Intel 740 Guide

Intel740™ Graphics Accelerator
Design Guide
August 1998
Order Number: 290619-003

Intel740™ Graphics Accelerator Design Guide
Information in this document is provided in connection with Intel products. No license, express or implied, by estoppel or otherwise, to any intellectual
property rights is granted by this document. Except as provided in Intel's Terms and Conditions of Sale for such products, Intel assumes no liability
whatsoever, and Intel disclaims any express or implied warranty, relating to sale and/or use of Intel products including liability or warranties relating to
fitness for a particular purpose, merchantability, or infringement of any patent, copyright or other intellectual property right. Intel products are not
intended for use in medical, life saving, or life sustaining applications.
Intel may make changes to specifications and product descriptions at any time, without notice.
Contact your local Intel sales office or your distributor to obtain the latest specifications and before placing your product order.
The Intel740™ graphics accelerator may contain design defects or errors known as errata which may cause the products to deviate from published
specifications. Such errata are not covered by Intel’s warranty. Current characterized errata are available upon request.
I2C is a two-wire communications bus/protocol developed by Philips. SMBus is a subset of the I2C bus/protocol and was developed by Intel.
Implementations of the I2C bus/protocol or the SMBus bus/protocol may require licenses from various entities, including Philips Electronics N.V. and
North American Philips Corporation.
Copies of documents which have an ordering number and are referenced in this document, or other Intel literature may be obtained by:
calling 1-800-548-4725 or
by visiting Intel's website at http://www.intel.com.
Copyright © Intel Corporation, 1998
*Third-party brands and names are the property of their respective owners.

Intel740™ Graphics Accelerator Design Guide iii
Contents
1 Introduction................................................................................................................1-1
1.1 About This Design Guide..............................................................................1-1
1.2 References....................................................................................................1-2
2 Addin Card Design.....................................................................................................2-1
2.1 Introduction...................................................................................................2-1
2.1.1 Design Features...............................................................................2-2
2.1.1.1 Intel740™ Graphics Accelerator.....................................2-2
2.1.2 BT829B - Video Decoder.................................................................2-3
2.1.2.1 BT869 - TV Encoder.......................................................2-3
2.1.3 Terminology .....................................................................................2-3
2.1.3.1 Power Sources ...............................................................2-3
2.1.3.2 Fences............................................................................2-4
2.1.3.3 Stitching..........................................................................2-4
2.2 Layout and Routing Guidelines.....................................................................2-5
2.2.1 Placement........................................................................................2-5
2.2.2 Board Description ............................................................................2-6
2.2.3 BGA Component..............................................................................2-8
2.2.3.1 Layout Requirements......................................................2-8
2.2.3.2 Ground Connections.......................................................2-9
2.2.3.3 Power Connections.........................................................2-9
2.2.3.4 Decoupling....................................................................2-10
2.2.3.5 General Signal Routing.................................................2-11
2.2.4 Voltage Regulator ..........................................................................2-11
2.2.5 Bt829 Video Decoder.....................................................................2-11
2.2.5.1 Ground Planes..............................................................2-12
2.2.5.2 Power Planes................................................................2-12
2.2.5.3 Passive Components and Signal Routing ....................2-12
2.2.6 Bt869 Video Encoder.....................................................................2-12
2.2.6.1 Ground Planes..............................................................2-12
2.2.6.2 Power Planes................................................................2-13
2.2.6.3 Passive Components and Signal Routing ....................2-13
2.2.6.4 AGP Layout and Routing Guidelines............................2-13
2.2.6.5 Intel740™ Graphics Accelerator Memory
Layout and Routing Guidelines.....................................2-14
2.2.6.6 Intel740™ Graphics Accelerator Memory
Configurations...............................................................2-17
2.2.6.7 TV Out Interface ...........................................................2-20
2.2.6.8 Analog Signals..............................................................2-20
2.2.7 UL and FCC Considerations..........................................................2-20
2.3 Addin Card Schematics ..............................................................................2-21

