Intellinet 503693 User manual

INT-503693-UM-0608-01
Wireless G
BroadBand
router
user
manual
MODEL 503693

Thank you for purchasing the INTELLINET NETWORK SOLUTIONS™
Wireless G Broadband Router, Model 503693.
The Wireless G Broadband Router allows you to conveniently share
your network connection with multiple users on your network — with
or without wires. It delivers 10/100 Mbps (auto-sensing) WAN and LAN
connections, and is interoperable with 54 Mbps (802.11g) and 11 Mbps
(802.11b) devices over a 2.4 GHz band wireless network. The WAN
connection wizard makes installation a snap.
Keeping intruders out of your network can be a challenge, and this
feature-rich wireless router is designed to make that challenge easier.
It includes a true rewall that secures your network against hackers.
With Network Address Translation (NAT) to shield your networked
devices from intruders, Denial of Service (DoS) attack prevention to
avert potential threats by scanning incoming trafc, and WEP, WPA and
WPA2 encryption to conceal your information on the wireless LAN from
eavesdroppers, you can rest assured that you’ve taken the necessary
precautions to protect the data on your network.
The easy-to-follow instructions in this user manual help make setup
and operation relatively simple, so you’ll soon be enjoying the benets
of these additional features:
• Compatible with all common DSL and cable Internet service providers
• Easy wireless setup through integrated site survey function
• Supports Wi-Fi Protected Setup (WPS)
• Supports WMM function to meet the multi-media data bandwidth
requirement
• Supports MAC ltering for wireless clients
• Supports Access Point mode and WDS (Wireless Distribution
System) mode
• Integrated 10/100 Mbps LAN switch with Auto MDI/MDI-X support
• DHCP server assigns IP addresses for all LAN users
• Supports DDNS (dynamic DNS)
• 68 Mbps WAN-to-LAN throughput for wired networks
• Content control through URL, IP and Port lter
• Remote management function (enable/disable and management port)
• Easy installation and rmware updates through a Web-based user
interface
• Lifetime Warranty
NOTE: For a quick install procedure, refer to the printed quick install
guide enclosed with this product.
2

safety & compliance statements
This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of Federal Communications
Commission (FCC) Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment to an outlet on a circuit different from the
receiver.
• Consult the dealer or an experienced radio/TV technician for help.
3

contents
1 HARDWARE.................................................................................5
1.1 Front Panel / LEDs ....................................... ..........................5
1.2 Rear Panel / Ports & Jacks......................................................5
1.3 System Requirements .................................. ..........................5
1.4 Connection the Router.................................. ..........................6
2 CONFIGURATION ........................................................................6
2.1 Login........................................................................................6
2.2 Wireless Settings.....................................................................7
2.2.1 Basic Settings .................................................................7
2.2.2 Wireless Advanced Settings...........................................7
2.2.3 Wireless Security Setup .................................................8
2.2.4 Wireless Access Control.................................................8
2.2.5 WDS Settings .................................................................9
2.2.6 Wireless Site Survey ......................................................9
2.2.7 Wireless EasyCong.......................................................9
2.3 TCP/IP Settings .....................................................................10
2.3.1 LAN Interface Setup .....................................................10
2.3.2 WAN Interface Setup....................................................10
2.4 Firewall .................................................................................. 11
2.4.1 Port Filtering.................................................................. 11
2.4.2 IP Filtering .................................................................... 11
2.4.3 MAC Filtering ................................................................ 12
2.4.4 Port Forwarding ............................................................ 12
2.4.5 URL Filtering.................................................................12
2.4.6 DMZ.............................................................................. 13
2.4.7 Anti-ARP Cheating........................................................ 13
2.5 Management.......................................................................... 13
2.5.1 Status............................................................................13
2.5.2 Statistics .......................................................................14
2.5.3 Dynamic DNS Settings ................................................. 14
2.5.4 Time Zone Settings ......................................................14
2.5.5 Denial of Service ..........................................................15
2.5.6 System Log................................................................... 15
2.5.7 Upgrade Firmware ........................................................16
2.5.8 Saave/Reload Settings .................................................16
2.5.9 Password Setup............................................................16
2.6 Logout ...................................................................................16
3 SPECIFICATIONS.............................................. ........................ 17
4

