Intel®ServerBoardS5000PSL,

Intel®ServerBoardS5000XSL,

Intel®WorkstationboardS5000XVN,

Intel®ServerChassisSC5400,and

Intel®EntryServerChassisSC5299-E

SparesPartsListandConfigurationGuide

A reference guide to help customers order the necessary components to configure the Intel®

Server Board S5000PSL and Intel®Workstation Board S5000XVN with the appropriate Intel

chassis.

Rev 2.0

April, 2010

~ Subject to Change ~

ChangeHistory:

5/10/06 Rev 1.0: Deleted pre-production information.

5/10/06 Rev 1.1: Updated RAID MM#’s and MOQ, ROMB descriptions for RAK product codes.

5/22/06 Rev 1.11: Updated AXX6DRV3G and AXX4DRV3G descriptions.

5/23/06 Rev 1.12: Updated errors in RAID descriptions.

6/26/06 Rev 1.13: Corrected description for ASLIO, BB5000PSLSATA MM#, slides for 5100 series processors.

6/28/06 Rev 1.14: New MM# for ARIGRACK and ASLPWRCABLE.

9/1/06 Rev 1.20: New MM# for MCH ECO.

9/12/06 Rev 1.21: New MM# for AXX6FDSCSIFAN.

9/31/06 Rev 1.22: Updated Configuration presentation for AXXUSBFLOPPY.

11/13/06 Rev 1.3: Updated Configuration presentation for 5300 Series processors and ROMB / backplane support.

2/27/07 Rev 1.31: Added SC5400LXi information and SCSI HSBP and SCSI RAID cards to Configuration.

3/06/07 Rev 1.4: Added RMM2 Information.

3/06/07 Rev 1.41: Added AXX04HSBPYCBL.

8/07/07 Rev 1.5: Added Refresh SKUs.

11/09/07 Rev 1.6: New MM# for OEM 10-pack SKUs, corrected boxed board content, and removed MM# of Non-

Refresh SKUs.

1/02/08 Rev 1.7: Updated boxed processor content and production RAID products.

1/15/09 Rev 1.8: Removed 4-pin power cable ASLPWRCABLE from the boxed board SKUs.

11/11/09 Rev 1.9: Added AXX04HSBPYCBL, updated the MM# of production board SKUs, added VMware

vSphere* Virtualization Software

04/01/10 Rev 2.0: Removed AXXRMM and AXXUSBFLOPPY, updated MM# of AXXSCD.

Disclaimer

Information in this document is provided in connection with Intel®products. No license, express or implied, by estoppel or

otherwise, to any intellectual property rights is granted by this document. Except as provided in Intel's Terms and Conditions

of Sale for such products, Intel assumes no liability whatsoever, and Intel disclaims any express or implied warranty, relating

to sale and/or use of Intel products including liability or warranties relating to fitness for a particular purpose, merchantability,

or infringement of any patent, copyright or other intellectual property right. Intel products are not intended for use in medical,

life saving, or life sustaining applications. Intel may make changes to specifications and product descriptions at any time,

without notice.

*Other brands and names may be claimed as the property of others. Intel, Pentium, Itanium, and Xeon are trademarks or

registered trademarks of Intel Corporation.

All products, dates, and figures are preliminary and are subject to change without any notice.

Contents

Contents ..........................................................................................................3

Production SKU Details and Contents........................................................4

Production Configuration and Ordering Steps (Intel®Server Board S5000PSL / Intel®Server Board S5000XSL) 4

Production Configuration and Ordering Steps (S5000XVN).....................8

Production Configuration...........................................................................12

Production Board SKUs............................................................................15

Production Chassis....................................................................................16

Production Spares and Accessories ........................................................18

Production RAID Products........................................................................23

VMware vSphere* Virtualization Software Configuration Guide for vSphere* SKUs 25

Production SKU Details and Contents

Production Configuration and Ordering Steps (Intel®Server Board S5000PSL / Intel®Server Board

S5000XSL)

This section highlights the ordering steps and configurations for the Intel®Server Board S5000PSL and Intel®Server Board

S5000XSL server board families. More detailed information is in the following sections.