iv Intel740™ Graphics Accelerator Design Guide
3 3 Device AGP MotherBoard Design..........................................................................3-1
3.1 Introduction...................................................................................................3-1
3.1.1 Overview..........................................................................................3-1
3.1.2 About This Chapter..........................................................................3-2
3.1.3 Block Diagram .................................................................................3-2
3.1.4 Implementation Issues.....................................................................3-3
3.1.4.1 Disabling A Master Device .............................................3-3
3.1.4.2 Low Power Logic Implementation...................................3-4
3.1.4.3 GPO27# and GPO28# Signal Duration..........................3-5
3.1.5 State Diagrams................................................................................3-5
3.1.5.1 Signal Quality and Timing Issues ...................................3-6
3.1.5.2 Strobe Edge Quality Issues............................................3-7
3.1.5.3 Clock Issues...................................................................3-7
3.1.6 Design Recommendations...............................................................3-9
3.1.6.1 Voltage Definitions..........................................................3-9
3.1.6.2 General Design Recommendation .................................3-9
3.2 3 Device AGP Motherboard Layout and Routing Guidelines........................3-9
3.2.1 BGA Quadrant Assignment ...........................................................3-10
3.2.2 Board Description ..........................................................................3-12
3.2.3 3-point AGP Design Guidelines.....................................................3-12
3.2.3.1 Layout and Routing ......................................................3-12
3.2.3.2 Data and strobe definitions...........................................3-13
3.2.3.3 Assumptions for Board Design Guidelines...................3-14
3.2.3.4 Add-in Card guideline assumptions:.............................3-14
3.2.3.5 Motherboard Guideline Assumptions ...........................3-14
3.2.3.6 3-Load AGP Topology..................................................3-16
3.2.3.7 Overall Solution Space.................................................3-16
3.2.4 Intel740™ Graphics Accelerator Memory Layout and
Routing Guidelines ........................................................................3-18
3.2.4.1 3 Device AGP Intel740™ Graphics Accelerator
Memory Configurations ................................................3-21
3.3 3 Device AGP Motherboard Reference Design Schematics ......................3-22
4 Thermal Considerations.............................................................................................4-1
5 Mechanical Information..............................................................................................5-1
5.1 Board Dimensions ........................................................................................5-1
5.2 Fan/Heatsink Hole Pattern............................................................................5-1
5.3 VMI Header Placement.................................................................................5-2
5.4 50 Pin Video Connector................................................................................5-3
5.5 Bracket..........................................................................................................5-4
5.6 NLX Considerations......................................................................................5-5
6 Third Party Vendors...................................................................................................6-1
6.1 Voltage Regulator.........................................................................................6-1
6.2 50 Pin Connector..........................................................................................6-1
6.3 Fan/Heatsink.................................................................................................6-1
6.4 Flash Components........................................................................................6-1
6.5 Video Encoders/Decoders............................................................................6-1
6.6 DVD Daughter Cards....................................................................................6-2
6.7 TV Tuner.......................................................................................................6-2
A Application Notes
B Reference Information