LED Status Description
PWR On Power is on.
Off Power is off.
CPU On The router is initializing.
Flashing The router is operating properly.
Off The router is experiencing a hardware error.
WL Flashing The wireless radio function is enabled.
Off The wireless radio function is disabled.
WAN On There is a device linked to the port, but no activity.
Flashing There is an active device linked to the port.
Off There is no device linked to the port.
1/2/3/4 On There is a device linked to the port, but no activity.
Flashing There is an active device linked to the port.
Off There is no device linked to the port.
1 hardWare
1.1 Front Panel / LEDs
The front panel of the Wireless G Broadband Router features several
LEDs for immediate indication of the device’s operational status.
1.2 Rear Panel / Ports & Jacks
The rear panel of the
Wireless G Broadband
Router features these ports
and jacks (left to right):
• Power adapter jack. NOTE: Only use the power adapter included
with the Wireless G Broadband Router, as a different adapter could
result in product damage.
• WAN RJ-45 port for connecting the router to a cable, DSL modem or
Ethernet.
• Four LAN 10/100 Mbps RJ-45 ports for connecting the router to local
PCs.
• Factory default reset button (recessed). NOTE: To reset to factory
defaults, rst turn the router on. Next, press in and hold the reset
button for approximately 20 seconds. Then release the reset button
and wait for the router to reboot.
1.3 System Requirements
Proper use of the Wireless G Broadband Router requires the following
system components and connections:
5

• Broadband Internet access service (DSL/cable/Ethernet)
• DSL/cable modem that has an RJ-45 connector (not needed if you
connect the router to the Ethernet)
• Each PC on the LAN needs a working Ethernet adapter and an
Ethernet cable with RJ45 connectors
• TCP/IP protocol must be installed on each PC
• Web browser, such as Microsoft Internet Explorer 5.0 or later,
Netscape Navigator 6.0 or later
Also, keep these guidelines in mind when positioning the router
before installation and operation:
• Don’t place it in direct sunlight or near a heater or heating vent.
• Keep at least 2 inches (5 cm) of space on all sides of the router.
• Keep the space well ventilated (especially if placed in a closet).
• Maintain the operating temperature and humidity as per specications
listed at the back of this user manual.
1.4 Connecting the Router
Before installing the router, connect your PC to the Internet through
your broadband service. (If there is any problem, contact your ISP.)
Then proceed through the following steps.
1. Turn off your PC(s), cable/DSL modem and the router.
2. Adjust the antenna. Normally, upright is a good place to start.
3. Connect the PC(s) and each switch/hub on your local area network
to the LAN ports on the router.
4. Connect the DSL/cable modem to the WAN port on the router.
5. Connect the power adapter between the power socket on the router
and an electrical outlet. The router will start to work automatically.
6. Turn on your PC(s) and the cable/DSL modem.
2 confiGuration
2.1 Login
Connect to the Wireless G Broadband Router by entering http://192.168.1.254
in the address eld of your Web browser. Once you’ve logged in, the
browser will display the administrator menu on the left-hand side of
the screen, with the ve conguration options — Wireless (Settings),
TCP/IP Settings, Firewall, Management and Logout — explained in
detail in the following sections.
6

2.2 Wireless Settings
2.2.1 Basic Settings
Band — The three options in the drop-down menu are “2.4 GHz (G)”
for 54 Mbps (802.11g); “2.4G Hz (B)” for 11 Mbps (802.11b); and
“2.4 GHz (G+B),” which allows both 802.11g and 802.11b wireless
stations to connect to the router.
Mode — The default is “AP”; options are “Client,” “WDS,” “AP+WDS.”
Network Type — The default is “Infrastructure”; when Mode is set to
“Client,” this should be set to “Ad Hoc.”
SSID — Enter a value of up to 32 characters. The same name
(SSID) must be assigned to all wireless devices in your network.
NOTE: The default SSID is “Kingnet,” but it’s recommended that you
change your network’s SSID to a different (case-sensitive) value.
Channel — It isn’t necessary to change the channel (1-13) unless you
notice interference problems with another nearby access point.
Associated Clients — Click to show active clients.
2.2.2 Wireless Advanced Settings
These settings are
only for more
technically advanced
users who have
sufcient knowledge
of wireless LAN.
These settings
should not be
changed unless you
know what effect the
changes will have
on your access
point.
7