Step 1 – Select a Server Board

Server Board S5000PSLSATA

- 6 SATA 3Gb/s ports

- S5000P Chipset (Boxed or OEM 10-pack)

- Optional Remote Management Module

Upgrade

Server Board S5000PSLSAS

- 4 SAS ports

- S5000P Chipset (Boxed or OEM 10-pack)

- Optional Remote Management Module

Upgrade

Server Board S5000XSLSATA

- 6 SATA 3Gb/s ports

- S5000X Chipset (OEM 10-pack)

- Optional Remote Management Module

Upgrade

Server Board S5000PSLROMB

- 6 SATA 3Gb/s ports

- Integrated Server RAID (8-port SAS with optional upgrade to hardware RAID

- S5000P Chipset (Boxed or OEM 5-pack)

- Optional Remote Management Module Upgrade

Step 2 – Select an Intel Server Chassis

SC5400LX

- Support for hot-swap power supplies (2

power supply is

optional)

- Supports hot-swap fans

- Optional supports for one 4-drive bay

and/or

one 6-drive bay

- Supports S5000PSL and S5000XSL server boards

SC5400BRP

- Support for hot-swap power supplies (2

power supply is optional)

- Fixed fans

- Optional supports for one 4-drive bay

and/or

one 6-drive bay

- Supports S5000PSL and S5000XSL server boards

SC5400Base

-Fixed 670W power supply and fans

- Optional support for one 6-drive bay

SC5299BRP

-Support for hot-swap 650W power supply and fixed fans

- Optional support for one hot-swap 6-drive bay

SC5299DP

-Fixed 550W power supply and fans

- Optional support for one hot-swap 6-drive bay

- Consult the Power Budget spreadsheet to verify configuration

support on Support.Intel.com

SC5400LXi

- Includes FXX830WPSU redundant power supply module.

- Includes AXX6DRV3G 6-drive hot-swap, non-expanded, SATA/SAS

supported backplane assembly

- Supports S5000PSL and S5000XSL server boards

Step 3 – Select Optional Intel Drive Bays

AXX4DRV3GEXP

4 drive hot-swap SAS backplane kit

- SC5400BRP and SC5400LX only

- Requires 2 SAS ports for SAS or SATA drive support

AXX4FIXDB

4 drive tool-less fixed kit

- SC5400BRP and SC5400LX only

AXXRMM

- Intel® Remote Management Module

- Enables KVM and advanced, remote manageability functionality

Step 4: Choose an optional Intel® Remote Management Module

AXX4DRV3G

4 drive hot-swap SAS/SATA backplane kit

- SC5400BRP and SC5400LX only

- Requires 4 SAS ports for SAS and/or SATA drive support or 4

SATA ports for SATA drive support. Not supported with

S5000PSLROMB or the SRCSAS144E RAID card.

AXX6DRV3GEXP

6 drive hot-swap SAS backplane kit

- Supported in SC5400 and SC5299 families

- Requires 2 SAS ports for SAS or SATA drive support

AXX6DRV3G

6 drive hot-swap SAS/SATA backplane kit

- Supported in SC5400 and SC5299 families

- Requires 6 SAS ports for SAS and/or SATA drive support or 6

SATA ports for SATA drive support. Not supported with

S5000PSLROMB or the SRCSAS144E RAID card.

AXX4SCSIDB

4 drive hot-swap SCSI backplane kit

- SC5400BRP and SC5400LX only

AXX6SCSIDB

6 drive hot-swap SCSI backplane kit

- SC5299 requires optional APP3HSDBKIT

AXXRAK18E

- Hardware RAID 0, 1, 5, 10, 50 Activation Key for

S5000PSLROMB

- Requires a 256MB to 1GB DDR2-400 ECC DIMM

(purchased separately)

Step 5: Choose an optional Intel® SAS/SATA RAID Controller

AXXRAKSW5

- Activation key for software RAID 5 (SATA or SAS)

- Supports S5000PSL, S5000XSL and S5000XVN

board families

SRCSAS18E

- 8 Port SAS RAID controller (PCI Express x8)

AXXRSBBU3

- Battery backup for S5000PSLROMB SKU (with

AXXRAK18E)

AXXRPCM2

- 256MB DIMM and battery for SRCSAS18E

Key

= Supported

The Intel Server Board S5000PSLROMB comes with Intel Integrated Server RAID. This ROMB Card consumes a PCI

Express slot and provides 8 SAS ports. With the optional Activation Key (AXXRAK18E), hardware 0, 1, 5, 10, 50

RAID is activated.