Intel740™ Graphics Accelerator Design Guide v
Figures
2-1 Example of Power Plane Separation ("fencing")...........................................2-4
2-2 Example of Power Plane Stitching................................................................2-4
2-3 Major Signal Sections...................................................................................2-5
2-4 Example ATX Layout....................................................................................2-6
2-5 Four Layer Board Stack-up...........................................................................2-7
2-6 Metal Defined land dimensions.....................................................................2-8
2-7 BGA Trace....................................................................................................2-8
2-8 Dogbone Via Pattern.....................................................................................2-9
2-9 Suggested VCC Planes for the Intel740™ Graphics Accelerator...............2-10
2-10 Intel740™ Graphics Accelerator Decoupling..............................................2-10
2-11 Intel740™ Graphics Accelerator BGA Routing Example............................2-11
2-12 Layout Dimensions (MA[11:0])....................................................................2-15
2-13 Layout Dimensions (MD[63:0], DQM[7:0])..................................................2-15
2-14 Layout Dimensions (WEA#, SRASA#, SCASA#, CSA1#, CSB0#).............2-15
2-15 Layout Dimensions (WEB#, SRASB#, SCASB#, CSA0#)..........................2-16
2-16 Memory Layout Dimensions (TCLK0).........................................................2-16
2-17 Memory Layout Dimensions (TCLK1).........................................................2-16
2-18 Memory Layout Dimensions (RCLK and OCLK to RCLK)..........................2-17
2-19 2/4 MB Local Memory Connection (64-bit data path) .................................2-17
2-20 4/8 MB Local Memory Connection (64-bit data path) .................................2-18
2-21 8 MB Local Memory Connection (64-bit data path) ....................................2-19
2-22 Layout Dimensions, Digital TV Bus.............................................................2-20
2-23 512Kx32 and 256Kx32 Pinout Compatibility...............................................2-24
2-24 1M X 16 Pinout Compatibility.....................................................................2-24
3-1 Pentium®II Processor / Intel®440BX AGPset/Intel 740 Graphics
Accelerator System Block Diagram ..............................................................3-3
3-2 The Schematic Diagram for GPO27#, PCIRST# (System Reset),
RESET#, ROMA16 Signals ..........................................................................3-4
3-3 The Schematic Diagram for the WEB#, SCASB#, SRASB#,
CS0B#, CS1B# and TEST............................................................................3-5
3-4 Intel740™ Graphics Controller (On Board Device) Remains in
Low Power Mode..........................................................................................3-6
3-5 Intel740™ Graphics Controller (On Board Device) State Diagram...............3-6
3-6 Point-to-Point Topology ................................................................................3-8
3-7 Major Signal Sections.................................................................................3-10
3-8 Example ATX Placement for a UP Pentium®II Processor /
Intel®440BX AGPset / Intel 740 Graphics Accelerator Design ..................3-11
3-9 Four Layer Board Stack-up.........................................................................3-12
3-10 Point-to-Point Topology ..............................................................................3-15
3-11 3 Device Data Load Topology.....................................................................3-16
3-12 3 Device Strobe Load Topology..................................................................3-16
3-13 3 Device Data Load Topology (Solution 1 is Shown)..................................3-17
3-14 3 Device Strobe Load Topology (Solution 1 is shown) ...............................3-17
3-15 Clock Topology and Matching.....................................................................3-17
3-16 Layout Dimensions (MA[11:0])....................................................................3-19
3-17 Layout Dimensions (MD[63:0], DQM[7:0])..................................................3-19
3-18 Layout Dimensions (WEA#, SRASA#, SCASA#, CSA0#)..........................3-20
3-19 Memory Layout Dimensions (TCLK1).........................................................3-20
3-20 Memory Layout Dimensions (RCLK and OCLK to RCLK)..........................3-21

vi Intel740™ Graphics Accelerator Design Guide
3-21 2/4 MB Local Memory Connection (64-bit data path) .................................3-21
3-22 512Kx32 and 256Kx32 Pinout Compatibility...............................................3-26
3-23 1M X 16 Pinout Compatibility.....................................................................3-26
5-1 Mounting Hole Locations (Fan/Heatsink Assembly).....................................5-1
5-2 VMI Header Placement.................................................................................5-2
5-3 DVD Daughter Card Dimensions (ATX and NLX)—Top Side ......................5-2
5-4 50 Pin Video Connector Schematic..............................................................5-3
5-5 Recommended Bracket Placement ..............................................................5-4
5-6 Recommended Bracket Cutout.....................................................................5-4

