 5, RS-232/422/485 x 1
(COM1)
USB
USB2.0 x 8 (5x2 pin header for
internal x 2, onboard Type A
connector x 6)

Industrial Motherboard
EMB-H61A
Chapter 1 General Information
1-5
Digital I/O
Supports 8-bit (4-in/ 4-out)
PS/2 Port
Keyboard/ Mouse x 1
Audio
Audio jack with BTX type x 3
(Mic-in, Line-out, Line-in)

Industrial Motherboard
EMB-H61A
Chapter 2 Quick Installation Guide 2 - 1
Quick
Installation
Guide
Chapter
2

Industrial Motherboard
EMB-H61A
Chapter 2 Quick Installation Guide 2 - 2
2.1 Safety Precautions
Always completely disconnect the power cord
from your board whenever you are working on
it. Do not make connections while the power is
on, because a sudden rush of power can
damage sensitive electronic components.
Always ground yourself to remove any static
charge before touching the board. Modern
electronic devices are very sensitive to static
electric charges. Use a grounding wrist strap at
all times. Place all electronic components on a
static-dissipative surface or in a static-shielded
bag when they are not in the chassis

Industrial Motherboard
EMB-H61A
Chapter 2 Quick Installation Guide 2 - 3
2.2 Location of Connectors and Jumpers
Component Side

Industrial Motherboard
EMB-H61A
Chapter 2 Quick Installation Guide 2 - 4
Solder Side

Industrial Motherboard
EMB-H61A
Chapter 2 Quick Installation Guide 2 - 5
2.3 Mechanical Drawing
Component Side

Industrial Motherboard
EMB-H61A
Chapter 2 Quick Installation Guide 2 - 6
Solder Side

Industrial Motherboard
EMB-H61A
Chapter 2 Quick Installation Guide 2 - 7
2.4 List of Jumpers
The board has a number of jumpers that allow you to configure your
system to suit your application.
The table below shows the function of each of the board's jumpers:
Label
Function
CLRTC1
Clear CMOS
J1
LVDS Panel Voltage Selection
J2
Inverter Voltage Selection
J3
Mode Selection for Back Light Control of Inverter
J4
AT/ATX mode Selection
J5
COM1 Ring/+5V/+12V Selection
2.5 List of Connectors
The board has a number of connectors that allow you to configure your
system to suit your application.
The table below shows the function of each of the board's connectors:
Label
Function
ATX12V
ATX 4P Power Connector
AUDIO1
Audio jack Connector
BATTERY1
RTC - Coin Battery Holder
COM2
COM2 Connector
COM3
COM3 Connector
COM4
COM4 Connector
COM5
COM5 Connector
COM6
COM6 Connector

Industrial Motherboard
EMB-H61A
Chapter 2 Quick Installation Guide 2 - 8
CON14
COM1 & DVI-D Connector
CON17
LAN1 and USB1/2 Connector
CON18
LAN2 and USB3/4 Connector
CON19
PS/2 KB&MS and USB5/6 Connector
CON2
D-Sub15_VGA Connector with HDMI
Connector
CON3
mini PCI-E Slot
CON4
Compact Flash Slot
DEBUG
Debug Connector
DIMM_A1
DIMM1 Slot
DIMM_B1
DIMM2 Slot
DIO
Digital I/O Connector
F_PANEL
Front Panel Connector
INV
Inverter Connector
LGA1
CPU Socket - LGA-1155P
LVDS
LVDS Panel Signal Connector
PCIEX4
PCI Express x4 Slot
PWR1
SATA Power Connector
S_FAN1
System FAN Connector
S_FAN2
System FAN Connector
SATA1
SATA II Connector
SATA2
SATA II Connector
SIM1
SIM Card Socket
SPI
BIOS Programmable Connector
USB1
Int. USB 2.0 Connector
