NVS30
Network Video Server
MPEG4 + Motion-JPEG Dual Mode, PoE, Audio
Update your surveillance network without the
cost of camera replacement.
The INTELLINET NETWORK SOLUTIONS™NVS30 Network Video Server
digitizes analog video and then transmits the signal across an IP network, such
as a LAN, intranet or the Internet. This allows you to take your first step in
implementing an IP-based system without having to install new network
cameras.
Model
550994

NVS30 Network Video Server
Model
550994
Auto-Setup
No need to worry about complex network setup procedures. The installation wizard provides an easy
setup that allows a non-technical person to begin using the camera right away.
SSL Encryption
Secure network connections using data encryption between the camera and the network client for
additional data security.
Dual Mode: Simultaneous MPEG4 + Motion-JPEG Streaming
The NVS30 Network Video Server supports MPEG4 as well as Motion-JPEG video formats, providing
superior quality and, at the same time, continuing to support existing applications. MPEG4, on the other
hand, allows you to transmit a larger amount of data over the same amount of bandwidth while providing
smooth and seamless viewing.
Bi-Directional Audio Support
Attaching a microphone and loudspeakers to the NVS30 Network Video Server will allow you to listen and
talk using the two-way audio support. On top of that, the camera is equipped with an internal microphone. This
is ideal for most security and surveillance applications.
Integrated DDNS Client
Utilize the free DYNDNS service (like DYNDNS.org) in order to connect to your camera, even if you do not
have a static IP address assigned by your ISP (Internet service provider). This feature lets you easily set up a URL
that can be used to access the camera through the Internet using any Web browser.
Unique Windows Live Messenger Support
Set up a free MSN / Hotmail account for the network camera and connect to it via Windows Live Messenger as
if it were a regular contact in your buddy list. Remote access cannot be any easier.
Power over Ethernet
The NVS30 Network Video Server supports the 802.3af standard, allowing it to be installed in locations
where an AC power source is not readily available. Simply plug the camera into a PoE-compliant switch and
begin transmitting power as well as data over the Cat5e or Cat6 network cabling.

Features
• Analog video BNC input and analog video BNC
loop-through port
• Excellent image quality with 30 fps full-motion
video in all resolutions
• Supports image resolutions up to 640 x 480 (VGA)
• Audio support, full duplex, up to 8 kHz, with
integrated microphone
• Video access through any standard Web browser
• Integrated motion detection with pre- and post-
alarm image/video buffering
• Event-triggered FTP and e-mail upload of still
images and videos
• External microphone input connector
• External speaker output connector
• Terminal block for external sensors or external
alarm devices
• Supports simultaneous MPEG4 and Motion-JPEG
image compression
• Selectable video buffer for smoother video streaming
• Controllable frame rate
• Supports MPEG4 video streaming with CBR
(constant bit rate) and VBR (variable bit rate) modes
• Mobile phone streaming live video through 3GPP/
ISMA/RTSP
• Mobile phone live image through 2.5 WAP
• Windows Live Messenger support
• Supports privacy zone and text overlay functionality
• MPEG4 + Motion-JPEG + 3GPP mobile phone
streaming, audio and 10x digital zoom
• Supports HTTPS encryption for enhanced security
• Supports UPnP with UPnP port forwarding capability
• Integrated e-mail, FTP, DDNS and DHCP client
• Supports IEEE 802.3af Power over Ethernet
injectors, mid- and endspans
• Supports Pan/Tilt/Zoom CCTV cameras
• Including Windows-based IP Installer and monitoring/
recording software for up to 16 cameras
• Three-Year Warranty
INT-550994-DS-1109-01
Copyright © INTELLINET NETWORK SOLUTIONS
All names of products or services mentioned herein are trademarks or registered trademarks of their respective owners. Distribution and reproduction of this document, and use and disclosure of
the contents herein, are prohibited unless specifically authorized.
For more information on INTELLINET NETWORK SOLUTIONS products,
consult your local dealer or visit
www.intellinet-network.com .
Specifications
NVS30 Network Video Server
STANDARDS
• IEEE 802.3 (10Base-T Ethernet)
• IEEE 802.3u (100Base-TX Fast Ethernet)
• IEEE 802.3af (Power over Ethernet)
GENERAL
• 32-bit ARM9 RISC CPU
• 8 MByte ash memory
• 64 MByte SDRAM
• Supported image resolutions:
- PAL: 704 x 576, 352 x 288 and 176 x 144
- NTSC: 704 x 480, 352 x 240 and 176 x
120
• Supported video compression formats:
- Motion-JPEG
- MPEG4 Part2 (ISO/IEC 14496-2), Prole: SP
• Video frame rate:
- Up to 30 fps at 704 x 480 (NTSC)
- Up to 25 fps at 704 x 576 (PAL)
• Audio support:
- Full duplex
- Bandwidth: G.711 PCM, 8 kHz, 64 kbit/s
- Microphone: built-in
- Audio input: 3.5 mm (1/8”) microphone
input jack
- Audio line out jack: 3.5 mm (1/8”)
• Uni- and Multicast
• 1 x BNC video input
• 1 x BNC video output
• 1 x alarm input (5 V / 12 V DC)
• 1 x alarm output (max. 30 W)
• RS485 port for PTZ control
• Protocols supported: TCP/IP, DHCP, PPPoE,
ARP, ICMP, FTP, SMTP, DNS, NTP, UPnP,
RTSP, RTP, HTTP, TCP, UDP, 3GPP/ISMA/
RTSP, Bonjour
• Certications: FCC Class B, RoHS, CE
NETWORK
• LAN connector: RJ45 port to connect to
10/100 Mbps Ethernet
USERS AND SECURITY
• 10 user accounts
• 3 different access levels: administrator,
operator and viewer
• Password-protected access to the video
streams, or access without password
• HTTPS (SSL v3)
POWER
• Housing: aluminum
• Dimensions: 110 (L) x 100 (W) x 45 (H) mm
(4.3 x 3.9 x 1.8 in.)
• Weight: 0.9 kg (2.0 lbs.)
• Operating temperature: -30 – 50°C
(-22 – 122°F)
• Operating humidity: 20 – 80% RH, non-
condensing
• Storage temperature: 0 – 60°C (0 – 149°F)
SYSTEM REQUIREMENTS
• Pentium 4 1.8 GHz (or equivalent AMD)
• 64 MB RAM video card
• Windows 2000, XP, Vista, Windows 7,
Linux, Mac OS X
• Computer with network connection
• Web browser support:
- MS Internet Explorer 5.0 or higher (ActiveX)
- Mozilla Firefox 3.x (Java)
- Safari (Java)
PACKAGE CONTENTS
• NVS30 Network Video Server
• User manual
• External power adapter
• Software CD