Intel740™ Graphics Accelerator Design Guide vii
Tables
2-1 Mix and Match Options For Intel740™ Graphics Accelerator Card..............2-2
2-2 Intel740™ Graphics Accelerator Power Supplies.........................................2-3
2-3 Bt829B GND and AGND Pins.....................................................................2-12
2-4 Bt829B VCC and AVCC Pins......................................................................2-12
2-5 Bt869 Digital and Analog Power Pins .........................................................2-13
2-6 AGP Signal Lengths....................................................................................2-13
2-7 Strobes and Corresponding Signal Groups................................................2-13
2-8 Supported Memory Options (Other Memory Options Are
Not Supported)............................................................................................2-14
2-9 Memory Layout Restrictions (See Figure 2-12 and Figure 2-13)................2-14
2-10 Memory Layout Restrictions (See Figure 2-14 and Figure 2-15)................2-15
2-11 Memory Layout Restrictions (See Figure 2-16 and Figure 2-17)................2-16
2-12 TV Out/ROMA Trace Lengths (See Figure 2-22)........................................2-20
2-13 GPIO Functions ..........................................................................................2-21
3-1 State of Signals to be Driven After System Reset but at Least
One Clock Prior to Asserting TEST ..............................................................3-4
3-2 Signal Duration of the GPO Signals from PIIX4............................................3-5
3-3 Data and Associated Strobe.......................................................................3-13
3-4 Data Signal and Strobe Guideline Assumptions.........................................3-14
3-5 Control and Clock Signal Guideline Assumptions.......................................3-14
3-6 Data signal and strobe requirements..........................................................3-14
3-7 Control Signal Line Length Requirements..................................................3-15
3-8 Strobe and Data Segment Solution Space .................................................3-16
3-9 Clock Segment Solution Space ..................................................................3-18
3-10 Supported Memory Options (Other Memory Options Are
Not Supported)............................................................................................3-18
3-11 Memory Layout Restrictions (See Figure 3-16 and Figure 3-17)................3-19
3-12 Memory Layout Restrictions (See Table 3-16 and Table 3-17)...................3-19
3-14 Memory Layout Restrictions (See Figure 3-19) ..........................................3-20
3-13 Memory Layout Restrictions (See Figure 3-19) ..........................................3-20
4-1 Thermal Design Considerations Chart..........................................................4-1

viii Intel740™ Graphics Accelerator Design Guide
Revision History
Date Revision Description
2/98 -001 Initial Release.
4/98 -002
Part 2: Added Figure 2-2; added “Note” verbiage in 2.14.
Part 3: Added verbiage to 3.3.5; Modified Figures
3-14, 3-15, 3-16, 3-19; Modified Table 3-10.
Part 5: Modified Figure 5-6.
7/98 -003
Restructured document and added a motherboard design:
Chapter 2 contains the Addin Card design. This chapter combines
revision 2 Chapters 1, 2, 3, and Appendix A. Only re-organizaiton; the
information is the same.
Chapter 2 adds the motherboard design.

1
Introduction

Intel740™ Graphics Accelerator Design Guide 1-1
Introduction
Introduction
1
This document provides a complete package of design information for the Intel740™ Graphics
Accelerator. There are two design discussed:
•ATX Addin Card Design (Chapter 2 provides design considerations, layout and routing
guidelines, and schematic diagrams)
•Motherboard Design (Chapter 3 provides design considerations, layout and routing guidelines,
and schematic diagrams)
The purpose of the reference design is to provide a comprehensive design encompassing every
Intel740™ graphics accelerator interface. The designer of another board may then modify this
design as needed since the basic hook-up will remain the same.
For the latest Intel740™ graphics accelerator information, please visit Intel’s website at:
http://developer.intel.com/design/graphics/740.htm
1.1 About This Design Guide
This design guide is intended for hardware designers who are experienced with PC architectures
and board design. The design guide assumes that the designer has a working knowledge of the
vocabulary and practices of PC hardware design.
•This chapter introduces the designer to the organization and purpose of this design guide and
provides a list of references and related documents.
•Chapter 2, "Addin Card Design"—This chapter provides a detailed set of Intel740™ graphics
accelerator design information for ATX and NLX graphics cards. The basis of the design
information is a reference ATX card design. Schematics for the reference design are provided
at the end of the chapter.
•Chapter 3, "3 DeviceAGP Motherboard Design"—This chapter provides design guidelines for
developing a motherboard based on the Pentium II®processor, Intel®440BX AGPset, and the
Intel740™ graphics accelerator. The main focus of this chapter is the guidelines for
developing a 3-point AGP solution with the Intel740 graphics accelerator and provides a
detailed set of design information for a 3-point AGP reference design (DS1P/440BX/I740).
Schematics for the reference design are provided at the end of the chapter.
•Chapter 4, "Thermal Considerations"—This chapter introduces the topic of thermal
considerations. See Application Note 653 in Appendix A for a comprehensive description of
thermal considerations.
•Chapter 5, "Mechanical Information"— This chapter provides mechanical information on Fan/
Heatsink, VMI Header Placement, Video Connector, brackets, and NLX considerations.
•Chapter 6, "Third Party Vendor Information"— This section includes information regarding
various third-party vendors who provide products to support the Intel 440BX AGPset and the
Intel740 graphics accelerator.
•Appendix A, "Application Notes"—This appendix contains Application Note 653, Thermal
Design Considerations. The application note provides a comprehensive guide to thermal
design
•Appendix B, "Reference Information"—This appendix provides reference information for
designing with the Intel740 graphics accelerator. The appendix contains information on