2.2.3 Wireless Security Setup
Encryption — Select “None,” “WEP,” “WPA,” WPA2” or “WPA2 Mixed.”
• WEP: Wired Equivalent Protocol.
• WPA: WI-FI Protected Access (WPA) is an intermediate solution
for security issues. It uses Temporal Key Integrity Protocol (TKIP)
to replace WEP.
WPA Authentication Mode — “Enterprise” uses an external
authentication server (e.g., RADIUS) and EAP just as IEEE 802.1X
does; “Personal” uses pre-shared keys without the need for additional
servers. Both options will generate a master session key for the
authenticator (AP) and supplicant (client station).
WPA Cipher Suite/WPA2 Cipher Suite — Choose either TKIP or AES.
Pre-Shared Key Format — Select passphrase or hex characters.
Pre-Shared Key — Enter up to 128 characters.
Authentication RADIUS Server — Enter a port, IP address and
password.
2.2.4 Wireless Access Control
Wired Access Control Mode — If you choose “Allowed Listed” from the
drop-down menu, only those clients whose wireless MAC addresses
8

are on the access control list will be able to connect to your access
point. When”Deny Listed” is selected, these wireless clients on the
list will not be able to connect to the access point.
2.2.5 WDS Settings
Wireless Distribution System uses wireless media to communicate with
other APs, as the
Ethernet does. To
do this, you must
set these APs in
the same channel
and set the MAC
address of other
APs you want to
communicate with
in the table and
then enable the Wireless Distribution System.
2.2.6 Wireless Site Survey
This screen lets
you scan the
wireless network.
If any access point
or IBSS is found,
you could choose
to connect it
manually when
Client mode is enabled.
2.2.7 Wireless EasyCong
This screen lets you change the setting for EasyCong, a feature that
allows your wireless
client to automatically
synchronize its setting
and connect to the
access point in a minute
without any hassle.
9

2.3 TCP/IP Settings
2.3.1 LAN Interface Setup
IP Address — Enter the IP address of your router in dotted-decimal
notation (factory default = 192.168.1.254).
Subnet Mask — This determines the size of the network, and would
normally be set to 255.255.255.0.
DHCP — Drop-down options are “None,” “Client” and “Serve.” The
router is set up by default as a DHCP (Dynamic Host Conguration
Protocol) server, which provides the TCP/IP conguration for all the
PCs connected to the router on the LAN.
DHCP Client Range — Specify the rst and nal addresses in the IP
address pool range.
802.1d Spanning Tree — Select “Enabled” or “Disabled.”
Clone MAC Address — Enter a MAC address, then click “Apply.”
2.3.2 WAN Interface Setup
WAN Access Type — The drop-down menu lets you choose among
“Static IP,” “DHCP,” “PPPoE” and “PPTP.” Each option displays a
corresponding list of further options (IP address, subnet mask, server
IP address, username and password can be obtained from your
ISP, if necessary), including those below.
10

Connection Type — Select “Continuous,” “Connect on Demand” or
“Manual.”
Idle Time — When the connection type is set to “Connect on Demand,”
you can set the idle time.
MTU Size — The normal MTU (maximum transmission unit) value for
most Ethernet networks is 1492 Bytes. For some ISPs, you need to
reduce the MTU. This is rarely required, however, and shouldn’t be
done unless you’re sure it’s necessary for your ISP connection.
DNS — Select “Attain DNS Automatically” or “Set DNS Manually.”
Clone MAC Address — Enter a MAC address, then click “Apply.”
Enable UpnP — The Universal
Plug and Play (UPnP) feature
lets devices access the local host
resources or devices as needed.
UPnP devices can be automatically
discovered by the UPnP service
application on the LAN.
2.4 Firewall
2.4.1 Port Filtering
Entries on this screen
are used to restrict
certain types of data
packets from your
local network to the
Internet through the
gateway. Using such
lters can be helpful
in securing/restricting
your local network.
Enable Port Filtering — Select to modify the port lter.
Port Range — Enter the lter port range; for example, 20-220.
Protocol — Select “TCP,” “UDP” or “Both.”
Current Filter Table — This displays the list of port lters.
2.4.2 IP Filtering
Similar to Port Filtering (above), with similar options.
Enable IP Filtering — Select to modify the IP lter.
Local IP Address — Enter the lter IP address(es); for example,
192.168.1.23.
Protocol — Select “TCP,” “UDP” or “Both.”
Current Filter Table — This displays the list of IP lters.
11