SRCSAS144E

- 8 Port SAS RAID controller, 4 Int / 4 Ext

(PCI Express x8)

SRCS28X

- 64/133MHz PCI-X, 8-port SATA II RAID Controller

AXXRIBBU1

- Battery Backup Unit for RAID controller SRCS28X

Step 5a: Choose an optional Intel® SCSI RAID Controller

SRCU42E

- PCIe x8, 2 Channel U320 SCSI RAID Controller

Bulk SKU (SRCU42EBLK)

SRCU42X

- PCI-X, 2 Channel U320 SCSI RAID Controller

AXXRBBU1

- Battery backup for SRCU42X and SRCZCRX

AXXRPCM1

- 128MB DIMM and battery for SRCU42E

Key

= Supported

SRCU41L

- PCI-X 64/66 Single channel SCSI RAID Controller

APP3RACKIT

- Rack conversion kit for SC5299 family

Step 7b: Choose Intel Server Chassis

SC5299 family key accessories

APP4650WPSU

- 650W hot-swap power supply

- Required to provide full redundancy for

SC5299BRP

APP3HSDBKIT

- Hot-swap drive bay fan and adaptor kit

Required

for when adding optional hot-swap drive

bays in SC5299DP and SC5299BRP chassis

Processor Number Product Code

X5460 (3.16 GHz, 1333 MHz FSB) BX80574X5460P

X5450 (3.00 GHz, 1333 MHz FSB) BX80574X5450P

E5450 (3.00 GHz, 1333 MHz FSB) BX80574E5450P

E5440 (2.83 GHz, 1333 MHz FSB) BX80574E5440P

E5430 (2.66 GHz, 1333 MHz FSB) BX80574E5430P

E5420 (2.50 GHz, 1333 MHz FSB) BX80574E5420P

E5410 (2.33 GHz, 1333 MHz FSB) BX80574E5410P

E5405 (2.00 GHz, 1333MHz FSB) BX80574E5405P

X5355 (2.67 GHz, 1333 MHz FSB) BX80563X5355P

E5345 (2.33 GHz, 1333 MHz FSB) BX80563E5345P

E5335 (2.00 GHz, 1333 MHz FSB) BX80563E5335P

E5320 (1.86 GHz, 1066 MHz FSB) BX80563E5320P

E5310 (1.60 GHz. 1066 MHz FSB) BX80563E5310P

L5335 (2.00 GHz, 1333 MHz FSB, Low Voltage) BX80563L5335P

L5320 (1.86 GHz, 1066 MHz FSB, Low Voltage) BX80563L5320P

L5310 (1.60 GHz, 1066 MHz FSB, Low Voltage) BX80563L5310P

X5260 (3.33 GHz, 1333 MHz FSB) BX80573X5260P

E5205 (1.86 GHz, 1066 MHz FSB) BX80573E5205P

Processor Number Product Code

5160 (3.00 GHz, 1333 MHz FSB) BX805565160P

5150 (2.66 GHz, 1333 MHz FSB) BX805566150P

5148 (2.33 GHz, 1333 MHz FSB, Low Voltage) BX805565148P

5140 (2.33 GHz, 1333 MHz FSB) BX805565140P

5138 (2.13 GHz, 1066 MHz FSB, Low Voltage) BX805565138P

5130 (2.00 GHz, 1333 MHz FSB) BX805565130P

5128 (1.86 GHz, 1066 MHz FSB, Low Voltage) BX805565128P

5120 (1.86 GHz, 1066 MHz FSB) BX805565120P

5110 (1.60 GHz, 1066 MHz FSB) BX805565110P

5080 (3.73 GHz, 1066 MHz FSB) BX805555080P

5063 (3.20 GHz, 1066 MHz FSB) BX805555063P

5060 (3.20 GHz, 1066 MHz FSB) BX805555060P

5050 (3.00 GHz, 667 MHz FSB) BX805555050P