Introduction
1-2
Intel740™ Graphics Accelerator Design Guide
SDRAM/SGRAM Graphics SO-DIMM Modules. The appendix also contains information on
PC SGRAM specifications.
1.2 References
•Intel740™ Graphics Accelerator Datasheet: Contact your field sales representative (Literature
order #290618) or visit the Intel740™ Graphics Accelerator WEB page at:
http://developer.intel.com/design/graphics/740.htm
•Accelerated Graphics Port Interface Specification Rev 1.0: Contact www.agpforum.com
•Bt829A/Bt827A/Bt825A VideoStreamII Decoders Oct. 1996: Contact Rockwell*
Semiconductor
•Bt868/869 Flicker-Free Video Encoder with UltrascaleTM Technology: Contact Rockwell*
Semiconductor
•VMI 1.4 Interface Specification: Contact SGS Thompson Microelectronics
•PC ’98: Contact www.microsoft.com/hwdev
•PC SGRAM Specification: See Appendix B
•SO-DIMM Module Specification: See Appendix B
•Intel740™ Graphics Accelerator Application Note 653 - Thermal Design Considerations: See
Appendix A
•Intel 440BX AGPset Design Guide. Contact your field sales representative (Literature order
#290634). or visit the 440BX AGPSet WEB page at:
http://developer.intel.com/design/pcisets/designex/290634.htm

2
Intel740™ Graphics
Accelerator Addin
Card Design

Intel740™ Graphics Accelerator Design Guide 2-1
Addin Card Design
Addin Card Design
2
This chapter provides a complete package of design information for the Intel740™ graphics
accelerator. Usage of the Intel740™ graphics accelerator on an ATX and NLX graphics card is
discussed. The basis of this document is a reference ATX card.
2.1 Introduction
The reference design card described in this document contains the following features.
•ATX Form Factor
•Memory
— 100 MHz SDRAM or SGRAM
— SO-DIMM Memory Upgrade Socket
— 2,4 MB Solder-Down Option
•BIOS
— Support for Flash or ROM
— Capable of Supporting up to 256KB
•Monitor
— Hardware Support for DDC 2B
•Video
—Capture
— Bi-Directional VMI Video Port for DVD Hardware
— CCIR 601 8/16-bit Video Capture Port
— NTSC, PAL, and SECAM Inputs Accepted
— Intercast Capable
— Video-Conferencing Capable
— Output
— NTSC or PAL TV Output
— Flicker Free TV Output
— Overscan Compensation
— 50-Pin Video Connector
— S-Video In/Out
— Composite In/Out
—TVTuner
•I2C Programmability

