Intelix INT-IPSW1104 User manual

INT-IPSW1104 Installation Guide
Important notice:
• Do not attempt to disassemble or alter the housing. There are no user-serviceable parts
inside the unit. Doing so will void your warranty.
• To minimize the possibility of equipment damage from electrostatic discharge (ESD), all
source and destination equipment must be powered off during installation.
• Do not connect the device to a telecommunication outlet wired to unrelated equipment.
Doing so may damage the unit or any connected equipment. Ensure all connected twisted pair
cabling is straight-through (point-to-point).
• Allow proper ventilation to reduce the risk of thermal failure.

The Intelix INT-IPSW1104 is a four port 10/100BaseT Ethernet switch with PoE+
(up to 15w per downlink port). The switch features two operation modes:
Default and Isolate. In Default mode, the switch will pass data between all
downlink and uplink ports, similar to a standard Ethernet switch. In Isolate
mode, downlink ports will only communicate with the uplink port. The
INT-IPSW1104 includes a Kensington lock slot to prevent theft.
Front Panel
Rear Panel
123
A B C D
1. Isolate Active LED
2. Operation Mode Selection Switch
Default: Data will pass between all downlink and uplink ports
Isolate: Data will only pass from the individual downlink ports directly to the
uplink port.
3. Power LED
A. Power Input
B. 10/100BaseT Downlink Ports with Status LEDs
C. 10/100BaseT Uplink Port with Status LEDs
D. Ground Screw

Instructions
1. Verify all components included with the switcher are present before
installation.
2. Turn off power and disconnect the networking equipment by following
the manufacturer’s instructions.
3. If the switch will be sitting on a shelf, attach the supplied rubber feet to
the bottom of the product.
4. If the switch will be secured to a surface, attach the included mounting
brackets with the supplied screws. Secure the switch to the surface.
5. Optional: Secure a computer lock to the Kensington lock slot on the side of
the switch to prevent theft of the device.
6. Optional: Connect a wire from the switch to an earth ground to help
eliminate static shock between the switcher and connected network
devices.
7. Set the Operation Mode Selection Switch to either Default or Isolate mode.
When in Isolate mode, the green Isolate Active LED will be lit.
The switch must be powered off when altering the operation mode or the
changes will not activate even though the Isolate Active LED will change states.
8. Connect Category 5e or greater twisted pair cable with RJ45 connectors
between the switch and network devices. TIA/EIA-568B straight-through
wiring connections are highly recommended to limit potential interference.
9. Plug the power supply into the power input port of the switch. The red
Power LED will light when receiving power.
10. Power on attached network devices.
LED States
Uplink:
When an active network connection is detected, the green (left)
and amber (right) LEDs will light. The LEDs will flicker while
passing data.
Downlink:
When an active network connection is detected, the green
(right) LED will light. If an endpoint device requires Power over
Ethernet, the amber (left) LED will light. The green Link LEDs will
flicker while passing data.

rev 150420
8001 Terrace Ave, Ste 201
Middleton, WI 53562
608-831-0880
[e-mail]
Technical Specifications
Input/Output Connections
Ethernet Uplink One (1) 8P8C-F
Ethernet Downlink Four (4) 8P8C-F
DC Power 48V-57V at 1.25A One (1) Barrel (5.5 mm OD; 2.6 mm ID)
Ethernet Signal Characteristics
Maximum Distance 100m
Cable Requirements Solid core Category 5e, Category 6 or greater with TIA/EIA-568B
crimp pattern
Ethernet Standards IEEE 802.3/802.3u/802.3x/802.1p/802.1q
PoE Standards IEEE 802.3af/at (Type 1)
Backplane Bandwidth 1Gbps
Packet Forwarding Rate 0.75Mbps
Packet Buffer 768K
Chassis and Environmental
Enclosure Material Galvanized Steel
Enclosure Dimensions (H x W x D) 27 mm x 135 mm x 104 mm (1.06 in x 5.31 in x 4.05 in)
Shipping Weight 0.84 kg (1.85 lbs)
Operating Temperature 0° to +55° C (+32° to +131° F)
Operating Humidity 10% to 90%, Non-condensing
Storage Temperature -40° to +85° C (-40° to +185° F)
Storage Humidity 10% to 85%, Non-condensing
Power and Regulatory
Power Supply Input 100-240V AC / 50-60 Hz @ 2 A
Power Supply Output 54V DC at 1.1 A
Power Consumption ( <5W, PoE output <60W
ESD Protection ±15 kV
Product Regulatory CE, FCC, RoHS
Power Supply Regulatory CE, FCC, RoHS
Other
Warranty 2 years
Security Kensington Slot
Diagnostic Indicators Chassis: Power, Ethernet (2 ea), Isolate Mode
Uplink: Link Status (amber and green)
Downlink: Link Status (green), PoE Status (Amber)
Included Accessories Power supply, IEC power cable (US), Rubber feet (4 ea), Mounting
brackets (2 ea) with screws
Distances and picture quality may be affected by cable grade, cable quality, source and destination
equipment, RF and electrical interference, and cable patches.