2.4.3 MAC Filtering
Similar to Port and IP Filtering (above), with similar options.
Enable MAC Filtering — Select to modify the MAC lter.
MAC Address — Enter the MAC address; for example, 00:e0:4e:3f:2d:c5.
Protocol — Select “TCP,” “UDP” or “Both.”
Current Filter Table — This displays the list of MAC lters.
2.4.4 Port Forwarding
Entries on this
screen allow you
to automatically
redirect common
network services to
a specic machine
behind the NAT
rewall. These
settings are only
necessary if you
wish to host some sort of server, like a Web server or mail server on
the private local network behind your gateway’s NAT rewall.
Enable Port Forwarding — Select to enable the function.
IP Address — The IP address of the PC running the service application.
Protocol — Select “TCP,” “UDP” or “Both.”
Port Range — Enter the number(s) of the external port(s). Whether it’s
a single service port or a range of service ports, the format is XXX –
YYY, where XXX is the start port and YYY is the end port).
Current Port Forwarding Table — This displays the list of port
forwarding services.
2.4.5 URL Filtering
A URL lter is used
to deny LAN users
access to the
Internet. Once
selected, this lter
function lets you
use specic
keywords to block
associated URLs.
Enable URL Filtering — Select to enable the function.
URL Address — Enter a specic address to block; e.g., xxx.com.
12

2.4.6 DMZ
The DMZ host feature
allows one local host
to be exposed to the
Internet for a special-
purpose service, such
as Internet gaming or
videoconferencing.
DMZ Host forwards
all the ports at the same time. Any PC whose port is being forwarded
must have its DHCP client function disabled and should have a new
static IP address assigned to it because its IP address may change
when using the DHCP function.
DMZ Enable — Select to enable the function.
DMZ Host IP Address — Enter an IP address; e.g., 192.168.1.34.
2.4.7 Anti-ARP Cheating
On this screen, you
can set the device
to send packets to
other hosts to refresh
their ARP (address
resolution protocol)
cache. You can also
add static IP-MAC
address entries to
local ARP caches.
Use of this function
can be helpful in preventing ARP viruses or fake MAC addresses.
2.5 Management
2.5.1 Status
This screen shows the
current status — and
some basic settings of
— the device, such as
System Information,
LAN Interface
Information and WAN
Interface Information.
13

2.5.2 Statistics
This screen displays
the packet counters
for transmission and
reception as regards
to wireless and
Ethernet networks.
2.5.3 Dynamic DNS Settings
Dynamic DNS is a service that provides you with a valid, unchanging
Internet domain name (URL) to go with your (possibly ever-changing)
IP address. DDNS lets you assign a xed host and domain name to
a dynamic Internet IP address. It is useful when you are hosting your
own Web site, FTP server or other server behind the router. Before
using this feature, you need to sign up with a DDNS service provider,
such as www.oray.net or www.comexe.cn. The Dynamic DNS client
service provider will give you a password or key.
To set up for DDNS:
1. Enter your service provider.
2. Enter the username for your DDNS account.
3. Enter the password for your DDNS account.
4. Domain Name: The domain names are displayed here. Click
“Apply Changes” to log out of the DDNS service.
2.5.4 Time Zone Settings
You can maintain the system time by synchronizing with a public time
server over the Internet.
Current Time — Enter the date and time.
Time Zone Select — Select your local time zone from the drop-down
list.
14

Enable NTP client update — Select to get the time from NTP (Network
Time Protocol).
NTP server — Select a server from the drop-down menu.
Click “Apply Change” to get the time from the Internet (if connected).
2.5.5 Denial of Service
A denial-of-service
(DoS) attack is
characterized by an
explicit attempt by
hackers to prevent
legitimate users of a
service from using
that service.
Enable DOS
Prevention — Select
to modify the
function.
Enable Source IP
Blocking — Enter a source IP blocking time.
2.5.6 System Log
This screen displays
the system log and
can be used to set
the remote log server.
15