Addin Card Design
2-2
Intel740™ Graphics Accelerator Design Guide
Table 2-1 lists the various functions capable of being supported by the reference card design. This
table describes which component is necessary for a specific feature. For hookup information, the
corresponding schematic page should be referenced.
Intel740™ Graphics Accelerator
2.1.1 Design Features
2.1.1.1 Intel740™ Graphics Accelerator
The Intel740™ graphics accelerator is the main component of the graphics reference design. This
component delivers high performance 3D/2D graphics and video capabilities. Each of the
interfaces are described below.
•Accelerated Graphics Port (AGP) Interface. The AGP interface is a new interface designed
for 3D graphics. This interface provides increased bandwidth over PCI, side band addressing,
and AGP memory 3D texture storage. For a more complete description of the AGP interface
refer to the Intel740™ Graphics Accelerator Datasheet and AGP Specification.
•Local Memory Interface. The memory interface on the Intel740™ graphics accelerator can
operate at speeds up to 100 MHz. An SDRAM interface supports SGRAM and SDRAM to be
used for different memory densities.
•VMI Interface. A bi-directional VMI like port is incorporated into the Intel740™ graphics
accelerator providing a mechanism for affordable DVD. Video capture is also supported using
the video port pins.
•TV Out Interface. Intel has worked with Rockwell* (Brooktree*) to design an interface
capable of supporting a high quality TV out chip. This interface allows the Intel740™ graphics
accelerator to output on a monitor, TV, or both.
•BIOS Interface. The Intel740™ graphics accelerator supports a FLASH or ROM BIOS. Up
to 256Kx8 can be supported.
•GPIO Interface. Nine GPIO signals exist on the Intel740™ graphics accelerator. GPIO[8:0]
allow for power management, DDC, I2C, thermal fault sensing, and other general features.
•DAC Interface. An integrated DAC provides display resolutions up to 1600x1200.
Table 2-1. Mix and Match Options For Intel740™ Graphics Accelerator Card
Component/
Functionality
Intel740™
Graphics
Accelerator
Page 3
BT829
Page 5 BT869 Page 6
DVD Chip/
Daughter
Card
Page 7
SO-DIMM
Module
Page 11
Memory
Components
Page 12
2D/3D X
Video Capture X X
TV Out X X
DVD (HW) X X
2 MB X (1) 256K x 64 (2) 256K x 32
4 MB X (1) 512K x 64
or
(2) 256K x 64
(2) 512K x 64
or
(4) 256K x 32
8 MB X (1) 1M x 64 (4) 1M x 16

Intel740™ Graphics Accelerator Design Guide 2-3
Addin Card Design
2.1.2 BT829B - Video Decoder
The Bt829B is a video capture processor used to convert analog video data into CCIR 601 digital
video data. This chip contains the following capabilities.
•Analog Inputs. The Bt829B contains four composite video inputs along with one chroma and
one luma input for s-video.
•I2C Interface. Control of the Bt829B is accomplished though the use of an I2C interface. All
of the chip’s registers are programmed using this interface as is the selection of the analog
input source to use in generating digital video data.
•Video Port. The Bt829B contains a video port capable of outputting 8 or 16 bit data. The data
format is YUV 4:2:2 with HSYNC, VSYNC, and PIXEL CLOCK as control signals.
2.1.2.1 BT869 - TV Encoder
The Bt869 provides high quality TV out. This component contains the following interfaces:
•Input Port. The Bt869 is capable of receiving data in two formats. The format used by this
reference design for receiving data is through the 24 bit digital port accepting data on both
edges of the reference clock. This mode of operation is documented in the Intel740™
Graphics Accelerator Datasheet. The second method for capturing data is through the use of
the VMI protocol. This interface is documented in the VMI 1.4 Interface Specification.
•Flicker Filter Output. The output of the Bt869 is a very high quality flicker filtered output.
This is due to a 5 tap internal filter. Output can be displayed in interlaced, non-interlaced,
PAL, or NTSC formats. Macrovision7 output is also supported in the Bt869 component. The
Bt869 is capable of displaying composite or S-Video data.
•I2C Interface. Control of the Bt869 is achieved through the I2C port.
2.1.3 Terminology
2.1.3.1 Power Sources
The card is supplied with four voltages through the edge connector. Other voltages are derived on-
board. Thus, the Power Layer of the board must be divided into several distinct planes. Table 2-2
lists the various power elements on the Intel740™ graphics accelerator reference design. Each of
the voltage sources are supplied by a plane except for 12 volts, which is supplied by a 25 mil trace.
Table 2-2. Intel740™ Graphics Accelerator Power Supplies
Schematic
Symbol Description Voltage Max Current Source
VDDQ3 3.3V AGP Supply +3.3V 8.0A Edge connector
VCC3 3.3V Logic Supply +3.3V 6.0A Edge connector
VCC 5V Logic Supply +5.0V 2.0A Edge connector
+12V 12V Supply +12V 1.0A Edge connector
VCC2 2.7V Core Supply +2.7V 3.0A VCC3, via Voltage Regulator
3VAA_BT869 3.3V Analog Supply +3.3V < 1.0A VCC3, via Ferrite Bead
AVCC 5V Analog Supply +5.0V < 1.0A VCC, via “fence”