5030 (2.67 GHz, 667 MHz FSB) BX805555030P

Processor Number Product Code

X5460 (3.16 GHz, 1333 MHz FSB) BX80574X5460A

X5450 (3.00 GHz, 1333 MHz FSB) BX80574X5450A

E5450 (3.00 GHz, 1333 MHz FSB) BX80574E5450A

E5440 (2.83 GHz, 1333 MHz FSB) BX80574E5440A

E5430 (2.66 GHz, 1333 MHz FSB) BX80574E5430A

E5420 (2.50 GHz, 1333 MHz FSB) BX80574E5420A

E5410 (2.33 GHz, 1333 MHz FSB) BX80574E5410A

E5405 (2.00 GHz, 1333MHz FSB) BX80574E5405A

X5355 (2.67 GHz, 1333 MHz FSB) BX80563X5355A

E5345 (2.33 GHz, 1333 MHz FSB) BX80563E5345A

E5335 (2.00 GHz, 1333 MHz FSB) BX80563E5335A

E5320 (1.86 GHz, 1066 MHz FSB) BX80563E5320A

E5310 (1.60 GHz. 1066 MHz FSB) BX80563E5310A

L5335 (2.00 GHz, 1333 MHz FSB, Low Voltage) BX80563L5335A

L5320 (1.86 GHz, 1066 MHz FSB, Low Voltage) BX80563L5320A

L5310 (1.60 GHz, 1066 MHz FSB, Low Voltage) BX80563L5310A

X5260 (3.33 GHz, 1333 MHz FSB) BX80573X5260A

E5205 (1.86 GHz, 1066 MHz FSB) BX80573E5205A

5160 (3.00 GHz, 1333 MHz FSB) BX805565160A

5150 (2.66 GHz, 1333 MHz FSB) BX805566150A

5148 (2.33 GHz, 1333 MHz FSB, Low Voltage) BX805565148A

5140 (2.33 GHz, 1333 MHz FSB) BX805565140A

5138 (2.13 GHz, 1066 MHz FSB, Low Voltage) BX805565138A

5130 (2.00 GHz, 1333 MHz FSB) BX805565130A

5128 (1.86 GHz, 1066 MHz FSB, Low Voltage) BX805565128A

5120 (1.86 GHz, 1066 MHz FSB) BX805565120A

5110 (1.60 GHz, 1066 MHz FSB) BX805565110A

5080 (3.73 GHz, 1066 MHz FSB) BX805555080A

5063 (3.20 GHz, 1066 MHz FSB) BX805555063A

5060 (3.20 GHz, 1066 MHz FSB) BX805555060A

5050 (3.00 GHz, 667 MHz FSB) BX805555050A

5030 (2.67 GHz, 667 MHz FSB) BX805555030A

Step 9: Accessories that will or may have to be

purchased separately to create a complete system



Memory



533 MHz or 667MHz DDR2 Fully-Buffered DIMMs with a full-DIMM heat

spreader



For SL5000PSLROMB, a 256MB (or up to 1GB) ECC DDR2-400 DIMM is

required and must be purchased separately



Cables



1-2 power cables (unless using a SC5400BASENA, SC5400BRPNA,

SC5400LXNA, SC5299DPNA and SC5299BRPNA chassis in North

America)



Ethernet cables



Hard disk drives, keyboard, monitor and mouse



CD/DVD



Unless using AXXCDUSBFDBRK, AXXUSBFLOPPY and AXXSCD or

AXXDVDCDR (Step 7) in the SC5400 family of chassis

Production Configuration and Ordering Steps (S5000XVN)

This section highlights the ordering steps and configurations for the Intel®S5000XVN Workstation boards. More detailed

information is in the following sections.