2.5.7 Upgrade Firmware
This screen lets
you upgrade the
AP rmware.
NOTE: Do not
power off the
device during the
upload, as doing
so may crash the
system.
2.5.8 Save/Reload Settings
This screen lets
you save current
settings to a le or
reload the settings
from the le which
was saved
previously. You
can also reset the
current conguration
to factory default settings.
2.5.9 Password Setup
On this screen, you
can set up the
account to access
the Web server of
the access point.
NOTE: Empty elds
for “User Name” or
“Password” disables
the protection.
2.6 Logout
This screen is used to log out.
Browse...
Browse...
16

3 specifications
Standards
• IEEE 802.1d (Spanning
Tree Protocol)
• IEEE 802.1x (Wireless User
Authentication)
• IEEE 802.11b (11 Mbps
Wireless LAN)
• IEEE 802.11g (54 Mbps
Wireless LAN)
• IEEE 802.3 (10Base-T
Ethernet)
• IEEE 802.3u (100Base-TX
Fast Ethernet)
General
• LAN ports: 4 RJ-45 10/100
Mbps data ports
• LAN ports withAuto MDI/
MDI-X
• LAN to WAN throughput:
68 Mbps
• Certications: FCC Class B,
CE Mark, RoHS
Router
• Chipset: Realtek RTL8186
• Supported WAN connection
types:
- Dynamic IP (DHCP for
cable service)
- Static IP
- PPPoE (for DSL)
• Protocols:
- CSMA/CA
- CSMA/CD
- TCP/IP
- UDP
- ICMP
- PPPoE
- NTP
- NAT
- DHCP
- DNS
• NAT: Port forwarding
• Firewall:
- Port lter
- IP lter
- Access control based on .
MAC address
- URL lter
- DMZ (demilitarized zone)
- Anti-ARP Cheating
• Supports:
- UPnP (Universal Plug and
Play)
- DHCP (client/server)
- PPPoE (DSL), DHCP
(cable) and static IP
- VPN PPTP, L2TP and
IPsec pass-through
Wireless
• Chipset: RTL8225
• Wireless frequency range:
2.412 - 2.484 GHz
• Modulation technologies:
- 802.11b: Direct Sequence
Spread Spectrum (DSSS):
DBPSK, DQPSK, CCK
- 802.11g: Orthogonal
Frequency Division Multi-
plexing (OFDM): BPSK,
QPSK, 16QAM, 64QAM
• Number of channels: 11
• Data rates:
- IEEE 802.11b (11 Mbps,
5.5 Mbps, 2 Mbps, 1 Mbps)
- IEEE 802.11g (54 Mbps,
48 Mbps, 36 Mbps, 24 Mbps,
18 Mbps, 12 Mbps, 9 Mbps,
6 Mbps)
• Output power:
- OFDM: 15 dBm +/- 1 dBm
(54 Mbps, 50 mW max.)
- CCK: 15 dBm +/- 1 dBm
(11 Mbps, 50 mW max.)
• Max. coverage distance:
100 m / 300 ft. (indoor),
300 m / 900 ft. (outdoor)
• Wireless security:
- WEP encryption (64/128 bit)
- WPA (TKIP and AES)
- WPA2 (TKIP and AES)
- Client access control thru
MAC lter
• Antenna: single dipole,
2 dBi gain
LEDs
• Power
• CPU (operational status)
• WL (Wireless)
• WAN Link/Act
• LAN 1-4 Link/Act
Environmental
• Dimensions: 169 (W) x 108
(L) x 180 (H) mm (6.6 x 4.3
x 7.0 in.)
• Weight: 0.8 kg (1.8 lbs.)
• Operating temperature: 0 –
55°C (32 – 122°F)
• Operating humidity: 10 –
95% RH, non-condensing
• Storage temperature: 0 –
60°C (0 – 149°F)
Power
• External power adapter:
9.0 V DC, 0.8 A
• Power consumption:
6.3 Watts max.
Package Contents
• Wireless G Broadband Router
• User manual
• Power cord
• Ethernet Cat5 RJ-45 cable,
0.8 m (2.6 ft.)
17

INTELLINET NETWORK SOLUTIONS™offers a complete line
of active and passive networking products.
Ask your local computer dealer for more information or visit
www.intellinet-network.com.
Copyright © INTELLINET NETWORK SOLUTIONS
All products mentioned are trademarks or registered trademarks of their respective owners.