Addin Card Design
2-4
Intel740™ Graphics Accelerator Design Guide
2.1.3.2 Fences
A “fence” is a line routed out of the plane such that a given area is isolated from the rest of the
plane except at a single point of contact, conceptually the “gate” in the fence. A fence will
minimize noise originating from digital signaling onto the analog signals. This provides higher
quality video for both the Bt829B and Bt869. An example of a fenced power plane is shown in
Figure 2-1. The heavy black line is the routed area. The width of the gate or opening can be up to
75% of the length of the IC in question. The width of the routed fence should conform to the
separation routing between power planes (i.e., 25 mils minimum).
2.1.3.3 Stitching
Power plane “stitching” is required between the VCC3 and VDDQ3 planes. Stitching two isolated
planes together with capacitors allows a current return path for high frequency signals which pass
over split power planes. This helps to eliminate EMI. The six 0.1 µF capacitors coupling VCC3 to
VDDQ3 should be spaced evenly if possible. Note the VDDQ3 plane is only near the AGP
connector. An example of stitching is shown in Figure 2-2. This figure illustrates the power planes
and, therefore, does not show signal traces between capacitors. The general rule for power plane
stitching is to have a capacitor placed between every four signals crossing the two planes. As an
example, there should be a capacitor, four signals, a capacitor, another four signals, and so forth
ending with a capacitor.
Figure 2-1. Example of Power Plane Separation ("fencing")
Fenced area
(e.g. AVCC)
Plane
(e.g. VCC)
“gate”
Routed “fence”
Overlying Chip
Figure 2-2. Example of Power Plane Stitching
cap
cap
cap
cap
IC
VDDQ3
VCC3

Intel740™ Graphics Accelerator Design Guide 2-5
Addin Card Design
2.2 Layout and Routing Guidelines
This chapter describes layout and routing recommendations to insure a robust design. These
guidelines should be followed as closely as possible. Any deviations from the guidelines listed here
should be simulated to insure adequate margin is still maintained in the design.
2.2.1 Placement
The ball connections on the Intel740™ graphics accelerator have been assigned to simplify routing
and keep board fabrication costs down by enabling a 4-layer design. Figure 2-3 shows the four
signal quadrants of the Intel740 graphics accelerator. Component placement should be done with
this general flow in mind. This will simplify routing and minimize the number of signals which
must cross. The individual signals within the respective groups have also been optimized to be
routed using only 2 PCB layers.
A complete list of signals and ball assignments can be found in the Intel740™ Graphics
Accelerator Datasheet.
Figure 2-3. Major Signal Sections
Intel740
Top View
Pin #1 Corner 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23
A
B
C
D
E
F
G
H
J
K
L
M
N
P
R
T
U
V
W
Y
AA
AB
AC
AD
AE
AF
A.G.P.
Quadrant
BIOS/Flicker
Quadrant VMI Port
Quadrant
Local Memory
Quadrant

Addin Card Design
2-6
Intel740™ Graphics Accelerator Design Guide
An example of the proposed component placement for an ATX form factor design is shown in
Figure 2-4. This is the placement used on the reference card. For NLX placement issues, refer to
Section 5.6, “NLX Considerations” on page 5-5.
ATX Form Factor:
•The example placement (Figure 2-4) shows the Bt829B, Bt869, SO-DIMM Module, Intel740
graphics accelerator, VMI Port connections along with a 50 pin video connector.
•The trace length limitation between critical connections will be addressed later in this
document.
•Figure 2-4 is for reference only. The choice of size of memory, whether to have an SO-DIMM
connector, what video components to place on the board, and which video connectors to have
on the bracket will have to be evaluated by the board designer.
2.2.2 Board Description
Even with the following recommendations, it is important to simulate your design.
A 4-layer stack-up arrangement is recommended. The stack-up of the board is shown in Figure 2-5.
The impedance of all the signal layers are to be between 50 and 80 ohms. Lower trace impedance
will slow signal edge rates, over & undershoot, and have less cross-talk than higher trace
impedance. Higher trace impedance will create faster edge rates and decrease signal flight times.
Prepreg is FR-4 material.
Figure 2-4. Example ATX Layout
Memory
SO-DIMM
Connector
Intel740
28F010
Flash
BIOS
VMI Port
Connectors
50 Pin
Connector
Bt869
VGA
Connector
Bt829B
Memory
Intel740™
Chip