Step 1 – Select a Workstation Board

Workstation Board S5000XVNSATA

- 6 SATA 3Gb/s ports

- S5000X Chipset (Boxed or OEM 10-pack)

Workstation Board S5000XVNSAS

- 4 SAS ports

- S5000X Chipset (Boxed or OEM 10-pack)

Step 2 – Select an Intel Server Chassis

SC5400Base

Fixed 670W power supply and fans

- Optional support for one 6-drive bay

SC5299WS

Fixed 670W power supply and fans

- Optional support for one hot-swap 6-drive bay

Step 3 – Select Optional Intel Drive Bays

AXX6DRV3GEXP

6 drive hot-swap SAS backplane kit

- Supported in SC5400 and SC5299 families

- Requires 2 SAS ports for SAS or SATA drive support

AXX6DRV3G

6 drive hot-swap SAS/SATA backplane kit

- Supported in SC5400 and SC5299 families

- Requires 6 SAS ports for SAS and/or SATA drive support or 6

SATA ports for SATA drive support. Not supported with Intel

RAID controller SRCSAS144E.

AXXRAK18E

- Hardware RAID 0, 1, 5,10, 50 Activation Key for

S5000PSLROMB

- Requires a 256MB to 1GB DDR2-400 ECC DIMM

(purchased separately)

Step 4: Choose an optional Intel® SAS/SATA RAID Controller

AXXRAKSW5

- Activation key for software RAID 5 (SATA or SAS)

- Supports S5000PSL, S5000XSL and S5000XVN

board families

SRCSAS18E

- 8 Port SAS RAID controller (PCI Express x8)

AXXRSBBU3

- Battery backup for S5000PSLROMB SKU (with

AXXRAK18E)

AXXRPCM2

- 256MB DIMM and battery for SRCSAS18E

Key

= Supported

SRCSAS144E

- 8 Port SAS RAID controller, 4 Int / 4 Ext

(PCI Express x8)

SRCS28X

- 64/133MHz PCI-X, 8-port SATA II RAID Controller

AXXRIBBU1

- Battery Backup Unit for RAID controller SRCS28X

Step 4a: Choose an optional Intel® SCSI RAID Controller

SRCU42E

- PCIe x8, 2 Channel U320 SCSI RAID Controller

Bulk SKU (SRCU42EBLK)

SRCU42X

- PCI-X, 2 Channel U320 SCSI RAID Controller

AXXRBBU1

- Battery backup for SRCU42X and SRCZCRX

AXXRPCM1

- 128MB DIMM and battery for SRCU42E

Key

= Supported

SRCU41L

- PCI-X 64/66 Single channel SCSI RAID Controller

AXXLCPPED

- LCD accessory for SC5400 and SC5299 chassis families

Step 5: Choose an optional Intel® Local Control Panel

ARIGRACK

- Rack conversion kit for SC5400 chassis family

Step 6a: Choose Intel Server Chassis

SC5400 family key accessories

ARIGDLTRAIL

- DLT Accessory Kit (10 pack of rails)

AXXCDUSBFDBRK

- Used to install one slim-line CD/DVD and a slim-

line floppy in a 5.25” drive bay’

AXXSCD

- Slim-line CD for use with AXXCDUSBFDBRK

AXXUSBFLOPPY

- Slim-line floppy for use with AXXCDUSBFDBRK

AXXDVDCDR

- Slim-line DVD/CDR used with AXXCDUSBFDBRK

AXXCMA3U7U

- Cable management arm

Key

= Supported

APP3RACKIT

- Rack conversion kit for SC5299 family

Step 6b: Choose Intel Server Chassis SC5299 family key accessories

APP3HSDBKIT

- Hot-swap drive bay fan and adaptor kit

-Required for when adding optional hot-swap drive

bays in SC5299WS chassis

APP3RACKIT

- Rack conversion kit for SC5299 family

Step 7b: Choose Intel Server Chassis

SC5299 family key accessories

APP4650WPSU

- 650W hot-swap power supply

- Required to provide full redundancy for

SC5299BRP

APP3HSDBKIT

- Hot-swap drive bay fan and adaptor kit

-Required for when adding optional hot-swap drive

bays in SC5299DP and SC5299BRP chassis

Processor Number Product Code

X5460 (3.16 GHz, 1333 MHz FSB) BX80574X5460P

X5450 (3.00 GHz, 1333 MHz FSB) BX80574X5450P

E5450 (3.00 GHz, 1333 MHz FSB) BX80574E5450P

E5440 (2.83 GHz, 1333 MHz FSB) BX80574E5440P

E5430 (2.66 GHz, 1333 MHz FSB) BX80574E5430P

E5420 (2.50 GHz, 1333 MHz FSB) BX80574E5420P

E5410 (2.33 GHz, 1333 MHz FSB) BX80574E5410P

E5405 (2.00 GHz, 1333MHz FSB) BX80574E5405P

X5355 (2.67 GHz, 1333 MHz FSB) BX80563X5355P

E5345 (2.33 GHz, 1333 MHz FSB) BX80563E5345P

E5335 (2.00 GHz, 1333 MHz FSB) BX80563E5335P

E5320 (1.86 GHz, 1066 MHz FSB) BX80563E5320P

E5310 (1.60 GHz. 1066 MHz FSB) BX80563E5310P

L5335 (2.00 GHz, 1333 MHz FSB, Low Voltage) BX80563L5335P

L5320 (1.86 GHz, 1066 MHz FSB, Low Voltage) BX80563L5320P

L5310 (1.60 GHz, 1066 MHz FSB, Low Voltage) BX80563L5310P

X5260 (3.33 GHz, 1333 MHz FSB) BX80573X5260P

E5205 (1.86 GHz, 1066 MHz FSB) BX80573E5205P

5160 (3.00 GHz, 1333 MHz FSB) BX805565160P

5150 (2.66 GHz, 1333 MHz FSB) BX805566150P

5148 (2.33 GHz, 1333 MHz FSB, Low Voltage) BX805565148P

5140 (2.33 GHz, 1333 MHz FSB) BX805565140P

5138 (2.13 GHz, 1066 MHz FSB, Low Voltage) BX805565138P

5130 (2.00 GHz, 1333 MHz FSB) BX805565130P

5128 (1.86 GHz, 1066 MHz FSB, Low Voltage) BX805565128P

5120 (1.86 GHz, 1066 MHz FSB) BX805565120P

5110 (1.60 GHz, 1066 MHz FSB) BX805565110P

5080 (3.73 GHz, 1066 MHz FSB) BX805555080P

5063 (3.20 GHz, 1066 MHz FSB) BX805555063P

5060 (3.20 GHz, 1066 MHz FSB) BX805555060P

5050 (3.00 GHz, 667 MHz FSB) BX805555050P

5030 (2.67 GHz, 667 MHz FSB) BX805555030P

This manual suits for next models

Table of contents

Other Intel Motherboard manuals

Popular Motherboard manuals by other brands

Gigabyte

Gigabyte MNJ190I-FH user manual

Biostar

Biostar HI-FI-Z87X-3D Setup manual

Atmel

Atmel SAM9753PIA-DK user guide

Coapt

Coapt GEN2 Handbook

Supero

Supero SUPER P4DL6 user manual

Cypress

Cypress CY3210-PSoCEVAL1 quick start guide

ASROCK

ASROCK B660M-HDV manual

Fujitsu

Fujitsu D2831 Short description

Industrial Computers

Industrial Computers ADE-6050 user manual

Asus

Asus TUF Z270 MARK 2 manual

DFI

DFI NB71-BC user manual

ASROCK

ASROCK H61 Pro BTC user manual

Norco

Norco POS-7893 user manual

Asus

Asus B85M-VIEW PAKER user manual

Asus

Asus P5G41T-M LX V2 user manual

Gigabyte

Gigabyte GA-K8VT800-RH user manual

Gigabyte

Gigabyte Z790M AORUS ELITE user manual

Semtech

Semtech SC120 user guide

Intel S5000PSLSAS User manual

Popular Motherboard manuals by other brands
